Keri Systems TRB User Manual

Tamper Relay Board
TAMPER SWITCH
12
BYPASS
12
12 VDC
GND
N/C
COM
N/O
J1
J2
J3
J4
J5
J6
RELAY
Red LED
Green LED
1
2
3
4
5
Relay Contacts
Unit Power
Tamper Switch
Connections
NXT Tamper
Connection
Tamper Bypass
Jumpers
Green LED
unit in
non-alarm
state
Red LED
unit in
alarm state
Installation Guide
The Tamper Relay Board (TRB) is used to provide external annunciation of controller enclosure and peripheral enclosure tamper events; either an opened enclosure cover or for an enclosure that has been removed from its mounting location (requiring additional installation steps by the Installer). The TRB enables NXT-family and PXL-family controllers to meet UL-294/CSA Class 4812 requirements for annunciation of controller tamper incidents. It is designed to accept standard types of tamper switches. The Installer must supply the external annunciation device (alarm, signal light, etc.).
Figure 1: Tamper Relay Board Diagram

1.0 TRB PCB Installation

The NXT/PXL standard enclosure has a set of four PEMs in the upper-right corner of the enclosure to which the TRB is mounted.
The NXT-4x4 and KPS power supply enclosure has four holes in the upper-right corner of the enclosure. The TRB is mounted in this location using four stand-offs.

2.0 Tamper Switch Installation

Keri provides one enclosure tamper switch with each TRB. The switch is typically installed along the edge of the enclosure opposite the enclosure hinge and clear of the enclosure lock (see Figure 2 on page 2).
Page 1 of 3 P/N: 01513-001 Rev. D
Tamper Relay Board
Enclosure
Wall
Tamper
Switch
Switch
Plunger
Switch
Connection
Wires
Outside of
Enclosure
Installation Guide
Figure 2: Tamper Switch Installation

3.0 TRB Wiring Instructions

Refer to Figure 1 on page 1 for all instructions in this Section.
Tamper Switches
provides the input signal for enclosure tamper events – enclosure cover forced open and/or enclosure removed from its mounting location
uses normally-open switches
connection is made to either or both J3 and J5 (the switch connections are designed in parallel)
requires two-conductor, AWG 22 wire
Bypass Jumpers
used if a tamper switch is NOT used in one of the two switch positions (single-switch application)
factory default is jumpers ON (bypasses both Tamper Switches)
remove the corresponding jumper when a tamper switch is installed
- remove Bypass Jumper 1 (J4) for switch position 1 (J3)
- remove Bypass Jumper 2 (J6) for switch position 2 (J5)
Relay Contacts
completes the circuit for alarm annunciation
relay changes state as a tamper switch changes state
Keri does NOT provide the alarm annunciation device
requires two- or three-conductor, AWG 22 wire depending upon your alarm annunciation device
Unit Power
requires 12 VDC, can be tapped off of the controller’s power
requires two-conductor, AWG 22 wire
Page 2 of 3 P/N: 01513-001 Rev. D
Tamper Relay Board
Installation Guide
NXT Tamper Event Report Connection
allows the NXT controller to record an Enclosure Tamper event
connect the provided cable between J2 on the TRB and J1 on the NXT controller – this is a keyed connection so be sure to orient the plug correctly
NOTE: The Tamper Event Report connection does not apply to the PXL. The PXL does not have the ability to report Enclosure Tamper events.

4.0 Unit Operation

The TRB is operational as long as power is supplied to the unit. Two LEDs on the TRB provide unit status.
Red LED – indicates alarm condition
Green LED – indicates non-alarm condition
Verify tamper switch operation by toggling the tamper switch(es) and observing the red and green LEDs follow tamper switch state.
Contact Keri Systems:
Keri USA Keri UK, Ireland, Europe
2305 Bering Drive San Jose, CA 95131
Telephone: (800) 260-5265
(408) 435-8400 Fax: (408) 577-1792 Fax: + 44 (0) 1763 274 106 Web: www.kerisys.com Web: www.kerisystems.co.uk E-mail: sales@kerisys.com
techsupport@kerisys.com
End of document.
Unit 17 Park Farm Industrial Estate Ermine Street Buntingford Herts SG9 9AZ UK
Telephone: + 44 (0) 1763 273 243
E-mail: sales@kerisystems.co.uk
tech-support@kerisystems.co.uk
Page 3 of 3 P/N: 01513-001 Rev. D
