Kenmore Elite 11021062000, 11021064000, 11021066000, 11021082000, 11021084000 Owner’s Manual

...

E L I T E

Automatic Washers with CALYPSO TM Wash Motion

Lavadoras autom&ticas con CALYPSO TM Movimiento de lavada

Laveuses automatiques & mouvement

lava e CALYPSO TM

9724529A Sears Canada, Inc., Toronto, Ontario, Canada MSB 2B8 www.sears.ca

Sears Roebuck and Co., Hoffman Estates, IL 60179, U.S.A. www.sears.com

TABLE OF CONTENTS

WE SERVICE

WE SERVICE WHAT WE SELL ........................................... 2

WARRANTY ......................................................................... 3

WASHER SAFETY ............................................................... 4

INSTALLATION REQUIREMENTS ..................................... 5

Tools and Parts ............................................................................ 5

Alternate Parts You May Need .................................................... 5

Location Requirements ................................................................ 6

Drain System ................................................................................ 6

Electrical Requirements ............................................................... 7

INSTALLATION INSTRUCTIONS ....................................... 8

Install Leveling Feet ..................................................................... 8

Connect the Drain Hose .............................................................. 8

Connect the Inlet Hoses .............................................................. 9

Secure the Drain Hose ................................................................. 9

Level the Washer ....................................................................... 10

Complete Installation ................................................................. 10

FEATURES AND BENEFITS ............................................. 11

CALYPSO TM Wash Motion ........................................................ 11

WASHER USE .................................................................... 12

Starting Your Washer ................................................................. 12

Pausing or Restarting ................................................................ 13

Changing Cycles, Options and Modifiers .................................. 13

Cycles ......................................................................................... 13

What Happens in a Wash Cycle ................................................ 14

Options ....................................................................................... 15

Modifiers .................................................................................... 16

LAUN DRY TIPS ................................................................. 17

Loading ...................................................................................... 17

WASHER CARE ................................................................. 18

Cleaning Your Washer ............................................................... 18

Water Inlet Hoses ....................................................................... 18

Vacation, Storage, and Moving Care ........................................ 18

TROUBLESHOOTING ....................................................... 19

LIB INSTRUCTIONS .......................................................... 22

WHAT WE SELL

KENMORE ELITE TM WASHERS

"We Service What We Sell" is our assurance that you can depend on Sears for service. Your Kenmore appliance has added value when you consider that Sears has service units nationwide, staffed with professional technicians trained on all appliances Sears sells. They have knowledge and skills, tools, parts and equipment to ensure our pledge to you that "We Service What

We Sell." Maintain the value of your purchase with a Sears Maintenance

Agreement. Kenmore appliances are designed, manufactured, and tested for years of dependable operation. Yet, any major appliance may require service from time to time. The Sears Maintenance Agreement offers you an outstanding service program for your product.

The Sears Maintenance Agreement

• Is your way to buy tomorrow's service at today's prices.

• Eliminates repair bills resulting from normal use.

• Allows for as many service calls as required.

• Provides an annual Preventative Maintenance Check at your request to keep your Kenmore appliance in proper running

condition.

For more information, call 1-800-827-6655 (U.S.A) or

1-877-533-6937 (Canada)

WARRANTY

Limited Lifetime Warranty on Stainless Steel Basket For the lifetime of the washer from the date of purchase, Sears

will replace the Stainless Steel wash basket due to defective material or workmanship. This warranty does not include any polishing marks found in the bottom of the basket which occurs during the break in period of the washer. You will be charged for labor after the first year.

Limited Ten-Year Warranty on Plastic Tub*

For the second through tenth year from the date of purchase, Sears will replace the plastic tub if defective in material or workmanship. You will be charged for labor after the first year.

Limited Five-Year Warranty on Drive System Parts* For the second through fifth year from the date of purchase,

Sears will replace the following drive system parts if defective in material or workmanship. The washplate shaft, drive pulley, lower drive bearing plate and drive belt. You will be charged for labor after the first year.

Limited Two-Year Warranty on SENSOR SMART TM Electronic Control Board

For two years from the date of purchase, Sears will replace the electronic control boards if defective in material or workmanship. You will be charged for labor after the first year.

Full One-Year Warranty on Mechanical and Electrical Parts For one year from the date of purchase, when this washer is

installed and operated according to the instructions provided in the Owner's Manual, Sears will repair or replace any of its mechanical or electrical parts if defective in material or workmanship.

Warranty Restriction

If the washer is subject to other than private family use, the above warranty coverage is effective for only 90 days.

Warranty Service Warranty service is available by contacting the nearest Sears

Service Center in the United States or Canada. This warranty applies only while the product is in use in the United States or Canada. This warranty gives you specific legal rights and you may also have other rights which vary from state to state or province to province.

*Warranty terms may vary in Canada. In the U.S. for Sears warranty information or to contact a Sears

Service Center, call 1-800-4-MY-HOME _M(1-808-469-4663). In Canada, call 1-877-533-6937.

Sears, Roebuck and Co.

D/817WA, Hoffman Estates, IL 60179

Toronto, Ontario, Canada M5B 2B8

In the space below, record your complete model number, serial number, and purchase date. You can find this information on the model and serial number label, as shown.

Have this information available to help you quickly obtain assistance or service when you contact Sears concerning your appliance.

Model number 110

Serial number

Purchase date

Sears Canada, Inc.

Save these instructions and your sales receipt for future reference.

WASHER SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word "DANGER" or

This is the safety alert symbol.

"WARNING." These words mean:

You can be killed or seriously injured if you don't

immediately follow instructions.

You can be killed or seriously injured if you don't

follow instructions.

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

IMPORTANT SAFETY INSTRUCTIONS

WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow basic

precautions, including the following:

• Read all instructions before using the washer.

• Do not wash articles that have been previously

cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, other flammable,

or explosive substances as they give off vapors that could ignite or explode.

• Do not add gasoline, dry-cleaning solvents, or other flammable, or explosive substances to the

wash water. These substances give off vapors that could ignite or explode.

• Under certain conditions, hydrogen gas may be

produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN GAS IS

EXPLOSIVE. If the hot water system has not been used for such a period, before using the

washing machine, turn on all hot water faucets and let the water flow from each for several

minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not

smoke or use an open flame during this time.

• Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is

used near children.

• Before the washer is removed from service or discarded,

remove the door or lid.

Do not reach intothe washer if the drum, tub or agitator

is moving.

Do not install or store the washer where it will be exposed to the weather.

Do not tamper with controls. Do not repair or replace any part of the washer or

attempt any servicing unless specifically recommended

in this Use and Care Guide or in published user-repair instructions that you understand and have the skills to

carry out.

• See Installation Instructions for grounding requirements.

SAVE THESEINSTRUCTIONS

INSTALLATION

REQUIREMENTS

Assemble the necessary tools and supplies before beginning the washer installation. The parts supplied are in the washer basket.

Do not put the styrofoam back into the washer.

Tools needed for connecting the drain hose and water inlet hoses

• Pliers (that open to 1%8 in. {3.95 cm})

• Flashlight (optional)

Parts supplied:

Tools needed for securing the drain hose and leveling the washer

• Open end wrench 9/16in. (1.45 cm)

• Level

• Wood block

• Ruler or measuring tape Parts supplied:

1. Beaded tie strap

2. Front leveling feet with nuts (2)

3. Rear self-adjusting feet (2)

2 3

1. Drain hose "hook"

2. Yellow, single-wire hose clamp (for the top of the drain hose)

3. Water inlet hoses (2)

4. Flat water inlet hose washers (4)

Parts listed are available from your local Sears store or Sears Service Center, In the United States, call 1-800-366-PART

(1-800-366-7278). In Canada, call 1-877-533-6937. '_4_

If You Have You Will Need to Buy

Laundry tub or Sump pump system (if not already standpipe taller available) than 96 in. (2.4 m)

Overhead sewer Standard 20 gal (76 L) 39 in. (99 cm) tall

drain tub or utility sink and sump pump

(available from local plumbing suppliers)

Floor drain Siphon break, Part Number 285834;

Drain hose too Drain hose, Part Number 8318156 and short connector kit, Part Number 285835

Lint clogged drain Drain protector, Part Number 367031

Water faucets beyond reach of

fill hoses

additional drain hose, Part Number 8318155 and connector kit,

Part Number 285835

and connector kit, Part Number 285835

2 longer water fill hoses: 6 ft (1.8 m) Part Number 76314,

19 ft (3.0 m) Part Number 350008

S, _,,o_ O, ,_ '"_ _ ,,, •

Selecting the proper location for your washer improves performance and minimizes noise and possible washer "walk."

Your washer can be installed in a basement, laundry room, closet, or recessed area. (See "Drain System.")

Proper installation is your responsibility. You will need

• A water heater set to deliver 120°F (4g°c) water to the washen

• A grounded electrical outlet located within 4 ft (1.2 m)of where the power cord is attached to the back of the washer. (See "Electrical Requirements.")

• Hot and cold water faucets located within 4 ft (1.2 m) of the hot and cold water fill valves, and water pressure of 20-100 psi (137.9-689.6 kPa).

• A level floor with a maximum slope of 1 in. (2.5 cm) under entire washer• Installing the washer on carpeting is not

recommended.

• A sturdy floor to support the washer with a total weight (water and load) of 315 Ibs (143 kgs).

Do not operate your washer in temperatures below 32 F (0 C).

o o

Some water can remain in the washer and can cause damage in low temperatures.

Recessed area or closet installation

The dimensions shown are for the minimum spacing allowed.

The washer can be installed using the standpipe drain system (floor or wall), the laundry tub drain system, or the floor drain system• Select the drain hose installation method you need. (See "Alternate Parts You May Need•")

Standpipe drain system - wall or floor (view I & 2) The standpipe drain requires a minimum diameter standpipe of 2

in. (5 cm). The minimum carry-away capacity can be no less than

17 gal (64 L) per minute.

The top of the standpipe must be at least 39 in• (99 cm) high and no higher than 96 in. (2.4 m) from the bottom of the washer.

(310_ =)

rairimum

5,_

(om) (a_) (0_) _,_ua; le4.acml tt02eml

1.Front view

2. Side view

3. Closet door with vents

• Additional spacing should be considered for ease of installation and servicing.

• Additional clearances might be required for wall, door and floor moldings.

• Additional spacing of 1 in. (2.5 cm) on all sides of the washer is recommended to reduce noise transfer.

If a closet door is installed, the minimum air openings in the top and bottom of the door are required• Louvered doors with air openings in the top and bottom are acceptable•

Laundry tub drain system (view 1) The laundry tub needs a minimum 20 gal (76 L) capacity. The top

of the laundry tub must be at least 39 in. (99 cm) above the floor and no higher than 96 in• (2.4 m) from the bottom of the washer.

Floor drain system (view 2)

The floor drain system requires a siphon break that may be purchased separately. (See Alternate Parts You May Need•")

The siphon break must be a minimun of 28 in. (71 cm) from the bottom of the washer. Additional hoses might be needed.

Electrical Shock Hazard

Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter.

Do not use an extension cord. Failure to follow these instructions can result in

death, fire, or electrical shock.

• A 120-volt, 60-Hz., AC-only, 15- or 20-ampere, fused electrical supply is required. Time-delay fuse or circuit breaker is recommended. It is recommended that a separate circuit serving only this appliance be provided.

• This washer is equipped with a power supply cord having a 3 prong ground plug.

• To minimize possible shock hazard, the cord must be plugged into a mating, 3 prong, ground-type outlet, grounded in accordance with local codes and ordinances. If a mating outlet is not available, it is the personal responsibility and obligation of the customer to have the properly grounded outlet installed by a qualified electrician.

• If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate.

• Do not ground to a gas pipe.

• Check with a qualified electrician if you are not sure the washer is properly grounded.

• Do not have a fuse in the neutral or ground circuit.

1, 3 prong grounding plug

2. 3 prong grounding-type watt receptacle

3. Grounding prong

4. Power supply cord

GROUNDING INSTRUCTIONS

For a grounded, cord-connected washer:

This washer must be grounded. In the event of a mal- function or breakdown, grounding will reduce the risk

of electrical shock by providing a path of least resist- ance for electric current. This washer is equipped with

a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an

appropriate outlet that is properly installed and ground- ed in accordance with all local codes and ordinances.

WARNING: Improper connection of the equipment-

grounding conductor can result in a risk of electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the appliance is prop- erly grounded.

Do not modify the plug provided with the appliance - if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

For a permanently connected washer:

This washer must be connected to a grounded metal,

permanent wiring system, or an equipment grounding conductor must be run with the circuit conductors and

connected to the equipment-grounding terminal or lead on the appliance.

INSTALLATION

INSTRUCTIONS

Install the rear self-adjusting feet

1. To prevent floor damage, set the washer onto cardboard.

2. Move the washer to within approximately 3 feet (90 cm) of the final location.

3. Prop up the rear of the washer about 4 in. (10.2 cm) with a wood block or similar object. The block needs to support the

weight of the washer.

4. Install the self-adjusting rear feet by pushing all the way up into the hole shown below.

5. Tilt the washer forward and remove the wood block. Gently lower the washer to the floor.

Install the front leveling feet

6. Prop up the front of the washer about 4 in. (10.2 cm) with a

wood block or similar object. The block needs to support the weight of the washer.

7. Screw the lock nut onto each foot to within 1 in. (2.5 cm) of the base.

Proper connection of the drain hose protects your floors from damage due to water leakage. Carefully read and follow these

instructions. The drain hose is connected to your washer and is stored inside

of the washer cabinet.

Remove drain hose from washer cabinet

Gently pull the corrugated drain hose out of the washer from the top of the hose. Continue to pull the hose until the end emerges.

Do not force excess drain hose back into the rear of the washer.

Laundry tub drain or standpipe drain Connecting the drain hose "hook" to the corrugated drain

hose

1. Open the yellow single-wire clamp and slide over the end of the drain hose about 4 in. (10.2 cm) (Pliers optional.)

2. Wet the outside end of the drain hose with tap water. Do not use any other lubricant.

3. Twist and push the "hook" back and forth while pushing down onto the drain hose. Continue until the "hook" is down

to the enlarged diameter of the drain hose.

4. Open the yellow single-wire clamp (placed on the drain hose earlier) and slide over the base of the drain hose "hook" to secure the sections together. (Pliers optional.)

5. Put hooked end of drain hose into laundry tub or standpipe.

Rotate "hook" to eliminate kinks.

8. Screw the feet into the correct holes at the front corner of the washer until the nuts touch the washer.

NOTE: Do not tighten the nuts until the washer is level.

9. Tilt the washer back and remove the wood block. Gently lower the washer to the floor.

To prevent drain water from going back into the washer:

• Do not straighten hooked end of the drain hose and force excess drain hose into standpipe. Hose should be secure but loose enough to provide a gap for air.

• Do not lay excess hose on the bottom of the laundry tub.

Floor drain

Do not install the drain hose "hook" on to the corrugated drain hose. You may need additional parts. (See Floor Drain under "Alternate Parts You May Need.")

I, Inserta new flatwasher (supplied)intoeach end ofthe inlet

hoses,Firmlyseatthewashers inthe couplings,

1, Coupling

2. Washer

Connect the inlet hoses to the water faucets Make sure the washer basket is empty.

2. Attach the hose with the red coupling to the hot water faucet. Screw on coupling by hand until seated on the washer.

3. Attach the hose with the blue coupling to the cold water faucet. Screw on coupling by hand until seated on the

washer.

4. Using pliers, tighten the couplings with an additional two- thirds turn.

7. Attach the hose with the red coupling to the HOT water (right) inlet valve. Screw on coupling by hand until seated on the washer. Using pliers, tighten the couplings with an additional

two-thirds turn. NOTE: Do not overtighten. Damage to the valves can result.

Check for leaks

8. Turn on the water faucets and check for leaks. A small amount of water might enter the washer. You will drain this

later. NOTE: Replace inlet hoses after 5 years of use to reduce the

risk of hose failure. Record hose installation or replacement dates for future reference.

Periodically inspect and replace hoses if bulges, kinks, cuts, wear, or leaks are found.

1. Drape the power cord over the console.

2. Move the washer to its final location and remove any cardboard used to move washen

3. Locate the tie strap (supplied).

NOTE: Do not overtighten. Damage to the valves can result. Clear the water lines

5. Run water through both faucets and inlet hoses, into a bucket or laundry tub, to get rid of par[icles in the water lines that might clog the inlet valve screens.

Connect the inlet hoses to the washer

6. Attach the hose with the blue coupling to the COLD (left) inlet valve. Screw on coupling by hand until seated on the washer. Using pliers, tighten the couplings with an additional two-

thirds turn. NOTE: Do not overtighten. Damage to the valves can result.

Beaded TieStrap

4. Wrap the drain hose to the laundry tub leg or standpipe with the tie strap. (See illustration.)

If the washer faucets and the drain standpipe are recessed, put the hooked end of the drain hose in the standpipe. Tightly wrap the tie strap around the water inlet hoses and the drain

hose.

Do not force excess drain hose back into the rear of the washer.

1. Cold water inlet valve (blue)

2. Hot water inlet valve (red)

Properly leveling your washer prevents excessive noise and vibration.

1. Check the levelness of the washer by placing a level on the top edge of the washer, first side-to-side, then front-to-back.

If the washer is against a wall, move the washer out slightly before tipping back. If the washer is not level, prop up the front of the washer with the wood block and adjust the feet up or down as necessary. Repeat this step until washer is

level.

2. After the washer is in the final location and level, use a 9/18in. (1.43 cm) open-end wrench to turn the nuts on the feet

tightly against the washer cabinet. If the nuts are not tight against the washer cabinet, the

washer may vibrate.

3. Tilt the washer forward until the rear of the washer is at least 4 in. (10.2 cm) off the floor. You may hear the self-adjusting

rear feet click into place. Lower the washer to the floor.

1. Check the electrical requirements. Be sure that you have the correct electrical supply and the recommended grounding

method. (See "Electrical Requirements.")

2. Check to be sure all parts are now installed. If there is an extra part, go back through the steps to see which step was skipped.

3. Check to be sure you have all of your tools.

4. Dispose/recycle all packaging materials. Keep the styrofoam for use if the washer should be transported.

5. Check to be sure the water faucets are on.

6. Check for leaks around faucets and inlet hoses.

Electrical Shock Hazard

Plug into a grounded 3 prong outlet. Do not remove ground prong. Do not use an adapter.

Do not use an extension cord. Failure to follow these instructions can result in

death, fire, or electrical shock.

7. Plug into a grounded 3 prong outlet.

8. Remove the protective film on the console and any tape remaining on the washer.

9. Read "Washer Use."

10. To test your washer, measure _&the normal recommended amount of powdered or liquid detergent and pour it into the detergent dispenser. Close the lid. Press HEAVY DUTY, and then press START. Allow it to complete one whole cycle.

BENEFITS

Your new washer works differently than most washers that you are accustomed to. The most striking difference is the washer

does not have an agitator. It uses the innovative CALYPSO TM Wash Motion. The Wash Plate, at the bottom of the basket,

creates a motion that lifts, rolls and bounces your wash load through a mixture of water and detergent that is continuously

reapplied to the load to force out stains and soils.

The CALYPSO TM Wash Motion

• Is easier to load (since there is no agitator.)

• Is gentler on clothes. There is less wear and tear on your clothes.

• Fluffs the load after the final spin to make unloading easier.

SENSOR SMART TM Electronic Controls SENSOR SMART electronic controls are easy to use whether you

are a beginner or an "expert."

TRIPLE SMART TM Dispensers The TRIPLE SMART dispensers make your washer truly

automatic. It is unnecessary for you to return to the washer during the cycle to add detergent, bleach, or fabric softener.

Laundry products are diluted with fresh water and added to the load at the proper time in the wash cycle.

Larger Load Size Since there is no agitator, you can wash larger, bulkier items like a

sleeping bag. You are also able to wash more clothes at one time, which means fewer loads. The KING SlZF M Capacity Plus allows for loads such as king size bedding. You can wash a pillow ora large stuffed teddy bear.

ULTRA QUIET PAK TM

The ULTRA QUIET PAK reduces water sounds and ringing noises. The cabinet and base are insulated with sound-

dampening materials. An additional tub wrap is added for superior vibration and sound-dampening.

Suspension System To reduce washer "walk" and "out of balance" conditions, your

new washer combines:

• 4 Spring damper struts to isolate vibration

• 2 Shock absorbers at the washer base to minimize movement

• Balance ring at the top of the wash basket to minimize vibration

Stainless Steel Basket The Stainless Steel basket eliminates corrosion and enables

higher spin speeds for more water extraction, reducing drying time.

High-Efficiency Wash System Your new top loading, high-efficiency washer saves time with

fewer, larger loads, conserves resources and lowers your water and energy bills too.

Force Filter Wash/Rinse System This washer filters 100% of the wash and rinse water. The water is filtered then re-circulated. The force filter traps sand and dirt,

flushing it down the drain, so it is not re-deposited on the clean clothes.

Auto Water Level

This washer senses load size and composition, then automatically adjusts water level for best cleaning and rinsing performance. It eliminates the guess work. The water level is just right for every wash load size.

WASHER USE

Fire Hazard

Never place items in the washer that are dampened with gasoline or other flammable

fluids.

No washer can completely remove oil. Do not dry anything that has ever had any type of

oil on it (including cooking oils). Doing so can result in death, explosion, or fire.

The following is a guide to starting your washer. Periodic references to other sections of this manual provide more detailed

information.

1. Place a load of sorted clothes into the washer. Load to a level shown below. (See "Loading.")

2. Pour measured powdered or liquid detergent into the detergent dispenser.

For best performance use with High Efficiency detergents. The package for this type of detergent will be marked "HE" or High Efficiency." The new wash action of CALYPSO TM along with less water, could create too much sudsing with a regular detergent. HE detergents like TIDE" HE are made to produce the right amount of suds for the best performance. Follow the manufacturer's instructions

to determine the amount of detergent to use.

If High Efficiency detergent is not available, use a reduced amount of regular laundry detergent.

NOTE: You can add color-safe bleach (liquid or powdered) to

this dispenser as well.

Pour measured liquid chlorine bleach into the liquid chlorine

bleach dispenser, if needed. Bleach is diluted and automatically dispensed at the proper time during the wash cycle.

• Do not overfill. Never use more than 1 cup (250 mL) for a

full load. Use less with a smaller load size.

• Follow the manufacturer's directions for safe use.

• To avoid spilling, use a cup with a pouring spout. Do not

let bleach splash, drip, or run down into the washer basket.

NOTE: Use only liquid chlorine bleach in this dispenser.

4. Pour measured liquid fabric softener into the fabric softener

dispenser, if desired.

• Do not overfill. The dispenser holds 3 oz (94 mL). or a capful of fabric softener.

• The fabric softener is dispensed in the final rinse.

• Do not spill or drip any fabric softener on the clothes.

NOTE: Use only liquid fabric softener in this dispenser.

5. Close the washer lid.

6. Select a Cycle. This turns on the washer display. (See "Cycles.")

7. Select an Option. if desired. (See "Options.")

8. Select the desired Modifiers. (See "Modifiers.")

9. Press START. The wash cycle begins and the display shows the estimated remaining time.

NOTE: If you do not press Start within 5 minutes of selecting the cycle, the washer automatically shuts off.

Use these pads to choose the right wash cycle for the type of fabrics you are washing.

S_LEC3"CYCLE

• For most loads, use the time recommended in the preset cycle settings.

• For heavy soil and sturdy fabrics, use more wash time.

• For light soil and delicate fabrics, use less wash time.

Heavy Duty

Use this cycle to get 15 to 19 minutes of wash time for loads of sturdy, colorfast fabrics such as work clothes. Cycle combines high speed wash action and high spin speed. The preset cycle

wash time is 19 minutes.

To pause the washer at any lime Press STOP/CANCEL.

To restart the washer Close the lid and press START.

You can change Cycles, Options and Modifiers any time before Start is pressed.

• A short tone sounds when a change is selected.

• Two short tones sound if an unavailable combination is selected. The last selection will not be accepted.

Changing Cycles after pressing Start

1. Press STOP/CANCEL twice.

2. Select the desired wash cycle.

3. Press START.

The washer restarts at the beginning of the new cycle. NOTE: If you do not press Start within 5 minutes of pausing the

washer, the washer automatically shuts off.

Changing Options and Modifiers after pressing Start You can change an Option or Modifier anytime before the

selected Option or Modifier begins.

1. Press STOP/CANCEL.

2. Select the new Option and/or Modifiers.

3. Press START to continue the cycle.

Normal

Use this cycle to get 12 to 16 minutes of wash time for normally soiled cottons and linens. Cycle combines medium speed wash action and high spin speed. The preset cycle wash time is 14

minutes.

Jeans/Colors

Use this cycle to get 14 to 18 minutes of wash time for dark. colored items that may run or fade. Cycle combines low/medium speed wash action and high speed final spin. The preset cycle

wash time is 16 minutes.

Whitest Whites

This cycle introduces liquid chlorine bleach to the load at the proper time for improved whitening of your heavily soiled white fabrics. Use this cycle to get 13 to 17 minutes of medium speed wash action and high speed final spin. For maximum soil and stain removal, liquid chlorine bleach must be used. The preset cycle wash time is 15 minutes.

Delicate/Casual

Use this cycle to get 12 to 16 minutes of low speed wash action for no-iron fabrics and garments indicating "Gentle" cycle on the care label. Low/medium spin speed is used to reduce wrinkling. The preset cycle wash time is 14 minutes.

Bulky Items

Use this cycle to get 13 to 17 minutes of wash time for large items like blankets and comforters. Cleaning starts with a spray of water and detergent mixture to thoroughly saturate your large load. This is followed by low/medium wash action and low/ medium spin speed to maintain load balance. The preset cycle

wash time is 15 minutes.

Ultra Handwash

Use this cycle to get 7 to 11 minutes of wash time for garments labeled "Hand Wash" and special care items• Gentle cleaning starts with a continuous spray of water and detergent mixture as the load is spun at extra-low speed• This lasts for about one minute and is followed by a brief period of extra-low wash action. Low/medium spin speed helps reduce wrinkling. The preset cycle

wash time is 7 minutes.

Garments are labeled "Hand Wash" because:

• Thefiber construction may be sensitiveto wash action.

• The fabric contains sensitive dyes that may bleed. NOTE: Some "Hand Wash" items, particularly wool, naturally

shrink when washed. Keep this in mind when you purchase items labeled "Hand Wash." Items that shrink should be dried flat.

When still wet, block these items by gently stretching to original measurements.

Express Wash

Use this cycle to get 7 to 11 minutes of wash time for small, lightly soiled loads that are needed in a hurry. Fast cleaning starts with a continuous spray of water and detergent mixture as the load is spun at extra-low speed, followed by a brief period of low/ medium speed wash action• High spin speed reduces drying time. For the fastest results, select warm wash. The preset cycle wash

time is 7 minutes•

Wool/Silk

Use this cycle to get 6 to 10 minutes of wash time for washable items that are normally dry cleaned• Cycle combines extra-low speed spray cleaning and wash action to provide gentle care for delicate items, such as wool sweaters and silk blouses• Low spin speed helps garments maintain their shape. The preset cycle

wash time is 6 minutes.

Custom Program Custom Program allows you to store acustomized wash cycle for

future use. Fills TO Custom Program a wash cycle:

1. Select a cycle.

2. Select the desired Options.

3. Select t he desired Modifiers.

4. Press and hold CUSTOM PROGRAM (approximately 3 seconds) until a beep sounds•

5. Press START. The Custom Program cycle is now stored for Washes future use• To reuse the cycle, select CUSTOM PROGRAM and press START.

Preset Cycle Settings

For ease of use, preset cycle settings provide the recommended fabric care settings for each cycle•

To use the preset cycle settings:

1. Select the cycle you want by pressing one of the pads under SELECT CYCLE. The preset cycle settings will be displayed (see chart below).

2. Press START. The wash cycle will begin.

PRESET CYCLE SETTING

HEAVY DUTY 19 Maximum Warm/Cold

JEANS/COLOR 16 Normal Warm/Cold

DELICATE/CASUAL 14 Normal Warm/Cold

ULTRA HANDWASH 7 Minimum Cold/Cold

EXPRESS WASH 7 Minimum Warm/Cold

WHITEST WHITES 15 Normal Hot/Cold

BULKY ITEMS 15 Normal Warm/Cold

*Wash Time in minutes will appear in the display while making selections. The total cycle time will appear, including an estimated time for drain and fill times, once Start is pressed.

After you have loaded the washer, selected the cycle, options and modifiers and you have pressed START, you washer does the following:

Distributes the load

• Load is initially fluffed to distribute the load before water is added.

• Water enters through the dispenser to mix with the detergent. Water continues to be added until the load is soaked and just enough water is present to maintain the spray• This way of washing and rinsing uses less water and makes the detergent

more effective in cleaning your clothes. As a result, you will

only see a wet load and not a full tub of water, if you open the

lid.

• As the washer continues to fill, a low speed spin begins and the detergent/water mixture is sprayed on to the load.

The spinning stops and the CALYPSO TM Wash Motion

begins, while the wash water continues to be sprayed on to

the moving load. The length of wash depends on the cycle and wash time selected.

The CALYPSO Wash Motion features five wash speeds in combination with low-speed spin sprays for a variety of fabric

care needs.

Liquid chlorine bleach is dispensed in the last 2-3 minutes of

the wash cycle to help ensure the best cleaning results. The wash water is then drained and spun out before rinsing

begins.

Cycle Preset Wash Wash/Rinse

Minutes Time* Temperature

NORMAL 14 Normal Warm/Cold

(No ATC)

WOOL/SILK 6 Minimum Cold/Cold

Rinses

• Rinsing is accomplished in the same manner as washing. Fresh water is added to a slow spinning load. Then the load moves through the spray rinses. The water is then drained away and the rinsing process is repeated. The number of rinses varies depending on the cycle.

• During the last rinse, fabric softener is dispensed into the bottom of the tub and then sprayed through the load.

Final Spin

• The last of the rinse water is drained and the load is spun. The amount of spinning depends on the cycle selected.

To make unloading easy the load is peeled off the sides of the basket by the CALYPSO TM Wash Motion.

Normal Washer Sounds

As with any new product, you will hear sounds that you are not accustomed to. You may hear various sounds occurring during the washing, rinsing and spinning process. Between changes in wash actions, there will be momentary pauses. You will hear water spraying and splashing during the wash and rinse cycles. These new sounds and pauses are part of normal washer operation. (See "Troubleshooting.")

Use this feature to select the desired prewash and rinse options for your wash cycle.

Prewash Options

Select a prewash option to ensure thorough cleaning of your heavily soiled and stained loads.

0SATURATED SOAK O_rAIN TREAT

PREWASH

OP_ONS

Saturated Soak

Use this option for set-in stains and soil that need extra time for removal. Soaking in this washer is different than in a conventional washer. The washer sprays the load with water and detergent for

4 minutes at extra low spin speed followed by a brief period of wash action at the speed of the selected cycle. Then another 4

minutes of spraying and extra low spinning occurs. The wash action then pauses for the detergent to work on the soils. The

SATURATED SOAK feature is followed by the selected cycle. Using SATURATED SOAK will extend your wash cycle by 16

minutes.

Stain Treat

Selecting this option boosts cleaning in any cycle. This option allows you to use more detergent than you would normally use in

a single cycle. For best results, use 2 times the amount of recommended detergent for a load. Using STAIN TREAT will

extend your wash cycle by 14 minutes.

Rinse/Spin Options

Selecting this option allows you to choose a 2nd Rinse and Extended Spin option. You may also select and run EXTENDED SPIN and RINSE/SPIN without first selecting a cycle. RINSE/ SPIN is not available if a cycle has been selected.

O2ND RINSE eE_HDIED SPl_

•D_NSE/ SPIN

Press RINSE/SPIN OPTIONS until the indicator light next to the desired setting glows.

2nd Rinse

Selecting this option provides a second rinse with the same water temperature as selected for the first rinse. A 2nd Rinse can be added to any wash cycle.

Extended Spin

This option adds an additional 3 minutes of spin to any cycle to reduce drying time and save energy. If you select EXTENDED SPIN and do not select a wash cycle, you will get an 8 minute, high speed spin.

Rinse/Spin

Use this option to get a combination of rinses and spins followed by a high-speed spin. The time display will include an estimate of how long it will take to fill and drain the washer. Fabric softener can be added to the Fabric Softener dispenser.

When to use Rinse/Spin:

• For loads that need rinsing only.

• For completing a cycle after the power has been off.

• To add fabric softener to load. To use or change Rinse/Spin settings:

1. Add fabric soffener to the dispenser (if desired),

2. Press the RINSE/SPIN OPTIONS control until the RINSE/ SPIN indicator light glows.

3. Press START.

next to MINIMUM illuminates. This is the shortest wash time available for that cycle.

Modifiers allow you to further customize your cycles and save energy.

Wash/Rinse Temp

Select a water temperature based on the type of load you are

l MA_MUM o o _RMAL o O MiNImUM

washing. Use the warmest water safe for fabrics. Follow garment label instructions.

Warm rinses leave the loads dryer than cold rinses. Warm rinses increase wrinkling. In cold climates, a warm rinse makes the load

more comfortable to handle. Cold rinses save energy. When a wash cycle is started, the estimated time remaining for

the cycle, including fills and drains, will be displayed. The time

Temperature Guide will count down to the end of the cycle. The ESTIMATED TIME

Wash Water Temperature Suggested Fabrics REMAINING light will glow.

HOT Whites and pastels

111°F (44°0) or above Heavy and greasy soils

WARM Bright colors

90°-110°F (32°-43°0) Moderate to light soils

COLD Colors that bleed or fade

7O°-9O°F (21°-32°0) Light soils

In wash water temperatures colder than 70°F (21°C), detergents do not dissolve well. Soils may be difficult to remove.

Auto Temp Control ATC (Auto Temp Control) electronically senses and maintains a uniform water temperature. ATC regulates incoming hot and cold

water. The ATC is automatically turned On when a cycle is selected. (See "Preset Cycle Settings" in "Cycles,")

ATC is available with WARM/WARM, WARM/COLD and COLD/ COLD settings, The AUTO TEMP CONTROL light will glow indicating that ATC is working.

o _TO TEMP

CONTROL

o HOT/COLD o WARM / WAF_ o WARM / COLD o COLD / COLD

o T_ COLD/OOLD

O ESTIMATED_ME

P_MAINING

Set Delay Time

You can use the SET DELAY TIME feature to delay the start of a wash cycle for up to 11 hours (depending on you model).

1. Load the washer and fill the dispensers.

2. Close the washer lid.

3. Select the desired Cycle, Options and Modifiers.

4. Press SET DELAY TIME. 1H (one hour) will be displayed in the time display window. The indicator light for DELAY TIME will glow.

OIl-LAY _ME

• ATC ensures consistent cleaning.

• When using ATC, warm water is added to the washer to maintain a termperature of approximately 75°F (24°C), so

detergents dissolve properly.

• Warm washes are regulated at approximately 1O0°F (38°C).

• Warm rinses are regulated at approximately 75°F (24°C). This is a cooler warm rinse than you are used to, but it saves

energy and gives proper rinsing. The load is a comfortable temperature to remove from the washer

Wash Time Wash Time is preset for each wash cycle. (See "Preset Cycle

Settings" in "Cycles.") As you press WASH TIME pad, the cycle time (minutes) will increase or decrease in the ESTIMATED TIME REMAINING display and a different WASH TIME light will glow. To get the minimum wash time, press the pad until the indicator light

For a longer delay time, press SET DELAY TIME. The time will increase by one-hour steps.

Press START. The countdown to the wash cycle will show in

the time display window. To change the Delay Time:

• Press STOP/CANCEL.

• Reset the SET DELAY TIME.

• Press START to begin the countdown. To cancel Delay Start:

Press START again to begin the cycle right away or press

STOP/CANCEL twice.

Adjustable End Of Cycle Signal

A tone will sound at the end of the cycle. The sound level of this tone can be adjusted by pressing END OF CYCLE SIGNAL. The volume of tone you will hear at the end of the cycle will sound as the pads are pressed.

IH_N gLOW OOFF

Indicator Lights Select Cycle

Located next to each pad, these lights show the cycle you have selected.

Options

These lights show the Prewash and/or Rinse/Spin Options you have selected.

Modifiers

These lights show the selected Wash/Rinse Temperature, Wash Time, Estimated Time Remaining in cycle, and End of Cycle

Signal.

Washer Status

These lights show what portion of the cycle the washer is operating.

WASHER STATUS

OWASHHNG O RINSING

OAUTo FLUFF O CLOTHESCLFAN

LAUNDRY TIPS

Preparing clothes for washing

Follow these recommendations to help you prolong the life of your garments.

• Close zippers, snaps, and hooks to avoid snagging other items. Remove pins, buckles, and other hard objects to avoid scratching the washer interior. Remove non-washable trim

and ornaments.

• Empty pockets and turn them inside out.

• Turn down cuffs, brush away lint and dirt.

• Turn synthetic knits inside out to avoid pilling.

• Tie strings and sashes so they will not tangle.

• Mend tears, loose hems, and seams.

• Treat spots and stains.

• Stained or wet garments should be washed promptly for best results.

Sorting

• Separate heavily soiled items from lightly soiled ones, even if they would normally be washed togethen Separate lint givers (towels, chenille) from lint takers (corduroy, synthetics, permanent press). When possible, turn lint givers inside out.

• Separate dark colors from light colors, color_ast items from non-colorfast items.

• Sort by fabric and construction (sturdy cottons, knits, delicate items).

Operating Controls Start

Press START to start your washer after a cycle has been selected. Be sure all desired Options and Modifiers have been

selected. The lid must be closed for the washer to start.

Stop/Cancel

Press STOP/CANCEL once to pause or stop the washer at any time. Press START to complete the cycle from where it was

stopped. Press STOP/CANCEL twice to turn off the washer.

Loading suggestions (maximum size loads).

KING SIZE TM Capacity Plus Washer

Heavy Work Clothes

4 jeans 2 sweatpants 4 workpants 2 sweatshirts 4 workshirts

Towels

10 bath towels 14wash cloths 10 hand towels

Mixed Load

3 sheets (1 king, 2 twin) 9 T-shirts 4 pillowcases lg handkerchiefs

3 shirts

9 shorts

3 blouses

WASHER CARE

Cleaning the exterior Use a soft, damp cloth or sponge to wipe up any spills such as

detergent or bleach. Occasionaly wipe the outside of your washer to keep it looking new.

Cleaning the interior

Clean your washer interior by mixing 1 cup (250 mL) of chlorine bleach and 2 scoops or caps full of detergent. Pour this into your

washer and run it through a complete cycle using hot water. Repeat this process if necessary.

NOTE: Remove any hard water deposits using only cleaners labeled as washer safe.

Replace inlet hoses after five years of use to reduce the risk of hose failure. Periodically inspect and replace inlet hoses if bulges, kinks, cuts, wear or leaks are found.

When replacing your inlet hoses, mark the date of replacement on the label with a permanent marker.

Install and store your washer where it will not freeze. Because some water may stay in the hoses, freezing can damage your washer. If storing or moving your washer during freezing weather,

winterize it.

Non-use or vacation care:

Operate your washer only when you are at home. If you will be on vacation or not using your washer for an extended period of time, you should:

• Unplug washer or disconnect power.

• Turn off the water supply to the washer. This helps avoid accidental flooding (due to a water pressure surge) while you are away.

To winterize washer.

1. Shut off both water faucets.

2. Disconnect and drain water inlet hoses.

3. Put 1 quart (1 L) of R.V.-type antifreeze in the basket.

4. Run washer on an EXTENDED SPIN cycle.

5. Unplug washer or disconnect power.

TO use washer again:

1. Flush water pipes and hoses.

2. Reconnect water inlet hoses.

3. Turn on both water faucets.

4. Plug in washer or reconnect power.

5. Run the washer through the Normal cycle with 1 scoop or cap full of detergent to clean out antifreeze.

To transport the washer:

1. Shut off both water faucets.

2. Disconnect and drain water inlet hoses.

3. If washer will be moved during freezing weather, put in a quart (1 L) of R.V.-type antifreeze in the basket. Run washer on an EXTENDED SPIN cycle.

4. Disconnect the drain from the drain system.

5. Unplug the power cord.

6. Place the inlet hoses into the basket.

7. Drape the power cord and drain hose over edge and into the

basket.

8. Place the styrofoam plug retained from the washers shipping

material into basket opening. Close the lid and put a piece of

tape over the lid and down to the front of the washer.

Re-installing the washer

1. Follow the "Installation Instructions" to locate, level and connect the washer.

2. Run the washer through the Normal cycle with 1 scoop or cap full of detergent to clean the washer and remove the

antifreeze, if used.

TROUBLESHOOTING

First try the solutions suggested here and possibly avoid the cost of a service call...

Washer displaying code messages.

If any of these codes continue to occur, call for service.

• "PF" (Power Failure) flashes

Was the washing cycle interrupted by a power failure? Press START to continue the cycle from the moment that power was lost, - OR - Press STOP/CANCEL to clear the display and completely cancel the cycle.

• "FU' (Over Fill) flashes The washer will beep every 10 seconds with no time-out. The pump will cycle one half minute on, one half minute off, until the over fill switch is reset or power is discontinued to the unit. Press STOP/CANCEL to clear the display. Shut off the

water faucets to the inlet hoses if water continues to flow.

• "Er" (Processor Reset Error) Cycle information was not stored during a power failure. Press STOP/CANCEL to clear the display.

• "LF" (Long Fill) flashes Are the water inlet hoses kinked or clogged?

Are the water inlet valve screens clear? Press STOP/CANCEL to clear the display.

• "CE" (Communications Error) flashes - beeps once Press STOP/CANCEL to clear the display.

• "Ld" (Long Drain) flashes Is the drain hose kinked or clogged? Press STOP/CANCEL to clear the display,

• "CA" or "Cl" (Current Limit) Is the washer overloaded?

Press STOP/CANCEL to clear the display.

• "Or" (Open Relay) Washer operation failure. Call for service.

• "Sr" (Stuck Relay) Washer operation failure. Call for service.

• "LS" (Lid Switch Error) flashes Is the washer lid open? Close the lid and press START to continue the cycle.

Is the lid closed? Open and close the lid. Press STOP/ CANCEL to clear the display.

• "SL" (Suds Lock) Press STOP/CANCEL to clear the display. Drain/Spin load:

restart cycle. Do not add detergent. Use cold water.

• "dt" (Diagnostic Tests) For service diagnostics only. Press STOP/CANCEL to clear the display.

• "ob" (Off Balance) Is the load unbalanced? Redistribute the load. Close lid and

press START.

Washer won't fill, rinse or wash

• Does the water level seem too low, or does the washer

appear to not fill completely?

This washer uses very little water and never fills completely. Water will not be seen over the top of the wash plate.

• Checkthe following: Is the power cord plugged into a grounded 3 prong outlet?

Is there power at the plug? Check electrical source or call electrician.

Are the hot and cold water faucets turned on? Is the water inlet hose kinked?

Are the water inlet valve screens clogged?

Washer stops

• Checkthe following: Is the power cord plugged into a grounded 3 prong outlet?

Is there oversudsing? Cancel the current cycle. Press RINSE/ SPIN to drain the load. Re-select your desired cycle and press START. Do not add detergent, Use cold water.

Are the hot and cold water faucets turned on? Is the water inlet hose kinked?

Are the water inlet valve screens clogged? After opening the lid, did you press START?

If the lid is opened during washer operation, the washer will stop. Closing the lid will not restart the washer. You must press START.

Is there power at the plug? Check electrical source or call electrician.

Has a fuse blown or has the circuit breaker tripped? If problem continues, call electrician.

Are you using an extension cord?

Do not use an extension cord.

• Isthe washer overloaded? Wash smaller loads. See "Starting Your Washer" for

maximum load size.

Did you add more items to the load once the washer started?

Once the load is wet, there may appear to be space for more items. For best results determine load size with dry items only.

Washer won't drain or spin

Is the drain hose clogged, or the end of the drain hose more than 96 inches (2.4 m) above the floor?

See "Installation Instructions" for proper installation of drain hose.

Is the lid open? The lid must be closed during operation.

Is there excessive sudsing? For best results, use High Efficiency detergents like TIDE HE, which produce less suds. Follow manufacturer's directions.

Is your voltage low? Check electrical source or call electrician. Do not use an

extension cord.

Washer continues to fill or drain, or the cycle seems stuck Dispensers clogged or leaking

Does the drain hose fit too tightly in the standpipe, or is it taped to the standpipe?

The drain hose should be loose yet fit securely. Do not seal the drain hose with tape. The hose needs an air gap. (See "Installation Instructions.")

Washer makes noise

• Is the load balanced and the washer level? The wash load should be balanced. See "Starting Your

Washer" for maximum load size. The washer must be level. The front feet should be properly

installed and the nuts tightened. Reset the rear leveling legs if needed. (See "Installation Instructions.")

Are the self-adjusting rear feet installed? Can you hear water spraying? This is part of the wash action. If water is drained quickly from the washer, you may hear air

being pulled through the pump. This happens during the end of draining. It is normal.

When the cycle changes from washing to draining or • spinning, you may hear a noise as the drive system shifts.

This is normal.

• Are you washing items with metal snaps, buckles or

zippers?

You may hear metal items touching the basket. This is normal.

• Are you washing a small load? You will hear more splashing sounds when washing small

loads. This is normal.

• Is the washer installed on a solid floor? Refer to the "Installation Instructions" for flooring

requirements.

Washer leaks •

• Checkthe following: Are the fill hoses tight? Are the fill hose washers properly

seated? Is the drain hose clamp properly installed? (See "installation Instructions.")

Is the sink or drain clogged?

Sink, floor drain and standpipe must be able to handle 17 gallons (64.1 L) of water per minute.

Is water bouncing off the tub ring or the load? The wash load should be balanced and not overloaded. If

not, the fill or spray rinses can bounce off the load. The washer must be level. The front and rear feet should be

properly installed and the nuts tightened. Reset the self- adjusting rear feet if needed. (See "Installation Instructions.")

Did you pull the drain hose from the washer cabinet and install it in a standpipe or laundry tub?

(See "installation Instructions".)

• Check household plumbing for leaks.

Washer basket is crooked

• Is the load balanced and the washer level? The wash load should be balanced.

The washer must be level. The front feet should be properly installed and the nuts tightened. Reset the rear leveling legs,

if needed. (See "Installation Instructions.")

Is the laundry products in the correct dispenser? Add the correct amounts of detergent, fabric softener or chlorine bleach to the correct dispenser. Add powdered or

liquid color-safe bleach to the detergent dispenser. Do not

use the chlorine bleach dispenser for color-safe bleach.

Load too wet

• Did you use the right cycle for the load being washed? Select a cycle with a higher spin speed.

• Did you use a cold rinse? Cold rinses leave loads wetter than warm rinses. This is normal.

• Did you use regular laundry detergent?

Regular detergent can cause too much suds and leave the load wet. Use High Efficiency detergents like TIDE" HE.

Residue or lint on load

• Did you add detergent to the dispenser?

For best results, use the dispenser to dissolve the detergent.

Did you sort properly?

Sort lint givers (towels, chenille) from lint takers (corduroy, synthetics). Also sort by color.

Did you overload the washer?

The wash load must be balanced. See "Starting Your Washer" for maximum load size. Lint can be trapped in the

load if overloaded. Wash smaller loads. Check the following:

Was paper or tissue left in pockets?

Bid you use enough detergent? Follow manufacturer's directions. Use enough detergent to

hold the lint in the water.

Is your water colder than 7O°F (21°0)?

Wash water colder than 70°F (21°C) may not completely dissolve the detergent.

Are you using a gentle wash cycle?

Consider using liquid detergent for slow speed cycles like

Bulky, Hand Wash, Wool/Silk.

Stains on load

• Bid you add detergent to the dispenser?

For best results, use the dispenser to dissolve the detergent. Did you use enough detergent?

Use enough detergent to remove soil and hold it in suspension. For best performance, use High Efficiency detergents like

TIDE "_HE, at the manufacturer's recommended amounts.

Did you add fabric softener directly to the load? Use your fabric softener dispenser, if available. Do not drip

fabric softener on clothes.

Is there above average iron (rust) in water?

You may need to install an iron filter.

Did you properly sort the load?

Sort dark clothes from whites and lights.

Bid you unload the washer promptly?

To avoid dye transfer, unload the washer as soon as it stops.

Did you use a fabric softener dispensing ball? Use the fabric dispenser provided with the washer.

Dispensing balls will not operate correctly with this washer.

• Did you use powder detergent in a low speed cycle? Consider using liquid detergent.

• Did you add detergent, chlorine bleach or fabric softener

too late in the cycle?

Detergent and chlorine bleach should be added before starting the washer. Fabric softener should be added before the rinse status light is lit.

• Did you use EXPRESS WASH on a large load? EXPRESS WASH is designed to wash only a few items for

best results.

Load is wrinkled

• Did you unload the washer promptly? Unload the washer as soon as it stops.

• Did you use the right cycle for the load being washed? Use the Delicate/Casual cycle or another cycle with a low spin speed to reduce wrinkling.

• Did you overload the washer?. The wash load must be balanced and not overloaded. Loads

should move freely during washing.

• Are the hot and cold water hoses reversed? Check to be sure the hot and cold water hoses are connected

to the right faucets. (See "Installation Instructions.")

Load is tangled or twisted

• Did you overload the washer?. See "Starting Your Washer" for maximum load size. Loads should move freely during washing.

Garment damage

• Checkthe following: Were sharp items removed from pockets before washing?

Empty pockets, zip zippers, snap or hook fasteners before washing.

Were strings and sashes tied to prevent tangling? Were items damaged before washing? Mend rips and broken

threads in seams before washing. Did you overload the washer?

See "Starting Your Washer" for maximum load size.

Did you properly add chlorine bleach?

Do not pour chlorine bleach directly on load. Use your liquid chlorine bleach dispenser. Wipe up bleach spills. Undiluted bleach will damage fabrics. Do not place load items on top of the bleach dispenser when loading and unloading the washer.

• Did you follow the manufacturer's care label instructions?

Cycle too long

• Are you using a High Efficiency Detergent? If using a regular sudsing detergent, the washer may be using

extra rinses to remove the suds, which will cause the cycle to run longer. Use a High Efficiency detergent like TIDE' HE, which produces less suds, or reduce the amount of regular detergent.

Gray whites, dingy colors

• Did you properly sort the load? Dye transfer can occur when mixing whites and colors in a

load. Sort dark clothes from whites and lights.

• Was the wash temperature too low? Use hot or warm washes if safe for the load. Hot water should

be at least 111°F (44°C) to clean heavy or greasy soils.

• Did you use enough detergent, or do you have hard

water?

Use more detergent for washing heavy soils in cold or hard water. Water temperature should be at least 70°F (21°C) for

soap to dissolve and work properly.

• Are the hot and cold water inlet hoses reversed?

_J_,_J,_,_,_,,,___,_,_,_,,,,,,,_Washtemperature is not what I picked _' '_

As washing progresses, the wash temperature will decrease slightly for hot and warm washes. This is normal.

LID INSTRUCTIONS

These instructions are found under the lid of your washer.

Ill

HEAVYDUTY E_CIRADIR'IY

NORMAL C01TQNS

__ BLENDS

DELICA'I_/ CASUAL DYNTHE'nCS/ DEUCATE/CASUAL I_IITS

BULKY ITEMS For thoroughly washing large, bulky

items.

Cleans big items such as comforters,

pillows and rugs.

ULTRA HANDWASH For garments indicating "hand wash"

on the care label.

Gently cleans fine washables like

lingerie and sweaters.

EXPRESS WASH For quickly cleaning afew lightly

soiled items.

Cleans and refreshes your favorite

item of clothing in a hurry.

_ ULTRAHANDWASH LINGERIE _'

HOTWASH

WARMWASH

• COLDWASH

/_ ANYBLEACH

/_ BLEACH

FOR BEST WASH PERFORMANCE USE A HIGH EFFICIENCY / LOW SUDSING DETERGENT.

1. SELECT CYCLE Select the cycle according to the

fabric type being washed.

Press START, if OPTIONS and MODIFIERS are the desired settings.

HEAVY DUTY For sturdy fabrics and heavy soil.

Deep cleans ground-in dirt on work clothes and play wear

JEANS/COLORS For dark colored cotton items that

may run or fade.

Reduces fading of dark colored items like denim jeans and casual cottons.

(To minimize fading, turn garment

inside out before laundering.)

NON-CHLORINE

DONOTBLEACH

WOOL/SILK For many washable items normally

dry cleaned.

Gently cleans items such as wool

sweaters and silk blouses.

CUSTOM PROGRAM For creating your own special cycle.

Remembers your personal preferences for future use.

2. OPTIONS

PREWASH SATURATED Loosens soils when

SOAK added to any cycle.

STAIN TREAT Removes toughest

soils/stains (with 2 measures of

detergent).

RINSE/SPIN 2ND RINSE Adds an additional

rinse to any cycle.

EXTENDED Extracts more water SPIN from heavy items.

RINSE/SPIN Rinses the load

without a cycle selected.

3. MODIFIERS

WASH/RINSE TEMP Provides best care and cleaning on

AUTO TEMP selections.

NORMAL For mixed loads and average soil.

Cleans a variety of items including

linens and everyday wea_

WHITEST WHITES For extra whitening and brightening

(with 1 cup of liquid chlorine bleach).

Deep cleans white items such as underwear, sheets and socks.

DELICATE/CASUAL For fabric blends and all garments

indicating "gentle" cycle on the care label.

Keeps colored items like golf shirts. cottons sweaters and wrinkle-

resistant clothes looking new and uses a slower spin to prevent

wrinkles from setting.

WASH TIME Fine tunes wash time for selected

cycle.

SET DELAY TIME Starts the wash when it is convenient.

It's best to wash stains Use liquid

as soon as possible, chlorine

• _ Ring around

the Collar

bleach dispenser

Uss ho_sst wash •

_mperotu_

ss_ _r _bric.

WARMorHOT

Mechanical Oil

Dirty

_- Mud

Tomato Products t_

Ketchup,

_W_ Perspiration,

Do nottumble drysoiledor stained itermLHeat maypermanentlyset stains.

• Foradditional informationregardingstainsrefer to ownersmanual. •

Deodorants

Grass t/

Blood J

Ball Point Pen,

._. Ink

_ ) Chocolate,

Coffee

Cosmetics

WARMorHOT

COLD_ WARM

WARMorHOT

+ 53 hidden pages
