- 1-1 -
SECTION 1. GENERAL
• SERVICING PRECAUTIONS
.......................................................................................................
1-2
• ESD PRECAUTIONS
...................................................................................................................
1-4
• SPECIFICATIONS
........................................................................................................................
1-5
• LOCATION OF CUSTOMER CONTROLS
...................................................................................
1-6
SECTION 2. AUDIO PART
• BLOCK DIAGRAM
........................................................................................................................
2-1
• SCHEMATIC DIAGRAMS
............................................................................................................
2-3
• WIRING DIAGRAM
....................................................................................................................
2-15
• VOLTAGE SHEET (IC&TR) ........................................................................................................ 2-17
• PRINTED CIRCUIT DIARGAMS
................................................................................................
2-21
SECTION 3. DVD PART
• DVD PART ELECTRICAL TROUBLESHOOTING GUIDE
..........................................................
3-1
• DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING ...................................... 3-8
• DVD PART SCHEMATIC DIAGRAMS
........................................................................................
3-21
• VOLTAGE SHEET (IC & TR)
......................................................................................................
3-27
• PRINTED CIRCUIT DIAGRAM
...................................................................................................
3-29
SECTION 4. EXPLODED VIEWS
......................................................................................
4-1
SECTION 5. SPEAKER PART
..........................................................................................
5-1
SECTION 6. REPLACEMENT PARTS LIST
.....................................................................
6-1
CONTENTS
SECTION 1. GENERAL PART
❏
SERVICING PRECAUTIONS
NOTES REGARDING HANDLING OF THE PICK-UP
1. Notes for transport and storage
1) The pick-up should always be left in its conductive bag until immediately prior to use.
2) The pick-up should never be subjected to external pressure or impact.
2. Repair notes
1) The pick-up incorporates a strong magnet, and so should never be brought close to magnetic materials.
2) The pick-up should always be handled correctly and carefully, taking care to avoid external pressure and
impact. If it is subjected to strong pressure or impact, the result may be an operational malfunction and/or
damage to the printed-circuit board.
3) Each and every pick-up is already individually adjusted to a high degree of precision, and for that reason
the adjustment point and installation screws should absolutely never be touched.
4) Laser beams may damage the eyes!
Absolutely never permit laser beams to enter the eyes!
Also NEVER switch ON the power to the laser output part (lens, etc.) of the pick-up if it is damaged.
5) Cleaning the lens surface
If there is dust on the lens surface, the dust should be cleaned away by using an air bush (such as used
for camera lens). The lens is held by a delicate spring. When cleaning the lens surface, therefore, a
cotton swab should be used, taking care not to distort this.
6) Never attempt to disassemble the pick-up.
Spring by excess pressure. If the lens is extremely dirty, apply isopropyl alcohol to the cotton swab. (Do
not use any other liquid cleaners, because they will damage the lens.) Take care not to use too much of
this alcohol on the swab, and do not allow the alcohol to get inside the pick-up.
- 1-2 -
Storage in conductive bag
Drop impact
NEVER look directly at the laser beam, and don’t let
contact fingers or other exposed skin.
Magnet
How to hold the pick-up
Pressure
Pressure
Cotton swab
Conductive Sheet
NOTES REGARDING COMPACT DISC PLAYER REPAIRS
1. Preparations
1) Compact disc players incorporate a great many ICs as well as the pick-up (laser diode). These
components are sensitive to, and easily affected by, static electricity. If such static electricity is high
voltage, components can be damaged, and for that reason components should be handled with care.
2) The pick-up is composed of many optical components and other high-precision components. Care must
be taken, therefore, to avoid repair or storage where the temperature of humidity is high, where strong
magnetism is present, or where there is excessive dust.
2. Notes for repair
1) Before replacing a component part, first disconnect the power supply lead wire from the unit
2) All equipment, measuring instruments and tools must be grounded.
3) The workbench should be covered with a conductive sheet and grounded.
When removing the laser pick-up from its conductive bag, do not place the pick-up on the bag. (This is
because there is the possibility of damage by static electricity.)
4) To prevent AC leakage, the metal part of the soldering iron should be grounded.
5) Workers should be grounded by an armband (1MΩ)
6) Care should be taken not to permit the laser pick-up to come in contact with clothing, in order to prevent
static electricity changes in the clothing to escape from the armband.
7) The laser beam from the pick-up should NEVER be directly facing the eyes or bare skin.
- 1-3 -
Armband
Conductive
Sheet
Resistor
(1 Mohm)
Resistor
(1 Mohm)
❏
ESD PRECAUTIONS
Electrostatically Sensitive Devices (ESD)
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components
commonly are called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated
circuits and some field-effect transistors and semiconductor chip components. The following techniques should
be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off
any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a
commercially available discharging wrist strap device, which should be removed for potential shock reasons
prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ESD devices, place the assembly on a conductive
surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ESD devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can
generate electrical charges sufficient to damage ESD devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESD
devices.
6. Do not remove a replacement ESD device from its protective package until immediately before you are ready
to install it. (Most replacement ESD devices are packaged with leads electrically shorted together by
conductive foam, aluminum foil or comparable conductive materials).
7. Immediately before removing the protective material from the leads of a replacement ESD device, touch the
protective material to the chassis or circuit assembly into which the device will by installed.
CAUTION : BE SURE NO POWER IS APPLIED TO THE CHASSIS OR CIRCUIT, AND OBSERVE ALL OTHER
SAFETY PRECAUTIONS.
8. Minimize bodily motions when handing unpackaged replacement ESD devices. (Otherwise harmless motion
such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can
generate static electricity sufficient to damage an ESD device).
CAUTION. GRAPHIC SYMBOLS
- 1-4 -
THE LIGHTNING FLASH WITH APROWHEAD SYMBOL. WITHIN AN EQUILATERAL
TRIANGLE, IS INTENDED TO ALERT THE SERVICE PERSONNEL TO THE PRESENCE OF
UNINSULATED “DANGEROUS VOLTAGE” THAT MAY BE OF SUFFICIENT MAGNITUDE TO
CONSTITUTE A RISK OF ELECTRIC SHOCK.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO
ALERT THE SERVICE PERSONNEL TO THE PRESENCE OF IMPORTANT SAFETY
INFORMATION IN SERVICE LITERATURE.
- 1-5 -
❏
SPECIFICATIONS
- 1-6 -
❏
LOCATION OF CUSTOMER CONTROLS
FRONT PANEL
DISPLAY WINDOW
- 1-7 -
REAR PANEL
- 1-8 -
AUDIO ELECTRICAL TROUBLESHOOTING GUIDE
INSERT
POWER CORD.
TURN ON
THE RED LED?
IS POWER ON?
CHECK POWER PLUG
AND POWER SUPPLY CIRCUIT.
DOES INITIAL
READ WORK?
DOES IT PLAY?
YES
NO
YES
YES
OK
NO
YES
NO
NO
CHECK POWER SUPPLY CIRCUIT.
CHECK LASER CIRCUIT.
CHECK TRACKING SERVO CIRCUIT.
TURN POWER ON.
CHECK FOCUS CIRCUIT.
CHECK DISC.
DOES IT OUTPUT
AUDIO?
YES
NO
CHECK AUDIO CIRCUIT.
1.
1.1.
1.
- 1-9 -
2. AUDIO µ. COM CIRCUIT
POWER ON
Does CD/DVD
appear at FLT?
Does LOADING
appear at FLD?
Does it appear
DVD Error at
FLD?
Does Video1/2, TV
AUDIO, FM 87.5
appear at FLD?
OK.
Check
Connector(PN903)if
is normally.
Reconnet it.
Refer to SMPS
Refer to oscillator
Circuit.
Check DVD Reset Waveform.
Check IC101 Reset Wavefrom.
Check 3.3V line.
Check Power dection Circuit..
Check power part
of Main B/D.
Check oscillator
of x101.
Check if PN200
PIN is High.
Check if IC101
PIN is High.
Check if IC101 PIN
, , , is high
(5V).
Check if IC101
PIN
is High .
Replace IC101.
Does no Dise or
Time appear at FLD?
Check if DVD an Audio
Micom Interface is OK.
Check power.
Check DVD Module.
Check SMPS.
17
46 72
90
11
5
26
- 1-10 -
3. FRONT CIRCUIT (1/2)
POWER ON
TURN ON
THE GREEN LED?
CHECK IF THE
FRONT POWER
IS OK(*2).
IS DIGITRON
ON NORMALLY?
CHECK IF
THE HEADPHONE
IS OK.
YES
NO
YES
NO
YES
REFER TO SMPS PART.
CHECK IF
THE REMOCON
IS OK.
YES
CHECK IF
THE PN101/PN102
IS OK?
RECONNECT IT.
(REFER TO NOTICE *1).
CHECK IF
ALL BUTTENS
ARE OK.
YES
CHECK IF
THE VOLUME IS
OK.
YES
FRONT B/D OK.
YES
CHECK IF
THE VFD001 PINS
ARE OK.
CHECK PATTERN
AND RESOLDERING.
NO
YES
*1: When it i s needed to reconnect FPC cable into PN101/PN102,
short ZD972 + and screw(chassis GND) near to ZD972.
*2: PN101 Pins
PIN2 : -23.0V
PIN3 : -27.5V
PIN4 : 5.0V
PIN11 : -34.0V
PIN20 : 12.0V
NO
NO
- 1-11 -
4. FRONT CIRCUIT (2/2)
MEMO
- 1-12 -
- 3-1 -
SECTION 3. DVD PART ELECTRICAL
TROUBLESHOOTING GUIDE
1. Power check flow
- 3-2 -
2. Test & debug flow
- 3-3 -
- 3-4 -
- 3-5 -
- 3-6 -
- 3-7 -
- 3-8 -
❏
DETAILS AND WAVEFORMS ON SYSTEM TEST
AND DEBUGGING
1. SYSTEM 27MHz CLOCK,RESET,FLASH R/W SIGNAL
1) MT1379 main clock is at 27MHz(X501)
2) MT1336 reset is high active
- 3-9 -
3) RS232 waveform during procedure(Downloading)
4) Flash R/W enable signal during download(Downloading)
- 3-10 -
2. SDRAM CLOCK
1) MT1379 main clock is at 27MHz(X501)
3. TRAY OPEN/CLOSE SIGNAL
1) Tray open/close waveform
- 3-11 -
2) Tray close waveform
3) Tray open waveform
- 3-12 -
4. SLED CONTROL RELATED SIGNAL (NO DISC CONDITION)
5. LENS CONTROL RELATED SIGNAL(NO DISC CONDITION)
- 3-13 -
6. LASER POWER CONTROL RELATED SIGNAL
(NO DISC CONDITION)
7. DISC TYPE JUDGEMENT WAVEFORM
- 3-14 -
- 3-15 -
8. FOCUS ON WAVEFORM
- 3-16 -
9. SPINDLE CONTROL WAVEFORM (NO DISC CONDITION)
- 3-17 -
10. TRACKING CONTROL RELATED SIGNAL(System checking)
- 3-18 -
11. RF WAVEFORM
12. MT1379 AUDIO OPTICAL AND COAXIAL OUTPUT (ASPDIF)
- 3-19 -
13. MT1379 VIDEO OUTPUT WAVEFORM
1) Full colorbar signal(CVBS)
2) Y
- 3-20 -
3) C
14. AUDIO OUTPUT FORM AUDIO DAC
1) Audio related Signal
- 5-1 -
SECTION 5. SPEAKER PART
❏
MODEL: LHS-D6530W
853
851
852
850
854
855
862
LOCA.NO. PART NO A B C D E DESCRIPTION SPECIFICATION REMARKS
850 3720RMF060A O O O O O PANEL,FRONT SPK LHS-D6530W MOLD SILVER SPR
851 3701RM0047A O O O O O NET ASSEMBLY SPK LHS-D6530W NET ASSY
852 6400WETN01A O O O O O SPEAKER,WOOFER 18P90EHC1391 EAW WOOFER 4 OHM
853 3091RMW058A O O O O O CABINET ASSEMBLY SPK LHS-D6530W WOOD CABINET
854 6871RU9271F O O O O O PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230W SUB WOOFER 2.5M, OR
855 3610RM0002A O O O O O FOOT RUBBER FE-5620WE STANDARD 4 EA
862 353M050C O O O O O SCREW BH 3.5X16 FBK
RUN DATE : 28.AUGUST.2003
MODEL : <A> LGECM, <B> LGEIN, <C> LGEMT, <D> LGETT
<E> S&E
- 5-2 -
❏
MODEL: LHS-D6530C
862
854
853
A800
855
852
851
850
LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS
850 3720RMF058A PANEL,FRONT SPK LHS-D6530CV MOLD SILVER SP
851 6400DBHX01A SPEAKER,TWEETER SN11AP06D BALHAE TWEETER(DOME)
852 6400WETC01A SPEAKER,WOOFER 08P60EHC1390J EAW WOOFER 8 OHM
853 3110RMP019A CASE LHS-D6530CV MOLD SILVER SPRAY
854 6871RU9272A PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6530V/C/T TERMINAL + 2.2U
855 3610RM0001F FOOT FE-5620 FOOT (PH 10 X 2T,EVA,2
862 353M050D SCREW WOOD DRC 3.5X 12 BK
865 6871RU9271C PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230T CENTER WIRE(5M)/ (G
A800 6401RM0064A SPEAKER ASSEMBLY 08R60EHC3015 EAW LHS-D6530C(ST
- 5-3 -
❏
MODEL: LHS-D6530T
862
854
853
864
852
851
A800
850
LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS
850 3720RMF059A PANEL,FRONT SPK LHS-D6530S MOLD SILVER SPR
851 6400DBHX01A SPEAKER,TWEETER SN11AP06D BALHAE TWEETER(DOME)
852 6400WETC01B SPEAKER,WOOFER 08R60EHC3015 EAW FULL-RANGE(HI
853 3110RMP020A CASE LHS-D6530S MOLD SILVER SPRAY
854 6871RU9272A PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6530V/C/T TERMINAL + 2.2U
862 353M050D SCREW WOOD DRC 3.5X 12 BK
864 353M056D SCREW TRQ 3.5X8 FBK
865 6871RU9271D PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230T REAR WIRE(10M) R/CH
866 6871RU9271E PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230T REAR WIRE(10M)/ L/C
A800 6401RM0066A SPEAKER ASSEMBLY 08R60EHC3015 EAW LHS-D6530T (S
- 5-4 -
❏
MODEL: LHS-D6530V
853
A800
862
854
852
851
850
LOCA.NO. PART NO DESCRIPTION SPECIFICATION REMARKS
850 3720RMF057A PANEL,FRONT SPK KHS-D6530 MOLD SILVER SPRA
851 6400DBHX01A SPEAKER,TWEETER SN11AP06D BALHAE TWEETER(DOME)
852 6400WETC01A SPEAKER,WOOFER 08P60EHC1390J EAW WOOFER 8 OHM
853 3110RMP018A CASE LHS-D6530V MOLD SILVER SPRAY
854 6871RU9272A PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6530V/C/T TERMINAL + 2.2U
862 353M050D SCREW WOOD DRC 3.5X 12 BK
865 6871RU9271A PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230T FRONT WIRE(5M) R CH
866 6871RU9271B PWB(PCB) ASSEMBLY,SUBSET(AUDIO LHS-D6230T FRONT WIRE(5M)/ L C
A800 6401RM0065A SPEAKER ASSEMBLY 08R60EHC3015 EAW LHS-D6530V (S
2-1 2-2
SECTION 2. AUDIO PART
❏
BLOCK DIAGRAM
2-3 2-4
❏
SHEMATIC DIAGRAMS
• FRONT & POWER SCHEMATIC DIAGRAM
2-5 2-6
• MICOM SCHEMATIC DIAGRAM
2-7 2-8
• I/O SCHEMATIC DIAGRAM
NOTE: Warning
Parts that are shaded are critical With respect
to risk of fire or electrical shock.
NOTE:
1. Shaded(■) parts are critical for safety.Replace only
with specified part number.
2. Voltages are DC-measured with a digital voltmefer
during Play mode.
2-9 2-10
• DAP SCHEMATIC DIAGRAM
• AMP SCHEMATIC DIAGRAM
2-11 2-12
• SMPS SCHEMATIC DIAGRAM
2-13 2-14
NOTE: Warning
Parts that are shaded are critical With respect
to risk of fire or electrical shock.
2-15 2-16
❏ WIRING DIAGRAM
NOTE: Warning
Parts that are shaded are critical With respect
to risk of fire or electrical shock.
2-17 2-18
1.LH-D6530(MAIN)
1).IC101(LC876748C-52K, MICOM)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
1 2.15V 21 4.88V 41 -31.V 61 81
2 4.8V 22 3.94V 42 -28.V 62 82
3 1.36V 23 3.26V 43 -29.V 63 83
4 24 3.26V 44 -25.V 64 2.2V 84
5 25 0 45 -32.V 65 85 3.3V
6 26 2.75V 46 4.85V 66 86 1.8V
7 27 4.85V 47 -31.V 67 87 3.17V
8 28 4.85V 48 -31.V 68 88 3.3V
9 29 49 -26.V 69 89 0
10 30 -31.V 50 -25.V 70 3.26V 90 4.88V
11 31 -31.V 51 -32.V 71 3.15V 91 1.5V
12 32 -31.V 52 -26.V 72 5.V 92
13 33 -31.V 53 -26.V 73 4.95V 93
14 0 34 -31.V 54 -26.V 74 4.96V 94
15
2.68V(9.8304MHz)
35 -31.V 55 -26.V 75 95 0
16
2.94V(9.8304MHz)
36 -31.V 56 -32.V 76 96 0
17 4.89V 37 -31.V 57 -32.V 77 97 0
18 4.86V 38 -31.V 58 -32.V 78 98 2.7V
19 39 -31.V 59 -25.V 79 99 2.6V
20 4.88V 40 -31.V 60 0 80 100 2.6V
2).IC201(AK5365VQ, ADC & FUCTION IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
1 12 2.5V 23 LRCK 34 0
2 0 13 2.5V 24 MCLK 35 0
3
ADATA4_L_IN
14 2.5V 25 3.3V 36
ADATA1_R_IN
4 0 15 2.5V 26 3.3V 37 0
5
ADATA3_L_IN
16 5.V 27 0 38
ADATA2_R_IN
6 0 17 0 28 0 39 0
7
ADATA2_L_IN
18 2.5V 29 0 40
ADATA3_R_IN
8 0 19 0 30 0 41 0
9
ADATA1_L_IN
20 3.3V 31 3.3V 42
ADATA4_R_IN
10 2.5V 21
ADATA_OUT
32 3.3V 43 0
11 2.5V 22 BCK 33 3.9V 44
3).IC202(AK4117VF-E2, DIR IC)
PIN No. Volt(V) PIN No. Volt(V)
10 13
ADATA_IN
2 3.3V 14 MCLK
315
416
5 SPDIF_IN 17
6 3.3V 18
7 0 19 3.3V
8
2.2V(12.288MHz)
20 3.3V
921
10 LRCK 22
11 BCK 23 3.3V
12
ADATA_OUT
24 0
4).IC203(74VHC244MTCX, BUFFER IC)
PIN No. Volt(V) PIN No. Volt(V)
1 0 11 ADATA1
2 0 12 ADATA2
3 LRCK 13 ADATA0
4 14 ADATA3
5 BCK 15 BCK
6 ADATA3 16
7 ADATA0 17 LRCK
8 ADATA2 18 0
9 ADATA1 19 0
10 0 20 3.2V
5).IC301(PS9818, DAP IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
1 0 21 0 41
PWM_OUT
61
PWM_OUT
81 0
2 0 22 3.3V 42 2.5V 62
PWM_OUT
82 3.3V
3 2.35V 23 ADATA0 43 0 63 0 83 3.3V
4 5.V 24 ADATA1 44 0 64 0 84 0
5 2.35V 25 ADATA2 45
PWM_OUT
65 3.3V 85 0
6 2.32V 26 ADATA3 46
PWM_OUT
66 2.5V 86
2.27(12.288MHz)
7 0.89V 27 47 3.3V 67
PWM_OUT
87 3.3V
8 0 28 0 48
PWM_OUT
68
PWM_OUT
88
9 0 29 3.3V 49
PWM_OUT
69 0 89
10 3.3V 30 50 0 70
PWM_OUT
90
11 0 31 51
PWM_OUT
71
PWM_OUT
91 2.5V
12 0 32 52
PWM_OUT
72 3.3V 92 0
13 2.5V 33 53 0 73 0 93
14 0 34 2.5V 54
PWM_OUT
74
PWM_OUT
94 3.3V
15 0 35 0 55
PWM_OUT
75
PWM_OUT
95 0
16 0 36
PWM_OUT
56 3.3V 76 3.2V 96 4.89V
17 0 37
PWM_OUT
57 0 77 0 97
18 0 38 0 58
PWM_OUT
78 1.5V 98
19 BCK 39 3 59
PWM_OUT
79 1.8V 99
20 LRCK 40
PWM_OUT
60 0 80 2.5V 100
6).IC501(NJM4580M, OP AMP IC)
PIN No. Volt(V) PIN No. Volt(V)
1
Audio1_L_OUT
5
Audio1_R+_IN
2
Audio1_L-_IN
6
Audio1_R-_IN
3
Audio1_L+_IN
7
Audio1_R_OUT
4 -11.8V 8
7).IC502(NJM4580M, OP AMP IC)
PIN No. Volt(V) PIN No. Volt(V)
1 S/W_OUT 5 S/W_OUT
2 S/W-_IN 6 S/W_OUT
3 S/W+_IN 7 S/W_OUT
4 -11.8V 8 11.9V
8).IC503(NJM4580M, OP AMP IC)
PIN No. Volt(V) PIN No. Volt(V)
1
H/Phone_L_OUT
5
H/Phone_R+_IN
2
H/Phone_L-_IN
6
H/Phone_R-_IN
❏
VOLTAGE SHEET (IC&TR)
2-19 2-20
3
H/Phone_L+_IN
7
H/Phone_R_OUT
4 -11.8V 8 11.9V
9).IC601(NJM2296M, VIDEO SWITCHING IC)
PIN No. Volt(V) PIN No. Volt(V)
1 Video_OUT 9
2 5.V 10 5.V
3 Video2_IN 11 Video_OUT
4120
5 Video1_IN 13
6 14 5.V
7
COMPOSITE_IN
15 Video_OUT
8 -12.V 16 5.V
10).IC710(STA505, DIGITAL AMP IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
10 10
REAR_L+_OUT
19 0 28 3.28V
2
FRONT_L+_OUT
11
REAR_L+_OUT
20 0 29 REAR_L- _IN
3
FRONT_L+_OUT
12 31.5V 21 4.89V 30
REAR_L+_IN
4 31.5V 13 0 22 4.89V 31
FRONT_L-_IN
5 0 14 0 23 3.3V 32
FRONT_L+_IN
6 0 15 31.5V 24 0 33 26.36V
7 31.5V 16
REAR_L-_OUT
25 3.18V 34 26.36V
8
FRONT_L-_OUT
17
REAR_L-_OUT
26 3.16V 35 31.42V
9
FRONT_L-_OUT
18 27 3.16V 36 31.42V
11).IC730(STA505, DIGITAL AMP IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
10 10
FRONT_R+_OUT
19 0 28 3.28V
2
REAR_R+_OUT
11
FRONT_R+_OUT
20 0 29s
FRONT_R-_IN
3
REAR_R+_OUT
12 31.5V 21 4.89V 30
FRONT_R+_IN
4 31.5V 13 0 22 4.89V 31
REAR_R-_IN
5 0 14 0 23 3.3V 32
REAR_R+_IN
6 0 15 31.5V 24 0 33 26.36V
7 31.5V 16
FRONT_R-_OUT
25 3.18V 34 26.36V
8
REAR_R-_OUT
17
FRONT_R-_OUT
26 3.16V 35 31.42V
9
REAR_R-_OUT
18 27 3.16V 36 31.42V
12).IC750(STA501, DIGITAL AMP IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
1 0 10 19 0 28 3.28V
2
CENTER+_OUT
11 20 0 29
3
CENTER+_OUT
12 31.5V 21 4.89V 30
4 31.5V 13 0 22 4.89V 31
CENTER-_IN
5 0 14 0 23 3.3V 32
CENTER+_IN
6 0 15 31.5V 24 0 33 26.36V
7 31.5V 16 25 3.18V 34 26.36V
8
CENTER-_OUT
17 26 3.16V 35 31.42V
9
CENTER-_OUT
18 27 3.16V 36 31.42V
13).IC770(STA505, DIGITAL AMP IC)
PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V) PIN No. Volt(V)
10 10
WOOFER-_OUT
19 0 28 3.28V
2
WOOFER+_OUT
11
WOOFER-_OUT
20 0 29
WOOFER-_IN
3
WOOFER+_OUT
12 31.5V 21 4.89V 30
WOOFER-_IN
4 31.5V 13 0 22 4.89V 31
WOOFER+_IN
5 0 14 0 23 3.3V 32
WOOFER+_IN
6 0 15 31.5V 24 0 33 26.36V
7 31.5V 16
WOOFER-_OUT
25 3.18V 34 26.36V
8
WOOFER+_OUT
17
WOOFER-_OUT
26 3.16V 35 31.42V
9
WOOFER+_OUT
18 27 3.16V 36 31.42V
2.LH-D6530(SMPS)
1).IC901(KA5M0365R-YDTU, PWM IC)
PIN No. Volt(V)
1 GND
2 300V
3 12V
4 0 ~ 6V
2).IC902(KA5Q1265RF-YDTU, PWM IC)
PIN No. Volt(V)
1 300V
2 GND
3 15V
4 0 ~ 6.5V
5 0 ~ 3V
3).IC921(KA378R05-TSTU, REGULATOR IC)
PIN No. Volt(V)
1 5.6V
25V
3 GND
4 2.5V
4).IC922(KA78R12TSTU, REGULATOR IC)
PIN No. Volt(V)
1 13V
2 12V
3 GND
4 3.3V
5).IC923(KA78R33TSTU, REGULATOR IC)
PIN No. Volt(V)
1 4.5V
2 3.3V
3 GND
4 2.5V
6).IC924(KIA7808API-CU, REGULATOR IC)
PIN No. Volt(V)
1 12V
2 GND
38V
7).IC941(KA431AZ, REGULATOR IC)
PIN No. Volt(V)
1 2.5V
2 GND
3 4.8V
8).IC942(KA431AZ, REGULATOR IC)
PIN No. Volt(V)
1 2.5V
2 GND
3 30V
2-21 2-22
❏
PRINTED CIRCUIT DIAGRAMS
• MAIN P.C BOARD (SOLDER SIDE)
2-23 2-24
• MAIN P.C BOARD (COMPONENT SIDE)
2-25 2-26
• FRONT P.C. BOARD
2-27 2-28
• SMPS P.C. BOARD
3-21 3-22
❏
DVD PART SCHEMATIC DIAGRAMS
• MPEG SCHEMATIC DIAGRAM
3-243-23
• SERVO SCHEMATIC DIAGRAM
• INTERFACE SCHEMATIC DIAGRAM
3-263-25
3-27 3-28
❏
VOLTAGE SHEET (IC&TR)
3-29 3-30
❏
PRINTED CIRCUIT DIAGRAM
• DVD P.C. BOARD(SOLDER SIDE)
3-31 3-32
• DVD P.C. BOARD (COMPONENT SIDE)
4-1 4-2
351
301
268
302
303
A46
A41
A26
275
266
267
A43
270
272
264
265
250
260
269
305
A47
TUNER
454
454
SECTION 4. EXPLODED VIEWS
• CABINET AND MAIN FRAME SECTION
NOTE) Refer to “SECTION 6 REPLACEMENT
PARTS LIST” in order to look for the
part number of each part.
4-3 4-4
• Deck Mechanism Exploded View
LOCA.NO. PART NO DESCRIPTION SPECIFICATION
A26 6721RF0381A DECK ASSEMBLY,AUDIO DECK/MECHA DP-7A-HZ
A01 4861R-0016D CLAMP ASSEMBLY DECK/MECHA DISC DP-7C(7A) -HZ
A02 3041R-M018A BASE ASSEMBLY MAIN DP-7A-HZ
A03 3041R-M016D BASE ASSEMBLY SLED DP-7C(7A) -HZ
003 4860R-0021A CLAMP UPPER DP7
004 4930R-0402A HOLDER CLAMP DP-7A
010 6850R-GK12A CABLE,FLAT P=1.0 FFC UL2896(0.05X0.65) 11
011 3210R-M002A FRAME UP/DOWN MOLD DP7C
011A 6850R-JW14B CABLE,FLAT P=1.0 FFC UL2896(0.035X0.7) 23
012 5040R-0075D RUBBER DAMPER DP7 (YAMAUCHI 30)
013 4400R-0006B BELT DECK/MECHA DP2-5, DP7C,DP7A OT
014 4470R-0055A GEAR PULLEY
015 6871RJ4415A PWB(PCB) ASSEMBLY,JACK(AUDIO) PWB(PCB) TOTAL LOADING-HZ
015A 4681R-1023G MOTOR ASSEMBLY DECK/MECHA LOADING-HZ
015B 4560R-0008A PULLEY MOTOR
015C 4680R-E010A MOTOR(MECH) FEEDING BCZ3B51 SANKYO FOR DP7
017 4470R-0056A GEAR LOADING
018 4974R-0023A GUIDE UP/DOWN
020 3040R-D001A BASE MAIN MOLD DP-7AUDIO
021 4680R-C011A MOTOR(MECH) SPINDLE JCL9B68 SANKYO FOR COM
022 4681R-0034D MOTOR ASSEMBLY DECK/MECHA FEEDING DP-7C(7A) -
024 4470R-0131A GEAR PINION DP7C
024A 5006R-0044A CAP SKEW-T DP7C
024B 5006R-0043A CAP SKEW DP7C
025 4470R-0130A GEAR MIDDLE DP7C
026 3390R-0012A TRAY DISC(DP-5RM MULTI)
028 4370R-0082B SHAFT DECK/MECHA PU R DP-7C OTHER
029 4370R-0082A SHAFT PU DP-7C
030 4471R-0013D GEAR ASSEMBLY DECK/MECHA RACK DP-7C(7A) -HZ
031 6716DPH005A PICK UP,DVD PVR-502W MITSUMI PLAYER H/HIGH
429 1SZZR-0012A SCREW B-TITE
430 1SZZH-1003A SCREW + D2.0 6MM SWRCH16A/NIY 4.5MM
431 1SZZH-1007B SCREW,DRAWING + D2.0 6MM SWRCH16A/ZNBK 4MM 1
432 1SZZR-0023B SCREW,DRAWING + 1 D1.7 L6.0 SWRCH16A/FZY RAC
433 1SZZR-0050A SCREW,DRAWING + 1 D2.0 L4.5 SWRCH16A/ZNY S-T
435 1SZZR-0011A SCREW MACHINE
Loading...
