85102B-01
SERVICE NOTE
SUPERSEDES: None
85102B IF DETECTOR
Serial Numbers: See below
New J1 Molex connector on the old A26 Rectifier Board
Duplicate Service Notes:
85102A Serial Numbers: 0000A00000 / 9999Z99999
85102B Serial Numbers: 0000A00000 / 3901A07250
85102R Serial Numbers: 0000A00000 / 3901A00743
To Be Performed By: Agilent-Qualified Personnel
Parts Required:
P/N Description Quantity
85102-60278 Kit-Repair 1 (Not require for solution Number 1.)
Situation:
The above model and serial numbers have an old design for J1 Molex connector on the old
A26 Rectifier Board which is not able to handle the total current requirement for the
85102A/B/R over its lifetime.
Agilent redesigned the A26 rectifier board, which includes the protection circuitry and new J1
Molex connector, enhancing the reliability.
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
MODIFICATION AVAILABLE
ACTION
CATEGORY:
AGREEABLE TIME
Continued
DATE: August 1999
PERFORMANCE ENHANCEMENT
SERVICE/RELIABILITY ENHANCEMENT
LOCATION
CATEGORY:
AUTHOR:
AP
CUSTOMER INSTALLABLE
ON-SITE
SERVICE CENTER
ENTITY:
5340
© 1999 AGILENT TECHNOLOGIES
PRINTED IN U.S.A.
AVAILABLE UNTIL:
End of product life
ADDITIONAL INFORMATION:
1 of 2
Page 2 Service Note 85102B-01
Solution:
There are two methods to solve this problem:
1. Unplug J1 Molex connector from the old A26 Rectifier Board then solder each of the six
wires to its corresponding pin.
2. Order the retrofit kit (p/n. 85102-60778) which will replace the old A26 board with the
new redesigned A26 board.
