Ablesbarkeit (d) 0,1 g 0,1 g 1 g 1 g
Wägebereich (Max) 200 g 500 g 2000 g 5000 g
Reproduzierbarkeit 0,01 g 0,1 g 0,01g 0,01 g
Linearität ± 0,2 g ± 0,2 g± 2 g ± 2 g
EMB
EMB
EMB
EMB
Empf. Justiergewicht nicht
200 g
500 g
2000 g
beigegeben ( Klasse )
Einschwingzeit (typisch) 2-3 sec.
Luftfeuchtigkeit max. 80 % (nicht kondensierend)
Gehäuse (B x T x H) mm
145 x 205 x 45
Wägeplatte mm Ø 120
Batteriebetrieb (Standard)
2 x 1.5 V AA
Netzadapter (Option) 300 mA / 9 V
Unterflurwägung Haken
5000 g
EMB-S-BA-d-1612
4
2 Grundlegende Hinweise (Allgemeines)
2.1 Bestimmungsgemäße Verwendung
Die von Ihnen erworbene Waage dient zum Bestimmen des Wägewertes von Wägegut. Sie ist zur Verwendung als „nichtselbsttätige Waage“ vorgesehen, d.h. das Wägegut wird manuell, vorsichtig und mittig auf die Wägeplatte aufgebracht. Nach Erreichen eines stabilen Wägewertes kann der Wägewert abgelesen werden.
2.2 Sachwidrige Verwendung
Waage nicht für dynamische Verwiegungen verwenden. Werden kleine Mengen vom
Wägegut entnommen oder zugeführt, so können durch die in der Waage vorhandene „Stabilitätskompensation“ falsche Wägeergebnisse angezeigt werden! (Beispiel:
Langsames Herausfließen von Flüssigkeiten aus einem auf der Waage befindlichen
Behälter.)
Keine Dauerlast auf der Wägeplatte belassen. Diese kann das Messwerk beschädigen.
Stöße und Überlastungen der Waage über die angegebene Höchstlast (Max), abzüglich einer eventuell bereits vorhandenen Taralast, unbedingt vermeiden. Waage
könnte hierdurch beschädigt werden.
Waage niemals in explosionsgefährdeten Räumen betreiben. Die Serienausführung
ist nicht Ex-geschützt.
Die Waage darf nicht konstruktiv verändert werden. Dies kann zu falschen W ägergebnissen, sicherheitstechnischen Mängeln sowie der Zerstörung der Waage führen.
Die Waage darf nur gemäß den beschriebenen Vorgaben eingesetzt werden. Abweichende Einsatzbereiche/Anwendungsgebiete sind von KERN schriftlich freizugeben.
2.3 Gewährleistung
Gewährleistung erlischt bei
- Nichtbeachten unserer Vorgaben in der Betriebsanleitung
- Verwendung außerhalb der beschriebenen Anwendungen
- Veränderung oder Öffnen des Gerätes
- mechanische Beschädigung, und Beschädigung durch Medien, Flüssigkeiten
- natürlichem Verschleiß und Abnützung
- nicht sachgemäße Aufstellung oder elektrische Installation
- Überlastung des Messwerkes
EMB-S-BA-d-1612
5
2.4 Prüfmittelüberwachung
Im Rahmen der Qualitätssicherung müssen die messtechnischen Eigenschaften der
Waage und eines eventuell vorhandenen Prüfgewichtes in regelmäßigen Abständen
überprüft werden. Der verantwortliche Benutzer hat hierfür ein geeignetes Intervall
sowie die Art und den Umfang dieser Prüfung zu definieren. Informationen bezüglich
der Prüfmittelüberwachung von Waagen sowie die hierfür notwendigen Prüfgewichte
sind auf der KERN-Homepage (www.kern-sohn.com) verfügbar. In seinem akkredi-
tiertem DKD-Kalibrierlaboratorium können bei KERN schnell und kostengünstig Prüfgewichte und Waagen kalibriert werden (Rückführung auf das nationale Normal).
3 Grundlegende Siche rheitshinwei s e
3.1 Hinweise in der Betriebsanleitung beachten
Lesen Sie diese Betriebsanleitung vor der Aufstellung und Inbetriebnahme sorgfältig
durch, selbst dann, wenn Sie bereits über Erfahrungen mit KERN-Waagen verfügen.
3.2 Ausbildung des Personals
Das Gerät darf nur von geschulten Mitarbeitern bedient und gepflegt werden.
4 Transport und Lagerung
4.1 Kontrolle bei Übernahme
Überprüfen Sie bitte die Verpackung sofort beim Eingang sowie das Gerät beim
Auspacken auf eventuell sichtbare äußere Beschädigungen.
4.2 Verpackung / Rücktransport
Alle Teile der Originalverpackung für einen eventuell notwendigen
Rücktransport aufbewahren.
Für den Rücktransport ist nur die Originalverpackung zu verwen-
den.
Vor dem Versand alle angeschlossenen Kabel und losen / beweg-
lichen Teile trennen.
Evtl. vorgesehene Transportsicherungen wieder anbringen.
Alle Teile z.B. Glaswindschutz, Wägeplatte, Netzteil etc. gegen
Verrutschen und Beschädigung sichern.
EMB-S-BA-d-1612
6
5 Auspacken, Aufstellung und Inbetriebnahme
5.1 Aufstellort, Einsatzort
Die Waagen sind so konstruiert, dass unter den üblichen Einsatzbedingungen zuverlässige Wägeergebnisse erzielt werden.
Exakt und schnell arbeiten Sie, wenn Sie den richtigen Standort für Ihre Waage wählen.
Beachten Sie deshalb am Aufstellort folgendes:
Waage auf eine stabile, gerade Fläche stellen;
extreme W ärme sowie Temperaturschwankungen z.B. durch Aufstellen
neben der Heizung oder direkte Sonneneinstrahlung vermeiden;
Waage vor direktem Luftzug durch geöffnete Fenster und Türen schüt-
zen;
Erschütterungen während des Wägens vermeiden;
Waage vor hoher Luftfeuchtigkeit, Dämpfen und Staub schützen;
Setzen Sie das Gerät nicht über längere Zeit starker Feuchtigkeit aus.
Eine nicht erlaubte Betauung (Kondensation von Luftfeuchtigkeit am
Gerät) kann auftreten, wenn ein kaltes Gerät in eine wesentlich wärmere Umgebung gebracht wird. Akklimatisieren Sie in diesem Fall das
vom Netz getrennte Gerät ca. 2 Stunden bei Raumtemperatur.
statische Aufladung von Wägegut, Wägebehälter und W indschutz ver-
meiden.
Beim Auftreten von elektromagnetischen Feldern, bei statischen Aufladungen sowie
bei instabiler Stromversorgung sind große Anzeigeabweichungen (falsche Wägeergebnisse) möglich. Der Standort muss dann gewechselt werden.
EMB-S-BA-d-1612
7
KERN EMB-S
• Waage
1
3
4
5
6
5.2 Auspacken
Die Waage vorsichtig aus der Verpackung nehmen, Plastikhülle entfernen und die
Waage am vorgesehenen Arbeitsplatz aufstellen.
5.2.1 Aufstellen
Die Waage ist so aufzustellen, dass die Wägeplatte genau waagrecht steht.
5.2.2 Lieferumfang
Serienmäßiges Zubehör:
• Batterien (2 x 1,5V AA)
• Betriebsanleitung
5.3 Anzeigenübersicht
Stabilitätsanzeige
2
EMB-S-BA-d-1612
Negativer Wert
Waage auf Null gestellt
Nettogewicht
Kapazitätsanzeige
Wägeeinheiten
8
Wägeeinheiten umschalten
Transportsicherung
Wurde die Transportsicherung im Wägebetrieb nicht gelöst, erscheint
5.4 Tastaturübersicht
• Waage einschalten
• Waage tarieren
5.5 Transportsicherung
Vor der Inbetriebnahme Transportsicherung an der Unterseite der Waage entriegeln
s. Abb. unten:
•
• Waage ausschalten
• Justierung aufrufen (langer Tastendruck)
Transportsicherung verriegelt
bei Transport der Waage
bei Erreichen der Maxlast eine Fehlermeldung „E“.
Transportsicherung gelöst
im Wägebetrieb
EMB-S-BA-d-1612
9
5.6 Batteriebetrieb (Standard)
Batteriedeckel unter der Waagschale abnehmen. 2 x 1,5 V Batterien einlegen. Batteriedeckel wieder einsetzen.
Zur Batterieschonung schaltet die Waage 3 Minuten nach abgeschlossener Wägung
automatisch ab.
Sind die Batterien verbraucht, erscheint im Display „LO“. Taste drücken und
sofort Batterien wechseln.
Wird die Waage längere Zeit nicht benützt, Batterien herausnehmen und getrennt
aufbewahren. Auslaufen von Batterieflüssigkeit könnte die Waage beschädigen.
5.7 Netzanschluss (Option)
Die Stromversorgung erfolgt über das externe Netzgerät KERN YKA-03 (optional).
Der aufgedruckte Spannungswert muss mit der örtlichen Spannung übereinstimmen.
Verwenden Sie nur KERN- Originalnetzgeräte. Die Verwendung anderer Fabrikate
bedarf der Zustimmung von KERN.
5.8 Erstinbetriebnahme
Eine Anwärmzeit von 3 Minuten nach dem Einschalten stabilisiert die Messwerte.
Die Genauigkeit der Waage ist abhängig von der örtlichen Fallbeschleunigung.
Unbedingt die Hinweise im Kapitel „Justierung“ beachten.
EMB-S-BA-d-1612
10
5.9 Justierung
Da der Wert der Erdbeschleunigung nicht an jedem Ort der Erde gleich ist, muss
jede Waage – gemäss dem zugrundeliegenden physikalischen Wägeprinzip – am
Aufstellort auf die dort herrschende Erdbeschleunigung abgestimmt werden (nur
wenn die Waage nicht bereits im Werk auf den Aufstellort justiert wurde). Dieser Justiervorgang, muss bei der ersten Inbetriebnahme, nach jedem Standortwechsel sowie bei Schwankungen der Umgebungstemperatur durchgeführt werden. Um genaue
Messwerte zu erhalten, empfiehlt es sich zudem, die Waage auch im Wägebetrieb
periodisch zu justieren.
Mit einem Justiergewicht ist die Waagengenauigkeit jederzeit überprüfbar und neu
einstellbar.
Vorgehen bei der Justierung:
Stabile Umgebungsbedingungen beachten. Eine Anwärmzeit zur Stabilisierung ist
erforderlich.
Waage mit einschalten
drücken und ca. 5 sec. gedrückt halten, bis im Dis-
play kurz „--------„ und danach kurz „CAL“ erscheint.
Danach wird ein interner Wert angezeigt
kurz drücken; im Display wird die Größe des Justier-
Nun das Justiergewicht in die Mitte der Wägeplatte stellen.
(Beispiel)
(Beispiel)
„--------„ wird kurz angezeigt, gefolgt von „F“.
EMB-S-BA-d-1612
11
Die Justierung ist erfolgt, die Waage wechselt automatisch
in den Wägemodus.
(Beispiel)
Justiergewicht abnehmen, die Justierung ist hiermit beendet.
Bei einem Justierfehler oder falschem Justiergewicht erscheint „E“. Justierung wiederholen.
Justiergewicht bei der Waage aufbewahren. Tägliche Überprüfung der Waagengenauigkeit wird bei qualitätsrelevanten Anwendungen empfohlen.
EMB-S-BA-d-1612
12
einschalten. Die Waage führt einen
Ist das Wägegut schwerer als der Wägebereich, erscheint
im Display „E“ (=Überlast).
Es erscheint kurz „oFF“ in der Anzeige, danach
Taragefäß auf die Waagschale stellen
, das Gewicht
Wägegut auflegen, Meßwert ablesen.
6 Betrieb
6.1 Wägen
Waage mit
Selbsttest durch und wechselt dann zur Nullanzeige.
Die Waage wird durch Drücken der Taste ausgeschaltet.
schaltet sich die Waage automatisch aus.
6.2 Tarieren
Im Wägemodus
und drücken. Die Anzeige geht auf „0“
des Gefäßes ist nun intern gespeichert.
(Beispiel)
(Beispiel)
Drückt man nach Abschluß des Wägevorganges wieder Taste , erscheint erneut
„0“ im Display.
Der Tariervorgang kann beliebige Male wiederholt werden, beispielsweise beim Einwiegen von mehreren Komponenten zu einer Mischung (Zuwiegen).
Die Grenze ist dann erreicht, wenn der gesamte Wägebereich belegt ist.
Nach Abnehmen des Taragefäßes erscheint das Gesamtgewicht als Minus-Anzeige.
EMB-S-BA-d-1612
13
Display-
Umrechnungsfaktor
Gramm *
g
1.
Unze
oz
0.035273962
Troy Unze
ozt
0.032150747
Pennyweight
dwt
0.643014931
6.3 Wägeeinheiten
Die Waage kann unterschiedliche Einheiten anzeigen .
Die Umschaltung erfolgt über die -Taste.
Bei belasteter Wägeplatte – Taste gedrückt halten, nach einigen Sekunden
wechselt die Einheit.
anzeige
6.4 Zero-tracking
Mit der Auto-Zero-Funktion werden kleine Gewichtsschwankungen automatisch tariert.
Werden kleine Mengen vom Wägegut entnommen oder zugeführt, so können durch
die in der Waage vorhandene „Stabilitätskompensation“ falsche Wägeergebnisse
angezeigt werden! (Beispiel: Langsames Herausfließen von Flüssigkeiten aus einem
auf der Waage befindlichen Behälter).
Bei Dosierungen mit kleinen Gewichtsschwankungen empfiehlt es sich daher, diese
Funktion auszuschalten.
Bei ausgeschaltetem Zero-Tracking wird die Waagenanzeige jedoch unruhiger.
Zero-Tracking aktivieren/deaktivieren:
1 g =
Bei ausgeschalteter Waage die OFF-Taste drücken und gedrückt halten
OFF -Taste nicht loslassen. ON/TARE-Taste ebenfalls drücken und gedrückt hal-
ten
OFF -Taste kurz loslassen und wieder erneut drücken
im Display erscheint „AF“
Beide Tasten loslassen. Die Waage befindet sich im Menü.
Mit der ON/TARE-Taste “tr” auswählen
Mit der OFF -Taste bestätigen. In der Anzeige erscheint die aktuelle Einstellung.
EMB-S-BA-d-1612
14
Anzeige
Einstellung
Anzeige
Einstellung
Mit der ON/TARE-Taste kann nun zwischen folgenden Einstellungen ausgewählt
werden:
„tr Y“
„tr n“
Bestätigen Sie Ihre Auswahl mit der OFF-Taste. Nach kurzer Zeit kehrt die Waa-
ge automatisch in den Wägemodus zurück.
6.5 AUTO-OFF-Funktion
Für den Batteriebetrieb verfügt die Waage über eine automatische Abschaltfunktion,
die im Menü aktiviert oder deaktiviert werden kann. Gehen Sie hierzu wie folgt vor:
Bei ausgeschalteter Waage die OFF-Taste drücken und gedrückt halten
OFF-Taste nicht loslassen. ON/TARE-Taste ebenfalls drücken und gedrückt hal-
ten
OFF-Taste kurz loslassen und erneut kurz drücken
Auto-Zero eingeschaltet
Auto-Zero ausgeschaltet
im Display erscheint „AF“
Mit der OFF-Taste bestätigen
Mit der ON/TARE-Taste kann nun zwischen folgenden Einstellungen ausgewählt
werden:
„AF Y“
„AF n“
Bestätigen Sie Ihre Auswahl mit der OFF-Taste. Nach kurzer Zeit kehrt die Waa-
ge automatisch in den Wägemodus zurück.
Zur Batterieschonung schaltet die Waage 3 Minuten nach
abgeschlossener Wägung automatisch ab
Dauerbetrieb
EMB-S-BA-d-1612
15
Anzeige
Einstellung
6.6 Reset-Funktion
Rücksetzung des Menüs auf Werkseinstellungen.
Bei ausgeschalteter Waage die OFF-Taste drücken und gedrückt halten
OFF-Taste nicht loslassen. ON/TARE-Taste ebenfalls drücken und gedrückt hal-
ten
OFF -Taste kurz loslassen und erneut kurz drücken
im Display erscheint “AF” erscheint
Beide Tasten loslassen. Die Waage befindet sich im Menü.
Mit der ON/TARE-Taste “rSt” auswählen
Mit der OFF-Taste bestätigen. In der Anzeige erscheint die aktuelle Einstellung.
Mit der ON/TARE-Taste kann nun zwischen folgenden Einstellungen ausgewählt
werden:
„rst Y“
„rst n“
Bestätigen Sie Ihre Auswahl mit der OFF-Taste. Nach kurzer Zeit kehrt die Waa-
ge automatisch in den Wägemodus zurück.
Rücksetzung des Menüs auf Werkseinstellungen.
Keine Rücksetzung des Menüs auf Werkseinstellungen.
7 Wartung, Instandhaltung, Entsorgung
7.1 Reinigen
Vor der Reinigung trennen Sie das Gerät bitte von der Betriebsspannung.
Benutzen Sie bitte keine aggressiven Reinigungsmittel (Lösungsmittel o.ä.), sondern
nur ein mit milder Seifenlauge angefeuchtetes Tuch. Achten Sie darauf, dass keine
Flüssigkeit in das Gerät eindringt und reiben Sie mit einem trockenen, weichen Tuch
nach.
Lose Probenreste/Pulver können vorsichtig mit einem Pinsel oder Handstaubsauger
entfernt werden.
Verschüttetes Wägegut sofort entfernen.
EMB-S-BA-d-1612
16
Im Zusammenhang mit dem Vertrieb von Batterien und Akkus sind wir als Händler
gemäß Batterieverordnung verpflichtet, Endverbraucher auf folgendes hinzuweisen:
/Akkus können nach Gebrauch in kommunalen Sammelstellen
Schadstoffhaltige Batterien sind mit einem Zeichen, bestehend aus einer durch-
schlaggebenden Schwermetalls versehen.
Die Rückgabemöglichkeit beschränkt sich auf Batterien der Art, die wir in unserem
cher üblicherweise entledigen.
7.2 Wartung, Instandhaltung
Das Gerät darf nur von geschulten und von KERN autorisierten Servicetechnikern
geöffnet werden.
Vor dem Öffnen vom Netz trennen.
7.3 Entsorgung
Die Entsorgung von Verpackung und Gerät ist vom Betreiber nach gültigem nationalem oder regionalem Recht des Benutzerortes durchzuführen.
Hinweis gemäß Batter ieverordnung – BattV
Nur gültig für Deutschland!
Endverbraucher sind zur Rückgabe gebrauchter Batterien/Akkus gesetzlich verpflichtet. Batterien
oder im Handel zurückgegeben werden.
Dabei muss das übliche Gebrauchsende der Batterien/Akkus erreicht sein, ansonsten muss Vorsorge gegen Kurzschluss getroffen werden.
gestrichenen Mülltonne und dem chemischen Symbol (Cd = Cadmium, Hg =
Quecksilber, oder Pb = Blei) des für die Einstufung als schadstoffhaltig aus-
Schadstoffarme Batterien nur mit einer durchgestrichenen Mülltonne.
Sortiment führen oder geführt haben, sowie auf die Menge, deren sich Endverbrau-
EMB-S-BA-d-1612
17
• Es sind keine Batterien eingelegt.
wählen/ falls möglich, störendes Gerät
8 Kleine Pannenhil f e
Bei einer Störung im Programmablauf sollte die Waage kurz ausgeschaltet und vom
Netz getrennt werden. Der Wägevorgang muss dann wieder von vorne begonnen
werden.
Hilfe:
Störung Mögliche Ursache
Die Gewichtsanzeige leuchtet nicht.
Die Gewichtsanzeige ändert sich
fortwährend
• Die Waage ist nicht eingeschaltet.
• Die Batterien sind falsch eingelegt
oder leer.
• Die Verbindung zum Netz ist unterbrochen (Netzkabel nicht eingesteckt/defekt).
8 Instant help ................................................................................................... 17
9 Declaration of Conformity ........................................................................... 18
EMB-S-BA-e-1612
3
200-1S
500-1S
2000-0S
5000-0S
(M1)
( M2 )
(M1)
( M2 )
(With battery operation)
Operating period: 12 h
1 Technical data
KERN
Readability (d) 0,1 g 0,1 g 1 g 1 g
Weighing range (max) 200 g 500 g 2000 g 5000 g
Reproducibility 0.01 g 0.1 g 0.01g 0.01 g
Linearity ± 0.2 g ± 0.2 g± 2 g ± 2 g
EMB
EMB
EMB
EMB
Recommended adjustment
weight, not added (class)
Stabilization time (typical) 2-3 sec.
AUTO-OFF-function
Units dwt, g, oz, ozt
Operating temperature +5°C… +35°C
Humidity of air max. 80 % (not condensing)
Housing (B x D x H) mm
Weighing plate mm Ø 120
Battery operation (Standard)
Mains adapter (Option) 300 mA / 9 V
Underfloor weighing Hooks
200 g
500 g
3 min.
145 x 205 x 45
2 x 1.5 V AA
2000 g
5000 g
EMB-S-BA-e-1612
4
2 Basic Information (General)
2.1 Intended use
The balance you purchased is intended to determine the weighing value of material
to be weighed. It is intended to be used as a “non-automatic balance”, i.e. the
material to be weighed is manually and carefully placed in the centre of the weighing
pan. As soon as a stable weighing value is reached the weighing value can be read.
2.2 Improper Use
Do not use balance for dynamic weighing. In the event that small quantities are
removed or added to the material to be weighed, incorrect weighing results can be
displayed due to the “stability compensation“. (Example: Slowly draining fluids from a
container on the balance.)
Do not leave permanent load on the weighing pan. This may damage the measuring
system.
Impacts and overloading exceeding the stated maximum load (max) of the balance,
minus a possibly existing tare load, must be strictly avoided. Balance may be
damage by this.
Never operate balance in explosive environment. The serial version is not explosion
protected.
The structure of the balance may not be modified. This may lead to incorrect
weighing results, safety-relat ed faul ts and destruction of the balance.
The balance may only be used according to the described conditions. Other areas of
use must be released by KERN in writing.
2.3 Warranty
Warranty claims shall be voided in case
- Our conditions in the operation ma nual ar e i g nor ed
- Appliance used outside the described uses
- Appliance modified or opened
- Mechanical damage and damage caused by media, liquids
- Natural wear and tear
- Appliance improperly set up or incorrectly electrically connected
- Measuring system overloaded
EMB-S-BA-e-1612
5
2.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the
balance and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this test.
Information is available on KERN’s home page (www.kern-sohn.com) with regard to
the monitoring of balance test substances and the test weights required for this. In
KERN’s accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.
3 Basic Safety Precautions
3.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and commissioning, even if you
are already familiar with KERN balances.
3.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
4 T ransport and storage
4.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
4.2 Packaging / return transport
Keep all parts of the original packaging for a possibly required
return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove loose/mobile
parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the glass wind screen, the weighing
platform, power unit etc. against shifting and damage.
EMB-S-BA-e-1612
6
5 Unpacking, Setup and Commi s si oning
5.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use.
You will work accurately and fast, if you select the right location for your balance.
Therefore, observe the following for the i nstallation site:
Place the balance on a firm, level surface;
Avoid extreme heat as well as temperature fluctuation caused by
installing next to a radiator or in the direct sunlight;
Protect the balance against direct draughts due to open windows and
doors;
Avoid jarring during weighing;
Protect the balance against high humidity, vapours and dust;
Do not expose the device to extreme dampness for longer periods of
time. Non-permitted condensation (condensation of air humidity on the
appliance) may occur if a cold appliance is taken to a considerably
warmer environment. In this case, acclimatize the disconnected
appliance for ca. 2 hours at room temperature.
Avoid static charging of the material to be weighed, weighing container
and windshield.
If electro-magnetic fields or static charge occur, or if the power supply is unstable
major deviations on the display (incorrect weighing results) are possible. In that case,
the location must be changed.
EMB-S-BA-e-1612
7
KERN EMB-S
• Balance
1
2
Negative value
4
5
5.2 Unpacking
Carefully remove the balance from the packaging, remove plastic cover and setup
balance at the intended workstation.
5.2.1 Placing
The balance must be installed in a way that the weighing plate is exactly in horizontal
position.
5.2.2 Scope of delivery
Serial accessories:
• Batteries (2 x 1.5V AA)
• Operating instructions
5.3 Overview of display
Stability display
3 Balance set at zero
Net weight
Capacity display
6 Weighing Units
EMB-S-BA-e-1612
8
How to change weighing units
If the transport locking device remains locked in weighing mode, an error
5.4 Keyboard overvie w
• Switch on balance
• Tare balance
•
• Switch off the balance
• Adjustment menu access (longer pressing of the button)
5.5 Transport Securing
Before putting into operation, unlock the transport locking device on underside of
weighing scale, see illustration below:
Transport Securing
Transport locking device locked
During transport of weighing scale
message “E“ will appear on reaching max load.
Transport security loosened
In weighing mode
EMB-S-BA-e-1612
9
5.6 Battery operation (Standard)
Remove battery cover on the underside of the weighing pan. Insert 2 x 1.5 V
batteries. Reinsert the battery cover.
In order to save the battery, the balance switches automatically off after 3 minutes
without weighing.
If the batteries are run down, "LO" appears in the display. Press button and
replace the batteries immediately.
If the balance is not used for a longer time, take out the batteries and store them
separately. Leaking battery liquid could damage the balance.
5.7 Mains connection (option)
Power supply is provided by the external power supply unit KERN YKA-03 (optional).
The stated voltage value must be the same as the local voltage.
Only use original KERN mains adapters. Using other makes requires consent by
KERN.
5.8 Initial Commissioning
A warming up time of 3 minutes after switching on stabilizes the measuring values.
The accuracy of the balance depends on the local acceleration of gravity.
Strictly observe hints in chapter “Adjustment”.
EMB-S-BA-e-1612
10
Afterwards an internal value will be shown.
briefly and the size for the adjusting weight
pecifications) will be displayed on the
Now set the adjusting weight in the centre of the weighing
5.9 Adjustment
As the acceleration value due to gravity is not the same at every location on earth,
each balance must be coordinated - in compliance with the underlying physical
weighing principle - to the existing acceleration due to gravity at its place of location
(only if the balance has not already been adjusted to the location in the factory). This
adjustment process must be carried out for the first commissioning, after each
change of location as well as in case of fluctuating environment temperature. To
receive accurate meas uring values it is also recommended to adjust the balance
periodically in weighing operation.
With an adjustment weight, the weighing accuracy can be checked and re-adjusted
at any time.
Procedure when adjusting:
Observe stable environmental conditions. Stabilisation requires a certain warm-up
time.
Start balance by
Press and hold for approx. 5 sec until “--------“,
followed by “CAL“ briefly appears on the screen.
Press
(See chap. 1, S
screen.
plate.
(example)
(example)
“--------“ will be shortly displayed, followed by “F“.
EMB-S-BA-e-1612
11
This completes adjustment and the weighing scale will
Remove adjustment weight, adjustment complete.
change automatically to weighing mode.
(example)
An error during adjustment or the use of an incorrect adjusting weight will result in an
error message „E“. Repeat adjustment.
Keep the adjustment close to the balance. Daily control of the weighing exactness is
recommended for quali ty-relevant applications.
EMB-S-BA-e-1612
12
The weighing scale will
If the material to be weighed is heavier than the weighing
range, the display will show "E" (=Overload).
appear on the screen before the weighing scale is turned
In weighing mode, put tare vessel on weighing pan and
The display will show “0“, indicating that the
Place material to be weighed; read measured result.
6 Operation
6.1 Weighing
Start balance by pressing .
perform a self-test and change to zero display.
To turn off weighing scale, press the button . “oFF“ wil l
off automatically.
6.2 Taring
press .
weight of the vessel has been saved internally.
(example)
(example)
If one after finishing the weighing process presses again the button, „0“ appears
anew in the display.
The taring process can be repeated any number of times, e.g. when adding several
components for a mixture (ad di ng ) .
The limit is reached when the whole weighing range is exhausted.
After removing the taring container the total weight is displayed as negative display.
EMB-S-BA-e-1612
13
Display
Conversion factor
Grams *
g
1.
Ounce
oz
0.035273962
Troy ounce
ozt
0.032150747
Pennyweight
dwt
0.643014931
6.3 Weighing Units
Weighing results can be displayed in different units.
Change by pressing the button.
Press and hold the button when the weighing plate is loaded and the unit will
change after a few seconds.
screen
6.4 Zero-Tracking
The Auto-Zero function is used to tare small variations in weight automatically.
In the event that small quantities are removed or added to the material to be
weighed, incorrect weighing results can be displayed due to the “stability
compensation“. (Example: Slowly draining fluids from a cont ai ner on t he balance).
When apportioning involves small variations of weight, it is advisable to switch off this
function.
If Zero-Tracking however is switched off, the weighing display becomes more busy.
Activate/deactivate Zero-Tracking:
When the balance is switched off, press the OFF-button and keep it pressed
Do not release OFF -button. Press also the ON/TARE-button and keep it pressed
1 g =
Release OFF –button br iefly and press again
“AF“ will appear on the screen
Release both buttons. The balance is situated in the menu.
Select “tr” with the help of the ON/TARE-button
Confirm by pressing the OFF-button. The current setting will be shown on the
screen.
EMB-S-BA-e-1612
14
Display
Adjustment
Display
Adjustment
Now you can use the ON/TARE-button to select between the following settings:
„tr Y“
„tr n“
Confirm your selection with the OFF-button. After a short period the balance
returns automatically to weighing mode.
6.5 AUTO OFF function
For battery operation the balance has an automatic switch-off function which can be
activated or deactivated in the menu. Proceed as foll ows:
When the balance is switched off, press the OFF-button and keep it pressed
Do not release OFF -button. Press also the ON/TARE-button and keep it pressed
Release OFF-button briefly and press again briefly
“AF“ will appear on the screen
Confirm by pressing the OFF-button
Auto-Zero activated
Auto Zero switched off
Now you can use the ON/TARE-button to select between the following settings:
„AF Y“
„AF n“
Confirm your selection with the OFF-button. After a short period the balance
returns automatically to weighing mode.
In order to save the battery, the balance switches
automatically off after 3 minutes without weighing.
Continuous operation
EMB-S-BA-e-1612
15
Display
Adjustment
6.6 Reset function
Reset menu to default settings.
When the balance is switched off, press the OFF-button and keep it pressed
Do not release OFF -button. Press also the ON/TARE-button and keep it pressed
Release OFF-button briefly and press again briefly
“AF“ will appear on the screen
Release both buttons. The balance is situated in the menu.
Press the ON/TARE-button to select “rSt“
Confirm by pressing the OFF-button. The current setting will be shown on the
screen.
Now you can use the ON/TARE-button to select between the following settings:
„rst Y“
„rst n“
Confirm your selection with the OFF-button. After a short period the balance
returns automatically to weighing mode.
Reset menu to default settings.
No reset of menu to default settings.
7 Servicing, maintenance , disposal
7.1 Cleaning
Before cleaning, please disconnect the appliance from the operating voltage.
Please do not use aggressive cleaning agents (solvents or similar agents), but a
cloth dampened with mild soap suds. Ensure that no liquid penetrates into the device
and wipe with a dry soft cloth.
Loose residue sample/powder can be removed carefully with a brush or manual
vacuum cleaner.
Spilled weighing goods must be removed immediately.
EMB-S-BA-e-1612
16
In our capacity as retailers we are obliged in connection with the distribution of
batteries and storage batteries to inform our end users as follows:
storage batteries can be returned to municipal collection points or specialist shops
taken in cases where the service life of the
Batteries containing noxious substances bear a symbol consisting of a
chemical symbol (Cd = cadmium, Hg =
of the heavy metal crucial for the classification
of the noxious substance.
Return options are restricted to the types of battery that we keep or used to keep in
stock as well as the quantity commonly disposed of by end users.
7.2 Servicing, maintenance
The appliance may only be opened by trained service technicians who are authorized
by KERN.
Before opening, disconnect from power supply.
7.3 Disposal
Disposal of packaging and appliance must be carried out by operator according to
valid national or regional law of the location where the appliance is used.
Note on battery recycling regulations ( BattV)
Applies to Germany only!
End users are bound by law to return waste batteries / storage batteries. Batteries /
whilst taking into account common expiration times.
Precautions against short circuit must be
batteries / storage batteries has not yet expired.
crossed-out bin plus the
quicksilver, or Pb = lead)
Batteries with a low degree of noxious substances bear merely a crossed
out bin.
EMB-S-BA-e-1612
17
• No batteries inserted.
The displayed weight is permanently
Electromagnetic fi elds / stati c c har g i ng
The weighing result is obviously
Electromagnetic fi elds / stati c c har g i ng
8 Instant help
In case of an error in the program process, briefly turn off the balance and disconnect
from power supply. The weighing process must then be restarted from the beginning.
Help:
Fault Possible cause
The displayed weight does not glow.
changing
• The balance is not switched on.
• Batteries are inserted incorrectly or
empty
• The mains supply connection has
been interrupted (mains cable not
plugged in/faulty).
• Power supply interrupted.
• Draught/air movement
• Table/floor vibrations
• Weighing pan has contact with other
objects.
•
(choose different locat ion/switch off
interfering device if possible)
incorrect
Should other error messages occur, switch balance off and then on again. If the error
message remains inform manufacturer.
EMB-S-BA-e-1612
• The display of the balance is not at
zero
• Adjustment is no longer correct.
• Great fluctuations in temperature.
•
(choose different location/switch off
interfering device if possible)
18
9 Declaration of Conformity
To view the current EC/EU Declaration of Conformity go to:
www.kern-sohn.com/ce
The scope of delivery for verified weighing balances (= conformityrated weighing balances) includes a Declaration of Conformity.
EMB-S-BA-e-1612
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
