KEC KRA769U, KRA768U, KRA766U, KRA772U, KRA770U Datasheet
...
2002. 7. 9 1/6
SEMICONDUCTOR
TECHNICAL DATA
KRA766U-KRA772U
EPITAXIAL PLANAR PNP TRANSISTOR
Revision No : 3
SWITCHING APPLICATION.
INTERFACE CIRCUIT AND DRIVER CIRCUIT APPLICATION
FEATURES
With Built-in Bias Resistors.
Simplify Circuit Design.
Reduce a Quantity of Parts and Manufacturing Process.
EQUIVALENT CIRCUIT
MAXIMUM RATING (Ta=25 )
MARK SPEC
TYPE NO.
R1(k ) R2(k )
KRA766U 1 10
KRA767U 2.2 2.2
KRA768U 2.2 10
KRA769U 4.7 10
KRA770U 10 4.7
KRA771U 47 10
KRA772U 100 100
CHARACTERISTIC SYMBOL RATING UNIT
Output Voltage
KRA766U 772U
V
O
-50 V
Input Voltage
KRA766U
V
I
-10, 5
V
KRA767U -12, 10
KRA768U -12, 5
KRA769U -20, 7
KRA770U -30, 10
KRA771U -40, 15
KRA772U -40, 10
Output Current
KRA766U 772U
I
O
-100 mA
Power Dissipation
PD *
200 mW
Junction Temperature
T
j
150
Storage Temperature Range
T
stg
-55 150
TYPE KRA766U KRA767U KRA768U KRA769U KRA770U KRA771U KRA772U
MARK P2 P4 P5 P6 P7 P8 P9
EQUIVALENT CIRCUIT (TOP VIEW)
BIAS RESISTOR VALUES
* : Total Rating.
Marking
OUT
R1
IN
R2
COMMON(+)
B
B1
DIM MILLIMETERS
1
C
A
2
A1
C
3
H
1. Q COMMON (EMITTER)
1
2. Q IN (BASE)
1
3. Q OUT (COLLECTOR)
2
4. Q COMMON (EMITTER)
2
5. Q IN (BASE)
2
6. Q OUT (COLLECTOR)
1
G
6
A
5
B
D
4
B1
C
D
G
H
T
T
_
2.00 0.20
+
_
+
1.3 0.1A1
_
2.1 0.1
+
_
1.25 0.1
+
0.65
0.2+0.10/-0.05
0-0.1
_
0.9 0.1
+
0.15+0.1/-0.05
US6
65 4
Q1
Q2
1
23
6
Type Name
54
123
2002. 7. 9 2/6
KRA766U-KRA772U
Revision No : 3
ELECTRICAL CHARACTERISTICS (Ta=25 )
Note : * Characteristic of Transistor Only.
CHARACTERISTIC SYMBOL TEST CONDITION MIN. TYP. MAX. UNIT
Output Cut-off Current
KRA766U 772U
I
O(OFF)
VO=-50V, VI=0
- - -500 nA
DC Current Gain
KRA766U
G
I
VO=-5V, IO=-5mA
33 - -
KRA767U
VO=-5V, IO=-20mA
20 - -
KRA768U
VO=-5V, IO=-10mA
33 - -
KRA769U
VO=-5V, IO=-10mA
30 - -
KRA770U
VO=-5V, IO=-10mA
24 - -
KRA771U
VO=-5V, IO=-5mA
33 - -
KRA772U
VO=-5V, IO=-5mA
62 - -
Output Voltage
KRA766U
V
O(ON)
IO=-10mA, II=-0.5mA
- - -0.3
V
KRA767U
IO=-10mA, II=-0.5mA
- -0.1 -0.3
KRA768U
IO=-10mA, II=-0.5mA
- - -0.3
KRA769U
IO=-10mA, II=-0.5mA
- -0.1 -0.3
KRA770U
IO=-10mA, II=-0.5mA
- -0.1 -0.3
KRA771U
IO=-10mA, II=-0.5mA
- -0.1 -0.3
KRA772U
IO=-5mA, II=-0.25mA
- -0.1 -0.3
Input Voltage (ON)
KRA766U
V
I(ON)
VO=-0.3V, IO=-20mA
- -0.98 -3
V
KRA767U
VO=-0.3V, IO=-20mA
- -1.83 -3
KRA768U
VO=-0.3V, IO=-20mA
- -1.22 -3
KRA769U
VO=-0.3V, IO=-20mA
- -1.76 -2.5
KRA770U
VO=-0.3V, IO=-2mA
- -2 -3
KRA771U
VO=-0.3V, IO=-2mA
- -3.9 -5
KRA772U
VO=-0.3V, IO=-1mA
- -1.64 -3
Input Voltage (OFF)
KRA766U
V
I(OFF)
VCC=-5V, IO=-100 A
-0.3 -0.63 -
V
KRA767U -0.5 -1.15 KRA768U -0.3 -0.67 KRA769U -0.3 -0.82 KRA770U -0.8 -1.68 KRA771U -1 -3.09 KRA772U -0.5 -1.17 -
Transition Frequency
KRA766U 772U
fT* VO=-10V, IO=-5mA
- 250 - MHz
Input Current
KRA766U
I
I
VI=-5V
- - -7.2
mA
KRA767U - - -3.8
KRA768U - - -3.8
KRA769U - - -1.8
KRA770U - - -0.88
KRA771U - - -0.16
KRA772U - - -0.15
