Kenmore 110.2477*, 110.2478*, 110.2479*, 110.2481*, 110.2482* Feature Sheet

Models/Modelos/Modèles 110.2477 , 2478 , 2479 , 2481 , 2482 , 2483 , 2489 , 2490 , 2492 , 2493 , 2590= color number, número de color, numéro de couleur

WASHER CYCLE DESCRIPTIONS

This information covers several different models. Your washer may vary from the model shown and may not have all the cycles and features described.

Water Level Control

Adjust to load size. Clothes should move freely. To change to a higher water level after agitating starts, you may turn knob to desired setting. On models with Variable Water Level Control, you should turn the knob to Reset, then to desired setting.

Water Temperature Control

You should select the wash/rinse water temperature based on the type of load you are washing. Always use the warmest wash water safe for the fabric and follow garment label instructions. Some models have AUTO TEMPERATURE CONTROL (ATC). ATC electronically senses and maintains a uniform water temperature by regulating the temperature of incoming hot and cold water.

On models without AUTO TEMPERATURE CONTROL (ATC) that do have a Warm/Warm temperature setting, the warm wash will be followed by an “Energy Saving” cold rinse followed by warm spray rinses. This saves energy while providing the same effective rinse performance.

Speeds Control

WASH/	LOAD TYPE	AGITATE/
SPIN SPEED		SPIN SPEED
Heavy Duty	Sturdy or heavily	High-speed
	soiled loads	agitation/
		High-speed spin
Normal	Normally soiled	Low-speed agitation/
	cottons & linens	High-speed spin
Delicate	Washable knits &	Low-speed agitation/
	permanent press	Low-speed spin
	fabrics
Handwash/	Lingerie &	Extra-low speed
Casual	loosely knit	agitation/
	items	Low-speed spin
Handwash Plus	Hand washable	Extra-low speed
Fine Delicates	and special care	agitation/Soak/
	items	Low-speed spin

8537393A

Cycle Selections continued on next page

Cycle Selector (Timer) Control

Permanent Press I

A load cooling spray rinse reduces wrinkling.

Permanent Press II

During the wash cycle, the timer reaches PAUSE, and the washer cools down the load by replacing some of the wash water with rinse water. This helps to reduce wrinkling.

Ultra Clean

You may select this cycle for most loads.

Prewash

Helps to remove heavy soils and stains that need pretreatment. This cycle should be followed by an Ultra Clean or Permanent Press cycle with additional detergent.

Automatic 2nd Rinse

Removes excess detergent residue. May be automatically added to the Ultra Clean or Permanent Press cycles. Set the RINSE OPTIONS Control to 2nd Rinse before you start the washer. You won’t have to come back later to select a second rinse.

Soak

Features agitation followed by unlimited soak time to help remove heavy soils and stains that need pretreatment. After the soaking has finished, you should reset the washer to a Spin setting to remove water. The Soak cycle should be followed by an Ultra Clean or Permanent Press cycle with additional detergent.

Rinse & Spin

May be used when an extra rinse is needed to remove additional detergent residue. Set WATER LEVEL Control, then WATER TEMPERATURE Control. Set RINSE OPTIONS Control to One Rinse and set the SPEEDS Control. You should then set Cycle Selector (Timer) Control to a Rinse setting.

Spin Only

A drain and spin may help shorten drying times for some fabrics by removing excess water. Set RINSE OPTIONS Control to One Rinse and set the SPEEDS Control. You should then set Cycle Selector (Timer) Control to a Spin setting.
