Model 7705 Control Module
Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
(440) 248-0400
Fax: (440) 248-6168
www.keithley.com
User’s Guide
Introduction
t^okfkd The information contained in this packing sheet is intended for use by qualified service
personnel only. Do not perform these procedures unless qualified to do so. Failure to
recognize and observe normal safety precautions could result in personal injury or
death.
This document contains information specific to the Model 7705 control module. If you have any questions after reviewing this
information, please contact your local Keithley representative or our Applications Engineers at 1-888-KEITHLEY
(1-888-534-8453, U.S. only) or Telefax: 440-498-2990 (Instrument Products).
The Model 7705 is a 40-channel, single-pole relay module with the following features:
• 40 Independent Form A switches
• Quick-disconnect 50 pin D-shell connector (2 × DB-50)—use with Model 7788.
Connection and Wiring Information
• Designed specifically for use with Keithley’s Model 2700/2750/2701 Systems.
klqb The 7705 module can be used with Keithley Models 2700, 2701, and 2750. All references to the
Model 27xx apply to the Models 2700, 2701, and 2750.
t^okfkd Before operating the Model 27xx with an accessory card, verify that the card is properly
installed and the mounting screws are tightly fastened. If the mounting screws are not
properly connected, an electrical shock hazard may be present.
Connection information
Keep the following in mind when using the Model 7705 module:
• The 7705 module is a non-measurement card. No channels are connected to the internal DMM (the channels cannot
be connected to the backplane).
• Multiple channel operation should be used to close channels on the 7705 module. For remote operation, the
ROUT:MULT commands are used to close channels.
• For remote operation, system (single) channel operation (ROUT:CLOS <list> command) can be used to close
7705
module channels. However, only the specified channel will be closed. All other channels on the card will be
open.
PA-696 Rev. D / October 2006
• Front panel system (single) channel operation cannot be used to close channels on this module. For front panel
operation, system channel operation will cause message “NO MEAS CARD” to be displayed.
• In order to perform measurements, you must use the front panel inputs of the 27xx mainframe. You can still use the
7705 module to control external circuits.
klqb For details on multiple channel operation, refer to Section 2 of the Model 27xx User’s Manual.
• Although the Model 7705 relays are the latching type (relays hold their state even after power has been removed),
all relay states are set to open a few seconds after either a power cycle or a *RST command is issued.
Simplified schematic for Model 7705
Card configuration—connections
t^o k f k d The information in this section is intended for qualified service personnel. Do not
attempt to perform this procedure unless qualified to do so.
Do not exceed the maximum specifications for the Model 7705 module.
klqb When looking at the rear connectors of the Model 7705 module, the connector on the left is P1000
and the connector on the right is P1001.
Model 7705 Pinouts
P1000
17
33
Channel 1
IN
OUT
(Channels 2–39)
IN
Channel 40
OUT
1
18
17
33
P1001
1
18
50
34
Channels 1–20 Channels 21–40
50
34
2
Ta b le 1
Model 7705 channel designations
P1000 P1001
CH PIN CH PIN CH PIN CH PIN CH PIN CH PIN
1 IN 6 8 IN 25 15 IN 39 21 IN 6 28 IN 25 35 IN 39
1 OUT 8 8 OUT 26 15 OUT 40 21 OUT 8 28 OUT 26 35 OUT 40
2 IN 10 9 IN 27 16 IN 41 22 IN 10 29 IN 27 36 IN 41
2 OUT 12 9 OUT 28 16 OUT 42 22 OUT 12 29 OUT 28 36 OUT 42
3 IN 14 10 IN 29 17 IN 43 23 IN 14 30 IN 29 37 IN 43
3 OUT 16 10 OUT 30 17 OUT 44 23 OUT 16 30 OUT 30 37 OUT 44
4 IN 17 11 IN 31 18 IN 45 24 IN 17 31 IN 31 38 IN 45
4 OUT 18 11 OUT 32 18 OUT 46 24 OUT 18 31 OUT 32 38 OUT 46
5 IN 19 12 IN 33 19 IN 47 25 IN 19 32 IN 33 39 IN 47
5 OUT 20 12 OUT 34 19 OUT 48 25 OUT 20 32 OUT 34 39 OUT 48
6 IN 21 13 IN 35 20 IN 49 26 IN 21 33 IN 35 40 IN 49
6 OUT 22 13 OUT 36 20 OUT 50 26 OUT 22 33 OUT 36 40 OUT 50
7 IN 23 14 IN 37 27 IN 23 34 IN 37
7 OUT 24 14 OUT 38 27 OUT 24 34 OUT 38
Power limits
`^rqflk To prevent damage to the card, do not exceed the maximum signal level specifications of
the card. For reactive loads, be sure to use voltage clamping and current limiting as
explained in the “Reactive loads” paragraph.
Maximum signal levels
`^rqflk To prevent overheating or damage to the relays, never exceed the following maximum
signal levels: 300V (DC or RMS) between any two inputs or chassis, 60W (DC, resistive),
125VA (AC, resistive), or 2A switched.
Reactive loads
Model 7705 operation is specified for resistive loads (see “Typical connections—indicator lamp, alarm, and relay” figure).
Reactive loads require voltage clamping (for inductive loads) and current surge limiting (for capacitive loads) to prevent
damage to the relays and to external circuitry. For additional information, refer to the Model 2700/2750/2701 User’s manual.
3
Wire sizes
Make all connections using correct wire size (up to 20 AWG). Use Model 7788 (DB-50 kit) to provide for a high quality
connection to the Model 7705 module. Also, make sure to add supplementary insulation around the harness for voltages above
42V peak (see “Supplementary insulation” figure).
Typical connections—indicator lamp, alarm, and relaySupplementary insulation
Model 7705
IN 1
OUT 1
Alarm
Relay
Indicator
Lamp
Supplementary
Insulation
5V
12V
30V
IN 2
IN 3
IN 4
IN 5
IN 6
OUT 2
OUT 3
OUT 4
OUT 5
OUT 6
Equivalent circuit
Connection log
Make a copy of Table 2 and affix it to the cover of the Model 7705. Use this to record connection information and channel
descriptions as needed.
4
Ta b le 2
Connection Log Model 7705
Channel Color Description Description Color Channel
1 IN IN 21
OUT OUT
2 IN IN 22
OUT OUT
3 IN IN 23
OUT OUT
4 IN IN 24
OUT OUT
5 IN IN 25
OUT OUT
6 IN IN 26
OUT OUT
7 IN IN 27
OUT OUT
8 IN IN 28
OUT OUT
9 IN IN 29
OUT OUT
10 IN IN 30
OUT OUT
11 IN IN 31
OUT OUT
12 IN IN 32
OUT OUT
13 IN IN 33
OUT OUT
14 IN IN 34
OUT OUT
15 IN IN 35
OUT OUT
16 IN IN 36
OUT OUT
17 IN IN 37
OUT OUT
18 IN IN 38
OUT OUT
19 IN IN 39
OUT OUT
20 IN IN 40
OUT OUT
5
6
GENERAL
RELAY SWITCH CONFIGURATION: 40 independent channels of 1-pole
switching. Isolated from internal DMM.
CONTACT CONFIGURATION: 1 pole Form A.
RELAY TYPE: Latching electromechanical.
CONNECTOR TYPE: Two 50-pin female D-sub connectors.
INPUTS
MAXIMUM SIGNAL LEVEL: 300VDC or rms, 2A switched, 60W (DC,
resistive), 125VA (AC, resistive).
CONTACT LIFE: Cold Switching: 10
8
closures.
At Maximum Signal Levels: 10
5
closures.
CHANNEL RESISTANCE (per conductor): <1Ω.
CONTACT POTENTIAL: ≤4μV per contact.
OFFSET CURRENT: <100pA.
ACTUATION TIME: 3ms.
ISOLATION: Channel to Channel: >10
9
Ω, <50pF.
Common Mode: >10
9
Ω, <100pF.
CROSSTALK (1MHz, 50Ω load): <–35dB.
INSERTION LOSS (50Ω source, 50Ω load): <0.3dB below 1MHz, <3dB
below 10MHz.
COMMON MODE VOLTAGE: 300V between any terminal and chassis.
ENVIRONMENTAL
OPERATING ENVIRONMENT:Specified for 0°C to 50°C.
Specified to 80% R.H. at 35°C.
STORAGE ENVIRONMENT: –25°C to 65°C.
WEIGHT: 0.45kg (1 lb).
7705 40-Channel Control Module
Channel 1
(Channels 2–39)
Channel 40
IN
OUT
IN
OUT
This page intentionally left blank.
12/04
Specifications are subject to change without notice.
All Keithley trademarks and trade names are the property of Keithley Instruments, Inc.
All other trademarks and trade names are the property of their respective companies.
A GREATER MEASURE OF CONFIDENCE
Keithley Instruments, Inc.
Corporate Headquarters • 28775 Aurora Road • Cleveland, Ohio 44139 • 440-248-0400 • Fax: 440-248-6168 • 1-888-KEITHLEY (534-8453) • www.keithley.com
Loading...
