www.CookWithKenyon.com

LITE-TOUCH Q® 2B TOUCH CONTROL

O W N E R S M A N U A L

Part # 143719

Created: October 20, 2010

Revised: December 28, 2011

Table of Contents

Section Page

Important Safeguards ................................................................................................................

Product Specications ..............................................................................................................

Installation Instructions

Step # 1 - Unpacking the Cooktop ....................................................................................

Step # 2 - Checking the Electrical Supply Requirements .................................................

Step # 3 - Countertop Preparation ....................................................................................

Step # 4 - Installing the Cooktop .......................................................................................

Step # 5 - Electrical Connection .......................................................................................

Step # 6 - Final Preparations Prior to Use .......................................................................

Operation of Lite-Touch™ Q Cooktop

Cookware ..........................................................................................................................

Lock Mode.........................................................................................................................

Initial Start-up ...................................................................................................................

Controls of Lite-Touch™ Q Cooktop .................................................................................

Hot Surface Indicator .......................................................................................................

Safety Thermal Cutout ......................................................................................................

Master Off ........................................................................................................................

Temperature Setting Guide ..............................................................................................

Cleaning ...........................................................................................................................

Maintenance ....................................................................................................................

1

3

5
6
6

9
10
10

11
11
12
12
13
13
13
13
14
14

Warranty Information ...............................................................................................................

Kenyon International, Inc.

8 Heritage Park Road

P.O. Box 925

Clinton, CT 06413 USA

Phone: [phone]

www.CookWithKenyon.com

15

IMPORTANT SAFEGUARDS

Please read these instructions in their entirety before

installation and use. The following information applies to all

KENYON Electric Cooktops.

This cooktop, like all appliances, has the potential to create safety problems
through careless and improper use. Please observe all of the following safety
precautions.

Proper Installation.

Be sure your appliance is properly installed and grounded by a qualied technician.

Never use your appliance for warming or heating the room.

CAUTION
Do not leave children alone.

Children should never be left alone or unattended in the area where the appliance is in use. They
should never be allowed to sit or stand on any part of the appliance. Do not let children play with
cooktop. Do not store items of interest to a child in cabinets above the cooktop, children
climbing on the cooktop to reach such items could be seriously injured.

Wear proper clothing/apparel.

Loose tting or hanging garments should never be worn while using the appliance. Fabric or other
ammable materials may contact hot surfaces during operation and may ignite and result in personal

injury.

User Servicing

Do not repair or replace any part of the appliance. If service ever becomes necessary, this
appliance should be serviced by AUTHORIZED PERSONNEL ONLY or call KENYON Customer

Care at [phone].

Storage in or on Appliance

Flammable materials should not be stored above, under or near surface cooking units.

Keep ammable materials away from cooktop.

Do not store plastic material (such as plastic utensils) in storage areas beneath cooktop.

Plastic items with low melting temperatures should not be stored under/over or near the cooktop.

Do not use water on grease res.

Smother re or ame or use dry chemical or foam-type extinguisher.

1

Use only dry pot holders.

Moist or damp pot holders on hot surfaces may result in burns from steam. Do not let pot holders
touch the elements on the appliance. Do not use a towel or other bulky cloth in place of a pot holder.

Do not cook on broken cooktop.

If cooktop should break, cleaning solutions and spillovers may penetrate the broken cooktop and
create a risk of electric shock. Contact an authorized service center or KENYON Customer Care
immediately at [phone].

Clean cooktop with caution.

Do not clean the cooktop while it is still hot. If a wet sponge or cloth is used to wipe spills on a hot
cooking surface, be careful to avoid steam burns. Some cleaners produce noxious fumes if applied to
a hot surface. Read the cleaner label for details prior to using.

Use proper pan size.

This appliance is equipped with one or more surface units of different size. Select cookware

having at bottoms large enough to cover the surface unit heating element. The use of undersized

utensils will expose a portion of the heating element to direct contact and may result in ignition of

clothing. Proper relationship of cookware to burner size will also improve efciency.

Never leave surface units unattended at high heat settings.

Boilover may cause smoking and greasy spillovers may ignite.

Glazed cooking utensils

Only certain types of glass, glass/ceramic, ceramic, earthenware, or other glazed utensils are suitable
for range-tip service without breaking due to sudden change in temperature.

Utensil handles should be turned inward and not extend over adjacent surface units.

To reduce the risk of burns, ignition of ammable materials, and spillage due to unintentional

contact with the utensil, the handle of a utensil should be positioned so that it is turned inward, and
does not extend over adjacent surface units.

Do not use aluminum foil on the surface of the cooktop.

Cookware should always be dry.

Do not heat cookware with excess water droplets on the outside of the pan. The droplets may begin
to boil and splatter.

Do not touch surface units or areas near units.

Surface units may be hot even though they are dark in color. Areas near surface may become hot

enough to cause burns. During and after use, do not touch, or let clothing or other ammable
materials contact surface units or areas near units until they have had sufcient time to cool. Among

these areas are the heating elements and surrounding glass surface.

DO NOT DISCARD THESE INSTRUCTIONS, KEEP THEM

WITH THE KENYON COOKTOP FOR FUTURE REFERENCE.

2

PRODUCT SPECIFICATIONS

Lite-Touch™ Q Series 2-Burner Large Models

B41540 - 120V AC - one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1400 watts

B41549 - 208V AC- one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1800 watts

B41541 - 240V AC - one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1800 watts

B41540L - 120V AC - one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1400 watts

B41549L - 208V AC - one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1800 watts

B41541L - 240V AC - one 6.5” (165mm) @ 1200 watts
one 8” (200mm) @ 1800 watts

Overall dimensions: 23 1/4” x 14 1/4” x 3 1/4”

590.6mm x 362mm x 82.6mm

Cutout dimensions: 21 3/4” x 12 3/4” with 1/4” radius

552.5mm x 323.9mm with 6.4mm radius

14 1/4"

23 1/4"

3 1/4"

12 3/4"21 3/4"

B41540, B41549, & B41541

23 1/4"

3 1/4"

12 3/4"

14 1/4"

21 3/4"

B41540L, B41549L, & B41541L

3

Lite-Touch™ Q & Lite-Touch™ Q Cortez Series 2-Burner Trimline Models

B41575 & B41775 - 120V AC - two 6.5” (165mm) @ 1200 watts

B41579 & B41779 - 208V AC- two 6.5” (165mm) @ 1200 watts

B41576 & B41776 - 240V AC - two 6.5” (165mm) @ 1200 watts

B41575L & B41775L - 120V AC - two 6.5” (165mm) @ 1200 watts

B41579L & B41779L - 208V AC - two 6.5” (165mm) @ 1200 watts

B41576L & B41776L - 240V AC - two 6.5” (165mm) @ 1200 watts

Overall dimensions: 21” x 12” x 3 1/4”

533.4mm x 304.8mm x 82.6mm

Cutout dimensions: 20” x 10 3/4” with 1/4” radius
508mm x 273.1mm with 6.4mm radius

12”

20"

21”

3 1/4”

10 3/4"

B41575, B41579, B41576,

B41775, B41779, & B41776

B41575L, B41579L, B41576L,

B41775L, B41779L, & B41776L

4
