Kenmore 110.1571*, 110.1572*, 110.1573*, 110.1584*, 110.1585* Feature Sheet

Models/Modelos/Modèles 110.1571✼, 1572✼, 1573✼, 1584✼, 1585✼, 1586✼
✼ = color number, número de color, numéro de couleur

WASHER CYCLE DESCRIPTIONS

This information covers several different models. Your washer may vary from the model shown and may not have all the cycles and
features described.

Water Level Control

Adjust to load size. Clothes should move freely. To change to a
higher water level after agitating starts, you may turn knob to
desired setting. On models with Variable Water Level Control, you
should turn the knob to Reset, then to desired setting.

Water Temperature Control

Temperatures in this Energy Star washer differ from temperatures
you may be used to in conventional washers. They are designed
to provide maximum energy efficiency while delivering optimal
cleaning results.

You should select the wash/rinse water temperature based on the
type of load you are washing. Always use the warmest wash
water safe for the fabric and follow garment label instructions.
Some models have AUTO TEMPERATURE CONTROL (ATC). ATC
electronically senses and maintains a uniform energy saving
water temperature by regulating the temperature of incoming hot
and cold water.

Speeds Control

WASH/
SPIN SPEED

Heavy Duty Sturdy or heavily

Normal Normally soiled

Delicate Washable knits &

Handwash/
Casual

LOAD TYPE AGITATE/

soiled loads

cottons & linens

permanent press
fabrics

Lingerie &
loosely knit
items

SPIN SPEED

High-speed
agitation/
High-speed spin

Low-speed agitation/
High-speed spin

Low-speed agitation/
Low-speed spin

Extra-low speed
agitation/
Low-speed spin

8543668

Continued on next page

Cycle Selector (Timer) Control

Permanent Press I

A load cooling spray rinse reduces wrinkling.

Automatic 2nd Rinse

Removes excess detergent residue. May be automatically added
to the Ultra Clean or Permanent Press I cycles. Set the RINSE
OPTIONS Control to 2nd Rinse before you start the washer. You
won’t have to come back later to select a second rinse.

Ultra Clean

You may select this cycle for most loads.

Prewash

Helps to remove heavy soils and stains that need pretreatment. This
cycle should be followed by an Ultra Clean or Permanent Press I
cycle with additional detergent.

Soak

Features agitation followed by unlimited soak time to help
remove heavy soils and stains that need pretreatment. After the
soaking has finished, you should reset the washer to a Spin
setting to remove water. The Soak cycle should be followed by an
Ultra Clean or Permanent Press I cycle with additional detergent.

Rinse & Spin

May be used when an extra rinse is needed to remove additional
detergent residue. Set WATER LEVEL Control, then WATER
TEMPERATURE Control. Set RINSE OPTIONS Control to One
Rinse, and set the SPEEDS Control. You should then set Cycle
Selector (Timer) Control to a Rinse setting.

Spin Only

A drain and spin may help shorten drying times for some fabrics
by removing excess water. Set RINSE OPTIONS Control to One
Rinse, and set the SPEEDS Control. You should then set Cycle
Selector (Timer) Control to a Spin setting.
