Integra Series integrated switching, measurement, and datalogg ing solutions
DIGITAL MULTIMETERS & SYSTEMS
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
2700, 2701,
2750
Multimeter/Data Acquisition/
Switch Systems
Integra Series systems (2700, 2701, 2750) combine precision measurement, switching, and
control in a single, tightly integrated enclosure
for either rack-mounted or benchtop applications. These cost-effective, high performance test
platforms offer affordable alternatives to separate DMMs and switch systems, dataloggers/
recorders, plug-in card data acquisition equipment, and VXI/PXI systems. The Integra Series
plug-in switching and control modules offer
unmatched flexibility and testing efficiency for a
wide range of industries and applications.
System builders can create test solutions with a
combination of channel count, cost per channel,
and system performance unmatched by any
other single-box measurement system. The input
modules provide the flexibility to vary the channel count from 20 to 200 (2-pole), apply a stimulus to the device under test, route signals, control system components, and make precision
measurements with up to 14 functions. Robust
digital I/O capabilities can be used for triggering,
handshaking with other automation equipment,
and alarm limit outputs. Scan rates of up to 500
channels/second (up to 3500 readings/second
on a single channel) will increase test
productivity.
Fast Setup and Operation
The Integra systems are fully integrated, off-the-shelf measurement and control systems. Their DMMlike interfaces make it easy for users to collect data and/or perform troubleshooting within minutes
of installation and startup. Once sensor or DUT leads are hooked to the instrument’s input, use the
front panel controls to select the measurement function, range, filtering, scaling, trigger source, scanning sequence, alarms, and more. The free ExceLINX-1A software makes it easy to configure and use
the system in a graphical “point-and-click” environment. This gives developers the basic tools needed
to create a simple application without writing program code.
The Advantage of Integrated Design
The Integra systems offer a variety of advantages
over existing solutions for ATE and data acquisition applications. For example, their flexible
modular architecture and integrated measurement, switching, and control capabilities save
rack space by reducing the number of separate
instruments needed. This design also simplifies
expanding the system as the number of channels
grows or re-purposing it as new test requirements evolve. Integrated signal conditioning,
scaling, stimulus, filtering and I/O capabilities
eliminate the need for external circuitry when
designing and building data acquisition systems.
The Integra systems offer accuracy and repeatability superior to plug-in data acquisition boards,
while providing faster test times than typical
DMM/switch systems. This makes it possible to
combine higher test yields with higher test
throughput.
• Combines functions of DMM,
switch system, and datalogger
• True 6
1
⁄2-digit (22-bit) resolution
• Choice of 12 switch/control
plug-in modules
• Up to 200 differential input
channels (with 300V isolation)
for measurement and control
• Convenient front panel inputs
• Free LabVIEW
™
, LabWindows/
CVI, Visual Basic, C/C++, and
TestPoint
™
drivers (IVI style)
• Ethernet, GPIB, RS-232
communications capabilities
• Free ExceLINX
™
-1A datalogging
software
ACCESSORIES AVAILABLE
2750-321A Extra slot cover
7007-1 Shielded IEEE-488 Cable, 1m (3.3 ft.)
(Models 2700, 2750 only)
7007-2 Shielded IEEE-488 Cable, 2m (6.6 ft.)
(Models 2700, 2750 only)
7788 50-Pin D-Shell Connector Kit (2 each)(for Models
7703, 7705 Modules w/D-sub Connectors)
7789 50-Pin/25-Pin D-Shell Kit (1 each)
7790 50-Pin Male, 50-Pin Female, and 25-Pin Male IDC
D-Shell Connector Kit (1 each) (Ribbon Cable
not Included)
7797 Calibration Extender Board (for Model 2750)
7705-MTC-2 50-Pin Male to Female D-Sub Cable, 2m
7707-MTC-2 25-Pin Male to Female D-Sub Cable, 2m
KPCI-488LP IEEE-488 Interface/Controller for the PCI Bus
(Models 2700, 2750 only)
KPXI-488 IEEE-488 Interface Board for the PXI Bus (Models
2700, 2750 only)
KUSB-488A IEEE-488 USB-to-GPIB Interface Adapter (Models
2700, 2750 only)
Integra Series integrated switching, measurement, and datalogg ing solutions
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
DIGITAL MULTIMETERS & SYSTEMS
Install up to five input modules in the 2750 mainframe (or up to two in the 2700 and 2701 mainframes). All switch/control modules are fully enclosed in impact-resistant plastic for exceptional
ruggedness. Three connector alternatives simplify connecting the modules to DUTs. Rugged D-sub
connectors allow quick, secure connections and are especially convenient when performing routine maintenance or when the system is installed in a rack. IDC ribbon cable adapters are supplied with the Model 7701, 7707, and 7709 modules for fast, uncomplicated hookups in production test and process monitoring applications. Oversize screw-terminal connectors simplify setup
in applications that require the greatest connection flexibility. Additional D-sub and IDC ribbon
cable connector kits and pre-wired cable assemblies are sold separately.
Ethernet
The Model 2701 offers a 10/100 BaseT Ethernet connection for high speed and long distance communication between a computer and a virtually infinite number of instruments. Any PC with an
Ethernet port can connect to a single Model 2701 in a point-to-point configuration, to multiple
Model 2701s through a hub, or to multiple Model 2701s distributed on a network.
The Model 2701 Ethernet port uses the industry-standard TCP/IP socket interface. This provides data
rates up 100Mbits/sec. and allows the instrument to be located up to 100 meters from the nearest
computer or network hub in hardwired systems and miles in wireless Ethernet systems. The maximum distances between a control PC and the instruments are limited only by the size of the network.
The instrument also provides a built-in diagnostic web page for easy remote access to the Model
2701. Entering the instrument’s IP address in the URL line of Microsoft Internet Explorer will allow
communication with and control of the Model 2701. This Web page allows users to read and set network parameters, such as IP address, subnet mask, gateway, MAC address, and calibration dates, and
to send commands to and query data from the Model 2701.
Temperature Capabilities
Integra Series mainframes support three major types of temperature sensors with built-in signal conditioning and 300V isolation: thermocouples, RTDs, and thermistors. To begin using a sensor, simply
hook it up and the instrument does the rest. If a thermocouple is broken or disconnected, the instrument will alert the operator. The mainframes also support three methods for cold-junction compensation (CJC): automatic (built-in), external (built-in), and simulated.
Ordering Information
2700 DMM, Data Acquisition,
Datalogging System w/2
Slots
2701 DMM, Data Acquisition,
Datalogging System w/2
Slots and Ethernet
Support
2750 DMM, Data Acquisition,
Switching, Datalogging
System w/5 Slots
Extended warranty, service, and
calibration contracts are available
.
Accessories Supplied
LabVIEW, LabWindows/ CVI,
Visual Basic, C/C++, and
TestPoint drivers; manual; and
Model 1751 Safety Test Leads.
Built-in measurement functions
include:
• DCV • ACV • DCI • ACI
• Resistance (2- or 4-wire, offset
compensation selectable)
• Dry circuit ohms (20mV clamp)
2750 only
• Temperature (with thermocouples, RTDs, or thermistors)
• Frequency/Period
• Continuity
TYPICAL APPLICATIONS
• Production test of electronic
products and devices
• Accelerated stress testing (AST)
• Process monitor and control
• Device characterization/R&D
• Low ohms, multichannel
measurements
2700, 2701,
2750
Multimeter/Data Acquisition/
Switch Systems
Integra Series integrated switching, measurement, and datalogg ing solutions
DIGITAL MULTIMETERS & SYSTEMS
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Web-Enabled Data Acquisition and
Control via Standard Ethernet
A built-in 10/100BaseTX Ethernet interface
makes the Model 2701 the best choice for distributed data acquisition applications that
demand stable, high precision measurements.
Just connect it directly to an Ethernet port—
there’s no need for additional interface cards,
proprietary cables, or software. The Model 2701
is a cost-effective solution for industrial monitoring and control applications. It combines remote
communications with high measurement precision for research and development tasks, such as
remote equipment diagnostics and economical
monitoring of lab environments.
Immediate alarm notification
independent of the PC
provided by built-in opencollector digital I/O lines for
control, external triggering, and
HI/LO alarm/limit outputs.
Fast and convenient
10/100BaseTXEthernet
with TCP/IP protocol
(Model 2701).
Built-in relay cycle
counters on each module
for ease of maintenance.
A variety of measurement and
control modules makes it simple
to mix, match, and change input
signals or control lines as
needed. Get up to 80 differential
channels and scanning rates of
up to 500 channels per second.
ExceLINX-1A is an easy-to-use add-in utility for Microsoft
®
Excel and Integra systems. No
programming is required; enter values quickly through pop-up menus and eliminate timeconsuming coding.
Built-in Web diagnostic tool (Model
2701 only) sends command strings and
receives data over the network. It also
reads and sets network parameters.
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
Integra Series integrated switching, measurement, and datalogg ing solutions
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
DIGITAL MULTIMETERS & SYSTEMS
Ordering Information
7700 20-Channel Differential
Multiplexer Module with
up to 50MHz Bandwidth,
Automatic CJC, and
Screw Terminals
7701 32-Channel Differential
Multiplexer Module with a
25- and 50-Pin Female D-Sub
Connector. Supplied with Male
IDC Ribbon Cable Connectors
7702 40-Channel Differential
Multiplexer Module w/Screw
Terminals
7703 32-Channel, High Speed,
Differential Multiplexer
Module with 2 50-Pin Female
D-Sub Connectors. Includes 2
Mating Connectors
7705 40-Channel, Single-Pole
Control Module with 2 50-Pin
Female D-Sub Connectors.
Includes 2 Mating Connectors
7706 All-in-One I/O Module: 20-
Channel Differential
Multiplexer w/Automatic CJC,
16 Digital Outputs, 2 Analog
Outputs, a Counter/Totalizer,
and Screw Terminals
7707 32-Channel Digital I/O
w/10-Channel Differential
Multiplexer Module with a 25Pin Female and 50-Pin Male DSub Connectors. Supplied with
Mating IDC Ribbon Cable
Connectors
7708 40-Channel Differential
Multiplexer Module
w/Automatic CJC and Screw
Terminals
7709 6x8 Matrix Module with 25-
and 50-Pin Female D-Sub
Connectors. Supplied with
Male IDC Ribbon Cable
Connectors
7710 20-Channel Solid-State/Long
Life Differential Multiplexer
w/Automatic CJC and Screw
Terminals
7711 2GHz 50Ω RF Module with
Dual 1x4 Configuration and
SMA Connections
7712 3.5GHz 50Ω RF Module with
Dual 1x4 Configuration and
SMA Connections
Extended warranty, service, and
calibration contracts are available
.
Rugged 50-pin D-sub connectors ensure
dependability and quick setup/teardown in
production test racks.
Screw terminals use oversize connectors for
easier, mistake-free wiring. Easy-to-use removable terminals are available on some models.
Software Solutions
Whether the task calls for a simple start-up package to acquire several channels of data or the tools to
create a fully custom acquisition and analysis solution, Keithley has the software needed to get the
most performance from a Model 2700, 2701, or 2750 Multimeter/Switch System. Our broad range of
software solutions makes it easy to get applications “Up & Running” quickly and economically.
Measurement Ranges for the Integra Series Systems
2700, 2701,
2750
Multimeter/Data Acquisition/
Switch Systems
Measurement Ranges
1n 1µ 1m 1 1k 1M 1G
DC Voltage
AC Voltage
DC Current
AC Current
Frequency
Period
Resistance (2-Wire)
Resistance (4-Wire)
Logarithmic scale
Temperature–RTD
Temperature–TC
Temperature–Thermistor
Linear scale
100nV 1000V
100nV 750V
10nA 3A
1μA 3A
2μs 333ms
10μΩ 120MΩ
1μΩ 120MΩ
–500 0 500 1000 1500 2000
–200°C 630°C
–200°C 1820°C
–80°C 150°C
3Hz 500kHz
Model 2750 only
Integra Series integrated switching, measurement, and datalogg ing solutions
DIGITAL MULTIMETERS & SYSTEMS
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Important Features and Benefits
• Full per-channel configurability—Each channel can be
independently configured for making measurements. The
parameters that can be chosen for each channel include speed,
range, resolution, number of power line cycles (NPLC), filtering
type, offset compensation, math functions to be displayed, CJC
type, RTD type, frequency gate time, “m” and “b” values in mX + b
format, HI/LO limits, low Ω (Model 2750 only), ratio calculation,
and thermistor type.
• Channel monitor feature—Monitor any specific input channel on
the front panel display during a scan. This feature can also serve
as an analog trigger to initiate a scan sequence based on some
external factor, such as a temperature rising above a pre-set limit.
Only the data of interest is acquired, so there’s no need to spend
hours searching through reams of normal readings to find
anomalous data.
•Front/rear switch—Switching between the front and rear panel
measurement inputs is as easy as pressing a button. Users can
select the front panel inputs for tasks such as system setup and
verification, manual probing, troubleshooting, and calibration,
while the rear panel inputs through the modules allow fast,
automated multiplexing and control.
• Battery-backed setup memory—Up to four different setup
configurations can be stored in onboard memory. If the line
power fails during a scan, the system will resume scanning where
it stopped once power is restored.
• Relay counting—Provides preventive maintenance of the system
and switches.
• Memory buffer—The mainframe’s non-volatile wrap-around
reading memory allows continuous, unattended datalogging over
long periods. Data in the buffer can be transferred to a PC
controller automatically as new data is acquired. The real-time
clock can be used to time- and date-stamp readings for later
review and interpretation.
• 2 TTL-level digital inputs—Use to implement external triggers to
initiate a scan sequence.
• 5 “per-channel” HI/LO alarm limit TTL outputs—Trigger external
alarms or perform other control functions without a PC controller.
• Dry circuit ohms (20mV clamp)—Protects sensitive devices from
damage and prevents self-heating errors during testing (Model
2750 only).
• Virtual channel—Stores the results of channel-to channel ratio
and average math operations.
• Onboard statistical analysis—Mathematical functions available
at the push of a button are channel average, mX+b scaling,
minimum, maximum, average, and standard deviation.
• GPIB and RS-232 interfaces (Models 2700 and 2750)
• Ethernet and RS-232 interface (Model 2701 only)
• 3-year warranty
2700 2701 2750
No. of differential input channels 80 80 200
Matrix crosspoints 96 96 240
Ohms resolution 100 µΩ 100 µΩ 1 µΩ
Dry circuit ohms (20mV clamp) No No Yes
No. of slots 2 2 5
Memory buffer 55,000 rdgs 450,000 rdgs 110,000 rdgs
Size (2U height) Half-rack width Half-rack width Full-rack width (19˝)
Communications GPIB, RS-232 Ethernet, RS-232 GPIB, RS-232
Scan-Rate (memory) 180/s 500/s 230/s
Scan-Rate (bus) 145/s 440/s 210/s
Max. Internal Trigger Rate 2000/s 2800/s 2000/s
Max. External Trigger Rate 375/s 2000/s 375/s
Which Integra Mainframe is the Best Choice for the Application?
Use this selector guide to decide which Integra Series mainframe offers the combination of features
and capacity that’s right for a specific application. If testing requirements change in the future,
switch/control modules and test code can be easily re-used.
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Integra Series condensed specifications
DIGITAL MULTIMETERS & SYSTEMS
DC CHARACTERISTICS
1
CONDITIONS: MED (1 PLC)2or 10 PLC or MED (1 PLC) with Digital Filter of 10
INPUT
TEST RESISTANCE
ACCURACY: ±(ppm of reading + ppm of range)
CURRENT ±5% OR OPEN CKT.
(ppm = parts per million) (e.g., 10ppm = 0.001%)
TEMPERATURE
OR BURDEN VOLTAGE
3
24 Hour
4
90 Day 1 Year COEFFICIENT
FUNCTION RANGE RESOLUTION VOLTAGE 2700/2701 2750 23°C±1° 23°C±5° 23°C±5° 0°–18°C & 28°–50°C
Voltage
11
100.0000 mV 0.1 µV >10 GΩ >10 GΩ 15 + 30 25 + 35 30 + 35 (1 + 5)/°C
1.000000 V 1.0 µV >10 GΩ >10 GΩ 15 + 6 25 + 7 30 + 7 (1 + 1)/°C
10.00000 V 10 µV >10 GΩ >10 GΩ 10 + 4 20 + 5 30 + 5 (1 + 1)/°C
100.0000 V 100 µV 10 MΩ ±1% 10MΩ ±1% 15 + 6 35 + 9 45 + 9 (5 + 1)/°C
1000.000 V
5
1mV 10MΩ ±1% 10MΩ ± 1% 20 + 6 35 + 9 50 + 9 (5 + 1)/°C
Resistance
6, 8
1.000000 Ω
24
1µΩ 10 mA 5.9 V 80 + 40 80 + 40 100 + 40 (8 + 1)/°C
10.00000 Ω
24
10 µΩ 10 mA 5.9 V 20 + 20 80 + 20 100 + 20 (8 + 1)/°C
100.0000 Ω 100 µΩ 1 mA 6.9 V 12.2 V 20 + 20 80 + 20 100 + 20 (8 + 1)/°C
1.000000 kΩ 1mΩ 1 mA 6.9 V 12.2 V 20 + 6 80 + 6 100 + 6 (8 + 1)/°C
10.00000 kΩ 10 mΩ 100 µA 6.9 V 6.8 V 20 + 6 80 + 6 100 + 6 (8 + 1)/°C
100.0000 kΩ 100 mΩ 10 µ A 12.8 V 12.8 V 20 + 6 80 + 10 100 + 10 (8 + 1)/°C
1.000000 MΩ
23
1.0 Ω 10 µA 12.8 V 12.8 V 20 + 6 80 + 10 100 + 10 (8 + 1)/°C
10.00000 MΩ
7, 23
10 Ω 0.7 µA // 10M Ω 7.0 V 7.0 V 150 + 6 200 + 10 400 + 10 (70 + 1)/°C
100.0000 MΩ
7, 23
100 Ω 0.7 µA // 10M Ω 7.0 V 7.0 V 800 + 30 2000 + 30 2000 + 30 (385 + 1)/°C
Dry Circuit 1.000000 Ω 1µΩ 10 mA 20 mV 80 + 40 80 + 40 100 + 40 (8 + 1)/°C
Resistance
21, 24
10.00000 Ω 10 µΩ 1 mA 20 mV 25 + 40 80 + 40 100 + 40 (8 + 1)/°C
100.0000 Ω 100 µΩ 100 µA 20 mV 25 + 40 90 + 40 140 + 40 (8 + 1)/°C
1.000000 kΩ 1mΩ 10 µA 20 mV 25 + 90 180 + 90 400 + 90 (8 + 1)/°C
Continuity (2W) 1.000 kΩ 100 mΩ 1 mA 6.9 V 12.2 V 40 + 100 100 + 100 100 + 100 (8 + 1)/°C
Current 20.00000 mA 10 nA < 0.2 V 60 + 30 300 + 80 500 + 80 (50 + 5)/°C
100.0000 mA 100 nA < 0.1 V 100 + 300 300 + 800 500 + 800 (50 + 50)/°C
1.000000 A 1.0 µA < 0.5 V
9
200 + 30 500 + 80 800 + 80 (50 + 5)/°C
3.000000 A 10 µA < 1.5 V
9
1000 + 15 1200 + 40 1200 + 40 (50 + 5)/°C
Channel (Ratio)
10
Ratio Accuracy = Accuracy of selected Channel Range + Accuracy of Paired Channel Range
Channel (Average)
10
Average Accuracy = Accuracy of selected Channel Range + Accuracy of Paired Channel Range
TEMPERATURE
19
(Displayed in °C, °F, or K. Exclusive of probe errors.)
Thermocouples (Accuracy based on ITS-90.)
90 DAY/1 YEAR (23°C ± 5°C)
RELATIVE TO TEMPERATURE
SIMULATED USING COEFFICIENT
REFERENCE 77XX 0°–18°C &
TYPE RANGE RESOLUTION JUNCTION MODULE* 28°–50°C
J –200 to +760 °C 0.001°C 0.2°C 1.0°C 0.03°C/°C
K –200 to +1372°C 0.001°C 0.2°C 1.0°C 0.03°C/°C
N –200 to +1300°C 0.001°C 0.2°C 1.0°C 0.03°C/°C
T –200 to +400°C 0.001°C 0.2°C 1.0°C 0.03°C/°C
E –200 to +1000°C 0.001 °C 0.2°C 1.0°C 0.03°C/°C
R 0 to +1768°C 0.1 °C 0.6°C 1.8°C 0.03°C/°C
S 0 to +1768°C 0.1°C 0.6°C 1.8°C 0.03°C/°C
B +350 to +1820°C 0.1°C 0.6°C 1.8°C 0.03°C/°C
* Using 7710 Module: J: 2.5°C; K: 1°C. N, T, E Types: 1.5°C. R, S, B Types: 2.7°C.
4-Wire RTD:
(100Ω platinum [PT100], D100, F100, PT385, PT3916, or user type. Offset compensation On.)
–200° to +630°C 0.01°C 0.06°C 0.003°C/°C
Thermistor: (2.2kΩ, 5kΩ, and 10kΩ)
20
–80° to +150°C 0.01°C 0.08°C 0.002°C/°C
DC SYSTEM SPEEDS
15,18
2700/2750 2701
RANGE CHANGES (excludes 4WΩ)16: 50/s (42/s) 50/s (42/s)
FUNCTION CHANGES
16
: 50/s (42/s) 50/s (42/s)
AUTORANGE TIME16: <30 ms <30 ms
ASCII READINGS TO RS-232 (19.2k BAUD): 55/s 300/s
MAX. EXTERNAL TRIGGER RATE: 375/s 2000/s
DC MEASUREMENT SPEEDS
15
Single Channel, 60Hz (50Hz) Operation
FUNCTION DIGITS READINGS/s PLCs
DCV, DCI, Ω (<10M), 6.5
12,16
5 (4) 10
Thermocouple, 6.5
16
35 (28) 1
Thermistor 6.5
12,16
45 (36) 1
5.5
12,16
150 (120) 0.1
5.5
16, 17
300 (240) 0.1
5.5
17
500 (400) 0.1
2700 and 2750 only 4.5
17
2500 (2000) 0.01
2701 only 3.5 3500 (2800) 0.002
4WΩ (<10M) 6.5
16
1.4 (1.1) 10
6.5
16
15 (12) 1
5.5
17
33 (25) 0.1
4WΩ OComp, RTD
22
6.5
16
0.9 (0.7) 10
6.5
16
8 (6.4) 1
5.5
16, 17
18 (14.4) 0.1
Channel (Ratio), 6.5
16
2.5 (2) 10
Channel (AVG) 6.5
16
15 (12) 1
5.5
17
25 (20) 0.1
Multiple Channels, Into Memory
18
Channels/s
2700 2701 2750
7710 Scanning DCV 180/s 500/s 230/s
7710 Scanning DCV with Limits or Time Stamp On 170/s 500/s 230/s
7710 Scanning DCV alternating 2WΩ 45/s 115/s 60/s
Multiple Channels, Into and Out of Memory to GPIB
16, 18
or Ethernet Channels/s
2700 2701 2750
7702 Scanning DCV 65/s 75/s 65/s
7700 and 7708 Scanning Temperature (T/C) 50/s 50/s 50/s
7710 Scanning DCV 145/s 440/s 210/s
7710 Scanning DCV with Limits or Time Stamp On 145/s 440/s 210/s
7710 Scanning DCV alternating 2WΩ 40/s 115/s 55/s
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
Integra Series condensed specifications
DIGITAL MULTIMETERS & SYSTEMS
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
DC NOTES
1. 20% overrange except on 1000V and 3A.
2. Add the following to “ppm of range” uncertainty; 100mV 15ppm; 1V and 100V 2ppm; for Model 2750 1Ω and Dry Circuit
Ω 40ppm; 10→1MΩ 2ppm, for Models 2700/2701 100Ω 30ppm, 20mA and 1A 10ppm, 100mA 40ppm.
3. ±2% (measured with 10MΩ input resistance DMM, >10GΩ DMM on 10MΩ and 100MΩ ranges). For Dry Circuit Ω, ±25%
with Input HI connected to Sense HI; with Sense HI disconnected add 30mV.
4. Relative to calibration accuracy.
5. For signal levels >500V, add 0.02ppm/V uncertainty for portion exceeding 500V.
6. Specifications are for 4-wire Ω, 1Ω, 10Ω, and 100Ω with offset compensation on. With 77XX plug-in modules, LSYNC on.
With offset compensation on, OPEN CKT. VOLTAGE is 12.8V. For 2-wire Ω add 1.5Ω to “ppm of range” uncertainty. 1Ω
range is 4-wire only.
7. Must have 10% matching of lead resistance in Input HI and LO.
8. Add the following to “ppm of reading” uncertainty when using plug in modules:
10 kΩ 100 kΩ 1 MΩ 10 MΩ 100 MΩ
All Modules: 220 ppm 2200 ppm
7701, 7703, 7707, 7709 Modules: 10 ppm 100 ppm 1000 ppm 1% 10%
7706, 7708, 7710 Modules: 5 ppm 50 ppm 500 ppm 5000 ppm 5%
7710 Module 23°C ±5°C: 11 ppm 110 ppm 1100 ppm 1.1% 11%
9. Add 1.5V when used with plug in modules.
10. For RATIO, DCV only. For AVERAGE, DCV, and Thermocouples only. Available with plug in modules only.
11. Add 6µV to “of range” uncertainty when using Models 7701, 7703, and 7707, and 3µV for Models 7706 and 7709.
12. Auto zero off.
13. For LSYNC On, line frequency ±0.1 %. For LSYNC Off, use 60dB for ≥ 1PLC.
14. For 1kΩ unbalance in LO lead. AC CMRR is 70dB.
15. Speeds are for 60Hz (50Hz) operation using factory defaults operating conditions (*RST). Autorange off, Display off, Limits
off, Trigger delay = 0.
16. Speeds include measurements and binar y data transfer out the GPIB or ASCII data transfer for Ethernet and RS-232 (reading element only).
17. Sample count = 1000, auto zero off (into memor y buffer).
18. Auto zero off, NPLC = 0.01 (Models 2700 and 2750), NPLC = 0.002 (Model 2701).
19. Additional Uncertainty: Plug-In Modules
Front Terminals 7709 7701, 7703, 7707 7700, 7708, 7706
Simulated Simulated Simulated 7710 Using Using
Type Range Ref. Junction Ref. Junction Ref. Junction CJC CJC
J –200 to 0°C 0.1 0.1 0.3 0.8 1.6
K –200 to 0°C 0.2 0.2 0.4 0.8 1.6
N –200 to 0°C 0.3 0.3 0.6 0.8 1.6
T –200 to 0°C 0.2 0.1 0.4 0.8 1.6
E –200 to 0°C – 0.1 0.3 0.8 1.6
R 0 to +400°C 0.4 0.6 1.2 0.5 1.0
S 0 to +400°C 0.4 0.6 1.2 0.5 1.0
B +350 to +1100°C 0.8 0.3 1.7 0.5 1.0
20. For lead resistance >0Ω, add the following uncertainty/Ω for measurement temperatures of:
70°–100°C 100°–150°C
2.2 kΩ (44004) 0.22°C 1.11°C
5.0 kΩ (44007) 0.10°C 0.46°C
10 kΩ (44006) 0.04°C 0.19°C
21. For 4-wire Ω only, offset compensation on, LSYNCon.
22. For Dry Circuit 1kΩ range, 2 readings/s max.
23. For 2750 Front Inputs, add the following to Temperature Coefficient “ppm of reading” uncertainty: 1MΩ 25ppm, 10MΩ
250ppm, 100MΩ 2500ppm. Operating environment specified for 0°C to 50°Cand 50% RH at 35°C.
24. Model 2750 only.
25. Front panel resolution is limited to 0.1Ω.
AC SPECIFICATIONS
1
Accuracy: ±(% of reading + % of range), 23°C ± 5°C
Calibration 3 Hz– 10 Hz– 20 kHz– 50 kHz– 100 kHz–
Function Range Resolution Cycle 10 Hz 20 kHz 50 kHz 100 kHz 300 kHz
Voltage
2
100.0000 mV 0.1 µV 90 Days 0.35 + 0.03 0.05 + 0.03 0.11 + 0.05 0.6 + 0.08 4.0 + 0.5
1.000000 V 1.0 µV (all ranges)
10.00000 V 10 µV 1 Year 0.35 + 0.03 0.06 + 0.03 0.12 + 0.05 0.6 + 0.08 4.0 + 0.5
100.0000 V 100 µV (all ranges)
750.000 V 1.0 µV
(Temp. Coeff.)/°C30.035 + .003 0.005 + .003 0.006 + .005 0.01 + .006 0.03 + .01
3 Hz–10 Hz 10 Hz–3 kHz 3 kHz–5 kHz
Current
2
1.000000 A 1.0 µA 90 Day/1 Yr. 0.30 + 0.04 0.10 + 0.04 0.14 + 0.04
3.00000 A
14
10 µA 0.35 + 0.06 0.16 + 0.06 0.18 + 0.06
(Temp. Coeff.)/°C30.035 + 0.006 0.015 + 0.006
(3 Hz–500 kHz) (333 ms–2 µs)
Frequency
4
100 mV 0.333 ppm 90 Day/ 1 Yr. 100 ppm + 0.333 ppm (SLOW, 1s gate)
and Period to 3.33 ppm 100 ppm + 3.33 ppm (MED, 100ms gate)
750 V 33.3 ppm 100 ppm + 33.3 ppm (FAST, 10ms gate)
DC SPEED vs. NOISE REJECTION
RMS Noise
10V Range
Rate Filter Readings/s12Digits 2700,2750 2701 NMRR CMRR
14
10 50 0.1 (0.08) 6.5 < 1.2 µV < 2.5 µV 110 dB13140 dB
1 Off 15 (12) 6.5 < 4 µV < 6 µV 90 dB
13
140 dB
0.1 Off 500 (400) 5.5 < 22 µV < 40 µV — 80 dB
0.01 Off 2500 (2000) 4.5 < 150 µV < 300 µV — 80 dB
0.002 Off 3500 (2800) 3.5 — < 1 mV — 60 dB
DC MEASUREMENT CHARACTERISTICS
DC VOLTS
A-D LINEARITY: 2.0 ppm of reading + 1.0 ppm of range.
INPUT IMPEDANCE:
100mV–10V Ranges: Selectable >10GΩ // with <400pF or 10MΩ ±1%.
100V, 1000V Ranges: 10MΩ ±1%.
Dry Circuit: 100kΩ ± 1% // <1µF.
EARTH ISOLATION: 500V peak, >10GΩ and <300pF any terminal to chassis.
INPUT BIAS CURRENT:<75pA at 23°C.
COMMON MODE CURRENT:<500nApp at 50Hz or 60Hz.
AUTOZERO ERROR: Add ±(2ppm of range error + 5µV) for < 10 minutes and ±1°C.
INPUT PROTECTION: 1000V, all ranges. 300V with plug in modules.
RESISTANCE
MAXIMUM 4WΩ LEAD RESISTANCE: 80% of range per lead (Dry Ckt mode). 5Ω per
lead for 1Ω range; 10% of range per lead for 10Ω, 100Ω, and 1kΩ ranges; 1kΩ
per lead for all other ranges.
OFFSET COMPENSATION:Selectable on 4WΩ, 1Ω, 10Ω, 100Ω, 1kΩ, and 10kΩ
ranges.
CONTINUITY THRESHOLD: Adjustable 1 to 1000 Ω
INPUT PROTECTION: 1000V, all Source Inputs, 350V Sense Inputs. 300V with plug-in
modules.
DC CURRENT
SHUNT RESISTORS: 100mA–3A, 0.1Ω. 20mA, 5Ω.
INPUT PROTECTION: 3A, 250V fuse.
THERMOCOUPLES
CONVERSION: ITS-90.
REFERENCE JUNCTION: Internal, External, or Simulated (Fixed).
OPEN CIRCUIT CHECK: Selectable per channel. Open >11.4kΩ ±200Ω.
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Integra Series condensed specifications
DIGITAL MULTIMETERS & SYSTEMS
ADDITIONAL UNCERTAINTY ±(% OF READING)
Low Frequency Uncertainty MED FAST
20 Hz – 30 Hz 0.3 —
30 Hz – 50 Hz 0 —
50 Hz – 100 Hz 0 1.0
100 Hz – 200 Hz 0 0.18
200 Hz – 300 Hz 0 0.10
>300 Hz 0 0
CREST FACTOR:
5
1–2 2–3 3–4 4–5
Additional Uncertainty: 0.05 0.15 0.30 0.40
Max. Fundamental Freq.: 50kHz 50kHz 3kHz 1kHz
Maximum Crest Factor: 5 at full-scale.
AC MEASUREMENT CHARACTERISTICS
AC VOLTS
MEASUREMENT METHOD: AC -coupled, True RMS.
INPUT IMPEDANCE: 1MΩ ±2% // by <100pF.
INPUT PROTECTION: 1000Vp or 400VDC. 300Vrms with plug in modules.
AC CURRENT
MEASUREMENT METHOD: AC-coupled, True RMS.
SHUNT RESISTANCE:0.1Ω.
BURDEN VOLTAGE: 1A <0.5Vrms, 3A <1.5Vrms. Add 1.5Vrms when used with plug
in modules.
INPUT PROTECTION: 3A, 250V fuse.
FREQUENCY AND PERIOD
MEASUREMENT METHOD: Reciprocal counting technique.
GATE TIME:SLOW 1s, MED 100ms, and FAST 10ms.
AC GENERAL
AC CMRR6: 70dB.
VOLT HERTZ PRODUCT: <= 8 × 10
7
.
AC MEASUREMENT SPEEDS
7, 13
Single Channel, 60Hz (50Hz) Operation
Function Digits Readings/s Rate Bandwidth
ACV, ACI 6.5 2s/Reading SLOW 3 Hz–300 kHz
6.5 4.8 (4) MED 30 Hz–300 kHz
6.5
9
40 (32) FAST 300 Hz–300 kHz
Frequency, 6.5 1 (1) SLOW 3 Hz–300 kHz
Period 5.5 9 (9) MED 30 Hz–300 kHz
4.5 35 (35) FAST 300 Hz–300 kHz
4.5
10
65 (65) FAST 300 Hz–300 kHz
Multiple Channel
7710 SCANNING ACV
10, 11
: 500/s.
7710 SCANNING ACV WITH AUTO DEL AY ON: 2s/reading.
AC SYSTEM SPEEDS
7, 9, 11
2700/2750 2701
AC System Speed: (19.2k) (115.2K)
Range Changes:
12
4/s (3/s) 4/s (3/s)
Function Changes:
12
4/s (3/s) 4/s (3/s)
Autorange Time: < 3s < 3s
ASCII Readings to RS-232 (19.2k baud): 50/s 300/s
Max. External Trigger Rate: 250/s 2000/s
AC NOTES
1.20% overrange except on 750V and 3A.
2. Specification are for SLOW mode and sine wave inputs >5% of range. SLOW and MED are multi-sample A/D conversions.
FAST is DETector:BANDwidth 300 with nPLC = 1.0.
3.Applies to 0°–18°C and 28°–50°C.
4.For square wave inputs >10% of ACV range, except 100mV range. 100mV range frequency must be >10Hz if input is <20mV.
5.Applies to non-sine waves >5Hz.
6.For 1kΩ unbalance in LO lead.
7.Speeds are for 60Hz (50Hz) operation using factory defaults operating conditions (*RST). Autorange off, Display off, Limits
off, Trigger delay=0..
8. For ACV inputs at frequencies of 50 or 60Hz (±10%), add the following to “% of Range” uncertainty: 100mV 0.25%, 1V
0.05%, 10V 0.13%, 100V 0.03%, 750V 0.015 (Model 2701 only)..
9.Auto Zero off.
10. Sample count = 1024.
11. DETector:BANDwidth 300 with nPLC = 0.006 (2701 only).
12. Maximum useful limit with trigger delay = 175ms.
13. Includes measurement and binary data transfer out GPIB or ASCII data transfer for Ethernet and RS-232 (Reading Element only).
GENERAL
EXPANSION SLOTS:2 (2700, 2701), 5 (2750).
POWER SUPPLY: 100V / 120V / 220V / 240V ±10%.
LINE FREQUENCY: 45Hz to 66Hz and 360Hz to 440Hz, automatically sensed at power-up.
POWER CONSUMPTION: 28VA (2700), 80VA (2701, 2750).
OPERATING ENVIRONMENT: Specified for 0°C to 50°C. Specified to 80% RH at 35°C.
STORAGE ENVIRONMENT:–40°C to 70°C.
BATTERY: Lithium battery-backed memory, 3 years @ 23°C (Models 2700, 2750) Lithium Ion battery-backed
memory, 30 days of buffer storage @ 23°C and >4 hours charge time. Battery lifetime: >3 years @ 23°C,
>1.5 years @ 50°C (Model 2701)
WARRANTY: 3 years excludes battery.
EMC: Conforms to European Union Directive 89/336/EEC EN61326-1.
SAFETY: Conforms to European Union Directive 73/23/EEC EN61010-1, CAT I.
VIBRATION: MIL-PRF-28800F Class 3, Random.
WARM-UP:2 hours to rated accuracy.
DIMENSIONS:
Rack Mounting: 89mm high × 213mm wide (2700, 2701) or 485mm wide (2750) × 370mm deep (3.5 in ×
8.375 in or 19 in × 14.563 in).
Bench Configuration (with handle and feet): 104mm high × 238mm wide (2700, 2701) or 485mm wide
(2750) × 370mm deep (4.125 in × 9.375 in (2700, 2701) or 19 in (2750) × 14.563 in).
SHIPPING WEIGHT:6.5kg (14 lbs.) (2700, 2701) or 13kg (28 lbs.) (2750).
DIGITAL I/O:2 inputs, 1 for triggering and 1 for hardware interlock.
5 outputs, 4 for Reading Limits and 1 for Master Limit. Outputs are TTL compatible or can sink 250mA,
diode clamped to 40V.
TRIGGERING AND MEMORY:
Window Filter Sensitivity: 0.01%, 0.1 %, 1%, 10%, or Full-scale of range (none).
Reading Hold Sensitivity: 0.01%, 0.1 %, 1%, or 10% of reading.
Trigger Delay:0 to 99 hrs (1ms step size).
External Trigger Delay:<2ms (2700), <1ms (2701, 2750).
External Trigger Jitter:<1ms (2700), <500µs (2701), <500µs (2750).
Memory Size: 55,000 readings (2700), 450,000 readings (2701), 110,000 readings (2750).
MATH FUNCTIONS: Rel, Min/Max/Average/Std Dev/Peak-to-Peak (of stored reading), Limit Test, %, 1/x, and
mX+b with user defined units displayed.
REMOTE INTERFACE:
GPIB (IEEE-488.2) (2700, 2750), RS-232C (2700, 2701, and 2750).
Ethernet TCP/IP (10bT and 100bT) (2701)
SCPI (Standard Commands for Programmable Instruments)
LabVIEW Drivers
ACCESSORIES SUPPLIED: Model 1751 Safety Test Leads, Product Informtion CD-ROM. (Model 2701 only:
Getting Started Foldout, 3m Ethernet crossover cable, software CD-ROM with IVI/VISA drivers for VB,
VC/C++, LabVIEW, and LabWindows/CVI, plus free runtime start-up software.)
ACCESSORIES AVAILABLE:
4288-7 R ack Mount Rear Support Kit (2750)
77XX-904A Module Manual
77XX Modules
Extended Warranty
ExceLINX-1A (Excel add-in datalogger softwar)
FOR MODEL 2701:
Ethernet: RJ-45 connector, TCP/IP, 10bT and 100bTx autosensed.
IP Configuration: Static or DHCP.
Password Protection: 11 Characters.
Software: Windows 98, NT, 2000, ME, and XP compatible. Internet Explorer 5.0 or higher required. Web
page server by 2701.
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
Integra Series switch/control modules
DIGITAL MULTIMETERS & SYSTEMS
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Switch/Control Module Capabilities
All plug-in modules are compatible with the two-slot Model 2700 and
Model 2701 Multimeter/Data Acquisition Systems and the five-slot Model
2750 Multimeter/Switch System. When the application’s needs change, simply change modules. Integra systems reconfigure themselves automatically.
Module Capabilities Overview
7700 7701 7702 7703 7705 7706 7707 7708 7709 7710 7711 7712
DC Volts ✓✓✓✓ ✓✓✓✓✓
DC Current ✓✓
Temperature
T/C w/Automatic CJC ✓✓✓✓
T/C w/External CJC ✓✓✓✓ ✓✓✓✓✓
RTD ✓✓✓✓ ✓✓✓✓✓
Thermistor ✓✓✓✓ ✓✓✓✓✓
Resistance (2- or 4-wire) ✓✓✓✓ ✓✓✓✓✓
Continuity ✓✓✓✓ ✓✓✓✓✓
AC Volts ✓✓✓✓ ✓✓✓✓✓
AC Current ✓✓
Frequency ✓✓✓✓ ✓✓✓✓✓
Event Counter/Totalizer ✓
Signal Routing/Control ✓✓✓✓✓✓✓✓✓✓✓✓
Digital Input ✓
Digital Output ✓✓
Analog Output ✓
RF Switching ✓✓
2700, 2701, 2750
Multimeter/Data Acquisition/
Switch Systems
Integra Plug-In Modules
www.keithley.com
1.888.KEITHLEY (U.S. only)
A GREATER MEASURE OF CONFIDENCE
Use with Integra Series mainframes: 2700, 2701, 2750
DIGITAL MULTIMETERS & SYSTEMS
Selector Guide
Plug-In Modules for 2700, 2701, 2750
Integra Mainframes
Module Selector Guide
This selector guide may prove helpful in identifying the best module for a specific application. Install up to
five modules at a time in the Model 2750 mainframe or two modules in the Model 2700 or 2701 mainframe.
Max.
# Analog Type of Max. Switched Contact Switch
Module Inputs Configuration Connector Voltage Current Bandwidth Life Speed Other
7700 20 Multiplexer 1×20 or Screw 300 V 1 50 MHz 10
8
3 ms Maximum power = 125VA.
w/CJC two 1×10 terminals 2 current measure channels.
7701 32 Multiplexer 1×32 or D-sub 150 V 1 A 2 MHz 10
8
3 ms Maximum power = 125VA.
two 1×16
7702 40 Multiplexer 1×40 or Screw 300 V 1 A 2 MHz 10
8
3 ms Maximum power = 125VA.
two 1×20 terminals 2 current measure channels.
7703 32 Multiplexer 1×32 or D-sub 300 V 500 mA 2 MHz 10
8
1 ms Reed relays.
two 1×16
7705 40 Independent N/A D-sub 300 V 2 A 10 MHz 10
8
3 ms Maximum power = 125VA.
SPST
7706 20 Multiplexer 1×20 or Screw 300 V 1 A 2 MHz 10
8
3 ms 2 analog outputs.
w/CJC two 1×10 terminals 16 digital outputs.
Maximum power = 125VA.
7707 10 Digital I/O/ 1×10 or D -sub 300 V 1 A 2 MHz 10
8
3 ms 32 digital I/O.
Multiplexer two 1×5 Maximum power = 125VA.
7708 40 Multiplexer 1×40 or Screw 300 V 1 A 2 MHz 10
8
3 ms Maximum power = 125VA.
w/CJC two 1×20 terminals
7709 48 Matrix 6×8 D-sub 300 V 1 A 2 MHz 10
8
3 ms Connects to internal DMM.
Daisy chain multiple cards
for up to a 6×40 matrix.
Maximum power = 125VA.
7710 20 Multiplexer 1×20 or Removable 60 V 0.1 A 2 MHz 10
10
0.5 ms Solid state relays, 60Vmax.
w/CJC two 1×10 screw 500 channels/second scan rate.
terminals
7711 8 Multiplexer Dual 1×4 SMA 60 V 0.5 A 2 GHz 10
6
10 ms Insertion loss <1.0dB @ 1GHz.
VSWR <1.2 @ 1GHz.
7712 8 Multiplexer Dual 1×4 SMA 42 V 0.5 A 3.5 GHz 10
6
10 ms Insertion loss <1.1dB @ 2.4GHz.
* Can be disconnected from internal DMM for routing external signals
Integra Plug-In Module Accessories
Module Connector Type Supplied Accessories Available Accessories
7700 Oversized Screw Terminal Strain Relief 7401 T/C wire
7701 50-pin female D-sub & 25-pin female D -sub 7789 connector kit 7790 connector kit, 7705-MTC-2 & 7707-MTC-2 cables
7702 Oversized Screw Terminal Strain Relief —
7703 Two 50-pin female D-sub 7788 connector kit 7705-MTC-2 cable
7705 Two 50-pin female D-sub 7788 connector kit 7705-MTC-2 cable
7706 Screw Terminal Strain Relief 7401 T/C wire kit
7707 50-pin male D-sub & 25-pin female D -sub 7790 connector kit 7789 connector kit, 7705-MTC-2 & 7707-MTC-2 cables
7708 Oversized Screw Terminal Strain Relief 7401 T/C wire kit
7709 50-pin female D-sub & 25-pin female D -sub 7790 connector kit 7789 connector kit, 7705-MTC-2 & 7707-MTC-2 cables
7710 Quick Disconnect Screw Terminal Strain Relief 7401 T/C wire kit
7711 SMA — 7711-BNC-SMA & 7712-SMA-N adaptors, 7712-SMA-1 & S46-SMA-0.5,-1 SMA cables,
7051-2,-5,-10 BNC cables
7712 SMA — 7712-SMA-N adaptor, 7712-SMA-1 & S46-SMA-0.5,-1 SMA cables
Loading...
