In This Manual
Agilent 4155C/4156C provides three command modes to control the 4155C/4156C
via GPIB interface. You can control the 4155C/4156C using one of the following
command modes.
• 4155/4156 SCPI command mode
SCPI means Standard Commands for Programmable Instruments. This mode is
the default mode of the 4155C/4156C, and allows you to control all functions of
the 4155C/4156C.
• 4155/4156 FLEX command mode
FLEX means Fast Language for EXecution. This mode allows you to control
measurement functions of the 4155C/4156C. Command execution is faster than
the SCPI command mode.
• 4145 syntax command mode
This mode allows you to execute the 4145A/B programs on the 4155C/4156C
directly with little or no modification. In this command mode, you cannot
control all functions of the 4155C/4156C.
To confirm the present control mode, see the language mode indicator on the screen,
or enter the CMD? command.
Language mode
indicator The indicator is located between the fourth primary softkey and
the fifth primary softkey, and next to the screen lock indicator.
The meaning of the indicator is as follows:
S: SCPI command mode
F: FLEX command mode
4: 4145 syntax command mode
CMD? command This query command returns the present command mode. The
response is as follows:
0: SCPI command mode
1: FLEX command mode
2: 4145 syntax command mode
This command is effective for all command mode.
Agilent 4155C/4156C SCPI Command Reference, Edition 1 5
This manual describes about the 4155C/4156C SCPI command set, and consists of
the following chapters:
• Functional Syntax Conventions
Explains the functional syntax required to create program messages that are
transmitted to a 4155C/4156C.
• Response Message Syntax
Explains the syntax of the response messages from the 4155C/4156C.
• Status Reporting Structure
Explains the status reporting structure of the 4155C/4156C.
• Common Commands
Lists SCPI common commands available for the 4155C/4156C, and provides
description, command syntax, example statements, and so on.
• SCPI Commands
Lists device specific SCPI commands of the 4155C/4156C, and provides
description, command syntax, example statements, and so on.
• Error Messages
Lists the 4155C/4156C error messages, and provides error number, error
message and description.
For information about the 4155C/4156C FLEX command set and the 4145 Syntax
command set, refer to GPIB Command Reference.
See User's Guide General Information and User's Guide Measurement and Analysis
for information about the 4155C/4156C itself.
Refer to Programmer's Guide to make a program and use built-in Instrument
BASIC.
Text Conventions
The following text conventions are used in this manual:
Screen Text Represents text that appears on screen of the 4155C/4156C.
Italic Refers to a related document, or is used for emphasis.
6 Agilent 4155C/4156C SCPI Command Reference, Edition 1
