life in a day

www.kef.com

Page 2

KEF - The story so far

The story began two generations ago, with Raymond Cooke,

an acoustic engineering genius who was driven by a passion and belief

in the power of revolutionary design, technology and new materials to

enhance the enjoyment of recorded sound. His radical innovations,

and those of the company he founded, have led to KEF loudspeakers

ranking among the finest in the world ever since. No other

manufacturer has done more to advance the principles of loudspeaker

design technology.

So when such a forward-thinking audiophile company enters the

multi-media world of modern home entertainment, expectations run

high. National and international awards follow - and whether you’re

into music, movies or games, the latest KEF Instant Theatre (KIT)

systems set new standards of sound quality, ease of use and sheer

listening pleasure for every room in your house.

Page 3

KEF Instant Theatre

The KIT concept brings true simplicity and convenience to high-end

audio, comprising four distinct ranges, each offering logical steps in

price and performance (including wireless speaker connectivity).

The KIT systems come complete with everything you need: two or five

main loudspeakers, a powered subwoofer and a matching DVD/CD

player incorporating HDMI

Right from the start, each system has been designed to be easy to set

up and use, with a single cable connection between subwoofer and

loudspeakers, plus one for the DVD player. They all share KEF’s

legendary sound quality: the ability to recreate a detailed,

distortion-free 3D sound picture evenly throughout the room.

technology.

As the story unfolds in the following pages, you’ll see that there’s a

KIT system for every home and lifestyle. To help you choose the right

one for you, read on…

easy set up

Page 4

which one’s for you?

start here

kit120 09

A complete surround sound system from only two compact front speakers. Ingeniously designed lateral radiators generate virtual centre and rear effects channels.

kit140 13

True surround sound from just two mid-size Uni-Q®front speakers each with 7 drivers to produce an incredible sound stage.

kit160 17

Two slim floorstanders with 11 drivers each, including front-firing Uni-Q arrays and lateral radiators generating rear and centre effects.

kit510 21

A full 5.1 system based on KEF’s ultra-compact and deceptively powerful ‘egg’ speakers with 75mm (3in.) Uni-Q drivers.

kit520 25

A more powerful 5.1 system based on five award-winning ‘egg’ speakers incorporating KEF’s 100mm (4in.) Uni-Q drivers and 19mm (0.75in.) tweeter.

kit530 29

The ultimate ‘egg’ 5.1 system, combining the latest ribbed cone 115mm (4.5in.) Uni-Q array, Sealed Suspension Technology and dedicated high performance centre channel.

kit540 33

Perfect for large flat screen TVs, with five slender wall or floor-mounted speakers housing 75mm (3in.) long-throw bass drivers alongside each Uni-Q array.

kit550 37

With the revolutionary Uni-Q array flanked by four long-throw midrange/bass drivers per speaker and KEF’s ACE technology, this is one of the best sounding surround systems that money can buy.

kit DVD player

All KIT systems come with a compact DVD/CD player incorporating HDMI technology. Complete with a radio tuner, USB connection and MP3 capability via KEFDock (KEFDock sold separately).

kit570w 41

All the performance of the kit540 with the addition of KEF’s clever wireless technology for the rear speakers. CD quality surround sound with no cables to run across the room.

kit580w 45

Identical to the kit550 in specification and performance, but with wireless signal transmission to the rear speakers for even greater convenience and ease of set up.

kit subwoofer

Every KIT system comes with a closed box 250mm (10in.) long-throw high performance subwoofer with integral power amplifier.

Page 5

kit120

Page 6

07.34am

Music pumping - sounding awesome. Surrounded by animated voices.

Everyone smiling, dancing, having fun. Feeling happy and relaxed.

A gap appears between the people and through it a quick glimpse of

hair flying as her head turns and eyes briefly meet.

Suddenly there is nothing except a blinding white light,

engulfing everything. Eyes screw closed against the intrusion.

The voices disappear but the band continues to play.

Braving the glare, one tired eye opens and is bathed in the bright

morning light seeping across the bed through the blinds.

Searching the room for the source of the music, settling on the

elegant kit120 speakers in the corner of the room, a flicker of

recognition then the broadening of a smile.

A groggy hand reaches out and locating the remote, turns up the

volume. Two discreet speakers emanate a clear and detailed 3D

surround sound which fills the room as though the band are really

there, enhanced by the full bass from the subwoofer.

Sliding contentedly back into the warm bed, a smile now illuminating

the whole face, the day begins.

kit120 Full surround sound from just two speakers: combining vertical NXT

phantom centre speakers and KEF’s wide dispersion Uni-Q driver array, the innovative kit120 delivers a truly three-dimensional soundfield. Complete with a powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

radiators that generate rear effects channels and

Page 7

kit140

Page 8

07.45am

Take 1 fresh green mango, slice it in half lengthways, cutting carefully

around the stone. Pull the two halves apart, remove the stone and

discard then scoop the flesh into a bowl with a spoon. Repeat with the

second mango. Take 2 limes, cut in half and squeeze - adding the juice

to the mango flesh. Take 2 ripe bananas, remove the skins

and discard...

The problem with making smoothies is that the whole process can

become very mundane. To eliminate any boredom it is strongly

recommended that you insert your favourite music, (CD or DVD -

the system will instantly recognise it and adapt accordingly) into your

kit140 and allow yourself to be carried away by the full

three-dimensional sound effect from only 2 speakers and subwoofer,

enjoying the rich, spacious, truly natural-sounds, on both vocal and

instrumental tracks.

kit140 With 7 drivers each including KEF’s signature Uni-Q ‘point source’ arrays and NXT technology, kit140 speakers combine

two advanced audio technologies to deliver accurate, full-bodied virtual surround sound throughout the room. Complete with hide-away powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 9

kit160

Page 10

09.10am

Excitement can hardly be contained. One hand holding the package,

fingers fumble, working as fast as they can to release the bonds that

hold the reward.

Quick eyes dart around the room for something sharp to make the job

easier and distractedly, settle momentarily on the sleek aluminium

shape of the kit160 speakers. Attention back to the task in hand,

fingernails scratch at the cardboard, make a tear, and finally the DVD

emerges from its prison.

Eagerly it is placed into the kit160 DVD player and all the intricacies

of the soundtrack are reproduced loud and clear, precisely positioned

in space. Sounds even manage to come from behind, or so it seems.

The instant benefit is definitely worth the wait.

kit160 The same radical design concept as kit140, but with no less than 11 drivers in each floorstanding column

(including front-firing Uni-Q arrays and lateral radiators for creating virtual rear and centre effects) for even more authority, spaciousness and depth. Complete with powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 11

kit510

Page 12

10.06am

Ideas drying up, motivation dwindling.

Thoughts drifting, looking for inspiration.

A need to re-energise.

The clock hits 10. DVD already loaded into the sleek kit510 DVD

player and ready to go, play is pressed and the five compact

aluminium egg speakers spring to life, generating an intensely

involving soundfield.

Within seconds the drudgery of work is long forgotten and the

concert captures full attention. Sucked into another world the relief

and joy is unmistakable.

Time speeds up and in what seems like minutes, break time is over.

Refreshed and revitalised work begins again with renewed vigour.

kit510 A full 5.1 system based on KEF’s ultra-compact and deceptively powerful ‘egg’ speakers. With 75mm (3in.) Uni-Q drivers

in distinctive cast aluminium enclosures creating a rich, spacious, natural-sounding soundscape out of all proportion to their modest size. Complete with powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 13

kit520

Page 14

12.17pm

It has started to rain.

Forced by the weather to the confines of the lounge, the children try

to continue their game inside. Running. Chasing. Flitting around

obstacles or bounding over furniture. Jumping. Pushing. Caught in the

action and desperate to win, they are oblivious to everything else

around them.

The chaos swirls and noise levels build until a new sound is introduced

and filters into the others. Realising the source of the noise,

the children squeal with delight as they clamber onto the sofa to

watch the latest animation blockbuster.

As the kit520 entertains them they are drawn into the story like never

before, the soundtracks are so enveloping, so surprisingly real and

vivid. KEF’s Uni-Q technology ensures everyone in the room finds

themself in the same real 3D surround sound picture.

Stunned into silence, before long the only sound is from the kit520.

kit520 Using five slightly larger ‘egg’ speakers with 100mm (4in.) Uni-Q arrays producing an awesome maximum SPL, kit520 is

as easy to set up as all other models in the range, and combines KEF’s trademark design innovations with uncompromised sound quality, further enhanced by dedicated EQs tailored to this specific system. Complete with hide-away powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 15

kit530

Page 16

01.00pm

At the photoshoot the atmosphere is charged. The music is all

encompassing - a solid invisible presence, almost touchable.

Fingertips gliding over frets, the brush caressing the hi-hat,

brass sliding over bass strings, so vivid, so real, and not a musician

in sight.

The whole place is buzzing with activity. The finishing touches are

added to the set. The camera is ready. Waiting in position, the models

flawless complexions need no alteration. Features are fascinatingly

alluring, attention attracted to flecked iris’ at the centre of large

glinting eyes. The lights are switched on and instantly fall upon each

models graceful form, highlighting the illustrious curves.

Now illuminated, the cast aluminium shells of the kit530

exude perfection.

kit530 The ultimate ‘egg’ 5.1 system, combining the latest 115mm (4.5in.) Uni-Q arrays with Sealed Suspension Technology

(SST) and a dedicated high performance centre channel. Complete with powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. High gloss silver or high gloss black finish.

Page 17

kit540

Page 18

03.31pm

A warm breeze gently rustled their hair as they sat in an idyllic spot by

the edge of a river. The morning sun reflected on calm waters,

turning to ripples as floats splashed the surface. The two of them

happily tucked into the lunch that Dad had made. The calm serenity

didn’t last for long when, as predicted, the outing turned into a fierce

contest to see who could get the biggest catch.

These days Dad is still as competitive as ever, finally replacing those

big, old speakers with the elegantly tall and slender columns of

kit540. At least they can agree on one thing and their mutual love of

music has brought them closer. Now, as they listen to favourite tracks

they are able to hear subtleties they had never heard before.

Bathed in the wash of real and alive sound that surrounds them,

they both enjoy the time together.

Luckily there is plenty of output in reserve, so as Dad strives to take

the limelight, as usual, with his superior knowledge of long-throw bass

drivers, high performance tweeters and of course KEFs unique

Uni-Q technology, it is easy to turn the volume up, allowing Kit540 to

speak for itself.

kit540 With five speakers suitable for floor or wall mounting and ultra-low distortion bass drivers alongside each Uni-Q array,

kit540 combines outstanding dynamics with phenomenal 3D accuracy and perfectly complements large flat screen TVs. Complete with powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 19

kit550

Page 20

04.22pm

Running through the darkness, their only chance of escape is to make

it to cover.

The night silent, they can hear with pin sharp clarity the unmistakable

sound behind them of rotor blades turning, the ominous dark form

getting ever nearer. Gaining on them. Overcome with fear, the sound

becoming so intense they expect the helicopters search light to

discover them at any second.

A forest appears in front of them and the darkness turns to pitch black

as they dive inside. Clambering through the trees they hear the sound

of leaves thrashing above, being moved by the down draft form the

helicopter. Exhausted, they eventually find cover in the huge roots of

an up-turned tree. Clinging to each other, the sound of the helicopter

retreating is replaced by a deafening silence, broken only by sharp

shallow breaths when they begin to breathe again. They have made it.

A sigh of relief.

But what was that? A gasp as the snap of a broken twig behind them

echoes through the night. Then darkness.

As the credits start to roll they find themselves back

in their lounge, mesmerized, surrounded by the kit550.

kit550 A lucid and compelling surround system, kit550 boasts the sophisticated Uni-Q array, flanked by no less than four

midrange/bass drivers per speaker and with KEF’s Acoustic Compliance Enhancement (ACE) technology to optimise bass extension. Complete with powered subwoofer, matching DVD/CD player incorporating HDMI technology and remote control. High gloss silver or high gloss black finish.

Page 21

kit570w

Page 22

07.51pm

Monaco is his kind of track. With a screaming crescendo of Italian

pistons from behind, the scarlet front aerofoil darkening as car No.5

plunges into the tunnel for the last time.

The kit570w was cutting seconds off his lap times, no question.

The sheer three-dimensional realism of the sound picture takes you

into the zone every time. Here’s where one ultra-high performance

technology meets another. Innovative engineering. Uncompromised

build quality. And incredible dynamics. Pity cars aren’t as quick to set

up as the sound system, though: a couple of cables to connect the

player and powered sub - and being wireless, the rear speakers were

even easier.

Something was wrong. Emerging into what should have been sunlight,

all was dark. A squeal of types and the crunch of carbon fibre.

Good job other racing drivers don’t have to contend with having a

friend’s hand over their eyes at crucial moments.

kit570w The same five slender speakers as the kit540 (with each Uni-Q array flanked by long throw bass drivers), plus KEF’s

ultra-reliable wireless technology transmitting the signal to the rear pair for even easier set up and convenience. Complete with powered subwoofer (upright or horizontal), matching DVD/CD player incorporating HDMI technology and remote control. Matt silver or high gloss black finish.

Page 23

kit580w

Page 24

09.00pm

Showing off. Always has to be the centre of attention. So popular all

of a sudden. So many people at the party. The whole place is alive and

buzzing. Animated voices, everyone smiling, dancing having fun.

Don’t know how he has managed it.

And the music. Hate to admit it but there has been one great track

after another. The sound system is awesome - a KEF kit580w,

pumping out such loud clear sound with no distortion no matter

where you stand. That will be down to the incredible track record of

technology firsts like, what was it? Uni-Q. Really impressive.

They look so strikingly smart - so sleek and well made. The whole

wireless thing is incredible and if he managed to install them then it

must be really easy.

Serious KIT, easy living.

kit580w Four slim floorstanders and a matching centre channel, each with the latest Uni-Q ‘point source’ array flanked by four

midrange/bass drivers and Acoustic Compliance Enhancement (ACE) technology to optimise bass extension - plus KEF’s ultra-reliable wireless technology transmitting the signal to the rear pair for even easier set up and convenience. Complete with powered subwoofer (upright or horizontal), matching DVD/CD player incorporating HDMI technology and remote control. High gloss black finish.

Page 25

accessories

KEFDock

For entertainment storage, your MP3 player is second to none -

but for playback, nothing beats a decent sound system.

That’s why we created the KEFDock. All you do is connect it to your

KEF Instant Theatre system, park your iPod in the slot and select

whatever you fancy from the menu that appears on your TV screen

(with music and movie titles in almost any language you want).

KEFDock accepts all types of iPod and MP3 players and is specifically

designed for KEF Instant Theatre (KIT) systems. The neat die-cast

zinc enclosure is styled to match, and you can control the whole

set up through your KIT remote.

stands

iPod is a Trademark of Apple computer Inc, registered in the U.S. and other countries.

adjustable height

kit120 kit140 kit510 kit520 kit530 kit540 / kit570w kit550 / Kit580w

Page 26

specifications

UNI-Q

NXT

ACE

SST

NXT

UNI-Q

NXT

UNI-Q

WSMBE

USB

HDMI

MP3

NXT

UNI-Q UNI-Q

kit120 speakers 09

Design Closed-box surround sound Drive units 100mm (4in.) Uni-Q array with

13mm (0.5in.) tweeter, NXT flat panel

Crossover frequencies 110Hz, 5kHz Frequency range (±3dB)* 95Hz - 30kHz Maximum output (SPL)* 103dB Sensitivity (2.83V/1m) 86dB Weight 2.6kg (5.7lbs) Internal volume 1litre Magnetic shielding Ye s Cabinets Die-cast aluminium Dimensions (H x W x D) 237 x 119 x 260 mm

(9.3 x 4.7 x 10.2 in.)

Finish Matt silver or high gloss black Optional accessories Floorstand and wall bracket

kit140 speakers 13

Design Closed-box surround sound Drive units 7 Speaker drivers, comprising:

Dedicated centre channel

1 x 75mm (3in.) Uni-Q array with

1 x 15mm (0.6in.) HF

Front left/right channel

1 x 75mm (3in.) Uni-Q array with

1 x 15mm (0.6in.) HF

2 x 75mm (3in.) LF

Rear left/right channel

1 x NXT flat panel

Crossover frequencies 100Hz, 400Hz, 5kHz Frequency range (±3dB)* 100Hz - 30kHz Maximum output (SPL)* 104dB Sensitivity (2.83V/1m) 87dB Weight 3.9kg (8.6lbs) Internal volume 1.4litres Magnetic shielding Ye s Cabinets Extruded aluminium Dimensions (H x W x D) 400 x 104 x 230 mm

(15.7 x 4.1 x 9.1 in.)

Finish Matt silver or high gloss black Optional accessories Floorstand and wall bracket

kit160 speakers 17

Design Closed-box surround sound Drive units 11 Speaker drivers, comprising:

Dedicated centre channel

1 x 75mm (3in.) Uni-Q array with

1 x 15mm (0.6in.) HF

1 x 75mm (3in.) LF

Front left/right channel

1 x 75mm (3in.) Uni-Q array with

1 x 15mm (0.6in.) HF

4 x 75mm (3in.) LF

Rear left/right channel

2 x NXT flat panel

Crossover frequencies 90Hz, 600Hz, 5kHz Frequency range (±3dB)* 90Hz - 30kHz Maximum output (SPL)* 109dB Sensitivity (2.83V/1m) 87dB Weight 8kg (17.6lbs) Internal volume 15litres Magnetic shielding Ye s Cabinets Extruded aluminium Dimensions (H x W x D) 1020 x 210 x 230 mm

(40.2 x 8.3 x 9.1 in.)

Finish Matt silver or high gloss black Optional accessories Wall bracket

kit510 speakers 21

Design Two-way closed box Drive units 75mm (3in.) Uni-Q array with

15mm (0.6in.) aluminium HF

Crossover frequencies 150Hz, 3kHz Frequency range (±3dB)* 120Hz - 22kHz Maximum output (SPL)* 104dB Sensitivity (2.83V/1m) 86dB Weight 0.7kg (1.5lbs) Internal volume 0.5litres Magnetic shielding Ye s Cabinets Die-cast aluminium Dimensions (Satellite H x W x D) 165 x 110 x 78 mm

(6.5 x 4.4 x 3.1 in.)

Dimensions (Centre H x W x D) 107 x 181 x 78 mm

(4.2 x 7.1 x 3.1 in.)

Finish Matt silver or high gloss black Optional accessories Floorstand

* Specification for the stand-alone speaker.

Uni-Q KEF's patented driver array, using aerospace materials to allow the tweeter to be mounted at the

acoustic centre of the midrange cone to create a single point source. This is what gives KEF loudspeakers exceptionally wide dispersion characteristics, with everyone in the room experiencing the same clear, accurate sound image.

nxt A flat panel speaker configuration that reproduces sound with a wide directivity pattern without

restricting listeners to a particular 'sweet spot'. This diffuse radiation of sound waves is ideal for reproducing ambient sound effects.

ace technology KEF's way of dramatically increasing the effective volume (and therefore

output) of bass driver enclosures by adding granules of activated carbon, whose adsorption characteristics reduce resistance to each backward movement of the cone. ACE-enabled loudspeakers perform like units up to three times their size, subjectively as well as objectively.

wireless Wireless transmission dispenses with running cables across the room to the rear speakers by

using radio waves from a discreet sender unit to transmit the audio signal to a receiver built in to the speaker. KEF’s high performance wireless system ensures exceptional signal integrity under even the most demanding conditions.

selecta-mount

is KEF's ingenious system of concealed brackets designed to simplify wall mounting.

True to the ease of use that underpins the whole kit concept, SelectaMount

bass extender Another KEF innovation, the Bass Extender is a hollow reflex-ported floor stand

whose additional volume helps to enhance bass extension.

sealed suspension technology A patented KEF technology that effectively

seals the gap between a moving mid-range cone and tweeter, which has the effect of dramatically improving sound quality, particularly at higher volumes.

usb The standard

interface for connecting different electronic devices (such as flash drives and external hard drives).

hdmi A digital interface

that supports TV or PC video formats up to 1080p on one single cable.

mp3 KEFDock plug and

play connection. KEFDock is available as a separate add-on to interface to iPods. Please see accessories page.

Page 27

specifications

UNI-Q

SST

UNI-Q

ACE

UNI-Q

NXT

ACE

SST

WSMBE

USB

HDMI

MP3

kit520 speakers 25

Design Two-way bass reflex Drive units 100mm (4in.) Uni-Q array with

19mm (0.75in.) aluminium HF

Crossover frequencies 100Hz, 3kHz Frequency range (±3dB)* 80Hz - 27kHz Maximum output (SPL)* 104dB Sensitivity (2.83V/1m) 88dB Weight 2kg (4.4lbs) Internal volume 1.5litres Magnetic shielding Ye s Cabinets Die-cast aluminium Dimensions (Satellite H x W x D) 228 x 130 x 150 mm

(9.0 x 5.1 x 5.9 in.)

Dimensions (Centre H x W x D) 162 x 190 x 150 mm

(6.4 x 7.5 x 5.9 in.)

Finish Matt silver or high gloss black Optional accessories Floorstand

kit530 speakers 29

Model kit530 satellite kit530 centre Design Two-way bass reflex Three-way closed-box Drive units 115mm (4.5in.) 115mm (4.5in.)

Uni-Q array with Uni-Q array with

19mm (0.75in.) 19mm (0.75in.)

aluminium HF aluminium HF

2 x 75mm (3in.) LF

Crossover frequencies 90Hz, 500Hz, 90Hz, 500Hz,

2.2kHz 2.2kHz

Frequency range (±3dB)* 70Hz - 55kHz 65Hz - 55kHz Maximum output (SPL)* 108dB 110dB Sensitivity (2.83V/1m) 88dB 90dB Weight 2kg (4.4lbs) 2.6kg (5.8lbs) Internal volume 1.8litres 2.4litres Magnetic shielding Ye s Ye s Cabinets Die-cast aluminium Die-cast aluminium

Dimensions (H x W x D) 245 x 125 x 150 mm 130 x 300 x 185 mm

(9.6 x 4.9 x 5.9 in.) (5.1 x 11.8 x 7.3 in.)

Finish High gloss silver High gloss silver

or high gloss black or high gloss black

Optional accessories Floorstand N/A

kit540 speakers 33

Design Three-way closed box Drive units 75mm (3in.) Uni-Q array with

15mm (0.6in.) aluminium HF,

2 x 75mm (3in.) LF

Crossover frequencies 90Hz, 300Hz, 3kHz Frequency range (±3dB)* 95Hz - 30kHz Maximum output (SPL)* 106dB Sensitivity (2.83V/1m) 87dB Weight 2kg (4.4lbs) Internal volume 1.4litres Magnetic shielding Ye s Cabinets Die-cast aluminium Dimensions ( Satellite H x W x D) 419 x 88 x 127 mm

(16.5 x 3.5 x 5.0 in.)

Dimensions (Centre H x W x D) 88 x 419 x 127 mm

(3.5 x 16.5 x 5.0 in.)

Finish Matt silver or high gloss black Optional accessories Height adjustable deskstand,

floorstand

kit550 speakers 37

Design Three-way closed box,

ACE in MF enclosure

Drive units 75mm (3in.) Uni-Q array with

15mm (0.6in.) aluminium HF,

4 x 75mm (3in.) LF

Crossover frequencies 80Hz, 800Hz, 3kHz Frequency range (±3dB)* 90Hz - 30kHz

75Hz - 30kHz

(with optional ‘Bass ExtenderTM’ bass enhancing stand)

Maximum output (SPL)* 109dB Sensitivity (2.83V/1m) 87dB Weight 3.9kg (8.6lbs)

Internal volume 2.9litres Magnetic shielding Ye s Cabinets Extruded aluminium Dimensions (Satellite H x W x D) 600 x 121 x 85 mm

(23.6 x 4.8 x 3.4 in.)

Dimensions (Centre H x W x D) 121 x 577 x 85 mm

(4.8 x 22.7 x 3.4 in.)

Finish Matt silver or high gloss black Optional accessories Floorstand with Bass Extender

* Specification for the stand-alone speaker.

Uni-Q KEF's patented driver array, using aerospace materials to allow the tweeter to be mounted at the

nxt A flat panel speaker configuration that reproduces sound with a wide directivity pattern without

restricting listeners to a particular 'sweet spot'. This diffuse radiation of sound waves is ideal for reproducing ambient sound effects.

ace technology KEF's way of dramatically increasing the effective volume (and therefore

wireless Wireless transmission dispenses with running cables across the room to the rear speakers by

selecta-mount

is KEF's ingenious system of concealed brackets designed to simplify wall mounting.

True to the ease of use that underpins the whole kit concept, SelectaMount

bass extender Another KEF innovation, the Bass Extender is a hollow reflex-ported floor stand

whose additional volume helps to enhance bass extension.

sealed suspension technology A patented KEF technology that effectively

seals the gap between a moving mid-range cone and tweeter, which has the effect of dramatically improving sound quality, particularly at higher volumes.

usb The standard

interface for connecting different electronic devices (such as flash drives and external hard drives).

hdmi A digital interface

that supports TV or PC video formats up to 1080p on one single cable.

mp3 KEFDock plug and

play connection. KEFDock is available as a separate add-on to interface to iPods. Please see accessories page.

Page 28

HDMI

USB

MP3

HDMI

USB

MP3

specifications

UNI-Q

WSMBE

ACE

UNI-Q

NXT

ACE

SST

WSMBE

USB

HDMI

MP3

kit570w 41

For specifications of speakers see kit540, additional wireless information below.

Frequency band Data rate Up to 1.1Mbps Transmission protocol AAFHSS Range 25m (27.3yds) typical maximum* Amplifier 2 x 50W digital amplifiers Finish Matt silver or high gloss black

Dimensions (Transmitter module H x W x D) 147 x 79 x 79 mm

Dimensions (Receiver module additional height)

Additional 50mm (2in.) height on floorstand

Additional 122mm (4.8in.) height on deskstand

* Environmental factors such as building materials and construction may adversely affect wireless signal range.

2.4 - 2.4835GHz (ISM band)

(5.8 x 3.1 x 3.1 in.)

kit580w 45

For specifications of speakers see kit550, additional wireless information below.

Frequency band Data rate Up to 1.1Mbps Transmission protocol AAFHSS Range 25m (27.3yds) typical maximum* Amplifier 2 x 50W digital amplifiers Finish High gloss black Dimensions (Transmitter module H x W x D) 147 x 79 x 79 mm

Dimensions (Receiver module H x W x D) 147 x 79 x 79 mm

* Environmental factors such as building materials and construction may adversely affect wireless signal range.

2.4 - 2.4835GHz (ISM band)

(5.8 x 3.1 x 3.1 in.)

kit dvd player

Playback formats supported DVD, DVD-RW, DVD+RW, CD,

CDR/RW, MP3, multi-media CD

Audio processor DTS 5.1, Dolby Digital 5.1,

Dolby Pro Logic II and stereo

USB 2.0 files supported MP3, WMA, WAV, AVI, MPEG4, WMV9,

VOB, JPEG, BMP

Tuner section AM/FM with RDS facility (Europe only) Audio inputs MP3, cable/satellite, (analogue & optical

digital) AUX and TV (analogue)

Audio output optical digital Video inputs cable/satellite and AUX

(S-video & composite)

Video outputs HDMI (up to 1080p),

SCART (Europe only),

component, S-video and composite

Aerial inputs FM & AM (included) Cabinet material Die-cast zinc alloy Finish Matt silver, high gloss black Display blue VFD display Control back-lit infra-red remote control Weight 5.2kg (11.5lbs) Dimensions including feet (H x W x D) 59 x 324 x 262 mm

(2.3 x 12.8 x 10.3 in.)

kit subwoofer

Design Closed box powered subwoofer Drive unit 250mm (10in.) long-throw unit Frequency range 40Hz - 150Hz Maximum output (SPL) 100dB Finish Matt black vinyl with gloss black acrylic front panel,

Matt silver vinyl with gloss black acrylic front panel

Weight 14.9kg (32.8lbs) Internal volume 16litres Dimensions (H x W x D) 393 x 175 x 470 mm

(15.5 x 6.9 x 18.5 in.)

Uni-Q KEF's patented driver array, using aerospace materials to allow the tweeter to be mounted at the

nxt A flat panel speaker configuration that reproduces sound with a wide directivity pattern without

restricting listeners to a particular 'sweet spot'. This diffuse radiation of sound waves is ideal for reproducing ambient sound effects.

ace technology KEF's way of dramatically increasing the effective volume (and therefore

sealed suspension technology A patented KEF technology that effectively

seals the gap between a moving mid-range cone and tweeter, which has the effect of dramatically improving sound quality, particularly at higher volumes.

wireless Wireless transmission dispenses with running cables across the room to the rear speakers by

selecta-mount

is KEF's ingenious system of concealed brackets designed to simplify wall mounting.

True to the ease of use that underpins the whole kit concept, SelectaMount

bass extender Another KEF innovation, the Bass Extender is a hollow reflex-ported floor stand

whose additional volume helps to enhance bass extension.

usb The standard

interface for connecting different electronic devices (such as flash drives and external hard drives).

hdmi A digital interface

that supports TV or PC video formats up to 1080p on one single cable.

mp3 KEFDock plug and

play connection. KEFDock is available as a separate add-on to interface to iPods. Please see accessories page.
