Keysight N9910X Configuration Guide

FieldFox Handheld Analyzers

4/6.5/9/14/18/26.5/32/44/50 GHz

This configuration guide describes configurations, options and accessories
for the FieldFox A-Series family of portable analyzers. This guide should be
used in conjunction with the technical overview and data sheet for a
complete description of the analyzers. The table on Page 3 titled “FieldFox
A-Series Family and Options” shows a comparison of the functions available
in the FieldFox A-Series family of analyzers.

Included accessories

The following accessories
are included with every
FieldFox

Note: Combination analyzer (combo) = Cable and antenna tester (CAT) +
Vector network analyzer (VNA) + Spectrum analyzer (SA)

• AC/DC adapter

• Battery

• Soft carrying case

• LAN cable

• Quick Reference Guide

Find us at www.keysight.com Page 1

Table of Contents

FieldFox A-Series Family and Options ......................................................................................................... 3

FieldFox RF and Microwave (Combination) Analyzers ................................................................................. 4

Analyzer models ........................................................................................................................................ 4

Analyzer options ........................................................................................................................................ 5

FieldFox RF and Microwave (Combination) Analyzer FAQs ........................................................................ 7

ERTA System Typical Configuration ........................................................................................................... 10

FAQs – Applicable to All FieldFox RF and Microwave Analyzers

FieldFox Microwave Vector Network Analyzers .......................................................................................... 13

Analyzer models ...................................................................................................................................... 13

Analyzer options ...................................................................................................................................... 13

FieldFox Microwave Vector Network Analyzer FAQs ................................................................................. 14

FieldFox Microwave Spectrum Analyzers ................................................................................................... 15

Analyzer models ...................................................................................................................................... 15

Analyzer options ...................................................................................................................................... 15

FieldFox Spectrum Analyzer FAQs ............................................................................................................. 16

Upgrades ..................................................................................................................................................... 17

FieldFox microwave (combination) analyzer upgrades N9913AU, N9914AU, N9915AU,

N9916AU, N9917AU, N9918AU, N9950AU, N9951AU, N9952AU ........................................................ 17

......................................................... 11

FieldFox signal analyzer upgrades N9935AU, N9936AU, N9937AU, N9938AU, N9960AU,

N9961AU, N9962AU ............................................................................................................................... 18

FieldFox VNA upgrades N9925AU, N9926AU, N9927AU, N9928AU .................................................... 19

FieldFox RF and microwave analyzers hardware upgrades ................................................................... 19

Documentation ............................................................................................................................................ 20

Calibration Kits ............................................................................................................................................ 20

Accessories ................................................................................................................................................. 22

Find us at www.keysight.com Page 2

FieldFox A-Series Family and Options

CAT/vector network analysis

010

VNA time domain

√ √ —

√ on N991xA

(Not on N995xA)

210

VNA transmission/reflection

√

Base model 1

—

211

VNA full 2-port S-parameters

√ √ —

212

1-port mixed-mode S-parameters

√ √ —

215

TDR cable measurements

√ √ —

305

Cable and antenna analyzer

Base model 1

√

— 2

308

Vector voltmeter

√ √ —

320

Reflection meas. (RL, VSWR and scalar meas.)

— 3

— 3

√

√ on N991xA

N995xA)

209

Extended range transmission analysis (ERTA)

√ — √

220

Tracking generator

— 4 — √

233

Spectrum analyzer

√

—

Base model 1

235

Pre-amplifier √ —

√

236

Interference analyzer and spectrogram

√ — √

238

Spectrum analyzer time gating

√ — √

312

Channel scanner

√ — √

350

Real-time spectrum analyzer (RTSA)

√ (Not on N9912A)

—

√

351

I/Q Analyzer (IQA)

√ (Not on N9912A)

—

√

352

Indoor and outdoor mapping

√ (Not on N9912A)

—

√

353

IQ streaming

√ (Not on N9912A)

—

√

355

Analog demodulation

√ — √

356

Noise figure (NF)

√ (Not on N9912A)

—

√

358

EMF measurements

√ (Not on N9912A)

—

√

360

Phased array antenna support

√ (N995xA only)

—

√ (N996xA only)

370

Over-the-Air (OTA) LTE FDD

√ (Not on N9912A)

—

√

371

Over-the-Air (OTA) LTE TDD

√ (Not on N9912A)

—

√

377

Over-the-Air (OTA) 5GTF

√ (Not on N9912A)

—

√

Option Description

112 QuickCal

V5K VNA 5kHz start frequency

Spectrum analysis

Combination
Analyzers N991xA,
N995xA

(Not on N9912A nor

Vector Network
Analyzers N992xA

√ —

— —

Spectrum Analyzers
N993xA, N996xA

1. Base model means that the functionality listed is the primary function of that instrument. For example, on the N991xA or
N995xA combo analyzers, cable and antenna analysis is the standard function included with every N991xA or N995xA.

2. Option 305 is not available on the N993xA or N996xA. However, a subset of cable and antenna analyzer measurements, return
loss and VSWR, is available as Option 320.

3. Option 320 is not applicable to N991xA, N995xA, or N992xA. The reflection measurements of return loss and VSWR are
included with every N991xA, N995xA, and N992xA. So, there is no need for an Option 320 on these analyzers.

4. On the N991xA or N995xA analyzers, order Options 233 and 210 to obtain a tracking generator with the spectrum analyzer.
Option 220 is not available on the N991xA or N995xA analyzers. Option 233 provides the spectrum analyzer capability and
Option 210 the “tracking” capability.

Find us at www.keysight.com Page 3

Combination

Power measurements

208

USB power sensor meas. versus frequency

√ √ √

302

USB power sensor support

√ √ √

310

Built-in power meter

√ √ √

330

Pulse meas. with USB peak power sensor

√ √ √

030

Remote control capability

√ √ √

307

GPS receiver √ √

√

309

DC bias variable-voltage source

√ (Not on N9912A)

√

√

—

Frequency extender support 1

√ (Not on N9912A)

—

√

89601B

PathWave VSA (89600 VSA) software

√ (Not on N9912A)

—

√

N6820ES

Surveyor 4D software

√ (Not on N9912A)

—

√

N9913A

4 GHz FieldFox RF analyzer

30 kHz to 4 GHz

100 kHz to 4 GHz

Type-N (f)

N9914A

6.5 GHz FieldFox RF analyzer

30 kHz to 6.5 GHz

100 kHz to 6.5 GHz

Type-N (f)

N9915A

9 GHz FieldFox microwave analyzer

30 kHz to 9 GHz

100 kHz to 9 GHz

Type-N (f)

N9916A

14 GHz FieldFox microwave analyzer

30 kHz to 14 GHz

100 kHz to 14 GHz

Type-N (f)

N9917A

18 GHz FieldFox microwave analyzer

30 kHz to 18 GHz

100 kHz to 18 GHz

Type-N (f)

N9918A

26.5 GHz FieldFox microwave analyzer

30 kHz to 26.5 GHz

100 kHz to 26.5 GHz

3.5 mm (m)

N9950A

32 GHz FieldFox microwave analyzer

300 kHz to 32 GHz

9 kHz to 32 GHz

NMD 2.4 mm (m)

N9951A

44 GHz FieldFox microwave analyzer

300 kHz to 44 GHz

9 kHz to 44 GHz

NMD 2.4 mm (m)

N9952A

50 GHz FieldFox microwave analyzer

300 kHz to 50 GHz

9 kHz to 50 GHz

NMD 2.4 mm (m)

Option Description

System features

Windows based software

1. Frequency extenders are not currently supported on models N9913A, N9914A and N9915/35A since the starting LO
frequency of these mixers is higher than 9 GHz and the LO is provided to the mixer from FieldFox Port 1. For a list
of supported OML frequency extenders, see Accessories page 23.

Analyzers
N995xA

N991xA,

Vector Network
Analyzers N992xA

Spectrum Analyzers
N993xA, N996xA

FieldFox RF and Microwave (Combination) Analyzers

Analyzer models

Step 1. Select the model that provides the desired frequency range.

Model Description

1. Useable to 5 kHz.

CAT and VNA
frequency

SA frequency 1 Test port connectors

Find us at www.keysight.com Page 4

Analyzer options

010

VNA time domain

Requires 210, recommend 211. See page 7, FAQ #7

112

QuickCal

Not available for N995xA models. See page 7, FAQ #9

Recommend ordering a cal kit. See page 6, FAQ #4 and page 7,
FAQ #6

211

VNA full 2-port S-parameters

Requires 210, recommend ordering a cal kit. See page 6, FAQ #5

212

1-port mixed-mode S-parameters

Requires 210 and 211

215

TDR cable measurements

—

210 and 211 required to obtain full VVM functionality. See page 7,
FAQ #8

V5K

VNA 5kHz start frequency

Not available for N9912A nor N995xA

Requires 233 and 210. Recommend 307. Requires two FieldFox
units. See page 8, FAQ # 10. See page 10 for typical configuration.

233

Spectrum analyzer

—

235

Pre-amplifier

Requires 233

236

Interference analyzer and spectrogram

Requires 233

238

Spectrum analyzer time gating

Requires 233

312

Channel scanner

Requires 233

350

Real-time spectrum analyzer (RTSA) 1

Requires 233, Recommend 235. See page 8, FAQ #12

351

I/Q Analyzer (IQA) 1

Requires 233

Requires 233, 307, and at least one of 312, 360, 370, 371 or 377.
See page 9, FAQ #17

353

IQ streaming

1

Requires 233, 351

355

Analog demodulation

Requires 233

Requires 233, 235, 309 and accessory item N9910X-713 BNC to

noise source requirements.

358

EMF measurements

Requires 233. Also requires triaxial antenna. See page 9, FAQ #18

Requires 233. Also requires phased arrayed antenna. See page 9,
FAQ #16

370

Over-the-Air (OTA) LTE FDD 1

Requires 233, 307. Recommend 235.

371

Over-the-Air (OTA) LTE TDD 1

Requires 233, 307. Recommend 235.

377

Over-the-Air (OTA) 5GTF 1

Requires 233, 307. Recommend 235. See page 9, FAQ #19

Step 2. Select optional measurement capabilities.

Any of these options can easily be added as a software upgrade in the future. Exception: Option 112 is
only applicable to N991xA models. It is not applicable to N995xA models.

Option Description Prerequisite options/notes

CAT/vector network analysis

210 VNA transmission/reflection

308 Vector voltmeter

Spectrum analysis

209 Extended range transmission analysis (ERTA)

352 Indoor and outdoor mapping

356 Noise Figure (NF) 1

360 Phased array antenna support

1. Requires CPU2 fast processor. See page 9, FAQ #13.

SMB cable. See page 9, FAQ #15 for external preamplifier and

Find us at www.keysight.com Page 5

Option Description Prerequisite options/notes

208

USB power sensor meas. versus frequency

Requires 302

302

USB power sensor support

Need to order USB power sensor 2

310

Built-in power meter

No power sensor required. See page 11, FAQ #1

Need to order USB peak power sensor. See page 12, FAQs #7 and
#8

030

Remote control capability

Requires an iOS device

307

GPS receiver

Need to order GPS antenna, N9910X-825. See page 12, FAQ #3

309

DC bias variable-voltage source

Recommend N9910X-713 cable, see page 12, FAQ #4

Requires 233. Optional 350, 351, 360, 370, 371, 377, PathWave
VSA software. See Accessories, page 23

89601B

PathWave VSA (89600 VSA) software

Requires 233 and CPU2 processor. See page 9, FAQ #13

N6820ES

Surveyor 4D software 1

Requires 233, 235 and 307, see page 10, FAQ #20

Power measurements

330 Pulse meas. with USB peak power sensor

System features

— Frequency extender support

Windows based software

1. Requires CPU2 fast processor. See page 9, FAQ #13.

2. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport.

Find us at www.keysight.com Page 6

FieldFox RF and Microwave (Combination) Analyzer FAQs

The base model includes the cable and antenna analyzer

Measurements: DTF (dB, linear, VSWR), return loss and DTF, return loss (dB), and 1-port cable loss

Calibrations: CalReady, OSL, and response cal

Note: 2-port insertion loss is NOT included with the base model, if 2-port insertion loss is needed, order
Option 210

Note: Base analyzer does not have phase information, for S11 or S21 phase, order Option 210

Basic spectrum analysis, four traces, different detector types, radio standard selection, limit lines

Channel power, occupied bandwidth, adjacent channel power, spectrum emission mask

AM/FM tune and listen, field strength measurements, antenna factors, frequency counter marker

Tracking generator (TG)/Independent source:

• TG tracking mode (traditional TG operation, swept SA coupled to swept source) - (requires Option 210)

3. What is included with

236?

Interference analyzer and spectrogram

Option 210 adds a VNA with transmission/reflection (T/R) capability

Measurements: S21, S11, magnitude and phase

Additionally, in the CAT mode, you can measure 2-port insertion loss

Calibrations: CalReady, OSL, response, and enhanced response cal

If you need all four S-parameters, order Options 210 and 211

If you need 2-port cal, order Options 210 and 211

Adds tracking mode to the tracking generator/independent source included with Option 233, spectrum
analyzer

5. What is included with

Option 211 adds full 2-port S-parameter capability to the VNA mode

Measurements: All four S-parameters (S11, S21, S22, S12), magnitude and phase

Calibrations: CalReady, OSL, response, enhanced response, and full 2-port cal

6. Can I measure group delay

analyzers?

S11/S21 in time domain, if Option 210 is ordered. To get time domain data for all four S-parameters and
full 2-port cal, order Option 211.

View both time and frequency domain data at the same time

Low-pass, impulse, and band-pass modes

Minimum, medium, and maximum window

Gating

With Option 308: 1-port cable trimming

With Options 308 and 210: 1-port cable trimming, 2-port transmission

With Options 308, 210, and 211: 1-port cable trimming, 2-port transmission, A/B and B/A

Note: A/B and B/A measurements require an external source

Option 112 (QuickCal), is not available for N995xA analyzers. It is available for N991xA analyzers.

QuickCal is included with Option 112.

• 1-port, enhanced response, and 2-port QuickCal with a full 2-port analyzer (one that has Option 211)

Question Answer

1. What is included with a
base N991xA/N995xA
analyzer?

2. What is included with
N991xA/N995xA Option
233?

• TG CW mode (source CW frequency can be set independent of SA frequency) - included

• TG CW coupled mode (source CW frequency is auto coupled to SA’s center frequency) - included

N991xA/N995xA Option

4. What is included with
N991xA/N995xA Option
210?

N991xA/N995xA Option
211?

on N991xA/ N995xA

7. What is included with
N991xA/N995xA Option
010?

8. What is included with
N991xA/N995xA Option
308?

Trace playback and recording

If you have phase measurement capability, then you can measure group delay. Option 210 is required for
any phase measurement capability. So, if you do not have Option 210, you cannot measure group delay.

• 1-port QuickCal with a base analyzer

9. What is included with
N991xA Option 112?

• 1-port and enhanced response QuickCal with a T/R analyzer (one that has Option 210)

QuickCal is most accurate for DUTs with 7/16 and Type-N connectors and measurement uncertainties

are provided for frequencies ≤ 18 GHz. Reduced accuracy for DUTs with 3.5 mm (m), SMA (m), or other

male coaxial connectors; performance is unspecified. QuickCal is not recommended for DUTs with

3.5 mm (f), SMA (f), or other similar female connectors. QuickCal is not applicable to waveguide.

Find us at www.keysight.com Page 7

Question Answer

Extended Range Transmission Analysis (ERTA) or Option 209 is a scalar measurement system

used in an ERTA pair, the ERTA system frequency range is limited to the lowest of the pair.

Required hardware

A. Two (2) FieldFox units. FieldFox units can be any of these models:

• ERTA cannot use N9912A, N9923A, N9925A, N9926A, N9927A or N9928A

The two FieldFox units used in ERTA do not have to be the same model.

ERTA requires the following options on Combo FieldFox models (N9913A, N9914A, N9915A,

• Option 233, spectrum analyzer

With either the Combo or SA FieldFox units, the following options are highly recommended:

frequency accuracy and permitting the use of a narrower RBW

B. Power splitter, two-resistor model, Keysight 11667A, 11667B, or 11667C. Other power splitters

11667A, 11667B, or 11667C. Three-resistor power splitters are not recommended.

C. N9910X-712, Trigger/Reference-in cable, SMA (m) to BNC(f), 1 m, quantity two

D. N9910X-713, Trigger/Reference-out cable, SMB (m) to BNC (m), 1 m, quantity two

E. LAN connection – For ERTA, the two FieldFox units communicate via a LAN connection. For a

area network.

F. N9910X-825, GPS Antenna

FieldFox analog demodulation has two parts: (1) Tune and listen, and (2) AM/FM metrics. Tune and

demodulated baseband signal waveform, carrier power, frequency deviation, SINAD and more.

Real-time spectrum analyzer (RTSA) or Option 350 provides real-time measurements on a

include a frequency-mask trigger (FMT).

All N995xA and N996xA analyzers include CPU2. On other FieldFox models, if the serial number

N9910HU-100/200/300/400 to have CPU2.

based on the use of two (2) FieldFox units. One FieldFox acts as the source and reference receiver,
while the second FieldFox acts as the measurement receiver. When different frequency models are

• FieldFox microwave combination analyzers: N9913A, N9914A, N9915A, N9916A, N9917A,
N9918A, N9950A, N9951A, N9952A

• FieldFox microwave spectrum analyzers: N9935A, N9936A, N9937A, N9938A, N9960A,
N9961A, N9962A

N9916A, N9917A, N9918A, N9950A, N9951A, N9952A):

• Option 210, VNA transmission/reflection

ERTA requires the following options on SA FieldFox models (N9935A, N9936A, N9937A, N9938A,
N9960A, N9961A, N9962A)

10. What are the requirements for
Option 209?

• Option 220, tracking generator

Both FieldFox units (the one used as the source, and the other used as the receiver) must have the
options listed above. The ERTA option (209) cannot be installed unless 210 and 233 are present on
a combo analyzer; or 220 is present on a SA analyzer.

• Option 235, preamplifier – this option increases the measurement dynamic range by increasing
the received signal power

• Option 307, GPS receiver – this option increases the dynamic range by increasing the

can be used but the specifications listed are based on the match and tracking performance of

direct connection, a cross-over LAN cable is required. Alternately, both analyzers can be on a local

Recommended accessory

11. What is included with Option
355?

12. What is included with Option
350?

13. How do I determine if my
FieldFox has CPU2 fast
processor?

listen is available with the purchase of the spectrum analyzer option 233. AM/FM metrics becomes
available when Option 355 is purchased. AM/FM metrics provides the user with RF spectrum view,

FieldFox. The FieldFox must be equipped with spectrum analysis capability. The preamplifier option is
recommended, as elusive signals often have low power levels. The maximum real-time bandwidth
for option 350 is 10 MHz. RTSA includes trace recording and playback capabilities. It does not

starts with MY5607/SG5607/US5607, then it has CPU2. If the serial number prefix is different, then
the analyzer firmware needs to be checked to see if the instrument has been upgraded with

Find us at www.keysight.com Page 8

Question Answer

Spectrum Analyzer mode (Option 233) does not include Trace Recording and Playback by default.

be purchased.

RTSA

Record and playback spectrum traces

Yes

Yes

Save trace data with GPS time stamp over time

Yes

Yes

Record and playback spectrogram data

Yes

No 1

Requires spectrum analyzer mode (Option 233 on combination models), internal preamplifier

DC bias variable voltage source to noise source connection.

Requires spectrum analyzer mode (Option 233 on combination models). Also requires phased array

N995xA and N996xA models, since phased array antenna operates at 28 GHz.

FieldFox’s mapping function is available in the following modes: Channel Scanner (312), Phased-

match the current GPS coordinates.

Requires triaxial antenna, not sold or provided by Keysight. Supported antenna is AGOS advanced

are supported with spectrum analyzer mode (Option 233 on combination models).

Recommend 32, 44 or 50 GHz FieldFox model (N995xA and N996xA) to support 5GTF FR2

interface is 2.92 mm (f).

Surveyor 4D software connected to FieldFox spectrum analyzer mode offers a versatile, truly

(N6820ES-USD). Requires Surveyor 4D software version 4.3 or later (May 2019).

To obtain this capability in SA mode, Option 236 Interference Analyzer and Spectrogram needs to

RTSA mode (Option 350) does include Trace Recording and Playback by default in RTSA mode.

Purchasing RTSA mode (Option 350) does not enable Trace Recording and Playback in SA mode

14. Is Spectrum Analyzer Trace

(Option 233).

Recording and Playback
standard or an option?

Trace record/playback features

(Option 235) and DC bias variable voltage source (Option 309) as well as CPU2 processor. An

15. What are the requirements for
Noise figure (NF) Option 356?

external noise source is also required and FieldFox supports Keysight noise source models
346A/B/C/K40/K01. Also recommended to improve accuracy is an external preamplifier Keysight
models U7227A/C/F or U7228A/C/F. Requires accessory item N9910X-713 BNC to SMB cable for

SA mode
SA and Interference Analyzer
Options 233 and 236

mode
RTSA
Option 350

16. What is required for phased
array antenna support (Option

360)?

17. What is included with indoor
and outdoor mapping (Option

352)?

18. What is required for EMF
measurements (Option 358)?

19. What is required for 5GTF
over-the-air (OTA)
measurements (Option 377)?

20. What is required for N6820ES
Surveyor 4D software?

antenna, can be ordered as Keysight 85571A-028 or directly from Anokiwave as AWMF-0129.
Recommend GPS receiver (Option 307) and internal preamplifier (Option 235). Supported only on

Array Antenna (360), OTA LTE FDD/TDD (370/371), and OTA 5GTF (377). Mapping is currently not
available in SA or RTSA modes. Outdoor mapping requires the availability of GPS (Option 307).
Maps can be saved to the FieldFox internal memory, SD card or USB drive. Using a direct wired LAN
connection, FieldFox will automatically access OSM once location coordinates (latitude and
longitude) and zoom levels have been entered the Map Explorer menu. If using the l

Support Tool

, OSM map files can be downloaded to a .zip file and imported to FieldFox internal

FieldFox Map

memory. If the FieldFox GPS receiver is enabled and OSM maps have been previously saved to
FieldFox with those GPS coordinates, FieldFox can automatically load the corresponding map to

technologies Triaxial Isotropic Antenna model SDIA-6000 30 MHz to 6 GHz. EMF measurements

frequency of 28 GHz. Requires spectrum analyzer mode (Option 233 on combination models). Also
recommend GPS receiver (Option 307) and internal preamplifier (Option 235). FieldFox models

26.5 GHz and below will require external mixer to down convert millimeter wave frequency to
intermediate frequency (IF). For Keysight direct sales, mixer is orderable as Keysight model
N9910XM28-H2A for 3.5 mm test ports or N9910XM28-H2N for Type-N test ports. For indirect
sales, the mixer is orderable as OML Inc. model M28H2ADC-K, please see website

www.omlinc.com for more information or contact a Keysight representative. OML mixer RF input

portable spectrum monitoring system that covers VLF to 50 GHz, including 5G millimeter wave
bands. The software runs on an external PC or tablet. FieldFox required options include spectrum
analyzer mode (Option 233 on combination models), preamplifier (Option 235) and built-in GPS
receiver (Option 307). Core Surveyor 4D software for Windows (Option N6820ES-114) is required
to run the Surveyor 4D software. Other Surveyor 4D software optional licenses that are supported
include basic modulation recognition application (N6820ES-MR1) and universal signal detection

1. RTSA trace recordings can be recalled and played back in SA mode Spectrogram. This has the added benefit that the
measurements are shown ‘slower’, making it easier for the human eye to decipher the signal content.

Find us at www.keysight.com Page 9

ERTA System Typical Configuration

Combo analyzer: Required Options 210, 233. Recommended: 235, 307
SA analyzer: Required: Option 220. Recommended: 235, 307

Power splitter

11667A (Type-N) or 11667B (3.5 mm) or 11667C (2.4 mm)

1

Type-N(m) to Type-N(m) adapter

N9910X-850 (for use with 11667A or Type-N systems)

1

N9910X-712, SMA(m) to BNC(f)

2 of each

N9910X-713, SMB(m) to BNC(m)

Total of 4 cables

RF test cable

Connecting FieldFox source port 1 to power splitter input

1

RF test cable or adapter

Connecting power splitter output arm to FieldFox port 2

1

RF jumper cable or adapter

Power splitter output arm to DUT input

1

RF jumper cable or adapter

DUT output to FieldFox receiver port 2

1

LAN cable to connect two FieldFox units directly, or the analyzers must be on
the LAN

N9910X-825

GPS antenna, recommended. Necessary if Option 307 is ordered.

2

Item Description/Options Quantity

FieldFox

Trigger cables 1

LAN cable

1. The trigger cables and LAN cables must be at least as long as the separation distance between the two ends of the DUT.

2

1

Figure 1. ERTA system diagram

Find us at www.keysight.com Page 10

FAQs – Applicable to All FieldFox RF and Microwave Analyzers

1. What USB power sensors
work with Option 302?

All Keysight U2000x Series USB power sensors are supported with FieldFox.
Visit: www.keysight.com/find/fieldfoxsupport for an up-to-date listing.

Option 302 allows users to

power measurements

USB power sensor
required

Power
measurement

Broadband diode detector,
measures all frequencies

Tuned receiver, so measures frequencies within
defined channel bandwidth

Frequency range

Depends on USB sensor

Frequency range of the analyzer

Settings

Set CW frequency

Set CW frequency, Set channel width/span

Power range

Depends on USB sensor

Depends on channel width and attenuator setting.

30 minutes to meet
accuracy specifications

InstAlign accuracy: ± 0.5 dB typical for a CW

bandwidth and set those accurately.

Programmable

Yes, via SCPI

Yes, via SCPI

The power sensor can

detector to FieldFox.

The measurement point needs to be connected to

analyzer).

FieldFox source
control

Yes, on/off, and nominal
power level control

No access to FieldFox's source from the built-in
power meter mode

Question Answer

2. What is the difference
between USB power sensor
(Option 302) and built-in
power meter (Option 310)?

Description

External hardware

Warm-up time

Accuracy Depends on USB sensor

Physical
connection

Option 302
USB power sensor

connect a USB power
sensor to FieldFox's USB
port and make broadband

easily be moved to the
measurement point, with a
USB cable connecting the

Option 310
Built-in power meter (or channel power meter)

Option 310 is a channelized power measurement
capability built into FieldFox analyzers. Maximum
bandwidth is 100 MHz.

None. Uses internal receiver.

No warm-up time required

signal. Since the measurement is within a certain
frequency channel or bandwidth, to make an
accurate measurement, the user needs to know
the exact center frequency and the signal's

FieldFox's RF input port. If an RF jumper cable is
used, the user needs to account for the loss of the
cable with an offset value (can be entered into the

Find us at www.keysight.com Page 11

Question Answer

1. The recommended GPS solution is to order:

frequency accuracy of the instrument.

4. What is the connector for
Option 309, DC output?

The DC output has a SMB (m) connector. Recommend ordering N9910X Option 713 bias-tee power
cable SMB (f) to BNC (m).

The connector for the Ref/Trig In is SMA (f). Recommend ordering N9910X Option 712 Trig/Ref in

power cable SMB (f) to BNC (m).

1. Option 030 provides a license for FieldFox to allow remote control via an iOS device.

• A WiFi or 3G/4G network connection between FieldFox and iOS device

Option 330 or pulse measurements requires a Keysight USB peak power sensor. Visit

Keysight USB power sensor

Average power, peak power, and peak to average ratio

Analog gauge display and digital display, dBm and watts

Relative/absolute measurements, dB or %, minimum and maximum limits

Trace graph for pulse profiling with gating

Rise time, fall time, pulse width, pulse period, pulse repetition frequency

Option 302, USB power sensor measurements, includes CW power measurements (one frequency at

offset from the receiver frequency. The power sensor needs to be purchased separately.

• Option 307 - built-in GPS receiver

• A GPS antenna such as N9910X-825

3. What do I need to get GPS
information?

• Other GPS antennas can also be used

• The GPS connector on the instrument is SMA (f)

2. Alternatively, you can purchase a USB-based GPS receiver. You do not need to purchase any
FieldFox options for the USB-based GPS to work. However, the USB-based GPS only provides
time and location data, and time synchronization capability. It cannot be used to increase the

5. What are the connectors for the
Reference/Trigger In and
Reference/Trigger Out?

6. What is Option 030 remote
control capability?

7. What USB sensor is required
for Option 330?

8. What measurement capabilities
are included with Option 330?

9. What is included with Option
208?

SMA (m) to BNC (f) cable.
The connector for the Ref/Trig Out is SMB (m). Recommend ordering N9910X Option 713 bias-tee

2. Not supplied by user, but necessary for operation of Option 030 are:

www.keysight.com/find/usbsensorsforfieldfox for a list of supported peak power sensors. Average

power sensors cannot be used with Option 330, only peak power sensors. The peak power sensor
needs to be purchased separately. Option 330 or pulse measurement requires Option 302 and

a time). With Option 208 added, you can make swept-frequency power measurements. You can plot
source power, gain, and receive power versus frequency. Additionally, the source frequency can be

• iOS device: iPad, iPhone, or iPod Touch with iOS 6.1 or higher with free FieldFox app

Find us at www.keysight.com Page 12

FieldFox Microwave Vector Network Analyzers

N9925A

9 GHz FieldFox microwave VNA

30 kHz to 9 GHz

Type-N (f)

N9926A

14 GHz FieldFox microwave VNA

30 kHz to 14 GHz

Type-N (f)

N9927A

18 GHz FieldFox microwave VNA

30 kHz to 18 GHz

Type-N (f)

N9928A

26.5 GHz FieldFox microwave VNA

30 kHz to 26.5 GHz

3.5 mm (m)

010

VNA time domain

Recommend 211. See page 14, FAQ #3

112

QuickCal

See page 14, FAQ #7

211

VNA full 2-port S-parameters

—

212

1-port mixed-mode S-parameters

Requires 211

215

TDR cable measurements

Requires 305

305

Cable and antenna analyzer

—

308

Vector voltmeter

211 required to obtain full VVM functionality. See page 14, FAQ #5

208

USB power sensor meas. versus frequency

Requires 302

302

USB power sensor support

Need to order USB power sensor 1

310

Built-in power meter

No power sensor required. See page 11, FAQ #1

330

Pulse meas. with USB peak power sensor

Need to order USB peak power sensor. See page 12, FAQs #7 and #8

030

Remote control capability

Requires an iOS device

307

GPS receiver

Need to order GPS antenna, N9910X-825. See page 12, FAQ #3

309

DC bias variable-voltage source

Recommend N9910X-713 cable, see page 12, FAQ #4

Analyzer models

Step 1. Select the model that provides the desired frequency range.

Model Description Frequency Test port connectors

A standard N992xA FieldFox microwave VNA includes transmission/reflection measurement capability.
Additional functionality such as full 2-port S-parameters can be added using the options listed below.

Analyzer options

Step 2. Select optional measurement capabilities. Any of these options can easily be added as a software
upgrade in the future.

Option Description Prerequisite options/notes

Vector network analysis/CAT

Power measurements

System features

1. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport.

Find us at www.keysight.com Page 13

FieldFox Microwave Vector Network Analyzer FAQs

1. What is included with a
base N992xA analyzer?

Measurements: Transmission/reflection or S21 and S11, magnitude and phase

Calibrations: CalReady, OSL, response, and enhanced response cal

Option 211 adds full 2-port S-parameter capability

Measurements: All four S-parameters (S11, S21, S22, S12), magnitude and phase

Calibrations: CalReady, OSL, response, enhanced response, and full 2-port cal

S11/S21 in time domain. To get time domain data for all four S-parameters and full 2-port cal, order
Option 211

View both time and frequency domain data at the same time

Low-pass, impulse, and band-pass modes

Minimum, normal, and maximum window

Gating

Measurements: DTF (dB, Linear, VSWR), return loss and DTF, return Loss (dB), and 1-port cable loss,
2-port insertion loss

TDR (linear, ohm). TDR measurements require Option 215, in addition to Option 305.

Calibrations: CalReady, OSL, and response cal

N992xA with Option 308: 1-port cable trimming, 2-port transmission

N992xA with Options 308 and 211: 1-port cable trimming, 2-port transmission, A/B and B/A

Note: A/B and B/A measurements require an external source

6. If I have the full 2-port VNA

CAT mode's basic measurements are similar to VNA measurements. The features listed below are

• Cable type selection and editing, includes the cable's velocity factor and loss

QuickCal is included with Option 112.

• 1-port, enhanced response, and 2-port QuickCal with a full 2-port analyzer (one that has Option 211).

QuickCal is most accurate for DUTs with 7/16 and Type-N connectors and measurement uncertainties

3.5 mm (f), SMA (f), or other similar female connectors. QuickCal is not applicable to waveguide.

Additional FAQs

FAQs on pages 8 through 12 apply to all microwave FieldFox models.

Question Answer

2. What is included with
N992xA Option 211?

3. What is included with
N992xA Option 010?

4. What is included with
N992xA Option 305?

5. What is included with
N992xA Option 308?

with time domain, why
would I order Option 305?
What additional
functionality is available?

7. What is included with
N992xA Option 112?

often used for distance-to-fault cable testing and are only available in CAT mode:

• 3-peak marker tracking for finding faults for DTF measurements

• 1-port cable loss

• 1-port and enhanced response QuickCal with a base analyzer

are provided for frequencies 18 GHz. Reduced accuracy for DUTs with 3.5 mm (m), SMA (m), or other
male coaxial connectors; performance is unspecified. QuickCal is not recommended for DUTs with

Find us at www.keysight.com Page 14

FieldFox Microwave Spectrum Analyzers

N9935A

9 GHz FieldFox microwave spectrum analyzer

100 kHz to 9 GHz

Type-N (f)

N9936A

14 GHz FieldFox microwave spectrum analyzer

100 kHz to 14 GHz

Type-N (f)

N9937A

18 GHz FieldFox microwave spectrum analyzer

100 kHz to 18 GHz

Type-N (f)

N9938A

26.5 GHz FieldFox microwave spectrum analyzer

100 kHz to 26.5 GHz

Type-N (f) 2

N9960A

32 GHz FieldFox microwave spectrum analyzer

9 kHz to 32 GHz

NMD 2.4 mm (m)

N9961A

44 GHz FieldFox microwave spectrum analyzer

9 kHz to 44 GHz

NMD 2.4 mm (m)

N9962A

50 GHz FieldFox microwave spectrum analyzer

9 kHz to 50 GHz

NMD 2.4 mm (m)

Spectrum analyzer

100 1

3.5 mm (m) connectors

Only available on N9938A. Not available as an upgrade.

Requires 220. Recommend 307. Requires two (2) FieldFox units.
See page 8, FAQ # 10. See page 10 for typical configuration.

220

Full-band tracking generator

CW, CW coupled, and tracking

235

Pre-amplifier

—

236

Interference analyzer and spectrogram

—

238

Spectrum analyzer time gating

—

312

Channel scanner

—

320 requires 220 on all models. On N9938A specifically, 320 also
requires 100.

350

Real-time spectrum analyzer (RTSA) 2

Recommend 235. See page 8, FAQ # 12

351

I/Q Analyzer (IQA) 2

—

Requires 307, and at least one of 312, 360, 370, 371, or 377. See
page 9, FAQ #17

353

IQ streaming

2

Requires 351

355

Analog demodulation

—

Requires 235, 309, and accessory item N9910X-713 BNC to SMB

source requirements.

358

EMF measurements

Requires triaxial antenna. See page 9, FAQ #18

360

Phased array antenna support

Requires phased array antenna. See page 9, FAQ #16

370

Over-the-Air (OTA) LTE FDD 2

Requires 307, Recommend 235.

371

Over-the-Air (OTA) LTE TDD 2

Requires 307, Recommend 235.

377

Over-the-Air (OTA) 5GTF 2

Requires 307, Recommend 235. See page 9, FAQ #19

Analyzer models

Step 1. Select the model that provides the desired frequency range.

Model Description Frequency range 1 Test port connectors

1. Useable to 5 kHz.

2. Order Option 100 for 3.5 mm (m) test port connectors. With N9938A- 100, the spectrum analyzer is built with 3.5 mm test port
connectors instead of the standard Type- N (f). Option 100 is a prerequisite for Option 320 for N9938A. Option 100 is not
available as an upgrade.

Analyzer options

Step 2. Select optional measurement capabilities. Any of these options can easily be added as a
software upgrade in the future.

Option Description Prerequisite options/notes

209 Extended range transmission analysis (ERTA)

320 Reflection measurements

352 Indoor and outdoor mapping

356 Noise figure (NF) 2

cable. See page 9, FAQ #15 for external preamplifier and noise

Find us at www.keysight.com Page 15

Option Description Prerequisite options/notes

Power measurements

208

USB power sensor meas. vs. frequency

Requires 302

302

USB power sensor support

Need to order USB power sensor 3. See page 10, FAQ #1

310

Built-in power meter

No power sensor required. See page 10, FAQ #2

Need to order USB peak power sensor. See page 11, FAQs #7 and
#8

030

Remote control capability

Requires an iOS device

307

GPS receiver

Need to order GPS antenna, N9910X-825. See page 12, FAQ #3

309

DC bias variable-voltage source

Recommend N9910X-713 cable, see page 12, FAQ #4

Optional 350, 351, 360, 370, 371, 377, PathWave VSA software.
See Accessories, page 23

Windows based software

89601B

PathWave VSA (89600 VSA) software

Requires CPU2 processor. See page 9, FAQ #13

N6820ES

Surveyor 4D software 2

Requires 235 and 307, see page 10, FAQ #20

Basic spectrum analysis, four traces, different detector types, radio standard
selection, limit lines

Channel power, occupied bandwidth, adjacent channel power, spectrum emission
mask

AM/FM tune and listen, field strength measurements, antenna factors, frequency
counter marker

Interference analyzer and spectrogram

Trace playback and recording

Return loss and VSWR

Normalization using data/memory

Option 320 on the N993xA/N996xA SA offers RL and VSWR. CAT mode on the

also various calibration capabilities such as QuickCal and OSL.

FieldFox analog demodulation has two parts: (1) Tune and listen, and (2) AM/FM

deviation, SINAD and more.

Additional FAQs

FAQs on pages 8 through 12 apply to all microwave FieldFox models.

330 Pulse meas. with USB peak power sensor

System features

— Frequency extender support

1. Order Option 100 for 3.5 mm (m) test port connectors. With N9938A- 100, the spectrum analyzer is built with 3.5 mm test port

connectors instead of the standard Type- N (f). Option 100 is a prerequisite for Option 320 for N9938A. Option 100 is not
available as an upgrade.

2. Requires CPU2 fast processor. See page 9, FAQ #13.

3. List of compatible power sensors available from www.keysight.com/find/fieldfoxsupport

FieldFox Spectrum Analyzer FAQs

Question Answer

1. What is included with the basic spectrum
analyzer?

2. What is included with Option 236?

3. What is included with Option 320?

4. What is the difference between Option 320 and
the CAT mode on the combo base model?

N991xA/N995xA combo analyzers offer RL and VSWR, DTF, insertion loss, and

metrics. Tune and listen are available as a standard feature on all N993xA and

5. What is included with Option 355?

N996xA FieldFox spectrum analyzers. AM/FM metrics becomes available when
Option 355 is purchased. AM/FM metrics provides the user with RF spectrum
view, demodulated baseband signal waveform, carrier power, frequency

Find us at www.keysight.com Page 16

Upgrades

010

VNA time domain analysis

License key

210, recommend 211

030

Remote control capability

License key

Requires an iOS device

112

Enable QuickCal

License key

None (Does not apply to N995xAU)

USB power sensor measurements versus
frequency

209

Extended range transmission analysis (ERTA) 1

License key

233 and 210 1, recommend 307

210

VNA transmission and reflection

License key

None

211

VNA full 2-port S-parameters

License key

210

212

Mixed-mode S-parameters

License key

210 and 211

215

TDR cable measurements

License key

None

233

Spectrum analyzer

License key

None

235

Preamplifier

License key

233

236

Interference analyzer and spectrogram

License key

233

238

Spectrum analyzer time gating

License key

233

302

External USB power sensor support

License key

None

307

GPS receiver

License key

None

308

Vector voltmeter

License key

210 and 211 for full VVM functionality

309

DC bias variable-voltage source

License key

Recommend N9910X-713 cable

310

Built-in power meter

License key

None

312

Channel scanner

License key

233

330

Pulse measurements

License key

Need to order USB peak power sensor

350

Real-time spectrum analyzer (RTSA)

License key 2

233, recommend 235

351

I/Q Analyzer (IQA)

License key 2

233

233, 307, and at least one of 312, 360, 370, 371, or
377

353

IQ streaming

License key

2

233, 351

355

Analog demodulation

License key

233

356

Noise figure (NF)

License key

2, 3

233, 235, 309 and accessory cable N9910X-713

233. Also requires triaxial antenna. See page 9, FAQ
#18

233. Also requires phased array antenna. See
page 9, FAQ#16

370

Over-the-Air (OTA) LTE FDD

License key 2

233 and 307, recommend 235

371

Over-the-Air (OTA) LTE TDD

License key 2

233 and 307, recommend 235

377

Over-the-Air (OTA) 5GTF

License key 2

233 and 307, recommend 235

Information on upgrades is available from: www.keysight.com/find/fieldfoxsupport

FieldFox microwave (combination) analyzer upgrades
N9913AU, N9914AU, N9915AU, N9916AU, N9917AU, N9918AU,
N9950AU, N9951AU, N9952AU

Option Description Upgrade contents Additional requirements

208

352 Indoor and outdoor mapping License key 2

License key 302

358 EMF measurements License key 2

360 Phased array antenna support License key 2

1. 209 is a system based on two FieldFox units. See page 8, FAQ #10, for a detailed description of the system requirements.

2. Requires CPU2 fast processor. See page 9, FAQ #13.

3. See page 9, FAQ #15 for external preamplifier and noise source requirements.

Find us at www.keysight.com Page 17

FieldFox signal analyzer upgrades

030

Remote control capability

License key

Requires an iOS device

100

3.5 mm connectors

Not applicable

Not applicable

USB power sensor measurements versus
frequency

209

Extended range transmission analysis (ERTA)

License key

220 1, recommend 307

220

Full-band tracking generator

License key

None

235

Preamplifier

License key

None

236

Interference analyzer and spectrogram

License key

None

238

Spectrum analyzer time gating

License key

None

302

External USB power sensor support

License key

None

307

GPS receiver

License key

None

309

DC bias variable-voltage

License key

Recommend N9910X-713 cable

310

Built-in power meter

License key

None

312

Channel scanner

License key

None

Option 220 for all models

Option 100 and 220 for N9938A

330

Pulse measurements

License key

Need to order USB peak power sensor

350

Real-time spectrum analyzer (RTSA)

License key 3

Recommend 235

351

I/Q Analyzer (IQA)

License key 3

None

352

Indoor and outdoor mapping

License key 3

307, and at least one of 312, 360, 370, 371, or 377

353

IQ streaming

License key

3

351

355

Analog demodulation

License key

None

356

Noise figure (NF)

License key

3, 4

235, 309 and accessory cable N9910X-713

358

EMF measurements

License key 3

Requires triaxial antenna. See page 9, FAQ #18

Requires phased array antenna. See page 9,
FAQ#16.

370

Over-the-Air (OTA) LTE FDD

License key 3

307, recommend 235

371

Over-the-Air (OTA) LTE TDD

License key 3

307, recommend 235

377

Over-the-Air (OTA) 5GTF

License key 3

307, recommend 235

N9935AU, N9936AU, N9937AU, N9938AU, N9960AU, N9961AU, N9962AU

Option Description Upgrade contents Additional requirements

208

License key 302

320 Reflection measurements License key 2

360 Phased array antenna support License key 3

1. 209 is a system based on two FieldFox units. See page 8, FAQ #10, for a detailed description of the system requirements.

2. On N9938A, Option 320 is only available as a software upgrade if the spectrum analyzer is already equipped with Option 100,
which is 3.5 mm connectors on the test port. Option 100 must have been ordered at the time of original purchase. It cannot be
upgraded later.

3. Requires CPU2 fast processor. See page 9, FAQ #13.

4. See page 9, FAQ #15 for external preamplifier and noise source requirements.

Find us at www.keysight.com Page 18

FieldFox VNA upgrades

010

VNA time domain analysis

License key

None

030

Remote control capability

License key

None

112

Enable QuickCal

License key

None

USB power sensor measurements versus
frequency

211

VNA full 2-port S-parameters

License key

None

212

Mixed-mode S-parameters

License key

211

215

TDR cable measurements

License key

305

302

External USB power sensor support

License key

None

305

Cable and antenna analyzer

License key

None

307

GPS receiver

License key

None

308

Vector voltmeter

License key

211 required to obtain full VVM functionality

309

DC bias variable-voltage source

License key

None

310

Built-in power meter

License key

None

330

Pulse measurements

License key

Need to order USB peak power sensor

N9913/14/15/16/17A processor
upgrade

Improved performance for
N9915/16/17A models

Improved performance for
N9925/26/27A models

Improved performance for
N9935/36/37A models

Improved performance for
N9918/28/38A models

N9925AU, N9926AU, N9927AU, N9928AU

Option Description Upgrade contents Additional requirements

208

License key 302

Information on upgrades is available from: www.keysight.com/find/fieldfoxsupport.

FieldFox RF and microwave analyzers hardware upgrades

Model number/Option

N9910HU-100

N9910HU-200 N9925/26/27A processor upgrade

N9910HU-300 N9935/36/37A processor upgrade

1, 2

Description Upgrade contents Additional requirements

Return to service center only

Return to service center only

Return to service center only

N9910HU-400 N9918/28/38A processor upgrade

1. Upgrades are not available for FieldFox analyzers with serial number prefix starting MY5607/SG5607/US5607, as these

analyzers already have the improved hardware.

2. Please contact your local Keysight Service Center for instructions on how and where to send the instrument and how to order

the factory upgrades.

Return to service center only

Find us at www.keysight.com Page 19

Documentation

N99xxA-0B0

Do not include User's Guide

N99xxA-ABA

Printed User's Guide in English

7-16

N9910X-802

3-in-1 OSL Cal kit

7/16 (m)

DC to 4 GHz

Open, short, load (all male)

N9910X-803

3-in-1 OSL Cal kit

7/16 (f)

DC to 4 GHz

Open, short, load (all female)

85038A

Standard cal kit

7/16

DC to 7.5 GHz

Open, short, load (both female and male)

N9910X-800 1

3-in-1 OSL cal kit

Type-N (m)

DC to 6 GHz

Open, short, load (all male)

N9910X-801 1

3-in-1 OSL cal kit

Type-N (f)

DC to 6 GHz

Open, short, load (all female)

85032E

Economy cal kit

Type-N (m)

DC to 6 GHz

Open, short, load (all male)

85514A

4-in-1 OSLT cal kit

Type-N (m)

DC to 9 GHz

Open, short, load, thru (all male)

85515A

4-in-1 OSLT cal kit

Type-N (f)

DC to 9 GHz

Open, short, load, thru (all female)

85032F

Standard cal kit

Type-N

DC to 9 GHz

Open, short, load (both female and male)

85518A

4-in-1 OSLT cal kit

Type-N (m)

DC to 18 GHz

Open, short, load, thru (all male)

85519A

4-in-1 OSLT cal kit

Type-N (f)

DC to 18 GHz

Open, short, load, thru (all female)

85054D

Economy cal kit

Type-N

DC to 18 GHz

Open, short, load, thru (both female and male)

Open, short, fixed load, sliding load (both
female and male)

85092C

ECal, 2-ports

Type-N

300 kHz to 9 GHz

Connectors configurable

N4690B/C

ECal, 2-ports

Type-N

300 kHz to 18 GHz

Connectors configurable

300 kHz to 18 GHz
or DC to 18 GHz

N7550A

ECal economy, 2-ports

Type-N

DC to 4 GHz

Connectors configurable

N7551A

ECal economy, 2-ports

Type-N

DC to 6.5 GHz

Connectors configurable

N7552A

ECal economy, 2-ports

Type-N

DC to 9 GHz

Connectors configurable

N7553A

ECal economy, 2-ports

Type-N

DC to 14 GHz

Connectors configurable

N7554A

ECal economy, 2-ports

Type-N

DC to 18 GHz

Connectors configurable

By default, a printed copy of the User’s Guide is not included in FieldFox orders. If you wish to receive
the printed User’s Guide, please order N99xxA Option ABA.

Option Description Notes

The latest FieldFox User’s Guide (manual) is available online from: www.keysight.com/find/fieldfoxsupport.
The Service Guide, SCPI Programming Guide, Quick Reference Guide, and Data Link software help file
can also be found via the website above.

Calibration Kits

FieldFox analyzers support most standard HP/Agilent/Keysight mechanical calibration kits and all Keysight
USB ECal modules. Component list shows calibration components, some calibration kits also include
adaptors. Custom calibration kits can be created and uploaded to FieldFox using Data Link software.

Model Description Connector Frequency range Components

Type-N, 50 Ω

85054B Standard cal kit Type-N DC to 18 GHz

N4690D ECal, 2-ports Type-N

Connectors configurable

Find us at www.keysight.com Page 20

Type-N, 75 Ω 2

85036B

Standard cal kit

Type-N 75 Ω

DC to 3 GHz

Open, short, load (both female and male)

85036E

Economy cal kit

Type-N(m) 75 Ω

DC to 3 GHz

Open, short, load, all male

85096C

ECal, 2-ports

Type-N(m) 75 Ω

300 kHz to 3 GHz

Connectors configurable

3.5 mm

85520A

4-in-1 OSLT

3.5 mm (m)

DC to 26.5 GHz

Open, short, load, thru (all male)

85521A

4-in-1 OSLT

3.5 mm (f)

DC to 26.5 GHz

Open, short, load, thru (all female)

85033D/E

Economy cal kit

3.5 mm

DC to 6/9 GHz

Open, short, fixed load (both female and male)

85052D

Economy cal kit

3.5 mm

DC to 26.5 GHz

Open, short, fixed load (both female and male)

Open, short, fixed load, sliding load (both
female and male)

Open, short, fixed load (both female and male),
two-line lengths

85093C

ECal, 2-ports

3.5 mm

300 kHz to 9 GHz

Connectors configurable

N4691B

ECal, 2-ports

3.5 mm

300 kHz to 26.5 GHz

Connectors configurable

300 kHz to 26.5 GHz
or DC to 26.5 GHz

N7550A

ECal economy, 2-ports

3.5 mm

DC to 4 GHz

Connectors configurable

N7551A

ECal economy, 2-ports

3.5 mm

DC to 6.5 GHz

Connectors configurable

N7552A

ECal economy, 2-ports

3.5 mm

DC to 9 GHz

Connectors configurable

N7553A

ECal economy, 2-ports

3.5 mm

DC to 14 GHz

Connectors configurable

N7554A

ECal economy, 2-ports

3.5 mm

DC to 18 GHz

Connectors configurable

N7555A

ECal economy, 2-ports

3.5 mm

DC to 26.5 GHz

Connectors configurable

85561A

4-in-1 OSLT cal kit

2.92 mm (f)

DC to 40 GHz

Open, short, fixed load, thru (all female)

85562A

4-in-1 OSLT cal kit

2.92 mm (m)

DC to 40 GHz

Open, short, fixed load, thru (all male)

Open, short, fixed load, sliding load (both
female and male)

85056KE02 4

Economy cal kit

2.92 mm

DC to 40 GHz

Open, short, fixed load (both female and male)

N4692A

ECal

2.92 mm

10 MHz to 40 GHz

Connectors configurable

85563A

3-in-1 OSL cal kit

2.4 mm (f)

DC to 50 GHz

Open, short, fixed load (all female)

85564A

3-in-1 OSL cal kit

2.4 mm (m)

DC to 50 GHz

Open, short, fixed load (all male)

85056D

Economy cal kit

2.4 mm

DC to 50 GHz

Open, short, fixed load (both female and male)

Open, short, load, fixed load, sliding load (both
female and male)

N4693A

ECal

2.4 mm

10 MHz to 50 GHz

Connectors configurable

N9911X-11x

Econ. waveguide cal kit

WR-137

5.38 to 8.18 GHz

Short, termination, offset length

N9911X-21x

Econ. waveguide cal kit

WR-90

8.2 to 12.5 GHz

Short, termination, offset length

N9911X-31x

Econ. waveguide cal kit

WR-62

11.9 to 18 GHz

Short, termination, offset length

N9911X-41x

Econ. waveguide cal kit

WR-42

17.6 to 26.7 GHz

Short, termination, offset length

X11644A

Waveguide cal kit

WR-90

8.2 to 12.4 GHz

Short, shim, termination, standard section

P11644A

Waveguide cal kit

WR-62

12.4 to 18 GHz

Short, shim, termination, standard section

K11644A

Waveguide cal kit

WR-42

18 to 26.5 GHz

Short, shim, termination, standard section

R11644A

Waveguide cal kit

WR-28

26.5 to 40 GHz

Short, shim, termination two straight sections

Q11644A

Waveguide cal kit

WR-22

33 to 50 GHz

Short, shim, termination, two straight sections

U11644A

Waveguide cal kit

WR-19

40 to 60 GHz

Short, shim, termination, two straight sections

85052B Standard cal kit 3.5 mm DC to 26.5 GHz

85052C Precision TRL kit 3.5 mm DC to 26.5 GHz

N4691D ECal, 2-ports 3.5 mm

2.92 mm (same as K connector)

85056KE01 3 Standard cal kit 2.92 mm DC to 40 GHz

2.4 mm

85056A Standard cal kit 2.4 mm DC to 50 GHz

Waveguide

Connectors configurable

1. This calibration kit is not eligible for annual re-calibration. There are also no data report calibrations (UK6, 1A7 and A6J). If
annual calibration is required, please order 85514A or 85515A.

2. Recommend ordering quantity 2 of N9910X Option 846, 50 to 75 Ω adapter.

3. Same as Maury’s 8770C47.

4. Same as Maury’s 8770D47.

Find us at www.keysight.com Page 21

Accessories

All cables listed below are rugged phase-stable cables.

N9910X-700

Type-N (m)

Type-N (f)

18 GHz

3.28 ft

1 m

N9910X-701

Type-N (m)

Type-N (m)

18 GHz

3.28 ft

1 m

N9910X-704

Type-N (m)

TNC (f)

13 GHz

5 ft

1.5 m

N9910X-705

Type-N (m)

TNC (m)

13 GHz

5 ft

1.5 m

N9910X-708

3.5 mm (m)

3.5 mm (f)

26.5 GHz

3.28 ft

1 m

N9910X-709

3.5 mm (f)

3.5 mm (f)

26.5 GHz

3.28 ft

1 m

N9910X-714

2.4 mm (f)

2.4 mm (m)

50 GHz

3.28 ft

1 m

N9910X-715

2.4 mm (f)

2.4 mm (f)

50 GHz

3.28 ft

1 m

N9910X-716

Type-N (m)

Type-N (m)

18 GHz

2 ft

0.61 m

N9910X-718

2.4 mm (f)

K / 2.92 mm (m)

40 GHz

3 ft

0.914 m

N9910X-810

Type-N (m)

Type-N (m)

8 GHz

5 ft

1.5 m

N9910X-811

Type-N (m)

Type-N (f)

8 GHz

5 ft

1.5 m

N9910X-812

Type-N (m)

Type-N (m)

8 GHz

12 ft

3.6 m

N9910X-813

Type-N (m)

Type-N (f)

8 GHz

12 ft

3.6 m

N9910X-814

Type-N (m)

7/16 (m)

6 GHz

5 ft

1.5 m

N9910X-815

Type-N (m)

7/16 (m)

6 GHz

12 ft

3.6 m

N9910X-816

Type-N (m)

Type-N (f)

6 GHz

3.28 ft

1 m

N9910X-817

Type-N (m)

Type-N (m)

6 GHz

3.28 ft

1 m

U7227A

USB preamplifier, 10 MHz to 4 GHz

www.keysight.com/find/U7227A

U7227C

USB preamplifier, 100 MHz to 26.5 GHz

www.keysight.com/find/U7227C

U7227F

USB preamplifier, 2 to 50 GHz

www.keysight.com/find/U7227F

U7228A

USB preamplifier, 10 MHz to 4 GHz

www.keysight.com/find/U7228A

U7228C

USB preamplifier, 100 MHz to 26.5 GHz

www.keysight.com/find/U7228C

U7228F

USB preamplifier, 2 to 50 GHz

www.keysight.com/find/U7228F

Noise source family

www.keysight.com/find/346noisesources

Cables

Model Cable connector Other cable connector Max frequency Length (ft) Length (m)

Preamplifiers

Noise sources

346A/B/C/K01/K40

Find us at www.keysight.com Page 22

Antennas

N9910X-820

Antenna, directional, multiband, 800 to 2500 MHz, 10 dBi, Type-N (f)

N9910X-821

Antenna, telescopic whip, 70 MHz to 1 GHz, BNC (m)

N9910X-822

Antenna, directional, log periodic, 600 MHz to 9 GHz, Type-N (f)

N9910XA-823 1

Antenna, cellular narrowband, 824 to 869 MHz, Type-N (f)

N9910XA-824 1

Antenna, cellular narrowband, PCS 1850 to 1990 MHz, Type-N (f)

N9910X-825

Antenna, GPS, active, SMA (m)

85571A-028 1

5G Phased Array Antenna 28 GHz

OML frequency extenders can be purchased directly through OML, Inc. One mixer, OML model number M28H2ADC-K (24 to 40 GHz),

the-air (LTE FDD, 5GTF), phased array antenna support and PathWave vector signal analysis software (formerly 89600 VSA).

Frequency range with FieldFox

M28H2ADC-K 1

24 to 40 GHz

24 to 40 GHz

24 to 34 GHz

M15H4ADC

50 to 75 GHz

50 to 75 GHz

50 to 62 GHz

M12H6ADC

60 to 90 GHz

60 to 90 GHz

60 to 90 GHz

M10H6ADC

75 to 110 GHz

75 to 110 GHz

75 to 90 GHz

1. Currently not RoHS compliant.

OML frequency extender modules

has been set up as a Keysight special handling part number N9910XM28-H2A for 3.5 mm test ports or N9910XM28-H2N for Type-N test
ports and they are available for sale directly through Keysight. Contact OML, Inc. directly (
datasheet information or contact a Keysight representative for assistance.
FieldFox operating modes that support frequency extenders include: Spectrum analyzer, real-time spectrum analyzer, I/Q analyzer, over-

www.omlinc.com) for pricing, ordering and

OML model number

1. Not applicable to N9951/61A and N9952/62A models with maximum frequency coverage of 44 and 50 GHz.

OML mixer frequency
range

models N9918/38A, N9917/37A, and
N995x/6xA

Frequency range with
FieldFox models N9916/36A

Find us at www.keysight.com Page 23

RF and microwave adapters

83059A

Coaxial adapter, 3.5 mm (m) to 3.5 mm (m), 26.5 GHz

83059B

Coaxial adapter, 3.5 mm (f) to 3.5 mm (f), 26.5 GHz

83059C

Coaxial adapter, 3.5 mm (m) to 3.5 mm (f), 26.5 GHz

N9910X-601

Coaxial adapter, NMD 2.4 mm (f) to Type-N (f), 50-ohm, 18 GHz

N9910X-602

Coaxial adapter, NMD 2.4 mm (f) to 2.92 mm/K (f), 40 GHz

N9910X-603

Coaxial adapter, NMD 2.4 mm (f) to 3.5 mm (f), 26.5 GHz

N9910X-604

3.5 mm NMD (f) to 3.5 mm (f) adapter, 26.5 GHz

N9910X-605

3.5 mm NMD (f) to Type-N (f) adapter, 18 GHz

N9910X-843

Coaxial adapter, Type-N (m) to 7/16 DIN (f)

N9910X-845

Adapter kit: Type-N (f) to 7/16 DIN (f), Type-N (f) to 7/16 DIN (m), Type-N (f) to Type-N (f)

N9910X-846

Coaxial adapter, Type-N (m) 50 ohm to Type-N (f) 75 ohm

N9910X-847

Adapter kit: Type-N (f) to TNC (m) adapter, Type-N (f) to TNC (f) adapter, 11 GHz

N9910X-848

Coaxial adapter, Type-N (f) to 3.5 mm (f), 18 GHz

N9910X-849

Coaxial adapter, Type-N (f) to 3.5 mm (m), 18 GHz

N9910X-850

Coaxial adapter, Type-N (m) to Type-N (m), 18 GHz

N9910X-851

Coaxial adapter, Type-N (f) to Type-N (f), 18 GHz

N9910X-852

Coaxial adapter, Type-N (m) to Type-N (f), 18 GHz

N9910X-856

Coaxial adapter, 2.4 mm (f) to 2.4 mm (f), 50 GHz

N9910X-857

Coaxial adapter, 2.4 mm (f) to 2.92 mm/K (f), 40 GHz

N9910X-860

Fixed attenuator, 40 dB, 100 W, DC to 3 GHz, Type-N (m) to Type-N (f)

N9910X-861

Fixed attenuator, 40 dB, 50 W, DC to 8.5 GHz, Type-N (m) to Type-N (f)

N9910X-874 1

External bias-tee, 2.5 MHz to 6 GHz, 1 W, 0.5 A

N9910X-886

Torque wrench, 17 mm, 90 N-cm (8 in-lb)

N9910X-712

Trig/Ref in Cable SMA (m) to BNC (f), 1 m or 3.28 ft

N9910X-713

Bias-tee power cable SMB (f) to BNC (m), 1 m or 3.28 ft

N9910X-876

Extra highcapacity battery

N9910X-872

External battery charger

N9910X-873

AC/DC adapter

N9910X-875

DC car charger and adapter

N9910X-880

Extra soft carrying case with backpack and shoulder strap

N9910X-881

Hard transit case

N9910X-886

Torque wrench, 17 mm, 90 N-cm (8 in-lb), recommended for N995xA and N996xA analyzers

Other RF and microwave accessories

1. Also recommend ordering N9910X-713 Bias-Tee Power Cable, SMB(f) to BNC(m), 3.28 ft., to connect to the FieldFox DC bias
variable voltage source port.

Other FieldFox accessories

Find us at www.keysight.com Page 24

Description Accessory

Description Accessory

N9910X-701
Type-N (m) to Type-N (m)
cable, 3.28 ft

N9910X-708

3.5 mm (m) to

3.5 mm (f) cable,

3.28 ft

N9910X-820
Antenna, directional

N9910XA-823
Antenna, cellular narrowband

N9910X-822
Antenna, directional

N9910X-825
Antenna, GPS, active

N9910X-812
Type-N (m) to Type-N (m) cable,
12 ft

N9910X-816
Type-N (m) to Type-N (f) cable,

3.28 ft

N9910X-821
Antenna, telescopic whip ™

N9910X-848
Coaxial adapter, Type-N(f) to

3.5 mm (f)

N9910X-875
DC car charger and adapter

N9910X-873
AD/DC adapter

N9910X-876
Extra high capacity battery

N9910X-872
External battery charger

N9910X-881
Hard transit case

N9910X-874
External bias-tee

N4690B
2-port ECal, Type-N,
18 GHz

N9910X-800
3-in-1 OSL cal kit, Type-N (m),
6 GHz

Find us at www.keysight.com Page 25

Description Accessory

Description Accessory

N9910X-811
Type-N (m) to
Type-N (f) cable, 5 ft

85514A
4-in-1 OSLT cal kit, Type-N (m)
9 GHz

85515A
4-in-1 OSLT cal kit, Type-N (f),
9 GHz

85518A
4-in-1 OSLT cal kit, Type-N (m),
18 GHz

N9910X-801
3-in-1 OSL cal kit, Type-N (f),
6 GHz

85520A
4-in-1 OSLT cal kit, 3.5 mm (m),

26.5 GHz

85521A
4-in-1 OSLT cal kit, 3.5 mm (f),

26.5 GHz

85033D/E

3.5 mm cal kit, 9 GHz

85519A
4-in-1 OSLT cal kit, Type-N (f),
18 GHz

85054D
Economy cal kit,
Type-N, 18 GHz

85052D

3.5 mm cal kit, 26.5 GHz

N9911X-211/212/213/214
WR-90 economical cal kit

Find us at www.keysight.com Page 26

This information is subject to change without notice. © Keysight Technologies, 2016 - 2021, Published in USA, November 1, 2021, 5990-9836EN

Learn more at: www.keysight.com

Description Accessory Description Accessory

N4691B
2-port ECal, 3.5 mm,

26.5 GHz

N4693A

2.4 mm 2-port ECal, 50 GHz

N4691D

3.5 mm, 2-port ECal, 26.5
GHz

N4693D

2.4 mm, 2-port ECal, 50 GHz

1

N4692A

2.92 mm, 2-port ECal,

1

40 GHz

1

85056D

2.4 mm cal kit, 50 GHz

N4692D

2.92 mm, 2-port ECal,
40 GHz

X11644A
WR-90 standard cal kit

1. Discontinued

For more information on Keysight Technologies’ products, applications, or services,
please contact your local Keysight office. The complete list is available at:
www.keysight.com/find/contactus

Find us at www.keysight.com Page 27
