C1
CONTENT
1.WARNINGS.............................…………………..….-2-
2.GETTING STARTED...................................………..….-4-
3.YOUR PHONE...................................……………..…...-5-
4.FUNCTION MENU..................................………..…….-7-
4.1 CONTACTS..................................………………..…..-7-
4.2.MESSAGE..........................…………………..….-7-
4.3. CALL LOGS...................................……………..……-9-
4.4. GAMES.................................…………………..…….-9-
4.5. AUDIO.................................…………………..……..-9-
4.6. FM RADIO.................................……………..……..-10-
4.7. SETTINGS...................................…………..……...-10-
4.8. FACE BOOK..................................…………………-11-
4.9.MULTIMEDIA...................................……………….-11-
4.10. APPLICATION..................................……………..-11-
4.11.PROFILES……………….................................…..-11-
4.12 INTERNET...................................………………….-11-
5. ENTRY MODE..................................…………..…….-12-
6. CARE AND MAINTENANCE...............................…...-13-
7. TECHNICAL INFORMATION.............................…....-14-
8. BATTERY WARNING..................................…..…….-15-
1
1.Warnings
Not following these simple guidelines may be
dangerous or illegal. Read the complete user
guide for further information.
TURN ON SAFELY
Do not turn on the phone when wireless phone is
prohibited or when it may cause interference or
danger.
ROAD SAFETY
Obey all road safety laws. Always use both of
your hands to operate the vehicle while driving.
INTERFERENCE
All wireless phones may be sensitive to
interference, which may affect performance.
TURN OFF IN THE HOSPITALS
Follow all restrictions. Turn off the phone near
medical equipment.
TURN OFF ON AIRCRAFTS
2
Follow all restrictions. Wireless devices can
cause interference on aircrafts.
TURN OFF WHEN REFUELING
Do not use the phone at/near refueling stations.
Do not use near fuel or chemicals.
USE SENSIBLY
Only qualified personnel may install or repair this
product.
ENHANCEMENTS AND BATTERIES
Use only appropriate enhancements and
batteries. Do not connect incompatible products.
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACKUP COPIES
Remember to make back-up copies or keep a
written record of all important information stored
in your phone.
3
2.Getting Started
2.1 SIM Card Installation
When you subscribe to a cellular network,
you will receive a plug-in SIM card complete with
your subscription details, such as your PIN, and
available optional services.
Caution: Do not bend or scratch your SIM card.
Avoid exposing your SIM card to static electricity,
water, or dirt.
Tips：Face the gold color contact point of SIM
card towards the mobile phone and push the SIM
card into the slot.
2.2 Battery Installation
Caution: Install according to the illustration above
to avoid breaking the battery connectors.
2.3 Charging the Battery
Insert the charger; the flash symbol on the
4
charger plug must face upwards.
2.4 T-flash Card
Insert the T-Flash card into phone. This will
expand the Flash memory of the phone. Tap
Multimedia menu, you can browse MP3, MP4,
picture, etc.
2.5 USB Cable
You can transfer and store files, such as MP3,
MP4 and pictures from PC, through USB cable,
to the U-disk in phone or identified SD card that
is inserted.
3. Y our Phone
3.1 Making a Call
In standby mode, press numerical keys to dial
phone number. When you finish inputting phone
number, press the dial key、 SIM2 key to make a
call. If you're making a long distance call, add the
area code preceding the telephone number.
During a call, you can press up/down keys to
5
adjust volume. Press left soft key to access
Options.
3.2 Emergency Service
You can dial an emergency call without the SIM
card. Contact your service provider to get the
emergency call number.
3.3 Answering a Call
When you receive a call, the phone will ring or
vibrate and will display an incoming call indicator.
Press the dial key, SIM2 key or left soft key to
answer. Press left soft key to access options.
3.4 Rejecting/Ending a Call
Press end key to reject an incoming call or end
current call.
3.5 Keypad Definition
1. OK key: To confirm
2. Right soft key: To perform the function of the
prompt displayed in lower right corner of the
screen.
3. Left soft key: Enter main menu or to perform
6
the function of the prompt displayed in lower left
corner of the screen. Click the left soft key then *
lock the phone
4. Send key: To dial and pick up calls; on standby
mode, to see the record of all calls made.
5. End key: Hold down this key to power On/Off.
6. Number keys: To enter numbers and letters
7. * key: cycle according to * keys to switch and
input *, +, P, W, display symbols list in edit mode;
8. # key: long press # key scene mode switch
9.0 key: Long press 0 key open flashlight
4.Function menu
4.1 Contacts
You can store contacts' personal information and
numbers while also search for previously stored
contacts. Press left soft key to access options.
4.2.Message
4.2.1 Write Message
7
This function can begin a new SMS. After
completing the SMS，press left soft key to
access to options.
4.2.2 Inbox
To check received messages in inbox.
4.2.3 Outbox
Checks the information of unsuccessfully sent
message in outbox .
4.2.4 Drafts
Checks the information of unsuccessfully sent
message in drafts .
4.2.5 Sent box
Checks the information of unsuccessfully sent
message in sent box.
4.2.6 Security inbox
You will like information collection in the security
in the box
4.2.7 T emplates
There are 5 alternative templates
4.2.8 Broadcast message
8
Edit broadcast message list
4.2.9 Voice mail server
Edit speech number
4.2.10 SMS settings
Settings Delete all Broadcast message
4.3. Call logs
In the call history menu, you can check dialed
calls, received calls, missed calls, rejected calls,
delete calls, call timers, call cost, and GPRS
counter.
4.4. Games
Your phone supplies built-in game, you can play it
whenever or wherever you want.
4.5. Audio
The music player is used to play music files in
supported formats in the current player’s list. You
may view details of the music files and set the
current music file as the ring signal for incoming
call. You may connect the Bluetooth earphone to
enjoy the music.
9
4.6. FM radio
Enter FM radio (insert earphone). Press left/right
key to change frequency, Press the left soft key
to access Options.
4.7. Settings
4.7.1 Phone settings
Date &time, language settings, Shortcut settings,
Auto power on/off, Power management, Browser
selection, Restore factory settings
4.7.2 Display
Wallpaper settings, Idle display settings,
Contrast, Backlight, Keypad backlight time
4.7.3 Security
PIN, Modify PIN2, Phone locked, Modify the cell
phone password, Privacy, Auto keypad lock, Lock
screen by end-key, Guard lock, Fixed dialing,
Blacklist
4.7.4 Call settings
Dual-SIM, Call divert, Call waiting, Call barring,
Hide ID, Others.
10
4.7.5 Connections
Network account, GPRS Service, Data
connection settings, Network selection
4.8. Facebook
Choose need network landing page
4.9.Multimedia
DV, Video, Recorder, Image.
4.10. Application
My files, Bluetooth, Calculator, Calendar, Clock, E
book, Torch Light, Games,STK,
4.11.Profiles
This phone provides several profiles, by pressing
left soft key, you can enter to set: Active,
Customize, Rename, and Enhance Sound.
4.12 Internet
Your mobile phone supports wireless application
protocol (WAP) service. You can access many
different WAP services such as news, weather
reports, flight information and so on. These
11
services are especially designed for mobile
phones and maintained by WAP service
providers.
4.12.2 Ebuddy
Choose need network landing page
5. Entry mode
You can use several methods for entering text
and numbers. By selecting a Text Entry Mode, the
phone provides a few Text Entry Mode for new
adding, editing contact records, finding contacts,
editing SMS and writing memos.
Select Text Entry Mode:
5.1 Letter entry mode
Editing interface, click on the appropriate soft
keyboard subtitles.
5.2 Number entry mode
Click the top left corner of the input image to
switch to digital input, through the point of the soft
12
keyboard to enter the corresponding number
6. Care and maintenance
Battery care
• Your device is powered by a rechargeable
battery. When the power is weak, please charge
the battery.
• Leaving the battery in hot or cold places, such
as in a closed car in summer or a freezer in
winter conditions, will reduce the capacity and
lifetime of the battery. Always try to keep the
battery between 59°F and 77°F (15°C and 25°C).
• Battery performance is particularly limited in
temperatures below freezing. Cell phones are not
considered household waste.
Mobile phone maintenance
• Keep the device dry. Precipitation, humidity, and
all types of liquids or moisture can contain
minerals that will corrode electronic circuits. If
13
your device does get wet, remove the battery and
allow the device to dry completely before
replacing it.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the
device and may violate regulations governing
radio devices.
All of the above suggestions apply to your device,
battery, charger.
7. Technical Information
Weight: 67g
Size: 116mm*50mm*14.7mm
Battery: 1000mAh
Networks: GSM 850/900/1800/1900 GPRS 1800
Battery work times refer to the list below (Will not
announce if the capacity is changed)
The operation time of the battery depends on
conditions such as:
14
• Transmitting power level
• Signal (distance between the phone and the
base station)
• Network parameters defined by the operator
• Phone use (WAP, games, SMS)
• Charging procedure used
Explanation:
The company has the final right of the
explanation for this document.
Software upgrades will not be announced.
8. Battery warning
8.1 Please use original matched battery. If wrong
battery is used, there will be danger of explosion.
8.2 Disused old battery, please handle it
according to local environmental protection law
and don't throw it at random.
All pictures are for reference only in the
instruction book; please refer to the actual
phone.
15
FCC Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmfulinterference to radio or television reception,
which can be determined by turning the equipment off and on, theuser is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly
approved by manufacturer could void your authority to operate this
equipment. This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
Specific Absorption Rate (SAR)
Specific Absorption Rate (SAR)
information:
This Feature phone meets the governments requirements for exposure to
radio waves. The guidelines are based on standards that were developed
by independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons regardless of age or
health.
FCC RF Exposure Information and
Statement the SAR limit of USA (FCC) is 1.6kg averaged over
one gram of tissue. Device types: Feature phone (FCCID: ZSHC1)
has also been tested against this SAR limit. This device was tested for
typical body-worn operations with the back of the phone kept 10mm from
the body. To maintain compliance with FCC RF exposure requirements,
use accessories that maintain a 10mm separation distance between the
user's body and the back of the phone. The use of belt clips, holsters a
nd similar accessories should not contain metallic components in its
embly. The use of accessories that do not satisfy these requirements
ass
may not comply with FCC RF exposure requirements, and should be
avoided
Loading...
