CONFIGURATION GUIDE
EPM and EPM-P Series Power Meters
E-Series Power Sensors
Introduction
This configuration guide describes the standard configurations, options, and compatible accessories of
EPM Series and EPM-P Series power meters. For full specifications, see EPM Series Power Meters ESeries and 8480 Series Power Sensors - Data Sheet (Keysight literature number 5965-6382E) or
E4416A/E4417A EPM-P Series Power Meters and E-Series E9320 Peak and Average Power Sensors –
Data Sheet (Keysight literature number 5980-1469E). Contact your local Keysight Technologies, Inc.
representative at the offices listed on the back of this guide if you need more information.
EPM Series power meters
•
N1913A power meter (single channel)
•
N1914A power meter (dual channel)
EPM-P Series power meters
•
E4416A power meter (single channel)
•
E4417A power meter (dual channel)
E-Series power sensors
•
E441xA CW power sensors (10 MHz to 26.5 GHz, sensor dependent)
•
E9300 average power sensors (9 kHz to 18 GHz, sensor dependent)
•
E9320 peak and average power sensors (50 MHz to 18 GHz, sensor dependent)
2
EPM-P Series Power Meters
The EPM-P Series power meters provide peak, peak-to-average ratio, average, and time-gated power
measurements. For peak, peak-to-average ratio, and time-gated measurements, the EPM-P Series power
meters must operate with the E-Series E9320 power sensors. For average power measurements only,
the EPM-P Series power meters are compatible with all the 8480 Series power sensors, the E-Series CW,
the E-Series E9300 average power sensors, and the E-Series E9320 power sensors.
The standard E4416A and E4417A power meters include:
•
Single-channel power meter, order E4416A
•
Dual-channel power meter, order E4417A
•
Input sensor connector(s) on the front panel
•
Reference calibrator connector on the front panel
•
Power sensor cable, 1.5 m (5 ft). (One per E4416A, two per E4417A)
•
Power cord (plug matches destination requirements)
EPM Series Power Meters
The EPM Series power meters provide average power measurements.
The standard N1913A and N1914A power meters include:
•
Single-channel power meter, order N1913A
•
Dual-channel power meter, order N1914A
•
Input sensor connector(s) on the front panel
•
Reference calibrator connector on the front panel
•
Power sensor cable, 1.5 m (5 ft) (One per N1913A, two per N1914A)
•
USB cable Type A to Mini-B, 6 ft
•
Standard Calibration of Certificate
•
Power cord (plug matches destination requirements)
3
E-Series Power Sensors
The standard E4412A and E4413A CW power sensors include:
•
Power sensor 10 MHz to 18 GHz, order E4412A
•
Power sensor 50 MHz to 26.5 GHz, order E4413A
The standard E9300 average power sensors include:
+20 to –60 dBm:
•
Power sensor 10 MHz to 18 GHz, order E9300A
•
Power sensor 10 MHz to 6 GHz, order E9301A
•
Power sensor 9 kHz to 6 GHz, order E9304A
+30 to –50 dBm:
•
Power sensor 10 MHz to 18 GHz, order E9300H
•
Power sensor 10 MHz to 6 GHz, order E9301H
+44 to –30 dBm:
•
Power sensor 10 MHz to 18 GHz, order E9300B
•
Power sensor 10 MHz to 6 GHz, order E9301B
The standard E9320 peak and average power sensors include:
•
Power sensor, 50 MHz to 6 GHz, 300 kHz bandwidth, order E9321A
•
Power sensor, 50 MHz to 6 GHz, 1.5 MHz bandwidth, order E9322A
•
Power sensor, 50 MHz to 6 GHz, 5 MHz bandwidth, order E9323A
•
Power sensor, 50 MHz to 18 GHz, 300 kHz bandwidth, order E9325A
•
Power sensor, 50 MHz to 18 GHz, 1.5 MHz bandwidth, order E9326A
•
Power sensor, 50 MHz to 18 GHz, 5 MHz bandwidth, order E9327A
Please refer to the N1913A/14A data sheet for more average power sensor selections.
4
Compatibility
Power sensors compatibility
For compatibility of power meters, power sensors, and power sensor cables, please refer to the table below.
Power sensors
Power meters
Power sensor cables
EPM-P
Series
EPM Series
11730 (grey)
E9288 (blue)
E441x family
Yes
Yes
Yes
Yes
E9300 family
Yes
Yes
Yes
Yes
E9320 family
Yes
No
No
Yes
8480 Series
Yes
Yes
Yes
Yes
N8480 Series
Yes
Yes
Yes
Yes
U8480, U2000 and
U2040/50/60
Series (except
U2049XA & U2060
Series in Average
Mode only) USB
No
Yes
Not applicable
Not applicable
Firmware compatibility
Firmware upgrade information can be accessed from the World Wide Web, free of charge.
Calibration Options
•
E441xA/B-A6J - Supplies ANSI Z540 certificate of calibration with data.
•
E441xA/B-1A7 - Supplies ISO 17025 certificate of calibration with data.
•
N1913/4A-A6J - Supplies ANSI Z540 certificate of calibration with data.
•
N1913/4A-1A7 - Supplies ISO 17025 certificate of calibration with data.
•
E93xxA/B/H-A6J - Supplies ANSI Z540 certificate of calibration with data.
5
Hardware Options
The following options are available on the EPM and EPM-P Series power meters. All order combinations
must be configured upon ordering; these options are not available for field upgrade.
EPM Series power meters
Option
Description
N1913/4A-004
Delete power sensor cable(s)
N1913/4A-101
1
Single/dual-channel average power meter
N1913/4A-201
Single/dual-channel average power meter with VGA, trigger in/out, one front and one rear
USB ports
N1913/4A-B01
Without battery (Mandatory for option 201)
N1913/4A-C01
Front calibrator, front sensor (Need to order option 201)
N1913/4A-C02
Front calibrator, parallel front, and rear sensor (Need to order option 201)
N1913/4A-C03
Rear calibrator, parallel front, and rear sensor (Need to order option 201)
N1913A-200
436A and 437B code compatibility via GPIB interface only. 436A and 437B language modes
are not compatible with LAN or USBTM remote interface. For new N1913A purchase.
N1914A-200
438A code compatibility via GPIB interface only. 438A language mode is not
compatible with LAN or USBTM remote interface. For new N1914A purchase
N1913/4A-908
Rack mount kit (one instrument). Can be ordered as standalone
N1913/4A-909
Rack mount kit (two instruments). Can be ordered as standalone
BV0007B
BenchVue Power Meter/Sensor Control and Analysis app license
N6901A-1FP
436A and 437B code compatibility for N1913A. Post purchase upgrade only
N6902A-1FP
438A code compatibility for N1914A. Post purchase upgrade only
1. Op tio n 10 1 p r ovi d es the fro n t c ali b rat or a nd t he fro n t s e nso r(s ) , a n d i t c a n’t be ord e red wit h a n y o f th e o p tio ns B 0x/ C 0x.
EPM-P Series power meters
Option
Description
E441xA/B-002
Parallel rear panel sensor input connector(s) and front panel reference calibrator connector
E441xA/B-003
Parallel rear panel sensor input connector(s) and rear panel reference calibrator connector
E441xA/B-004
Delete power sensor cable(s)
E441xA/B-908
Rack mount kit (one instrument). Can be ordered as stand-alone
E441xA/B-909
Rack mount kit (two instruments). Can be ordered as stand-alone
6
Service and Support Options
Calibration 1
The following calibration options are available:
Option
Description
R-50C-011-3
Calibration Assurance Plan - Return to Keysight - 3 years
R-50C-011-5
Calibration Assurance Plan - Return to Keysight - 5 years
R-50C-016-3
ISO 17025 compliant calibration plan, 3 years
R-50C-016-5
ISO 17025 compliant calibration plan, 5 years
R-50C-021-3
ANSI Z540-1-1994 calibration plan, 3 years
R-50C-021-5
ANSI Z540-1-1994 calibration plan, 5 years
1. Options are not available in all countries.
Special Options
Special options for EPM-P Series power meters, EPM Series power meters, and E-Series sensors are
available. The special options provide customized measurement capabilities to fit a wider range of
applications. Contact your local Keysight representative for more information.
Orderable Documentation
Documentation
EPM-P series power meter
EPM series power meter
User’s Guide and Installation
Guide (English)
E441xA-0B1
N1913/4A-0B1
Programming Guide
E441xA-0BF
N1913/4A-0BF
Service Guide
E441xA-0B3
Not available
Delete manual set
E441xA-0B0
N1913/4A-0B0
Add manual set, User’s Guide
and Programming Guide
(English)
E441xA-0BK
N1913/4A-0BK
Printed User’s Guide in
Japanese
E441xA-ABJ
N1913/4A-ABJ
Documentation
E4412/3A
E9300
E9320A
Add manual set
E4412/3A-0B1
E930xx-0B1
E932xA-0B1
Printed User’s Guide in
Japanese
E4412/3A-ABJ
E930xx-ABJ
—
7
Available Accessories
E9288A-C power sensor cables (refer to the compatibility section):
•
1.5 meters (5 ft) E9288A
•
3 meters (10 ft) E9288B
•
10 meters (31 ft) E9288C
11730A-F power sensor cables (refer to the compatibility section):
•
1.5 meters (5 ft) 11730A
•
3 meters (10 ft) 11730B
•
6.1 meters (20 ft) 11730C
•
15.2 meters (50 ft) 11730D
•
30.5 meters (100 ft) 11730E
•
61 meters (200 ft) 11730F
Accessory pouch, 34161A
•
Holds accessories supplied or ordered
Basic instrument transit case, 34131A
•
Protects the power meter during transit
Soft carry/operating case, 34141A
•
Power meter with battery option can be operated in soft carry case
Auxiliary Equipment
The 11683A range calibrator verifies the accuracy and linearity of the EPM-P and EPM Series power
meters. Outputs corresponding to the meter readings of 3, 10, 30, 100, and 300 μW and 1, 3, 10, 30, and
100 mW are provided. Calibration uncertainty is ±0.25% on all ranges.
Fo r m ore in for mat ion on Ke ysi ght Te chn olo gie s’ pro duc ts, app lic ati ons , or ser vic es,
pl eas e v isi t: www. key sig ht. com
Th is inf orm ati on is sub jec t t o c han ge wit hou t n oti ce. © K eysi ght Te chn olo gie s, 2010 - 20 22,
Pu bli she d i n U SA, Jun e 2 8, 202 2, 5990 -41 73E N
Literature References
Publication title
Publication number
EPM-P Series Single and Dual-Channel Power Meters E9320 Family of Peak and
Avera - Technical Overview
5980-1471E
E4416A/E4417A EPM-P Series Power Meters and E-Series E9320 Peak and Average
Power Sensors – Data Sheet
5980-1469E
EPM-P Series Single and Dual Channel Power Meters – Data Sheet
5988-1605EN
Choosing the Right Power Meter and Sensor - Application Note
5968-7150E
EPM Series Power Meters E-Series and 8480 Series Power Sensors - Data Sheet
5965-6382E
EPM Series Power Meters - Brochure
5965-6380E
Fundamentals of RF and Microwave Power Measurements - Application Note
5965-6630E
4 Steps for Making Better Power Measurements - Application Note
5965-8167E
Wide dynamic range. Multiple modulation formats. One sensor. - Technical Overview
5968-4960E
Seven Reasons to Migrate from an E4418/4419B to a Keysight N1913/1914A EPM Series
Power Meter - Migration Guide
5990-4016EN
