Keysight Add Source and Receiver
Attenuators Upgrade Kit
o Upgrade PNA N5224A/B or N5225A/B Option 401 to Option 417 or
T
PNA-X N5244A/B or N5245A/B Option 401 to Option 417
For Analyzers with Serial Numbers Prefixed MY/SG/US5150 and Below
Upgrade Kit Order Numbers: N5224AU-417, N5225AU-417,
N5224BU-417, N5225BU-417, N5244AU-417, N5245AU-417,
N5
244BU-417, and N5245BU-417
Keysight Kit Number: N5225-60107
Installation Note
Notices
© Keysight Technologies, Inc.
2009-2019
No part of this manual may be
reproduced in any form or by any
means (including electronic storage
and retrieval or translation into a
foreign language) without prior
agreement and written consent from
Keysight Technologies, Inc. as
governed by United States and
international copyright laws.
Trademark Acknowledgments
Manual Part Number
N5225-90107
Edition
Edition 2, June 2019
Supersedes: July 2017
Printed in USA/Malaysia
Published by:
Keysight Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403
Warranty
THE MATERIAL CONTAINED IN THIS
DOCUMENT IS PROVIDED “AS IS,”
AND IS SUBJECT TO BEING
CHANGED, WITHOUT NOTICE, IN
FUTURE EDITIONS. FURTHER, TO
THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW, KEYSIGHT
DISCLAIMS ALL WARRANTIES,
EITHER EXPRESS OR IMPLIED WITH
REGARD TO THIS MANUAL AND
ANY INFORMATION CONTAINED
HEREIN, INCLUDING BUT NOT
LIMITED TO THE IMPLIED
WARRANTIES OF
MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
KEYSIGHT SHALL NOT BE LIABLE
FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN
CONNECTION WITH THE
FURNISHING, USE, OR
PERFORMANCE OF THIS
DOCUMENT OR ANY INFORMATION
CONTAINED HEREIN. SHOULD
KEYSIGHT AND THE USER HAVE A
SEPARATE WRITTEN AGREEMENT
WITH WARRANTY TERMS
COVERING THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH
THESE TERMS, THE WARRANTY
TERMS IN THE SEPARATE
AGREEMENT WILL CONTROL.
Technology Licenses
The hardware and/or software
described in this document are
furnished under a license and may be
used or copied only in accordance
with the terms of such license.
U.S. Government Rights
The Software is “commercial
computer software,” as defined
by Federal Acquisition Regulation
(“FAR”) 2.101. Pursuant to FAR
12.212 and 27.405-3 and
Department of Defense FAR
Supplement (“DFARS”) 227.7202,
the U.S. government acquires
commercial computer software
under the same terms by which
the software is customarily
provided to the public.
Accordingly, Keysight provides
the Software to U.S. government
customers under its standard
commercial license, which is
embodied in its End User License
Agreement (EULA), a copy of
which can be found at
http://www.keysight.com/find/sweula
The license set forth in the EULA
represents the exclusive authority
by which the U.S. government
may use, modify, distribute, or
disclose the Software. The EULA
and the license set forth therein,
does not require or permit,
among other things, that
Keysight: (1) Furnish technical
information related to
commercial computer software
or commercial computer
software documentation that is
not customarily provided to the
public; or (2) Relinquish to, or
otherwise provide, the
government rights in excess of
these rights customarily provided
to the public to use, modify,
reproduce, release, perform,
display, or disclose commercial
computer software or
commercial computer software
documentation. No additional
government requirements
beyond those set forth in the
EULA shall apply, except to the
extent that those terms, rights, or
licenses are explicitly required
from all providers of commercial
computer software pursuant to
the FAR and the DFARS and are
set forth specifically in writing
elsewhere in the EULA. Keysight
shall be under no obligation to
update, revise or otherwise
modify the Software. With
respect to any technical data as
defined by FAR 2.101, pursuant
to FAR 12.211 and 27.404.2 and
DFARS 227.7102, the U.S.
government acquires no greater
than Limited Rights as defined in
FAR 27.401 or DFAR 227.7103-5
(c), as applicable in any technical
data.
Safety Notices
A CAUTION notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or adhered
to, could result in damage to the
product or loss of important data. Do
not proceed beyond a CAUTION
notice until the indicated conditions
are fully understood and met.
A WARNING notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that,
if not correctly performed or adhered
to, could result in personal injury or
death. Do not proceed beyond a
WARNING notice until the indicated
conditions are fully understood and
met.
Keysight Add Source and Receiver Attenuators Upgrade Kit
Upgrade Kit Number: N5225-60107
Installation Note
Description of the Upgrade
Some of the assembly drawings in this document may be different from
your instrument, but the process is similar for both an "A" model and "B"
model instruments.
If you had an A model PNA-X with Option 219/419 with Option H85 that
was upgraded to a B model, please refer to Options 217/417. If you had an
A model PNA-X with Option 224/423 with Option H85 that was upgraded
to a B model then refer to Option 222/422.
This upgrade adds the following items to your N5224A/B Option 401 or
N5225A/B Option 401 or N5244B Option 401 or N5245B Option 401 network
analyzer:
— a 60-dB source attenuator in each source port channel
— a 35-dB receiver attenuator in each receiver channel
— front panel overlay replacement
— new cables
After installation of this upgrade, your analyzer will be an N5224A/B Option
417 or N5225A/B Option 417 or N5244B Option 417 or N5245B Option 417.
1
-
Description of the Upgrade
Getting Assistance from Keysight
Getting Assistance from Keysight
By internet, phone, or fax, get assistance with all your test and measurement
needs.
Contacting Keysight
Assistance with test and measurements needs and information on finding a
local Keysight office are available on the Web at:
http://www.keysight.com/find/assist
If you do not have access to the Internet, please contact your Keysight field
engineer.
In any correspondence or telephone conversation, refer to the Keysight
product by its model number and full serial number. With this information,
the Keysight representative can determine whether your product is still
within its warranty period.
If You Have Problems With the Upgrade Kit Contents
Keysight stands behind the quality of the upgrade kit contents. If you have
problems with any item in the kit, refer to www.keysight.com and the Contact
Keysight link.
2 Installation Note N5225-90107
Description of the Upgrade
Getting Prepared
Getting Prepared
The PNA contains extremely sensitive components that can be ruined if
mishandled. Follow instructions carefully when making cable connections,
especially wire harness connections.
The person performing the work accepts responsibility for the full cost of
the repair or replacement of damaged components.
To successfully install this upgrade kit, you will need the following:
—A license key - refer to “License Key File Redemption” below.
— A PDF copy or a paper copy of the PNA Service Guide - refer to
— An ESD-safe work area - refer to “Protecting Your Workspace from
— Correct tools - refer to “Tools Required for the Installation” on page 6.
“Downloading the Online PNA Service Guide” below.
Electrostatic Discharge” below.
— Enough time - refer to “About Installing the Upgrade” on page 6.
— Test equipment for the post-upgrade adjustments and full instrument
calibration. To view the equipment list, click the Chapter 3 bookmark “Tests
and Adjustments” in the PDF Service Guide
1
.
1. See “Downloading the Online PNA Service Guide” on page 5.
Installation Note N5225-90107 3
-
Description of the Upgrade
Getting Prepared
License Key File Redemption
The only difference between an A model license key redemption and a B
model is that the A model uses a 12-character license key and the B model
uses a license key file.
Ensure that you are connected to an external server, before attempting to
download your email and license key file.
If you are unfamiliar with the licensing process:
For A models: Refer to
http://literature.cdn.keysight.com/litweb/pdf/N5225-90110.pdf.
For B models: Refer to
http://literature.cdn.keysight.com/litweb/pdf/N5242-90024.pdf.
The enclosed Software Entitlement Certificate is a receipt, verifying that
you have purchased a licensed option for the analyzer of your choice. You
must now use a Keysight Web page to request a license key email that
contains the license key files for the instrument that will receive the
option.
To enable the option product, you must request license key(s) (A models) or
license key files(s) (B models) from the Keysight Software Manager:
http://www.keysight.com/find/softwaremanager.
To complete the request, you will need to gather the following information:
— From the certificate
— Order number
— Certificate number
— From your instrument
(Instrument information is available in the network analyzer - on the
toolbar, click Help, then click About Network Analyzer.)
— Model number
— Serial number
— A models ONLY: From the online Keysight HostID utility
Part of the OEC procedure to obtain the 12-digit license key online requires
you to provide the HostID number of the PNA. This HostID number is NOT
the one currently shown on the PNA. To find your new HostID, go to
http://www.na.support.keysight.com/pna/upgrades.html and, using the
HostID utility, enter the PNA serial number and your new, upgraded PNA-X
model number - N5224A, N5225A, N5244A, or N5245A.
—Host ID
4 Installation Note N5225-90107
Description of the Upgrade
Getting Prepared
Using the information just gathered, you must request license key(s) for your A
model or for your B models, a license key file(s) from the Keysight Software
Manager: http://www.keysight.com/find/softwaremanager.
You will need to provide an email address, Keysight will promptly email your A
model license key(s) or a for a B model, license key file(s) attachment message.
Refer to “License Key File Redemption” on page 4.
Verify the License Contents
Refer to the license message you received from Keysight:
If the model number, serial number, or option number do not match those on
the license message you received from Keysight, you will not be able to install
the license key file. If this is the case, contact Keysight for assistance. Refer to
“Getting Assistance from Keysight” on page 3.
Downloading the Online PNA Service Guide
To view the online Service Guide for your PNA model number, use the following
steps:
1. Go to www.keysight.com.
2. In the Search box, enter the model number of the analyzer (Ex: N5242A)
and click Search.
3. Click Technical Support > Manuals.
4. Click Service Manual.
5. Click the service guide title to download the PDF file.
6. When the PDF of the Service Guide is displayed, scroll through the
Contents section bookmarks to locate the information needed.
Protecting Your Workspace from Electrostatic Discharge
For information, click on the Chapter 1 bookmark, “Electrostatic Discharge
Protection” in the PDF Service Guide.
ESD Equipment Required for the Installation
Description Keysight Part Number
ESD grounding wrist strap 9300-1367
5-ft grounding cord for wrist strap 9300-0980
2 x 4 ft conductive table mat and 15-ft grounding wire 9300-0797
ESD heel strap (for use with conductive floors) 9300-1308
Installation Note N5225-90107 5
-
Description of the Upgrade
Getting Prepared
Tools Required for the Installation
Description Qty Part Number
T-10 TORX driver - set to 9 in-lbs (1.02 N.m) 1 N/A
T-20 TORX driver - set to 21 in-lbs (2.38 N.m) 1 N/A
5/16-in (8 mm) nutsetter or open end torque wrench - set to
10 in-lbs (1.13 N.m)
1N/A
Use a 5/16-in torque wrench set to 10 in-lbs on all cable connections.
About Installing the Upgrade
Products affected N5224A/B, N5225A/B, N5244B, and N5245B Option 401
Installation to be performed by Keysight service center or personnel qualified by Keysight
Estimated installation time 2 hours
Estimated adjustment time 0.5 hour
Estimated full instrument calibration time 4.5 hours
6 Installation Note N5225-90107
Description of the Upgrade
Items Included in the Upgrade Kit
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any part is missing or
damaged, contact Keysight Technologies. Refer to “Getting Assistance from
Keysight” on page 2.
Table 1 Contents of Upgrade Kit N5225-60107
Ref
Desig.
-- Installation note (this document) 1 N5225-90107
-- Software Entitlement Certificate 1 5964-5145
A38–
A41
A46–
A49
0–60 dB source step attenuator 4 33325-60022
0-35 dB receiver step attenuator 4 33325-60023
Attenuator bracket (For A47 port 3 & A48 port 4 rcvr attenuators & all src
-attenuators.)
-- Attenuator bracket (For A46 port 1 and A49 port 2 receiver attenuators.) 2 N5225-00001
-- Lower Front panel overlay — PNA A models (N5224/5A) 1 N5225-80003
-- Lower Front panel overlay — PNA B models (N5224/5B) 1 N5225-80006
-- Lower Front panel overlays — PNA-X models (N5244/5B) 1 N5242-80031
Machine screw, M3 x 8, pan head (to attach brackets to attenuators; to attach port 1
-and port 2 receiver attenuators to deck)
Machine screw, M3 x 6, pan head (to attach source attenuators and port 3 and port 4
-receiver attenuators to deck)
Description Qty Part Number
6 N5245-00015
27 0515-0372
15 0515-0430
Machine screw, M3.0 x 6, flat head (to attach front frame to coupler
-plate)
-- Cable tie wrap 6 1400-0249
-- Cable clamp 11 1400-1334
-- Protective caps 4 1401-0214
W12 A29 port 1 receiver coupler to W11 1 N5245-20050
W18 A32 port 2 receiver coupler to W17 1 N5245-20049
W21 A29 port 1 receiver coupler to A37 reference mixer switch 1 N5245-20008
W25 A30 port 3 receiver coupler to front-panel REF 3 SOURCE OUT 1 N5245-20116
W29 A31 port 4 receiver coupler to front-panel REF 4 SOURCE OUT 1 N5245-20117
W33 RF cable, A32 port 2 receiver coupler to front-panel REF 2 SOURCE OUT 1 N5245-20010
W47 REF 2 RCVR R2 IN to A27 mixer brick (R2) 1 N5245-20115
Installation Note N5225-90107 7
2 0515-1946
-
Description of the Upgrade
Items Included in the Upgrade Kit
Table 1 Contents of Upgrade Kit N5225-60107
Ref
Desig.
Description Qty Part Number
W81 RF cable, A29 test port 1 receiver coupler to A38 test port 1 source attenuator 1 N5245-20029
W82 RF cable, A38 test port 1 source attenuator to front-panel Port 1 SOURCE OUT 1 N5245-20077
W85 RF cable, A30 test port 3 receiver coupler to A39 test port 3 source attenuator 1 N5245-20026
W86 RF cable, A39 test port 3 source attenuator to front-panel Port 3 SOURCE OUT 1 N5245-20027
W89 RF cable, A31 test port 4 receiver coupler to A40 test port 4 source attenuator 1 N5245-20026
W90 RF cable, A40 test port 4 source attenuator to front-panel Port 4 SOURCE OUT 1 N5245-20028
W93 RF cable, A32 test port 2 receiver coupler to A41 test port 2 source attenuator 1 N5245-20029
W94 RF cable, A41 test port 2 source attenuator to front-panel Port 2 SOURCE OUT 1 N5245-20031
W97 RF cable, front-panel Port 1 RCVR A IN to A46 port 1 receiver attenuator 1 N5245-20054
W98 RF cable, A46 port 1 receiver attenuator to A27 mixer brick (A) 1 N5245-20056
W99 RF cable, front-panel Port 3 RCVR C IN to A47 port 3 receiver attenuator 1 N5245-20073
W100 RF cable, A47 port 3 receiver attenuator to A28 mixer brick (C) 1 N5245-20066
W101 RF cable, front-panel Port 4 RCVR D IN to A48 port 4 receiver attenuator 1 N5245-20074
W102 RF cable, A48 port 4 receiver attenuator to A28 mixer brick (D) 1 N5245-20075
W103 RF cable, Port 2 RCVR B IN to A49 port 2 receiver attenuator 1 N5245-20055
W104 RF cable, A49 port 2 receiver attenuator to A27 mixer brick (B) 1 N5245-20057
-- Ribbon cable, A23 test set motherboard J205 to A46 port 1 receiver attenuator
-- Ribbon cable, A23 test set motherboard J206 to A47 port 3 receiver attenuator
4 N5245-60026
-- Ribbon cable, A23 test set motherboard J207 to A48 port 4 receiver attenuator
-- Ribbon cable, A23 test set motherboard J208 to A49 port 2 receiver attenuator
-- Ribbon cable, A23 test set motherboard J549 to A38 test port 1 source attenuator
-- Ribbon cable, A23 test set motherboard J547 to A39 test port 3 source attenuator
4 N5245-60006
-- Ribbon cable, A23 test set motherboard J548 to A40 test port 4 source attenuator
-- Ribbon cable, A23 test set motherboard J546 to A41 test port 2 source attenuator
Extra quantities of items such as protective plastic caps, screws, cable ties,
and cable clamps may be included in this upgrade kit. It is normal for some
of these items to remain unused after the upgrade is completed.
8 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Installation Procedure for the Upgrade
The network analyzer must be in proper working condition prior to installing
this option. Any necessary repairs must be made before proceeding with this
installation.
This installation requires the removal of the analyzer’s protective
outer covers. The analyzer must be powered down and
disconnected from the mains supply before performing this
procedure.
Some of the following figures provided in this procedure contain bias tees.
Bias tees are included in the Option 219/419 upgrade kits and can be
ignored for Options 217/417 and 222/422.
Overview of the Installation Procedure
“Step 1. Obtain a Keyword and Verify the Information.”
“Step 2. Remove the Outer Cover.”
“Step 3. Remove Some Bottom-Side (Test Set) Cables.”
“Step 4. Assemble the Port 1 and Port 2 Receiver Attenuator Assemblies.”
“Step 5. Install the Port 1 and Port 2 Receiver Attenuator Assemblies.”
“Step 6. Assemble the Port 3 and Port 4 Receiver Attenuator Assemblies.”
“Step 7. Install the Port 3 and Port 4 Receiver Attenuator Assemblies.”
“Step 8. Assemble the Source Attenuator Assemblies.”
“Step 9. Install the Source Attenuator Assemblies.”
“Step 10. Install Some Bottom-Side (Test Set) Cables.”
“Step 11. Remove the Old Lower Front Panel Overlay.”
“Step 12. Reinstall Front Panel Assembly.”
“Step 13. Install the New Lower Front Panel Overlay.”
“Step 14. Reinstall Front Panel Jumpers.”
“Step 15. Install the Second Source Boards.”
“Step 16. Reinstall the Outer Cover.”
“Step 17. Remove Option 401 License.”
“Step 18. Enable Option 417.”
“Step 19. Perform Post-Upgrade Adjustments and Calibration.”
“Step 20. Prepare the PNA for the User.”
Installation Note N5225-90107 9
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 1. Obtain a Keyword and Verify the Information
Follow the instructions on the Software Entitlement Certificate supplied to
obtain a license key for installation of this upgrade. Refer to “License Key File
Redemption” on page 4.
Verify that the model number, serial number, and option number information
on the license key match those of the instrument on which this upgrade will be
installed.
If the model number, serial number, or option number do not match those on
your license key, you will not be able to install the option. If this is the case,
contact Keysight for assistance before beginning the installation of this
upgrade. Refer to “Contacting Keysight” on page 2.
Once the license key (A models) or license key file (B models) has been
received and the information verified, you can proceed with the installation at
“Step 2. Remove the Outer Cover” on page 10.
If the model number, serial number, or option number do not match those
on your license key (A models) or license key file (B models), you will not
be able to install the option. If this is the case, contact Keysight for
assistance before beginning the installation of this upgrade. Refer to
“Contacting Keysight” on page 2.
Step 2. Remove the Outer Cover
For instructions, click the Chapter 7 bookmark “Removing the Covers” in the
PDF Service Guide.
Step 3. Remove Some Bottom-Side (Test Set) Cables
Leave the gray flexible cables, the wire harnesses, and the ribbon cables
connected where possible. Any that are removed should be labeled for
reconnection later.
Be careful not to damage the center pins of the semirigid cables. Some
flexing of the cables may be necessary but do not over-bend them.
1. Place the analyzer bottom-side up on a flat surface.
2. Remove the following cables. To see an image showing the location of
these cables, click the Chapter 6 bookmark “Bottom RF Cables, Standard
4-Port Configuration, Option 401” in the PDF Service Guide
1
.
These cables may be discarded - they will not be reinstalled.
— W12 (N5245-20109) A29 port 1 receiver coupler to W11
1. See “Downloading the Online PNA Service Guide” on page 5.
10 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
— W18 (N5245-20111) A32 port 2 receiver coupler to W17
— W19 (N5245-20039) A29 test port 1 receiver coupler to front-panel
Port 1 SOURCE OUT
— W21 (N5245-20110) A29 port 1 receiver coupler to A37 reference
mixer switch
— W23 (N5245-20051) A30 test port 3 receiver coupler to front-panel
Port 3 SOURCE OUT
— W25 (N5245-20016) A30 port 3 receiver coupler to front-panel REF 3
SOURCE OUT
— W27 (N5245-20052) A31 test port 4 receiver coupler to front-panel
Port 4 SOURCE OUT
— W29 (N5245-20017) A31 port 4 receiver coupler to front-panel REF 4
SOURCE OUT
— W31 (N5245-20040) A32 test port 2 receiver coupler to front-panel
Port 2 SOURCE OUT
— W33 (N5245-20108) A32 port 2 receiver coupler to front-panel REF 2
SOURCE OUT
— W37 (N5245-20041) Front-panel Port 1 RCVR A IN to A27 mixer brick
(A)
— W38 (N5245-20037) Front-panel Port 3 RCVR C IN to A28 mixer brick
(C)
— W39 (N5245-20038) Front-panel Port 4 RCVR D IN to A28 mixer brick
(D)
— W40 (N5245-20042) Port 2 RCVR B IN to A27 mixer brick (B)
— W46 (N5245-20011) Front-panel REF 2 RCVR R2 IN to A27 mixer brick
(R2)
These cables must be saved - they will be reinstalled.
— W14 (N5245-20043) A30 port 3 receiver coupler to W13
— W16 (N5245-20044) A31 port 4 receiver coupler to W15
— W44 (N5245-20020) REF 3 RCVR R3 IN to A28 mixer brick (R3)
— W45 (N5245-20021) REF 4 RCVR R4 IN to 3 dB pad on A28 mixer brick
(R4)
— W36 (N5245-20155) Front panel jumpers (quantity = 12)
NOTE: Remove and save the cable guards for the front panel jumpers.
Installation Note N5225-90107 11
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 4. Assemble the Port 1 and Port 2 Receiver Attenuator Assemblies
Refer to Figure 1 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
Figure 1 Port 1 and Port 2 Receiver Attenuator and Bracket Assembly
Step 5. Install the Port 1 and Port 2 Receiver Attenuator Assemblies
Refer to Figure 2 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
12 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 2 Port 1 and Port 2 Receiver Attenuator Assemblies Installation
Step 6. Assemble the Port 3 and Port 4 Receiver Attenuator Assemblies
Refer to Figure 3 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
Installation Note N5225-90107 13
-
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 3 Port 3 and Port 4 Receiver Attenuator and Bracket Assembly
Step 7.Install the Port 3 and Port 4 Receiver Attenuator Assemblies
Refer to Figure 4 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
14 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 4 Port 3 and Port 4 Receiver Attenuator Assemblies Installation
Installation Note N5225-90107 15
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 8.Assemble the Source Attenuator Assemblies
Refer to Figure 5 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
Figure 5 Source Attenuator and Brackets Assembly
16 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Step 9. Install the Source Attenuator Assemblies
Refer to Figure 6 for this step of the procedure. New parts are listed in Table 1
on page 7. Use a T-10 TORX driver to tighten all screws.
Figure 6 A26 and A27 Test Port Bridge Assembly
Installation Note N5225-90107 17
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 10. Install Some Bottom-Side (Test Set) Cables
Follow the two instructions shown in Figure 5 in this document. New parts are
listed in Table 1 on page 7 of this document.
Follow instructions carefully when making cable connections, especially
wire harness connections. Incorrect connections can destroy components,
resulting in additional customer costs.
Install the Semirigid Cables
To see an image showing the location of these cables, click the Chapter 6
bookmarks “Bottom RF Cables, 4-Port Configuration, Option 417” in the PDF
Service Guide
Install the following new cables in the order listed.
— W103 (N5245-20055) Port 2 RCVR B IN to A49 port 2 receiver
attenuator
1
. New parts are listed in Table 1 on page 7.
— W94 (N5245-20031)
A41 port 2 source attenuator to front-panel Port 2
SOURCE OUT
— W33 (N5245-20010) A32 port 2 receiver coupler to front-panel REF 2
SOURCE OUT
* As shown in Figure 7, install four clamps (part number 1400-1334) to
secure W33.
1. See “Downloading the Online PNA Service Guide” on page 5.
18 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 7 Location of Cable Clamps for W33 N5245-20010
— W104 (N5245-20057) A49 port 2 receiver attenuator to A27 mixer brick
(B)
— W47 (N5245-20115) REF 2 RCVR R2 IN to A27 mixer brick (R2)
— W101 (N5245-20074) Port 4 RCVR D IN to A48 port 4 receiver
attenuator
— W45 (reuse) (N5245-20021) REF 4 RCVR R4 IN to 3 dB pad on A28
mixer brick (R4)
— W90 (N5245-20028)
A40 port 4 source attenuator to front-panel Port 4
SOURCE OUT
— W102 (N5245-20075) A48 port 4 receiver attenuator to A28 mixer brick
(D)
— W29 (N5245-20117) A31 port 4 receiver coupler to front-panel REF 4
SOURCE OUT
* As shown in Figure 8, install one clamp (part number 1400-1334) to
secure W29.
Installation Note N5225-90107 19
-
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 8 Location of Cable Clamps for W29 (N5245-20117)
— W18 (N5245-20049) A32 port 2 receiver coupler to W17
— W85 (N5245-20026) A30 port 3 receiver coupler to A39 port 3 source
attenuator
— W89 (N5245-20026) A31 port 4 receiver coupler to A40 port 4 source
attenuator
— W99 (N5245-20073) Port 3 RCVR C IN to A47 port 3 receiver attenuator
— W86 (N5245-20027)
A39 port 3 source attenuator to front-panel Port 3
SOURCE OUT
— W25 (N5245-20116) A30 port 3 receiver coupler to front-panel REF 3
SOURCE OUT
— W100 (N5245-20066) A47 port 3 receiver attenuator to A28 mixer brick
(C)
— W44 (reuse) (N5245-20020) REF 3 RCVR R3 IN to A28 mixer brick (R3)
* As shown in Figure 9, install two cable ties (part number 1400-0249) to
secure W25 and W44.
20 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 9 Location of Cable Ties for W25 and W44 (N5245-20116)
— W14 (reuse) (N5245-20043) A30 port 3 receiver coupler to W13
— W16 (reuse) (N5245-20044) A31 port 4 receiver coupler to W15
— W97 (N5245-20054) Front-panel Port 1 RCVR A IN to A46 port 1
receiver attenuator
— W82 (N5245-20077)
A38 port 1 source attenuator to front-panel Port 1
SOURCE OUT
— W21 (N5245-20008) A29 port 1 receiver coupler to A37 reference mixer
switch
* As shown in Figure 10, install one cable tie (part number 1400-0249) and
one clamp (part number 1400-1334) to secure W21.
Installation Note N5225-90107 21
-
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 10 Location of Cable Tie and Clamp for W21 (N5245-20008)
* If the screws that attach the reference mixer switch to the test set deck
were loosened, torque these screws now to 9 in-lbs.
— W98 (N5245-20056) A46 port 1 receiver attenuator to A27 mixer brick
(A)
— W81 (N5245-20029) A29 port 1 receiver coupler to A38 port 1 source
attenuator
— W93 (N5245-20029)A32 port 2 receiver coupler to A41 port 2 source
attenuator
Install the Ribbon Cables
To see an image showing the location of these cables, click the Chapter 6
bookmarks “Bottom Ribbon Cables and Wire Harnesses, 4-Port, Option 417” in
1
the PDF Service Guide
. New parts are listed in Table 1 on page 7.
Connect step attenuator ribbon cables as follows:
— (N5245-60006) A38 port 1 source step attenuator to A23 test set
motherboard J549
— (N5245-60006) A39 port 3 source step attenuator to A23 test set
motherboard J547
— (N5245-60006) A40 port 4 source step attenuator to A23 test set
motherboard J548
1. See “Downloading the Online PNA Service Guide” on page 5.
22 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
— (N5245-60006) A41 port 2 source step attenuator to A23 test set
motherboard J546
— (N5245-60026) A46 port 1 receiver step attenuator to A23 test set
motherboard J205
— (N5245-60026) A47 port 3 receiver step attenuator to A23 test set
motherboard J206
— (N5245-60007) A48 port 4 receiver step attenuator to A23 test set
motherboard J207
— (N5245-60007) A49 port 2 receiver step attenuator to A23 test set
motherboard J208.
Installation Note N5225-90107 23
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 11.Remove the Old Lower Front Panel Overlay
Refer to Figure 11 on page 25 for this step of the procedure. New parts are
listed in Table 1 on page 7.
1. From the back side of the front panel, use a blunt object in the cutouts in
the lower front dress panel to push on the old overlay (item
separate it from the front dress panel.
2. From the front side of the front panel, pull off the overlay completely and
discard it.
3. Remove any adhesive remaining on the front panel.
To avoid possible damage to the lower front panel overlay (label), do not
attempt to attach the lower front panel label until
Lower Front Panel Overlay” on page 26
.
“Step 13. Install the New
) and
24 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 11 Lower Front Panel Overlay Replacement
Installation Note N5225-90107 25
-
Description of the Upgrade
Installation Procedure for the Upgrade
Step 12.Reinstall Front Panel Assembly
For instructions on reinstalling the front panel assembly, click the Chapter 7
bookmark “Removing and Replacing the Front Panel Assembly” in the PDF
1
Service Guide
.
Step 13.Install the New Lower Front Panel Overlay
Refer to Figure 11 on page 25 for this step of the procedure. New parts are
listed in Table 1 on page 7.
1. Remove the protective backing from the new front panel overlay,
N5225-80003 for PNA N5224/5A or N5225-80006 for PNA N5224/5B or
N5242-80031 for PNA-X N5244/5B models (item Á).
2. Starting from either side, loosely place the overlay in the recess on the
lower front panel, ensuring that it fits tightly against the edges of the
recess.
3. Once the overlay is in place, press it firmly onto the frame to secure it.
Step 14.Reinstall Front Panel Jumpers
Reinstall all twelve of the front panel jumper cables (W36), part number
N5245-20155. Torque to 10 in-lbs.
Step 15.Install the Second Source Boards
On the top side of the PNA, carefully position the gray flex cables so they can’t
be pinched between the covers and the rails.
On the bottom side of the PNA, carefully fold or push down the ribbon cables
and wires so they can’t be pinched between the hardware and the outer cover.
Ribbon cables and wires must never be positioned on top of hardware.
1. See “Downloading the Online PNA Service Guide” on page 5.
26 Installation Note N5225-90107
Description of the Upgrade
System
Service
Option Enable
Installation Procedure for the Upgrade
Step 16.Reinstall the Outer Cover
— For instructions, click the Chapter 7 bookmark “Removing the Covers” in
the PDF Service Guide
1
Step 17. Remove Option 401 License
Procedure Requirements
— The analyzer must be powered up and operating to perform this procedure.
— The Network Analyzer program must not be running.
— A keyboard and mouse must be connected to the network analyzer.
A Model Option 401 License Removal Procedure
For B models, refer to “B Model Option 401 License Removal Procedure.”
1. To start the option enable utility, press UTILITY , then ,
then . An option enable dialog box will appear.
2. Click the arrow in the Select Desired Option box. A list of available options
will appear.
3. In the Select Desired Option list, click 401.
4. Click Remove.
B Model Option 401 License Removal Procedure
For A models, refer to “A Model Option 401 License Removal Procedure.”
1. To start the Keysight License Manager, press Start > Keysight License
Manager > Keysight License Manager . A Keysight License Manager dialog
box will appear.
2. Right click the on the desired option and click Delete.
3. In the Keysight License Manager dialog box that appears, press or click
Yes to confirm delete.
4. A message displays stating that the option removal was successful.
1. See “Downloading the Online PNA Service Guide” on page 5.
Installation Note N5225-90107 27
-
System
Service
Option Enable
Description of the Upgrade
Installation Procedure for the Upgrade
Step 18. Enable Option 417
Procedure Requirements
— The analyzer must be powered up and operating to perform this procedure.
— The Network Analyzer program must not be running.
— Refer to the license message you received from Keysight: Verify that the
analyzer’s model and serial numbers match those on the license message
you received from Keysight.
— Obtain a license key (A models) or license key file (B models) for installation
of this upgrade by following the instructions on the supplied Software
Entitlement Certificate.
— A keyboard must be connected to the network analyzer.
For "A" models, refer to “Option Enable Procedure for "A" Model Instruments”
on page 28.
For "B" models refer to “Option Enable Procedure for "B" Model Instruments ”
on page 29.
Option Enable Procedure for "A" Model Instruments
1. To start the option enable utility, press UTILITY , then ,
then . An option enable dialog box will appear.
2. Click the arrow in the Select Desired Option box. A list of available options
will appear.
3. In the Select Desired Option list, click 417 - Configurable TS + Attens.
4. Using the keyboard, enter the license key in the box provided. The license
key is printed on the license message you received from Keysight. Enter
this key exactly as it is printed on the message.
5. Click Enable.
6. Click Yes in answer to the displayed question in the Restart Analyzer?
box.
7. When the installation is complete, click Exit.
"A" Model Option Verification Procedure
Once the analyzer has restarted and the Network Analyzer program is again
running:
1. On the analyzer’s Help menu, click About Network Analyzer.
2. Verify that “417” is listed after “Options:” in the display.
28 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
3. Click OK.
If if the option has not been enabled or an older option has not been
removed, contact Keysight Technologies. Refer to “Getting Assistance
from Keysight” on page 2
.
Option Enable Procedure for "B" Model Instruments
For this step, you will need a USB flash drive.
A single license file may contain more than one feature.
1. Locate the email(s) from Keysight which contain license file attachments.
These emails are a result of Step 3 on “License Key File Redemption” on
page 4.
2. Copy the license file(s) from the email(s) to the root directory of the USB
flash drive.
More than one license file may be copied to the USB flash drive.
A license file may contain more than one feature.
3. Verifying and editing the license file:
For these steps, refer to the example in Figure 12 on page 30.
a. Verify your USB flash drive is connected to a PC.
b. Open your license file using a text read/write program similar to
Notepad.
c. If you have more than one licensed feature, delete the feature that is
not required for this upgrade. (e.g., in this case N5242B-423 is the
correct upgrade. So, N5242B-422 is to be deleted from the text file.)
Installation Note N5225-90107 29
-
Description of the Upgrade
Installation Procedure for the Upgrade
Figure 12 Editing a Keysight License File Using a Text Editor
The figure above may not contain your specific features and is an example
only. In this example N5242B-422 is the incorrect feature. N5242B-423 is
the correct feature
d. Re-save the text license file to the root directory of your USB flash
drive.
e. Verify that only the single correctly edited text license file is in the
root directory of your USB drive.
f. Eject your USB flash drive and remove the USB flash drive from your
PC.
4. Connect the USB flash drive to the PNA. Within 5 seconds, the PNA
should display a small "New licenses installed" message.
Else, load the license key file(s), manually move your license file(s) to
C:\Program Files\Agilent\ licensing. It may take Keysight License
Manager an extra ~5 seconds to enable the licenses.
Attempting to re-install a license file that is already installed may generate
a “Corrupt Media” error message. Ignore this message.
5. Disconnect the USB flash drive from the PNA.
6. On the analyzer, click or press to open the KLM software from your PNA’s
Windows taskbar by pressing Start > More Programs > Keysight License
Manager folder > Keysight License Manager and verify the options are
correct.
30 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
"B" Model Option Verification Procedure
If if the option(s) have not been enabled or if Option 401 has not been
removed, contact Keysight Technologies. Refer to
from Keysight” on page 2
.
“Getting Assistance
1. Start the Network Analyzer program.
2. Once the Network Analyzer program is running:
— Press Help > About NA and verify that Option 419 or 423 is listed in
the PNA application.
3. After successful installation of all upgrades, some features require some
adjustments to ensure the instrument meets its specified performance.
Refer to the following Web site: http://na.support.keysight.com/pna.
Step 19.Perform Post-Upgrade Adjustments and Calibration
Adjustments
The following adjustments must be made due to the hardware changes of the
analyzer.
—source adjustment
— IF gain adjustment
— receiver characterization
—receiver adjustment
— IF Response adjustment (For A model: Options 090, 093, or 094 Only. For B
models: Options S93090xA/B, S93093A/B, or S93094A/B Only.)
— Noise adjustment (For N5244/5B models: Option 029 with S93029A/B
Only.)
These adjustments are described in the PNA Service Guide and in the PNA
on-line HELP. A list of equipment required to perform these adjustments is also
found in the service guide.
To view this service guide information, click the Chapter 3 bookmark “Tests
1
and Adjustments” in the PDF Service Guide
.
After the specified adjustments have been performed, the analyzer should
operate and phase lock over its entire frequency range.
1. See “Downloading the Online PNA Service Guide” on page 5.
Installation Note N5225-90107 31
-
Description of the Upgrade
Installation Procedure for the Upgrade
Operator’s Check
Perform the Operator’s Check to check the basic functionality of the analyzer.
For instructions, click the Chapter 3 bookmark “Tests and Adjustments” in the
PDF Service Guide
1
.
If you experience difficulty with the basic functioning of the analyzer, contact
Keysight. Refer to “Contacting Keysight” on page 2.
Calibration
Although the analyzer functions, its performance relative to its specifications
has not been verified. It is recommended that a full instrument calibration be
performed using the analyzer’s internal performance test software. To view
information on the performance test software, click the Chapter 3 bookmark
“Tests and Adjustments” in the PDF Service Guide.
32 Installation Note N5225-90107
Description of the Upgrade
Installation Procedure for the Upgrade
Step 20.Prepare the PNA for the User
1. If necessary, reinstall front jumper cables.
2. Install the cable guards, pushing them over the front jumper cables until
the cushioning material touches the front panel of the PNA.
3. Install the dust caps on the test ports.
4. Clean the analyzer, as needed, using a damp cloth.
Installation Note N5225-90107 33
This information is subject to change
without notice.
© Keysight Technologies 2011-2019
Edition 2, June 2019
N5225-90107
www.keysight.com
Loading...
