Key Digital KD-AAXDA, KD-DAXAA Operating Instructions Manual

521 East 3rd Street, Mount Vernon, NY 10553
Phone

::

914.667.9700 Fax :: [phone]

Web

::

www.keydigital.com

Rev 0 – Aug. 2011

Operating Instructions

Audio Format Converters

Key Digital® HD Spider Series™ of Audio Format Converters are capable of
converting PCM Coaxial Digital Audio and Optical Digital Audio formats to Analog
L/R (KD-DAxAA) or Analog L/R Audio to PCM Coaxial Digital Audio and Optical
Digital Audio formats (KD-AAxDA)

KD-DAXAA

KD-AA

XDA

How to Contact Key Digital

®

Customer Support

For customer support questions please contact us at:

➔

Phone: [phone]

➔

E-mail: [e-mail]

Technical Support

For technical questions about using Key Digital® products, please contact us at:

➔

Phone: [phone]

➔

E-mail: [e-mail]

Repairs and Warranty Service

Should your product require warranty service or repair, please obtain a Key Digital®
Return Material

Authorization (RMA) number by contacting us at:

➔

Phone: [phone]

➔

E-mail: [e-mail]

Feedback

Please email any comments/questions about the manual to:

➔

E-mail: [e-mail]

Page 4 Page 1

Table of Contents

About KD-DAxAA, KD-AAxDA.......................................1

Connections

....................................................2

Application Examples .............................................3

Quick Setup Guide

...............................................3

Specifications ...................................................4

Important Product Warnings ........................................5

Safety Instructions

................................................5

How to Contact Key Digital

®

.........................................5

Warranty

.......................................................5

© 2011 Key Digital, Inc. All rights reserved.

Please read all instructions to ensure safe operation of the product.

About KD-DAxAA, KD-AAxDA

The HD Spider Series™ Audio Converters feature the capability to convert audio formats
from Analog, PCM or Optical Toslink, to Analog, PCM or Optical formats.

Key Features:

➔

KD-DAxAA

➔

Converts 2-Channel PCM Digital Audio or Toslink Digital Audio to
Analog L/R Audio

➔

Supports 32, 44.1, 48, and 96 KHz sampling rates

➔

Auto Selection of Input source with priority given to Optical Audio

➔

KD-AAxDA

➔

Converts Analog L/R Audio to PCM Digital Audio and Toslink Digital Audio

➔

Simultaneous output of both Digital Audio Connections

➔

Supports 48 KHz output sampling rate

➔

Uncompressed 2-channel PCM (LPCM) digital audio output

Key Benefits:

➔

Format conversion enables integration full integration with Audio Amplifiers, Distributed
Audio Systems, and AV Receivers

➔

Ideal for source devices with limited output formats, such as AppleTV

➔

Space-efficient design enables easy installation and concealing

Accessories:

➔

External 5 Volt DC 2 Amp power supply

➔

Set Up Guide
