KGnmorG
Ultra Wash Dishwasher
Use & Care Guide
Lavavajillas Ultra Wash
Manual de uso y cuidado
Lave-vaisselle Ultra Wash
Guide d’utilisation et d’entretien
Models/Modelos/Modèles 665.15772,15777,15779,16772,16777,16779,17772,
' 17777,17779
3384335
Sears Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
Sears Canada, Inc., Toronto, Ontario, Canada MSB 2B8
wvnv.sears.com
www.sears.ca
TABLE OF
WE SERVICE
CONTENTS
WE SERVICE WHAT WE SELL
WARRANTY
...........................................................
DISHWASHER SAFETY
Before Using Your Dishwasher.........................................5 specifically trained on Sears appliances and having the
PARTS AND FEATURES 6 parts, tools, and equipment to ensure that we meet our
ULTRA WASH* Soil RemovaïSystëmT!!""!!!"^ ^o you...“We Service What We Sell.”
....................................................4 nationwide, staffed with professional technicians
........................................
..............
1..................................3 depend on Sears for service. Your dishwasher has added
...........
2 “We Service What We Sell" is our assurance that you can
value when you consider that Sears has service units
WHAT WE SELL
Sea'S Maintenance Agreement
LOADING YOUR DISHWASHER
Loading Suggest^ns^........................................................8 manufactumd, and tested for years of
Loading the i^op Hack......................................................y dependable operation. Yet, any modern appliance may
Loading the Bottom Rack
Loading the Silverware Basket
USING YOUR DISHWASHER..........................................11 jhe Sears Maintenance Agreement
Detergent Dispenser.....................................................11 , . . .
Rinse Aid Dispenser......................................................12 " ‘"''y tomorrow s service at today’s prices.
Dishwasher Efficiency Tips.............................................13 ■ Eliminates repair bills resulting from normal use.
Control Panel..................................................................14 ^ Allows for as many service calls as required.
Cycle Selection Chart
Canceling a Cycle..........................................................15 ■ Provides for service by professional Sears Trained
Changing a Cycle or Setting...........................................15 Technicians.
Adding Items During a Cycle
Option Selections
Cycle Status indicators...................................................17 check-up at your request!
Overfill Protection Float
WASHING SPECIAL ITEMS
CARING FOR YOUR DISHWASHER
Cleaning Your Dishwasher
Drain Air Gap.................................................................19 _ . .... .
Storing Your Dishwasher
TROUBLESHOOTING.......................................................21 ■ Door and access panel accessories
...................................................
...........................................................
..............................................................
.................................................17 installation, reinstallation, or damage resulting from
........................................
...............................................
.....................................
..........................................
.............................................
...............................
...........................................
...............................................
8 Maintain the value of your KENMORE* Dishwasher with a
10 require service from time to time.
11
14
15 ■ Even if you don’t need repairs, the Maintenance
16 Agreement offers an annual preventative maintenance
This Maintenance Agreement does not cover original
18 external causes such as acts of abuse, theft, fire, flood,
19 wind, lightning, freezing, power failure, power reduction,
19 '
stc
20 To customize your dishwasher, you can order
■ Custom wood panel trim accessories to match
your dishwasher color
See back page of Installation Instructions that came with
your dishwasher for further information.
WARRANTY
FULL ONE-YEAR WARRANTY ON 770 SERIES
KENMORE ULTRA WASH* DISHWASHERS
For one year from the date of purchase, when this
dishwasher is installed and operated according to
instructions provided in the installation Instructions and
Use & Care Guide, Sears will repair this dishwasher, free of
charge, if defective in material or workmanship.
FULL TWO-YEAR WARRANTY ON ELECTRONIC
CONTROL AND POWER SUPPLY BOARD
For two years from the date of purchase, when this
dishwasher is installed and operated according to
instructions provided in the Installation Instructions and
Use & Care Guide, Sears will repair, free of charge, the
electronic module and power supply board if defective in
material or workmanship.
LIMITED TWO-YEAR WARRANTY ON THE
ULTRA WASH WASH SYSTEM
After the first year and until two years from the date of
purchase, when the dishwasher is installed and operated
in accordance with the instructions provided in the
Installation Instructions and Use & Care Guide, Sears will
replace any part of the ULTRA WASH wash system (motor,
pump, spray arms, ULTRAFLOW* water feed tube, motor
seals and pump gasket) due to defective materials or
workmanship. Customer assumes any labor costs
associated with replacement of these parts.
If the dishwasher is subject to other than private family
use, the above warranty coverage is effective for only 90
days,
WARRANTY SERVICE IS AVAILABLE BY CONTACTING
THE NEAREST SEARS SERVICE CENTER IN THE UNITED
STATES OR CANADA. This warranty applies only while the
product is in use in the United States or Canada. This
warranty gives you specific legal rights and you may also
have other rights which vary from state to state or province
to province.
FULL WARRANTY FOR THE LIFE OF THE
DISHWASHER, ON ULTRA LIFE* TUB MODELS,
AGAINST LEAKS IN THE TUB AND INNER
DOOR PANEL
For the life of the dishwasher, if a leak should occur as a
result of failure of the polypropylene tub or inner door
panel due to cracking, chipping or peeling. Sears wili
replace free of charge the tub or inner door panel.
Warranty terms may vary in Canada.
For Sears Warranty information in the United States or
Canada call 1-800-469-4663.
Sears, Roebuck and Co.
D/817WA, Hoffman Estates, IL 60179
Sears Canada, Inc.
Toronto, Ontario, Canada MSB 2B8
In the space below, record your complete model number,
serial number, and purchase date. You can find this
information on the model and serial number label, located
as shown in the Parts and Features section of this book.
Have this information available to help you quickly obtain
assistance or service when you contact Sears concerning
your appliance.
Model number 665.
Serial number_________________________________________
Purchase date
Save these instructions and your sales receipt for
future reference.
____________________________________
________________________________________
DISHWASHER SAFETY
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards that can kill or hurt you and others.
All safety messages will be preceded by the safety alert symbol and the word “DANGER” or
A
All safety messages will identify the hazard, tell you how to reduce the chance of injury; and tell you what can
happen if the instructions are not followed.
"WARNING.” These words mean:
ADANGER
AWARNING
You wiU be killed or seriously injured if you don't follow instructions.
You can be killed or seriously injured if you don't follow instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING : When using the dishwasher, follow basic precautions, including the following:
Read all instructions before using the dishwasher.
Use the dishwasher only for its intended function.
Use only detergents or rinse agents recommended
for use in a dishwasher, and keep them out of the
reach of children.
When loading items to be washed:
1) Locate sharp items so that they are not likely to
damage the door seal; and
2) Load sharp knives with the handles up to reduce
the risk of cut-type injuries.
Do not wash plastic items unless they are marked
“dishwasher safe" or the equivalent. For plastic
items not so marked, check the manufacturer's
recommendations.
Do not touch the heating element during or
immediately after use.
Do not operate the dishwasher unless all enclosure
panels are properly in place.
Do not tamper with controls.
Do not abuse, sit on, or stand on the door or dish
racks of the dishwasher.
To reduce the risk of injury, do not allow children to
play in or on the dishwasher.
Under certain conditions, hydrogen gas may be
produced in a hot water system that has not been
used for two weeks or more. HYDROGEN GAS IS
EXPLOSIVE. If the hot water system has not been
used for such a period, before using the dishwasher
turn on all hot water faucets and let the water flow
from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable,
do not smoke or use an open flame during this time.
Remove the door to the washing compartment when
removing an old dishwasher from service or
discarding it.
SAVE THESE INSTRUCTIONS
Before Using Your Dishwasher
^WARNING
GROUNDING INSTRUCTIONS
For a grounded, cord-connected dishwasher:
The dishwasher must be grounded, in the event
of a malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a
path of least resistance for electric current. The
dishwasher is equipped with a cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appro
priate outlet that is installed and grounded in
accordance with all local codes and ordinances,
Tip Over Hazard
Do not use dishwasher until completely installed.
Do not push down on open door.
Doing so can result in serious injury or cuts.
^WARNING
>8
Electrical Shock Hazard
Electrically ground dishwasher.
Connect ground wire to green ground connector
in terminal box.
Do not use an extension cord.
Failure to follow these Instructions can result In
death, fire, or electrical shock.
WARNING; improper connection of the
equipment-grounding conductor can result in a
risk of electric shock. Check with a qualified
electrician or service representative if you are in
doubt whether the dishwasher is properly
grounded. Do not modify the plug provided with
the dishwasher; if it will not fit the outlet, have a
proper outlet installed by a qualified electrician.
For a permanently connected dishwasher:
The dishwasher must be connected to a
grounded metal, permanent wiring system, or an
equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
dishwasher.
SAVE THESE INSTRUCTIONS
Install where dishwasher is protected from the
elements. Protect against freezing to avoid possible
rupture of fill valve. Such ruptures are not covered by
the warranty. See “Storing Your Dishwasher” in the
“Caring for Your Dishwasher” section for winter storage
information.
Install and level dishwasher on a floor that will hold the
weight, and in an area suitable for its size and use.
Remove all shipping plugs from hoses and connectors
(such as the cap on the drain outlet) before installing.
See Installation Instructions for complete information.
PARTS AND FEATURES
1. Upper level wash
2. Top rack
3. Utensil basket
4. Bottom rack
5. Lower spray arm
6. Water inlet opening [in tub wall]
7. Rack bumper
Control Panel
8. Heating element
9. Vent
10. Top spray arm
11. Extra-capacity fold-down shelves
12. ULTRA FLOW* water feed tube
13. Silverware basket
14. Model and serial number label
15. ULTRA WASH* module
16. Overfill protection float
17. Detergent dispenser
18. Rinse aid dispenser
Other features your dishwasher
may have .
NO-FLIP* clips
Fold-down tines
Small items basket
ULTRA WASH* Soil
Removal System
The ULTRA WASH soil removal system gives you sparkling
clean dishes, while using less energy and time. The ULTRA
WASH soil removal system includes:
■ A heavy-duty grinder that acts as a food disposer to
grind and dispose of large food particles.
■ An ULTRA WASH sensor to monitor soil level and
adjust the cycles as needed.
How the ULTRA WASH soil removal system
works:
1. Load the dishwasher. Remove bones, large chunks or
burned-on food. No rinsing is necessary. Any remaining
food soil will be ground up and disposed down the
drain with the rinse water.
2. Hot water fills the dishwasher to a level near the bottom
of the overfill protection float.
3. The Water Heating indicator glows and the dishwasher
pauses while the water is heated.
4. When the water reaches the proper temperature, the
Water Heating indicator turns off and the cycle
countdown resumes.
5. Detergent from the detergent dispenser is dispensed at
the correct cycle times and hot water is pumped
through the ULTRA WASH pump.
6. Hot water and detergent sprays against the soiled
surfaces of the load and removes food particles.
8. Food soil is disposed down the drain with the wash
water.
9. Fresh, hot water enters the dishwasher and sprays on
the dishes. The rinse water is then pumped through the
ULTRA WASH soil removal system and remaining soil is
removed.
10. The food soil that is held in the ULTRA WASH soil
removal system is disposed down the drain with the
rinse water.
11. The final rinse water is heated. The rinse aid is added to
the water for the final rinse to prepare the dishes for
drying.
How the ULTRA WASH Sensor adjusts the cycle:
1. The SENSING indicator glows when the ULTRA WASH
Sensor is measuring the amount of soil in the
dishwasher.
2. After the soil level is determined, unnecessary portions
of the cycle are skipped.
7. Food soil is held in an accumulating chamber.
START-UP GUtDE
LOADING YOUR
Before using your dishwasher, remove afl hang tags,
temporary labels, and packaging materials. Read this
entire Use and Care Guide, You wili find important safety
information and useful operating tips.
Using Your New Dishwasher
1. Scrape large food soil and hard items (toothpicks or
bones) from dishes.
2. Properly load the dishwasher. (See “Loading Your
Dishwasher.’’) Make sure nothing prevents the spray
arm(s) from spinning freely.
3. Add detergent and check the rinse aid dispenser. Add
rinse aid if needed. (See “Using Your Dishwasher.”)
DISHWASHER
Loading Suggestions
■ Remove leftover food, bones, toothpicks and other
hard items from the dishes. It is not necessary to rinse
the dishes before putting them in the dishwasher. The
wash module removes food particles from the water.
The module contains a chopping device which will
reduce the size of food items.
NOTE: If hard items such as fruit seeds, nuts, and egg
shells enter the wash module, you might hear chopping,
grinding, crunching, or buzzing sounds. These sounds are
normal when hard items enter the module. Do not let
metallic items (such as pot handle screws) get into the
wash module. Damage can,occur,
■ Load dishes so soiled surfaces face the spray (down or
inward). It is important for the water spray to reach all
soiled surfaces.
■ Load dishes so they are not stacked or overlapping if
possible. For best drying, water must be able to drain
from all surfaces.
■ Make sure pot lids and handles, pizza pans, cookie
sheets, etc., do not interfere with the spray arm
rotation.
Push door firmly closed. The door latches
automatically. Run hot water at the sink nearest your
dishwasher until the water is hot, (See “Dishwasher
Efficiency Tips.”) Turn off water.
5. Press the desired cycle and option selections. (See
“Using Your Dishwasher.”} Press START.
■ Run a rinse cycle to keep dishes moist if you do not
plan to wash them soon, Foods like eggs, rice, pasta,
spinach, and cooked cereals may be hard to remove if
they are left to dry over a period of time.
Quiet operating tips
To avoid thumping/clattering noises during operation:
■ Make sure lightweight load items are secured in the
racks.
■ Make sure pot lids and handles, pizza pans, cookie
sheets, etc., do not touch interior walls or interfere with
the rotation of the spray arm.
■ Load dishes so they do not touch one another.
NOTE: For built-in models, keep sink drain plugs closed
during dishwasher operation to prevent noise transfer
through drains.
8
Loading the Top Rack
The top rack is designed for cups, glasses, and smaller
items. (See recommended loading patterns shown.)
NOTE: The features on your dishwasher rack may vary
from the drawings shown.
10 place setting
Utensil basket
Use this extra capacity basket on the top rack to hold
spatulas, wooden spoons, and similar items.
Extra-capacity fold-down shelves
Fold down the extra shelf on the right side of the top rack
to hold additional cups, or long items such as utensils and
spatulas.
Fold-down tines (on some models)
Fold the tines in the top rack all the way down to
accommodate larger items.
12 place setting
Place items so open ends face down for cleaning and
draining.
Load glasses in top rack only. The bottom rack is not
designed for glasses. Damage can occur.
Place cups and glasses in the rows between prongs.
Placing them over the prongs can lead to breakage.
China, crystal, and other delicate items must not touch
each other during dishwasher operation. Damage may
occur.
Load plastic items in the top rack only. Only plastic
items marked “dishwasher safe” are recommended.
Load plastic items so the force of the spray does not
move them during the cycle.
To avoid chipping, do not let stemware touch other
items.
Small bowls, pans, and other utensils can be placed in
the top rack. Load bowls in the center section for best
stability.
No-flip dips (on some models)
The no-flip clips hold lightweight plastic items like cups,
lids, or bowls in place during washing. You can move a clip
anywhere in the rack.
1. Pull the clip up and off the tine.
2. Reposition the clip on another tine.
Small items basket (on some models)
Place this basket in the top rack.
Use the basket to hold small items that could otherwise
“fly" around inside the dishwasher during a cycle.
Loading the Bottom Rack
The bottom rack is designed for piates, pans, casseroies,
and utensiis. Items with cooked-on or dried-on food
should be ioaded with soiled surfaces facing inward to the
spray. (See recommended loading patterns shown.)
NOTE: The features on your dishwasher rack may vary
from the drawings shown.
10 place setting
Do not load glasses, cups, or plastic items in the
bottom rack. Load small items in the bottom rack only
if they are secured in place.
■ Load cookie sheets, cake pans, and other large items
at the sides and back. Loading such items in front can
keep the water spray from reaching the detergent
dispenser.
■ Secure heavily soiled cookware face down in the rack.
■ Make sure pot handles and other items do not stop
rotation of the spray arm(s). The spray arm(s) must
move freely.
■ Do not load items between the bottom rack and the
side of the dishwasher tub. You can block the water
inlet opening.
NOTE: If you have removed the bottom rack for unloading
or cleaning, replace it with the bumpers in front.
Fold-down tines
You can fold down one or both rows of tines at the back of
the bottom rack.
Load plates, soup bowls, etc., between prongs and
facing inward to the spray.
Overlap the edges of plates for large loads.
Load soup, cereal, and serving bowls in the rack in a
variety of ways depending upon their size and shape.
Load bowls securely between the rows of prongs. Do
not nest bowls because the spray will not reach all
surfaces.
12 place setting
1.
Grasp the tip of the tine that is in the tine holder.
2.
Gently pull the tine out of the tine holder.
3.
Lay the row of tines down in the rack to make room for
larger dishes, bowls, pots, pans or roasters.
10
Loading the
Silvetwate Basket
Load the silverware basket while it is in the bottom rack or
take the basket out for loading on a counter or table.
NOTE: Unload or remove the basket before unloading the
racks to avoid spilling water droplets on the silverware.
■ Place small items like baby bottle caps, jar lids, corn
cob holders, etc., in the section(s) with hinged cover(s).
Close the cover to hold small items in place (on some
models).
This silverware basket can be separated and placed
into the bottom rack in several locations. Load
silverware in all sections or just one, depending upon
your load.
Mix items in each section of the basket with some
pointing up and some down to avoid nesting. Spray
cannot reach nested items.
USING YOUR
DISHWASHER
Detergent Dispenser
The detergent dispenser has 2 sections. The Pre-Wash
section empties detergent into the dishwasher when you
close the door.
1. Cover
2. Main wash section
3. Cover latch ■
4. Pre-wash section
The larger Main Wash section automatically empties
detergent into the dishwasher during the main wash. (See
the “Cycle Selection Chart.”)
■ Use automatic dishwashing detergent only. Other
detergents can produce excessive suds that can
overflow out of the dishwasher and reduce washing
performance.
IMPORTANT: Always load sharp items (knives, skewers,
forks, etc.) pointing down.
To remove a small basket
1. Hold the center basket and one small basket. Slide the
small basket forward to release the tabs from the
corresponding slots.
2. Pull the baskets apart.
NOTES:
■ Do not load silver or silver-plated silverware with
stainless steel. These metals can be damaged by
contact with each other during washing.
■ Some foods (such as salt, vinegar, milk products, fruit
juices, etc.) can pit or corrode silverware. Run a rinse
cycle if you do not have a full load to wash immediately.
■ Add detergent just before starting cycle.
■ Store tightly closed detergent in a cool, dry place.
Fresh automatic dishwasher detergent results in better
cleaning.
NOTE: Do not use detergent with a rinse cycle.
Filling the dispenser
1. If the dispenser cover is closed, open the cover by
pushing the Cover latch.
2. Fill the Main Wash section with detergent. See “How
Much Detergent to Use.”
3. Close the Main Wash dispenser cover. Fill the Pre
Wash section if needed.
It is normal for the cover to open partially when dispensing
detergent.
NOTE: Use both sections for cycles with 2 washes. Use
only the covered section for cycles with 1 wash. See the
“Cycle Selection Chart” for more details.
11
How much detergent to use
■ The amount of detergent to use depends on the
hardness of your water and the type of detergent. If you
use too little, dishes won’t be clean. If you use too
much in soft water, glassware will etch.
■ Water hardness can change over a period of time. Find
out your water’s hardness by asking your local water
department, water softener company, or county
extension agent.
■ Different brands of dishwasher detergent have different
amounts of phosphorous for softening water, if you
have hard water and use a detergent with a
phosphorous content of less than 8,7%, you might
need to use more detergent, or use a detergent with a
phosphorous content higher than 8.7%.
Medium to Hard
Water heavily soiled loads:
7 to 12 grains per
gallon
NOTE: Fill amounts shown are for standard powdered
detergent. Amounts may vary if you use liquid or
concentrated powdered detergent. Follow instructions on
the package when using liquid dishwasher detergent or
concentrated powdered detergent.
For normally soiled and
■ Fill the Main Wash section
(3 tbs or 45 g)
■ Partially fill the Pre-Wash
section (2 tbs or 30 g) if
needed
Rinse Aid Dispenser
Where to fill
Top of 3rd step (3 tbs or 45 g)
Top of 2nd step (2 tbs or 30 g)
Top of 1 St step {1 tb or 15 g)
Water Hardness Amount of Detergent
Soft to Medium
Hard Water
0 to 6 grains per
gallon
For normally soiled loads:
■ Partially fill the Main Wash
section (2 tbs or 30 g)
■ Partially fill the Pre-Wash
section (2 tbs or 30 g) if
needed
NOTE: Add only 1 tb or 15 g of
detergent to both sections if
dishes are pre-rinsed or the water
is very soft (0 to 2 grains per
gallon).
For heavily soiled loads:
■ Fill the Main Wash section
(3 tbs or 45 g)
■ Partially fill the Pre-Wash
section (2 tbs or 30 g)
Rinse aids prevent water from forming droplets that can
dry as spots or streaks. They also improve drying by
allowing water to drain off of the dishes during the final
rinse by releasing a small amount of the rinse aid into the
rinse water. Your dishwasher is designed to use a liquid
rinse aid. Do not use a solid or bar-type.
Checking the dispenser
Check the center of the Fill Indicator cap. Clear means it
needs filling.
Or you can remove the Fill Indicator cap. If an “E” is visible,
the dispenser is empty.
Filling the dispenser
The rinse aid dispenser holds 6 oz (175 mL) of rinse aid.
Under normal conditions, this will last for about three
months. You do not have to wait until the dispenser is
empty to refill it. Try to keep it full, but be careful not to
overfill It.
1. Make sure the dishwasher door is completely open.
2. Remove the Fill Indicator cap.
3. Add rinse aid. Fill to the smallest opening in the lower
part of the dispenser. Overfilling can cause the rinse aid
to leak out, and could cause oversudsing.
12
4. Clean up any spilled rinse aid with a damp cloth.
5. Replace the Fill Indicator cap. CIcse tightly.
Dishwasher Efficiency Tips
Hot water dissolves and activates the dishwashing
detergent. Hot water also dissolves grease on dishes and
helps glasses dry spot-free. For best dishwashing results,
water must be at least 120°F {49“C) as it enters the
dishwasher. Loads may not wash as well if the water
temperature is too low.
4. If the water temperature at the faucet is below 120°F
(49°C), have a qualified person raise the water heater’s
thermostat setting.
■ To save water and energy, do not rinse dishes before
putting them into the dishwasher.
■ Use a low energy, quick, or short cycle whenever
possible. These cycles use less hot water and energy
than the Normal cycle.
To check water temperature
1. Run hot water at the faucet closest to your dishwasher
for at least 1 minute.
2. Place a candy or meat thermometer in a glass
measuring cup.
3. Check the temperature on the thermometer as the
water is running into the cup.
■ Use a delay feature (on some models) to run your
dishwasher during off-peak hours. Local utilities
recommend avoiding heavy usage of energy at certain
times of day.
■ During the summer, run your dishwasher at night to
reduce daytime heat buildup.
■ Use an air dry, or an energy-saving dry option
whenever possible. Allow longer drying times
(overnight) when using these options. Use a rinse aid to
improve drying.
■ Use cycles or options that add extra heat to the wash
or rinse portion of the cycle only when needed.
■ Run your dishwasher with full loads. Run a rinse cycle
after meals until the dishwasher is full.
13
Control Panel
SENSItVG
1 POTS
1 PANS
WATER HEATirœ
• • -
normal! water
WASH 1 MISER
SENSING CYCLES
WASH
•
CHINA
WASH
RINSE DRY CLEAN
• •
QUICK 1 [WATER
RINSE J 1 HEAT
Cycle Selection Chart
Select the wash cycle and options desired. Or press
START to use the same cycle and options as the previous
cycle.
NOTE: If the last cycle you completed was a rinse cycle,
the dishwasher will run the last full wash cycle and options
that you selected when you press Start.
■ If the power is off or the door is open for an extended
period of time, the Start button memory will default to
the Normal cycle with heated drying.
■ If you do not run the dishwasher daily, close the door to
maintain memory.
A shows what steps are in each cycle.
•
NOHEA'h
DRY
OPTIONS
[NORMAL{
I WASH J
Soil
Level
Sensed
Heavy
Medium
Light
LOCK ON HOURS
2 4 6
Use this cycle for loads Use both
with normal amounts of detergent
food soil. {The energy- dispenser
usage label is based on sections,
this cycle.)
Wash
Rinse
•
•
Main
Rinse
Wash
•
•
140*F
(60'C)
•
140“F
(60*0
•
Final
Heated
Rinse
•
140°F
(60*0
•
140*F
(60*0
e •
140*F
(60*0
•
•
Dry
• 90*
•
•
Time
(min)
86*
70*
J
Water
Usage
(galA.)
10.8/
40.9
8.6/32.7
6.5/24.5
Temperatures indicate where extra heat is added.
Water usage is shown in U.S. gallons/liters.
Cycle time includes dry time. An asterisk (*) by the cycle
time indicates the cycle time might be longer depending
on the temperature of the water entering the dishwasher.
TTie cooler the water, the longer the cycle time. If the water
is already hot enough, the cycle time will be as shown.
-
----------
( POTS 1 to-ck
I PANS I pots,
V y anri r
Soil
Level
Sensed
Heavy
Light
<< Use t
Use this cycie for hard
i-clean, heavily-soiled
pans, casseroles,
and regular tableware.
Wash
Rinse Main
Wash
• •
•
136"F
(67*0
140°F
(60*0
140*F
(60*0
•
•
Rinse
•
• e
Rnal
Heated
Rinse
•
140*F
(60°C)
1«“F
(60°C)
Use both
detergent
dispenser
sections.
Dry
Time
(min)
• 86*
• 80*
Water
Usage
(galÆ)
10.8/
40.9
8.6/32.7
f WATER ]
I MISER j
Soil
Wash
Level
Sensed
Heavy
Ught
Use this cycle for pre
rinsed and lightlysoiled loads. This cycle
uses less hot water
than the Normal Wash
cycle.
Rinse Main
•
Wash
•
140”F
(60*0
• m
Rinse
Final
Heated
Rinse
•
140*F
(60*0
140°F
(60*0
Use
covered
detergent
dispenser
section.
Dry
•
•
•
• 60* 4.3/16.3
Time
(min)
70*
Water
Usage
(gaÆ)
6.5/24.6
14
( CHINA ì
Use this cycle for china
and crystal. This cycle
uses a light wash and
gentle dry. During the
heated dry, the heating
Use
covered
detergent
dispenser
section.
element cycles on and
off.
Soil
Wash Rinse Main
Level
Sensed
Heavy • • •
Ught • • •
Use this rinse cycle for
f QUICK ]
t RINSE I
rinsing dishes, glasses,
and silverware that will
not be washed right
away. '
Soil
Wash Rinse Main
Lev«l
Sensed
Heavy
Light
Wash
Wash
Rinse Final
Heated
Rinse
130°F
(54“C)
130'F
(54“C)
Rinse Final
Heated
Rinse
Dry Time
•
cycled
cycled
Do not
use
detergent
with this
cycle.
Dry
Water
(min)
Usage
(gal/L)
70*
•
•
60*
Time
(min)
IS
14
6.5/24.6
4.3/16.3
Water
Usage
(aal^)
4.3/16.4
2.2/8.2
NOTE: The sensor in your dishwasher monitors the soil
level. Cycle time and/or water usage can vary from the
numbers above as the sensor adjusts the cycle for the
best wash performance.
Canceling a Cycle
Anytime during a cycle, press
Changing a Cycle or Setting
During the first minute of a cycie
Press a new cycle and/or options.
After the first minute of a cycle
1. Press
CANCEL
CANCEL/DRAIN glows. The dishwasher pauses for 5
seconds and starts a 2 minute drain (if needed). Let the
dishwasher drain completely.
2. Check the detergent dispensers. If the main wash cup
has opened and the detergent washed away, refill the
cups as needed.
3. Close the door.
4. Press a new cycle and/or options.
5. Press START.
A
DRAIN
Adding Items During a Cycle
You can add an item anytime before the main wash starts.
Open the door and check the detergent dispenser. If the
main wash section is still closed, you can add items.
To add items
1. Lift up the door latch to stop the cycle. Wait for the
spraying action to stop before opening the door.
2. Open the door. If the main wash detergent dispenser is
still closed, add the item.
r
CANCEL)
DRAIN
CANCEL7DRAIN glows. The dishwasher pauses for about
5 seconds and starts a 2 minute drain (if needed). Let the
dishwasher drain completely. The light goes off when the
dishwasher finishes the drain.
To stop the drain
You can press Cancel/Drain again to stop the drain
immediately. Remember to drain the dishwasher before
starting a new cycle.
NOTE: A small amount of water remains in the dishwasher.
This is normal.
To clear the indicators
Press Cancel/Drain before starting the dishwasher to clear
all options and cycles.
3. Close the door, but do not latch it. Wait 30 seconds for
the air in the dishwasher to warm up. This reduces the
amount of moisture escaping from the vent when
restarting a cycle.
4. Close the door firmly until it latches. The dishwasher
resumes the cycle after about a 5 second pause.
15
Option Selections
You can customize your cycles by pressing an option. If
you change your mind, press the option again to turn the
option off. Select a different option if desired.
You can change an option anytime before the selected
option begins. For example, you can press an unheated
drying option any time before drying begins.
Press START to use the same cycle and option(s) as the
previous wash cycle.
NOTE: If the last cycle you completed was a rinse cycle,
when you press Start, the dishwasher runs the last full
wash cycle and options.
Water Heat
Select this option to heat the water to 140°F (60°C) during
parts of the cycle. (See the Cycle Chart.) Heating the water
helps improve washing results. This option adds both heat
and wash time to parts of the cycle.
f WATER I
I HEAT I
NOTE: Pots Pans automatically uses this option. Water
Heat is an option with the Normal Wash and Water Miser
cycles.
No Heat Dry
Select this energy-saving option to dry without heat. No
Heat drying is useful when loads contain plastic
dinnerware that may be sensitive to high temperatures.
Control Lock On
Use the Lock to prevent your dishwasher from accidentally
being turned on. Use the Lock, also, to prevent accidental
cycle or option changes during a cycle.
Lock On
When LOCK ON is lit, all buttons are disabled.
NOTES:
■ The dishwasher door can be opened while the controls
are locked.
■ You can turn on the Lock while the dishwasher is
running.
To turn on the Lock
Press and hold
for 4 seconds. LOCK ON glows.
If you press any pad while your dishwasher is locked, the
light flashes 3 times.
To turn off the Lock
Press and hold NO HEAT DRY for 4 seconds. The light
turns off.
Delay Hours
Select this option to run your dishwasher at a later time or
during off-peak hours.
To delay the start
1. Close the door.
NO HEAT I
The dishes take longer to dry and some spotting can
occur.For best drying, use a liquid rinse aid. Some items
(such as plastics) may need towel drying,
NOTE: Quick Rinse automatically use this option. No Heat
Dry is an option with all other cycles.
2. Select a wash cycle and options.
3. Press DELAY HOURS 1 time for a 2-hour delay, 2 times
for a 4-hour delay, or 3 times for a 6-hour delay.
HOURS
2 4 6
f DELAY
I HOURS
The number glows above Delay Hours. The dishwasher
starts the cycle in the selected number of hours.
4. Press START.
NOTE: To cancel the delay, press CANCEL/DRAIN until all
Delay Hours lights are off.
IMPORTANT:
■ Operate your dishwasher only when you are at home.
■ If your home is equipped with a water softener, do not
start the dishwasher during the regeneration of the
softener.
16
Cycle Status Indicators
Follow the progress of your dishwasher with the Cycle
Status Indicators. CLEAN glows when a cycle is finished.
The light turns off when you open the door or press
Cancel/Drain.
SENSING WATER HEATING WASHING
Sensing
Your dishwasher senses the soil level on the dishes. Soil
level determines the length of some cycles, the amount of
heat added to the wash or rinse, and the cycle needed for
the load. SENSING glows during the soil sensing parts of
the cycle. Wash action continues while sensing occurs.
Water Heating
WATER HEATING glows, and the cycle progression
pauses, whenever water is heated during a cycle. Wash or
rinse action continues as the water Heats.
Lock On
When LOCK ON is lit, all buttons are disabled.
RINSE
Drying System
During drying, you can see steam escaping through the
vent at the upper left corner of the door. This is normal as
the heat dries your dishes.
%
i ^ \/ I *
ff X
X __I
IMPORTANT: The vapor is hot. Do not touch the vent
during drying.
Overfill Protection Roat
The overfill protection float {in the front right corner of the
dishwasher tub) keeps the dishwasher from overfilling. It
must be in place for the dishwasher to operate.
LOCK On
You can turn on the Lock while the dishwasher is running.
To lock or unlock the controls, see “Option Selections."
Check under the float for objects that may keep the
protector from moving up or down.
17
WASHING SPECIAL
ITEMS
If you have doubts about washing a particular item, check
with the manufacturer to see if it is dishwasher safe.
MATERIAL
DISHWASHER SAFE7/COMMENTS
MATERIAL
Pewter, Brass,
Bronze
Disposable No
Plastics
DISHWASHER SAFE7/COMMENTS
No
High water temperatures and
detergent can discolor or pit the
finish.
Cannot withstand high water
temperatures and detergents.
Aluminum Yes
High water temperature and
detergents can affect finish of
anodized aluminum.
Disposable No
Aluminum
Bottles and
Cans
Cast Iron
China/ Yes
Stoneware
Crystal
Do not wash throwaway aluminum
pans in the dishwasher. These might
shift during washing and transfer
black marks to dishes and other
items.
No
Wash bottles and cans by hand.
Labels attached with glue can loosen
and clog the spray arms or pump and
reduce washing performance.
No
Seasoning will be removed and iron
will rust.
Always check manufacturer’s
recommendations before washing.
Antique, hand-painted, or over-the-
glaze patterns may fade. Gold leaf
can discolor or fade.
Yes
Check manufacturer’s
recommendations before washing.
Some types of leaded crystal can
etch with repeated washing.
Plastics
Stainless Steel Yes
Sterling Silver
or Silver Plate
Tin
Wooden Ware
Yes
Always check manufacturer’s
recommendations before washing.
Plastics vary in their capacity to
withstand high temperatures and
detergents. Load plastics in top rack
only.
Run a rjnse cycle if not washing
immediately. Prolonged contact with
food containing salt, vinegar, milk
products, or fruit juice can damage
finish.
Yes
Run a rinse cycle if not washing
immediately. Prolonged contact with
food containing salt, acid, or sulfide
(eggs, mayonnaise, and seafood) can
damage finish.
No
Can rust.
No
Wash by hand. Always check
manufacturer's instructions before
washing. Untreated wood can warp,
crack, or lose its finish.
Gold
Glass Yes
Hollow-Handle
Knives
No
Gold-colored flatware will discolor.
dishwasher washing.
to the blade with adhesives which
can loosen if washed in the
dishwasher.
18
Milk glass yellows with repeated
No
Handles of some knives are attached
CARING FOR YOUR
DISHWASHER
Cleaning Your Dishwasher
Cleaning the exterior
In most cases, regular use of a soft, damp cloth or sponge
and a mild detergent is all that is necessary to keep the
outside of your dishwasher looking nice and clean.
Drain Air Gap
Check the drain air gap anytime your dishwasher
isn’t draining well
Some state or local plumbing codes require the addition of
a drain air gap between a built-in dishwasher and the
home drain system. If a drain is clogged, the drain air gap
protects your dishwasher from water backing up into it.
The drain air gap is usually located on top of the sink or
countertop near the dishwasher To order a drain air gap
call 1-800-366-7278 and ask for Part Number 300096.
Cleaning the interior
Hard water minerals can cause a white film to build up on
the inside surfaces, especially just beneath the door area.
Do not clean the dishwasher interior until it has cooled.
Wear rubber gloves. Do not use any type of cleanser other
than dishwasher detergent because it may cause foaming
or sudsing.
To clean interior
Make a paste with powdered dishwasher detergent on a
damp sponge and clean.
OR
Use liquid automatic dishwasher detergent and clean with
a damp sponge.
OR
Seethe vinegar rinse procedure in “Spotting and filming on
dishes” in “Troubleshooting."
NOTE: Run a Normal cycle with detergent after cleaning
the interior.
NOTE: The drain air gap is an external plumbing device
that is not part of your dishwasher. The warranty provided
with your dishwasher does not cover service costs directly
associated with the cleaning or repair of the external drain
air gap.
To dean the drain air gap
Clean the drain air gap periodically to ensure proper
drainage of your dishwasher. Follow the cleaning
instructions provided by the manufacturer. With most
types, you lift off the chrome cover. Unscrew the plastic
cap. Then check for any soil buildup. Clean if necessary.
19
storing Your Dishwasher
Storing for the summer
Protect your dishwasher during the summer months by
turning off the water supply and power supply to the
dishwasher.
Moving or winterizing your dishwasher
Protect your dishwasher and home against water damage
due to freezing water lines. If your dishwasher is left in a
seasonal dwelling or could be exposed to near freezing
temperatures, have a qualified person do the following:
1. Disconnect power supply to the dishwasher.
2. Turn off water supply to the dishwasher.
3. Remove the 4 screws on the lower access panel.
Remove the lower access panel.
5. Remove the spring clamp from the water outlet and
separate from the water supply valve; drain water into
pan.
6. Reconnect both water inlet and water outlet to the
water supply valve.
7. Empty the pan and reposition it under the water pump.
8. Remove the clamp and disconnect the drain hose from
the water pump; drain water into pan.
9. Reconnect drain hose to the water pump, being sure
to position the clamp over the connection.
10. Replace the lower access panel.
NOTE: If your dishwasher is connected to a garbage
disposal, do not run water into the sink after winterizing.
This could cause water to refill the drain hose on your
dishwasher.
Reconnecting your dishwasher
1. Remove the 4 screws on the lower access panel and
remove lower access panel.
2. Turn on the water supply to dishwasher.
3. Turn on power supply to dishwasher.
4. Run dishwasher through a complete cycle and check
for leaks.
4. Place a shallow pan under the water supply valve.
Then, use a wrench to disconnect the water inlet from
the water supply valve. Separate the water inlet from
the water supply valve and drain water into the pan.
1. Water outlet
2. Spring clamps
3. Water supply valve
4. Water Inlet
5. Water pump and motor
6. Drain hose
6. Replace lower access panel.
20
TROUBLESHOOTING
First try the solutions suggested here and possibly avoid the cost of a service call...
Dishwasher is not operating properly
Dishwasher does not run or stops during a cycle
Is the door closed tightly and latched?
Is the right cycle selected? Refer to the "Cycle Selection
Chart.”
Is there power to the dishwasher? Has a household fuse
blown or circuit breaker tripped?
Has the motor stopped due to an overload? The motor
automatically resets itself within a few minutes. If it does
not restart, call for service.
Is the water shut-off valve (if installed) turned on?
I Dishwasher will not fill -
Is the overfill protection float able to move up and down
freely? Press down to release.
I Dishwasher seems to run too long
Is the water supplied to the dishwasher hot enough? The
dishwasher runs longer while heating water. Refer to the
“Water Temperature Tips” section.
A delay automatically occurs in some wash and rinse
cycles until the water reaches the proper temperature.
i Water remains in the dishwasher
Is the cycle complete?
I Detergent remains in the covered section of the
dispenser
Is the cycle complete?
Is the detergent lump-free? Replace detergent if
necessary.
Is the bottom rack installed properly with the bumpers in
the front? Refer to the “Parts and Features” section.
Reinstall the rack if necessary.
I White residue on the front of the access panel
Was too much detergent used? Refer to the “Detergent
Dispenser” section.
Is the brand of detergent making excess foam? Try a
different brand to reduce foaming and eliminate buildup.
Odor in the dishwasher
Are dishes washed only every 2 or 3 days? Run a rinse
cycle once or twice a day until you have a full load.
Does the dishwasher have a new plastic smell? Run a
vinegar rinse as described in “Spotting and filming on
dishes” later in this Troubleshooting guide.
Condensation on the kitchen counter (built-in
models)
Is the dishwasher aligned with the counter top? Moisture
from the vent in the dishwasher console can form on the
counter. Refer to the Installation Instructions for more
information.
Dishes are not completely clean
Food soli left on the dishes
Is the dishwasher loaded correctly? Refer to the
“Loading Your Dishwasher” section.
Is the water temperature too low? If needed, turn home
water heater up to ensure water entering dishwasher is
at least 120°F (49°C). Refer to the “Dishwasher
Efficiency Tips” section.
Did you use the correct amount of fresh detergent? Use
recommended dishwasher detergents only. Refer to the
“Detergent Dispenser^ section. Never use less than 1 tb
(15 g) per load. Detergent must be fresh to be effective.
Store detergent in a cool, dry area. Heavy soil and/or
hard water generally require extra detergent.
Is detergent caked in dispenser? Use fresh detergent
only. Do not allow detergent to sit for several hours in a
wet dispenser. Clean dispenser when caked detergent is
present.
Is the pump or spray arm clogged by labels from bottles
and cans? Remove labels before washing bottles and
cans or wash by hand.
Is the home water pressure high enough for proper
dishwasher filling? Home water pressure should be 20
to 120 psi (138 to 828 kPa) for proper dishwasher fill. A
booster pump on the water supply can be added if
pressure is too low.
Are high suds slowing the wash arm? Never use soap or
laundry detergents. Use recommended dishwasher
detergents only.
-.'.«sjwiwef» ini. V-
21
Spots and stains on dishes
Spotting and filming on dishes
Is your water hard or is there a high mineral content in
your water? Conditioning the final rinse water with a
liquid rinse aid helps eliminate spotting and filming.
Keep the rinse aid dispenser filled.
Is the water temperature too low? If needed, turn home
water heater up to ensure water entering dishwasher is
at least 120°F (49“C). Refer to the “Dishwasher
Efficiency Tips” section.
Did you use the correct amount of effective detergent?
Use recommended dishwasher detergents only. Referto
the “Detergent Dispenser” section. Never use less than
1 tb (15 g) per load. Detergent must be fresh to be
effective. Store detergent in a cool, dry area. Heavy soil
and/or hard water generally require ejctra detergent.
Is the home water pressure high enough for proper
dishwasher filling? Home water pressure should be 20
to 120 psi (138 to 828 kPa) for proper dishwasher fill. A
booster pump on the water supply can be added if
pressure is too low. '
NOTE: To remove spots and film from dishes, try a white
vinegar rinse. This procedure is intended for occasional
use only. Vinegar is an acid and using it too often could
damage your dishwasher.
1. Wash and rinse dishes. Use an air-dry or an energy
saving dry option. Remove all silverware or metal
items.
2. Put 2 cups (473 mL) white vinegar in a glass or
dishwasher-safe measuring cup on the bottom rack.
3. Run the dishwasher through a complete washing
cycle using an air-dry or an energy saving dry option.
Do not use detergent. Vinegar will mix with the wash
water.
Silica film or etching (siiica film Is a milky, rainbow-
colored deposit; etching is a cloudy film)
Sometimes there is a water/chemical reaction with
certain types of glassware. This is usually caused by
some combination of soft or softened water, alkaline
washing solutions, insufficient rinsing, overloading the
dishwasher, and the heat of drying. It might not be
possible to prevent the problem, except by hand
washing.
To slow this process use a minimum amount of
detergent but not less than 1 tb (15 g) per load. Use a
liquid rinse aid and underload the dishwasher to allow
thorough rinsing. Silica film and etching are permanent
and cannot be removed. Do not use heated drying.
White spots on cookware with non-stick finish
Has the dishwasher detergent removed cookware
seasoning? Reseason cookware after washing in the
dishwasher.
Brown stains on dishes and dishwasher Interior
Does your water have high iron content? Rewash dishes
using 1-3 tsp (5-15 mL) of citric acid crystals added to
the covered section of the detergent dispenser. Do not
use detergent. Follow with a Normal wash cycle with
detergent. If treatment is needed more often than every
other month, the installation of an iron removal unit is
recommended.
Black or gray marks on dishes
Are aluminum items rubbing dishes during washing?
Disposable aluminum items can break down in the
dishwasher and cause marking. Hand wash these items.
Remove aluminum markings by using a mild abrasive
cleaner.
Orange stains on plastic dishes or dishwasher
interior
Are large amounts of tomato-based foods on dishes
placed in the dishwasher? Stains gradually fade over
time. Regular use of heated drying will slow fading.
Stains will not affect dishwasher performance. Regular
use of a rinse cycle and an air-dry or energy-saving dry
option will reduce the likelihood of staining.
Dishes do not dry completely
Dishes are not dry
Did you load your dishwasher to allow proper water
drainage? Do not overload. Refer to the “Loading Your
Dishwasher” section. Use a liquid rinse aid to speed
drying.
Are the plastics wet? Plastics often need towel drying.
Is the rinse aid dispenser empty? Refer to the "Rinse Aid
Dispenser” section.
Did you use an air-dry or energy-saving dry option? Use
a heated drying option for dryer dishes.
Dishes are damaged during a cycle
I Chipping of dishes
Did you load the dishwasher properly? Load the dishes
and glasses so they are stable and do not strike together
from washing action. Minimize chipping by moving the
rack in and out slowly.
NOTE: Antiques, feather-edged crystal, and similar
types of china and glassware might be too delicate for
automatic dishwashing. Wash by hand.
Noises
I Grinding, grating, crunching or buzzing sounds
A hard object has entered the wash module (on some
models). The sound should stop when the object is
ground up.
22
In U.S.A. or Canada
for in-home major brand repair service:
Call 24 hours a day, 7 days a week
1-800-4-MY-HOME’“ (1-800-469-4663)
Para pedir servicio de reparación a domicilio - 1-800-676-5811
Au Canada pour tout le service - 1-877-LE-FOYERf“ (1-877-533-6937)
For the repair or replacement parts you need:
Call 6 a.m. - 11 p.m. CST, 7 days a week
PartsDirect“
1.800-366-part (1-800-366-7278)
www.sears.com/partsdirect
Para ordenar piezas con entrega a domicilio - 1-800-659-7084
For the location of a Sears Service Center in your area:
Call 24 hours a day, 7 days a week
1-800-488-1222
To purchase or inquire about a Sears Maintenance Agreement:
Call 7 a.m. - 5 p.m. CST, Monday - Saturday
1-800-827-6655
3384335
1999 Kenmore
* Registered Tredemarif/Trademark of Sears, Roebuck and Co., under licensee by Sears Canada Printed in U.S A
6/99
‘MacaRegistrada/nnaicadefàbricadeSears, Roebuck and Co., con licencia de Seaia Canada Impreso en los EE. UU.
' Marque déposée/marque de oommerce de Sears, Roebuck and Co., en vertu d’un porteur de licence par Sears Canada Imprimé aux É.-U.
Loading...
