RA 71

MODEL RA 71

RACK ADAPTER

DESCRIPTION

The Kepco Model RA 71 is designed for the installation of a Kepco ABC Series Power Supply in a standard 19-inch (482.6 mm)
rack. Slides can not be used with this rack adapter.

INSTALLATION

Assemble the rack adapter (refer to Figure 1): attach the two handles to the panel using four screws, then attach the two brackets
to the panel using six lockwashers and six nuts. Four mounting holes are provided for securing the rack adapter to the rack. Figure
2 provides instructions for installing the ABC power supply in the rack adapter, and shows outline dimensions of the assembled
rack adapter with the power supply installed.

KEPCO, INC. !"! 131-38 SANFORD AVENUE !" FLUSHING, NY. 11352 U.S.A.!!" TEL [phone]!!"

©1996, KEPCO, INC
Data subject to change without notice

FIGURE 1. RA 71 RACK ADAPTER ASSEMBLY
