KERN YKV-01, YKV-02 Operating And Installation Instructions

KERN & Sohn GmbH
Ziegelei 1
E-Mail: info@kern-sohn.com
Internet: www.kern-sohn.com
Operating and Installation Digital weighing transmitter
KERN YKV-01/02
Version 1.1
2019-04
Instructions
GB
D-72336 Balingen
Fax: +49-[0]7433-9933-149
YKV-01-02-BA_IA-e-1911
KERN YKV
Digital weighing transmitter
GB
Version 1.1 2019-04
Operating and installa t ion instructions
Contents
1 Technical data ................................................................................................ 4
2 Declaration of conformity ............................................................................. 5
3 Appliance overview ....................................................................................... 6
4 Basic Information (Gen eral) .......................................................................... 7
4.1 Proper use .................................................................................................................................. 7
4.2 Improper Use .............................................................................................................................. 7
4.3 Warranty ..................................................................................................................................... 7
4.4 Monitoring of Test Resources .................................................................................................... 8
5 Basic Safety Precaut io ns .............................................................................. 8
5.1 Pay attention to the instructions in the Operation Manual.......................................................... 8
5.2 Personnel training ....................................................................................................................... 8
6 Transport and storage ................................................................................... 8
6.1 Testing upon acceptance ........................................................................................................... 8
6.2 Packaging / return transport ....................................................................................................... 8
7 Unpacking and placing .................................................................................. 9
7.1 Installation Site, Location of Use ................................................................................................ 9
7.2 Unpacking and checking ............................................................................................................ 9
7.3 Transport Securing ..................................................................................................................... 9
7.4 Installation Weighing transmitter - Platform.............................................................................. 10
7.4.1 Weighing system design........................................................................................................... 10
7.4.2 How to connect the platform ..................................................................................................... 11
7.5 Connect weighing transmitter to PC ......................................................................................... 12
8 Configuration ............................................................................................... 13
9 Adjustment ................................................................................................... 14
10 Linearization / firs t adjustm ent ................................................................... 15
10.1 Carrying out the linearization .................................................................................................... 16
10.2 Performance of a single point adjustment ................................................................................ 17
11 Configuration using the KERN Balance Connectio n software ................ 18
12 Connection to your system ......................................................................... 20
12.1 USB .......................................................................................................................................... 20
12.2 Bluetooth .................................................................................................................................. 20
12.3 RS232 ....................................................................................................................................... 21
12.4 Ethernet .................................................................................................................................... 22
12.5 WLAN ....................................................................................................................................... 22
13 Carrying out measurements ....................................................................... 24
2 YKV-01-02-BA_IA-e-1911
13.1 Using your own software .......................................................................................................... 24
13.1.1 Request weighing data ......................................................................................................... 24
13.1.2 Zeroing and taring ................................................................................................................ 24
13.2 Using the BalanceConnection software ................................................................................... 24
13.2.1 Functions .............................................................................................................................. 27
YKV-01-02-BA_IA-e-1911 3

1 Technical data

KERN (type) TYKV-01-A TYKV-02-A
Model YKV-01 YKV-02 Net weight (kg) 1.1 1.1 Dimensions of the
housing (B x D x H) mm Permissible
ambient condition Housing material Synthetic material Humidity of air 80 % relative (not condensing) Input voltage Mains
adapter Input tension
Device Interfaces USB-Host/Master
100 x 127 x 28 mm 100 x 127 x 28 mm
- 10° C to +40° C
100 V - 240 V, 50 / 60 Hz
5 V, 500 mA
USB-Host/Master
(Standard)
WLAN/WiFi-Module
(factory option)
RS 232 (standard) RS 232 (standard)
Bluetooth 4.0
(factory option)
(Standard)
WLAN/WiFi-Module
(factory option)
Bluetooth 4.0
(factory option)
- Ethernet (Standard)
4 YKV-01-02-BA_IA-e-1911

2 Declaration of conform ity

The current EC/EU Conformity declaration can be found online in:
www.kern-sohn.com/ce
YKV-01-02-BA_IA-e-1911 5

3 Appliance overview

Example YKV-02-A:
Pos. Description
1 USB 2.0 type B 2 RS232 3 Ethernet 4 Connection to the load cell
6 YKV-01-02-BA_IA-e-1911

4 Basic Information (General)

4.1 Proper use

The digital weighing transmitter acquired by you is used in combination with a platform and serves to determine the weighing value of material to be weighed. It is intended to be used as a "non-automatic weighing system", i.e. the material to be weighed is manually and carefully placed in the centre of the weighing plate. As soon as a stable weighing value is reached the weighing value can be read.

4.2 Impro per Us e

Do not use weighing system (YKV and platform) for dynamic weighing. In the event that small quantities are removed or added to the material to be weighed, incorrect weighing results can be displayed due to the "stability compensation" in the device. (Example: Slowly draining fluids from a container on the balance.) Do not leave permanent load on the weighing pan. This may damage the measuring system. Impacts and overloading exceeding the stated maximum load (max) of the weighing plate, minus a possibly existing tare load, must be strictly avoided. The weighing system could be damaged. Never operate the weighing system in explosive environment. The serial version is not explosion protected. Changes to the weighing system's design are not permitted. This may lead to incorrect weighing results, safety-related faults and destruction of the weighing system. The weighing system may only be operated in accordance with the described default settings. Other areas of use must be released by KERN in writing.

4.3 Warranty

Warranty claims shall be voi ded i n cas e
Our conditions in the operation manual are ignored
The appliance is used outside the described uses
The appliance is modified or opened
Mechanical damage or damage by media, liquids, natural wear and tear
The appliance is improperly set up or incorrectly electrically connected
The measuring system is overloaded
YKV-01-02-BA_IA-e-1911 7

4.4 Monitoring of Test Resources

In the framework of quality assurance the measuring-related properties of the weighing system and, if applicable, the testing weight, must be checked regularly. The responsible user must define a suitable interval as well as type and scope of this test. Information is available on KERN’s home page (www.kern-sohn.com with regard to the monitoring of display units’ test substances and the test weights required for this. In KERN’s accredited DKD calibration laboratory test weights and digital weighing platforms may be calibrated (return to the national standard) fast and at moderate cost.

5 Basic Safety Precautions

5.1 Pay attention to the instructions in the Operation Manual

Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN balances.

5.2 Pers onnel training

The appliance may only be operated and maintained by trained personnel.

6 T ransport and storage

6.1 Testing upon acceptance

When receiving the appliance, please check packaging immediately, and the appliance itself when unpa c kin g for po s sible visible damage.

6.2 Packaging / return t ransp ort

Keep all parts of the original packaging for a possibly
required return.
Only use original packaging for returning. Prior to dispatch disconnect all cables and remove
loose/mobile parts.
8 YKV-01-02-BA_IA-e-1911
Weighing transmitter
in the downloads area on http://www.kern-sohn.com

7 Unpacking and placing

7.1 Installation Site, Location of Use

The weighing system is designed to achieve reliable weighing results under normal conditions of use. You will work accurately and fast, if you select the right location for your weighing system.
On the installation site observe the following:
Place the weighing system on a firm, le vel sur fa ce;
Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
Protect the weighing system against direct draughts due to open windows and doors;
Avoid jarring during weighing;
Protect the weighing system against high air humi dit y, vapours and dust;
Do not expose the weighing system to extreme dampness for longer periods
of time. Non-permitted condensation (condensation of air humidity on the appliance) may occur if a cold appliance is taken to a considerably warmer environment. In this case, acclimatize the disconnected appliance for ca. 2 hours at room temperature.
Avoid static charge of weighed items or wei ghing c ontainer.
Major display deviations (incorrect weighing results) may be experienced, should electromagnetic fields (e.g. due to mobile phones or radio equipment), static electricity accumulations or instable power supply occur. Change location or remove source of interference.

7.2 Unpacking and checking

Take the weighing transmitter out of the packaging, remove the packaging material and install at the designated workstation. Check if that there has been no damage and that all packing items are present.
Scope of delivery / serial accessories:
Net adapter EU/UK/US
USB A to USB B cable
These installation instructions
Software KERN BalanceConnection

7.3 Transport Securing

Please note: if the YKV is used together with platform with transportation lock, this transportation lock must be released prior to use.
YKV-01-02-BA_IA-e-1911 9

7.4 Installation Weighing transmitter - Platform

Installation / configuration of a weighing system must be carried out by a well acquainted specialist with the workings of weighing balances.

7.4.1 Weighing s ystem design

The digital weighing transmitter is suitable for connection to any analogue load cell in compliance with the required specifications. The following data must be established before selecting a load cell:
Weighing balance capacity This usually corresponds to the heaviest load to be weighed.
Preload This corresponds to the total weight of all parts that are to be placed on the weighing cell such as upper part of pl atf orm , weighing pan etc.
Total zero s etting range This is composed of the start-up zero setting range (± 2%) and the zero setting range available to the user via the ZERO-function (2%). The total zero setting range equal s there f or e 4 % of the s cale’s capacity.
The addition of w eighi ng s cal e s capa city, preload and the total zer o set ti ng range give the required capacity for the weighing cell. To avoid overloading of the weighing cell, include an additional safety margin.
10 YKV-01-02-BA_IA-e-1911
For power supply we recommend to connect the YKV to the PC.
the YKV.

7.4.2 How to connect the platfor m

 Connection to power supply via USB
Weld the individual w i res of the loa d cell cabl e to the pri nte d cir c ui t boar d.
Example of application:
For this purpose connect the USB coupl ing of the YKV to the PC.
If another interface is used, power has to be supplied via the external power pack. For this purpose connect the power pack to the USB coupling of
Prior to starting the assembly work, disconnect the digital weighing transmitter from the mains.
Couplings from left to right described as follows: E+ S+ OUT+ OUT- S- E- Shield
The strain relief of the load cell cable is between 4 mm and 8 mm.
YKV-01-02-BA_IA-e-1911 11
USB
WLAN/WiFi
Bluetooth 4.0
Ethernet
-
Standard

7.5 Connect weighing transmitter to PC

Weighing data can de edited to conne ct ed ne tworks or PCs via the interfaces. In reverse order, control comm a nd s and dat a in put s may be made via the connected devices (such as PC). Every interface has to be configured according to the peripheral device and the desired function. For data transfer a transfer software is required. Our optionally available transfer software Balance Connection SCD 4.0 gives you a lot of possibilities for transfer and recording.
Available interfaces:
Standard Standard Factory option Factory option
YKV-01 YKV-02
RS232
Standard Standard Factory option Factory option
12 YKV-01-02-BA_IA-e-1911
balance
balance
JDC 60.00 kg
JDC A
JDD 0.05 kg
JDD A JDO 60.45 kg
JDO A
JDA 60.00 kg
JDA A

8 Configuration

Description Sent to
Define maximum load (exp.: 60 kg) and unit (exp.: kg)
Resolution (decimal digits and readability) Exp.: 0.05 kg
Determine overload (exp. 60.45 kg): Define Adjustment weight (Bsp.: 60.00 kg)
Further linearization points can be defined with the JDL command.
Please observe the sequen ce; the same uni t m ust be u se d for all parameters.
Answer of
The configuration can als o be carr ied out u si ng the Bal an c eC on ne c ti on software. Please refer to the corresponding chapter down below.
YKV-01-02-BA_IA-e-1911 13
Observe stable enviro nment al c on di ti on s. Stabi l i sati on r equi r e s a cert ain

9 Adjustment

As the acceleration value due to gravity is not the same at every location on earth, every digital weighing pl atfor m mu st be coor d i nate d - in compl i a n ce w i th the underlying phy sical wei ghi ng pr i n cipl e - to the existing acceleration due to gravity at its place of location (only if the weighing system has not already been adjusted to the location in the factory). This adjustment process must be carried out for the first commissioning, after each change of location as well as in case of fluctuating environment temperature. To receive accur at e mea suri n g valu es it is also recommended to adjust the digital weighing platform in weighing operation.
Prepare the required adjustment weight. The adjustment weight to be used depends on the capacity of the weighing system. Carry out adjustment as near as possible to the weighing system’s maximum weight. Info about test weights can be found on the Internet at: http://www.kern-sohn.com.
warm-up time.
Make sure that the balance data are input cor r ectly
14 YKV-01-02-BA_IA-e-1911
A linearization is absolutely necessary after changing the weighing
After linearization, calibration is recommended.

10 Linearization / first adjustment

The linearity indicates the largest deviation of the weight display of a balance to the value of the respective test weight for plus and minus over the entire weighing range. If a linearity deviation is detected during test equipment monitoring, this can be improved by linearization.
parameters with JDC, JDD, etc.
For scales with a resolution> 15,000 division steps, it is recommended to carry out a linearization.
For scales with a resolution of <15,000 division s, an sin gl e-point adjustment is recommended. Only with display devices.
The linearization may only be carried out by a specialist with profound knowledge in the handling of balances.
The test weights to be used must be adapted to the specifications of the balance.
Observe stable environmental condit ions. A warm-up time for stabilization is required.
YKV-01-02-BA_IA-e-1911 15
Send the max. capacity of the scale JDC. Balance sends a confirmat ion.
JDC 60 kg
JDC A
Send the readability of the scale JDD. Balance sends a confirmat ion.
JDD 0.02 kg
JDD A
Send the max. overload of the scale JDO. Balance sends a confirmat ion.
JDO 60 kg
JDO A
Optional: Send more linearization points JDL x (x = 0 to 7)
JDL 0 30 kg JDL 1 60 kg
JDL A JDL A
JALZ
JALZ
JALZ A 60 kg
Put on the indicated load.
Continue linearization JALL
JALL
JALL B 30 kg
Put on the indicated load.
Continue linearization JALL
JALL
JALL A
Save linearization JAS
JAS
JAS A

10.1 Carrying out the linearization

For adjustment connect the weighing transmitter to the PC via the USB-interface as described in chap. 7.4.
Linearization can be initiated using the commands JALZ, JALL as well as JAS in the KCP protocol.
Sent to balance
Received from balance
Unload the weighing plate
Start linearization
The linearization is thus successfully completed. If errors occur, repeat linearization.
16 YKV-01-02-BA_IA-e-1911
Sending the command to adjust the zero point
upon
JAGZ
JAGZ A
Loading the balance with the adjustment load
Send the command to import the adjustment The balance sends a confirm ati on JAGL A.
JAGL
JAGL A
Save the adjustment usin g the comm an d JAS.
JAS
JAS A

10.2 Performance of a single point adjustment

For adjustment conne ct the weighing transmitter to the PC via the USB-interface as described in chap. 7.4.
Adjustment can be initiated using the commands JAGZ, JAGL as well as JAS in the KCP protocol.
Sent to balance
Answer of balance
Unload weighing plate
JAGZ. The balance sends a confirm ati on JAGZ A
15.00 kg
specifying the adjustment weight to be placed
load JAGL.
Now the process of adjustment is su c ces sf ully completed. Should err or s oc cur, repeat adjustment.
Observe the sequence :
JZ – JL – JS o Before and after changing the weighing parameters, perform a
linearization, only then does the one-point adjustment work.
YKV-01-02-BA_IA-e-1911 17

11 Configuration using the KERN Bal ance Conne c t ion software

The BalanceConnection software (expert mode) includes a dialog for configuring the device. You can download the BalanceConnection software from the following URL:
http://balanceconnection.kern-sohn.com/dl
You can find the manual at:
http://balanceconnection.kern-sohn.com/manual.pdf
18 YKV-01-02-BA_IA-e-1911
To configure the device with the BalanceConnection software, please follow the instructions below (according to the instructions of the software):
1) Switch to expert mode.
2) Select the desired device from the list.
3) Connect the correct port to the selected device
4) Start the configuration dialog via the following button:
5) Complete the desired parameters and press the "Apply" button.
YKV-01-02-BA_IA-e-1911 19
KCP (KERN Communications Protocol):
balances and other appliances, which allows all of the relevant parameters and functions to be called up and controlled. KERN devices that have KCP can use it to connect easily to computers, industrial control systems and other digital systems.

12 Connection to your system

Using and configuration of the digital weighing transmitter are made by the KCP communication log via the installed interfaces. KCP is described in the interface specification KCP-ZB (online available). The following sections describe how to connect the weighing platform to your system using your preferred communications interface.
KCP is a standardized set of interface commands for KERN

12.1 USB

Connect the device to the host computer using the enclosed USB cable. It will be recognized as a virtual COM port and will be assigned a corresponding numbered connection.
Example (Microsoft Windows Device Manager):
In modern devices the USB driver required for the weighing transmitter has already been pre-installed. If the system is not recognized automatically, you can obtain the correct driver from th e downloads area at http://www.kern-sohn.com.

12.2 Bluetooth

The weighing transmitter is optionally available with Bluetooth Low Energy (BLE) and will then be visible to Bluetooth Master devices using its serial number.
To access this, please use an appropriate software programme / app which supports Bluetooth Low Energy (BLE). Applications exclusively using Bluetooth Classic (BLC) will not work.
20 YKV-01-02-BA_IA-e-1911
Data bits:
8

12.3 RS232

Use a suitable cable to connect the weighing transmitter to the interface of the computer. The fault-free operation is ensured either by the corresponding KERN­interface cable (KERN 572-926) or directly via the RS232-interface of the PC.
Enter default values:
Baud rate 9600
Parity none Stop bits 1
YKV-01-02-BA_IA-e-1911 21
A
Select operating mode "apsta"
B
Enter WLAN-network name and the corresponding password
C
Save settings and restart target software (reboot button)
Should settings have been made on the device, make sure that afterwards the

12.4 Ethernet

In standard configuration the weighing transmitter uses the DHCP log to intrude into the network. For inquiry of the configuration allocated via DHCP, as well as to the specific/static configuration of the IP-address, subnet-mask or the gateway, the KCP-commands
JNEx can be used.

12.5 WLAN

After switching-on without config ur at ion, the YKV cr eates fi rst a WLAN a c cess
point named "AI-Thinker_xxxxxx.
Connect YKV to the computer via this access point. In a webbrowser enter the IP-address 192.168.4.1 of the YKV. The
configuration website will appear. The stati c IP wi l l be assigned via the KCP­commands.
(s. fig.:)
D
Separate connection to the PC (access point) and disconnect power supply of the YKV.
power supply to the YKV is disconnected. Only then the settings will be imported. Update (reboot-button) and saving (s ave-button) are not sufficient.
22 YKV-01-02-BA_IA-e-1911
E
Invoke the configuration website and c heck the IP-address.
F
(s. fig.:)
Reconnect YKV to the power supply,
Restore connection to the PC (access point),
G
(s. fig.:)
Close the configuration website, connect the PC to the sele cte d network Open the target software (e.g. KERN Balance Connection) and enter the
IP-address and port 23.
For inquiry of the configuration allocated via DHCP, as well as to the specific/static configuration of the IP-address, subnet-mask or the gateway, the KCP-commands JNWx can be used.
YKV-01-02-BA_IA-e-1911 23

13 Carrying out measurements

13.1 Using your own softwar e

Measurements may be requested using various KCP protocol commands.

13.1.1 Request weighing data

Central commands for the request are:
„S“: Transmit the next stable value
„SI“: Transmit the curr ent val ue
„SIR“: Transmit the current net weighing data continuously

13.1.2 Zeroing and t aring

The device can be zeroed and tared using the following commands:
„Z“: Zeroing the display on the balance
„T“: Taring the balance
„TA“: Setting or requesting the current tare value

13.2 Using the BalanceConnection software

The enclosed "KERN BalanceConnection" software includes an example configuration for working with the KDP weighing platform. The example configuration switches the balance to continuous transmission, displays the current weight value on-screen and includes the most important commands (adjustment, zeroing, taring, printing).
To activate the example configuration, please select the "KDP" model from the list of models.
After confirmation the software loads the example configuration and restarts. You will see the following items (two windows):
24 YKV-01-02-BA_IA-e-1911
1) Main window BalanceConnection:
2) On-screen display window with three areas: a. Main functions
b. Current measuring value c. Table listing weight values, which can be requested using "PRINT".
YKV-01-02-BA_IA-e-1911 25
In the example configuration the weighing platform sends data constantly. The
If you only want to keep the current value, then please use the operation "Save value" to accept the value. In the output method, the package type must be set
Important:
In the standard configuration COM1 is selected as the interface. Please adjust this on your balance. For access through Ethernet, WLAN or Bluetooth, please enter the relevant port in the software.
For details on changing the configuration please refer to the instructions for the BalanceConnectio n sof tware.
weight values would normally all be forwarded to the output methods.
to manual trigger.
26 YKV-01-02-BA_IA-e-1911

13.2.1 Functions

In the example configuration the following functions are pre-configured:
Zeroing (->0<-):
The display on the balance is set to zero, the full weighing range is available.
Taring (TARE):
The current weight value is adopted as the tare value. The new net value is displayed.
PRE-TARE:
You can define a tare value (please specify in and with the weighing unit).
PRINT:
The current weight displayed on the balance is adopted as a value into the assigned output methods.
Adjustment (CAL):
Adjustment of the platform is illustrated in the example configuration by a sequence of commands, which corresponds to the adjustment procedure in the chapter 8. Please follow the instruction displayed on the screen.
YKV-01-02-BA_IA-e-1911 27
Loading...
