2050/60 X-Series
Wide Dynamic Range
Power Sensors
This document provides security information
for the following instruments:
U2051XA/U2052XA/U2053XA/U2054XA/U2055XA
U2061XA/U2062XA/U2063XA/U2064XA/U2065XA
L2051XA/L2052XA/L2053XA/L2054XA/L2055XA
L2061XA/L2062XA/L2063XA/L2064XA/L2065XA/L2065XT
Security
Features and
Document of
Volatility
Notices
© Keysight Technologies, Inc.
2019-2020
No part of this manual may be
reproduced in any form or by any
means (including electronic
storage and retrieval or translation
into a foreign language) without
prior agreement and written
consent from Keysight
Technologies, Inc. as governed by
United States and international
copyright laws. The information
found in this manual is subject to
change without notice.
Document Part Number
5992-4311EN
Print Date
November 2020
Supersedes: July 2020
Published in USA
Keysight Technologies Inc.
1400 Fountaingrove Parkway
Santa Rosa, CA 95403
2
Table of Contents
Contacting Keysight Sales and Service Offices ............................................................................................................ 4
Products Covered by this Document ............................................................................................................................. 5
Instrument Memory ........................................................................................................................................................ 6
3
Contacting Keysight Sales and Service Offices
Assistance with test and measurement needs, and information on finding a local Keysight office, is
available on the Internet at:
http://www.keysight.com/find/assist
If you do not have access to the Internet, please contact your field engineer.
In any correspondence or telephone conversation, refer to the instrument by its model number
and full serial number. With this information, the Keysight representative can determine whether
your unit is still within its warranty period.
4
Products Covered by this Document
Product Family Name
Product Names
Model Numbers
Power Sensors
2050/60 X-Series Wide Dynamic Range Power
U2051XA, U2052XA, U2053XA, U2054XA, U2055XA,
Sensors
U2061XA, U2062XA, U2063XA, U2064XA, U2065XA,
L2051XA, L2052XA, L2053XA, L2054XA, L2055XA, L2061XA,
L2062XA, L2063XA, L2064XA, L2065XA and L2065XT
This document describes instrument security features and the steps to declassify an instrument through
memory clearing, sanitization or removal.
For additional information, go to:
http://www.keysight.com/find/security
Be sure that all information stored by the user in the instrument that needs to be saved is
properly backed up before attempting to clear any of the instrument memory. Keysight
Technologies cannot be held responsible for any lost files or data resulting from the clearing of
memory. Be sure to read this document entirely before proceeding with any file deletion or
memory clearing.
5
Memory Type: Flash
Memory Size: 1024 Megabit
Bank 0 (256 Megabit)
Memory Function: Contains the instrument firmware
Memory Function: Not used
Bank 2 (256 Megabit)
Memory Function
Bank 3 (256 Megabit, only first half (128 Megabit) is used, second half (128 Megabit) is not used)
Memory Function: Contains User saved setup information such as: save/recall, frequency-dependent offset tables
only)
Instrument Memory
This section contains information on the types of memory available in your instrument. It explains the size
of memory, how it is used, its location, volatility, and the sanitization procedure.
User Modifiable (Y/N): N Removable (Y/N): N Volatile (Y/N): N
Memory Erase Processes:
- No user settable information in this memory
- No inherent security risk in this memory
Bank 1 (256 Megabit)
: Not used
User Modifiable (Y/N): Y (first half (128 Megabit)
Memory Erase Processes:
- REMOTE IO COMMAND : SERVice:SECure:ERASe does the following to the entire 256 Megabit:
o All memory locations are overwritten by
Writing each location with all zeros
Writing each location with a single character
o The entire memory bank is erased
The memory is erased in compliance with the manufacturers datasheet
The memory is reformatted to re-initialize the internal file system
Any factory-default file content is restored
- After that, user can try to read back save/recall states or FDO tables to verify the erase process is
completed
Removable (Y/N): N Volatile (Y/N): N
6
Memory Type: EEPROM #1 (Analogue Board)
Memory Size: 128 Kilobit
Memory Function: Contains basic instrument configuration information such as: model number, serial number,
calibration date and place, sensor calibration data, sensor type and tracking number
User Modifiable (Y/N): N
Removable (Y/N): N
Volatile (Y/N): N
Memory Erase Processes:
Memory Type: EEPROM #2
Memory Size: 128 Kilobit
FPGA board information.
User Modifiable (Y/N): N
Removable (Y/N): N
Volatile (Y/N): N
Memory Erase Processes:
- No user setup information contained in this memory.
- When the instrument is turned on, all the information is downloaded from the EEPROM to be used by the
instrument.
- The EEPROM is not user-accessible via the remote interface.
- No inherent security risk in this memory
Memory Function: Contains basic instrument configuration information such as: model number, serial number and
- No user setup information contained in this memory.
- When the instrument is turned on, all the information is downloaded from the EEPROM to be used by the
instrument.
- The EEPROM is not user-accessible via the remote interface.
- No inherent security risk in this memory
7
Memory Type: EEPROM #3
Memory Size: 128 Kilobit
Memory Erase Processes:
Memory Type: SDRAM
Memory Size: 1024 Megabit
User Modifiable (Y/N): N
Removable (Y/N): N
Volatile (Y/N): Y
Memory Erase Processes:
Memory Function: Contains measurement logic and board control logic.
User Modifiable (Y/N): N
Removable (Y/N): N
Volatile (Y/N): Y
Memory Erase Processes:
Memory Function: Contains basic instrument configuration information such as: part number, serial number and RF
assembly information
User Modifiable (Y/N): N Removable (Y/N): N Volatile (Y/N): N
- No user setup information contained in this memory.
- When the instrument is turned on, all the information is downloaded from the EEPROM to be used by the
instrument.
- The EEPROM is not user-accessible via the remote interface.
- No inherent security risk in this memory
Memory Function: Random Access Memory that temporary stores sensor’s information such as correction data
upon power up
- Data stored in SDRAM is erased when device is powered down.
Memory Type: FPGA Memory Size: 4824 Kilobit
- Data stored in FPGA is erased when device is powered down.
