1
1.WARNINGS .................................................... - 1 -
2.GETTING STARTED .................................... - 2 -
3. YOUR PHONE .............................................. - 3 -
4. FUNCTION MENU ...................................... - 5 -
4.1 CONTACTS ................................................. - 6 -
4.2.MESSAGE ................................................... - 6 -
4.3. CALL LOGS ............................................... - 7 -
4.4. OPEAR MINI ............................................. - 7 -
4.5. PALMCHAT ............................................... - 7 -
4.6. FACE BOOK .............................................. - 7 -
4.7. TWITTER ................................................... - 7 -
4.8. JAVA GAME ............................................... - 8 -
4.9. SETTINGS .................................................. - 8 -
4.10. CAMERA .................................................. - 9 -
4.11. AUDIO ....................................................... - 9 -
4.12. MY FILES ................................................. - 9 -
4.13. TORCH LIGHT ....................................... - 9 -
4.14. IMAGE ...................................................... - 9 -
4.15. CALENDAR ........................................... - 10 -
4.16. CLOCK ................................................... - 10 -
4.17. FM RADIO ............................................. - 10 -
4.18. DV ............................................................ - 10 -
4.19.RECORDER ............................................ - 10 -
4.20. BLUETOOTH ......................................... - 11 -
4.21.CALCULATOR ........................................ - 11 -
4.22 SERVICE .................................................. - 11 -
4.23.PROFILES ............................................... - 12 -
CONTENT
2
4.24. E BOOK .................................................. - 12 -
5. ENTRY MODE ............................................ - 12 -
6. CARE AND MAINTENANCE ................... - 13 -
7. TECHNICAL INFORMATION ................. - 14 -
8. BATTERY WARNING ................................ - 15 -
- 1 -
1.Warnings
Not following these simple guidelines may
be dangerous or illegal. Read the complete
user guide for further information.
TURN ON SAFELY
Do not turn on the phone when wireless
phone is prohibited or when it may cause
interference or danger.
ROAD SAFETY
Obey all road safety laws. Always use both
of your hands to operate the vehicle while
driving.
INTERFERENCE
All wireless phones may be sensitive to
interference, which may affect performance.
TURN OFF IN THE HOSPITALS
Follow all restrictions. Turn off the phone
near medical equipment.
TURN OFF ON AIRCRAFTS
Follow all restrictions. Wireless devices can
cause interference on aircrafts.
TURN OFF WHEN REFUELING
Do not use the phone at/near refueling
- 2 -
stations. Do not use near fuel or chemicals.
USE SENSIBLY
Only qualified personnel may install or
repair this product.
ENHANCEMENTS AND BATTERIES
Use only appropriate enhancements and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it
dry.
BACKUP COPIES
Remember to make back-up copies or keep
a written record of all important information
stored in your phone.
2.Getting Started
2.1 SIM Card Installation
When you subscribe to a cellular network,
you will receive a plug-in SIM card
complete with your subscription details,
such as your PIN, and available optional
services.
Caution: Do not bend or scratch your SIM
- 3 -
card. Avoid exposing your SIM card to static
electricity, water, or dirt.
Tips：Face the gold color contact point of
SIM card towards the mobile phone and
push the SIM card into the slot.
2.2 Battery Installation
Caution: Install according to the illustration
above to avoid breaking the battery
connectors.
2.3 Charging the Battery
Insert the charger; the flash symbol on the
charger plug must face upwards.
2.4 T-flash Card
Insert the T-Flash card into phone. This will
expand the Flash memory of the phone. Tap
Multimedia menu, you can browse MP3,
MP4, picture, etc.
2.5 USB Cable
You can transfer and store files, such as
MP3, MP4 and pictures from PC, through
USB cable, to the U-disk in phone or
identified SD card that is inserted.
3. Your Phone
- 4 -
3.1 Making a Call
In standby mode, press numerical keys to
dial phone number. When you finish
inputting phone number, press the dial key、
SIM2 key to make a call. If you're making a
long distance call, add the area code
preceding the telephone number. During a
call, you can press up/down keys to adjust
volume. Press left soft key to access
Options.
3.2 Emergency Service
You can dial an emergency call without the
SIM card. Contact your service provider to
get the emergency call number.
3.3 Answering a Call
When you receive a call, the phone will ring
or vibrate and will display an incoming call
indicator. Press the dial key, SIM2 key or
left soft key to answer. Press left soft key to
access options.
3.4 Rejecting/Ending a Call
Press end key to reject an incoming call or
end current call.
- 5 -
3.5 Keypad Definition
1. OK key: To confirm
2. Right soft key: To perform the function of
the prompt displayed in lower right corner
of the screen.
3. Left soft key: Enter main menu or to
perform the function of the prompt
displayed in lower left corner of the screen.
Click the left soft key then * lock the phone
4. Send key: To dial and pick up calls; on
standby mode, to see the record of all calls
made.
5. End key: Hold down this key to power
On/Off.
6. Number keys: To enter numbers and
letters
7. * key: cycle according to * keys to switch
and input *, +, P, W, display symbols list in
edit mode;
8. # key: long press # key scene mode
switch
9.0 key: Long press 0 key open flashlight
4. Function menu
- 6 -
4.1 Contacts
You can store contacts' personal information
and numbers while also search for
previously stored contacts. Press left soft
key to access options.
4.2.Message
4.2.1 Write Message
This function can begin a new SMS. After
completing the SMS，press left soft key to
access to options.
4.2.2 Inbox
To check received messages in inbox.
4.2.3 Outbox
Checks the information of unsuccessfully
sent message in outbox .
4.2.4 Drafts
Checks the information of unsuccessfully
sent message in drafts .
4.2.5 Sent box
Checks the information of unsuccessfully
sent message in sent box .
4.2.6 Security inbox
You will like information collection in the
- 7 -
security in the box
4.2.7 Templates
There are 5 alternative templates
4.2.8 Broadcast message
Edit broadcast message list
4.2.9 Voice mail server
Edit speech number
4.2.10 Option
SMS settings Message capacity
4.3. Call logs
In the call history menu, you can check
dialed calls, received calls, missed calls,
rejected calls, delete all, call timers, call cost,
and GPRS counter.
4.4. Opear Mini
Choose need network landing page
4.5. Palmchat
Choose need network landing page
4.6. Face book
Choose need network landing page
4.7. Twitter
Choose need network landing page
- 8 -
4.8. Java game
Your phone supplies built-in game, you can
play it whenever or wherever you want.
4.9. Settings
4.9.1 Phone settings
Date &time, language settings, Shortcut
settings, Auto power on/off, Power saving
mode, Restore factory settings
4.9.2 Display
Wallpaper settings, Idle display settings,
Contrast, Backlight, Keypad backlight time
4.9.3 Security
PIN, Modify PIN2, Phone locked, Modify
the cell phone password, Privacy, Auto
keypad lock, Lock screen by end-key, Guard
lock, Fixed dialing, Blacklist
4.9.4 Call settings
Dual-SIM, Call divert, Call waiting, Call
barring, Hide ID, Others.
4.9.5 Connections
Network account, GPRS Service, Data
connection settings, Network selection
- 9 -
4.10. Camera
Press left soft key or OK key to select the
function. The photo can be previewed in the
screen; press OK key to shoot and right soft
key to back, left soft key to access Options.
Use navigation keys, you can choose and
enter the functions list on screen.
4.11. Audio
The music player is used to play music files
in supported formats in the current player’s
list. You may view details of the music files
and set the current music file as the ring
signal for incoming call. You may connect
the Bluetooth earphone to enjoy the music.
4.12. My files
Enter this menu; you can check the files
store on T-flash card. Press left soft key, you
can do options.
4.13. Torch Light
Activate off
4.14. Image
Browse pictures and from already the photos
- 10 -
4.15. Calendar
You can use this feature to view the year,
date and solar term easily. Use navigation
keys to navigate other date. Press left soft
key, you can enter to submenu to do options.
4.16. Clock
World clock; Alarm;
4.17. FM radio
Enter FM radio (insert earphone). Press
left/right key to change frequency, Press the
left soft key to access Options.
4.18. DV
In the options of the video recorder interface,
you may set preview mode, white balance,
EV, night mode, avoid coruscate, video
quality, type, effect settings, storage and etc.
you may enter the video list to play the
video. You may select restore default and
the ex-factor setting is restored. Press the
middle (OK) key to begin recording and
press the left soft key to enter option. Your
phone can recorder 3GP, AVI formats file.
4.19.Recorder
- 11 -
You can take a recorder in this function. In
the play mode, use up key and down key to
adjust the volume. Press OK button to
record. After record, access Options. After
entering the file list, select one file, access to
Options.
4.20. Bluetooth
This mobile phone support Bluetooth
wireless connection. You can establish
wireless connection between mobile phone
and device to realize voice communication,
data exchange and synchronization. Press
left soft key to do options
4.21.Calculator
This feature can use your phone as a
calcularot for simple claculations. Press
corresponding keys to enter the numbers.
4.22 Service
Your mobile phone supports wireless
application protocol (WAP) service. You can
access many different WAP services such as
news, weather reports, flight information
and so on. These services are especially
- 12 -
designed for mobile phones and maintained
by WAP service providers.
4.23.Profiles
This phone provides several profiles, by
pressing left soft key, you can enter to set:
Active, Customize, Rename, and Enhance
Sound.
4.24. E book
This function can let you read E-Book
stored in the T-Flash Card.
5. Entry mode
You can use several methods for entering
text and numbers. By selecting a Text Entry
Mode, the phone provides a few Text Entry
Mode for new adding, editing contact
records, finding contacts, editing SMS and
writing memos.
Select Text Entry Mode:
5.1 Letter entry mode
Editing interface, click on the appropriate
soft keyboard subtitles.
5.2 Number entry mode
Click the top left corner of the input image
- 13 -
to switch to digital input, through the point
of the soft keyboard to enter the
corresponding number
6. Care and maintenance
Battery care
• Your device is powered by a rechargeable
battery. When the power is weak, please
charge the battery.
• Leaving the battery in hot or cold places,
such as in a closed car in summer or a
freezer in winter conditions, will reduce the
capacity and lifetime of the battery. Always
try to keep the battery between 59°F and
77°F (15°C and 25°C).
• Battery performance is particularly
limited in temperatures below freezing. Cell
phones are not considered household waste.
Mobile phone maintenance
• Keep the device dry. Precipitation,
humidity, and all types of liquids or
moisture can contain minerals that will
corrode electronic circuits. If your device
- 14 -
does get wet, remove the battery and allow
the device to dry completely before
replacing it.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas,
modifications, or attachments could damage
the device and may violate regulations
governing radio devices.
All of the above suggestions apply to your
device, battery, charger。
7. Technical Information
Weight:
Size :
Battery: 2500mhA
Networks: GSM900/1800
Battery work times refer to the list below
(Will not announce if the capacity is
changed):
The operation time of the battery depends
on conditions such as:
• Transmitting power level
• Signal (distance between the phone and the
base station)
- 15 -
• Network parameters defined by the
operator
• Phone use (WAP, games, SMS)
• Charging procedure used
Explanation:
The company has the final right of the
explanation for this document.
Software upgrades will not be announced.
8. Battery warning
8.1please used original matched battery. If
wrong battery is used, there will be danger o
f explosion.
8.2Disused old battery, please handle it
according to local environmental protection
law and don't throw it at random.
All pictures are for reference only in the
instruction book; please refer to the
actual phone.
- 16 -
FCC Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part 15
of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
- 17 -
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Caution: Any changes or modifications to
this device not explicitly approved by
manufacturer could void your authority
to operate this equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
RF Exposure Information
- 18 -
The device has been evaluated to meet
general RF exposure requirement. The
device can be used in portable exposure
condition without restriction.
FCC Statement
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part 15
of the FCC Rules. These limits are
designed to provide reasonable protection
against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed and
used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
- 19 -
reception, which can be determined by
turning the equipment off and on, the
user is encouraged to try to correct the
interference by one or more of the
following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Caution: Any changes or modifications to
this device not explicitly approved by
manufacturer could void your authority
to operate this equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any
- 20 -
interference received, including
interference that may cause undesired
operation.
RF Exposure Information
The device has been evaluated to meet
general RF exposure requirement. The
device can be used in portable exposure
condition without restriction.
Specific Absorption Rate (SAR)
Specific Absorption Rate (SAR)
information:
This Feature phone meets the
governments
requirements for exposure to radio waves.
The guidelines are based on standards
that were
developed by independent scientific
organizations through periodic and
thorough evaluation of
- 21 -
scientific studies. The standards include a
substantial safety margin designed to
assure the safety of all persons regardless
of age or health.
FCC RF Exposure Information and
Statement the SAR limit of USA (FCC) is
1.6 W/kg averaged over
one gram of tissue. Device types: Feature
phone (FCC
ID: ZSHK7720) has also been tested
against this SAR limit. This device was
tested for typical
body-worn operations with the back of
the phone
kept 10mm from the body. To maintain
compliance with FCC RF exposure
requirements, use
accessories that maintain a 10mm
separation distance between the user's
body and the back of
the phone. The use of belt clips, holsters
and similar
accessories should not contain metallic
- 22 -
components in its assembly. The use of
accessories that do not
satisfy these requirements may not
comply with
FCC RF exposure requirements, and
should be avoided.
Loading...
