KD-CSW2x1
KD-CSW2x1 is a Video/Audio Switcher with capability of switching
2 Component/RGBHV Video Sources/Inputs to 1 output
Audio
Audi
o
Surround Sound
KD-CSW2x1
Optical IR
Plasma TV
Cable Box
DVD Player
Component
Au
d
io
12V Trigger Control
Component
Componen
t
/R
GBHV
*All Component sources can be
substituted with RGBHV sources
Home Theater Application
Model: KD-CSW2x1
Key Digital® Exclusive Technologies Supported Technologies
4 Flexible switching of up to 2 YPrPb/RGBHV Video/Audio
formats (Component, RGBHV, S-Video, Composite) with
Toslink Optical Audio and Coaxial/Digital (PCM) Audio
4 Switches automatically any Video/Audio sources
to one output
4 Switches Left, Right analog stereo, PCM audio
4 Front LEDs indicate the selected source and
input/output status
4 Incorporates 4 Key Digital
™
Exclusive Technologies
4 12 Volt Trigger, Optical IR, Front Panel Controls,
RCA connectors
Key Benefits
Key Solutions General Info
Provides switching from 2 analog sources to 1 analog output
Converts digital coax audio to optical (Toslink) digital audio
Allows for multiple expansions of YPrPb/RGBHV sources to a display
Supports 3rd party control systems via IR, 12 Volt trigger
›
›
›
›
Power: 100VAC to 240VAC,
50Hz and 60Hz, NTSC, PAL
Rack Mount: No
Remote Control: Included
Enclosure Type: Metal
Dimensions:
8.5” x 4.5” x 1.75”
Shipping Carton Dimensions:
13.5” x 7” x 4.5”
Product Weight: 2 lbs
Shipping Weight: 6 lbs
›
›
›
›
›
›
›
›
