Input 1
Frequency Range: 500 MHz to 26.5 GHz
Sensitivity
500 MHz - 12.4 GHz: -32 dBm (-35 dBm typical)
12.4 GHz - 20.0 GHz: -27 dBm (-32 dBm typical)
20.0 GHz - 26.5 GHz: -20 dBm (-27 dBm typical)
Agilent Technologies
5348A 26.5 GHz Microwave
Counter/Power Meter
Data Sheet
Maximum Input: +7 dBm
Damage Level: +25 dBm, peak
SWR
500 MHz - 12.4 GHz: <2:1 typical
12.4 GHz - 20.0 GHz: <3:1 typical
20.0 GHz - 26.5 GHz: <3:1 typical
Accuracy: ±1 LSD ±time base error x frequency
Resolution: 1 Hz or 10 kHz, selectable
Optional Increased Damage Level Option 006
Protects Input 1 from damage by limiting high level signals.
All specifications are the same except Input 1.
Damage Level
500 MHz to 6 GHz: +39 dBm (8 watts)
6 GHz to 18 GHz: +36 dBm (4 watts)
18 GHz to 26.5 GHz: +34.8 dBm (3 watts)
Sensitivity reduced by
3 dBm, 500 MHz to 12.4 GHz
4 dBm, 12.4 GHz to 20.0 GHz
5 dBm, 20.0 GHz to 26.5 GHz
Input 2
Frequency Range: 10 Hz - 525 MHz
Sensitivity: 25 mV rms (15 mV rms typical)
Impedance: 1 Mohm nominal shunted by <70 pF (10 Hz to 80 MHz) or 50 Ù nomimnal (10 MHz to 525 MHz)
Damage Level: 50Ù or 1 MÙ
dc - 5 kHz: 250V (dc + ac peak)
>5 KHz: 5.5V rms (+28 dBm) + 1.25 x 106 V rms/FREQ
Accuracy: ±1 LSD ±[(1.4 x Trigger Error/Gate Time)±Time Base Error] x frequency
Resolution: 1 Hz or 10 kHz, selectable
Automatic Amplitude Discrimination
Automatically measures the largest of all signals present, provided that signal is >6 dB (typical) above any signal within
500 MHz ; >20 dB (typical) above any signal within 500 MHz to 26.5 GHz.
Tracking Speed
Resolution = 1 Hz, Speed = 1 MHz/sec
Resolution = 10 kHz, Speed = 1 GHz/sec
Acquisition Time
Resolution = 1 Hz, Time = <125 ms
Resolution = 10 kHz, Time = <60 ms
Maximum Deviation
20 MHz p-p, Automatic mode
60 MHz p-p, Manual mode (via HP-IB only)
Maximum FM Rate: 10 MHz
AM Tolerance: Any modulation index provided the minimum signal level is not less than the sensitivity specification.
Power Meter Specifications
Frequency Range: 0 MHz to 26.5 GHz, sensor dependent
Power Range: -70 to +20 dBm (100 pW to 100 mW), sensor dependent
Dynamic Range: 50 dB in 10 dB steps
Resolution: 0.01 dB in logarithmic mode, 0.1% of full scale in linear mode.
Auto Filter: The meter automatically selects the required number of averages for the selected range.
Accuracy
Instrumentation: ±0.02 dB or ±5%
Zero Set (digital settability of zero): ±5% of full scale on most sensitive range. Decrease percentage by a factor of 10
for each higher range, ±1 display count.
