KENMORE 592.8504 User Manual
Models / Modelos : 592.8504*
Use & Care Guide
Manuel D’utilisation Et D’entretien
English / Français
Kenmore
®
Microwave Hood Combination
Four à Micro-ondes à Hotte Intégrée
* = color number, nombre de couleurs
P/N DE68-03805B
Sears Canada Inc.
290 Young Street, suite 700, Toronto, Ontario, M5B SC3
www.sears.ca
59285049-0_DE68-03805B_EN+CFR.indb 1 2010-09-06 �� 8:56:02
2
Table of Contents
Microwave Hood Combination Warranty . . 3
Sears Service ....................... 4
Master Protection Agreements ..........4
IMPORTANT SAFETY INSTRUCTIONS ..... 6
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY ........................... 7
Getting the Best cooking results ........ 10
Testing your dinnerware or cookware ....10
Features .......................... 11
Oven Specications ..................11
Features ...........................13
Operating instructions ............... 14
Learn about your microwave oven ......14
Clock .............................14
Kitchen Timer .......................14
Options ...........................14
Turntable On/Off ...................15
Vent Fan ...........................15
Delay Off .........................15
Control Lock ........................15
Add 30 Sec ........................15
Light Set Timer ......................16
Light Hi/Nite/Off ...................16
Cooking at high power levels ..........17
Cooking at lower power levels .........17
Multi - stage cooking .................17
Cooking guide for power levels ........18
Sensor cooking guide ................19
Popcorn ...........................20
Pizza .............................20
Veggies ...........................20
Sensor Cook ........................21
Potato ............................21
Sensor Reheat ......................21
Time Cook .........................23
Favorite ...........................23
Warm & Hold ......................23
Snacks ............................24
Kids Meals .........................25
Soften/Melt ........................26
Auto Defrost ........................27
1 Lb Defrost ........................28
Cooking guide ......................29
Cooking utensils ................... 32
Microwave utensil guide ..............32
Care and Cleaning .................. 33
Care and Cleaning ..................33
Cleaning the grease lter .............33
Charcoal Filter replacement ...........34
Cooktop/Night Light replacement .......34
Oven Light replacement ..............35
Troubleshooting .................... 36
Troubleshooting guide ................36
59285049-0_DE68-03805B_EN+CFR.indb 2 2010-09-06 �� 8:56:02
3
Microwave Hood
Combination
Warranty
One Year Limited Warranty
When installed, operated and maintained
according to all instructions supplied with the
product, if this appliance fails due to a defect
in material or workmanship within one year
from the date of purchase, call 1-800-4-MYHOME® to arrange for free repair.
If this appliance is used for other than private
family purposes, this warranty applied for only
90 days from the date of purchase.
This warranty covers only defects in material
and workmanship. Sears will NOT pay for:
1. Expendable items that can wear out from
normal use, including but not limited to lters,
belts, light bulb, and bags.
2. A service technician to instruct the user in
correct product installation, operation or
maintenance.
3. A service technician to clean or maintain this
product.
4. Damage to or failure of this product if it
is not installed, operated or maintained
according to all instructions supplied with the
product.
5. Damage to or failure of this product
resulting from accident, abuse, misuse or use
for other than its intended purpose.
6. Damage to or failure of this product caused
by the use of detergents, cleaners, chemicals
or utensils other than those recommended in
all instructions supplied with the product.
7. Damage to or failure of parts or systems
resulting from unauthorized modications
made to this product.
Disclaimer or implied warranties; limitations
of remedies
Customer’s sole and exclusive remedy under
this limited warranty shall be product repair as
provided herein. Implied warranties, including
warranties of merchantability or tness for a
particular purpose, are limited to one year or
the shortest period allowed by law. Sears shall
not be liable for incidental or consequential
damages. Some states and provinces do not
allow the exclusion or limitations on the duration
of implied warranties of merchantability or
tness, so these exclusions or limitations may not
apply to you.
This warranty applied only while this appliance
is used in the United States.
This warranty gives you specic legal rights,
and you may also have other rights which vary
from state to state.
Sears Canada Inc.
290 Young Street, suite 700, Tronto, Ontario,
M5B 2C3
59285049-0_DE68-03805B_EN+CFR.indb 3 2010-09-06 �� 8:56:02
4
Master Protection Agreements
Congratulations on making a smart
purchase.
Your new Kenmore® product is designed
and manufactured for years of dependable
operation.
But like all products, it may require preventive
maintenance or repair from time to time.
That’s when having a Master Protection
Agreement can save you money and
aggravation.
The Master Protection Agreement also helps
extend the life of your new product. Here’s
what the Agreement* includes:
Parts and labor needed to help keep
products operating properly under normal
use, not just defects. Our coverage goes
well beyond the product warranty. No
deductibles, no functional failure excluded
from coverage— real protection.
Expert service by a force of more
than 10,000 authorized Sears service
technicians, which means someone you can
trust will be working on your product.
Unlimited service calls and nationwide
service, as often as you want us, whenever
you want us.
“No-lemon” guarantee – replacement
of your covered product if four or more
product failures occur within twelve months.
Product replacement if your covered
product can’t be xed.
Annual Preventive Maintenance Check at
your request – no extra charge.
Fast help by phone – we call it Rapid
Resolution – phone support from a Sears
representative on all products. Think of us
as a “talking owner’s manual.”
Sears Service
Power surge protection against electrical
damage due to power uctuations.
$250 Food Loss Protection annually
for any food spoilage that is the result
of mechanical failure of any covered
refrigerator or freezer.
Rental reimbursement if repair of
your covered product takes longer than
promised.
10% discount off the regular price of any
non-covered repair service and related
installed parts.
Once you purchase the Agreement, a simple
phone call is all that it takes for you to schedule
service. You can call anytime day or night, or
schedule a service appointment online.
The Master Protection Agreement is a risk free
purchase. If you cancel for any reason during
the product warranty period, we will provide
a full refund. Or, a prorated refund anytime
after the product warranty period expires.
Purchase your Master Protection Agreement
today!
Some limitations and exclusions apply. For
prices and additional information in the
U.S.A. call 1-800-827-6655.
* Coverage in Canada varies on some items.
For full details call Sears Canada at 1-888Kenmore.
Sears Installation Service
For Sears professional installation of home
appliances, garage door openers, water
heaters, and other major home items, in the
U.S.A. or Canada call 1-800-4-MY-HOME®.
59285049-0_DE68-03805B_EN+CFR.indb 4 2010-09-06 �� 8:56:02
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
5
WARNING
Improper use of the grounding plug can result
in a risk of electric shock.
GROUNDING
INSTRUCTIONS
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire for the electrical
current. This appliance is equipped with a cord
that includes a grounding wire and a grounding
plug. The plug must be plugged into an outlet
that is properly installed and grounded. See
Installation Instructions.
This appliance must be connected to a
grounded, metallic, permanent wiring system or
an equipment grounding conductor should be
run with the circuit conductors and connected to
the equipment grounding terminal or lead on
the appliance.
Consult a qualied electrician or servicer if
grounding instructions are not completely
understood, or if doubt exists as to whether the
oven is properly grounded.
Do not use an extension cord. If the product power
cord is too short, have a qualied electrician
install a three-slot receptacle. This oven should
be plugged into a separate 60 Hertz circuit with
the electrical rating as shown in specications
table. When the oven is on a circuit with other
equipment, an increase in cooking times may be
required and fuses can be blown.
Microwave operates on standard household
current, 110- 120V.
FEDERAL
COMMUNICATIONS
COMMISSION RADIO
FREQUENCY INTERFERENCE
STATEMENT (U.S.A. ONLY)
This equipment generates and uses ISM
frequency energy and if not installed and
used properly, that is in strict accordance with
the manufacturer’s instructions, may cause
interference to radio and television reception. It
has been type tested and found to comply with
limits for ISM Equipment pursuant to part 18
of FCC Rules, which are designed to provide
reasonable protection against such interference
in a residential installation.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following:
Reorient the receiving antenna of the radio •
or television.
Relocate the microwave oven with respect •
to the receiver.
Move the microwave oven away from the •
receiver.
Plug the microwave oven into a different •
outlet so that the microwave oven and the
receiver are on different branch circuits.
The manufacturer is not responsible for any
radio or television interference caused by
unauthorized modication to this microwave
oven. It is the responsibility of the user to
correct such interference.
59285049-0_DE68-03805B_EN+CFR.indb 5 2010-09-06 �� 8:56:02
6
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WHAT YOU NEED TO
KNOW ABOUT SAFETY
INSTRUCTIONS
Warning and Important Safety Instructions
appearing in this Use & Care Guide are not
meant to cover all possible conditions and
situations that may occur. Common sense,
caution, and care must be exercised when
installing, maintaining, or operating microwave.
Always contact your dealer, distributor, service
agent, or manufacturer about problems or
conditions you do not understand.
RECOGNIZE SAFETY
SYMBOLS, WORDS, LABELS
DANGER
Immediate hazards which WILL result in
severe personal injury or death.
WARNING
Hazards or unsafe practices which COULD
result in severe personal injury or death.
CAUTION
Hazards or unsafe practices which COULD
result in minor personal injury.
CAUTION
To avoid personal injury or property
damage, observe the following:
1. Do not deep fat fry in oven. Fat could
overheat and be hazardous to handle.
2. Do not cook or reheat eggs in shell or with
an unbroken yolk using microwave energy.
Pressure may build up and erupt. Pierce
yolk with fork or knife before cooking.
3. Pierce skin of potatoes, tomatoes,
and similar foods before cooking with
microwave energy. When skin is pierced,
steam escapes evenly.
4. Do not operate oven without load or food
in oven cavity.
5. Use only popcorn in packages designed
and labeled for microwave use. Popping
time varies depending on oven wattage.
Do not continue to heat after popping has
stopped. Popcorn will scorch or burn. Do
not leave oven unattended.
6. Do not use regular cooking thermometers
in oven. Most cooking thermometers contain
mercury and may cause an electrical arc,
malfunction, or damage to oven.
7. Do not use metal utensils in oven.
8. Never use paper, plastic, or other
combustible materials that are not intended
for cooking.
9. When cooking with paper, plastic, or
other combustible materials, follow
manufacturer’s recommendations on product
use.
10. Do not use paper towels which contain
nylon or other synthetic bers. Heated
synthetics could melt and cause paper to
ignite.
11. Do not heat sealed containers or plastic
bags in oven. Food or liquid could expand
quickly and cause container or bag to
break. Pierce or open container or bag
before cooking.
12. To avoid pacemaker malfunction, consult
physician or pacemaker manufacturer
about effects of microwave energy on
pacemaker.
59285049-0_DE68-03805B_EN+CFR.indb 6 2010-09-06 �� 8:56:03
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
7
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
A. DO NOT attempt to operate this oven with
the door open since open door operation
can result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
B. DO NOT place any object between the
oven front face and the door or allow soil
or cleaner residue to accumulate on sealing
surfaces.
C. DO NOT operate the oven if it is
damaged. It is particularly important that
oven door close properly and that there is
no damage to:
1. door (bent),
2. hinges and latches (broken or loosened),
3. door seals and sealing surfaces.
D. Oven should not be adjusted or repaired
by anyone except properly qualied
service personnel.
WARNING
Liquids such as water, coffee, or tea are
able to be overheated beyond the boiling
point without appearing to be boiling due to
surface tension of the liquid. Visible bubbling
or boiling when the container is removed
from the microwave oven is not always
present. THIS COULD RESULT IN VERY HOT
LIQUIDS SUDDENLY BOILING OVER WHEN
A SPOON OR OTHER UTENSIL IS INSERTED
INTO THE LIQUID. To reduce the risk of
injury to persons:
1. Do not overheat the liquid.
2. Stir the liquid both before and halfway
through heating it.
3. Do not use straight-sided containers with
narrow necks.
4. After heating, allow the container to
stand in the microwave oven for a short
time before removing the container.
5. Use extreme care when inserting a spoon
or other utensil into the container.
59285049-0_DE68-03805B_EN+CFR.indb 7 2010-09-06 �� 8:56:03
8
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING
When using electrical appliances, basic safety
precautions should be followed to reduce the
risk of burns, electric shock, re, or injury to
persons or exposure to excessive microwave
energy.
1. READ all instructions before using oven.
2. READ AND FOLLOW the specic
“PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY” on page 7
3. Install or locate this oven ONLY in
accordance with the installation instructions
in this manual.
4. Some products such as whole eggs and
sealed containers—for example, closed
glass jars—are able to explode and
SHOULD NOT be HEATED in this oven.
5. Use this oven ONLY for its intended use
as described in this manual. Do not use
corrosive chemicals or vapors in this oven.
This type of oven is specically designed to
heat, cook, or dry food. It is not designed
for industrial or laboratory use.
6. As with any appliance, CLOSE
SUPERVISION is necessary when used by
CHILDREN or INFIRM PERSONS.
7. See door cleaning instructions in the Care
and Cleaning section on page 33
8. Baby food jars shall be open when heated
and contents stirred or shaken before
consumption, in order to avoid burns.
9. DO NOT use this oven for commercial
purposes. It is made for household use only.
10. DO NOT heat baby bottles in oven.
11. DO NOT operate this oven if it has a
damaged cord or plug, if it is not working
properly, or if it has been damaged or
dropped.
12. This oven, including power cord, must
be serviced ONLY by qualied service
personnel. Special tools are required to
service oven. Contact nearest authorized
service facility for examination, repair, or
adjustment.
13. DO NOT cover or block lter or other
openings on oven.
14. DO NOT store this oven outdoors. DO NOT
use this product near water – for example,
near a kitchen sink, in a wet basement,
near a swimming pool or similar locations.
15. DO NOT immerse cord or plug in water.
16. Keep cord A WAY from HEATED surfaces.
17. DO NOT let cord hang over edge of table
or counter.
18. Clean the ventilating hood frequently.
19. DO NOT allow grease to accumulate on
the hood or lters.
20. Use care when cleaning the ventilating
hood lter. Corrosive cleaning agents such
as lye-based oven cleaners may damage
the lters.
21. When aming foods under the hood, turn
the fan on.
22. This oven is suitable for use above both gas
and electric cooking equipment 36 inches
or less wide.
23. This appliance must be grounded. Connect
only to properly grounded outlet. See
“GROUNDING INSTRUCTIONS” found on 5
page.
59285049-0_DE68-03805B_EN+CFR.indb 8 2010-09-06 �� 8:56:03
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
9
CAUTION
To avoid risk of re in the oven cavity:
a. DO NOT overcook food. Carefully attend oven when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c. If materials inside the oven ignite, keep oven door CLOSED, turn oven off and disconnect the
power cord, or shut off power at the fuse or circuit breaker panel.
d. DO NOT use the cavity for storage. DO NOT leave paper products, cooking utensils, or food
in the cavity when not in use.
59285049-0_DE68-03805B_EN+CFR.indb 9 2010-09-06 �� 8:56:03
10
Getting the Best cooking results
Testing your dinnerware or cookware
Test dinnerware or cookware before using. To test a dish for safe use, put it into oven with a
cup of water beside it. Cook at 100% cook power for one minute. If the dish gets hot, do not
use it.
Some dishes (melamine, some ceramic dinnerware, etc.) absorb microwave energy, becoming
too hot to handle and slowing cooking times. Cooking in metal containers not designed for
microwave use could damage the oven, as could containers with hidden metal (twist-ties, foil
lining, staples, metallic glaze or trim).
To get the best results from your microwave oven, read and follow the guidelines below.
Storage Temperature:
• Foods taken from the freezer or refrigerator take longer to cook than the
same foods at room temperature.
Size:
• Small pieces of food cook faster than large ones, and pieces similar in size and shape
cook more evenly. For even cooking, reduce the power when cooking large pieces of food.
Natural Moisture:
• Very moist foods cook more evenly because microwave energy is attracted to
water molecules.
Stir foods
• such as casseroles and vegetables from the outside to the center to distribute the heat
evenly and speed cooking. Constant stirring is not necessary.
Turn over foods like pork chops,
• baking potatoes, roasts, or whole cauliower halfway through the
cooking time to expose all sides equally to microwave energy.
Place delicate areas of foods,
• such as asparagus tips, toward the center of the dish.
Arrange unevenly shaped foods,
• such as chicken pieces or salmon steaks, with the thicker, meatier
parts toward the outside of the dish.
Shield, with small pieces of aluminum foil,
• parts of food that may cook quickly, such as wing tips
and leg ends of poultry.
Let It Stand:
• After the timed cooking period ends, let food stand inside or outside of the oven so
that it nishes cooking to the center and to avoid overcooking the outer edges. The length of
standing time depends on the density and surface area of the food. For standing time outside
the oven, cover the food with foil or a casserole lid.
Wrapping in waxed paper or paper towel:
• Sandwiches and many other foods containing
prebaked bread should be wrapped prior to microwaving to prevent drying out.
59285049-0_DE68-03805B_EN+CFR.indb 10 2010-09-06 �� 8:56:03
11
Features
Wire rack
The wire rack gives you extra space when
cooking in more than one container at the same
time.
CAUTION
To avoid risk of property damage:
Do not• use rack to pop popcorn.
Rack must be on the four plastic supports •
when used.
Use the rack only when cooking food on •
rack position.
Do not• cook with rack on oor of the
oven.
To use rack:
1. Place rack securely in the four plastic
supports.
Rack MUST NOT touch metal walls or back •
of microwave oven.
2. Place equal amounts of food both ABOVE
AND BELOW rack.
Amount of food must be approximately the •
same to balance out cooking energy.
IMPORTANT:
To avoid oven damage, • DO NOT store or use
the wire rack in this oven unless more than one
item is being cooked or a recipe calls for it.
Oven Specications
Power Supply 120 VAC, 60 Hz
Input Power 1,500W
Cooking Power 1,000W IEC 60705 Standard
Frequency 2,450 MHz
Rated Current 13.5 A
Outer Dimensions 29 7/8 (W) x 16 1/2 (H) x 15 1/8 (D)
Cavity Volume 1.9 Cu. Ft.
Net Weight 50.5 lbs. / 51.8 lbs. (85043 model)
Door Handle Window with
Metal Shield
Cooking Guide
Wire Rack
Door Safety
Lock System
Oven Control
Panel
Glass
Turntable
Model and Serial
Number Plate
59285049-0_DE68-03805B_EN+CFR.indb 11 2010-09-06 �� 8:56:03
12
FEATURES
59285049-0_DE68-03805B_EN+CFR.indb 12 2010-09-06 �� 8:56:03
FEATURES
13
Features
1. DISPLAY : The Display includes a clock and
indicators to tell you time of day, cooking
time settings and cooking functions selected.
2. POPCORN : Touch this pad when popping
popcorn in your microwave oven. The oven’s
sensor will tell the oven how long to cook
depending on the amount of humidity it
detects from the popcorn.
3. PIZZA : Touch this pad to reheat pizza. The
oven’s sensor will tell the oven how long to
cook depending on the amount of humidity
it detects.
4. VEGGIES : Touch this pad to cook fresh or
frozen vegetables. The oven’s sensor will
tell the oven how long to cook depending
on the amount of humidity it detects from
the vegetables.
5. SENSOR COOK : Touch this pad to cook
beverage, frozen dinner, frozen breakfast,
or chicken breast. The oven’s sensor will
tell the oven how long to cook depending
on the amount of humidity coming from the
food.
6. POTATO : Touch this pad to cook potatoes.
The oven’s sensor will tell the oven how
long to cook depending on the amount of
humidity it detects from the potato.
7. SENSOR REHEAT : Touch this pad to reheat
dinner plate, casserole, and pasta. The
oven’s sensor will tell the oven how long to
cook depending on the amount of humidity
coming from the food.
8. KIDS MEALS, SOFTEN/MELT, SNACKS :
Touch these pads to cook specic food.
9. AUTO DEFROST: Touch this pad to defrost
food by weight.
10. 1LB DEFROST : Touch this pad to defrost
1.0 pound of frozen food.
11. TIME COOK : Touch this pad to input
cooking time.
12 FAVORITE : Touch this pad to recall one
cooking instruction previously programmed
into memory.
13. WARM & HOLD : Touch this pad to keep
hot, cooked food warm in your microwave
oven for up to 99 minutes 99 seconds.
14. NUMBER : Touch number pads to enter
cooking time, power level, quantities, or
weights.
15. POWER LEVEL : Touch this pad to select a
cooking power level.
16. ADD 30 SEC : Touch this pad to set and
start cooking quickly at 100% power level.
17. TIMER : Touch this pad to set the kitchen
timer.
18. CLOCK : Touch this pad to enter the time of
day.
19. TURNTABLE ON/OFF : Touch this pad to
turn off the turntable. OFF will appear in
the display.
TURNTABLE ON/OFF is not available in
sensor cook and defrost modes.
20. OPTIONS : Touch this pad to change the
oven’s default settings.
21. START : Touch this pad to start a function.
If you open the door after oven begins
to cook, close the door and touch ENTER/
START pad again.
22. STOP : Touch this pad to stop the oven or to
clear all entries.
23. VENT ON/OFF : Touch this pad to turn the
fan on/off.
24. VENT 4 SPEED: Touch this pad to choose
one of 4 fan speeds.
25. VENT DELAY OFF : Touch this pad when
setting ventilation time (1, 3, 5, 10, 30
minutes).
26. LIGHT HI/NITE/OFF : Touch this pad to turn
on the cooktop light.
27. CONTROL LOCK : Touch and hold this pad
more than 3 seconds to lock the control
panel.
28. LIGHT SET TIMER : Touch this pad to set the
light timer.
59285049-0_DE68-03805B_EN+CFR.indb 13 2010-09-06 �� 8:56:03
14
Operating instructions
Learn about your microwave oven
This section introduces you to the basics you
need to know to operate your microwave oven.
Please read this information before use.
CAUTION
To avoid risk of personal injury or •
property damage, do not run oven
empty.
To avoid risk of personal injury or •
property damage, do not use stoneware,
aluminum foil, metal utensils, or metal
trimmed utensils in the oven.
Clock
Example: To set 8:00 AM.
1 Touch CLOCK pad.
2 Enter the time by using the
number pads.
3 Touch ENTER/ START pad.
4 Touch 1 for AM.
5 Touch START pad.
Kitchen Timer
You can use your microwave oven as a timer.
Use the Kitchen Timer for timing up to 99
minutes, 99 seconds.
Example: To set for 8 minutes.
1. Touch KITCHEN TIMER
pad.
2. Enter the time by using the
number pads.
3. Touch START pad.
When the time is over, you will hear beeps and
END will display.
Options
You can change the default values. See
following chart for more information.
No. Function No. Result
1
Weight mode
selected
12Lbs.
Kg.
2
Sound on/off
control
12Sound ON
Sound OFF
3
Clock display
control
1212HR
24HR
4 Display
1
2
3
Slow speed
Normal speed
Fast speed
5
Remind end
signal
12ON
OFF
6 Demo mode
12ON
OFF
7
Daylight
Saving time
12ON
OFF
Example: To change weight mode (from Lbs. to Kg).
1. Touch OPTIONS pad.
2. Touch number 1 pad.
3. Touch number 2 pad.
59285049-0_DE68-03805B_EN+CFR.indb 14 2010-09-06 �� 8:56:04
OPERATING INSTRUCTIONS
15
Turntable On/Off
For best cooking results, leave the turntable on.
It can be turned off for large dishes.
1. Touch TURNTABLE ON/
OFF pad to turn the
turntable on or off.
NOTES:
This option is • not available in sensor cook,
auto cook and defrost modes.
Sometimes the turntable can become hot •
to touch. Be careful touching the turntable
during and after cooking.
Do not operate oven if it is empty.•
Vent Fan
The VENT moves steam and other vapors from
the cooking surface.
Example: To set Level 2.
1. Touch ON/OFF pad. This
shows the last level until
you select the fan speed
level.
2. Touch 4 SPEED pad until
Level 2 appears in the
display.
3 Touch ON/OFF pad to turn
off fan when desired.
NOTES:
If the temperature gets too hot around the
microwave oven, the fan in the vent hood will
automatically turn on at the LEVEL 1 setting
to cool the oven. When this occurs, the fan
cannot be turned off manually. The fan will
automatically turn off when the internal parts
are cool.
The vent fan will operate only in LEVEL1-2
while the microwave is working.
Delay Off
Example: To turn off fan after 30 minutes for Level
2.
1. Touch ON/OFF pad.
2. Touch 4 SPEED pad until
Level 2 appears in the
display.
3. Touch DELAY OFF pad ve
times. AFTER 30 MINUTES
will appear in the display.
Control Lock
You may lock the control panel to prevent the
microwave from being accidentally started or
used by children.
The Control Lock feature is also useful when
cleaning the control panel. Control Lock
prevents accidental programming when wiping
the control panel.
Example: To set the control lock.
Touch and hold CONTROL
LOCK pad more than 3
seconds. CHILD LOCK ON
will appear in the display
window with two beeps.
Example: To cancel the control lock.
Touch and hold CONTROL
LOCK pad more than 3
seconds. LOCKED will
disappear and you will hear
two beeps.
Add 30 Sec
A time-saving pad, this simplied control lets
you quickly set and start microwave cooking.
Example: To set ADD 30 SEC for 2 minutes.
Touch ADD 30 SEC pad 4
times and touch START pad.
The oven begins cooking and
display shows time counting
down.
59285049-0_DE68-03805B_EN+CFR.indb 15 2010-09-06 �� 8:56:05
16
OPERATING INSTRUCTIONS
Light Set Timer
You can set the LIGHT to turn on and off
automatically at any time. The light comes on
at the same time every day until reset.
Example: Turn on 2:00 AM, turn off 7:00 PM.
12 hour clock mode.
1. Touch LIGHT SET TIMER
pad.
2. Enter the time you want the
LIGHT to turn on.
3. Touch START pad.
4. Touch 1 for AM.
5. Touch START pad.
6. Enter the time you want the
LIGHT to turn off.
7. Touch START pad.
8. Touch 2 for PM.
9. Touch START pad.
24 hour clock mode.
1. Touch LIGHT SET TIMER
pad.
2. Enter the time you want the
LIGHT to turn on.
3. Touch START pad.
4. Enter the time you want the
LIGHT to turn off.
5. Touch START pad.
To cancel the light timer.
1. Touch LIGHT SET TIMER
pad.
2. Touch 0 pad.
Light Hi/Nite/Off
Touch LIGHT HI/NITE/OFF
pad once for bright light,
twice for night light, or three
times to turn the light off.
59285049-0_DE68-03805B_EN+CFR.indb 16 2010-09-06 �� 8:56:05
OPERATING INSTRUCTIONS
17
Cooking at high power levels
Example: To cook food for 8 minutes 30 seconds at
100% power.
1. Enter the cook time.
2. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Cooking at lower power levels
HIGH power cooking does not always give
you the best results with foods that need
slower cooking, such as roasts, baked goods,
or custards. Your oven has 9 power settings in
addition to HIGH.
Example: To cook food for 7 minutes 30 seconds at
70% power.
1. Enter the cook time.
2. Touch POWER LEVEL pad.
3. Enter the power level.
4. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
See cooking guide for power levels, page 18.
IMPORTANT:
To avoid damge to the oven,• DO NOT store
or use the wire rack in this oven unless more
than one item is being cooked or a recipe
calls for it.
NOTE:
If the oven is set to cook for more than 20
minutes, it will automatically adjust itself to
70 percent power after 20 minutes to avoid
overcooking.
Multi - stage cooking
For best results, some recipes call for one
Power Level for a certain length of time, and
another Power Level for another length of time.
Your oven can be set to automatically change
from one power level to another for two
cooking stages, or for three stages.
Example: To cook food for 3 minutes at 90% power
and then 70% power for 7 minutes 30 seconds.
1. Enter the cook time.
2. Touch POWER LEVEL pad.
3. Enter the power level.
4. Enter the second cook time.
5. Touch POWER LEVEL pad.
6. Enter the power level.
7. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
NOTE:
You can set the second cook cycle to 0 power
to conveniently establish a period of standing
time within the oven.
59285049-0_DE68-03805B_EN+CFR.indb 17 2010-09-06 �� 8:56:06
18
OPERATING INSTRUCTIONS
Cooking guide for power levels
The power levels allow you to choose the best amount of heating energy for the food you are
cooking. Below are listed all the power levels, examples of foods best cooked at each level, and
the amount of microwave power you are using.
POWER
LEVEL
MICROWAVE
OUTPUT
USE
10 High 100 % Boil water.•
Cook ground beef or begin cooking roasts.•
Make candy.•
Cook fresh fruits and vegetables.•
Preheat browning dish.•
Reheat beverages.•
Bacon slices.•
9 90 % Reheat meat slices quickly.•
Saute onions, celery, and green pepper.•
8 80 % All reheating.•
Cook scrambled eggs.•
7 70 % Cook poultry or seafood.•
Cook breads and cereal products.•
Cook cheese dishes, veal.•
Cook cakes, mufns, brownies, cupcakes.•
6 60 % Cook pasta.•
5 50 % Cook meats.•
Cook custard.•
Cook spare ribs, rib roast, sirloin roast.•
4 40 % Cook less tender cuts of meat.•
Reheat frozen convenience foods.•
3 30 % Thaw meat, poultry, and seafood.•
Cook small quantities of food.•
Finish cooking casserole, stew, and some sauces.•
2 20 % Soften butter and cream cheese.•
Heat small amounts of food.•
1 10 % Soften ice cream.•
Raise yeast dough.•
0 0 % Standing time in oven.•
59285049-0_DE68-03805B_EN+CFR.indb 18 2010-09-06 �� 8:56:06
OPERATING INSTRUCTIONS
19
Sensor operating instructions
(Following page 20 ~ 22)
Sensor Cook allows you to cook most of your
favorite foods without selecting cooking times
and power levels. The display will indicate
the sensing period by scrolling the name of
the food category that you select. The oven
automatically determines required cooking
time for each food item. When the internal
sensor detects a certain amount of humidity
coming from the food, it will tell the oven how
much longer to cook. The display will show the
remaining heating time.
For best results when cooking by Sensor, follow
these recommendations:
1. Food cooked with the sensor system should
be at normal storage temperature.
2. Glass turntable and outside of container
should be dry to assure best cooking results.
3. Most foods should always be covered
loosely with microwavable plastic wrap,
waxed paper, or a lid.
4. Do not open the door or touch the STOP/
CLEAR pad during the sensing time. When
sensing time is over, the oven beeps and the
remaining cooking time will appear in the
display window. At this time you can open
the door to stir, turn, or rearrange the food.
See sensing chart on page 22.
IMPORTANT:
When using sensor cook, the oven must cool for
5 minutes between uses or food will not cook
properly.
Sensor cooking guide
Appropriate containers and coverings help
assure good Sensor cooking results.
1. Always use microwavable containers and
cover them with lids or vented plastic wrap.
2. Never use tight-sealing plastic covers. They
can prevent steam from escaping and cause
food to overcook.
3. Match the amount to the size of the
container. Fill containers at least half full for
best results.
4. Be sure the outside of the cooking container
and the inside of the microwave oven are
dry before placing food in the oven. Beads
of moisture turning into steam can mislead
the sensor.
NOTE:
If food is not thoroughly cooked or reheated
when using the sensor feature, complete using
a power level and cooking time. DO NOT
continue using the sensor pad.
59285049-0_DE68-03805B_EN+CFR.indb 19 2010-09-06 �� 8:56:06
20
OPERATING INSTRUCTIONS
Popcorn
POPCORN pad lets you pop commercially
packaged microwave popcorn. Pop only one
package at a time. For best results, use fresh
bags of popcorn.
Example: To pop popcorn.
1. Touch POPCORN pad.
2. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Recommended amounts: 3.0-3.5 ozs.•
CAUTION
DO NOT• leave microwave oven
unattended while popping corn.
When popping commercially packaged •
popcorn, remove the rack from the
oven;
Do not place the bag of microwave
popcorn on the rack or under the rack.
Pizza
The PIZZA pad lets you reheat one to four
slices of pizza without selecting cooking times
and power levels.
Example: To reheat 2 slices of pizza.
1. Touch PIZZA pad.
2. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
• Recommended amounts: 1-4 slices.
Veggies
VEGGIES pad has preset cooking times and
power levels power for 2 food categories:
Fresh, Frozen.
Example: To cook Frozen Vegetables.
1. Touch VEGGIES pad.
2. Choose food category.
3. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Category Touch Pad Number
Fresh 1
Frozen 2
• Recommended amounts: 1 to 4 servings.
59285049-0_DE68-03805B_EN+CFR.indb 20 2010-09-06 �� 8:56:07
OPERATING INSTRUCTIONS
21
Sensor Cook
Using SENSOR COOK pad lets you heat
common microwave-prepared foods without
needing to program cooking times and power
levels. SENSOR COOK has 4 preset food
categories: Beverage, Frozen Dinner, Frozen
Breakfast and Chicken Breast.
Example: To cook Frozen Breakfast.
1. Touch SENSOR COOK
pad.
2. Choose food category.
3. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Category Touch Pad Number
Beverage 1
Chicken Breast 2
Frozen Breakfast 3
Frozen Dinner 4
Recommended amounts:
Beverage 8 ozs. (1cup)
Chicken Breast 8-24 ozs.
Frozen Breakfast 4-8 ozs.
Frozen Dinner 8-14 ozs.
Potato
The POTATO pad lets you bake one to six
potatoes without selecting cooking times and
power levels.
Example: To cook 2 potatoes.
1. Touch POTATO pad.
2. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Recommended amounts: 1-6 potatoes, •
about 6-8 oz. each.
NOTES:
Cooking time is based on a 6-8 oz. potato.•
Before baking, pierce potato with fork •
several times.
If potatoes are not completely cooked, •
continue cooking using cooking time.
After baking, let stand for 5 minutes.•
Sensor Reheat
SENSOR REHEAT pad lets you heat foods
without needing to program cooking times and
power levels. SENSOR REHEAT has 3 preset
categories: Dinner Plate, Casserole and Pasta.
Example: To reheat Casserole.
1. Touch SENSOR REHEAT
pad.
2. Choose food category.
3. Touch START pad.
When the cook time is over, you will hear four
beeps and END will display.
Category Touch Pad Number
Casserole 1
Dinner Plate 2
Pasta 3
Recommended amounts:
Casserole 1-4 servings
Dinner Plate 1 serving
Pasta 1-4 servings
59285049-0_DE68-03805B_EN+CFR.indb 21 2010-09-06 �� 8:56:07
22
OPERATING INSTRUCTIONS
Sensor cook table
CATEGORY DIRECTIONS AMOUNT
Popcorn
Use only one microwave-only bag of popcorn at a time. Use
caution when removing and opening the hot bag from oven. Let
oven cool for at least 5 minutes before using again.
3.0 to 3.5
oz.
1 package
Potato
Prick each potato several times with fork. Place on turntable in
spoke-like fashion. Let stand 3-5 minutes. Let oven cool for at least
5 minutes before using again.
1 to 6
potatoes
VEGGIES
Fresh
Vegetables
Place fresh vegetables in microwave-safe ceramic, glass or plastic
dish and add 2-4 Tbs. water. Cover with lid or vented plastic wrap
during cooking and stir before standing. Let oven cool for at least
5 minutes before using again.
1 to 4
servings
Frozen
Vegetables
Place frozen vegetables in microwave-safe ceramic, glass or
plastic dish and add 2-4 Tbs. water. Cover with lid or vented
plastic wrap during cooking and stir before standing. Let oven cool
for at least 5 minutes before using again.
1 to 4
servings
Pizza
Put 1-4 slices of pizza on a microwave-safe plate with wide end
of slice toward the outside edge of the plate. Do not let slices
overlap. Do not cover. Let oven cool for at least 5 minutes before
using again.
1 to 4 Slices
Beverage
Use measuring cup or mug ; do not cover. Place the beverage
in the oven. After heating, stir well. Let oven cool for at least 5
minutes before using again.
Note:
Reheat times based on an 8 ounce cup. (1 cup.)•
Beverage heated with the beverage feature may be very hot.•
Remove container with care.•
8 oz.
(1 cup.)
Chicken Breast
Place chicken breasts on a microwave-safe plate and cover with
plastic wrap. Cook to an internal temperature of 170 degrees F.
Turn over during countdown time. Let stand 5 minutes. Let oven cool
for at least 5 minutes before using again.
8 to 24 oz.
Frozen
Breakfast
Follow package instructions for covering and standing. Use this
pad for frozen sandwich, breakfast entree, etc. Let oven cool for
at least 5 minutes before using again.
4 to 8 oz.
Frozen Dinner
Remove food from outer wrapping and follow box instructions for
covering and standing. Let oven cool for at least 5 minutes before
using again.
8 to 14 oz.
Sensor reheat table
CATEGORY DIRECTIONS AMOUNT
Dinner Plate
Use only pre-cooked, refrigerated foods. Cover plate with vented
plastic wrap or waxed paper, tucked under plate. If food is not as
hot as you prefer after heating with REHEAT, continue heating using
cooking time and power level. Do not continue cooking using the
Reheat pad.
Contents:
3-4 oz. meat, poultry or sh (up to 6 oz. with bone)•
1/2 cup starch (potatoes, pasta, rice, etc.)•
1/2 cup vegetables (about 3-4 oz.)•
1 serving
(1 plate)
Casserole Cover plate with lid or vented plastic wrap. If food is not as hot as
you prefer after heating with REHEAT, continue heating using time
and power level. Do not continue cooking using the Reheat pad.
Stir foods once before serving.
Contents:
Casserole-refrigerated foods. (Examples: Lasagna and beef •
stew.)
Pasta-Canned spaghetti and ravioli, refrigerated foods.•
1 to 4
servings.
Pasta
59285049-0_DE68-03805B_EN+CFR.indb 22 2010-09-06 �� 8:56:07
Loading...
