TRANSCONTINENTAL SUPERSPORT
14/14 ABS
Page 2
™
TRANSCONTINENTAL SUPERSPORT
Most weekend sportbike riders have their own personal
favorite stretch of two-lane roads laced with fl owing
esses, challenging hairpins, and inviting straight-
aways. Now imagine expanding the possibilities to the
entire continent on the Concours 14, a sport-touring
machine so complete in its mastery of the road it
has earned several Motorcycle of the Year honors.
Its 1,352cc digitally fuel-injected DOHC In-Line Four
engine with variable valve timing leaps to the task,
delivering incredible midrange torque together with a
superbike-strength top-end punch – along with superb
smoothness from dual balancers. Whether sport-t ouing
by yourself, with that special someone, no gear, or fully
loaded, the Concours 14 allows you to easily adjust the
preload settings on the rear suspension for that perfect
ride. The chassis likewise offers unparalleled command
and comfort with an aluminum monocoque frame
and there’s an electrically adjustable windscreen,
Kawasaki’s Intelligent Proximity Activation Start
System (KI-PASS) for “no key” starting and security,
a Tetra-Lever Swingarm, detachable side cases, an
accessory power outlet and optional anti-lock brakes
take this a sport-touring machine to a whole new level.
No wonder all roads belong to the Concours 14.
14/14 ABS
Conveniently located on the fuel-tank cover, the Concours glove box can easily hold a wallet, sunglasses, garage-door opener or other small items while you’re riding.
Its generous 1.6-quart storage capacity improves versatility.. An easy-to-use centerstand improves parking stability and security for a fully loaded Concours 14.
CANDY DIAMOND RED / FLAT SUPER BLACK | | | METALLIC DIABLO BLACK / FLAT SUPER BLACK
1 Comprehensive multi-function LCD
instrumentation includes a trip
computer that estimates fuel mileage,
plus gear-indicator and tire-pressure
readouts for peace of mind. Controller
Area Network (CAN) circuitry reduces
complexity for improved reliability.
2 With its advanced geometry, the
unique 4-link Tetra-Lever Swingarm
provides the suspension response of
a chain-drive sportbike with the smoothness, quietness and reliability of a touring
bike’s shaft drive.
3 Lockable and detachable side cases
hold up to 22 pounds of gear—including
a full-face helmet. The rear rack further
expands storage capability with mounts
for an accessory top case.
news. product. race information. KAWASAKI.COM
Page 3
Engine Type
Displacement
Bore and Stroke
Maximum Torque
Compression Ratio
Fuel System
Ignition
Transmission
Final Drive
CONCOURS 14 / 14 ABS | | | SPECIFICATIONS
Rake / Trail
Front Tire Size
Rear Tire Size
Front Suspension /
Wheel Travel
Rear Suspension /
Wheel Travel
Front Brake Type
Rear Brake Type
Fuel Tank Capacity
Seat Height
Curb Weight
Wheelbase
Overal Length
Overall height windscreen min /
windscreen max
Overall width at handlebars /
at saddlebags
Color
Four-stroke, liquid-cooled, DOHC, four valve per cylinder,
In-Line Four with V VT(Variable Valve Timing
1,352cc
)
84.0 x 61.0mm
102.0 LbFt @ 6,200 rpm
10.7:1
Digital Fuel Injection
TCBI with Digital Advance
6-speed
Tetra-Lever shaft drive
26.1 degr ees / 4.4 in.
120/70 ZR-17
190/50 ZR-17
43mm inverted, telescopic fork with adjust able rebound
damping and spring preload / 4.4 in.
Tetra-Lever with stepless rebound damping adjustment and
remote spring preload adjuster / 5.4 in.
Dual fl oating 310mm petal discs with four-piston calipers
Single 270mm petal disc
5.8 gal.
32.1 in.
670.3 lbs. / 679.1 lbs. (ABS model)
59.8 in.
89.4 in.
50.8 / 55.3
30.7 in. / 39.4 in.
Metallic Diablo Black / Flat Super Black
Candy Diamond Red / Flat Super Black
Three-Year Warranty
Your new Concours motorcycle comes with a 36-month/unlimited mileage limited
factory warranty. Read the next paragraph to find out how you can extend your
coverage inexpensively, or ask your dealer for details about the factory warranty
and available extended coverage.
Up to Three Years Additional Coverage*
Let Kawasaki protect your new machine for years to come* with t he exclusive Good
™
Times
Protection Plan. This plan repairs or replaces most components free of
charge if found defective in material or workmanship. Everything about t he plan is
easy: There’s no deductible. It’s honored at every authorized Kawasaki motorcycle
dealer nationwide. It’s transferable to another owner with no fee. Just ask your
dealer how you can buy extended coverage of 12, 24, or 36 months. Imagine, for
just pennies a day, you can ride with no worry and no hassle. Just tell your dealer
you want the Good Times Protection Plan.
*Depending on the program purchased.
Ride With Zero Down**
We offer up to 100% instant financing on most Kawasaki products with the
™
Good Times
Credit Plan† and the Good Times™ Credit Card. Qualified buyers can
ride away on a brand-new Kawasaki with no down payment. In most cases, the
computerized credit approval takes just minutes. You can even add insurance,
accessories and the Good Times Protection Plan to your contract. Ask your
participating dealer for details.
†
Good Times Credit Plan not available in Canada.
**
Qualified buyers.
Safe Riding’s More Fun
Ride responsibly. Kawasaki believes safety begins with us and continues with you.
Always wear a helmet, eye protection and proper apparel. Passengers too.
Ride defensively. Obey the Basic Speed Law. Never ride under the infl uence of drugs
or alcohol. Riding is more fun on a well-maintained motorcycle...follow the instr uctions
in your owner’s manual. Remember, riding safe is smart.
Specifi cations subject to change without no tice. Availability may be limited. Always wear a helmet and appropriate
apparel. Call 1-800-446-9227 for the Motorcycle Safety Foundation beginner or expert course near you.
Action Photography: Professional riders on a closed course.
For more information, visit our Web site at:
kawasaki.com
For the nearest Kawasaki dealer, call:
1-800-661-RIDE
Concours™ 14 ABS
