GPIB, USB and Instrument
Control Products
for Easy PC-to-Instrument Connection
– Choose the best way to connect your PC to GPIB, USB and
RS-232 instruments
– Take advantage of PC-standard interfaces (USB, LAN, PCI, PCIe®)
– Protect your investment with industry-standard I/O software
BROCHURE
Introduction
The Keysight Technologies, Inc. GPIB, USB and Instrument Control
Products
Keysight instrument control hardware family benefits
– Easy connection to GPIB, USB and RS-232 instruments — Keysight instrument control hardware offer
simple “plug-and-go” set up and configuration.
– Use PC-standard interfaces — Connect via your computer PCI/PCIe® slot or use the built-in USB or LAN
ports on your PC to connect to your instruments.
– Choice of interfaces (GPIB, RS-232, USB, LAN, PCI, PCIe® — Keysight of fers you a selection of products
to meet your I/O needs. We work where you do!
– Use industry-standard I/O libraries — The included industry-standard VISA I/O libraries make it easy for
you to use your existing software programs and let you mix and match test instruments and software
from different vendors in a single system.
Easily mix instruments from different vendors
Keysight IO Libraries Suite eliminates the headaches associated with trying to combine hardware and
software from different vendors. The software is compatible with GPIB, USB, LAN and RS-232 test
instruments that adhere to the supported interface standards, no matter who makes them.
When you install the IO Libraries Suite, the software checks for the presence of other I/O sof tware on your
computer. If it finds another vendor’s VISA libraries (such as National Instruments), it automatically installs in
a side-by-side mode that allows you to use your existing I/O software and the Keysight software together in
multi-vendor systems without you being concerned with the behind-the-scenes details.
Works with millions of existing instruments from hundreds of vendors
Use the most trusted and reliable technology for your connections. The IO Libraries Suite ships with more
than 150 instruments from Keysight. It works with literally millions of existing instruments—helping you
minimize the number of software packages you need. You won’t have to switch between packages as you
use a mix of existing and new instruments in the future.
Work in the environment comfortable to you
In addition, the IO Libraries are compatible with a variety of application development environments and
programming APIs including Keysight or NI VISA, VISA COM, SICL, and Keysight 488 (compatible with
NI-488.2), giving you even more flexibility to choose the software and hardware from any vendor to get your
job done.
Connecting is as easy as 1-2-3
Install Keysight
1
IO Libraries Suite
software on your PC
Find us at www.keysight.com
Hook up the instrument
2
control hardware (USB, LAN,
RS-232 or GPIB cables)
between your instruments
and your PC
Detect instruments and
3
devices, then configure
interfaces with Connection
Expert
Page 2
Select the Right Connectivity for your Need
Model Description Recommended use Page
High Performance PCI-GPIB
Interface Card
High Performance PCIe/GPIB
card Interface Card
USB
LAN
Cables
82350C
82351B
82357B USB/GPIB Interface
Converters
E5810 B LAN/GPIB/USB Gateway
Converters
10833x GPIB Cables
108 34A GPIB-to-GPIB Adapter
and Adapter
System topology
Keysight instrument control
products help connect your
instruments to PC easily,
reliably and affordably.
From legendary GPIB
cables to the the one-box
connectivity gateway,
see how each provides
seamless integration of
your instruments no matter
where they are placed in
your system.
PCI/PCIe
– Maximum GPIB throughput for all configurations
– Standard and low-profile brackets allow flexible connection
– Bandwidth-intensive test applications
– Standard and low-profile brackets allow flexible connection
– Easiest GPIB connectivity
– Notebook computer GPIB connections
– One-box connectivity – remote GPIB, RS-232 and USB connections
– Sharing of instruments in a distributed system
– 10833A — 1 m
– 10833B — 2 m
– Extends the first cable 2.3 cm away from the rear panel to provide
clearance for other connectors, switches, and cables.
– 10833C — 4 m
– 10833D — 0.5 m
– 10833F — 6 m
– 10833G — 8 m
Device
82350C/
GPIB
Device
82351B
Device
USB
82357B
GPIB
RS-232
Device
Device
4
6
8
10
12
12
Find us at www.keysight.com
LAN
E5810B
GPIB
Device
USB
Device
Device
Page 3
Keysight 82350C High Performance PCI-GPIB Interface Card
The 82350C PCI-GPIB interface card converts any PCI bus computer into an
instrumentation control and data acquisition system. It comes with direct PCI computer
connection, and transaction overhead is minimized for the best overall operating
performance.
The 82350C interface card is fully compatible with IEEE-488 control and communication
standard, de-couples GPIB transfers from PCI bus transfers. Buf fering provides I/O and
system performance that is superior to direct memory access (DMA). The hardware
is software configurable and compatible with the plug-and-play standard for easy
installation. The GPIB interface card offers high flexibility to plug into standard or low
profile PC with a bracket change.
Features
– PCI IEEE-488 interface for PCs
– Transfer rates up to 900 KB/s
– Dual processor support on the
latest Windows operating system
Recommended use
– Maximum GPIB throughput for all
configurations
– Standard and low-profile brackets
allow flexible connection
82350C with standard (right) and low-profile (left) brackets
Find us at www.keysight.com
Page 4
82350C Technical Specifications
General requirements
Minimum system requirements Refer to page 12 for requirements in using the Keysight IO Libraries software (included with the
instrument control hardware)
Software requirements Keysight IO Libraries Suite
PCI bus slot Universal 3.3 V and 5 V PCI slot, 32 bits
Supported standards PCI rev 2.1, IEEE 488.1 and IEEE 488.2 compatible
General characteristics
Power Backplane +3.3 V or +5 V PCI
Connectors Standard 24-pin IEEE-488 (GPIB)
Universal +3.3 V and +5 V PCI
Maximum data rate 900 KB/s
Maximum instrument connection 14 instruments - daisy chain via GPIB
Buffering Built-in
Configuration Plug and play
EMC IEC 61326-1:2005/EN61326-1:2006
Dimension
Length, width and height 156 mm (L) X 121 mm (W) X 21.6 mm (H)
Weight 0.072 kg
Environmental specifications
Operating environment –5 °C to 60 °C
Operating humidity Up to 90% at 40 °C non condensing
Storage environment –40 °C to 70 °C
Storage humidity Up to 90% at 65 °C non condensing
Ordering information
Includes Low profile bracket, Quick start poster
Find us at www.keysight.com
Page 5
Keysight 82351B High Performance PCIe-GPIB Interface Card
Faster data transfer speed for high-throughput test application
The 82351B PCIe-GPIB interface card offers the fast data transfer rate associated with
PCIe to support high-bandwidth PC applications, ensuring that data is consistently
retained without being overwritten during the transfer to memory.
PCIe is the next generation of PCI and offers unsurpassed speed and performance,
making PCIe cards an ideal choice for many computer platforms and automation
applications. It is full backward compatible with PCI-configured software or coding,
removing the need to reconfigure any code. The 82351B is highly flexible with plug-andplay configuration and enables usage in a low-profile PC with a bracket change.
Features
– High transfer rate of 1.4 MB/s
– High flexibility via up-plugging (to
x4 or x8 PCIe slots)
– 3.3 V signal level for lower power
consumption
Recommended use
– Bandwidth-intensive test
applications
– Standard and low-profile brackets
allow flexible connection
82351B with standard (right) and low-profile (left) brackets
Find us at www.keysight.com
Page 6
82351B Technical Specifications
General requirements
Minimum system requirements Refer to page 12 for requirements in using the Keysight IO Libraries software (included with the
instrument control hardware)
Software requirements Keysight IO Libraries Suite
PCI bus slot 3.3 V PCI slot, 32 bits
Supported standards PCIe rev 1.0a
IEEE-488.1 and IEEE-488.2 compatible
General characteristics
Power Backplane +3.3 V PCIe
Connectors Standard 24-pin IEEE-488 (GPIB)
+3.3 V PCIe
Maximum data rate 1.4 MB/s
Maximum instrument connection 14 instruments - daisy chain via GPIB
Buffering Built-in
Configuration Plug and play
EMC IEC 61326-1:2005/EN61326-1:2006
Dimension
Length, width and height 156 mm (L) X 121 mm (W) X 21.6 mm (H)
Weight 0.074 kg
Environmental specifications
Operating environment –5 °C to 60 °C
Operating humidity Up to 90% at 40°C non condensing
Storage environment –40 °C to 70 °C
Storage humidity Up to 90% at 65 °C non condensing
Ordering information
Includes Low profile bracket, Quick start poster
Find us at www.keysight.com
Page 7
Keysight 82357B USB/GPIB Interface
Connect GPIB instruments quickly and easily to your computer’s
USB port
The Keysight 82357B USB/GPIB interface provides a direct connection from the USB
port on your desktop and laptop computers to GPIB instruments. Once the sof tware is
loaded, your computer automatically detects the 82357B when it is connected to the
computer USB port.
With the 82357B USB/GPIB interface and its convenient plug-and-play feature, you just
plug and go. It is also hot pluggable, making it easy to connect and disconnect without
having to shut down the computer. No external power supplies are necessary.
The 82357B USB/GPIB interface implements USB 2.0 and is backward compatible with
USB 1.1. The 82357B USB/GPIB interface uses a thin, flexible, high-quality USB cable
that is USB 2.0-compliant. The USB cable is shielded, and the connector is specified to
1,500 insertions, ensuring a durable connection and reliable data transfer.
Features
– Fast and easy connection to GPIB
instruments
– Uses standard USB and IEEE-488
interfaces
– Maximum GPIB transfer rate of up
to 1.15 MB/s
– Use industry-standard software
– Parallel polling capability
Recommended use
– Easiest GPIB connectivity
– Notebook computer GPIB
connections
Boosting per formance with the simplest connectivity
Find us at www.keysight.com
Page 8
82357B Technical Specifications
General requirements
Minimum system requirements Refer to page 12 for requirements in using the Keysight IO Libraries sof tware (included with the
Software requirements
1
Supported standards USB 2.0 high speed
Unsupported GPIB modes of operation Pass control
General characteristics
Power USB bus-powered device, +5 V, 500 mA (max), 200 mA (typ)
GPIB transfer rate 1.15 MB/s or better
Connectors Standard 24-pin IEEE-488 (GPIB)
USB hubs Self-powered hubs
Parallel polling A single parallel poll can easily check up to eight individual devices at once, corresponding to the number
Cable 2.5-meter, shielded connector rated for 1500 insertions
LED indicators READY, ACCESS, FAIL
Maximum connections Maximum of 4 converters can be connected to the PC
Instrument connections 14 instruments—daisy chain via GPIB
Configuration Plug-and-play
EMC and safety IEC 61010-1:20 01/EN 61010-1:2001
Dimensions
Length, width, and height 105 mm (L) x 64 mm (W) x 30 mm (H) (includes connectors)
Weight 215 gra ms
Environmental specifications
Operating environment 0 °C to 55 °C
Operating humidity –40 °C to +70 °C
Storage environment Up to 90% at 40 °C non-condensing
Storage humidity Up to 90% at 65 °C non-condensing
instrument control hardware)
Keysight IO Libraries Suite
Standard USB endpoints supported
IEEE-488.1 and IEEE-488.2 compatible
SICL and VISA 2.2
Non-system controller mode
Standard USB A
of data lines on the GPIB
Canada: CSA C22.2 No. 61010-1:2004
USA: UL 61010-1:20 04
1. If you’re using Keysight IO Libraries Suite 15.0 or higher, you’re not required to install the driver separately as it would come built into the Suite.
Find us at www.keysight.com
Page 9
Keysight E5810B LAN/GPIB/USB Gateway
One-box connectivity solution for easy GPIB, USB and RS-232
instrument control via standard LAN
The E5810B allows users to control various instrument interfaces remotely over wired
or wireless LAN (with a wireless router). Now with USB capability, the E5810B connects
up to 14 GPIB instruments, four USB instruments via a self-powered hub and an RS-232
instrument, giving test engineers a fast and efficient one-box solution. The E5810B is
ideal for system integrators, automated testing and other applications requiring unlimited
connection range and simultaneous connectivity to multiple instruments. It can be used
during design verification, where the gateway makes it easy for engineers to share a rack
of test equipment. For manufacturing, users can easily connect several test systems via
a local LAN and control them with a single, centrally located PC; these systems can be
accessed remotely for troubleshooting and debug.
Greater ease of use
The E5810B comes with an improved GPIB transfer rate of 1.2 MB/s and 1000BASE-T
(1 Gigabit) LAN/Ethernet compatibility in addition to existing 100BASE-TX and 10BASE-T
supportability.
With the built-in LCD display, users can quickly retrieve the IP address of the gateway and
other system messages without needing to install additional software.
The E5810B also comes with LED indicators on the front panel display, allowing users to
determine connection statuses of the gateway box at a glance.
Features
– Remote access and control
of GPIB, USB and RS-232
instruments
– Faster GPIB transfer rate of up to
1.2 MB/s
– Supports 1000BASE-T (1 Gigabit)/
100BASE-TX/10BASE-T LAN/
Ethernet connection
– Power switch for hard reset
– Password-protected web interface
for configuration
– LCD display for easy setup and
use
Recommended use
– One-box connectivity – remote
GPIB, RS-232 and USB
connections
– Sharing of instruments in a
distributed system
Security functions
Make LAN to GPIB, USB and RS-232 connections with greater ease
– With the E5810B, a secure
password is required to access
and modify all web configuration
pages. The gateway comes with
the secure erase feature, which
will erase the systems preset and
data information securely.
Find us at www.keysight.com
Page 10
E5810B Technical Specifications
General requirements
Minimum system requirements Refer to page 12 for requirements in using the Keysight IO Libraries software (included with the
instrument control hardware)
Supported Web browsers Internet Explorer 7.0 or greater
Software requirements Web browser
Keysight IO Libraries Suite
Supported standards GPIB Standard IEEE 488.1, 488.2
USB 2.0 or lower (with the USBTMC-USB488 protocol)
LAN/Ethernet: 10BASE-T/100BASE-TX/1000BASE-T networks
RS-232
VX I-11 Protocol
VISA 2.2 and Keysight SICL
General characteristics
Power consumption +12 VDC, 2 A
Isolated ELV supply source
Connectors Standard 24-pin IEEE-488 (GPIB), USB 2.0, RS-232 (9-pin), LAN RJ-45
Maximum data rates 1.2 MB/s for GPIB
115 Kb/s for RS-232
480 Mb/s for USB
Maximum instrument connection 14 GPIB instruments
1 USB connection (supports up to 4 USB instruments via self-powered hub)
1 RS-232 instrument
Up to 16 simultaneous connectivity connections
LED indicators Power, LAN, GPIB, USB, RS-232, FAULT
EMC and safety IEC61326-1:2005/EN61326-1:2006
Canada: ICES/NMB-001: Issue 4, June 2006
Australia/New Zealand: AS/NZS CISPR11:2004
IEC 61010-1:2010/EN 61010 -1:2010 (3rd Edition)
Dimensions
Length, width, and height 226.5 mm (8.92 in) × 238 mm (9.37 in) × 61 mm (2.36 in)
Weight 1.3 kg
Environmental specifications
Operating environment Operating temperature from 0 °C to 55 °C
Relative humidity up to 95% RH at 40 °C
Altitude up to 2000 m
Pollution Degree 2
Installation Category II (through an AC/DC adapter)
Storage environment Storage temperature from –40 °C to 70 °C
Relative humidity up to 90% RH at 65 °C
Recommended accessories
GPIB cables/adapter (see page 12)
Option 300 – Rack mount kit
Find us at www.keysight.com
Page 11
GPIB Cables and Adapter
Keysight connectivity software
Keysight connectivity software helps you establish a connection in less than 15 minutes.
Keysight IO Libraries Suite eliminates the hours of effort it takes to connect and configure
PC-controlled test systems. This connectivity software ships with each Keysight
instrument control hardware and over 150 Keysight test and measurement instruments.
Connecting your instruments to a PC is as easy as connecting a PC to a printer — even if
you use multiple instruments from different vendors.
Now, Keysight IO Libraries Suite comes with expanded compatibility with other vendors’
IO software. You can now use any programming API with any standard T&M software
development environment. Simply install Keysight’s IO libraries Suite on your PC, then
cable the interfaces and instruments to your PC. The IO Libraries Connection Expert utility
will find the interfaces and instruments connected to your computer and configure them
properly.
System Requirements
Keysight IO Libraries version 2019.
Windows PC software: Operating system
– Windows 10 (32-bit and 64-bit), Home, Pro, Enterprise
– Windows 8 and 8.1 (32-bit and 64-bit), Pro, Enterprise
– Windows 7 SP1 (32-bit and 64-bit), Starter, Home Basic, Home Premium,
Professional, Ultimate, Enterprise
– Windows Server 2008 R2 SP1 (64-bit), Standard and Enterprise
– Windows Server 2012 (64-bit), Standard
Cables
Keysight also offers a variety of
cables that provide easy and reliable
connections. Keysight cables are
engineered for high reliability and
durability, even under harsh conditions.
Cable Length
10833D GPIB cable 0.5 m
10833A GPIB cable 1.0 m
10833B GPIB cable 2.0 m
10833C GPIB cable 4.0 m
10833F GPIB cable 6.0 m
10833G GPIB cable 8.0 m
Adapter
The 10834A GPIB-to-GPIB adapter can
help when limited rear-panel space
and other design considerations make
cabling difficult. The 10834A adapter
extends the first cable to 2.3 cm away
from the rear panel to provide clearance
for other connectors, switches, and
cables.
Linux PC software: Operating system
– 64-bit Red Hat Enterprise Linux Desktop Workstation 7.1 to 7.5
– 64-bit CentOS Desktop Workstation 7.1 to 7.5
PC hardware
– Processor: 1 GHz, no support for Itanium64
– RAM: 1 GB minimum
– Hard disk space required: 2 GB
– Display: 1024 x 768 96 or 120 DPI
– Web connection for Internet download
If you already own an Keysight I/O product or instrument, you can download the latest
version of Keysight IO Libraries Suite at no cost.
For more information, visit: www.keysight.com/find/iosuite
Find us at www.keysight.com
Page 12
Measurement Automation—Quick and Easy
Whatever instrument you’re programming—whether a signal analyzer, oscilloscope,
power supply or DMM—Keysight VEE graphical language software and instrument
control hardware provide you the ease and flexibility to set up and automate the way you
want for your application need. Make measurements quickly, easily and affordably today.
Related Literature
Publication name Publication number
Modern Connectivity — Using USB and LAN I/O Converters – Application Note 5989-0123EN
Simplified PC Connections for GPIB Instruments - Application Note 5988-5897EN
System Developer Guide Using LAN in Test Systems: The Basics - Application Note 5989-1412EN
Using LAN in Test Systems: Network Configuration - Application Note 5989-1413EN
System Developer Guide – Application Note 5989-1417EN
Test-System Development Guide Computer I/O Considerations - Application Note 5988-9818EN
Tips and Tricks for Using USB, LAN, and GPIB - Application Note 5989-3312EN
GPIB, USB and Instrument Control for Easy PC-to-Instrument Connections - Data Sheet 5989-1889EN
www.keysight.com/find/gpib
Learn more at: www.keysight.com
For more information on Keysight Technologies’ products, applications or services,
please contact your local Keysight office. The complete list is available at:
www.keysight.com/find/contactus
Find us at www.keysight.com
This information is subject to change without notice. © Keysight Technologies, 2015 - 2020, Published in USA, August 31, 2020, 5989-7374EN
Page 13
Loading...
