Keysight Streamline Series VNA
The freedom of portable network analysis doesn’t have to mean a compromise in performance. The B-models of
the Keysight Streamline Series VNAs unlock the full performance of the network analyzer hardware with fast
measurements over Thunderbolt 3 connections to your host PC. Gain confidence in your measurements with
best-in-class performance offering fast, reliable, and repeatable results. Explore the complete characterization of
your devices with a rich portfolio of software applications that transform the compact network analyzer into a
complete RF measurement solution.
The P50xxB Series offers the performance required for testing passive components, amplifiers, mixers or
frequency converters. The vector network analyzer (VNA) provides best-in-class key specifications such as
dynamic range, measurement speed, trace noise and temperature stability. Choose from 2- or 4-port models up
to 53 GHz, or 6-port models up to 20 GHz.
The P93xxB Series provides excellent performance in general-purpose network analysis for passive
components. With software applications like enhanced time domain analysis with TDR and automatic fixture
removal, you can easily characterize passive components with the same performance of a benchtop setup.
Choose from 2-port models up to 44 GHz or 4-port models up to 20 GHz.
The Streamline Series utilizes the same measurement science as other Keysight VNAs such as the PNA, ENA
and PXI VNA. A common software platform makes it easy to choose the right level of performance to match
budget and measurement needs. This commonality guarantees measurement consistency, repeatability, and a
common remote-programming interface across multiple instruments in R&D and manufacturing.
This configuration guide describes standard configurations, options, accessories, and compatible peripherals for
the P93xxB and P50xxB Keysight Streamline Series vector network analyzer (VNA).
Find us at www.keysight.com Page 4
P93xxB and P50xxB Configurations
Model 1
Description
Test port connectors
P937xB Series
P9370B
9 kHz to 4.5 GHz, 2-port
3.5 mm (f)
P9371B
9 kHz to 6.5 GHz, 2-port
3.5 mm (f)
P9372B
9 kHz to 9 GHz, 2-port
3.5 mm (f)
P9373B
9 kHz to 14 GHz, 2-port
3.5 mm (f)
P9374B
9 kHz to 20 GHz, 2-port
3.5 mm (f)
P9375B
100 kHz to 26.5 GHz, 2-port
3.5 mm (f)
P9377B
100 kHz to 44 GHz, 2-port
2.4 mm (f)
P938xB Series
P9382B
9 kHz to 9 GHz, 4-port
3.5 mm (f)
P9384B
9 kHz to 20 GHz, 4-port
3.5 mm (f)
P500xB Series
P5000B
9 kHz to 4.5 GHz, 2-port
3.5 mm (f)
P5001B
9 kHz to 6.5 GHz, 2-port
3.5 mm (f)
P5002B
9 kHz to 9 GHz, 2-port
3.5 mm (f)
P5003B
9 kHz to 14 GHz, 2-port
3.5 mm (f)
P5004B
9 kHz to 20 GHz, 2-port
3.5 mm (f)
P5005B
100 kHz to 26.5 GHz, 2-port
3.5 mm (f)
P5006B
100 kHz to 32 GHz, 2-port
2.4 mm (f)
P5007B
100 kHz to 44 GHz, 2-port
2.4 mm (f)
P5008B
100 kHz to 53 GHz, 2-port
1.85 mm (f)
P502xB Series 2
P5020B
9 kHz to 4.5 GHz, 4 or 6-port
3.5 mm (f)
P5021B
9 kHz to 6.5 GHz, 4 or 6-port
3.5 mm (f)
P5022B
9 kHz to 9 GHz, 4 or 6-port
3.5 mm (f)
P5023B
9 kHz to 14 GHz, 4 or 6-port
3.5 mm (f)
P5024B
9 kHz to 20 GHz, 4 or 6-port
3.5 mm (f)
P5025B
100 kHz to 26.5 GHz, 4-port
3.5 mm (f)
P5026B
100 kHz to 32 GHz, 4-port
2.4 mm (f)
P5027B
100 kHz to 44 GHz, 4-port
2.4 mm (f)
P5028B
100 kHz to 53 GHz, 4-port
1.85 mm (f)
1. All B -models of Keysight Stream line Series VNAs include: Thunderbolt 3 cable assembly for connection with a host PC (800- mm, P/N:
8121-3588), power supply (external AC- DC adapter. P/N: 0950- 6128 for P937xB/P500xB , or P/ N: 0950-6166 for P938xB/P502xB ), and
power cord.
2. P502xB Option 400 (>20 GHz mo dels) or Option 402 (all models) include one flexible control cable (P/N: M9800-61601) and one semirigid cable (P/N: M9800- 61602) for the connect ion on the fro nt panel. Both cable assemblies are i ncluded in Y1730A Option 001
(Interconnect cables for multiport configuration of 1-slot M980xA).
Find us at www.keysight.com Page 5
Test set options
Option number
2-port
4-port
6-port
Additional information
Option 200
X
Not available with P937xB, P938xB or P502xB Series.
Option 400
X
Not available with P937xB, P938xB or P500xB Series.
Option 402
X
Adds internal second source. Not available with
P937xB, P938xB or P500xB Series.
Option 600
X
Not available with P937xB, P938xB or P500xB Series.
For P937xB,
For P500xB,
Additional information
Automatic fixture removal
S97007B
S97007B
Time domain analysis
S97010B
S97010B
TDR
on the measurement trace.
S970250B.
Basic pulsed-RF measurements lite,
N/A
S970241B
Available with P5005B to P5008B, or
S970251B.
20 GHz 2
P5020B to P5024B.
53 GHz 2
P5025B to P5028B.
correction 3
Scalar mixer/converter measurements3
S97082B
S97082B
Provides SMC measurement class.
Vector and scalar mixer/ converter
N/A
S97083B
Provides SMC + phase
mixer characterization.
Embedded-LO capability 3
N/A
S97084B
Gain-compression measurements 3
N/A
S97086B
Intermodulation distortion
N/A
S97087B
Requires option 402 (internal second
measurements with S97551B.
measurements with S97551B.
Choose one of the frequency models, and one test set option for the P500xB or P502xB Series. Option 200
indicates two test ports, option 40x indicates four test ports and option 600 indicates six test ports. To add
options to a product, order the corresponding item number (ex. P5000B-200).
Application software
Description 1
Enhanced time domain analysis with
Real-time S-parameter and power
measurement uncertainty
Basic pulsed-RF measurements lite,
up to 20 GHz
2
up to 53 GHz 2
Basic pulsed-RF measurements, up to
Basic pulsed-RF measurements, up to
Noise figure measurements with vector
P938xB Series
P502xB Series
S97011B S97011B Includes all capabilities of S97010B.
N/A S97015B Displays the measurement
uncertainty dynamically (real-time)
N/A S970240B
Available with P5000B to P5004B, or
P5020B to P5024B. Subset of
P5025B to P5028B. Subset of
N/A S970250B Available with P5000B to P5004B, or
N/A S970251B Available with P5005B to P5008B, or
N/A S97029B Standard receivers are used.
measurements 3
measurements
3,4
Source phase control N/A S97088B Requires option 402 (internal second
Find us at www.keysight.com Page 6
measurement class. Provides vector
source option) or multiple instrument
source option) or multiple instrument
Differential and I/Q device
measurements 3
N/A
S97089B
Requires option 402 (internal second
measurements with S97551B.
Spectrum analysis, up to 4.5 GHz
N/A
S970900B
Available with P5000B or P5020B.
Spectrum analysis, up to 6.5 GHz
N/A
S970901B
Available with P5001B or P5021B.
Spectrum analysis, up to 9 GHz
3,5
N/A
S970902B
Available with P5002B or P5022B.
Spectrum analysis, up to 14 GHz
N/A
S970903B
Available with P5003B or P5023B.
Spectrum analysis, up to 20 GHz
N/A
S970904B
Available with P5004B or P5024B.
Spectrum analysis, up to 26.5 GHz
N/A
S970905B
Available with P5005B or P5025B.
Spectrum analysis, up to 32 GHz
N/A
S970906B
Available with P5006B or P5026B.
Spectrum analysis, up to 44 GHz
N/A
S970907B
Available with P5007B or P5027B.
Spectrum analysis, up to 44 GHz
N/A
S970908B
Available with P5008B or P5028B.
S97551B.
Series VNAs
Requires one ECal module.
matrix 9
analysis
extenders
class of Keysight’s VNAs.
Vector Network Analyzer (VNA)
S94051B
S94051B
Runs on your PC and simulates VNA
features of S97xxxB software 10
customizable templates.
masks for production tests.
Automated measurement expert
S94701A
S94701A
A smart software solution for
model and install in a host PC.
or raw cables) using 4-port VNA.
3,5
3,5
3,5
3,5
3,5
3,5
3,5
3,5
source option) or multiple instrument
True-mode stimulus N/A S97460B Requires option 402 or multiple
instruments measurements with
Multiple instruments measurements S97551B S97551B Provides multiport calibrated
measurements using two Streamline
6,7,8
Multiport calibration assistant S97552B S97552B Provides a tool to flexibly define cal
sets of multiport measurements.
Multiport calibrated measurements
with switch instruments
S97553B S97553B Provides multiport calibrated
measurements using P9164A/B or
P9165A/B USB Solid-State Switch
Banded millimeter-wave network
Vector Network Analyzer (VNA)
simulator - Standard
simulator - Advanced
S97560B S97560B Enables the operation with frequency
S94050B S94050B Runs on your PC and simulates
standard S-parameter measurement
functions including advanced
Device measurement expert (DMX) S94601B S94601B Assists the users in setting up
measurements automatically with
Limit assistant S94602B S94602B Allows to acquire the data from the
VNA, and easily generate limit
(AMX)
S94702A
KS8400A
S94702A
KS8400A
automated S-parameter
measurements with the Streamline
Series VNA. Order each software
USB Type-C interconnects compliance
test software
1. Refer to “Keysight Software Licensing Options Provide Flexibility and Support” for more detail about S97xxxB licenses.
Find us at www.keysight.com Page 7
11,12
N/A S94USBCB
Performs automated compliance
tests of USB Type-C interconnects
(ex. cable assemblies, connectors,
2. Enables internal pulse generators and pulse modulators on the analyzer’s source(s). Hardware options are not needed for pulsed-RF
Description
P500xB
P502xB
High-performance enabling software 1
S9720xB
S9721xB
VNA activation software 1
S9722xB
S9723xB
Performance
P50xxB
P93xxB
Dynamic range (10 Hz IFBW)
4 GHz
140 dB
115 dB
20 GHz
126 dB
105 dB
4 GHz
-130 dBm
-107 dBm
20 GHz
-122 dBm
-101 dBm
Max output power
4 GHz
+10 dBm
+8 dBm
20 GHz
+4 dBm
+4 dBm
IF bandwidth
1 Hz to 15 MHz
1 Hz to 700 kHz
(2-port cal, 0.8 to 1 GHz, typical)
201 points
1.8 ms (1 MHz IFBW)
15 ms (700 kHz IFBW)
401 points
2.5 ms (1 MHz IFBW)
28 ms (700 kHz IFBW)
measurements.
3. Provides frequency offset mode (FOM) to independe ntly set the frequency of internal source(s) and receivers, and to configure external
sources using External Device Co nfiguration.
4. The most commo n method to use S97087B is to use a 4- port P502xB with t he internal second source option 402, with each built-in
source generating one of th e two tones. Any of the re maining ports can be used as the receive port..
5. Enables spectrum analysis a nd vector signal analysis using the VNA’s receivers. PathWave Vector Signal Analysis (8960 0 VSA)
software is required for vector signal analysis. H ardware options are not n eeded for spectrum analysis or vector signal analysis.
6. When configur ing a multiport VNA using multiple Streamline Series VNAs, Y1701A is recommended for each additional multiport
interconnection.
7. P937xB and P938xB, or P500xB and P502xB can be combined in multiport configurations. P93xxB and P50xxB Series cannot be
combined.
8. A 4- port EC al module (ex. N4431/32/33D) is recommended for multiport measurements (n > 4).
9. Only the 4- port ECa l modules ( ex. N4431/32/33D ) are supported for calibration with S97553B.
10 . Features of S97007B, S97552B and S97553B are not supported w ith the S94051B.
11 . Requires S9701 1B, KS8400B PathWave Test Automation, and KS8104B HTML5 Result Listener Plugin.
12 . Supports L8990M-0LZ 20-port switch matrix to configure a multiport test system which eliminates the need for reconnections of test
cables with DUT.
P93xxB option
VNA activation software option (option 001) enables basic VNA functionalities of P937xB and P938xB
1. Option 001 is mandatory at the time of purchase of P937xB and P938xB Streamline Series VNA.
P50xxB software
S9720xB/S9721xB software improves measurement performance of P500xB and P502xB (ex. dynamic range,
noise floor, max output power or cycle time) compared to the performance of P937xB and P938xB.
S9722xB/S9723xB software enables basic VNA functionalities of P500xB and P502xB. The software ensures
compatibility with newly added features and keeps your instrument up to date.
1. S972xxB software includes node-locked, perpetual license and one-year support subscription. It is mandatory a t the time of
purchase of P5 00xB or P502xB Streamline Series VNA (x = 0 to 8).
Performance comparison between P50xxB and P93xxB
Noise floor (10 Hz IFBW)
Cycle time
1. Refer to data sheet (3121-1235.EN) for m ore details about the difference in performance/specifications between P50xxB and
P93xxB.
2. Refer to VNA selection guide (5989- 7603EN) for the comparison of P50xxB and P50xxA, or P93xxB and P937xA.
1,2
Find us at www.keysight.com Page 8
Calibration option
Option number
Description
Additional information
specifications. Conforms to ISO 17025 and ISO 9001.
For P937xB,
P938xB Series
For P500xB,
P502xB Series
Additional information
remotely or on-site.
office.
training needs with the Keysight sales representative.
Model number
Description
Additional information
P9164A
Solid-state switch matrix module, 2x16 full crossbar,
300 kHz to 6.5 GHz
S97553B application software
P9164B
Solid-state switch matrix module, 2x16 full crossbar,
300 kHz to 9 GHz
P9165A
Solid-state switch matrix module, 2x8 full crossbar,
300 kHz to 6.5 GHz
300 kHz to 9 GHz
Option 1A7 ISO 17025 compliant
calibration
Training options
Description
Included - instrument
care and operations
starter training
Optional - technology
and measurement
science standard
training
N/A PS-S40-01 Provides startup training service that reduces
N/A PS-S40-02 Provides customized technology and measurement
Provides a complete set of measurements which test
the unit to manufacturer’s published specifications.
Includes calibration label, ISO 17025 calibration
certificate and data report, and measurement
uncertainties and guardbands on all customer
complexity associated with initial setup and enables
users to get to measurements fast.
Recommended topics are product overview, system
setup and initial measurements. Can be delivered
science training. Enable users to get deeper insights
into the VNA measurement theory and applications.
Recommended topics are VNA theory and
applications. Can be delivered on-site or in Keysight
Optional - premium
functional and
customer specific
application training
Additional hardware
P9165B Solid-state switch matrix module, 2x8 full crossbar,
N/A PS-S40-03 Provides an integrated training experience that fits to
the users’ needs on applications or workflow.
Custom topics based on the user needs. Discuss the
is required for multiport
calibrated measurements.
Find us at www.keysight.com Page 9
Accessories
For P937xB or
For P938xB or
VNA (P938xB or P502xB Series).
VNA.
Y1701A-101
Y1701A-202
Includes latch kit for connecting two instruments 2.
additional VNA.
Hard transit case
Y1710A
Y1710A
of the VNA.
mm cable.
Streamline Series VNA 7.
Description
P500xB Series
P502xB Series
Additional information
Rack mount kit Y1700A-001 Y1700A-002 Order Option 001 for 2-port VNA (P937xB or
P500xB Series). Order Option 002 for 4 or 6-port
Multiple USB instruments
configuration kit
PXI adapter module
5,6
Y1701A-002
or 003
Y1701A-302 Y1701A-303
Y1701A-400
or 401
Y1701A-002
or 003
or 304
Y1701A-400
or 401
Includes interconnect cables for configurations
using two VNAs
1
. Add one kit for each additional
Includes interconnect cables for multiport
configurations in a rack
3
. Add one kit for each
Includes Thunderbolt 3 cable assembly with USB
Type-C connectors for connection with a host PC.
Y1731A-001 Y1731A-001 Includes one PXI module to enable coaxial
connections with control signals of Streamline
Series VNA. Equipped with twelve SMB
connectors. Includes 2 flexible control cables (500
mm and 175 mm) for connection with a control port
4
SMB (f) to MCX (m)
cable assembly
BNC (f) to MCX (m)
cable assembly
1. Order Y170 1A O ption 00 2 for P93xxB or P50xxB Series up to 20 GHz. Order Y1701A Option 003 f or greater th an
20 GHz models.
2. If 2-port VNA (ex. P500xB) and 4- or 6-port VNA (ex. P502xB) are connected for a multiport VNA, order Y1701A Option 102
latch kit for connecting 1- slot to 2- slot instruments.
3. Order Y170 1A Op tion 302 for 2-port VN A (P937xB or P500xB Ser ies). Order Option 303 for P938xB or P502xB- 400/600 up to
20 GHz. Order option 304 for P502xB- 400 (above 20 GHz) or P502xB- 402 (all models).
4. Y1701 A Option 400 includes on e 500-mm cable (P/N: 8121-3587) and one re tainer (P/N: P5000-29001). Option 401 includes
one 800-mm cab le (P/N: 8121- 3588) and one reta iner (P/N: P50 00-29001).
5. Y1731 A does not require power supply. PXI chassis is not needed for the operation.
6. Order Y1731A Option 800 (BN C (m) to SMB (f) cable assembly, 1000 m m) for connection with BNC connectors on external
peripherals (ex. pulse generators)
7. Usin g 10 MHz reference ports (10 MHz In/Out) on the rear panel of Streamline Series VNA is not supported.
Y1730A-800
or 801
Y1730A-800
or 801
For connection with 10 MHz external reference
ports (Ref In/Ref Out) on the front panel of
Streamline Series VNA
7
. Option 800 includes one
300-mm cable and option 801 includes one 1000-
Y1730A-810 Y1730A-810 For connection with 10 MHz external reference
ports (Ref In/Ref Out) on the front panel of
Find us at www.keysight.com Page 10
Figure 1. Rack mount kit for Keysight Streamline Series products (Y1700A option 001)
Figure 2. Transit case for Keysight Streamline Series products (Y1710A)
Figure 3. Multiple instruments configuration kit (Y1701A)
Find us at www.keysight.com Page 11
Test cables
Option number
Description
Additional information
Y1740A-100
Cable Assembly, 3.5 mm (m) to 3.5 mm (m), 26.5 GHz, 36 inches
Y1740A-200
Cable Assembly, 2.92 mm (m) to 2.92 mm (m), 40 GHz, 36 inches
Y1740A-300
Cable Assembly, 2.4 mm (m) to 2.4 mm (m), 50 GHz, 36 inches
Y1740A-310
Cable Assembly, 2.4 mm (m) to 2.92 mm (m), 40 GHz, 36 inches
Y1740A-400
Cable Assembly, 1.85 mm (m) to 1.85 mm (m), 67 GHz, 1 m
Figure 4. Cable assembly with 2.4-mm male connectors (Y1740A-300)
Find us at www.keysight.com Page 12
Measurement Application Software
Solid black series name indicates the feature is available on that series, while gray series name with
strikethrough indicates the feature is not available with that series. For example:
P50xxB Series: Available with P500xB or P502xB Series
P93xxB Series: Not available with P937xB or P938xB Series
Automatic fixture removal (S97007B)
P93xxB Series P50xxB Series
Many devices do not have coaxial connectors and are put in fixtures in order to measure them in a coaxial
environment. Accurately removing the effects of the fixture is required to get a good measurement of the device
under test (DUT). This application adds a powerful application wizard to guide you through characterizing a
fixture and removing it from the measurement. Devices can be single-ended or differential. Files can be saved in
a variety of formats for later use in ENA, PNA, PXI VNA, Streamline Series VNA, ADS, and PLTS.
Time domain analysis (S97010B)
P93xxB Series P50xxB Series
This application enables the analyzer to view reflection and transmission responses in time or distance. Use time
domain to tune filters, gate out the response of fixtures and cables, characterize the impedance of transmission
lines and more.
Enhanced time domain analysis with TDR (S97011B)
P93xxB Series P50xxB Series
This application enables the analyzer to perform enhanced time domain analysis for high-speed data
applications. All functionalities of the S97010B are included (TDR/TDT mode). In addition, the S97011B enables
more detailed measurements and evaluations, such as eye-diagram/mask modes, without adding PLTS
software. Jitters and/or emphasis/equalization capabilities enables simulation of real-world signals and
environment. S97011B covers up to 53 GHz bandwidth with 8.42 psec rise time. Full calibration is available and
automatic deskew ensures easy removal of fixture and probe effects. To get the best accuracy, mechanical
calibration kits or ECal with DC option (i.e. N443xD or N469xD with Option 0DC) are recommended.
Find us at www.keysight.com Page 13
Real time S-parameter and power measurement uncertainty (S97015B)
P93xxB Series P50xxB Series
This application provides uncertainties for both S-parameter and power measurements on the P50xxB. The realtime display of the uncertainty associated with power and S-parameter traces increases the confidence in the
reproducibility of measurements. This allows users to implement pass/fail tests easily because now the
instrument quantifies the gray region that is in between a full pass or a full fail, apply more realistic limit lines
which can increase the production yield and reduce the defect percentage on the finished products. This
application easily establishes a metric to quantify the quality of the measurement process, so your company’s
quality control procedures are simplified. It includes the uncertainty information for most Keysight calibration kits
and provides national metrology institute traceability through Keysight’s calibration kits. This application also
helps you to include uncertainty information for your product’s specifications and data sheets.
Basic Pulsed-RF measurements lite (S970240B/S970241B)
P93xxB Series P50xxB Series
This application enables internal pulse generators of P500xB or P502xB Series that can be used to control the
internal pulse modulators, and it provides an integrated pulse application that uses the wideband-detection
method.
The pulse application provides an easy way to set up point-in-pulse measurements with pulse width as narrow as
50 us, and pulse-profile measurements with 1 us minimum timing resolution. Using the built-in pulse modulators,
the P50xxB Series VNAs are complete pulsed-RF measurement solutions, eliminating the need for external test
sets and pulse generators. S97024xB also controls external pulse generators and modulators and can
synchronize to external master pulses. Y1731A I/O Adapter Module is recommended to access pulse signals
with SMB connectors if using external master pulses or external pulse modulators.
S970240B is available with P50xxB up to 20 GHz (20 GHz models or less), and S970241B is available for
P50xxB greater than 20 GHz. Hardware options are not needed for pulsed-RF measurements with P50xxB.
S97024xB is a subset of S97025xB, so they should not be installed together.
Basic Pulsed-RF measurements (S970250B/S970251B)
P93xxB Series P50xxB Series
This application enables internal pulse generators of P500xB or P502xB Series that can be used to control the
internal pulse modulators, and it provides an integrated pulse application that uses the wideband-detection
method.
S97025xB extends the capabilities of S97024xB and provides an easy way to set up point-in-pulse
measurements with pulse width as narrow as 200 ns, and pulse-profile measurements with 40 ns minimum
timing resolution. Using the built-in pulse modulators with pulse width as narrow as 1 us, the P50xxB Series
VNAs are complete pulsed-RF measurement solutions, eliminating the need for external test sets and pulse
generators. Examples of pulse modulation shapes with 1 us and 100 us pulse width using the internal pulse
modulators are included in P50xxB data sheet (3121-1235). S97025xB also controls external pulse generators
and modulators and can synchronize to external master pulses. Y1731A I/O Adapter Module is recommended to
access pulse signals with SMB connectors if using external master pulses or external pulse modulators.
S970250B is available with P50xxB up to 20 GHz (20 GHz models or less), and S970251B is available for
P50xxB greater than 20 GHz. Hardware options are not needed for pulsed-RF measurements with P50xxB.
Find us at www.keysight.com Page 14
Loading...
