K-BALL SERIES 171 AND 172 FLOATING BALL VALVES
MODEL CODE OPTIONS AND DESCRIPTIONS - NORTH AMERICA AND EUROPE ONLY
Model / Series
171SF - 0008 R3 PG 00 CC - CA S00 S0 T0 P0 I L - NP1 TPZ + GS-001
MODEL / SERIES
Code Description
171SF Series 171, Full Bore
172SF Series 172, Full Bore
SIZE
Code Description
0008 DN 8 / NPS ¼
0010 DN 10 / NPS ⅜
0015 DN 15 / NPS ½
0020 DN 20 / NPS ¾
0025 DN 25 / NPS 1
0032 DN 32 / NPS 1¼
0040 DN 40 / NPS 1½
0050 DN 50 / NPS 2
0065 DN 65 / NPS 2½
0080 DN 80 / NPS 3
0100 DN 100 / NPS 4
ZZZZ Special
END CONNECTION
Code Description
R3 Flange - ASME Raised Face (RF) -
BF Butt Weld - ASME B 16.25
SE* Screwed Ends (Threaded)
SW Socket Weld - ASME B16.11
S2 Socket Weld - Tube / Nipple Extension
BZ Butt Weld - welded Pipe or
H3 Hub/Clamp - Tri-Clamp
T0 Orbital Tubing (OD Tube)
MM Multiple / Mixed End Connection
ZZ Special
Size
End Connection
125 to 250 AARH
Extended Pups
Drilling / Schedule
Face to Face
Pressure Rating
Body Material
Ball Material
Stem Material
Seat Material
Sealing Material
Mounting Type
DRILLING / SCHEDULE
Code Description
PG PN 25 / 40
W1 Schedule 10
W4 Schedule 40
BT BSPT (Female)
BP* BSPP (Female)
NT* NPT (Female)
AC Socket Weld End
NA Not Applicable
2R BSPP / BSPT
2S BSPP / NPT
2N BSPP / Schedule 10
2P BSPP / Schedule 40
2T BSPP / Schedule 5
2U BSPP / Socket Weld
1C BSPT / BSPP
BN BSPT / NPT
2W BSPT / Schedule 10
1A BSPT / Schedule 40
1D BSPT / Schedule 5
BS BSPT / Socket Weld
1R NPT / BSPP
1Q NPT / BSPT
1M NPT / Schedule 10
1N NPT / Schedule 40
1L NPT / Schedule 5
NS NPT / Socket weld
1X Schedule 10 / BSPP
1V Schedule 10 / BSPT
1W Schedule 10 / NPT
1T Schedule 10 / Schedule 40
1S Schedule 10 / Schedule 5
1Y Schedule 10 / Socket Weld
2E Schedule 40 / BSPP
2C Schedule 40 / BSPT
Actuation Type
Optional Feature 1
Optional Feature ...
Code Description
2D Schedule 40 / NPT
2A Schedule 40 / Schedule 10
2X Schedule 40 / Schedule 5
2F Schedule 40 / Socket Weld
3M Schedule 5 / BSPP
3N Schedule 5 / BSPT
3P Schedule 5 / NPT
3R Schedule 5 / Schedule 10
3S Schedule 5 / Schedule 40
3T Schedule 5 / Socket Weld
1K Socket Weld / BSPP
1H Socket Weld / BSPT
1J Socket Weld / NPT
1E Socket Weld / Schedule 10
1F Socket Weld / Schedule 40
3U Socket Weld / Schedule 5
ZZ Special
Actuation Option
Emerson.com/FinalControl © 2019 Emerson. All Rights Reserved. VCREF-13363-EN20/12
K-BALL SERIES 171 AND 172 FLOATING BALL VALVES
MODEL CODE OPTIONS AND DESCRIPTIONS - NORTH AMERICA AND EUROPE ONLY
Model / Series
171SF - 0008 R3 PG 00 CC - CA S00 S0 T0 P0 I L - NP1 TPZ + GS-001
FACE TO FACE
Code Description
00 Standard (Refer to Product Literature)
01 EN558 Series 01
ZZ Special
PRESSURE RATING
Code Description
CC ASME 300 / 740 CWP / PN 40
CA ASME 400 / 1000 CWP / PN 63
ZZ Pressure Rating not Specified
BODY MATERIAL
Code Description
CA Carbon Steel A216 WCB
SE* Stainless Steel A351 CF8M
ZZ Special
Size
End Connection
Drilling / Schedule
Face to Face
Pressure Rating
Body Material
STEM MATERIAL
Code Description
S0* Stainless Steel 316
U0 Stainless Steel Duplex
SH Stainless Steel 17-4 PH /
ZZ Special
SEAT MATERIAL
Code Description
T0* PTFE
RC RPTFE (50% SS Filled)
RB RPTFE (25% Carbon Filled)
ZZ Special
SEALING MATERIAL
Code Description
P0* PTFE
ZZ Special
Ball Material
Stem Material
Type 630 H1150 D (NACE compliant)
Seat Material
Sealing Material
Mounting Type
Actuation Type
Optional Feature 1
Optional Feature ...
ACTUATION TYPE
Code Description
L Default Handle / Lever
OPTIONAL FEATURES
Code Description
NP1 Additional 316 stainless steel tag
TPZ Special hydrostatic test report
NOTE
For the full list of optional features, consult your local
Emerson representative.
ADDITIONAL ACTUATION OPTIONS
Code Description
PS-###### Standard pneumatic actuator
HZ Other handle
GZ Other gear operators
PZ Other pneumatic actuators
EZ Other electric actuators
BALL MATERIAL
Code Description
S00* Stainless Steel 316
ZZZ Special
OPERATOR MOUNTING TYPE
Code Description
I ISO 5211
NOTES
1.
Additional characters identify actuator configuration.
2. Required operator, mounting and accessory
part number(s) are specified per order
acknowledgment.
Actuation Option
[1]
[2]
[2]
[2]
[2]
NOTE
Consult your local Emerson representative for additional options.
* Indicates standard configuration
