22-91062/4/9, 90043
22-9106X.PDF
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specifications without
notice. Consult installation instructions packed with the product for
final dimensional data. For complete warranty information, contact
your local Sears Contract Sales Account Manager.
Effective 08/07/06
16406
Selection
White 22-91062
Stainless 22-90043
Bisque 22-91064
Black 22-91069
Oven Features
Oven Capacity (cu. ft.) 4.6
Cleaning System Manual-Clean
Electronic Dial/Oven Controls Easy Set™105
Automatic Oven Shutoff •
Broiling System Hi/Norm/Lo
Total Adjustable Oven Racks 2
Broiler Pan and Grill Mail-In Offer
Oven Light •
Removable Door* •
Window X-Large
Deluxe Reach-Through Handle •
Oven Interior WxHxD (Inches) 23 x 18 13/
16
x 19 3/
16
Cooktop Features
Element Type Coil
8-in. (Watts) 2@2,100
6-in. (Watts) 2@1,250
Dishwasher-Safe Knobs •
Removable Knobs •
Removable Drip Pans Chrome
Upswept Cooktop •
Lift-Up Cooktop •
Cooktop On Indicator Light •
General Features
Drawer Storage
Power Rating (kW) @ 240V/208V 10.0/7.5
Bake/Broil @ 240V Watts) 2,600/3,000
Bake/Broil @ 208V Watts) 1,950/2,250
Breaker/Copper Wire Size (240V) 40/8
Shipping Weight (Approx. Lbs.) 150
Warranty
1-Year Limited Warranty –
Entire Appliance Parts & Labor
If used for other than private family purposes, warranty applies for only
90 days.
*22-91062/4/9: painted door; 22-90043: glass door
30-Inch Manual-Clean Coil Range
page 1 of 1
All ranges are equipped with an
Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
22-91062 – White
22-90043 – Stainless
22-91064 – Bisque
22-91069 – Black
• 4.6 cu. ft. manual-clean porcelain oven
with two racks
• Two 8" @ 2,100W and two 6" @1,250W
coil elements
• Easy Set
™
105 electronic oven controls
• Chrome drip pans
• Lift-up porcelain cooktop
• Removable door with extra large
window (22-91062/4/9: painted door;
22-90043: glass door)
• Similar model 22-91072/4/9
also available
Range Cords for Electric Ranges
Order Wire Length
22-49614 3 4 ft.
22-49616 3 6 ft.
22-49624* 4 4 ft.
22-49626* 4 6 ft.
*Complies with 1/1/96 NEC code revision
for new construction and remodeling
22-49624
22-49626
22-49614
22-49616
Dimensions, Inches (+/
–
1
/8")
ABCD
22-91062/4/9 301/8473/4445/830
44 3/4"
Door Open
C
Door Open
29 7/8"
36"
47
3
/4"
max.Bmax.
30 1/8"A
25 3/4"
28 13/32"
with
Handle
30"
30"D
13"
18"
Min. to
cabinets on
either side
of range
36"
1"
Min. to wall on
either side of
range above
36" height.
30"
min.
0" clearance
below cooking
top and at
rear of range
Max. depth for
cabinets above
range top
25"
Dashed cubed area shows where the
electrical outlet must be installed for
flush to the wall installation.
All dimensions for electrical outlet
location are maximum.
Model Overall Console Controls Door Drawer Sides Handle Surface Drip Pans
22-91062 White White White White White White White White Chrome
22-90043 Stainless Black Black Stainless Stainless Black Black Black Chrome
22-91064 Bisque Bisque Bisque Bisque Bisque Bisque Bisque Bisque Chrome
22-91069 Black Black Black Black Black Black Black Black Chrome
Centerline
of range
11"
22"
6"
2 5/8" for models equipped
with warming drawer.
3 1/2" for models equipped
with storage drawer.
Wall
Edge
