Operating instructions
Precision/ compact balances and
platform scales

KERN 572/573/KB/DS/FKB/FCB

Version 5.8
04/2010
GB

572/573/KB/DS/FKB/FCB-BA-e-1058

GB

KERN 572/573/KB/DS/FKB/FCB

Version 5.8 04/2010

Operating instruction
Precision/compact balances and platform scales

Table of contents:

1 MODE - MENUE .......................................................................................................3

2 Technical data .........................................................................................................4

2.1 KERN 572............................................................................................................................................. 4

2.2 KERN 573............................................................................................................................................. 7

2.3 KERN KB ............................................................................................................................................. 8

2.4 KERN DS............................................................................................................................................ 12

2.5 KERN FCB ......................................................................................................................................... 17

2.6 KERN FKB ......................................................................................................................................... 19

3 Fundamental information (general) .....................................................................22

3.1 Intended use...................................................................................................................................... 22

3.2 Inappropriate use ............................................................................................................................. 22

3.3 Guarantee .......................................................................................................................................... 22

3.4 Monitoring the test substances ...................................................................................................... 22

4 Fundamental safety information..........................................................................23

4.1 Observe the information in the operating instructions ................................................................ 23

4.2 Staff training...................................................................................................................................... 23

5 Transport and storage ..........................................................................................23

5.1 Acceptance check ............................................................................................................................ 23

5.2 Packaging.......................................................................................................................................... 23

6 Unpacking, installation and commissioning ......................................................23

6.1 Place of installation, place of use................................................................................................... 23

6.2 Unpacking ......................................................................................................................................... 24

6.2.1 Installation........................................................................................................................................... 24

6.3 Mains supply ..................................................................................................................................... 24

6.4 Battery operation FKB...................................................................................................................... 24

6.5 Connecting peripheral equipment .................................................................................................. 24

6.6 Initial start-up .................................................................................................................................... 24

6.7 Adjustment ........................................................................................................................................ 25

6.8 Adjusting (go to 7.2.6)...................................................................................................................... 25

6.8.1 Adjusting for verification (KERN 573; FKB-M; KB-NM; FCB-M; DS-M) ............................................. 25

6.9 Verification ........................................................................................................................................ 26

7 Operation ...............................................................................................................27

7.1 Display control panel ....................................................................................................................... 27

7.2 Operation........................................................................................................................................... 28

7.3 Display background illumination.................................................................................................... 34

7.4 Interface RS 232 C ............................................................................................................................ 34

7.5 RS 232 C Data output via interface RS 232 C ................................................................................ 35

7.5.1 There are 5 methods for the data output via RS 232 C ..................................................................... 35

7.5.2 Description of the data transfer .......................................................................................................... 35

7.5.3 Numerator........................................................................................................................................... 36

7.6 Printer ................................................................................................................................................ 36

7.7 Underfloor weighing......................................................................................................................... 36

8 Maintenance, upkeep, disposal ...........................................................................37

8.1 Cleaning............................................................................................................................................. 37

8.2 Maintenance, upkeep ....................................................................................................................... 37

8.3 Disposal............................................................................................................................................. 37

9 Troubleshooting....................................................................................................37

10 Declaration of conformity

.....................................................................................38

2

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

1 MODE - MENUE

Important!

The modified settings - as well as the adjustment - must be stored when switching-off, via the
ON/OFF button.

572/573/KB/DS/FKB/FCB-BA-e-1058

3

2 Technical data

2.1 KERN 572

KERN 572-30 572-31 572-32 572-33

Readability (d) 0.001 g 0.001 g 0.001 g 0.01 g

Weighing range (max) 241 g 301 g 421 g 1610 g

Taring range (subtractive) 241 g 301 g 421 g 1610 g

Reproducibility 0.001 g 0.001 g 0.001 g 0.01g

Linearity ± 0.003 g ± 0.005 g ± 0.005 g ± 0.03 g

Smallest piece weight 0.001 g 0.001 g 0.001 g 0.01 g

Adjustment points 50/100/

200/240 g

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 180 x 310 x 90

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu

Weight kg (net) 2.3 2.3 2.3 2.3

Data interface yes (RS232)

200 g 200 g +100 g 200 g + 200 g 1 kg + 500 g

Ø 106 Ø 106 Ø 106 Ø 150

50/100/

200/300 g

+10 °C ... + 40 °C

100/200/

300/400 g

0.5/1.0/

1.5/1.6 kg

4

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN 572-35 572-37 572-39 572-43

Readability (d) 0.01 g 0.01 g 0.01 g 0.1 g

Weighing range (max) 2410 g 3010 g 4210 g 10100 g

Taring range (subtractive) 2410 g 3010 g 4210 g 10100 g

Reproducibility 0.01 g 0.01 g 0.01 g 0.1g

Linearity ± 0.03 g ± 0.05 g ± 0.05 g ± 0.3 g

Smallest piece weight 0.01 g 0.01 g 0.01 g 0.1 g

Adjustment points 0.5/1.0/

2.0/2.4 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 180 x 310 x 90

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu

Weight kg (net) 2.3 2.3 2.3 2.7

Data interface yes (RS232)

2 kg 2 kg + 1 kg 2 kg + 2 kg 10 kg

Ø 150 Ø 150 Ø 150 160 x 200

1.0/1.5/

2.0/3.0 kg

+10 °C ... + 40 °C

1.0/2.0/

3.0/4.0 kg

2/5/10 kg

572/573/KB/DS/FKB/FCB-BA-e-1058

5

KERN 572-45 572-49 572-55 572-57

Readability (d) 0.05 g 0.1 g 0.05 g 0.1 g

Weighing range (max) 12100 g 16100 g 20100 g 24100 g

Taring range (subtractive) 12100 g 16100 g 20100 g 24100 g

Reproducibility 0.05 g 0.1 g 0.05 g 0.1g

Linearity ± 0.15 g ± 0.3 g ± 0.25 g ± 0.3 g

Smallest piece weight 0.05 g 0.1 g 0.05 g 0.1 g

Adjustment points 2/5/10/12 kg 5/10/15/16 kg 5/10/15/20 kg 5/10/15/20/24 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 180 x 310 x 90

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu

Weight kg (net) 2.7 2.7 2.7 2.7

Data interface yes (RS232)

10 kg 10 kg + 5 kg 20 kg 20 kg

+10 °C ... + 40 °C

160 x 200 160 x 200 160 x 200 160 x 200

6

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

2.2 KERN 573

KERN 573-34NM 573-36NM 573-46NM 573-56NM

Accuracy class

Readability (d) 0.01 g 0.01 g 0.1 g 0.1 g

Verification value (e) 0.1 g 0.1 g 1 g 1 g

Weighing range (max) 650 g 2000 g 6500 g 20000 g

Minimum load (Min) 0.5 g 0.5 g 5 g 5 g

Taring range (subtractive) 650 g 2 000 g 6500 g 20000 g

Reproducibility 0.01 g 0.01 g 0.1 g 0.1g

Linearity ± 0.03 g ± 0.03 g ± 0.3 g ± 0.3 g

Smallest piece weight 0.01 g 0.01 g 0.1 g 0.1 g

Adjustment points 200g/500g/600g 500g/1000g/

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 180 x 310 x 90

Vibration filter yes

Weighing plate stainless
steel mm

Units g, kg g, kg g, kg g, kg

Weight kg (net) 2.3 2.3 2.7 2.7

Data interface yes (RS232)

II II II II

2/5/6 kg 5/10/20 kg

2 000g

600 g / F1 2 kg / F1 5 kg / F2 20 kg / F1

+10 °C ... + 30 °C

Ø 150 Ø 150 160 x 200 160 x 200

572/573/KB/DS/FKB/FCB-BA-e-1058

7

2.3 KERN KB

KERN KB 120-3N KB 200-3N KB 240-3N KB 360-3N

Readability (d) 0.001 g 0.001 g 0.001 g 0.001 g

Weighing range (max) 121 g 201 g 241 g 361 g

Taring range (subtractive) 121 g 201 g 241 g 361 g

Reproducibility 0.001 g 0.001 g 0.001 g 0.001g

Linearity ± 0.003 g ± 0.003 g ± 0.003 g ± 0.005 g

Smallest piece weight 0.001 g 0.001 g 0.001 g 0.001 g

Adjustment points 20/50/100/120 g 50/100/150/200 g 100/150/

200/240 g

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 167 x 250 x 85

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu

Weight kg (net) 1 1 1 1

Data interface yes (RS232)

100 g 200 g 200 g 200 g + 100 g

+10 °C ... + 40 °C

Ø 81 Ø 81 Ø 81 Ø 81

100/200/

300/360 g

8

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN KB 1200-2N KB 2000-2N KB 2400-2N KB 3600-2N

Readability (d) 0.01 g 0.01 g 0.01 g 0.01 g

Weighing range (max) 1 210 g 2 010 g 2 410 g 3 610 g

Taring range (subtractive) 1 210 g 2 010 g 2 410 g 3 610 g

Reproducibility 0.01 g 0.01 g 0.01 g 0.01g

Linearity ± 0.03 g ± 0.03 g ± 0.03 g ± 0.05 g

Smallest piece weight 0.01 g 0.01 g 0.01 g 0.01 g

Adjustment points 0.2/0.5/1.0/1.2 kg 0.5/1.0/1.5/2.0 kg 1.0/1.5/2.0/2.4 kg 1.0/2.0/3.0/3.6 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 167 x 250 x 85

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu

Weight kg (net) 1.5 1.5 1.5 1.5

Data interface yes (RS232)

1 000 g 2 000 g 2 000 g 2 kg + 1 kg

+10 °C ... + 40 °C

130 x 130 130 x 130 130 x 130 130 x 130

572/573/KB/DS/FKB/FCB-BA-e-1058

9

KERN

Accuracy class

Readability (d) 0.1 g 0.05 g

Weighing range (max) 10 100 g 10 100 g

KB

10000-1N

10k0.05N

KB

Taring range (subtractive)

Reproducibility

Linearity

Smallest piece weight

Adjustment points

Recommended adjusting
weight F1 (not supplied)

Stabilization time (typical)

Permitted environmental tem­perature

Housing (B x D x H) mm

Weighing plate stainless steel
mm

Units

Vibration filter

Weight kg (net)

Data interface

10 100 g 10 100 g

0.1 g 0.05 g

0.3 g 0.15 g

0.1 g 0.05 g

2/5/10 kg 2/5/10 kg

10 kg 10 kg

3 sec. 3 sec.

+10 °C ... + 40 °C +10 °C ... + 40 °C

167 x 250 x 85 167 x 250 x 85

150 x 170 150 x 170

see menu see menu

yes yes

1.7 1.7

yes (RS232) yes (RS232)

10

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN

Accuracy class II II II II

Readability (d) 0.01 g 0.1 g 0.01 g 0.1 g

Verification value (e) 0.1 g 1 g 0.1 g 1 g

Weighing range (max) 650 g 6 500 g 2 000 g 10 000 g

Minimum load (Min) 0.5 g 5 g 0.5 g 5 g

Taring range (subtractive) 650 g 6 500 g 2 000 g 10 000 g

Reproducibility 0.01 g 0.1 g 0.01 g 0.1g

Linearity ± 0.03 g ± 0.3 g ± 0.03 g ± 0.3 g

Smallest piece weight 0.01 g 0.1 g 0.01 g 0.1 g

Adjustment points 200/500/600 g 2/5/6 kg 0.5/1.0/1.5/2.0 kg 2/5/10 kg

Recommended adjusting
weight F1 (not supplied)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 167 x 250 x 85

Vibration filter yes

Weighing plate stainless
steel mm

Units g, kg, ct

Weight kg (net) 1.5 1.7 1.5 1.7

Data interface yes (RS232)

KB

650-2NM

600 g 6.0 kg 2 000 g 10 kg

130 x 130 150 x 170 130 x 130 150 x 170

KB

6500-1NM

+10 °C ... + 30 °C

KB

2000-2NM

KB

10000-1NM

572/573/KB/DS/FKB/FCB-BA-e-1058

11

2.4 KERN DS

KERN

Readability (d) 0.01 g 0.05 g 0.05 g 0,1 g

Weighing range (max) 3 100 g 5 100 g 8 100 g 10.100 g

Taring range (subtractive) 3 100 g 5 100 g 8 100 g 10.100 g

Reproducibility 0.02 g 0.05 g 0.05 g 0.1 g

Linearity ± 0.05 g ± 0.15 g ± 0.15 g ±0.3 g

Smallest piece weight 0.01 g 0.05 g 0.05 g 0.1 g

Adjustment points 1/2/3 kg 2/5/10 kg 2/4/5/7/8 kg 2/5/10 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 228 x 228 x 70 228 x 228 x 70 315 x 305 x 70 228 x 228 x 70

Vibration filter

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu

Weight kg (net) 5.5 5.5 7.5 5,5

Data interface yes (RS232)

DS

3K0.01S

3 kg 10 kg 5 kg + 2 kg 10 kg

228 x 228 228 x 228 315 x 305 228 x 228

DS

5K0.05S

+10 °C ... + 40 °C

DS

8K0.05

DS

10K0.1S

12

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN

Accuracy class

Readability (d) 0.1 g 0.1 g 0.1 g

Verification value (e)

Weighing range (max) 16 100 g 20 100 g 30 100 g

Minimum load (Min)

Taring range (subtractive) 16 100 g 20 100 g 30 100 g

Reproducibility 0.1 g 0.1 g 0.1g

Linearity ± 0.3 g ± 0.3 g ± 0.3 g

Smallest piece weight 0.1 g 0.1 g 0.1 g

Adjustment points 5/10/15/16 kg 5/10/15/20 kg 10/15/20/30 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 315 x 305 x 70

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu

Weight kg (net) 7.5 7.5 7.5

Data interface yes (RS232)

DS

16K0.1

10 kg + 5 kg 20kg 20 kg + 10 kg

+10 °C ... + 40 °C

315 x 305 315 x 305 315 x 305

DS

20K0.1

DS

30K0.1

572/573/KB/DS/FKB/FCB-BA-e-1058

13

KERN

Accuracy class

Readability (d) 0.2 g 0.1 g 0.2 g 0.2 g

Verification value (e)

Weighing range (max) 36 100 g 30 100 g 36 100 g 60 100 g

Minimum load (Min)

Taring range (subtractive) 36 100 g 30 100 g 36 100 g 60 100 g

Reproducibility 0.2 g 0.1 g 0.2 g 0.2g

Linearity ± 0.6 g ± 0.3 g ± 0.6 g ± 0.6 g

Smallest piece weight 0.2 g 0.1 g 0.2 g 0.2 g

Adjustment points 10/15/20/

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 315 x 305 x 70 450 x 350 x 115

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu

Weight kg (net) 7.5 9.5 9.5 9.5

Data interface yes (RS232)

DS

36K0.2

30/36 kg

20 kg + 10 kg 20 kg + 10 kg 20 kg + 10 kg 50 kg

315 x 305 450 x 350

DS

30K0.1L

10/15/20/

30 kg

+10 °C ... + 40 °C

DS

36K0.2L

10/15/20/

30/36 kg

DS

60K0,2

20/30/50/60 kg

14

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN

Readability (d) 0,5 g 0,5 g 1 g

Weighing range (max) 65 100 g 101 000 g 151 000 g

Taring range (subtractive) 65 100 g 101 000 g 151 000 g

Reproducibility 0,5 g 0,5 g 1 g

Linearity ± 1,5 g ± 1,5 g ± 3 g

Smallest piece weight 0,5 g 0,5 g 1 g

Adjustment points 20/30/50/60 kg 20/50/100 kg 50/100/150 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 450 x 350 x 115

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu

Weight kg (net) 9.5

Data interface yes (RS232)

DS

65K0.5

50 kg 50 kg + 50 kg

+10 °C ... + 40 °C

DS

100K0.5

450 x 350

DS

150K1

3 x 50 kg

3 x 50 kg

572/573/KB/DS/FKB/FCB-BA-e-1058

15

KERN

Accuracy class

Readability (d) 0.1 g 1 g 1 g 1 g / 2 g / 5 g 2 g / 5 g /10

Verification value (e) 1 g 10 g 10 g 1 g / 2 g / 5 g 2 g / 5 g /10

Weighing range (max) 15 000 g 65 000 g 150 000 g 10 kg/ 20 kg/

Minimum load (Min) 5 g 50 g 50g 50 g 100 g

Taring range (subtractive) 15 000 g 65 000 g 150 000 g 50 000 g 100 000 g

Reproducibility 0.1 g 1 g 1 g 1 g 1 g

Linearity ± 0.3 g ± 2 g ± 3 g ± 2 g

Smallest piece weight 0.1 g 1 g 1 g 1 g

Adjustment points 5/10/15/kg 20/30/50/

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 315 x 305 x 70 450 x 350 x 115

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu see menu

Weight kg (net) 7.5 9.5 9.5 9.5 9.5

Data interface yes (RS232)

DS

15K0.1M

II II II III III

10 kg + 5 kg 50 kg 3 x 50 kg 50 kg 2 x 50 kg

+10 °C ... + 30 °C +10 °C ... + 40 °C

315 x 305 450 x 350

DS

65K1M

60 kg

DS

150K1M

50/100/

150 kg

DS

50K1TM

50 kg

20/40/50 kg 50/100g

DS

100K2TM

g

g

20 kg/ 50 kg/

100 kg

16

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

2.5 KERN FCB

KERN

Readability (d) 0.02 g 0.05 g 0.1 g 0.1 g 0.2 g

Weighing range (max) 6 100 g 12 100 g 12 100 g 24 100 g 24 100 g
Taring range (subtrac-

tive)
Reproducibility 0.02 g 0.05 g 0.1 g 0.1 g 0.2 g
Linearity ± 0.06 g 0.15 g 0.3 g 0.3 g 0.6 g

Smallest piece weight 0.02 g 0.05 g 0.1 g 0.1 g 0.2 g

Adjustment points 2/5/6 kg 2/5/10/12 kg 2/5/10/12 kg

Recom. adjustment
weight F1
(not added)

Humidity of air max. 80% rel. (non-condensing)
Stabilization time (typi-

cal)
Permitted environ­mental temperature

Vibration filter yes
Housing

(B x D x H) mm
Weighing plate,

stainless steel
Units see menu

Vibration filter yes

Weight kg (net) 3.3 3.3 3.3 3.3 3.3

Data interface yes (RS232)

FCB

6K0.02B

6 100 g 12 100 g 12 100 g 24 100 g 24 100 g

5 kg 10 kg 10 kg 20 kg 20 kg

270 x 345 x

106

253x228 253x228 253x228 253x228 253x228

FCB

12K0.05B

270 x 345 x

106

FCB

12K0.1B

3 sec.

+ 10 °C ... + 40 °C

270 x 345 x

106

FCB

24K0.1B

5/10/15/

20/24 kg

270 x 345 x

106

FCB

24K0.2B

5/10/15/

20/24 kg

270 x 345 x

106

572/573/KB/DS/FKB/FCB-BA-e-1058

17

KERN

Accuracy class

Readability (d) 0.1 g 0.1 g 1 g

Verification value (e) 1 g 1 g 1 g / 2 g

Weighing range (max) 8 000 g 15 000 g 7.5 kg / 15 kg

Minimum load (Min) 5 g 5 g 50 g

Taring range (subtractive) 8 000 g 15 000 g 50 000 g

Reproducibility 0.1 g 0.1 g 1g

Linearity ± 0.2 g ± 0.3 g ±3 g

Smallest piece weight 0.1 g 0.1 g 1 g

Adjustment points 5/8 kg 5/10/15 kg 5/10/15 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 270 x 345 x 106

Vibration filter yes

Weighing plate stainless
steel mm

Units g, kg

Weight kg (net) 3.3

Data interface yes (RS232)

FCB

8K0.1BM

II II III

5 kg + 2 kg 15 kg 15 kg

+10 °C ... + 30 °C +10 °C ... + 40 °C

FCB

15K0.1BM

253 x 228

FCB

15K1BDM

18

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

2.6 KERN FKB

KERN

Readability (d) 0.02 g 0.05 g 0.05 g 0.1 g

Weighing range (max) 6 100 g 8 100 g 16 100 g 16 100 g

Taring range (subtractive) 6 100 g 8 100 g 16 100 g 16 100 g

Reproducibility 0.02 g 0.05 g 0.05 g 0.1g

Linearity ± 0.06 g ± 0.15 g ± 0.25 g ± 0.3 g

Smallest piece weight 0.02 g 0.05 g 0.05 g 0.1 g

Adjustment points 2/4/5/6 kg 2/4/5/7/8 kg 5/10/15/16 kg 5/10/15/16 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 350 x 390 x 120

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu

Weight kg (net) 6.5 6.5 6.5 6.5

Data interface yes (RS232)

FKB

6K0.02

5 kg 5 kg + 2 kg 10 kg + 5 kg 10 kg + 5 kg

340 x 240 340 x 240 340 x 240 340 x 240

FKB

8K0.05

+10 °C ... + 40 °C

FKB

16K0.05

FKB

16K0.1

572/573/KB/DS/FKB/FCB-BA-e-1058

19

KERN

Readability (d) 0.1 g 0.2 g 0.2 g 0.5 g

Verification value (e)

Weighing range (max) 36 100 g 36 100 g 65 100 g 65 100 g

Minimum load (Min)

Taring range (subtractive) 36 100 g 36 100 g 65 100 g 65 100 g

Reproducibility 0.1 g 0.2 g 0.2 g 0. g

Linearity ± 0.5 g ± 0.6 g ± 1.0 g ± 1.5 g

Smallest piece weight 0.1 g 0.2 g 0.2 g 0.5 g

Adjustment points 10/20/30/36 kg 10/20/30/36 kg 20/30/50/60 kg 20/30/50/60 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 350 x 390 x 120

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu

Weight kg (net) 6.5 6.5 6.5 6.5

Data interface yes (RS232)

FKB

36K0.1

20 kg + 10 kg 20 kg + 10 kg 50kg 50kg

340 x 240 340 x 240 340 x 240 340 x 240

FKB

36K0.2

+10 °C ... + 40 °C

FKB

65K0.2

FKB

65K0.5

20

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058

KERN

Accuracy class

Readability (d) 0.1 g 0.1 g 1 g 1 g/2 g/5 g

Verification value (e) 1.0 g 1.0 g 10 g 1 g/2 g/5 g

Weighing range (max) 8 000 g 15 000 g 65 000 g 10kg/20kg/50kg

Minimum load (Min) 5.0 g 5.0 g 50 g 20, 40, 100 g

Taring range (subtractive) 8 000 g 15 000 g 65 000 g 50 000 g

Reproducibility 0.1 g 0.1 g 1 g 1 g

Linearity ± 0.3 g ± 0.3 g ± 3 g ± 3 g

Smallest piece weight 0.1 g 0.1 g 1 g 1 g

Adjustment points 2/5/7/8 kg 5/10/15/16 kg 20/30/50/60 kg 20/30/50 kg

Recommended adjusting
weight F1 (not supplied)

Humidity of air max. 80% rel. (non-condensing)

Stabilization time (typical) 3 sec.

Permitted environmental
temperature

Housing (B x D x H) mm 350 x 390 x 120

Vibration filter yes

Weighing plate stainless
steel mm

Units see menu see menu see menu see menu

Weight kg (net) 6,5 6.5 6.5 6.5

Data interface yes (RS232)

FKB

8K0.1M

II II II III

5 kg + 2 kg 10 kg + 5 kg 50 kg 50 kg

+10 °C ... + 30

°C

340 x 240 340 x 240 340 x 240 340 x 240

FKB

15K0.1M

+10 °C ... + 30

°C

FKB

65K1M

+10 °C ... + 30

°C

FKB

50K1TM

+10 °C ... + 40

°C

572/573/KB/DS/FKB/FCB-BA-e-1058

21

3 Fundamental information (general)

It is essential to read through and observe the complete operating instructions before installing and commis­sioning.

3.1 Intended use

The balance you have acquired serves to determine the weighing value of the material to be weighed. It is
intended to be used as a “non-automatic“ balance, i.e. the material to be weighed is manually and carefully
placed in the centre of the weighing plate. The weighing value can be read off after a stable weighing value
has been obtained.

3.2 Inappropriate use

Do not use the balance for dynamic weighing. In the event that small quantities are removed or added to the
material to be weighed, incorrect weighing results can be displayed due to the “stability compensation“ in the
balance. (Example: Slowly draining fluids from a container on the balance.)
Do not leave a permanent load on the weighing plate. This can damage the measuring equipment.
Be sure to avoid impact shock and overloading the balance in excess of the prescribed maximum load rating
(max.), minus any possible tare weight that is already present. This could cause damage to the balance.
Never operate the balance in hazardous locations. The series design is not explosion-proof.
Structural alterations may not be made to the balance. This can lead to incorrect weighing results, faults
concerning safety regulations as well as to destruction of the balance.
The balance may only be used in compliance with the described guidelines. Varying areas of applica­tion/planned use must be approved by KERN in writing.

3.3 Guarantee

The guarantee is not valid following

- non-observation of our guidelines in the operating instructions

- use outside the described applications

- alteration to or opening of the device

- mechanical damage and damage caused by media, liquids

- natural wear and tear

- inappropriate erection or electric installation

- overloading of the measuring equipment

3.4 Monitoring the test substances

The metrology features of the balance and any possible available adjusting weight must be checked at regu­lar intervals within the scope of quality assurance. For this purpose, the answerable user must define a suit­able interval as well as the nature and scope of this check. Information is available on KERN’s home page
(www.kern-sohn.com
for this. Test weights and balances can be adjusted quickly and at a reasonable price in KERN’s accredited
DKD calibration laboratory (return to national normal).

) with regard to the monitoring of balance test substances and the test weights required

22

572/573/KB/DS/FKB/FCB/PCB-BA-e-1058
