Specifications: m B-K1670A odel 1670A
Output Voltage
Output Current
Constant Voltage Operation
Voltage Regulation
Line (120 VAC +- 10%) <= 0.05% + 10 mV
Load <= 0.05% + 10 mV
Recovery Time 100us
Ripple & Noise <= 5 mV rms
Temperature Coefficient <= 300 ppm 0 C
Constant Current Operation
Adjustable Current Range 5% to 100% (main output only)
Current Regulation
Line (120 VAC +- 10%) <= 0.4% + 10mA (main output only)
Load <= 0.4% + 10mA (main output only)
Current Ripple <= 10 mA rms
Metering
Display 2 digital Three Digit LCD
Voltmeter Range 0 to 12 VDC 0 to 5 VDC
Voltmeter Accuracy +- (1% of reading + 2 digits)
Ampmeter Range 0 - 3 A
Ampmeter Accuracy +- (1% of reading + 2 digits)
Overload Protection Current limiting, Reverse polarity protection, Short
Power Requirements 108 - 132 VAC, 60 Hz
Power Consumption 200W
Operating Temperature 0 0 to 40 0 C <=75% R.H.
Storage Temperature -15 0 to 70 0 C <= 85% R.H.
Dimensions (HxWxD) 4.9''x8.5''x11.5'' (124x216x292 mm)
Weight 11.5 lbs. (5.2 kg)
Accessories
SUPPLIED: Instruction Manual
OPTIONAL (for all models): TL-SA Hook up cables.
Main Output 0 to 30 VDC
Fixed 12VDC (+- 5%)
Fixed 5 VDC (+-5%)
Main Output 0 to 3 A
Fixed 0-500 mA continuous
Fixed 0-500 mA continuous
<= 1% (second and third output)
<= 1% (second and third output)
circuit
