MANUALCHANGES
HP 16074A
Calibration R-L Standard
Operating Note
This supplement contains information for correcting manual errors and for adapting the manual to newer Instruments that contains
Improvements or modifications notdocumented Inthe existing manual.
To use this SUl'plement
1. Make all ERRATAcorrections
2. Make all appropriate serial-number-related changes listed below
SERIAL PREAX OR NUMBER MAKEMANUAL CHANGES
All
All
All
.New Item
Change 1
Change 2
Change 3
SERIAL PREAX OR NUMBER MAKE MANUAl CHANGES
MANUALIDENTIFICATION
Model Number: HP 16P74A
Date Printed: May 1986
Part Number: 16074-90000
Change 1
Page 1t Section 5 Quasi-Inductance Standards
.-
Change section 5 as follows:
The HP 16074A's quasi-inductance standard consists of two resistors and a capacitor, and it acts as an inductor when it
is measured with HP four-terminal pair LCR meters. Figure 1 shows the quasi-inductance standard's structure and an
equivalent impedance when the quasi-inductance Standard's l00#H (or 100 mB) terminals are connected to an HP
LCR meter. 100rnH(100pl-OTerminals
~ L---.
Z =Rs + jwLs
Rs: R,+ R2
Ls: CR,R2
j : ImaginalYUnit
w: AngularFrequency
'-- H---'
(C-(;AUTenrinals .
Figure 1.Quasi-Inductance Standard Structure
Manual change supplement are revised as often as neceSS8ly to keep manuals as current and accurate as possible. Hewlett-Packard
recommends 'that you periodically ~uest the latest edition of this supplement. Free copies are available frOmallHPoffices. 'Nhen
requesting Copies, quote the manual identification Information from your supplement, or the model number and print date from the title
page of the manual.
NOTE
Date/DiY: September,1991/33
