125-26 / 150-26 CG
2015JAN22
！
Details described or illustrated in this booklet may differ from the vehicle's actual specification
as purchased, the accessories fitted or the national-market specification. No claims will be
asserted as a result of such discrepancies.
Dimensions, weights, fuel consumption and performance data are quoted to the customary
tolerances.
The right to modify designs, equipment and accessories is reserved. Errors and omissions
excepted.
WARNING
！
TIP
WARNING
！
Please read this ma nual carefully and compl etely
before operating this vehicle.
This is the safety alert symbol. It is used to alert you
to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
indicates special precautions
that must be taken to avoid
damage to the vehicle or other
property.
provides key information to
make procedures easier or
clearer.
1 - 2
Welcome to the world of motorcycling!
As the owner, you are benefiting from the vast experience and newest technology regarding the design
and manufacture of high-quality products, which have
earned us a reputation for dependability.
Please take the time to read this manual thoroughly,
so as to enjoy all advantages of your vehicle. The
Owner’s Manual does not only instruct you in how to
operate, inspect and maintain your vehicle, but also in
how to safeguard yourself and others from trouble
and injury.
In addition, the many tips given in this manual will
help keep your vehicle in the best possible condition.
If you have any further questions, do not hesitate to
contact our dealer.
Our team wishes you many safe and pleasant rides.
So, remember to put safety first!
Our company continually seeks advance in product
design and quality. Therefore, while this manual
contains the most current product information
available at the time of printing, there may be minor
discrepancies between your vehicle and this manual.
If there is any question concerning this manual,
please consult our dealer.
INTRODUCTION
IMPORTANT MANUAL
INFORMATION
NOTICE
INTRODUCTION
Safety information
● Safe-riding
● Further safe-riding points
DESCRIPTION
● Left view
● Right view
● Controls and instruments
CONSUMER INFORMATION
● VIN and engine serial number
INSTRUMENT AND CONTROL
FUNCTIONS
● Main switch/steering lock
● Meter & Indicator
● Handlebar
● Fuel tank switch & fuel tank
● Rear shock absorber
● Rear brake pedal
● Kick starting lever
● Shift pedal
PRE-OPERATION CHECKS
OPERATION AND IMPORTANT
RIDING POINTS
● Starting the engine
● Acceleration and deceleration
● Braking
1
3
3
5
6
6
6
7
7
7
7
7
8
10
11
12
13
13
13
14
15
15
16
16
● Engine break-in
● Parking
PERIODIC MAINTENANCE AND
ADJUSTMENT
● Periodic maintenance chart
● Checking the spark plug
● Engine oil
● Idle speed
● Valve clearance
● Air filter
● Checking the throttle cable free play
● Checking the clutch free play
● Checking the front brake lever and
rear brake pedal free play
● Checking the drum limit
● Checking the brake pads
● Checking the battery
● Brake fluid
● Replacing the fuses and bulbs
TIRE
STORAGE
● Storage
SPECIFICATIONS
● Specification
16
17
17
18
20
20
22
22
22
23
23
23
24
24
25
25
26
26
27
28
Be a Responsible Owner
As the vehicle's owner, you are responsible for the
safe and proper operation of your vehicle.
The safe use and operation are dependent upon the
use of proper riding techniques as well as the expertise of the operator. Every operator should know the
following requirements before riding this vehicle.
He or she should:
● Obtain thorough instructions from a competent
source on all aspects of vehicle operation.
● Observe the warnings and maintenance requirements in this Owner’s Manual.
● Obtain qualified training in safe and proper riding
techniques.
● Obtain professional technical service as indicated
in this Owner´s Manual and/or when made necessary by mechanical conditions.
Safe Riding
Perform the pre-operation checks each time you
use the vehicle to make sure it is in safe operating
condition. Failure to inspect or maintain the vehicle
properly increases the possibility of an accident or
equipment damage. See the page for a list of pre-operation checks.
SAFETY INFORMATION
3 - 4
● This vehicle is designed to carry the operator and
a passenger.
● The failure of motorists to detect and recognize
vehicles in traffic is the predominating cause of
automobile/vehicle accidents. Many accidents have
been caused by an automobile driver who did not
see the vehicle. Making yourself prominent appears
to be very effective in reducing the chance of this
type of accident. Therefore:
• Wear a brightly colored jacket.
• Use extra caution when you are approaching
and passing through intersections, since intersections are the most likely places for vehicle accidents
to occur.
• Ride where other motorists can see you. Avoid
riding in another motorist’s blind spot
● Many accidents involve inexperienced operators.
In fact, many operators who have been involved in
accidents do not even have a current driver´s
license.
• Make sure that you are qualified and that you only
lend your vehicle to other qualified operators.
• Know your skills and limits.
Staying within your limits may help you to avoid an
accident.
• We recommend that you practice riding your vehicle where there is no traffic until you have become
thoroughly familiar with the vehicle and all of its controls.
● Many accidents have been caused by error of the
vehicle operator. A typical error made by the operator
is veering wide on a turn due to excessive speed or
under- cornering (insufficient lean angle for the
speed).
• Always obey the speed limit and never travel faster
than legal speed limit.
• Always signal before turning or changing lanes.
Make sure that other motorists can see you.
● The posture of the operator and passenger is
important for proper control.
• The operator should keep both hands on the handlebar and both feet on the operator footrests during
operation to maintain control of the vehicle.
• The passenger should always hold onto the operator, the seat strap or grab bar, if equipped, with both
hands and keep both feet on the passenger footrests. Never carry a passenger unless he or she can
firmly place both feet on the passenger footrests.
● Never ride under the influence of alcohol or other
drugs.
● This vehicle is designed for on-road use only. It is
not suitable for off-road use.
Protective apparel
The majority of fatalities from vehicle accidents are
the result of head injuries. The use of a safety helmet
is the most critical factor in the prevention or reduction of head injuries.
● Always wear an approved helmet.
● Wear a face shield or goggles.
Wind in your unprotected eyes could contribute to an
impairment of vision that could delay seeing a
hazard.
● The use of a jacket, substantial shoes, trousers,
gloves, etc., is effective in preventing or reducing
abrasions or lacerations.
● Never wear loose-fitting clothes, otherwise they
could catch on the control levers or wheels and
cause injury or an accident.
● Always wear protective clothing that covers your
legs, ankles, and feet. The engine or exhaust system become very hot during or after operation and
can cause burns.
● A passenger should also observe the above precautions.
Avoid Carbon Monoxide Poisoning.
All engine exhaust contains carbonmonoxide, a
deadly gas. Breathing carbon monoxide can cause
headaches, dizziness, drowsiness, nausea confusion, and eventually death.
Carbon Monoxide is a colorless, odorless, tasteless
gas which may be present even if you do not see
5 - 6
or smell any engine exhaust. Deadly levels of carbon
monoxide can collect rapidly and you can quickly be
overcome and unable to save yourself. Also, deadly
levels of carbon monoxide can linger for hours or
days in enclosed or poorly ventilated areas. If you
experience any symptoms of carbon monoxide poisoning, leave the area immediately, get fresh air, and
SEEK MEDICAL TREATMENT.
● Do not run engine indoors. Even if you try to venti-
late engine exhaust with fans or open windows and
doors, carbon monoxide can rapidly reach dangerous levels.
● Do not run engine in poorly ventlated or partially
enclosed areas such as barns, garages.
● Do not run engine outdoors where engine exhaust
can be drawn into a building through openings
such as windows and doors.
Further safe-riding points
● Be sure to signal clearly when making turns.
● Braking can be extremely difficult on a wet road.
Avoid hard braking, because the vehicle could slide.
Apply the brakes slowly when stopping on a wet surface.
● Slow down as you approach a corner or turn. Once
you have completed a turn, accelerate slowly.
● Be careful when passing parked cars. A driver
might not see you and open a door in your path.
● Railroad crossings, streetcar rails, iron plates on
road construction sites,and manhole covers become
extremely slippery when wet. Slow down and cross
them with caution. Keep the vehicle upright, otherwise it could slide out .
● The brake pads could get wet when you wash the
vehicle. After washing the vehicle, check the brakes
before riding.
● Always wear a helmet, gloves, trousers (tapered
around the cuff and ankle so they do not flap), and a
bright colored jacket.
● Do not carry too much luggage on the vehicle. An
overloaded vehicle is unstable. Use a strong cord to
secure any luggage to the carrier (if equipped). A
loose load will affect the stability of the vehicle and
could divert your attention from the road.
DESCRIPTION
Left view
Right view
8
9
12 13
10
11
1 Clutch lever
2 Left handle switch
3 Meter
4 Key switch
8 Kick start lever
9 Rear brake pedal
10 Fuel tank switch
11 Shift pedal
12 Main stand
13 Side stand
5 Right handle switch
7 Front brake lever
6 Throttle grip
1 6 7 52 43
7 - 8
TIP
CONSUMER INFORMATION
The vehicle ident ification number or
the engine seri al
number are used to
register the vehi cle,they are also to
assist your dealer in
terms of order ing
parts or ref erring to
special service
information
Meter & Indicator
engine serial number
● The vehicle identification number ① is
stamped on the right
side steering head
tube.
● The engine serial
number ② is stamped
on the lower left of the
crankcase.
Vehicle identification number
( VIN )
*LBBXEHAD9EBB26219*
1
VIN No.
ENGINE No.
1. Gear Indicator Lamp
Numbers on the meter indicate the
gear position of the vehicle.
2. Neutral Indicator Lamp
When the transmission is shifted to neutral
position, the indicator is on.
3. High Beam Indicator Lamp
When the high beam lamp of the headlamp turns on,
the high beam indicator lamp would be on.
4. Tachometer
It indicates the revolving speed of the engine.
5. Speedometer
Speedometer shows the running speed.
6. Odometer & trip meter:
Relative mileage (TRIP): it records the mileage the vehicle covers in a period of time.
Odometer (TOTAL): it records the total mileage the vehicle has covered in km.
7. Adjust button
Short press the button to
switch between km/h and mph.Long press the button to
reset the "Trip" mileage.
8. Fuel Level Indicator：
It indicates the fuel level in the fuel tank.
9. Turning Indicator
The lamps would flash with the turning signals.
10. Clock
It shows the time.
11. Select button
Short press the button to switch between trip and odometer functions on the meter.
Press button “SELECT” for several seconds, there will
appear the interface for time adjustment:
“SELECT” for selection of digits of time display and
“ADJUST” for adjustment of each value.
1
7
2
3
4
11
8
9
10
5 6
INSTRUMENT AND CONTROL
FUNCTIONS
Key Switch
The Steering Lock
“ ”（Off）position:
All the circuits are off.
“ ”（On） position:
The circuits are on.
It is set at the lower right
side of the head tube.
When using it, steer the
handle to the left, and insert
the ignition key into the
steering lock and turn it
clockwise.
Do not turn your key to loc k the vehicle whil e
driving which is no t necessary and is also apt to
cause accident.
Press the key in a prope r force.
NOTICE
QJ157FMI-B
*41067014*
2
Loading...
