KBC ESUL5P User Manual
Ethernet Switch
ESUL5P
User Manual
Ethernet Switch User Manual
TABLE OF CONTENTS
1 OVERVIEW ................................................................................. 3
1.1
I
NTRODUCTION
............................................................................................ 3
1.1.1 ESUL5P.............................................................................................. 3
1.2
T
ECHNICAL SPECIFICATION
.............................................................................. 4
2 INSTALLATION ............................................................................. 5
2.1
P
ACKAGE CONTENTS
2.2
C
ONFIGURATIONS
2.2.1 Physical Connections ........................................................................... 6
2.3
I
NSTALLATION METHOD
2.3.1 DIN Rail Mount ................................................................................... 7
2.3.2 Wall-mount ........................................................................................ 7
2.4
E
2.5
2.6
2.7
THERNET
P
OWER CONNECTIONS
F
AULT ALARM CONTACT
LED S
RJ45 C
TATUS
............................................................................................... 9
...................................................................................... 5
......................................................................................... 5
................................................................................... 7
ONNECTIONS
.................................................................................... 8
................................................................................... 8
......................................................................... 7
3 TROUBLESHOOTING .................................................................... 10
3.1
S
ELF-TESTING
........................................................................................... 10
4 SYSTEM EXAMPLE ....................................................................... 11
5 DIMENSIONS (MM) ....................................................................... 11
6 WARRANTY .............................................................................. 12
6.1
W
6.2
6.3
ARRANTY INFORMATION
C
LASS A
FCC ....................................................................................................... 13
ITE ............................................................................................ 13
.............................................................................. 12
7 INSTRUCTION OF DISASSEMBLY ...................................................... 13
Manual-ESUL5P_Series_HW-Rev1112
Copyright © KBC Networks Ltd. Page 2 of 14 www.kbcnetworks.com
Ethernet Switch User Manual
1 Overview
1.1 Introduction
This manual covers the ESUL5P series. The KBC Networks’ ESUL5P products are
high performance, unmanaged, five port industrial PoE Ethernet switches
designed for use in a wide range of operating temperatures in nonenvironmentally conditioned, industrial applications. The units have redundant
power supply terminals and an alarm output. All copper ports are automatically
configured and the plug-and-play design provides ease and speed of
installation.
1.1.1 ESUL5P
The ESUL5P provides connectivity for up to five, 10/100 RJ45 twisted pair
copper ports, with four PoE (IEEE802.3af) Injector Power over Ethernet (PoE)
ports. Each port supports a self-adaptive function allowing it to be configured to
10Base-T or 100Base-TX, full or half duplex operation mode. It is available as
either DIN rail or wall-mount configurations.
Manual-ESUL5P_Series_HW-Rev1112
Copyright © KBC Networks Ltd. Page 3 of 14 www.kbcnetworks.com
Ethernet Switch User Manual
1.2 Technical Specification
Switching
Mode Store-and-forward
Switching rate 14,881pps, 148,810pps
Backplane switching bandwidth 1.0Gbps
Mac address table 2k
ESUL5P
Ports
Copper
Physical port 5 x shielded RJ45
RJ45 port 10BASE-T/100Base-TX
Auto-negotiation
Standard IEEE 802.3
Transmission distance <100m
PoE
Physical port 4 x shielded RJ45
Standard IEEE 802.3af
Power supplied (per port) 15.4W @ 48Vdc
Electromagnetic compatibility
Interference EN55022 Class A
Immunity IEC61000-6-2
Power
Input voltage
Power consumption
Power supply Supplied separately
48Vdc
3.4W (no PoE)
67W ( full load PoE)
Environmental
Operating temperature -40°C - +74°C / -40°F - +165°F
Storage temperature -40°C - +74°C / -40°F - +165°F
Relative humidity 5% - 95%, Non-condensing
Mean Time Between Failure >300,000 hours
Mechanical
Dimensions (W x H x D) 30mm x 140mm x 95 mm
1.18” x 5.51” x 3.74”
Protection class rating IP30
Weight
Manual-ESUL5P_Series_HW-Rev1112
Copyright © KBC Networks Ltd. Page 4 of 14 www.kbcnetworks.com
460g
1lb
Ethernet Switch User Manual
2 Installation
2.1 Package Contents
• Ethernet switch fitted with DIN rail mount.
• 2 x Wall-mount brackets with screws
• Pluggable terminal block
• Quick Start Guide
Note: A 48Vdc PSU is required but supplied separately.
Please contact you dealer or distributor if a part is missing or damaged.
2.2 Configurations
Products are available in either DIN rail or wall-mount packages, with the following
configurations:
Product Type DIN Rail Wall-mount
ESUL5P
Manual-ESUL5P_Series_HW-Rev1112
Copyright © KBC Networks Ltd. Page 5 of 14 www.kbcnetworks.com
