KDDI exilim CA005 User Manual

BasicManual

Illustrationsand Screenshots inThisManual

Noteson CellPhoneUse

Contents

GettingReady

Makingand AnsweringCalls

GlobalFunction

CharacterInput

Read this manual To master

the cellular phone

AddressBook

Mail

Camera

EZweb

EZNewsEX

EZNavi

TV(1Seg)

TeensMode

InCaseofLoss ofYourCA005

Troubleshooting

Index

Introduction

Thank you for purchasing the CA005. Before using your CA005, be sure to read the CA005 Basic Manual (this PDF manual) to ensure correct usage. After you have finished reading this manual, store this PDF manual and the printed manuals in safe places so you can retrieve them whenever you need them.

All mentions of "the CA005" in this manual refer to "theEXILIMケータイCA005."

•

Manuals for the CA005

There are three manuals for the CA005: the Basic Manual, printed Instruction Manual (Japanese) and full Instruction Manual (Japanese).

● For learning the basics:

Read the CA005 Basic Manual (this manual) or printed CA005 Instruction Manual (Japanese).

● For learning details of each function:

The full Instruction Manual (Japanese) gives detailed instructions on using each function and can be downloaded from the au homepage: http://www.au.kddi.com/torisetsu/index.html To ensure proper usage of the CA005, be sure to read the Safety Precautions “安全上のご注意” in the Instruction Manual.

To access from EZweb (free of packet communication charge):

•

R⇒ T

op Menu/Search ⇒

Scan this QR code to access the au Online Manual. ▶

auお客さまサポート

(au Customer Support) ⇒

オンラインマニュアル

(Online Manual)

Illustrations and Screenshots in This Manual

Note on Illustrations

■

The illustrations in this manual may look different from the actual cell phone in shape, color and typeface. The key illustrations are also simplified as shown below.

Key Illustration Key Illustration

① & ⑦ R

⑤

①

②

② ③

③

④

■

Note on Screenshots

⑥

⑦

⑦ ⑧

⑧ ⑨

⑨

⑩

⑩ ⑪

⑪ ⑫

⑫ ⑬

⑬ ⑭

⑭

⑮

The screenshots in this manual are simplified and may look different from the actual cell phone screens.

The display design themes of the CA005 vary by model color. The screenshots for the Black models are used in this

• manual.

② L ⑧ C ③ N ⑨ F

123 456

④

789 *0#

⑩ i ⑪ ( ⑫ g

⑬ f ⑤ cjsa ⑭ b ⑥ % ⑮ )

Illustrations and Screenshots in This Manual

1

Notes on Cell Phone Use

Cell Phone Etiquette

The cell phone always emits weak radio waves when power is on. Use the cell phone in an enjoyable and safe manner without forgetting to be considerate of others around you.

●

Use of cell phones is not allowed in some places.

•

Do not use the cell phone while you are driving. Doing so is both dangerous and prohibited by law.

•

Using a cell phone in an aircraft is prohibited by law. Set Airplane Mode to ON and turn the cell phone power off.

●

Radio waves from cell phones may interfere with medical electrical equipment.

•

Some people close to you in crowded places such as packed trains may be using a cardiac pacemaker. Turn the cell phone off in such places.

•

Abide by the rules of hospitals and other medical institutions where it is forbidden to use or carry cell phones.

●

Be considerate of where you use the cell phone and how loudly you talk.

•

Do not make calls in theaters, museums, libraries, and other similar places. Turn power off or turn on manner mode not to disturb others around you by ring tones.

•

Do not use the cell phone on a street where you might interrupt the flow of pedestrians. Move to areas where you will not inconvenience others

• on trains or in hotel lobbies.

•

Refrain from talking in a loud voice.

•

Obtain the permission of other people before you take their photos with the cell phone's camera. Do not record information with the cell phone's camera

• in bookstores and other locations where taking photos is not permitted.

Do Not Use the Cell Phone While Driving!

Turn off your cell phone or put it in Drive Mode while driving.

Do not use the cell phone while driving a car/motorcycle or riding a bicycle. It may result in a traffic accident. Using a cell phone while driving is prohibited by law. Using a cell phone while riding a bicycle may also be punishable by law.

Prohibited!

Looking at a cell phone display

• Talking on a cell phone while holding it

•

Drive Mode

In Drive Mode, a Japanese message meaning "I'm driving now, so I can't answer your call." is played when a call is received, and asks the caller to leave a message on the answer memo. When the standby screen is displayed, press

to select Drive, and then press (Set).

, use

2

Disaster Message Board Service

When a large scale disaster occurs, you can register your safety information from EZweb. The registered information can be referred from anywhere in Japan from EZweb or Internet.

When a large scale disaster occurs,

Registering

safety

information

Inquiring

for safety

information

Access

• from an au phone, you can register your safety information (i.e. your condition and comments) to the 災害用伝言板 (Disaster Message Board) created on the EZweb. After registration of your safety

• information, e-mail is sent to your family or acquaintances you have previously designated to notify that your safety information has been uploaded to the 災害用伝言板 (Disaster Message Board).

You can inquire for safety information

• of a person by entering his/her phone number from EZweb or Internet.* * To inquire from other carriers' cell

phone, a PHS or PC, access "http://dengon.ezweb.ne.jp/".

R ⇒ T

op Menu/Search ⇒

(Disaster Message Board)

http://dengon.ezweb.ne.jp/

災害用伝言板

•

Registered information is stored until the service set up for the disaster ends.

•

The maximum available number of registrations is 10 per phone number. When the number of registrations exceeds 10, the oldest one is overwritten. The demonstration of this service can be referred to

• anytime by pressing

客さまサポートる

(Search ) ⇒

Message Board (Demo Version)).

•

To view the Disaster Message Board in English, select English from the top menu of the Disaster Message Board.

⇒ Top Menu/Search ⇒

(au Customer Support) ⇒

災害用伝言板（デモ版）

auお

調べ

(Disaster

Notes on Cell Phone Use

3

Water Resistance

The CA005 complies with IPX5*1 and IPX7*2 water

Notes on Cell Phone Use

protection standards (JIS C 0920).

1

*

IPX5 compliant means that this cell phone continues

to function as a phone after being subjected to a water jet (approximately 12.5 liters/min.) discharged from a nozzle (inner diameter: 6.3 mm), from all directions (approximately three meters from the cell phone) for three minutes or more.

2

*

IPX7 compliant means that this cell phone continues

to function as a phone and no water seeps inside after being gently lowered into a tank filled with still tap water (at normal temperature) to the depth of one meter, and immersed at the bottom for approximately 30 minutes.

•

The CA005 is resistant to fresh or tap water at normal temperature (5℃ - 35℃) only.

•

The CA005 is resistant to water when the external connection jack cover, microSD memory card slot cover and battery pack cover are closed firmly. Malfunction resulting from misuse is not covered by

• the warranty.

4

Checking the Contents of the Box …………………… 7 Names of Parts ………………………………………… 8 Position of CA005 ……………………………………… 9 Replacing the Battery Pack …………………………… 10 Charging the Battery Pack …………………………… 11 Learning the Basics …………………………………… 12 Turning On Power ……………………………………… 13 Switching the Display Language to English ………… 13 Initial Setup of E-mail and EZweb …………………… 13 Checking Your Phone Number and E-mail Address … 13 Display Indicators ……………………………………… 14 Using Main Menu ……………………………………… 15 Changing Your E-mail Address ……………………… 17 Security Code and Passwords ………………………… 18 Using CA005 in Viewfinder Position ………………… 19

1

Making and Answering Calls 20

Making a Call …………………………………………… 20 Making an International Call …………………………… 20 Answering a Call ……………………………………… 21 Returning a Call (Outgoing History/Incoming History One-ring Calls …………………………………………… 21 Adjusting the Earpiece Volume during a Call ……… 22 Turning On Manner Mode ……………………………… 22 Changing the Incoming Ring Tone …………………… 22 Adjusting the Incoming Ring Tone Volume …………… 23 Turning On the Answer Memo ………………………… 23

) … 21

Global Function 25

Setting the Area ………………………………………… 25 Obtaining the Latest PRL (Preferred Roaming List) … 25 Calling Japan from Overseas ………………………… 26

Character Input 27

Character Entry Modes ………………………………… 27 Entering Alphanumeric Characters …………………… 27 Entering E-mail Addresses …………………………… 28 Entering Pictograms/Decoration-Emojis/Symbols/ Face Marks ……………………………………………… 29

Address Book 30

Saving an Address Book Entry ……………………… 30 Dialing from the Address Book ……………………… 30 Editing Address Book Entries ………………………… 30 Saving a Phone Number from the Incoming or Outgoing History …………………………………… 31

Contents

5

Mail 32

Using E-mail …………………………………………… 32 Creating and Sending E-mail Messages …………… 32

Contents

Reading Received E-mail Messages ………………… 33 Reading an E-mail Message with an Attached Photo or Movie ……………………… 33 Replying to Received E-mail Messages ……………… 33 Rejecting Spam ………………………………………… 34 Using C-mail …………………………………………… 35 Creating and Sending C-mail Messages …………… 35 Reading Received C-mail Messages ………………… 35

Camera 36

Photo Taking Tips ……………………………………… 36 About Photo Modes …………………………………… 36 Taking a Photo ………………………………………… 37 Taking a Photo in Viewfinder Position ………………… 37 Viewing Photos ………………………………………… 38

EZweb 39

Accessing Sites ………………………………………… 40 Bookmarking Frequently Accessed Pages ………… 41 Viewing Bookmarked Pages …………………………… 41 Checking Charges ……………………………………… 42 Downloading Chaku-Uta-Full-Plus™/ Chaku-Uta-Full

EZ News EX

Basic Operations ……………………………………… 43 Setting EZ News EX …………………………………… 43

®

/Chaku-Uta® ………………………… 42

43

EZ Navi 45

Passenger Seat Navi for People in the Passenger Seat to Check the Route ………… 45 Security Navi to Check Where Your Kids Are ……… 45 EZ Navi Walk for When You Go Out ………………… 46 Evacuate Navi to Guide You Home or to Nearby Evacuation Areas during Disasters …………………… 47

TV (1Seg)

Initial Setup of au Media Tuner ………………………… 49 Watching TV (1Seg) …………………………………… 49 Basic Operations ……………………………………… 50 Watching TV (1Seg) in Viewfinder Position ………… 50 Exiting the au Media Tuner …………………………… 50

48

Teens Mode 51

Setting Teens Mode …………………………………… 51

In Case of Loss of Your CA005 52

Setting Conditions for Activating the Remote Ctrl Lock ………………………………………………… 52 Remotely Activating the Remote Ctrl Lock on Your CA005 ………………………………………… 52 Activating the Remote Ctrl Lock by the Security Lock Service ………………………… 53

Troubleshooting 54

Index 56

6

Getting Ready

Checking the Contents of the Box

The box contains the cell phone and accessories.

Cell phone• Battery pack• Instruction Manual (Japanese)

•

The following accessories are not included.

- microSD memory card - Desktop holder - AC adapter

- USB cable - Earphone jack conversion adapter - Stereo earphone Purchase a specified AC adapter (sold separately) and a commercially available microSD memory card.

•

Warranty (Japanese)

•

Safety Precautions (Japanese)

•

Global Passport CDMA Owner's Guide (Japanese)

•

Osaifu-Keitai

•

JIBUN BANK Launcher Operation Guide (Japanese)

•

Dynamic Photo Guide (Japanese)

•

YouTube Uploader for CASIO mobile Leaflet (Japanese)

®

Guide (Japanese)

Getting Ready

7

Names of Parts

From the Front■

Optical sensor

Earpiece

Getting Ready

Earpiece

Display

Center key

Center key Cursor key

Cursor key

Address

Address book key

book key

Mail key

Answer key

Number keys

Microphone

Application key

EZ key

EZ key Clear/Memo key

Clear/Memo key End/Power key

End/Power key

From the Back■ From the Sides■

FeliCa mark

Incoming

indicator

(LED)

Speaker

Built-in

TV antenna

Photo light/

Photo light/ Pocket light

Pocket light

Camera

ring lamp

Battery pack/

cover

au IC-Card*

Manner key

Quick key

Charge indicator (LED)

microSD

microSD memory

memory card slot

card slot

cover

Built-in

Built-in antenna

antenna

Camera lens

Infrared port

Built-in

Built-in antenna

antenna

* Do not remove this card unnecessarily

as your phone number is recorded on it.

microSD memory

microSD memory card slot

card slot

External connection

External connection jack cover

jack cover

Up key (side)

Down key (side)

Center key

Shutter key

External

External connection jack

connection jack

Charging

Charging terminals

terminals

(side)

Strap

Strap eyelet

eyelet

8

Position of CA005

CA005 can not only be opened with the display facing inside, but also it can be used in Viewfinder position or Selfportrait position.

Viewfinder Position

■

Open the cell phone so that the display stands

➡

at 90 degrees (1-1), and rotate it 180 degrees clockwise (1-2 and 1-3).

1-1 1-2 1-31-1 1-2 1-3

➡

Close the cell phone.

22

In Illustrations 1-2 and 1-3, rotate the display in the

• directions of the arrows. Do not try to rotate the display when it is not in the position that Illustration 1-1 shows, or do not rotate the display over 180 degrees. Excess pressure may cause a malfunction.

•

When the cell phone is in the position that Illustration 1-2 shows, do not operate the CA005 or open/close the display with force.

•

To avoid an error, keep your fingers away from the keys when you are changing the position. Keep the display facing inside and closed when you

• carry the cell phone in your pocket or bag. The operating procedures in this manual apply when

• the cell phone is open and the display is facing inside, unless the cell phone's position is specified. To operate in Viewfinder position, press the side

• keys ( operations, see "Using CA005 in Viewfinder Position" on page 19. By default, the EXILIM menu appears when you set

• the cell phone to Viewfinder position while the standby screen or the main menu is displayed. For details about the EXILIM menu, see "Using the EXILIM Menu" on page 37.

Self-portrait Position

■

Open the display in Illustration 2 of "Viewfinder Position" (illustrated to the left) to set CA005 to Self-portrait position. When the cell phone is in Self-portrait position, you can take a photo with the lens facing toward yourself.

). For details on key

Getting Ready

9

Replacing the Battery Pack

Use only the battery pack for the CA005, and be sure to install it correctly.

Note on Removing the Battery Pack

■

Getting Ready

Cover

Do not pull up on the battery pack cover by forcibly pushing the the cover with fingers, as illustrated on the right. If the cover becomes extremely bent, the battery pack cover is damaged, which may cause injury.

Removing the Battery Pack

■

Insert your fingers at ① and ②

➡

in that order and then pull the battery pack cover upward.

➡

Hold the cover on both sides ③ and pull up to remove it.

➡

Move the lock slider to the "FREE" position.

part of

Recessed

Recessed part

part

③

Lock sliderLock slider

②

①②①

Battery pack cover

Remove the battery pack,

➡

by pulling up on the Pull tab.

Before removing the battery pack, turn the cell phone

• power off. When removing the battery pack, pull up on the Pull

• tab. Doing otherwise may result in damage to the contacts.

Attaching the Battery Pack

■

Move the lock

➡

slider to

Lock sliderLock slider

the "FREE" position.

➡

With the Pull tab of the

battery pack facing up, align the contacts on the battery pack with those of the cell phone,

Lock

Lock slider

slider

Pull tab

Contacts

and insert the battery pack securely. Then move the lock slider to the "LOCK" position.

Pull tabPull tab

10

Place the battery pack

➡

cover on the cell phone correctly and then push at the 11 places marked with circles on the right.

➡

Trace both sides of the

battery pack cover with fingers to check for any part of the cover not properly closed.

Before attaching the battery pack, make sure that the

• au IC-Card is inserted securely. Failure to follow the correct procedures when attaching

• the battery pack may result in damage to the battery pack or battery pack cover. If the battery pack cover is forcibly pushed with fingers

• with the tabs of the battery pack cover attached on the battery pack, the tabs may be damaged.

Charging the Battery Pack

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery pack before using the cell phone for the first time.

•

An AC adapter is not included. Purchase a specified AC adapter (sold separately).

Charge indicator (LED)

3

1

Connect a specified AC adapter to the cell

➡

2

phone with the battery pack attached.

Open the external connection jack cover. Check the

• shape of the connector of the AC adapter, and plug it straight into the external connection jack.

Unfold the power plug of the AC adapter and

➡

plug it into a 100 V AC power outlet.

Confirm that the charge indicator (LED) lights.

➡

Charging: A charge beginning sounds and the charge

• indicator (LED) lights. Charging finished: A charge completion sounds and

• the charge indicator (LED) goes out.

Be sure to close the external connection jack cover

• when charging is finished. Do not pull or twist the external connection jack cover

• forcibly. Be sure to use the common AC adapter 02 (sold

• separately) when charging overseas.

Getting Ready

11

Learning the Basics

Key Assignments

■

: Display Incoming History.

l

: Display Notification window/

d

Getting Ready

12

Shortcut menu.

: Use Address Book.

&

: Display E-mail/C-mail menu.

L

: Set/cancel Answer memo.

C

Delete characters.

Delete characters. Cancel operation.

Cancel operation.

: Make/answer calls.

N

■

Side Key Assignments

i:

Display QuickAccess menu.

i:

Display QuickAccess menu.

(:

Set/cancel Manner Mode.

(:

Set/cancel Manner Mode.

b: Activate Pocket light.

(hold down for at least one second)

For details on side key assignments, see page 19.

If you lose track of where you are or if you make a mistake, press to return to the previous screen. Return to the

• standby screen by holding down

for at least one second.

: Display the ticker field and info pane.

u

: Display Outgoing History.

r

: Display Main menu.

c

: Display EZapps menu.

%

: Display EZ Service menu.

R

: Turn power on/off.

F

End call/communication.

 Cancel operation.

:

0〜9*#

Input phone numbers and characters.

h: Page scroll at browser display.

h: Page scroll at browser display. g: Activate ImageAlbum.

g: Activate ImageAlbum.

(hold down for at least one second)

f: Activate au Media Tuner.

(hold down for at least one second)

): Activate Camera.

(hold down for at least one second)

:

Notification

Hiding/Redisplaying the

■

Notification Window

When the Notification window is displayed on the standby screen, you can temporarily hide it by pressing & (Back) and then display the Main menu by pressing c. To redisplay the hidden Notification window, press d when the standby screen is displayed.

Notification

window

Turning On Power

Hold down F for at least a few seconds.

You cannot receive or make calls if (out of range

• indicator) is displayed.

Turning Off Power

■

When the standby screen is displayed, hold down F for at least one second.

Switching the Display Language to English

You can switch the display language for function names and other items to English.

When the standby screen is displayed, press c.

Use a to select

➡

press c (選択 [Select]).

機能

(Function) and then

Use j to select

➡

画面表示

(Screen Display) and

then press c (選択 [Select]). Use j to select Set Language and then press

➡

c (選択 [Select]). Use j to select English and then press

➡

c (Set).

Initial Setup of E-mail and EZweb

To use e-mail and EZweb, you need to apply for an EZweb subscription. If you did not apply for an EZweb subscription at the time of purchase, contact an au shop or the au Customer Service Center. Also, before use, you need to configure initial settings. Your e-mail address is assigned automatically in the initial setup.

When the standby screen is displayed, press L.

➡

Press c (OK).

After a short while, your e-mail address is displayed.

➡

Press c (OK).

The initial settings are complete.

You can also configure initial settings by pressing

• or

.

Checking Your Phone Number and E-mail Address

When the standby screen is displayed, press c and then 0.

Getting Ready

13

Display Indicators

Display indicators inform you of mail arrival, current settings, etc.

Display

■

①

③ ⑩⑨⑧⑥①

③ ⑩⑨⑧⑥

②④⑤

Getting Ready

⑫

⑭

⑦

Indicator Description

① ②

⑪

③

④

⑤ ⑥

⑬

⑦ ⑧

⑮

⑨

⑱

⑰⑯

⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱

Signal strength

Battery level

A microSD memory card (commercially available) inserted

During a call

au Media Tuner activated

EZapps activated

Connecting to EZweb

Receiving EZ News EX information

Missed calls

New or unread e-mail/C-mail

Current date and time

Ticker field

Search window

Info pane

Notification icon

Shortcut menu

Auto Lock activated/Side key disable feature on



Manner mode set

 

Answer memo or manner mode set

14

Using Main Menu

You can access various functions from the Main menu. The Main menu patterns vary by model color. The screenshots for the Black models are used in this manual.

Model Color Main Menu Pattern

Black Standard

Pink × Purple Photo

White

Light Green

ahiru

Getting Ready

15

Each Main menu pattern has a different set of items.

Standard Photo ahiru Simple

Getting Ready

microSD Function Camera Camera

Data Folder Bluetooth/IrComm TV Data Folder

PC Site Viewer

Function Dynamic Photo

TV Movie Bluetooth/IrComm TV

Camera Photo Function Bluetooth/IrComm

LISMO ImageAlbum ImageAlbum Settings

Watch/Calendar Data Folder Data Folder Accessories

EZ FeliCa microSD microSD

ImageAlbum TV EZ FeliCa

Bluetooth/IrComm LISMO Watch/Calendar

Accessories Accessories Accessories

PC Site Viewer LISMO microSD

PC Site Viewer

LISMO

16

Changing Your E-mail Address

You can change the account name of your e-mail address.

When the standby screen is displayed, press L.

Use j to select E-mail Setup and then press

➡

c (Select). Use j to select Change adrs/Other and then

➡

press c (Select).

The cell phone connects to the server.

Use j to select

➡

Eメールアドレスの変更

E-mail Address) and then press c (Select). Use j to select the entry box, press c (Input),

➡

enter your security code, and then press c (OK).

Your security code is the four-digit number you wrote

• on your subscription form. If the security code is incorrectly entered three times

• consecutively during a single day, the e-mail address change operation will be disabled until the next day.

Use j to select 送信 (Send) and then press

➡

c (Select).

E-mail address

△△△@ezweb.ne.jp

Account name Domain name

(Change

Use j to select

➡

承諾する

(Accept) and then

press c (Select). Use j to select the entry box, press c (Input),

➡

enter an e-mail address using single-byte alphanumeric characters, and then press c (OK).

For details on entering e-mail addresses, see page 28.

•

Use j to select 送信 (Send) and then press

➡

c (Select). Use j to select OK, press c (Select) and then

➡

c (OK).

Check that the e-mail address has been updated

•

before pressing c (OK).

Your e-mail address cannot be changed if the new

• address you enter in the above procedure is already being used. In this case, enter a different e-mail address.

Getting Ready

17

KDDI exilim CA005 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Introduction

Illustrations and Screenshots in This Manual

Notes on Cell Phone Use

Cell Phone Etiquette

Do Not Use the Cell Phone While Driving!

Disaster Message Board Service

Water Resistance

Contents

Getting Ready

Checking the Contents of the Box

Names of Parts

Position of CA005

Replacing the Battery Pack

Charging the Battery Pack

Learning the Basics

Turning On Power

Switching the Display Language to English

Initial Setup of E-mail and EZweb

Checking Your Phone Number and E-mail Address

Display Indicators

Using Main Menu

Changing Your E-mail Address
