Kenmore ELITE 86003, ELITE 86009, ELITE 721.86003, ELITE 721.86009 Use And Care Manual
Use & Care Guide
Manual de Uso y Cuidado
English / Espafiol
Models/Modelos: 721.86002, 86003, 86009
Kenmore Elite
P/No.: MFL57601503
Sears Brands Management Corporation
Ftoffman Estates, IL 60179 U.S.A.
www.kenmore.com
www.sears.com
Wa rra nty .................................................................... 2
Protection Agreements .............................................. 3
Safety ........................................................................ 4
Overview .................................................................... 7
How Your Microwave Hood Combination Works ......7
Radio Interference ............................................................ 7
Testing Your Microwave Oven ....................................... 7
Testing Your Dinnerware or Cookware ........................ 8
Operating Safety Precautions ....................................... 8
Electrical Connection ........................................................ 8
Microwave Oven Features .............................................. 9
Glass Tray Components .................................................... 9
Installation Instructions for Glass Tray ........................ 10
Using an Oblong Dish .................................................... 10
Oven Control Panel ...................................................... 11
How to Use ............................................................... 12
Dial Control ..................................................................... 12
Function Selections ......................................................... 12
Clock ............................................................................... 12
Timer ............................................................................... 12
Vent ................................................................................... 13
Light ................................................................................... 13
Add 30 Seconds .............................................................. 13
Manual Cook .................................................................... 14
Two-Stage Cooking ....................................................... 14
Cooking Guide for Power Levels ................................ 15
Options ............................................................................ 16
Soften/Melt ................................................................... 18
Control Lock .................................................................... 18
Back ........................................................................... 18, 20
Favorites .......................................................................... 19
Using Sensor Cooking ................................................... 20
Popcorn ............................................................................ 20
Cook ................................................................................. 20
Reheat .............................................................................. 20
Warm & Hold ................................................................ 21
Auto Defrost .................................................................... 22
Weight Conversion Chart ............................................. 22
1 Lb Defrost .................................................................... 22
Defrosting Tips ............................................................... 22
Defrost Table .................................................................. 23
Care and Cleaning ................................................... 25
Replacing the Cooktop and Oven Lights .................. 26
Caring for the Filters ..................................................... 27
Cooking Tips ............................................................ 28
Questions and Answers .......................................... 30
Troubleshooting ........................................................ 31
Service ....................................................... Back Cover
One Year Limited Warranty
When installed, operated and maintained
according to all instructions supplied with the product,
if this appliance fails due to a defect in material or
workmanship within one year from the date of purchase,
call 1-800-4-MY-HOME _ to arrange for free repair.
Five-Year Limited Warranty on the Magnetron
For five years from the date of purchase, if the
magnetron in this microwave oven fails due to a defect
in material or workmanship, Sears will replace the
magnetron. Safety regulations require the magnetron to
be installed by Sears. After the first year, the customer
assumes any labor costs associated with magnetron
replacement.
If this appliance is used for other than private family
purposes, this warranty applies for only 90 days from
the date of purchase.
This warranty covers only defects in material and
workmanship. Sears will NOT pay for:
1. Expendable items that can wear out from normal use,
including but not limited to filters, belts, light bulbs,
and bags.
2. A service technician to instruct the user in correct
product installation, operation or maintenance.
3. A service technician to clean or maintain this product.
4. Damage to or failure of this product if it is not
installed, operated or maintained according to all
instructions supplied with the product.
5. Damage to or failure of this product resulting from
accident, abuse, misuse or use for other than its
intended purpose.
6. Damage to or failure of this product caused by the
use of detergents, cleaners, chemicals or utensils
other than those recommended in all instructions
supplied with the product.
7. Damage to or failure of parts or systems resulting
from unauthorized modifications made to this
product.
Disclaimer of implied warranties; limitation of remedies:
Customer's sole and exclusive remedy under this
limited warranty shall be product repair as provided
herein. Implied warranties, including warranties of
merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed
by law. Sears shall not be liable for incidental or
consequential damages. Some states and provinces
do not allow the exclusion or limitation of incidental or
consequential damages, or limitations on the duration of
implied warranties of merchantability or fitness, so these
exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in
the United States and Canada.
This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Sears Canada Inc., Toronto, Ontario, Canada M5B 2B8
_Master Protection Agreements
Congratulations on making a smart purchase. Your new Kenmore ® product is designed and manufactured
for years of dependable operation. But like all products, it may require preventive maintenance or
repair from time to time. That's when having a Master Protection Agreement can save you money and
aggravation.
The Master Protection Agreement also helps extend the life of your new product. Here's what the
Agreement _ includes:
• Parts and labor needed to help keep products operating properly under normal use, not just defects.
Our coverage goes well beyond the product warranty. No deductibles, no functional failure excluded
from coverage - real protection.
• Expert service by a force of more than 10,000 authorized Sears service technicians, which means
someone you can trust will be working on your product.
• Unlimited service calls and nationwide service, as often as you want us, whenever you want us.
• "No-lemon" guarantee - replacement of your covered product if four or more product failures occur
within twelve months.
• Product replacement if your covered product can't be fixed.
• Annual Preventive Maintenance Check at your request - no extra charge.
• Fast help by phone - we call it Rapid Resolution - phone support from a Sears representative on all
products. Think of us as a "talking owner's manual."
• Power surge protection against electrical damage due to power fluctuations.
• $250 Food Loss Protection annually for any food spoilage that is the result of mechanical failure of
any covered refrigerator or freezer.
• Rental reimbursement if repair of your covered product takes longer than promised.
• 10% discount off the regular price of any noncovered repair service and related installed parts.
Once you purchase the Agreement, a simple phone call is all that it takes for you to schedule service. You
can call anytime day or night, or schedule a service appointment online.
The Master Protection Agreement is a risk-free purchase. If you cancel for any reason during the product
warranty period, we will provide a full refund or a prorated refund anytime after the product warranty
period expires. Purchase your Master Protection Agreement today!
Some limitations and exclusions apply.
For prices and additional information in the U.S.A., call 1-800-827-6655.
Coverage in Canada varies on some items. For full details, call Sears Canada at 1-800-361-6665.
Sears Installation Service
For Sears professional installation of home appliances, garage door openers, water heaters, and other
major home items, in the U.S.A. or Canada call 1-800-4-MY-HOME ®.
3
In the space to the right, record the date of purchase,
model, and serial number of your product. You will find
the model and serial number printed on an identification
plate located inside the oven door. Have these items
of information available whenever you contact Sears
concerning your product.
Your safety and the safety of others is very important.
We have provided many important safety messages in thismanual and on your microwave oven.
Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word
"DANGER" or "WARNING." These words mean:
You will be killed or seriously injured
if you do not follow instructions.
You can be killed or seriously injured
if you do not follow these instructions.
Model No.
Date of Purchase
Serial No.
Save these instructions and your sales receipt for future
reference.
All safety messages will identify the hazard, tell you how to reduce the chance of injury, and
tell you what can happen if the instructions are not followed.
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including
the following:
AII_/'_I_INIIN_._: To reduce the risk of "
burns, electric shock, fire, injury to persons, or
exposure to excessive microwave energy:
• Read all instructions before using the
microwave oven.
Read and follow the specific
"PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY" found in this section.
The microwave oven must be grounded.
Connect only to a properly grounded outlet.
See "GROUNDING INSTRUCTIONS" found
at the end of this section.
• Install or locate the microwave oven only in
accordance with the provided installation
instructions.
Some products such as whole eggs in
the shell and sealed containers, such as
closed jars, can explode and should not
be heated in the microwave oven.
Use the microwave oven only for its
intended use as described in this manual.
Do not use corrosive chemicals or vapors
in the microwave oven. This type of oven
is specifically designed to heat, cook, or
dry food. It is not designed for industrial
or laboratory use.
As with any appliance, close supervision
is necessary when used by children.
Do not operate the microwave oven if
it has a damaged cord or plug, if it is
not working properly, or if it has been
damaged or dropped.
SAVE THESE INSTRUCTIONS
4
IMPORTANT SAFETY INSTRUCTIONS
• The microwave oven should be serviced only by
qualified service personnel. Call an authorized
service company for examination, repair, or
adjustment.
• See door surface cleaning instructions in the
"CARE AND CLEANING" section.
• To reduce the risk of fire in the oven cavity:
- Do not overcook food. Carefully attend to the
microwave oven when paper, plastic, or other
combustible materials are placed inside the
oven to facilitate cooking.
- Remove wire twist-ties from paper or plastic
bags before placing bags in oven.
- If materials inside the oven ignite, keep the
oven door closed, turn the oven off, and
disconnect the power cord, or shut off power
at the fuse or circuit breaker panel.
- Do not use the oven cavity for storage
purposes. Do not leave paper products,
cooking utensils, or food in the oven cavity
when not in use.
• This Microwave Oven is suitable for use above
both gas and electric cooking equipment.
• This Microwave Oven is intended to be used
above ranges with a maximum width of
36 inches (91 cm).
• Clean Ventilating Hoods frequently - grease
should not be allowed to accumulate on the hood
or filter.
• When flaming foods under the hood, turn the
fan on.
• Use care when cleaning the vent-hood filter.
Corrosive cleaning agents, such as lye-based
oven cleaners, may damage the filter.
• Oversized foods or oversized metal utensils
should not be inserted in the microwave oven,
as they may start a fire or create risk of electric
shock.
• Do not clean with metal scouring pads. Pieces
can break off the pad and touch electrical parts
causing a risk of electric shock.
• Do not store anything directly on top of the
microwave oven when the microwave oven is in
operation.
• Do not cover or block any openings on the
microwave oven.
Do not store this microwave oven outdoors.
Do not use the microwave oven near water - for
example, near a kitchen sink, in a wet basement,
near a swimming pool, or similar location.
Do not immerse the cord or plug in water.
Keep the cord away from heated surfaces.
Do not let the cord hang over the edge of a
table or counter.
Do not mount the oven over a sink.
Do not cover the racks or any other part of the
oven with metal foil. Doing so will cause the oven
to overheat.
Liquids such as water, coffee, or tea can be
overheated beyond the boiling point without
appearing to be boiling, due to surface tension
of the liquid. Visible bubbling or boiling when the
container is removed from the microwave oven is
not always present. This could result in very hot
liquids suddenly boiling over when a spoon
or other utensil is inserted into the liquid. To
reduce the risk of injury to persons:
1) Do not overheat the liquid.
2) Stir the liquid before and halfway through
heating it.
3) Do not use straight-sided containers with
narrow necks.
4) After heating, allow the container to stand in
the microwave oven for a short time before
removing the container.
5) Use extreme caution when inserting a spoon
or other utensil into the container.
SAVE THESE INSTRUCTIONS
5
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the
door open. Doing so can result in harmful
exposure to microwave energy. It is important
not to defeat or tamper with the
safety interlocks.
(b) Do not place any object between the oven
front face and the door, or allow soil or
cleanser residue to accumulate on
sealing surfaces.
ELECTRICAL REQUIREMENTS
Observe all governing codes and ordinances.
A 120-Volt, 60-Hz, AC-only, 20-amp fused
electrical supply is required. A time delay
fuse is recommended. It is recommended that
a separate circuit, serving only this appliance,
be provided.
(c) Do not operate the oven if it is damaged. It
is particularly important that the oven door
closes properly and that there is no damage
to the:
(1) Door (bent)
(2) Hinges and latches (broken or loosened)
(3) Door seals and sealing surfaces
(d) The oven should not be adjusted or repaired
by anyone except for a properly qualified
service technician.
Electrical Shock Hazard
Plug into a grounded 3-prong
outlet. Do not remove ground
prong. Do not use an adapter
Do not use an extension
cord. Failure to follow these
instructions can result in
electrical shock, fire, or death.
GROUNDING INSTRUCTIONS
For all cord-connected appliances:
The microwave oven must be grounded.
In the event of an electrical short circuit,
grounding reduces the risk of electric shock
by providing an escape wire for the electric
current. The microwave oven is equipped
with a cord having a grounding wire with a
grounding plug. The plug must be plugged
into an outlet that is properly installed and
grounded.
Ensure proper ground
exists before use
SAVE THESE INSTRUCTIONS
AWARNING: Improper grounding can
result in a risk of electric shock. Consult a
qualified electrician or service technician if you
do not understand the grounding instructions or if
doubt exists whether the appliance is properly
grounded. Do not use an extension cord. If the
power supply cord is too short, have a qualified
electrician or service technician install an outlet
near the microwave oven.
For a permanently connected appliance:
This appliance has a short power supply cord
to reduce the risk of anyone tripping over or
becoming entangled in the cord. The microwave
oven must be connected to a grounded, metallic,
permanent wiring system, or an equipment
grounding conductor should be run with the
circuit conductors and connected to the
equipment grounding terminal or lead on the
microwave oven.
This section discusses the concepts behind microwave cooking. It also discusses the basic information you
need to know to operate your microwave oven. Please read this information before you use your oven.
HOW YOUR MICROWAVE HOOD COMBINATION WORKS
Microwave ovens are safe. Microwave energy is not hot. It
causes food to make its own heat, and it is this heat that cooks
the food.
Microwaves are like TV waves, radio waves, or light waves. You ....
cannot see them, but you can see what they do.
A magnetron in the microwave oven produces microwaves. The
microwaves move into the oven where they contact the food as it
turns on the turntable.
The glass turntable of your microwave oven lets microwaves
pass through. Then they bounce off a metal floor, back through
the glass turntable, and are absorbed by the food. Metal floor Glass tray Guide tray
Microwaves pass through most glass, paper, and plastics
without heating them, so food absorbs the energy. Microwaves bounce off metal containers so food does
not absorb the energy.
Sensor Cooking
This Microwave System features Sensor Cooking functions. A humidity sensor in the oven cavity detects
moisture and humidity emitted from food as it heats. The sensor adjusts cooking times to various types and
amounts of food. Sensor Cooking takes the guesswork out of microwave cooking.
For the best cooking results
• Always cook food for the shortest cooking time recommended. Check to see how the food is cooking.
• Stir, turn over, or rearrange the food being cooked about halfway through the cooking time for all
recipes. This will help make sure the food is evenly cooked.
• If you do not have a cover for a dish, use wax paper, or microwave-approved paper towels or plastic
wrap. Remember to turn back a corner of the plastic wrap to vent steam during cooking.
• Always remove the cooking rack from the oven when the rack is not in use.
I : ...........
Magnetron
Oven cavity
RADIO INTERFERENCE
Using your microwave oven may cause interference to your radio, TV, or similar equipment. When there is
interference, you can reduce it or remove it by:
• Cleaning the door and sealing surfaces of the oven.
• Adjusting the receiving antenna of the radio or television.
• Moving the receiver away from the microwave oven.
• Plugging the microwave oven into a different outlet so that the microwave oven and receiver are on
different branch circuits.
TESTING YOUR MICROWAVE OVEN
Cook at 100% power for 1 minute. When the time is up, the water should be heated.
I o test the oven, put approximately 1 cup of cold water in a glass container in the oven. Close the door.
I
7
TESTING YOUR DINNERWARE OR COOl(WARE
Most heat resistant, nonmetallic cookware is safe for use in your microwave oven. However, to test
cookware before using, follow these steps:
1. Place empty cookware in the microwave oven.
2. Measure 1 cup (250ml) of water in a glass measuring cup and place it in the oven beside
the cookware.
3. Microwave on 100% power for 1 minute. If the cookware is warm, it should not be used for
microwave cooking.
NOTE:
Some dishes (melamine, some ceramic dinnerware, etc.) absorb microwave energy, becoming too hot to
handle and slowing cooking time. Cooking in metal containers, not designed for microwave use, could
damage the oven, as could containers with hidden metal (twist-ties, foil lining, staples, metallic
glaze or trim).
OPERATING SAFETY PRECAUTIONS
• Never lean on the door or allow a child to swing on it when the door is open.
• Use hot pads. Microwave energy does not heat containers, but the heat from the food can make the
container hot.
• Do not use newspaper or other printed paper in the oven.
• Do not dry flowers, fruit, herbs, wood, paper, gourds, or clothes in the oven.
• Do not start the microwave oven when it is empty or product life may be shortened. If you practice
programming the oven, put a container of water in the oven. It is normal for the oven door to look wavy
after the oven has been running for a while.
• Do not try to melt paraffin wax in the oven. Paraffin wax will not melt in a microwave oven because it
allows microwaves to pass through it.
• Do not operate the microwave oven unless the glass turntable is securely in place and can move freely.
The turntable can move in either direction. Make sure the turntable is correct-side up in the oven. Handle
your turntable with care when removing it from the oven to avoid possibly breaking it. If your turntable
cracks or breaks, contact your dealer for a replacement.
• When you use a browning dish, the browning dish bottom must be at least 3,,'16 inch above the
turntable. Follow the directions supplied with the browning dish.
• Never cook or reheat a whole egg inside the shell. Steam buildup in whole eggs may cause them to
burst, and possibly damage the oven. Slice hard-boiled eggs before heating. In rare cases, poached
eggs have been known to explode. Cover poached eggs and allow a standing time of one minute
before cutting into them.
• For best results, stir any liquid several times during heating or reheating. Liquids heated in certain
containers (especially containers shaped like cylinders) may overheat. The liquid may splash out with a
loud noise during or after heating or when adding ingredients (coffee granules, tea bags, etc.). This can
harm you or damage the microwave oven.
• Microwaves may not reach the center of a roast. The heat spreads to the center from the outer, cooked
areas just as in regular oven cooking. This is one of the reasons for letting some foods (for example,
roasts or baked potatoes) stand for a while after cooking, or for stirring some foods during the
cooking time.
• Do not deep fry in the oven. Microwavable utensils are not suitable and it is difficult to maintain
appropriate deep-frying temperatures.
• Do not overcook potatoes. At the end of the recommended cooking time, potatoes should be slightly firm
because they will continue cooking during standing time. After microwaving, let potatoes stand for flve
minutes. They will finish cooking while standing.
ELECTRICAL CONNECTION
qualified electrician check your electrical system.
I f your electric power line or outlet voltage is less than 110 volts, cooking times may be longer. Have a
I
MICROWAVE OVEN FEATURES
Your microwave oven is designed to make your
cooking experience as enjoyable and productive
as possible. To get you up and running quickly, the
following is a list of the oven's basic features:
A. Metal Shielded Window - The shield prevents
microwaves from escaping. It is designed as a
screen to allow you to view food as it cooks.
B. Model and Serial Number Plate
C. Charcoal Filter (behind Vent Grille)
D. Vent Grille
E. Glass Turntray/Guide Tray - The glass tray
moves food as it cooks for more even cooking.
It must be in the oven during operation for best
cooking results. NOTE: The Even Glide Plus system is
capable of handling dishes up to 12 x 15 inches.
GLASS TRAY COMPONENTS
2
F. Cooktop/Countertop Light
G. Grease Filter - See "CARING FOR THE FILTERS"
section.
H. Control Panel - Touch the pads on this panel to
perform all functions.
I. Cooking Rack - Use for extra space when cooking
in more than one container at the same time.
Remove cooking rack when you are not using it.
J. Door Handle
I(. Door Safety Lock System
L. Cooking Guide Label
1. Glass tray
2. Rotating ring
3. Guide tray
4. Shaft
3
4
The glass tray moves in both directions and
turns to help cook food more evenly. Do not
operate the microwave oven without the glass
tray in place.
9
INSTALLATION INSTRUCTIONS FOR GLASS TRAY
To install:
1. Place the guide tray on the oven cavity bottom. The rollers on the shaft should fit inside the guide tray
bottom groove. (See figures 1,2-1, and 2-2)
2. Place the rotating ring on the guide tray. (See Figure 3)
3. Place the glass tray on the rotating ring. Fit the rollers of the shaft between the raised, hollowed groove
of the glass tray bottom. The rollers on the rotating ring should fit inside the glass tray bottom ridge. (See
Figures 4-1 and 4-2)
Figure 1 Figure 2-1 Figure 2-2
Figure 3 Figure 4-1 Figure 4-2
USING AN OBLONG DISH
When using an oblong dish, don't forget to place it in the center of the guide tray, or poor performance
will result. An oblong dish which is smaller than 13 inches should be placed on the glass tray. A dish larger
than 13 inches should be placed on the raised edge of the guide tray preventing it from touching the
glass tray. Otherwise, poor performance will result. (See Figure 6)
Figure 5 Figure 6 Figure 7
10
Loading...
