Kenyon B41692 User Manual
INSTRUCTION MANUAL
Mediterranean 2-Burner
®
KENYON
Caribbean 2-Burner
Mediterranean, Caribbean & Alpine
Ceramic Glass Cook Tops
(240 Volt Models UL/C-UL APPROVED)
KENYON
P.O. Box 925
8 Heritage Park Road Part # 143048
Clinton CT 06413 USA
Phone: (860) 664 - 4906
FAX: (860) 664 - 4907 rev 3/26/2004
DC-1\kenyonengineering\manuals\ulmanuals\143048
PLEASE READ THESE
INSTRUCTIONS IN
THEIR ENTIRETY BEFORE
INSTALLATION AND USE
OF APPLIANCE.
***
DO NOT DISCARD
THIS MANUAL !
SAVE FOR FUTURE
REFERENCE.
Two Burner
B41511 - 240V AC - one 6” (165mm) burner @ 1200 watts
Trimline
B41516 - 240V AC - two 6” (165mm) burners @ 1200 watts each
Mediterranean Series Cook Top
PRODUCT SPECIFICATIONS
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
590.6mm x 362.0mm x 66.7mm
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
552.5mm x 323.9mm with 6.4 radius
Single Burner
Single Burner
B41518 - 240V AC - one 6” (165mm) burner @ 1200 watts
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 63.5mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 63.5mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
Two Burner
B41602 - 240V AC - two 6” (165mm) burners @ 1200 watts each
Single Burner
B41606 - 240V AC - one 6” (165mm) burner @ 1200 watts
Caribbean Series Cook Top
PRODUCT SPECIFICATIONS
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 63.5mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 63.5mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
Two Burner - Large
B49511 - 240V AC - one 6” (165mm) burner @ 1200 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
Two Burner - Small
B49516 - 240V AC - two 6” (165mm) burners @ 1200 watts each
Alpine Series Cook Top
PRODUCT SPECIFICATIONS
one 8” (200mm) burner @ 1800 watts
590.6mm x 362.0mm x 66.7mm
552.5mm x 323.9mm with 6.4 radius
Single Burner
Single Burner
B49518 - 240V AC - one 6” (165mm) burner @ 1200 watts
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 63.5mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 63.5mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
