E36300 Series
Programmable DC
User’s Guide
Power Supplies
Notices 5
Copyright Notice 5
Manual Part Number 5
Edition 5
Published by 5
Warranty 5
Technology Licenses 5
U.S. Government Rights 6
Third Party Licenses 6
Waste Electrical and Electronic Equipment (WEEE) 6
Declarations of Conformity 6
Safety Information 7
Safety and Regulatory Information 8
Safety Considerations 8
Safety Symbols 9
Regulatory Markings 10
South Korean Class A EMC declaration: 10
Safety and EMC Requirements 10
Environmental Conditions 11
1 Getting Started 13
Product Introduction 14
Front panel at a glance 15
Rear panel at a glance 17
Meter view 18
Data logger view 20
Dimension diagram 21
Setup the instrument 21
Prepare Instrument for Use 22
Initial inspection 22
Standard shipped items 22
Documentation and firmware revisions 22
Recommended calibration interval 22
Options and Fuse Information 23
Ensure the correct AC input voltage and fuse settings 23
Programming Ranges 25
Installation 26
Connecting the power cord 26
Connecting the outputs 27
Parallel and series connections (E36312A and E36313A only) 30
4-wire sense connection (E36312A and E36313A only) 32
Interface Connections 34
Installing the optional GPIB interface (E36312A and E36313A only) 38
Rack mounting the instrument 39
Remote Interface Configuration 40
Keysight IOLibraries Suite 40
GPIB configuration 40
LAN configuration 41
More about IP addresses and dot notation 46
Remote Control 47
Web interface 47
2
Keysight E36300 Series User's Guide
Technical connection details 48
Use the Built-in Help System 49
View the help information for the front panel key 49
View the list of help topics 49
Firmware Update 51
Front Panel Menu Reference 52
2 General Operating Information 53
Turning the Unit On 54
View the error log 55
Controlling the Outputs 56
Step 1 - Select an output 56
Step 2 - Set the output voltage and current 56
Step 3 - Enable the output 57
Step 4 - View the output voltage and current 57
Constant voltage and constant current 58
Using the Protection Function 59
Protection function 59
Configuring protection 59
Clears and OVP and OCP Event 61
Specifying 2-Wire or 4-Wire Sense (E36312A and E36313A Only) 62
Using the Tracking Operation 62
Configuring the Output Turn On Turn Off Sequence (E36312A and E36313A Only) 63
Step 1 – Set the output voltage and current of the output channels: 63
Step 2 – Configure the turn-on turn-off delays: 63
Step 3 – Coupling selected outputs: 63
Step 4 – Use the AllOutputs On and Off keys: 64
Specifying the Operation Mode (E36312A and E36313A Only) 65
Using the Digital Control Port (E36312A and E36313A Only) 66
Bi-directional digital IO 66
Digital input 68
Fault output 68
Inhibit input 69
Fault/inhibit system protection 70
Trigger input 71
Trigger output 72
Output couple controls 72
Using the Output LIST (E36312A and E36313A Only) 75
Step 1– Add/remove steps to/from the LIST 75
Step 2 – Configure the output sequence 76
Step 3 – Run the output sequence list 78
Using the Data Logger Function (E36312A and E36313A Only) 80
Logging data 80
Step 1 – Program the sequence for the output channels 80
Step 2 – Configure the data logger traces 81
Step 3 – Configure the data logger properties 82
Step 4 – Turn on Output 1, start the sequencing and log the data. 82
Step 5 – Export the data 83
Data logger view 84
Adjusting the waveform display 85
Data logger properties and waveform settings 86
Save the datalog 88
Keysight E36300 Series User's Guide 3
Locking/Unlocking the Front Panel 91
Capturing a Screen 91
Enabling the E3631A Mode 92
Utilities Menu 93
Utilities Menu - Store and Recall State 93
Store Settings 94
Recall Settings 96
Power On Setting 97
Set to Defaults 97
Utilities Menu - I/O Configuration 98
LAN Settings 98
Digital IO (E36312A and E36313A only) 99
GPIB (optional and applicable to E36312A and E36313A only) 99
Utilities Menu - Test / Setup 100
Calibration 100
Self Test 100
User Settings 101
Low Range 102
Help 102
Utilities Menu - Error 103
Utilities Menu - Manage Files 104
Action 104
Browse 104
File Name 105
3 Characteristics and Specifications 107
4
Keysight E36300 Series User's Guide
Notices
Copyright Notice
© Keysight Technologies 2017
No part of this manual may be reproduced in any form or by any means (including electronic storage and retrieval or
translation into a foreign language) without prior agreement and written consent from Keysight Technologies as
governed by United States and international copyright laws.
Manual Part Number
E36311-90001
Edition
Edition 1, April 30, 2017
Published by
Keysight Technologies
Bayan Lepas Free Industrial Zone
11900 Bayan Lepas, Penang
Malaysia
Warranty
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS SUBJECT TO BEING CHANGED,
WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, KEYSIGHT DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, WITH REGARD TO THIS MANUAL
AND ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. KEYSIGHT SHALL NOT BE LIABLE FOR ERRORS
OR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE FURNISHING, USE, OR
PERFORMANCE OF THIS DOCUMENT OR OF ANY INFORMATION CONTAINED HEREIN. SHOULD KEYSIGHT AND
THE USER HAVE A SEPARATE WRITTEN AGREEMENT WITH WARRANTY TERMS COVERING THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH THESE TERMS, THE WARRANTY TERMS IN THE SEPARATE AGREEMENT
SHALL CONTROL.
Technology Licenses
The hardware and/or software described in this document are furnished under a license and may be used or copied
only in accordance with the terms of such license.
Keysight E36300 Series User's Guide 5
U.S. Government Rights
The Software is “commercial computer software,” as defined by Federal Acquisition Regulation (“FAR”) 2.101.
Pursuant to FAR 12.212 and 27.405-3 and Department of Defense FAR Supplement (“DFARS”) 227.7202, the U.S.
government acquires commercial computer software under the same terms by which the software is customarily
provided to the public. Accordingly, Keysight provides the Software to U.S. government customers under its
standard commercial license, which is embodied in its End User License Agreement (EULA), a copy of which can be
found at http://www.keysight.com/find/sweula. The license set forth in the EULA represents the exclusive authority
by which the U.S. government may use, modify, distribute, or disclose the Software. The EULA and the license set
forth therein, does not require or permit, among other things, that Keysight: (1) Furnish technical information
related to commercial computer software or commercial computer software documentation that is not customarily
provided to the public; or (2) Relinquish to, or otherwise provide, the government rights in excess of these rights
customarily provided to the public to use, modify, reproduce, release, perform, display, or disclose commercial
computer software or commercial computer software documentation. No additional government requirements
beyond those set forth in the EULA shall apply, except to the extent that those terms, rights, or licenses are explicitly
required from all providers of commercial computer software pursuant to the FAR and the DFARS and are set forth
specifically in writing elsewhere in the EULA. Keysight shall be under no obligation to update, revise or otherwise
modify the Software. With respect to any technical data as defined by FAR 2.101, pursuant to FAR 12.211 and
27.404.2 and DFARS 227.7102, the U.S. government acquires no greater than Limited Rights as defined in FAR
27.401 or DFAR 227.7103-5 (c), as applicable in any technical data.
Third Party Licenses
Portions of this software are licensed by third parties including open source terms and conditions, copies of which
may be found in http://www.opensource.apple.com/source/CommonCrypto/CommonCrypto-7/Source/.
Waste Electrical and Electronic Equipment (WEEE)
This product complies with the WEEE Directive) marketing requirement. The affixed product label (see below)
indicates that you must not discard this electrical/electronic product in domestic household waste.
Product Category: With reference to the equipment types in the WEEE directive Annex 1, this product is classified as
“Monitoring and Control instrumentation” product. Do not dispose in domestic household waste.
To return unwanted products, contact your local Keysight office, or see
about.keysight.com/en/companyinfo/environment/takeback.shtml for more information.
Declarations of Conformity
Declarations of Conformity for this product and for other Keysight products may be downloaded from the Web. Go
to http://regulations.corporate.keysight.com/DoC/search.htm and click on “Declarations of Conformity.” You can
then search by product number to find the latest Declaration of Conformity.
6
Keysight E36300 Series User's Guide
Safety Information
A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed
or adhered to, could result in damage to the product or loss of important data. Do not proceed beyond a CAUTIONnotice until the
indicated conditions are fully understood and met.
A WARNING notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in personal injury or death. Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met.
Keysight E36300 Series User's Guide 7
Safety and Regulatory Information
Safety Considerations
The following general safety precautions must be observed during allphases of operation, service, and repair of this
instrument. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates
safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no
liability for the customer's failure to comply with these requirements.
BEFORE APPLYING POWER
– Verify that the product is set to match the available line voltage and that the correct fuse is installed. Use the label
on the rear of the instrument to configure the power. See Options and Fuse Information for additional details.
– Ensure the mains supply voltage fluctuation do not exceed ±10% of the nominal supply voltage.
GROUND THE INSTRUMENT
This product is a Safety Class I instrument (provided with a protective earth terminal). To minimize shock hazard, the
instrument chassis and cabinet must be connected to an electrical ground. The instrument must be connected to the
AC power supply mains through a three-conductor power cable, with the third wire firmly connected to an electrical
ground (safety ground) at the power outlet. Any interruption of the protective(grounding) conductor or disconnection of the protective earth terminal will cause a potential shock hazard that could result in personal injury. If
the instrument is to be energized via an external autotransformer for voltage reduction, be certain that the autotransformer common terminal is connected to the neutral (earthed pole) of the AC power lines (supply mains).
DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE OR WET ENVIRONMENTS
Do not operate the device around flammable gases or fumes, vapor, or wet environments.
DO NOT OPERATE DAMAGED OR DEFECTIVE INSTRUMENTS
Instruments that appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel.
DO NOT SUBSTITUTE PARTS OR MODIFY INSTRUMENT
Because of the danger of introducing additional hazards, do not install substitute parts or perform any unauthorized
modification to the instrument. Return the instrument to a Keysight Technologies Sales and Service Office for service
and repair to ensure that safety features are maintained. To contact Keysight for sales and technical support, refer to
the support links on the following Keysight website: www.keysight.com/find/assist (worldwide contact inform-
ation for repair and service).
USE THE POWER CORD PROVIDED
Use the device with the power cord provided with the shipment.
USE THE DEVICE AS SPECIFIED
If the device is used in a manner not specified by manufacturer, the device protection may be impaired.
DO NOT BLOCK VENTILATION HOLES
Do not block any of the ventilation holes of the device.
OBSERVE ALL DEVICE MARKINGS BEFORE CONNECTING TO DEVICE
Observe all markings on the device before connecting any wiring to the device.
8
Keysight E36300 Series User's Guide
TURN DEVICE OFF BEFORE CONNECTING TO OUTPUT TERMINALS
Turn off the device power before connecting to the output terminals.
ENSURE COVER IS SECURED IN PLACE
Do not operate the device with the cover removed or loosened.
TURN DEVICE OFF ANDREMOVEALL CONNECTIONS BEFORE INSTALLING THEGPIB INTERFACE
Turn off the power and remove all connections, including the power cord, from the instrument prior installation of
the GPIB interface.
CLEAN WITH SLIGHTLY DAMPENED CLOTH
Clean the outside of the instrument with a soft, lint-free, slightly dampened cloth. Do not use detergent, volatile
liquids, or chemical solvents.
Connect USB cable with ferrite core to the rear panel USB port of the instrument.
Safety Symbols
Symbol Description
Caution, risk of danger (refer to the manual for specific Warning or Caution information)
Protective earth (ground) terminal.
Frame or chassis (ground) terminal.
Standby supply. The instrument is not completely disconnected from AC mains when switch is off.
Alternating current (AC).
Plus, positive polarity.
Minus, negative polarity.
The WARNING sign denotes a hazard. It calls attention to a procedure, practice, or the like, which, if not correctly performed
or adhered to, could result in personal injury. Do not proceed beyond a WARNING sign until the indicated conditions are fully
understood and met.
The CAUTION sign denotes a hazard. It calls attention to an operating procedure, or the like, which, if not correctly
performed or adhered to, could result in damage to or destruction of part or all of the product. Do not proceed beyond
CAUTION sign until the indicated conditions are fully understood and met.
The NOTE sign denotes important information. It calls attention to a procedure, practice, condition or the like, which is
essential to highlight.
Keysight E36300 Series User's Guide 9
Regulatory Markings
Symbol Description
The RCM mark is a registered trademark of the Australian Communications and Media Authority.
The CE mark is a registered trademark of the European Community. This CE mark shows that the product
complies with all the relevant European Legal Directives.
ICES/NMB-001 indicates that this ISM device complies with the Canadian ICES-001.
Cet appareil ISM est conforme a la norme NMB-001 du Canada.
ISM GRP.1 Class A indicates that this is an Industrial Scientific and Medical Group 1 Class A product.
This symbol indicates the time period during which no hazardous or toxic substance elements are expected to
leak or deteriorate during normal use. Forty years is the expected useful life of the product.
This symbol is a South Korean Class A EMC Declaration. This is a Class A instrument suitable for professional
use and in electromagnetic environment outside of the home.
The CSA mark is a registered trademark of the Canadian Standards Association.
South Korean Class A EMC declaration:
Information to the user:
This equipment has been conformity assessed for use in business environments. In a residential environment this
equipment may cause radio interference.
– This EMC statement applies to the equipment only for use in business environment.
사 용 자 안 내 문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가
정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다.
– 사용자 안내문은 “업무용 방송통신기자재”에만 적용한다.
Safety and EMC Requirements
This power supply is designed to comply with the following safety and EMC (Electromagnetic Compatibility)
requirements:
– Low Voltage Directive 2014/35/EU
– EMC Directive 2014/30/EU
10
Keysight E36300 Series User's Guide
Environmental Conditions
The E36300 Series is designed for indoor use and in an area with low condensation. The table below shows the
general environmental requirements for this instrument.
Environmental condition Requirement
Temperature Operating condition: 0 °C to 40 °C
Storage condition: –20 °C to 70 °C
Humidity Operating condition: Up to 80% RH at 40 °C (non-condensing)
Storage condition: Up to 90% RH at 65 °C (non-condensing)
Altitude Up to 2000 m
Pollution degree 2
Keysight E36300 Series User's Guide 11
12
Keysight E36300 Series User's Guide
1 Getting Started
Product Introduction
Prepare Instrument for Use
Options and Fuse Information
Programming Ranges
Installation
Remote Interface Configuration
Remote Control
Using the Built-in Help System
Firmware Update
Front Panel Menu Reference
This chapter gets you started with the E36300 Series programmable DC
power supply.
Keysight E36300 Series User's Guide 13
Product Introduction
The Keysight E36300 Series is a series of three DC bench and system power supplies. All three models include:
– Three outputs:
– 6 V/5 A, +25 V/1 A, -25 V/1 A(E36311A)
– 6 V/5 A, +25 V/1 A, +25 V/1 A (E36312A)
– 6 V/10 A, +25 V/2 A, +25 V/2 A (E36313A)
– High performance functionality: accuracy, transient response, and rise/falltime
– Colorful, information-packed 4.3" LCDdisplay
– Code compatible and works like the E3631A when in E3631A mode
– Three rack-units (3U), 1/2-rack form factor
– Low acoustic noise
– Excellent usability
– USBIO interface
– NISPOM security (Optional)
– Web Interface
– SCPI programmability
– BenchVue application
– 3-year warranty standard
– Keysight worldwide support
The model-specific features are shown below.
Feature E36311A E36312A E36313A
Power output 80 W 80 W 160 W
IO interface USB standard USB/LAN standard,
GPIB optional
Low current measurement
Output list capability
Data logging
Output sequencing
High power (160 W)
Auto-Series/Parallel mode
Rear connections
P P
P P
P P
P P
P P
P P
USB/LAN standard,
GPIB optional
P
14
Keysight E36300 Series User's Guide
Front panel at a glance
Item Description
1 Information-packed, high contrast LED display; easily viewable even from sharp angles
2 Output selection keys
Selects an output to control. The lit key indicates the selected output.
Tip: When this key is selected, pressing this key again will toggle between multiple and single output view.
3 Voltage/Current knobs
Set the voltage and current of the selected output.
Meter View, Tracking and Store/Recall keys
4
– [Meter View] turns on the meter view for the selected output.
– [Tracking] turns on or off the track mode for output 2 and 3. (E36312A and E36313A only)
– [Store/Recall] opens the Store/Recall menu.
5 Navigation keys.
– Navigate through the control dialog windows; press [Enter] key to select a control.
6 Numeric keypad
– Enters numeric values. Press [Enter] key to complete the entry.
– Deletes the values entered into the dialog using the back key.
7 Output On key
Turns individual outputs On or Off; outputs are on when the key is lit.
8 Output terminals
Keysight E36300 Series User's Guide 15
Item Description
9 Earth ground reference
10 On/Standby key and LED indicator
Turns on the instrument. If the LED is amber, the instrument is in standby mode with AC inlet power connected, and if it is green, the
instrument is on.
11 All Output On/Off key
Turns all outputs On and Off according to the specified turn-on and turn-off delays.
12 Softkeys
Accesses the soft front panel menu.
13 USB port
Allows an external USB drive to be connected to the instrument. (E36312A and E36313A only)
16
Keysight E36300 Series User's Guide
Rear panel at a glance
Item Description
1 Output 2 and 3 terminal port (E36312A and E36313A only)
2 Earth ground reference (E36312A and E36313A only)
3 Kensington security slot
4 Output 1 terminal port (E36312A and E36313A only)
5 Digital I/O terminal port (E36312A and E36313A only)
6 LAN port (E36312A and E36313A only)
7 USB port
8 GPIB port (E36312A and E36313A Option GPIB only )
9 AC inlet
10 AC selector fuse-holder assembly
11 AC selector
12 Fan ventilation hole
Keysight E36300 Series User's Guide 17
Meter view
The power supply's front panel features a high contrast LED display.
Press [Meter View]. This key toggles between multiple and single output view.
Multiple Output View Single Output View
Item Description
1 Output identifier
When an output is selected, the background becomes highlighted. The selected output is displayed in an enlarged format in single
output view.
2 Remote sense status
2wire or 4wire indicates that 2-wire or 4-wire sensing measurement is in use.
3 Output status
OFF: The output is off
CV: The output is in constant voltage mode
CC: The output is in constant current mode
UR: The output is unregulated
4 Output meters
Displays the actual output voltage and current. Displays power in single output view.
5 Output settings
Displays the present output voltage and current settings. Use the numeric keypad or turn the front panel voltage or current knob to
adjust these settings.
6 Interface status
: The instrument is connected to USB.
OV: Over-voltage protection is tripped
OC: Over-current protection is tripped
OT: Over-temperature protection is tripped
: The instrument is not connected to LAN.
remote interface.
18
: The instrument is connected to LAN.
(blinking): The instrument is under identification mode via
(blinking): The LAN connection is at fault.
Keysight E36300 Series User's Guide
Item Description
7 Ratings and protection
Displays the present over-voltage protection (OVP) setting and whether over-current protection (OCP) is on or off.
8 Output delay
Displays the OCP, Output On and Output Off delay values.
9 Soft front panel menu
Keysight E36300 Series User's Guide 19
Data logger view
Press Data Logger from the soft front panel menu.
Item Description
1 Trace controls
Identifies the voltage or current trace that will be displayed. Dashes (----) indicate that the specified trace is turned off. Select the
trace and press [Enter] to turn it on or off.
2 Output traces
Voltage, current, or power traces. Voltage traces V1,V2 and V3 is shown. Press Auto Scale to auto scale all traces.
3 Status
Indicates whether the Data Logger is logging data, done logging, or is empty.
4 Filename
Indicates the file to which the data is being logged.
5 Data bar & time elapsed
Displays the progress of the data logger. The yellow bar indicates the visible data. Numbers to the right indicate time elapsed/total
duration.
6 Time/Div
Indicates the horizontal time-base setting.
7 Offset time
Indicates the time that the right gridline is offset or away from the end of the data log.
8 Grid time
Displays the time on the gridline
20
Keysight E36300 Series User's Guide
Dimension diagram
Setup the instrument
Place the instrument's feet on a flat, smooth horizontal surface. Connect output to the front panel or connect
output and sense leads to the rear panel (E36312A and E36313A only), being careful not to short the leads
together. Attach the power cable to the rear panel, then plug it into main power. Connect LAN, USB or GPIB cables
as desired, and you may also secure the instrument with a security lock cable.
Before disconnecting cables and cords from the instrument, turn the instrument off using the front-panel
On/Standby key and disconnect from the supply source by unplugging the detachable power cord.
Keysight E36300 Series User's Guide 21
Prepare Instrument for Use
Initial inspection
When you receive your power supply, inspect it for any obvious damage that may have occurred during shipment. If
there is damage, notify the shipping carrier and nearest Keysight Sales and Support Office immediately. Refer to
www.keysight.com/find/assist.
Until you have checked out the power supply, save the shipping carton and packing materials in case the unit has to
be returned. Check the list under Standard Shipped Items and verify that you have received these items with your
instrument. If anything is missing, please contact your nearest Keysight Sales and Support Office.
Standard shipped items
– Keysight E36311A/E36312A/E36313A DC power supply
– AC power cord
– Certificate of calibration
– One connector kit (P/N: E36312-89001) (E36312A and E36313A only):
– One 10 A, 3.5 mm female 4-pin terminal block connector
– One 12 A, 5 mm female 4-pin terminal block connector
– One 12 A, 5 mm female 8-pin terminal block connector
Documentation and firmware revisions
The Keysight E36300 Series documentation listed below can be downloaded for free through our website at
www.keysight.com/find/e36300manuals.
– Keysight E36300 Series programmable DC Power Supplies User's Guide. This manual.
– Keysight E36300 Series programmable DC Power Supplies Programming Guide.
– Keysight E36300 Series programmable DC Power Supplies Service Guide.
For the latest firmware revision and firmware update instruction, go to www.keysight.com/find/e36300firmware.
Recommended calibration interval
Keysight Technologies recommends a one year calibration cycle for the E36300 Series programmable DC power
supplies.
22
Keysight E36300 Series User's Guide
Options and Fuse Information
Ensure you order the proper instrument option for the mains power that will be used for the instrument.
Options 0EM, 0E3, and 0E9 determine which power-line voltage is selected at the factory.
Option Description
0EM 115 VAC ± 10%, 50/60 Hz input voltage
0E3 230 VAC ± 10%, 50/60 Hz input voltage
0E9 100 VAC ± 10%, 50/60 Hz input voltage
Ensure the correct AC input voltage and fuse settings
Use the proper switch settings
To change the input AC voltage selector on the power supply, use the two AC selector switches on the underside of
the power supply as shown.
For example, to select 230 V, slide the left switch to the left and the right switch to the right, as illustrated in the
diagram below the switches.
To select 115 V, slide both switches to the right, and to select 100 V, slide the two switches towards each other.
Keysight E36300 Series User's Guide 23
Use the correct fuse
The following table describes the fuse that you should use with each of the power supply's option.
Option Fuse
Description Fuse type Manufacturer Application
part number
E36311A-0E9
E36311A-0EM
E36312A-0E9
E36312A-0EM
E36311A-0E3
E36312A-0E3
E36313A-0E9
E36313A-0EM
E36313A-0E3 2110-0954 Fuse 3.5 A, 250 V Time-delay Slow-Blo 230 V line voltage
2110-1672 Fuse 4 A, 125 V Time-delay Medium-Acting Littelfuse 100 V and 115 V line voltage
2110-1640 Fuse 2 A, 250 V Time-delay Slow-Blo 230 V line voltage
2110-1673 Fuse 7 A, 125 V Time-delay Medium-Acting 100 V and 115 V line voltage
To configure the correct fuse, follow the three steps shown below:
Pull the fuse holder out of the
power supply.
Remove and insert the proper
fuse into the fuse holder.
Re-insert the fuse holder into the
power supply.
24
Keysight E36300 Series User's Guide
Programming Ranges
The following table shows the maximum voltage, current, and power that can be programmed for each model.
Parameter +6V output +25V output -25V output
1
Output Identifier P6V P25V N25V
Output Number 1 2 3
Voltage MAXimum 6.18 V 25.75 V 0 V
MINimum 0 V 0 V -25.75 V
DEFault (*RST) 0 V 0 V 0 V
Current MAXimum 5.15 A
10.3 A
2
1.03 A
2.06 A
2
2.06 A
2
1.03 A
MINimum 0.001 A 0.001 A 0.001 A
DEFault (*RST) 5 A
10 A
2
1 A
2 A
2
2 A
2
1 A
Note:
1. Applicable for E36311A or when SCPI IDis set to E3631A (E36312A and E36313A). In normal operation, the
E36312A and E36313A will output as +25 V.
2. Applicable for E36313A.
Keysight E36300 Series User's Guide 25
Installation
Connecting the power cord
Connecting the outputs
Parallel and series connections
4-wire sense connection
Interface connections
Installing the optional GPIB interface
Rackmounting the instrument
Connecting the power cord
FIRE HAZARD
Use only the power cord that was supplied with your instrument. Using other types of power cords may cause
overheating of the power cord, resulting in fire.
SHOCK HAZARD
The power cord provides a chassis ground through a third conductor. Be certain that your power outlet is of
the three-conductor type with the correct pin connected to earth ground.
Ensure the AC voltage setting on the rear panel is correctly set prior connecting the power cord.
Connect the power cord to the AC inlet connector on the rear of the unit. If the wrong power cord was shipped with
your unit, contact your nearest Keysight Sales and Support Office.
Removing the power cord will disconnect AC input power to the unit.
26
Keysight E36300 Series User's Guide
Connecting the outputs
All loads should either be connected to the front panel binding post or rear panel output.
Binding posts
SHOCK HAZARD
Turn off AC power before making rear panel connections. All wires and straps must be properly connected with
the terminal block screws securely tightened.
The binding posts accept wires sizes up to AWG 14 in location (A). Securely fasten all wires by hand-tightening the
binding posts. You can also insert standard banana plugs into the front of the connectors as shown in (B). A chassis
ground binding post is located on the front panel for convenience.
Maximum current rating:
(A) = 20 A
(B) = 15 A
Rear outputs connections
SHOCK HAZARD
Turn off AC power before making rear panel connections. All wires and straps must be properly connected with
the terminal block screws securely tightened.
Disconnect the connector plug to make your wire connections. The 12 A connector plug accepts wires sizes from
AWG 12 to AWG 30. Wire sizes smaller than AWG 20 are not recommended. Connect the load wires to the + and terminals. Connect the sense wires to the +s and -s terminals.
Securely fasten all wires by tightening the screw terminals. Insert the connector plug into the back of the unit.
Secure the 12 A connector by tightening the locking screws. A chassis ground binding post is located next to the fan
ventilation hole for ground connections.
Part number information for the connector kit is provided under Standard Shipped Items.
Keysight E36300 Series User's Guide 27
Wire sizing
FIRE HAZARD
Select a wire size large enough to carry short-circuit current without overheating (refer to the following table).
To satisfy safety requirements, load wires must be heavy enough not to overheat while carrying the short-circuit output current of the unit. .
AWG Suggested maximum
current (A)
12 25 1.59 5.2
14 20 2.53 8.3
16 13 4.02 13.2
18 10 6.39 21.0
20 7 10.2 33.5
22 5 16.1 52.8
24 3.5 25.7 84.3
1
mΩ/ft mΩ/m
Notes:
1. Single conductor in free air at 30 °C with insulation
Output isolation
The outputs of all three power supplies are isolated from earth ground. Any output terminal may be grounded, or an
external voltage source may be connected between any terminal output and ground. However, output terminals
must be kept within ±240 Vdc of ground. The ±25 V supplies are tied together at one common terminal (Applies to
E36311A or when the power supply is in E3631A mode). Any one of the three terminals can be tied to ground as
needed. An earth ground terminal is provided on the front panel for convenience.
Multiple loads
When connecting multiple loads to the power supply, each load should be connected to the output terminals using
separate connecting wires. This minimizes mutual coupling effects between loads and takes full advantage of the
low output impedance of the power supply. Each pair of wires should be as short as possible and twisted or shielded
to reduce lead inductance and noise pick-up. If a shield is used, connect one end to the power supply ground
terminal and leave the other end disconnected.
If cabling considerations require the use of distribution terminals that are located remotely from the power supply,
connect output terminals to the distribution terminals by a pair of twisted or shielded wires. Connect each load to
the distribution terminals separately.
For multiple load application, all loads should either be connected to the front panel binding post or rear panel
output.
28
Keysight E36300 Series User's Guide
Front panel
Rear panel (E36312A and E36313A only)
Keysight E36300 Series User's Guide 29
Parallel and series connections (E36312A and E36313A only)
Parallel connections
Series connections
Parallel connections
Only connect outputs that have identical voltage and current ratings in parallel.
Connecting outputs in parallel provides a greater current capability than can be obtained from a single output.
The following figures show how to connect two outputs when in Auto-Parallel mode.
Front panel
Rear panel
The figure on the left illustrates 2-wire sensing. If voltage drop in the load leads is a concern, the figure on the right
shows how to connect the sense leads directly at the load.
30
Keysight E36300 Series User's Guide
