KAT kt2 Owner's Manual

KIT

TEMPO

BEAT

KIT

TEMPO

BEAT

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 1 2012/9/4 13:32:03KMC_KIT_2_Manual_G09_120903.ai 1 2012/9/4 13:32:03

INFORMATION FOR YOUR SAFETY!

2

FCC COMPLIANCE NOTICE

This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and if not used in accordance with the
instructions, may cause harmful interference to radio
communications and there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one
or more of the following measures: reorient or relocate the
receiving antenna, increase the separation between the
equipment and receiver, connect the equipment into an outlet
on a circuit different from that of the receiver. Consult the
dealer or an experienced radio/TV technician if help is needed
with interference.

NOTE: FMIC will not be responsible for unauthorized
equipment modifications that could violate FCC rules, and/ or
void product safety certifications.

PRECAUTIONS

PLEASE READ CAREFULLY BEFORE PROCEEDING

Please keep this manual in a safe place for future reference.

Power Supply

Please connect the designated AC adaptor to an AC outlet of
the correct voltage.

Do not connect it to an AC outlet of voltage other than that for
which your instrument is intended.

Unplug the AC power adaptor when not using the instrument,
or during electrical storms.

Connections

Before connecting the instrument to other devices, turn off the
power to all units. This will help prevent malfunction and / or
damage to other devices.

Location

Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:

Interference with other electrical devices

Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable distance
from radios and televisions.

Cleaning

Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.

Handling

Do not apply excessive force to the switches or controls.

Do not let paper, metallic, or other objects into the instrument.
If this happens, unplug the AC adaptor from the wall outlet.
Then have the instrument inspected by qualified service
personnel.

Disconnect all cables before moving the instrument.

Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields

CAUTION

The normal function of the product may be disturbed by
Strong Electro Magnetic Interference. If so, simply reset the
product to resume normal operation by following the
owner’s manual. In case the function could not resume,
please use the product in other location.

CAUTION

Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.

This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 2 2012/9/4 13:32:03KMC_KIT_2_Manual_G09_120903.ai 2 2012/9/4 13:32:03

Contents

3

QUICK START

ADVANCED USE APPENDICES

Quick Start

Panel & Display Description

Front Panel..........................................................................4

Rear & Side Panel................................................................5

Display................................................................................5

Setup

Connecting Pads and Pedals...............................................6

Connections

Connecting Audio Equipment...............................................7

Connecting a set of Headphones.........................................7

Connecting an MP3/CD Player............................................7

Connecting a Computer.......................................................7

Connecting a Midi Keyboard................................................7

Power Supply.......................................................................7

Performing

Selecting a Drum Kit.............................................................8

Playing the Pads..................................................................8

Adjusting the Sensitivity of a Pad.........................................9

Using the Metronome/Click Feature.....................................9

Adjusting the Tempo............................................................9

Editing and Saving a Drum Kit

Adjusting the Volume of a Drum Kit...................................10

Switching Reverb On/Off and Setting EQ...........................10

Selecting the Drum Instrument of the Pad........................10

Adjusting the Volume, Pan and Pitch of the Pad...............10

Setting the Pads to Play Songs..........................................10

Saving the Edited Kit..........................................................10

Playing Along with Songs

Selecting and Playing Back a Song....................................11

Adjusting the Volume of the Accompaniment and Drum....11

Muting the Drums in Songs................................................11

Using the Pads to Play Songs............................................11

Recording Your Performance

Recording Your Performance Quickly................................12

Playing Back Your Recorded Performance........................12

Making the Settings for Recording.....................................12

Practicing with Patterns

Selecting a Pattern and Practicing with it............................13

Scoring Your Practice........................................................13

Playing Back Your Recorded Practice................................13

Creating Your Own Drum Kit

About the Drum Kits...........................................................14

Selecting a Drum Kit...........................................................14

Overall Drum Kit Setting.....................................................14

Selecting the Pad to Edit....................................................14

About the Drum Instruments..............................................15

Selecting Instruments........................................................15

Drum Instrument Setting....................................................15

Settings for Other Functions...............................................15

Saving to a User Drum Kit..................................................15

Making the Settings for Pads

About Settings of Pads.......................................................16

Adjusting the Pad Sensitivity..............................................17

Setting the Pad Threshold..................................................17

Eliminating Crosstalk between Pads..................................17

Selecting the Pad Curve.....................................................17

Setting Rim Sensitivity on Pads.........................................18

Adjusting the Hi-Hat Pedal Splash Sensitivity....................18

Saving Settings of Pads.....................................................18

Setting the Metronome

About Click.........................................................................19

Switching the Click On/Off..................................................19

Adjusting the Click Tempo.................................................19

Setting the Time Signature.................................................19

Setting the Interval.............................................................19

Adjusting the Click Volume................................................19

Selecting the Click Sound..................................................19

Playing Back Songs

About Songs......................................................................20

Selecting a Song................................................................20

Playing Back a Song..........................................................20

Adjusting the Accompaniment Volume...............................20

Adjusting the Drum Volume................................................20

Muting the Drums in Songs................................................20

Recording a Song

About Recording................................................................21

Recording Pad Performances............................................21

Recording Performances Accompanied with a Song.........21

Playing Back Your Recorded Performance........................21

Recording Standby............................................................21

Practicing in Learning Mode

About Learning Mode.........................................................22

Practicing with Beats..........................................................22

Practicing with Rhythms.....................................................23

Practicing with Patterns......................................................23

Recording and Scoring Your Practice................................24

Playing Back Your Recorded Practice................................24

Making the Setting for MIDI

About MIDI.........................................................................25

Making the MIDI Settings...................................................25

Connecting with an External Sound Device........................26

Using the digital drum as a Sound Module.........................26

Prompt Messages.........................................................27

Troubleshooting............................................................27

Specifications................................................................28

Kit/Voice/Song/Pattern/Parameter List..........................29

MIDI Implementation Chart............................................39

Advanced Use

Appendices

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 3 2012/9/4 13:32:03KMC_KIT_2_Manual_G09_120903.ai 3 2012/9/4 13:32:03

Panel Description

Front Panel

1. POWER Button

This Button turns the power on and off.

2. VOLUME Knob

Adjust the volume of phone and line output.

3. START/STOP Button

Start or stop playing.

4. SAVE Button

This button is used to save the current kit
settings in a user kit and save the trigger
settings under the Utility menu pages.

5. LCD Display

Please refer to the LCD Display section.

6. SONG/PATTERN Button

Enter the Song menu in NORMAL mode or enter
the Pattern Practice menu in LEARNING mode.

7. KIT/RHYTHM Button

Enter the Kit menu in NORMAL mode or enter
the Rhythm Practice menu in LEARNING mode.

8. VOICE/BEAT Button

Enter the Voice menu in NORMAL mode or
enter the Beat Practice menu in LEARNING mode.

9. PAGE/SELECT Button

Scroll through the menu pages. Press and hold it
for 1 second to switch modes between NORMAL
and LEARNING.

10.CLICK Button

Turn the metronome on or off and enter the
Click menu in NORMAL mode.

11. DRUM OFF Button

Mute the drum part of the pattern.

12. TEMPO Button

Adjust the current tempo.

13. UTILITY Button

Enter the Utility menu in NORMAL mode.

14. RECORD Button

Enter the Record menu in NORMAL mode.

15. PLAY/PRACTICE Button

Play back your recording in NORMAL mode.
Start practicing following sample practice
patterns in LEARNING mode.
Press and hold it for 1 second to play back
your practice in LEARNING mode.

16. + Button and - Button

Press the [ + ] button increases and press [ - ]
button decreases the current parameter.

17. Pad Select Buttons

These buttons play the pad voices of the
current kit. In Voice menu and Utility menu,
they select the pad to be edited.

4

KIT

TEMPO

BEAT

KIT

TEMPO

BEAT

15

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 4 2012/9/4 13:32:03KMC_KIT_2_Manual_G09_120903.ai 4 2012/9/4 13:32:03

Rear Panel & Side Panel

18. PHONES Jack(1/8”)

This stereo jack is used to connect
headphones to the unit.

19. AUX IN Jack(1/8”)

This stereo input jack is for an external sound
source, such as an MP3 or CD player.

20. LINE OUTPUT Jacks(1/4”)

Stereo output connection to an audio system
or drum amplifier.

21. CRASH 2 Jack(1/4”)

Input connection for Crash 2.

22. TOM 4 Jack(1/4”)

Input connection for Tom 4.

23. MIDI Connectors (IN, OUT)

These ports allow communication with other
products equipped with a MIDI interface.

24. USB Connector

This port is used to connect to a computer
(MIDI In/Out via USB).

25. DC IN Jack

Connect the included DC 9V power adaptor.

26. PAD Connectors

Input connections for Kick, Snare, Tom,
Cymbal pads and Hi-Hat control pedal.

5

Panel Description

Display

GOOD

TEMPO BEAT

4

1

1. Tempo/Measure

2. Hitting Indicator

3. Beat Count

4. Indicators for Learning

5. Indicators for Menus (Such as UTILITY, REC, etc.)

6. Current Mode and Parameter Display

KIT

1

2

3

4

5

6

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 5 2012/9/4 13:32:03KMC_KIT_2_Manual_G09_120903.ai 5 2012/9/4 13:32:03

Caution!

Connecting Pads and Pedals

Setup

To prevent electric shock and damage to the device, make sure the power is switched
OFF on the drum and all related device before making any connection.

Standard: KICK, SNARE, TOM1-3, CRASH1, RIDE, HIHAT, HIHAT CONTROL PEDAL
Extended: CRASH2, TOM4

Using the provided cable harness, connect with kick, snare, tom1~tom3, ride, crash, hi-hat, hi-hat control
triggers. Snare, tom, crash1, crash2 and ride pads are stereo input and support double triggering; crash1,
crash2, ride support choke. Hi-hat control pedal is stereo input.

Note:

For details on assembling the drum stand, attaching the digital drum and connecting pads, refer to the Assembly
Instructions.
Bass drum pedal NOT included on some models.

hi-hat

hi-hat control

kick

crash1 ride

tom1

tom2

tom3

snare

Drum Module

6

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 6 2012/9/4 13:32:04KMC_KIT_2_Manual_G09_120903.ai 6 2012/9/4 13:32:04

Connections

Connecting Audio Equipment

Connecting a set of Headphones

Connecting an MP3/CD Player

Connecting a Computer

Connecting a Midi Keyboard

Note:

For mono playback, use the L/MONO jack.
For stereo playback, connect both L/MONO and R jacks.
The line output volume is controlled by the VOLUME knob.

When using an amplifier, connect the Output L/MONO and R
jacks on the rear panel to the input of the amplifier.

An optional set of stereo headphones can be connected to the
PHONES jack located on the side of the drum module.
The headphones output volume is controlled VOLUME knob,
too.

Connect the audio output of an MP3/CD player or other audio
source to the stereo AUX IN jack on the rear panel.
The input signal is mixed with the drum signal, allowing you to
play along.

If you’re using an external MIDI keyboard or pads to control the
digital drum, make connections as shown. Here, it is used as a
sound module.

MIDI OUT

7

Via the USB Connector

This receives and transmits MIDI messages.

Via the MIDI Connectors
MIDI IN Connector

This receives MIDI messages transmitted from an external
MIDI device or a computer.

MIDI OUT Connector

Pad performance data is transmitted from this connector to
connected computer or MIDI device.

Power Supply

Make sure the power is turned OFF. Connect the power
adaptor to the DC IN jack on the side panel. After confirming
that all connections have been completed, rotate the volume
knob to the left (minimum volume level) before powering on the
module. Press the [POWER] button to turn on the module. The
KIT indicator on LCD will light up and the display will show kit
number 001.

Note:

Make sure the power is turned OFF when connecting the drum
module with external devices.

VOLUME

- +

HINT

The module will automatically turn off if there aren't
any operations for about 30 minutes except during
playing song or metronome, record, MIDI in via USB
port from computer and strike pads.
Please press [UTILITY] button repeatedly and enter
"POW" menu for the setting.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 7 2012/9/4 13:32:05KMC_KIT_2_Manual_G09_120903.ai 7 2012/9/4 13:32:05

Performing

After powering up, the digital drum will be in KIT menu (KIT
indicator ON ). The display should look like this:

Use the [ - ] and [ + ] buttons to select the active kit.
There are 45 kits in the digital drum:
30 preset kits (Kits 01-30)
15 user kits (Kits 31-45), the parameter display area will
display as "U31~U45", with an additional letter "U".

Pressing the Pad Select buttons allows you to preview the
current kit (fixed velocity).

Hit the pads to play the current kit.

Similar to an acoustic drum kit, the digital drum responds
differently to various playing techniques and dynamics. All the
pads are velocity sensitive. And some voices change timbre
depending on the striking force.

Drum Pad Head or Rim shot

The digital drum pad detects head and rim shots (rim shots
trigger the rim voice).

Cymbal Bow shot and Rim shot

The digital drum cymbals detect bow and rim shot.
Both Ride and Crash cymbals have cymbal choke. But hi-hat
does not have the cymbal choke. Choking the crash/ride edge
with the hand immediately after hitting the crash/ride mutes the
crash/ride sound.

Hi-Hat

The Hi-Hat sound varies depending on the position of the
Hi-Hat pedal:

Strike the Hi-Hat pad without pressing the
pedal.

Strike the Hi-Hat pad with the pedal
pressed halfway down.

Strike the Hi-Hat pad with the pedal
pressed completely down.

Press the pedal completely down without
striking the pad.

Press the pedal completely down and
release it immediately.

KIT

TEMPO

BEAT

8

1.

2.

3.

Open Hi-Hat:

Half-Open Hi-Hat:

Closed Hi-Hat:

Pedal Close:

Splash:

KICK

Head

Rim

Head

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 8 2012/9/4 13:32:05KMC_KIT_2_Manual_G09_120903.ai 8 2012/9/4 13:32:05

Performing

PAGE/SELECT

You may wish to adjust the sensitivity of the pads according to
your playing style and desired dynamic range.

For details on pad adjustments, refer to Advanced Use.

You can switch the click sound on and off by pressing [CLICK]
button. When the click plays at the current Time Signature and
Tempo (displayed in the top left corner of the LCD), the beat
indicators will swing accordingly. You can set the time signature
and interval, adjust the click volume and select the click sound
in the CLICK menu.

Press the [CLICK] button.
Start the metronome with click sound.

Press the [PAGE] button to select the click menu pages
and press the [ - ] or [ + ] button to adjust the parameters.

Press the [CLICK] button again.
Stop the metronome and exit the click menu.

You can adjust the tempo of the Metronome, the current song,
and the current learning pattern. The current tempo always
displays in the top left corner of the LCD.

Press the [TEMPO] button.

Press the [ - ] or [ + ] button.
Adjust the current tempo.

Press both [ - ] and [ + ] buttons at the same time, reset the
current tempo to its default value.

Note:

If there’s no operation, it will return to the previous menu page
automatically after 3 seconds.

UTILITY

TEMPO

BEAT

UTILITY

TEMPO

BEAT

CLICK

TEMPO

BEAT

SONG

TEMPO

BEAT

9

1.

2.

3.

1.

2.

3.

1.

2.

3.

4.

Press the [UTILITY] button
The UTILITY indicator appears.

Strike a pad or press a pad select button to select the one
whose sensitivity is to be adjusted. The PAD indicator
shows the current selected pad.

Press the [ - ] or [ + ] button to adjust the sensitivity.

Press the [SAVE] button to save the current setting.

CLICK

CLICK

TEMPO

SAVE

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 9 2012/9/4 13:32:05KMC_KIT_2_Manual_G09_120903.ai 9 2012/9/4 13:32:05

Editing and Saving a Drum Kit

In KIT menu, you can modify the parameters as you like and save to the selected user kit.

Press the [KIT] or [PAGE] button.
Select the Kit Volume page.

Press the [ - ] or [ + ] button.
Adjust the kit volume.

Press the [KIT] or [PAGE] button.
Select the Global Reverb page and EQ pages.

Press the [ - ] or [ + ] button.
Switch Reverb ON or OFF.
Set the gain of three-band EQ (high, middle, low)

Press the [VOICE] button.
Select the Pad Voice page.

Press the [ - ] or [ + ] button.
Select the drum instrument of the selected pad.
Please refer to Drum Instrument List.

Press the [VOICE] or [PAGE] button.
Select the Pad Volume, Pad Pan, and Pad Pitch pages.

Press the [ - ] or [ + ] button.
Adjust the corresponding parameter.

Press the [SAVE] button.
The number of user kit will be flashed.

Press the [ - ] or [ + ] button.
Select a user kit to save your settings. (No. 31-45)

Press the [SAVE] button again.
Save the setting to the selected user kit.

SAVE

Press the [VOICE] or [PAGE] button.
Select the Pad Song and Song Number pages.

Press the [ - ] or [ + ] button.
Switch the Pad Song function ON or OFF. Select the Song
that begins playing when the following pad is struck.

KIT

TEMPO

BEAT

VOICE

TEMPO

BEAT

KIT

TEMPO

BEAT

VOICE

TEMPO

BEAT

VOICE

TEMPO

BEAT

KIT

TEMPO

BEAT

10

1.

2.

1.

2.

1.

2.

1.

2.

1.

2.

1.

2.

3.

KIT

KIT

VOICE

VOICE

VOICE

HINT

If the edited kit isn’t saved before selecting
another kit, powering down the digital drum,
the changes will be lost.

Adjusting the Volume, Pan and Pitch of the Pad

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 10 2012/9/4 13:32:05KMC_KIT_2_Manual_G09_120903.ai 10 2012/9/4 13:32:05

Playing Along with Songs

Press the [SONG] button.
Switch to the SONG menu.

Press the [ - ] or [ + ] button.
Select the active song. The digital drum has many kinds of
songs. Please refer to Song list.

Press the [START/STOP] button.
Start or stop playing back this selected song. When playing
back this song, the PAD indicator will display which pads
are being played by drum track.

In SONG menu, you can adjust the volume of drum or
accompaniment track.

Press the [SONG] or [PAGE] button.
Select the ACC Volume or Drum Volume page.

Press the [ - ] or [ + ] button.
Adjust the corresponding volume.

If you want to mute the drum track of the song, please press the
[DRUM OFF] button. The [DRUM OFF] LED will turn on.

This function is available only with electric drum. When you
strike the pads that have been set to Pad Song function, they
will start the performance of the songs. If you don’t know how to
set this function, please return to previous page and review the
part “Setting the Pads to Play Songs”.

For Example：
Kick:

Crash:

SONG

TEMPO

BEAT

SONG

TEMPO

BEAT

DRUM OFF

11

1.

2.

1.

2.

3.

Muting the Drums in Songs

You can play the bass-line (Tap group, refer to Song
List) note by note with you kick drum.

The chords (Hit group, refer to Song List) progress
when you strike the pad.

SONG

SONG

START/

STOP

HINT

The sounds in the Tap song are played back
one by one when you pressing the
[START/STOP] button or hitting the "pad
song" pad.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 11 2012/9/4 13:32:05KMC_KIT_2_Manual_G09_120903.ai 11 2012/9/4 13:32:05

Recording Your Performance

In RECORD menu, you can record pad performances and the song as accompaniment.

RECORD

PLAY/PRACTICE

Press the [PAGE] button.
Select the Record Setting pages.

Press the [ - ] or [ + ] button.
Adjust the parameters about recording.
For details on record setting, refer to Advanced Use.

Press the [RECORD] button.
The [RECORD] LED will flash. The Metronome will be
turned on automatically.
The display will show:

Press the [START/STOP] button or strike the pad.
Recording will start.
The [RECORD] LED will turn on.

Press the [START/STOP] button again, or press the
[RECORD] button.
Stop recording, the [RECORD] LED will turn off.
Your performance has been recorded.

REC

TEMPO

BEAT

REC

MEAS

BEAT

REC

BEAT

If you are not satisfied with your recording, please press the
[RECORD] button to restart the recording progress.

Press the [PLAY] button.
Play back your recording.
The display will show:

Press the [PLAY] button again.
Stop playing back your performance.

12

1.

2.

1.

2.

1.

2.

3.

You can make the settings for recording on Record Standby.

START/

STOP

PAGE/SELECT

MEAS

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 12 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 12 2012/9/4 13:32:06

Practicing with Patterns

There are three types of patterns in LEARNING mode.

Beat:
Rhythm:
Pattern:

When you are in NORMAL mode, please press and hold the
[PAGE/SELECT] button for 1 second. The LED of LEARNING
mode will turn on. The display will show:

If you want to select the Rhythm or Pattern, please follow the
steps described above.

Press the [BEAT] button.
Select the Beat Choosing page.

Press the [ - ] or [ + ] button.
Select the beat which you want to practice.

Press the [PRACTICE] button.
Start or stop playing the pattern with your practice. The
PAD indicators will display which pads are being played by
drum track.

If you want to check your progress, please press the
[START/STOP] button. The display will show:

A measure count-in will be inserted before playing back the
pattern so that you can practice in good time. Your practice will
be recorded automatically. When finished playing back the
pattern, the digital drum will score your practice automatically.
The display will show the score.

If you are not satisfied with your score, please press the
[START/STOP] button and try again.

Press and hold the [PLAY/PRACTICE] button for 2
seconds.
The display will show:
You can listen to your recorded practice.

Press the [PLAY/PRACTICE] button again.
Stop playing back the recorded practice.

BEAT

LEARN

TEMPO

BEAT

LEARN

BEAT

LEARN

TEMPO

BEAT

LEARN

BEAT

13

1.

2.

1.

2.

3.

START/

STOP

Snare Practice
Drum Practice
Drum Practice with accompaniment

MEAS

MEAS

PLAY/PRACTICE

PLAY/PRACTICE

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 13 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 13 2012/9/4 13:32:06

Creating Your Own Drum Kit

About the Drum Kits

Selecting a Drum Kit

Overall Drum Kit Setting

Selecting the Pad to Edit

Pad Settings
Kick Head1

Head2 Rim2

Rim3
Rim4
Rim5
Rim6
Rim7
Rim8
Rim9

Head3
Head4
Head5
Head6
Head7
Head8
Head9
Head10

Snare
Tom1
Tom2
Tom3
Tom4
Crash1
Crash2
Ride
Hihat
Pedal

Overall Kit Settings
Kit Volume

Reverb on/off
EQ High gain
EQ Middle gain
EQ Low gain

Global

In KIT menu, you can select drum kits to play from the pads,
and you can edit voices and their associated parameters, such
as Pitch, Reverb Level, Volume, Pan, MIDI Note, etc.
There are 45 kits in the digital drum:
30 preset kits (Kits 01-30)
15 user kits (Kits U31-U45)

In addition, there are 11 General MIDI preset kits for MIDI/USB
applications, and for MIDI file playback. Please refer to GM
Drum Kit List. Each drum kit contains settings for up to 19
voices, assigned to the 10 pad inputs and 1 pedal controller:

If the digital drum is not yet in KIT menu, press the [KIT] button
to enter it. The KIT indicator will light up, and the LCD will
display the current kit number.

Press the [ - ] or [ + ] buttons to select a kit. When holding
down [ + ], values increase rapidly. When holding down [ - ],
values decrease rapidly.

The current pad to be edited can be selected either by pressing
its Pad Select button, or by striking the pad itself. The PAD
indicator will light up to show which pad is currently selected. If
the rim of a pad is selected, both the PAD indicator and the
RIM indicator will turn on.

Press the [PAGE] or [KIT] button, select Kit volume page.
The parameter adjusts the overall kit volume(0-32).

Press the [PAGE] or [KIT] button, select Reverb Switch
page. The parameter toggles the global reverb Switch
ON/OFF.

Press the [PAGE] or [KIT] button, select EQ gain page.
These parameters adjust the three bands of Master
EQ(-12dB-12dB).

14

KIT

TEMPO

BEAT

1.

2.

3.

In KIT menu, you can set the overall kit parameters.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 14 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 14 2012/9/4 13:32:06

About the Drum Instruments

Selecting Instruments

Drum Instrument Settings

Settings for Other Functions

Saving to a User Drum Kit

Drum Instrument Settings

Volume(0-32)
Pan(-8-8)
Pitch(-8-8)
Reverb(0-16)

Voice
Setting

Settings for Other Functions

MIDI Note(0-127)MIDI
Pad Song Switch(ON/OFF)
Song Number(1-80)

Others

HINT

While editing Voice Number, Pitch, Pan,
Volume, and Reverb, you can also preview
the result of the current settings by pressing
the Pad Select button to play the edited voice.

15

VOICE

TEMPO

BEAT

VOICE

VOICE

TEMPO

BEAT

SAVE

BEAT

1.

2.

1.

2.

3.

4.

5.

6.

The digital drum features 510 different drum instruments which are categorized into 9 separate groups, such as
Acoustic Kick, Electric Kick, Acoustic Snare, Electric Snare, Percussion. You can individually adjust the volume,
pan, pitch, reverb settings for instruments set to the pad.

If the digital drum is not yet in VOICE menu, press the [VOICE]
button to enter it. The VOICE indicator will light up, and the
LCD will display the current voice number.

After change any kit parameter, please press the [SAVE] button
to save the current settings to the user kit (No. 31-45). The
number of user kit will be flashed. Press the [SAVE] button to
save to user kit and return to Kit Select page.

Press the [ - ] or [ + ] buttons to change a pad’s Individual
voice (001-491).

If the selected pad is Hi-Hat, an additional option is
available: Hi-Hat Combination (001-019).

Press the [PAGE] or [VOICE] button, select Pad Volume
page. The parameter adjusts the volume of the pad.

Press the [PAGE] or [VOICE] button, select Pad Pan page.
The parameter adjusts the pan of the pad.

Press the [PAGE] or [VOICE] button, select Pad Pitch
page. The parameter adjusts the pitch of the pad.

Press the [PAGE] or [VOICE] button, select Pad Reverb
page. The parameter adjusts the reverb level of the pad.

Press the [PAGE] or [VOICE] button, select Pad MIDI Note
page. The parameter sets MIDI Note Number for each pad.

Press the [PAGE] or [VOICE] button, select Pad Song
pages. The parameters sets pad song function ON and
choose the song numbers.

Press the [ - ] or [ + ] buttons to adjust the parameters.

KIT

TEMPO

BEAT

Creating Your Own Drum Kit

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 15 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 15 2012/9/4 13:32:06

Making the Settings for Pads

About Settings of Pads

16

If the digital drum is not yet in UTILITY menu, press the
[UTILITY] button to enter it.

The UTILITY indicator will light up. You can use the [ - ] or [ + ]
buttons to adjust parameters (as shown to the right ) for each
pad as well as the rim sensitivity of the pad and the splash
sensitivity of the Hi-Hat control pedal.

The current pad to be edited can be selected either by pressing
its Pad Select button, or by striking the pad itself. The PAD
indicator will light up to show which pad is currently selected. If
the rim of a pad is selected, both the PAD indicator and the
RIM indicator will turn on.

Sensitivity:

Adjust the sensitivity of the pad to regulate the pad
response. Higher settings result in higher sensitivity, so that the
pad will produce a loud volume even when struck softly. You
can also adjust the sensitivity of the splash in SPLASH
SENSITIVITY.

Threshold:

This setting allows a trigger signal to be received
only when the pad is struck harder than a specified force. This
can be used to prevent a pad from sounding in response to
extraneous vibrations from another pad.

Crosstalk:

When two pads are mounted on the same stand, the
vibration produced by hitting one pad may trigger the sound
from another pad unintentionally (This is called crosstalk). You
can avoid this problem by adjusting Crosstalk Cancel on the
pad that is sounding inadvertently. If the value is set too high,
then when two pads are played simultaneously, the one that is
struck less forcefully will not sound. So be careful and set this
parameter to the minimum value required to prevent such
crosstalk. With a setting of 0 , crosstalk prevention does not
function.

Curve: This setting allows you to control the relation between

the velocity (striking force) and changes in volume (the dynamic
curve). Adjust this curve until the response feels as natural as
possible.

Pad Settings

Sensitivity(1-16)
Threshold(0-16)
Crosstalk(1-16)
Curve(1-6)
Rim Sensitivity(1-16)
Splash Sensitivity(1-9)
Off, 30, 60

Pad

Special
Auto Power off

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 16 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 16 2012/9/4 13:32:06

17

Adjusting the Pad Sensitivity

Setting the Pad Threshold

Eliminating Crosstalk between Pads

Press the [PAGE] or [UTILITY] button, select Pad Sensitivity
page. The display will show:

Changes how a pad responds to your playing. At higher
sensitivities, the pad will generate a louder signal, even when
you play softly. At lower sensitivities, the pad will generate a
quieter signal, even if you play strongly. Adjust according to
your playing style and desired dynamic range.

Press the [PAGE] or [UTILITY] button, select Pad Threshold
page. The display will show:

Changes how forcefully you must strike the pad to generate a
trigger signal. Setting a high threshold requires hitting the pad
very hard to get a sound. This can help cut out transient
responses, such as vibrations from the kit or accidental pad
taps that you don’t intend to generate sounds. Setting a low
threshold means even light touches will produce sound. Adjust
according to environment and playing style.

Press the [PAGE] or [UTILITY] button, select Pad Crosstalk
page. The display will show:

When two pads are mounted close to each other, hitting one
pad may trigger the sound from another pad unintentionally.
This effect can be eliminated by setting this parameter to a
higher value on the pad that is triggered unintentionally.

UTILITY

TEMPO

BEAT

UTILITY

UTILITY

TEMPO

BEAT

UTILITY

UTILITY

TEMPO

BEAT

UTILITY

HINT

If the value is set too high, then when two
pads are played simultaneously, the one that
is struck less forcefully will not sound. So be
careful and set this parameter to the minimum
value required to prevent such crosstalk.

Making the Settings for Pads

Selecting the Pad Curve

Press the [PAGE] or [UTILITY] button, select Pad Curve page.
The display will show:

UTILITY

TEMPO

BEAT

UTILITY

Curve refers to how the trigger signal’s dynamic response
relates to your pad hit.

Curve1:

Curve2, 3:

The standard setting, this produces the most natural
correspondence between playing dynamics and
volume change.
Compared to Curve1, strong dynamics produce a
greater change.

Curve 1 Curve 2

Loudness

Striking Force

Curve 3

Loudness

Striking Force

Loudness

Striking Force

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 17 2012/9/4 13:32:06KMC_KIT_2_Manual_G09_120903.ai 17 2012/9/4 13:32:06

Setting Rim Sensitivity on Pads

Making the Settings for Pads

18

Curve4, 5:

Curve6:

Compared to Curve1, a soft playing produces a
greater change.
Very little dynamic response, making it easy to
maintain strong volume levels. If using drum
triggers, these settings help maintain stable levels.

You can only set rim sensitivity on Snare, Tom1, Tom2, Tom3,
Tom4. If you select the other pads, this page will not appear.
Press the [PAGE] or [UTILITY] button, select Pad Rim
Sensitivity page. The display will show:
Same as the basic sensitivity feature, except that it relates
specifically to playing the rim.

Note:

This parameter can be adjusted only on SNARE, TOM1,
TOM2, TOM3, TOM4. If you select the other pads on this page,
a horizontal line "---" appears, and you can't make the setting.

UTILITY

TEMPO

BEAT

UTILITY

Curve 1 Curve 2

Curve 3

Curve 4

Loudness

Striking Force

Curve 5

Loudness

Striking Force

Curve 6

Loudness

Striking Force

Adjusting the Hi-Hat Pedal Splash Sensitivity

Saving Settings of Pads

1.

2.

Press the [PAGE] or [UTILITY] button, select Pedal Splash
Sensitivity page. The display will show:

This Setting controls the sensitivity of the foot splash.

After adjusting the trigger settings (sensitivity, Threshold,
crosstalk, curve, rim sensitivity, splash sensitivity), you can
save them into memory. In UTILITY menu, press the [SAVE]
button to store all pad settings.

If you turn off the power without saving, you will lose the
trigger setting changes you have just made.

These parameters affect all kits.

UTILITY

TEMPO

BEAT

UTILITY

UTILITY

TEMPO

BEAT

UTILITY

Note:

Auto Power Off

Press the [PAGE] or [UTILITY] button to select the Auto Power
Off setup page.
The LCD will display

030 and 060:
If there aren't any operations for about 30 or 60 minutes except
during playing song or metronome, record, MIDI in via USB
port from computer and strike pads, the module will turn the
power off automatically.

"OFF": Switch off the auto power off function.

UTILITY

UTILITY

TEMPO

BEAT

UTILITY

TEMPO

BEAT

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 18 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 18 2012/9/4 13:32:07

Setting the Metronome

About Click

Switching the Click On/Off

Adjusting the Click Tempo

Setting the Time Signature

Setting the Interval

Adjusting the Click Volume

Selecting the Click Sound

Click Settings

0-9/2, 0-9/4,
0-9/8, 0-9/16

1-2, 3-8, 1-4, 1-8, 1-12, 1-16
0-32
1-5Voice

Volume

Interval

Time
signature

Press the [CLICK] button to start the metronome. The
CLICK LED will blink accordingly. The metronome will play
at the current Time signature and tempo (displayed in the
left right corner of the LCD)
Press the [CLICK] button again to stop the metronome. The
CLICK indicator will turn off.

Press the [TEMPO] button, and use the [ - ] and [ + ] buttons to
adjust the current click tempo.

The current tempo always displays in the top left corner
of the LCD.

Press the [PAGE] button, select Click Time signature page.
The display will show:

When the parameter is set to "0", such as 0-2,0-4,0-8,0-16, no
accent is added to the first beat.

Press the [PAGE] button, select Click Interval page. The
display will show:

This parameter sets how the sound plays.

Press the [PAGE] button, select Click Volume page. The
display will show:

This parameter adjust the volume of the click sound.

Press the [PAGE] button, select Click Voice page. The display
will show:

This parameter choose the sound for the click.

19

CLICK

CLICK

TEMPO

BEAT

The digital drum is equipped with a built-in metronome, which
can be used by itself as a rhythm guide for practice, or in
conjunction with the song playback or record functions. If the
digital drum is not yet in CLICK menu, press the [CLICIK]
button to enter it. In CLICK menu, you can use the [ - ] or [ + ]
button to adjust the parameters(as shown to the right).

TEMPO

BEAT

TEMPO

CLICK

CLICK

CLICK

TEMPO

BEAT

CLICK

TEMPO

BEAT

CLICK

TEMPO

BEAT

CLICK

TEMPO

BEAT

PAGE/SELECT

PAGE/SELECT

PAGE/SELECT

PAGE/SELECT

1.

2.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 19 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 19 2012/9/4 13:32:07

About Songs

Selecting a Song

Playing Back a Song

Adjusting the Accompaniment Volume

Adjusting the Drum Volume

Muting the Drums in Songs

Playing Back Songs

20

There are 80 preset songs in the digital drum:

Please refer to Song List. In SONG menu, you can select the
song number and adjust the volume of the song’s
accompaniment and drum part.

If the digital drum is not yet in SONG menu, press the [SONG]
button to enter it. The SONG indicator will light up, and the LCD
will Display the current song number.

Press the [ - ] or [ + ] button to select a song. When holding
down [ + ], the song number increase rapidly. When holding
down [ - ], it decrease rapidly.

Press the [START/STOP] button to start song playback. The
LCD will display the current playing beat. Press the
[START/STOP] button again, stop the song during playback.
During song playback in SONG menu, the PAD indicators will
show which pads of the drum track is triggering.

This function can be disabled or enabled by pressing the
[KICK] button while in SONG menu.

Press the [PAGE] or [SONG] button, select Song
Accompaniment volume page. The display will show:

Use the [ - ] or [ + ] to adjust it. It will be restore to default value
on the next power on.

Press the [PAGE] or [SONG] button, select Song Drum volume
page. The display will show:

Use the [ - ] or [ + ] to adjust it. It will be restore to default value
on the next power on.

Press the [DRUM OFF] button to enable and disenable the
drum mute function. When DRUM OFF is enabled, the LED will
turn on.

SONG

TEMPO

BEAT

SONG

START/

STOP

Song Settings

Number(1-80)
Accomp(0-32)
Drum(0-32)Mix

No.

SONG

SONG

TEMPO

BEAT

SONG

TEMPO

BEAT

50 Looped Patterns
10 Looped Percussion Patterns
5 Hit Songs
15 Tap Songs

SONG

SONG

TEMPO

BEAT

DRUM OFF

HINT

If the song number is switched while
playing, the new song won’t start until the
end of the current bar.

HINT

The sounds in the tap song are played back
one by one in sequence each time [START]
is pressed or hitting the pad which is
functioned as "pad song".

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 20 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 20 2012/9/4 13:32:07

Recording a Song

About Recording

Recording Pad Performances

Recording Performances Accompanied with a Song

Playing Back Your Recorded Performance

Recording Standby

Record Settings

---/1-60

---/ON/OFF
ON/OFF

1-9/2, 1-9/4, 1-9/8, 1-9/16
1-2, 3-8, 1-4, 1-8, 1-12, 1-16

1-45
30-280

Signature

Tempo

Kit

Pre Count

Drum Off

Interval

Song Number

If you want to record your performance accompanied with a
song, first set the parameters (Song Number and Drum off)
before start to record. The display will be as shown to the right:

For details on setting, refer to Recording Standby. Recording
operations are as mentioned above.

Page1:Setting the song accompanied or not
Page2:Selecting the drum kit that you want to record.
Page3:Setting the recording tempo
Page4:Setting the time signature
Page5:Setting the interval
Page6:Setting the drums in songs muted or not
Page7:Setting a measure count-in inserted or not before recording.

Use the [PAGE] button to scroll through the various record
parameters and the [ - ] or [ + ] button to adjust the value.

21

In NORMAL mode, the digital drum allows you to quickly record
your performance as you play the pads. There are two ways to
start recording a new song:
Press the [START/STOP] button
Hit any pad
On Recording Standby, you can use the [ - ] or [ + ] button to
adjust the parameters(as shown to the right).

REC

BEAT

1.

2.

3.

Press the [RECORD] button, enter recording standby. The
[RECORD] LED will flash.

Press the [START/STOP] button or strike the pad.
Recording will start. The RECORD LED will turn on. After
Count-in, the display will show:
Now you will record your performance.

Press the [START/STOP] button again, or press the
[RECORD] button. Stop recording, the [RECORD] LED will
turn off.

1.

2.

Press the [PLAY] button. Play back your recording. The
display will show:

Press the [PLAY] button again. Stop playing back your
performance.

RECORD

RECORD

START/

STOP

REC

BEAT

REC

TEMPO

BEAT

REC

TEMPO

BEAT

REC

BEAT

PLAY/PRACTICE

PAGE/SELECT

MEAS

MEAS

MEAS

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 21 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 21 2012/9/4 13:32:07

About Learning Mode

Practicing with Beats

Practicing in Learning Mode

22

The LEARNING mode is a unique set of exercises specifically designed to help build speed, accuracy and stamina,
as well as develop better drum skills.
There are 42 practices in the digital drum:

You can select appropriate patterns to practice depending on your present skills.

If the digital drum is not yet in BEAT menu, press the [BEAT]
button to enter it. You can adjust the parameters (as shown to
the right).

There are 3 states in Learning mode:

20 Beats (Only Snare)
12 Rhythms (Only Drum, from Level1-Level6)
10 Patterns (from Level1-Level5)

Follow me:
Score:
Playback:

Practice with the selected pattern
Record and score your practice
Play back your recorded practice

LEARN

TEMPO

BEAT

LEARN

TEMPO

BEAT

1.

2.

3.

Press the [ - ] or [ + ] button to select the beat.

Press the [PRACTICE] button to listen to the beat and
follow it. Press it again to stop the beat.

Press the [BEAT] or [PAGE] button to select the Beat Drum
volume page. Press the [ - ] or [ + ] button to adjust the
drum volume of the beat.

Beat

1-20
0-32Drum Volume

Number

BEAT

If the digital drum is not yet in LEARNING mode, press and
hold the [PAGE/SELECT] button for 1 second. The LED of
LEARNING mode will turn on. The display will show:

In this Learning Mode, after you press the [PRACTICE] or
[START/STOP] to start practicng, your hitting accuracy will
always be indicated in the middle of the display according to the
current pattern.

DRAGGING:

PERFECT:

RUSHING:

PLAY/PRACTICE

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 22 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 22 2012/9/4 13:32:07

Practicing with Rhythms

If the digital drum is not yet in RHYTHM menu, press the
[RHYTHM] button to enter it. You can adjust the parameters
(as shown to the right).

RHYTHM

1.

2.

3.

4.

Rhythm

1-12

0-32

1-6Level

Drum Volume

Number

Press the [ - ] or [ + ] button to select the rhythm.

Press the [PRACTICE] button to listen to the rhythm and
follow it. Press it again to stop the rhythm.

Press the [RHYTHM] or [PAGE] button to select the
Rhythm Level page. Press the [ - ] or [ + ] button to select
the level of the rhythm.

Press the [RHYTHM] or [PAGE] button to select the
Rhythm Drum Volume page. Press the [ - ] or [ + ] button to
adjust the drum volume of the rhythm.

TEMPO

BEAT

LEARN

TEMPO

BEAT

LEARN

PLAY/PRACTICE

Practicing in Learning Mode

Practicing with Patterns

Pattern

1-10

0-32

1-5
0-32

Drum Volume

Accompany Volume

Level

Number

1.

2.

3.

4.

5.

If the digital drum is not yet in Pattern menu, press the
[PATTERN] button to enter it. You can adjust the parameters
(as shown to the right).

Press the [ - ] or [ + ] button to select the pattern.

Press the [PRACTICE] button to listen to the pattern and
follow it. Press it again to stop the pattern.

Press the [PATTERN] or [PAGE] button to select the
Pattern Level page. Press the [ - ] or [ + ] button to select
the level of the pattern.

Press the [PATTERN] or [PAGE] button to select the
Pattern Accompany Volume page. Press the [ - ] or [ + ]
button to adjust the accompaniment volume of the pattern.

Press the [PATTERN] or [PAGE] button to select the
Pattern Drum Volume page. Press the [ - ] or [ + ] button to
adjust the drum volume of the pattern.

TEMPO

BEAT

LEARN

TEMPO

BEAT

LEARN

PLAY/PRACTICE

PATTERN

23

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 23 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 23 2012/9/4 13:32:07

Practicing in Learning Mode

Recording and Scoring Your Practice

Playing Back Your Recorded Practice

24

1.

2.

1.

2.

MEAS

BEAT

LEARN

Press the [START/STOP] button, you can enter the score
state. A measure count-in will be inserted before playing
back the pattern so that you can practice in good time.
When playing back the pattern, your performance will be
recorded automatically. When finished playback, the digital
drum will score your practice automatically.

The display will show the score for 3 seconds.

Press the [START/STOP] button again to stop playing back
the pattern and recording your practice during the playback

TEMPO

BEAT

LEARN

LEARN

Press and hold the [PLAY/PRACTICE] button for 2
seconds, you can enter the playback state. The display will
show:
You will listen to your recorded practice.

Press the [PLAY/PRACTICE] button again. Stop playing
back the recorded practice.

BEAT

PLAY/PRACTICE

START/

STOP

MEAS

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 24 2012/9/4 13:32:07KMC_KIT_2_Manual_G09_120903.ai 24 2012/9/4 13:32:07

About MIDI

Making the MIDI Settings

Making the Settings for MIDI

25

MIDI (Musical Instrument Digital Interface) is a standard that allows performance data and other information to be
exchanged among electronic musical instruments and computers. With a MIDI cable connecting MIDI connectors
equipped device, you can play multiple instruments with a single keyboard, have multiple instruments perform in
ensemble, program the settings to change kits automatically to match the performance as the song progress, and
more.

MIDI Connection
MIDI IN:

MIDI OUT:

USB Connection

The USB connector allows you to connect the digital drum directly to your computer. It can be connected without
installing a driver in Windows XP/Vista/Win7 or MAC OSX environments. The digital drum will be recognized as a
“USB Audio device” to receive and transmit MIDI messages through a single USB cable. The USB port is used
only for MIDI messages (MIDI via USB)

Note:

When the USB port is connected to a computer, all MIDI messages will be received and transmitted via USB.

Local OFF:

Local ON:

Press the [PAGE] or [UTILITY] button, select GM mode
pages. The display will show:
Press the [ - ] or [ + ] button, set GM mode to ON or OFF.
Refer to

Using the Digital Drum as a Sound Module

.

Press the [START/STOP] button to start or stop songs
playback, the digital drum will transmit the MIDI system
real-time Message: FA or FC.

The pads and internal sequencer are
disconnected from the digital drum’s internal
sound generator. Striking the pads does not
cause sound to be produced by the internal sound
generator.

The pads and internal sequencer are connected
to the digital drum’s internal sound generator.
Sounds are produced by the internal sound
generator when the pads are struck.

Local Mode

GM Mode

Sync Mode

MIDI Settings

ON/OFF
ON/OFFGM on/off

Local on/off

UTILITY

UTILITY

TEMPO

BEAT

Trigger Input

MIDI
OUT

MIDI IN

Local On/Off

MIDI Note

Sound Module

UTILITY

TEMPO

BEAT

UTILITY

If the digital drum is not yet in UTILITY menu, press The
[UTILITY] button to enter it. Press the [PAGE] or [UTILITY]
button, select Local mode pages. The display will show:

Press the [ - ] or [ + ] button, set local mode to ON or OFF.

START/

STOP

This terminal receives MIDI data from an external
MIDI device.
This terminal transmits data from the digital drum
to other MIDI devices.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 25 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 25 2012/9/4 13:32:08

Making the Settings for MIDI

Connecting with an External Sound Device

Using the Digital Drum as a Sound Module

26

The digital drum transmission channel for the drum kit is fixed to Channel 10. It will output MIDI data generated by
the triggers when hitting the pads or stepping on the Hi-Hat control pedal (Note ON/OFF, and Foot messages).
Song playback data and metronome notes are not transmitted.

Recording Your Performance to an External Sequencer

Setting MIDI Note Number to be Transmitted/Received by Each Pad

1.

2.

3.

4.

5.

Connect the MIDI OUT of the digital drum to the MIDI IN of your sequencer, and the MIDI OUT of your
sequencer to the MIDI IN of the digital drum. If you are using a software sequencer on a computer, you can
simply connect the USB port of the digital drum to a USB port of your computer using a single USB A-B
cable.
Setup the active track of your sequencer on Channel 10. Activate RECORD on your sequencer.
Play the pads of your digital drum.
Stop recording. Locate your sequencer to the start of your recording.
Playback the recorded sequencer.

1.

2.

3.

4.

Press the [VOICE] button in NORMAL mode, enter the VOICE menu.
Press the [PAGE] or [VOICE] button, select Pad MIDI Note page.
Press the [ - ] or [ + ] button, change the MIDI Note Number for each pad. Hit the pad you wish to set or press
the related Pad Select button.
Press the [SAVE] button twice to save to user kit.

When GM Mode is ON,Channel 10 will play the GM percussion kits.
When GM Mode is OFF, Channel 10 will play the digital drum internal kits.

Each drum kit can have it’s own set of MIDI note to be transmitted/received by each pad, useful for advanced
purpose. Normally, you’ll never need to change them, but if you want to change, please follow these step:

Connecting an external keyboard or sequencer to the MIDI Input allows you to use the digital drum as a multi-part,
polyphonic sound module to play various instrument parts in addition to your drums (for instance, Piano on
Channel 1, Bass on Channel 2, Strings on Channel 3, etc). The voices on each MIDI channel are selected using
MIDI Program Change messages (refer to GM Backing Instrument List ).

The MIDI system in the digital drum has 16 reception channels numbered from 1-16. Each of the channels is
responsible for a voice. When the instrument receives MIDI information from an external device, the active channel
is determined by the control message. Channel 10 is reserved for Drums. The digital drum has two options for
Channel 10: GM ON or OFF, as selected in MIDI UTILITY menu.

Note:

For more information on received MIDI messages, refer to MIDI implementation chart.

Trigger MIDI Note Trigger MIDI Note Trigger MIDI Note Trigger MIDI Note Trigger MIDI Note
Kick
Snare
Snare R
Tom1
Tom1 R

Tom2
Tom2 R
Tom3
Tom3 R
Tom4

Tom4 R
Ride
Ride R
Crash1

Crash1 R
Crash2
Crash2 R
Hi-Hat O

36
38
40
48
50

45
47
43
58
41

39
51
53
49

55
57
52
46

Hi-Hat HO
Hi-Hat C
Hi-Hat P
Splash

23
42
44
21

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 26 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 26 2012/9/4 13:32:08

27

Prompt Messages

Display Meaning Action

TEMPO

BEAT

REC

TEMPO

BEAT

REC

Resetting the digital drum has failed.

Please press the [START/STOP]
button to score your practice, and
then play back your practice.

You didn’t record your practice in the
Learning mode.

The internal memory is full. You
cannot record any data.

If you want to record another song,
please restart recording and replace
it.

Please record your performance,
and then play it.

Please call your dealer for
evaluation.

There isn’t data in the digital drum’s
memory.

LEARN

TEMPO

BEAT

Troubleshooting

Problem Possible Cause and Solution

No Sound

1) Rotate the [VOLUME] knob to be sure that the volume isn’t down.

2) Be sure that Local Mode should be set to “ON”.

No Sound from Pads

1) Be sure that the pad is connected correctly.

2) Be sure not set the volume of the pad is not set to 0.

No Click Sound 1) To be sure not set the volume of the click is not set to 0.

Sound is Distorted 1) Turn down the volume.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 27 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 27 2012/9/4 13:32:08

28

Specifications

Maximum Polyphony

64

Drum kits

Drum Kits: 45（30 preset kits + 15 user kits)
General MIDI Kits: 11 GM Kits

Instruments

Drum Instruments: 510 (Drums, Percussion, SFX)
19 Hi-Hat Combos

Effect

Reverb,3 Band Equalizer

Sequencer

Normal: Song 80
Learning: Beat 20, Rhythm 12, Pattern 10
Resolution:120 ticks per quarter note
Recording Method: Real-time
Maximum Note Storage:approx.1600 Notes

Tempo

30~280

Display

Backlit Segment LCD

Connectors

9 Trigger Input Jack, Phone Jack(1/8”, stereo), Aux In
Jack(1/8”, stereo),
2 External Trigger Input Jack(1/4”, Tom4, Crash2),
Output(1/4”, L/Mono, R), USB, MIDI IN, MIDI OUT

Control Buttons

Power on/off switch, Volume, Start/Stop, Save, Song, Kit,
Voice, Page/Select, INC/DEC, Click, Drum off, Record,
Tempo, Utility, Play/Practice

Pad Select Buttons

12 Pad Select Buttons

Kit Configuration

Snare: 9”dual zone pad.
Tom1~tom3：9”dual zone pad.
Crash1:12” dual zone cymbal with choke.
Ride:14” dual zone cymbal with choke.
Hihat: 10”single zone cymbal without choke.

Power Supply

DC 9V

Dimensions

190(W) X 140(H) X 120(D) mm

Weight

0.5 kg

* All specifications and appearances are subject to change without notice.

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 28 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 28 2012/9/4 13:32:08

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

Standard 1
Pop Country
Standard 2
Funk 1
Funk 2
Fusion 1
Power Rock
Jazz Brush
Rock
Pop Rock
Fusion 2
Vintage
Latin Rock
Arena Rock
Banda
Ballad Rock
Disco
Prog Rock
Mambo
Songo
Beat Box 1
Hip Hop 1
Electro House
Break Beat
DubStep 1
Rap 1
Old Skool
Beat Box 2
DubStep 2
DrumNBass

NO. PRESET KIT

31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

Standard 1
Pop Country
Standard 2
Funk 1
Funk 2
Fusion 1
Power Rock
Jazz Brush
Rock
Pop Rock
Fusion 2
Vintage
Latin Rock
Arena Rock
Banda

NO. DEFAULT USER KIT

Drum Kit List

29

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 29 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 29 2012/9/4 13:32:08

30

Drum Instrument List

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49

50
51
52
53

54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98

99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129

130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147

148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198

Standard Kick 1
Standard Kick 2
Classic Kick 1
Classic Kick 2
Camco Kick 1
Camco Kick 2
Rock Kick 1
Rock Kick 2
Rock Kick 3
Room Kick 1
Room Kick 2
Jazz Kick 1
Jazz Kick 2
Big Band Kick 1
Big Band Kick 2
Funk Kick 1
Funk Kick 2
Funk Kick 3
HipHop Kick 1
HipHop Kick 2
HipHop Kick 3
HipHop Kick 4
1969 Kick
1971 Kick
1976 Kick
Power Kick
R&B Kick
Voice Kick
Acoustic Kick 1
Acoustic Kick 2
Acoustic Kick 3
Acoustic Kick 4
Orchestra Kick
Step Kick
Teckno Kick
Drum & Bass Kick
Junkyard Kick
Noise Kick
Industry Kick
Lowfi Kick
Disco Kick
808 Kick
909 Kick
House Kick 1
House Kick 2
Electronic Kick 1
Electronic Kick 2
Electronic Kick 3
Electronic Kick 4

Electronic Kick 5
Electronic Kick 6
Electronic Kick 7
Electronic Kick 8

Standard Snare 1
Standard Snare Rim 1
Standard Snare 2
Standard Snare Rim 2
Standard Snare 3
Standard Snare Rim 3
Standard Snare 4
Standard Snare Rim 4
R&B Snare
R&B Snare Stick
506 Snare
506 Snare Rim 1
506 Snare Rim 2
Classic Snare 1
Classic Snare Rim 1
Classic Snare 2
Classic Snare Rim 2
Acoustic Snare 1
Acoustic Snare Rim
Acoustic Snare 2
Rock Snare 1
Rock Snare Rim 1
Rock Snare 2
Room Snare 1
Room Snare 2
Room Snare 3
Steel Snare
Steel Snare Rim
Jazz Snare 1
Jazz Snare Rim 1
Jazz Snare 2
Jazz Snare Rim 2
Jazz Latin Snare
Big Band Snare
Camco Snare
Camco Snare Rim
Brush Snare 1
Brush Snare 2
Brush Snare Rim
Funk Snare
Funk Stick
Funk Band Snare
Funk Band Snare Rim
Funk Band Snare Stick
Fusion Snare

Fusion Snare Stick
Ringo Snare
Ringo Snare Rim
Snare Stick
Power Snare
HipHop Snare 1
HipHop Snare 2
1969 Snare
1969 Snare Rim
1971 Snare
1971 Snare Rim
1976 Snare
1976 Snare Rim
Step Snare
Step Snare Stick
House Snare 1
House Snare 2
House Snare 3
Teckno Snare 1
Teckno Snare 2
808 Snare
909 Snare
Drum & Bass Snare 1
Drum & Bass Snare 2
606 Snare
Electronic Snare 1
Electronic Snare 2
Electronic Snare 3
Electronic Snare 4
Electronic Snare 5
Noise Snare

Classic Tom 1
Classic 1 Tom Rim 1
Classic Tom 2
Classic 1 Tom Rim 2
Classic Tom 3
Classic 1 Tom Rim 3
Classic Tom 4
Classic 1 Tom Rim 4
Classic Tom 5
Classic 1 Tom Rim 5
Classic Tom 6
Classic 1 Tom Rim 6
Acoustic Tom 1
Acoustic Tom Rim 1
Acoustic Tom 2
Acoustic Tom Rim 2
Acoustic Tom 3
Acoustic Tom Rim 3

Acoustic Tom 4
Acoustic Tom Rim 4
Acoustic Tom 5
Acoustic Tom Rim 5
Acoustic Tom 6
Acoustic Tom Rim 6
Standard Tom 1
Standard Tom Rim 1
Standard Tom 2
Standard Tom Rim 2
Standard Tom 3
Standard Tom Rim 3
Standard Tom 4
Standard Tom Rim 4
Standard Tom 5
Standard Tom Rim 5
Standard Tom 6
Standard Tom Rim 6
Camco Tom 1
Camco Tom 2
Camco Tom 3
Camco Tom 4
Camco Tom 5
Camco Tom 6
Rock Tom 1
Rock Tom 2
Rock Tom 3
Rock Tom 4
Rock Tom 5
Rock Tom 6
Standard Tom 1
Standard Tom 2
Standard Tom 3
Standard Tom 4
Standard Tom 5
Standard Tom 6
Room Tom 1
Room Tom 2
Room Tom 3
Room Tom 4
Room Tom 5
Room Tom 6
Funk Tom 1
Funk Tom 2
Funk Tom 3
Funk Tom 4
Funk Tom 5
Funk Tom 6
Fusion Tom 1
Fusion Tom 2
Fusion Tom 3

KICK

SNARE

TOM

NO. NAME

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 30 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 30 2012/9/4 13:32:08

199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250

251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282

283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300

301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316

317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350

351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402

Fusion Tom 4
Fusion Tom 5
Fusion Tom 6
1969 Tom 1
1969 Tom 2
1969 Tom 3
1969 Tom 4
1971 Tom 1
1971 Tom 2
1971 Tom 3
1971 Tom 4
1976 Tom 1
1976 Tom 2
1976 Tom 3
1976 Tom 4
HipHop Tom 1
HipHop Tom 2
HipHop Tom 3
HipHop Tom 4
HipHop Tom 5
HipHop Tom 6
Jazz Tom 1
Jazz Tom 2
Jazz Tom 3
Jazz Tom 4
Jazz Tom 5
Jazz Tom 6
Brush 1 Tom 1
Brush 1 Tom 2
Brush 1 Tom 3
Brush 1 Tom 4
Brush 1 Tom 5
Brush 1 Tom 6
Brush 2 Tom Rim 1
Brush 2 Tom 2
Brush 2 Tom Rim 2
Brush 2 Tom 3
Brush 2 Tom Rim 3
Brush 2 Tom 4
Brush 2 Tom Rim 4
Brush 2 Tom 5
Brush 2 Tom Rim 5
Brush 2 Tom 6
Brush 2 Tom Rim 6
Tom Rim 1
Tom Rim 2
Tom Rim 3
Tom Rim 4
Timpani 1
Timpani 2
Timpani 3
Timpani 4

Step Tom 1
Step Tom 2
Step Tom 3
"Tom Rim"
606 Tom 1
606 Tom 2
606 Tom 3
606 Tom 4
606 Tom 5
606 Tom 6
808 Tom 1
808 Tom 2
808 Tom 3
808 Tom 4
808 Tom 5
808 Tom 6
Noise Tom 1
Noise Tom 2
Noise Tom 3
Electronic Tom 1
Electronic Tom 2
Electronic Tom 3
Electronic Tom 4
Electronic Tom 5
Electronic Tom 6
909 Tom 1
909 Tom 2
909 Tom 3
909 Tom 4
Junkyard Tom 1
Junkyard Tom 2
Junkyard Tom 3

Standard 20” Ride
Standard 21” Ride
Standard 22” Ride
Standard Ride Bell
Standard 22” Ride Rim
Junkyard Break
Junkyard Metal
Dry Ride Bell
Light Flat Ride
Classic Ride
Classic Ride Rim
Classic Ride Bell
Acoustic Ride
Acoustic Ride Rim
Acoustic Ride Bell
Standard 19” Ride
Vintage Ride
Teckno Ride 1

Teckno Ride 2
Jazz Ride Bell
Brush Ride
Brush Ride Rim
Brush Ride Bell
Rock Ride 1
Rock Ride 2
Clean Pop Ride
Ride Edge 1
Ride Edge 2
Mute Ride Bell
Clean Pop Ride Bell
Flat Ride
60’s Ride
808 Ride
Voice Hi-hat Pedal

Classic Crash 1
Classic Crash Rim 1
Classic Crash 2
Classic Crash Rim 2
Classic Crash 3
Standard Crash 1
Standard Crash Rim 1
Standard Crash 2
Standard Crash 3
Standard Crash 4
Rock Crash 1
Rock Crash 2
Rock Crash 3
Rock Crash 4
Rock Splash
Splash
Brush Crash 1
Brush Crash 2
China 1
China 2
China 3
China 4
Orchestra Crash
Orchestra Hit 1
Orchestra Hit 2
HipHop Crash
Junkyard Cymbal 1
Junkyard Cymbal 2
Cymbal Effect 1
Cymbal Effect 2
Drum & Bass Crash 1
808 Crash 1
808 Crash 2
808 Crash 3

606 Crash
Electronic Crash
606 Hi-hat Open
Industrial Short
Industrial Long
Standard Hi-hat Open 1
Standard Hi-hat Open 2
Classic Hi-hat Open
Pop Hi-hat Open
Rock Hi-hat Open 1
Rock Hi-hat Open 2
Jazz Hi-hat Open 1
Jazz Hi-hat Open 2
Brush Hi-hat Open
Mini Hi-hat Open
Junkyard Hi-hat Open
Noise Hi-hat Open
Electronic Hi-hat Open
808 Hi-hat Open 1
808 Hi-hat Open 2
909 Hi-hat Open
House Hi-hat Open
606 Hi-hat Open
Standard Half Open
Pop Half Open 1
Pop Half Open 2
Rock Half Open
Classic Half Open Rim
Jazz Half Open 1
Jazz Half Open 2
Brush Half Open
Mini Half Open
Junkyard Half Open Rim
Standard Hi-hat Close 1
Standard Hi-hat Close 2
Pop Hi-hat Close 1
Pop Hi-hat Close 2
Rock Hi-hat Close 1
Rock Hi-hat Close 2
Classic Hi-hat Close
Jazz Hi-hat Close
Brush Hi-hat Close
Mini Hi-hat Close
Junkyard Hi-hat Close

Noise Hi-hat Close
Electronic Hi-hat Close
808 Hi-hat Close 1
808 Hi-hat Close 2
909 Hi-hat Close
House Hi-hat Close
606 Hi-hat Close
Standard Hi-hat Pedal 1

RIDE

CRASH

Drum Instrument List

31

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 31 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 31 2012/9/4 13:32:08

PERCUSSION

HIHAT

403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426

427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446

447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491

492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510

Standard Hi-hat Pedal 2
Classic Hi-hat Pedal
Pop Hi-hat Pedal
Rock Hi-hat Pedal 1
Rock Hi-hat Pedal 2
Jazz Hi-hat Pedal 1
Jazz Hi-hat Pedal 2
Brush Hi-hat Pedal
Mini Hi-hat Pedal
Junkyard Hi-hat Pedal
Noise Hi-hat Pedal
Electronic Hi-hat Pedal
808 Hi-hat Pedal 1
808 Hi-hat Pedal 2
House Hi-hat Pedal
606 Hi-hat Pedal
Standard Hi-hat Splash
Splash
Pop Splash
Rock Hi-hat Splash
Classic Splash 1
Classic Splash 2
Mini Splash
Mute

Metronome Bell
Metronome Click
Scratch
Scratch Push
DJ FX
High Q Zap
Ding Bell
Finger Snaps
Standard Clap
Tambourine
Agogo High
Agogo Low
Bell Tree
Bongo High
Bongo Low
Shaker
Conga Slap High
Conga Slap Mid
Conga Low
Open Conga

Conga Slap
Cowbell
Timbale High
Timbale Low
Timpani High
Timpani Low
Open Tabla High
Open Tabla Low
Slap Tabla
Mute Slap Tabla
Maracas
Short Whistle
Short Guiro
Long Guiro
Claves
Wood Block 1
Wood Block 2
Muted Cuica
Open Cuica
Muted Triangle
Open Triangle
Open Surdo
Cowbell 1
Cowbell 2
Cowbell 3
Cowbell 4
Cowbell 5
Cowbell 6
DJ 1
DJ 2
DJ 3
DJ 4
DJ 5
DJ 6
DJ 7
DJ 8
DJ 9
DJ 10
FX 1
FX 2
FX 3
FX 4
FX 5
FX 6
FX 7

Standard A
Standard B
Pop A
Pop B
Rock A
Rock B
Classic
Jazz A
Jazz B
Brush
Mini
Junk
Dirty
Electron
808 A
808 B
909
House
606

Drum Instrument List

32

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 32 2012/9/4 13:32:08KMC_KIT_2_Manual_G09_120903.ai 32 2012/9/4 13:32:08

GM Drum Kit List

27－D#1
28 E1
29－F1
30－F#1
31－G1
32－G#1
33－A1
34－A#1
35－B1
36－C2
37－C#2
38－D2
39－D#2
40－E2
41－F2
42－F#2
43－G2
44－G#2
45－A2
46－A#2
47－B2
48－C3
49－C#3
50－D3
51－D#3
52－E3
53－F3
54－F#3
55－G3
56－G#3
57－A3
58－A#3
59－B3
60－C4
61－

C#4
62－D4
63－D#4
64－E4
65－F4
66－F#4
67－G4
68－G#4
69－A4
70－A#4
71－B4
72－C5
73－C#5
74－D5
75－D#5
76－E5
77－F5
78－F#5
79－G5
80－G#5
81－A5
82－A#5
83－B5
84－C6
85－C#6
86－D6
87－D#6

High Q
Slap
Scratch Push
Scratch Pull
Sticks
Square Click
Metronome Click
Metronome Bell
Acoustic Bass Drum
Standard 1 Bass Drum
Side Stick
Standard 1 Snare
Hand Clap
Standard 1 Snare Rim
Standard 1 Tom 6
Standard 1 Hi-hat Close
Standard 1 Tom 5
Standard 1 Hi-hat Pedal
Standard 1 Tom 4
Standard 1 Hi-hat Open
Standard 1 Tom 3
Standard 1 Tom 2
Standard 1 Crash 1
Standard 1 Tom 1
Standard 1 Ride
Chinese Cymbal 1
Ride Bell
Tambourine
Splash Cymbal
Standard 1 Cowbell
Standard 1 Crash 2
Vibra-slap
Ride Cymbal
Hi Bongo
Low Bongo
Mute Hi Conga
Open Hi Conga
Low Conga
High Timbale
Low Timbale
High Agogo
Low Agogo
Cabasa
Maracas
Short Whistle
Long Whistle
Short Guiro
Long Guiro
Claves
Hi Wood Block
Low Wood Block
Mute Cuica
Open Cuica
Mute Triangle
Open Triangle
Shaker
Jingle Bell
Bell Tree
Castanets
Mute Surdo
Open Surdo

<­<­<­<­<­<­<­<­<­Standard 2 Bass Drum
<­Standard 2 Snare
<­Standard 2 Snare Rim
Standard 2 Tom 6
Standard 2 Hi-hat Close
Standard 2 Tom 5
Standard 2 Hi-hat Pedal
Standard 2 Tom 4
Standard 2 Hi-hat Open
Standard 2 Tom 3
Standard 2 Tom 2
Standard 2 Crash 1
Standard 2 Tom 1
Standard 2 Ride
<­<­<­<­Standard 2 Cowbell
Standard 2 Crash 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­Room Bass Drum 1
Room Bass Drum 2
<­Room Snare
<­Room Snare Rim
Room Tom 6
Room Hi-hat Close
Room Tom 5
Room Hi-hat Pedal
Room Tom 4
Room Hi-hat Open
Room Tom 3
Room Tom 2
Room Crash 1
Room Tom 1
Room Ride
<­Room Ride Bell
<­Room Splash Cymbal
Room Cowbell
Room Crash 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­Rock Bass Drum 1
Rock Bass Drum 2
<­Rock Snare
<­Rock Snare Rim
Rock Tom 6
Rock Hi-hat Close
Rock Tom 5
Rock Hi-hat Pedal
Rock Tom 4
Rock Hi-hat Open
Rock Tom 3
Rock Tom 2
Rock Crash 1
Rock Tom 1
Rock Ride
<­Rock Ride Bell
<­Rock Splash Cymbal
Rock Cowbell
Rock Crash 2
<­<­<­<-

<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

Note No. Standard 1 (bank 0 ) Standard 2 (bank 4 ) Room (bank 09 ) Rock (bank 16 )

33

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 33 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 33 2012/9/4 13:32:09

27－D#1
28 E1
29－F1
30－F#1
31－G1
32－G#1
33－A1
34－A#1
35－B1
36－C2
37－C#2
38－D2
39－D#2
40－E2
41－F2
42－F#2
43－G2
44－G#2
45－A2
46－A#2
47－B2
48－C3
49－C#3
50－D3
51－D#3
52－E3
53－F3
54－F#3
55－G3
56－G#3
57－A3
58－A#3
59－B3
60－C4
61－C#4
62－D4
63－D#4
64－E4
65－F4
66－F#4
67－G4
68－G#4
69－A4
70－A#4
71－B4
72－C5
73－C#5
74－D5
75－D#5
76－E5
77－F5
78－F#5
79－G5
80－G#5
81－A5
82－A#5
83－B5
84－C6
85－C#6
86－D6
87－D#6

<­<­<­<­<­<­<­<­Funk Bass Drum 1
Funk Bass Drum 2
<­Funk Snare
<­Funk Snare Rim
Funk Tom 6
Funk Hi-hat Close
Funk Tom 5
Funk Hi-hat Pedal
Funk Tom 4
Funk Hi-hat Open
Funk Tom 3
Funk Tom 2
Funk Crash 1
Funk Tom 1
Funk Ride
<­<­<­<­<­Funk Crash 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­Electronic Bass Drum 1
Electronic Bass Drum 2
<­Electronic Snare
<­Electronic Snare Rim
Electronic Tom 6
Electronic Hi-hat Close
Electronic Tom 5
Electronic Hi-hat Pedal
Electronic Tom 4
Electronic Hi-hat Open
Electronic Tom 3
Electronic Tom 2
<­Electronic Tom 1
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­808 Bass Drum 1
808 Bass Drum 2
<­808 Snare
<­808 Snare Rim
808 Tom 6
808 Hi-hat Close
808 Tom 5
808 Hi-hat Pedal
808 Tom 4
808 Hi-hat Open
808 Tom 3
808 Tom 2
808 Crash 1
808 Tom 1
<­<­<­<­<­<­808 Crash 2
<­<­<­<­808 Mute Hi Conga
808 Open Hi Conga
808 Low Conga
<­<­<­<­<­808 Maracas
<­<­<­<­808 Claves
<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­House Bass Drum 1
House Bass Drum 2
<­House Snare
House Hand Clap
House Snare Rim
House Tom 6
House Hi-hat Close
House Tom 5
House Hi-hat Pedal
House Tom 4
House Hi-hat Open
House Tom 3
House Tom 2
<­House Tom 1
<­<­<­<­<­<­<­<­<­<­<­<-

<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

Note No. Funk (bank 17 ) Electronic (bank 24 ) 808 (bank 25 ) House (bank 28 )

GM Drum Kit List

34

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 34 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 34 2012/9/4 13:32:09

GM Drum Kit List

27－D#1
28 E1
29－F1
30－F#1
31－G1
32－G#1
33－A1
34－A#1
35－B1
36－C2
37－C#2
38－D2
39－D#2
40－E2
41－F2
42－F#2
43－G2
44－G#2
45－A2
46－A#2
47－B2
48－C3
49－C#3
50－D3
51－D#3
52－E3
53－F3
54－F#3
55－G3
56－G#3
57－A3
58－A#3
59－B3
60－C4
61－

C#4
62－D4
63－D#4
64－E4
65－F4
66－F#4
67－G4
68－G#4
69－A4
70－A#4
71－B4
72－C5
73－C#5
74－D5
75－D#5
76－E5
77－F5
78－F#5
79－G5
80－G#5
81－A5
82－A#5
83－B5
84－C6
85－C#6
86－D6
87－D#6

Note No.

<­<­<­<­<­<­<­<­Jazz Bass Drum 1
Jazz Bass Drum 2
<­Jazz Snare
<­Jazz Snare Rim
Jazz Tom 6
Jazz Hi-hat Close
Jazz Tom 5
Jazz Hi-hat Pedal
Jazz Tom 4
Jazz Hi-hat Open
Jazz Tom 3
Jazz Tom 2
<­Jazz Tom 1
Jazz Ride
<­<­<­<­<­Chinese Cymbal 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

Jazz (bank 32 )

<­<­<­<­<­<­<­<­Brush Bass Drum 1
Brush Bass Drum 2
<­Brush Snare
<­Brush Snare Rim
Brush Tom 6
<­Brush Tom 5
<­Brush Tom 4
<­Brush Tom 3
Brush Tom 2
Brush Crash 1
Brush Tom 1
Brush Ride
<­<­<­<­<­Brush Crash 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

Brush (bank 40 )

Concert Hi-hat Close
Concert Hi-hat Pedal
Concert Hi-hat Open
Concert Ride
<­<­<­<­Concert Bass Drum 1
Concert Bass Drum 2
<­Concert Snare 1
Castanets
Concert Snare 2
Timpani F
Timpani F#
Timpani G
Timpani G#
Timpani A
Timpani A#
Timpani B
Timpani C
Timpani C#
Timpani D
Timpani D#
Timpani E
Timpani F
<­<­<­Concert Crash 1
<­Concert Crash 2
<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<­<-

Orchestra (bank 48 )

35

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 35 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 35 2012/9/4 13:32:09

GM Backing Instrument List

PIANO

1 Acoustic Grand Piano
2 Bright Acoustic Piano
3 Electric Grand Piano
4 Honky-Tonk Piano
5 E.Piano 1
6 E.Piano 2
7 Harpsichord
8 Clavi

MALLET

9 Celesta
10 Glockenspiel
11 Music Box
12 Vibraphone
13 Marimba
14 Xylophone
15 Tubular Bells
16 Dulcimer

ORGAN

17 Drawbar Organ
18 Percussive Organ
19 Rock Organ
20 Church Organ
21 Reed Organ
22 Accordion
23 Harmonica
24 Tango Accordion

GUITAR

25 Nylon Guitar
26 Steel Guitar
27 Jazz Guitar
28 Clean Guitar
29 Muted Guitar
30 Overdriven Guitar
31 Distortion Guitar
32 Guitar Harmonics

BASS

33 Acoustic Bass
34 Finger Bass
35 Pick Bass
36 Fretless Bass
37 Slap Bass 1
38 Slap Bass 2
39 Synth Bass 1
40 Synth Bass 2

STRINGS

41 Violin
42 Viola

43 Celloi
44 Contrabass
45 Tremolo Strings
46 Pizzicato Strings
47 Orchestral Harp
48 Timpan

STRINGS ENSEMBLE

49 Strings Ensemble 1
50 Strings Ensemble 2
51 Synth Strings 1
52 Synth Strings 2
53 Choir Aahs
54 Voice Oohs
55 Synth Voice
56 Orchestra Hit

BRASS

57 Trumpet
58 Trombone
59 Tuba
60 Muted Trumpet
61 French Horn
62 Brass Section
63 Synth Brass 1
64 Synth Brass 2

REED

65 Soprano Sax
66 Alto Sax
67 Tenor Sax
68 Baritone Sax
69 Oboe
70 English Horn
71 Bassoon
72 Clarinet

PIPE

73 Piccolo
74 Flute
75 Recorder
76 Pan Flute
77 Blown Bottle
78 Shakuhachi
79 Whistle
80 Ocarina

LEAD

81 Lead1 (square)
82 Lead2 (sawtooth)
83 Lead3 (calliope)
84 Lead4 (chiff)
85 Lead5 (charang)

86 Lead6 (voice)
87 Lead7 (fifths)
88 Lead8 (bass & Lead)

PAD

89 Pad1 (newage)
90 Pad2 (warm)
91 Pad3 (Polysynth)
92 Pad4 (choir)
93 Pad5 (bowed)
94 Pad6 (metallic)
95 Pad7 (halo)
96 Pad8 (sweep)

EFFECTS

97 FX1 (rain)
98 FX2 (soundtrack)
99 FX3 (crystal)
100 FX4 (atmosphere)
101 FX5 (brightness)
102 FX6 (goblins)
103 FX7 (echoes)
104 FX8 (sci-fi)

ETHNIC

105 Sitar
106 Banjo
107 Shamisen
108 Koto
109 Kalimba
110 Bagpipe
111 Fiddle
112 Shanai

PERCUSSIVE

113 Tinkle Bell
114 Agogo
115 Steel Drums
116 Wood Block
117 Taiko Drum
118 Melodic Tom
119 Synth Drum
120 Reverse Cymbal

SOUND EFFECTS

121 Guitar Fret Noise
122 Breath Noise
123 Seashore
124 Bird Tweet
125 Telephone Ring
126 Helicopter
127 Applause
128 Gunshot

36

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 36 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 36 2012/9/4 13:32:09

37

Song List

No.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40

Name

Drum Intro
Drum Main A
Drum Main B
R&B
Modern Dance
Cool Jazz
Modern Pop
Fusion 1
Funk 1
Big Band 1
Funk 2
Pop Funk 1
Fusion 2
Funk 3
Fusion 3
Funk 4
Fusion 4
Pop Funk 2
Electronic&Funk
Drum & Bass 1
Break Beat
Dance
Drum & Bass 2
Latin Dance 1
Latin Dance 2
Swing 1
Latin Jazz 1
Big Band 2
3/4 Jazz
Jazz 1
Latin Jazz 2
Swing 2
6/8 Ballad
Pop Ballad
Pop Bossa
16 Beat Pop
Pop Shuffle
Ballad
Samba 1
Latin Pop 1

No.

41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80

Name

Mambo
Latin Rock 1
Latin Pop 2
Guitar Bossa
Country Blues
Rock
Reggae 1
60's Rock
Blues
World 1
World 2
Latin
Bossa
Samba 2
3/4 Pop
Pop
Jazz 2
Reggae 2
Reggae 3
Latin Rock 2
Fifths
Synth string
Brightness
Atmosphere
Chorused Piano
Bass Tap 1
Chorus Piano tap
Brightness Tap
Bass Tap 2
Pad Tap 1
Vibraphone
Bass Tap 3
Rain Tap
Pizzicato Strings
Bass Tap 4
Crystal
Xylophone
Bass Tap 5
Pad Tap 2
Glockenspiel Tap

Type

Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop

Type

Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Loop
Hit
Hit
Hit
Hit
Hit
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap
Tap

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 37 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 37 2012/9/4 13:32:09

Pattern List

BEAT

RHYTHM

No.

1
2
3
4
5
6
7
8

9
10
11
12
13
14
15
16
17
18
19
20

Name

Beat 1
Beat 2
Beat 3
Beat 4
Beat 5
Beat 6
Beat 7
Beat 8
Beat 9
Beat 10
Beat 11
Beat 12
Beat 13
Beat 14
Beat 15
Beat 16
Beat 17
Beat 18
Beat 19
Beat 20

Kit Bank

0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0

Beat

4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4

Tempo

100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100

Measure

4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4

No.

1

2

3

4

5

6

7

8

9
10
11
12

Name

Funk 1
Funk 2
HipHop 1
HipHop 2
Jazz 1
Jazz 2
Latin 1
Latin 2
Pop Rock 1
Pop Rock 2
Rock
6/8 Pop Rock

Kit Bank

0
0
0
0
0
0
0
0
0
0
0
0

Beat

4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
4/4
6/8

Tempo

110

90

90
113
157
187
190
200
105

97
100
125

Measure

4
4
4
4
4
4
4
4
4
4
4
4

PATTERN

No.

1
2
3
4
5
6
7
8
9

10

Name

Funk
HipHop
Latin Jazz
6/8 Ballad
Bossanova
R&B
3/4 Jazz
Reggae
Rock
Fusion

Kit Bank

17
25
40
8
17
25
40
0
0
0

Beat

4/4
4/4
4/4
6/8
4/4
4/4
3/4
4/4
4/4
4/4

Tempo

120
110
130

96

82

86
120

78
100
103

Measure

4
4
8
4
8
4

10

4
4
4

38

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 38 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 38 2012/9/4 13:32:09

Parameter List

NORMAL MODE

KIT

LEARNING MODE

Parameter

Kit Number
Kit Volume
Reverb
EQ High
EQ Middle
EQ Low

SONG
Parameter

Song Number
Accomp Volume of Song
Drum Volume of Song

Abbreviation

NUM

VOL

REV
EQH
EQM

EQL

Value

1—45
0—32

ON / OFF

-12 -- +12

-12 -- +12

-12 -- +12

VOICE
Parameter

Voice Number
Voice Volume
Voice Pan
Voice Pitch
Voice Reverb
MIDI Note
Pad Song Switch
Pad Song Number

Abbreviation

NUM/H-C

VOL
PAN

PIT

REV

MID

P-S

P-N

Value

1—510/ 1—19

0—32

-8 -- +8

-8 -- +8
0—16

0—127

ON / OFF

1—80

CLICK
Parameter

Signature
Interval
Click Volume
Click Voice

Abbreviation

SIG

INT

VOL

VOC

Value

0–9/2, 0–9/4, 0–9/8, 0–9/16

1–2, 3–8, 1–4, 1–8，1-12, 1-16

0—32

1—5

Abbreviation

NUM

ACC

DRM

Value

1—80
0—32
0—32

TEMPO
Parameter

TEMPO

Abbreviation

BPM

BEAT
Parameter

Beat Type
Drum Volume

Abbreviation

BEA

DRM

Value

1--20
0--32

PATTERN
Parameter

Pattern Type
Level
Accompany Volume
Drum Volume

Abbreviation

PTN

LEV
ACC
DRM

Value

1--10

1--5
0--32
0--32

RHYTHM
Parameter

Rhythm Type
Level
Drum Volume

Abbreviation

RHM

LEV
VOL

Value

1--12

1--6

0--32

RECORD
Parameter

Song Number
Kit
Tempo
Signature
Interval
Drum Off
Pre Count

Abbreviation

SNG

KIT

BPM

SIG

INT
DRM
PRC

Value

---/1—60
1—45

30—280

1–9/2, 1–9/4, 1–9/8, 1–9/16

1–2, 3–8, 1–4, 1–8，1-12, 1-16

---/ON/OFF
ON/OFF

UTILITY
Parameter

Pad Sensitivity
Pad Threshold
Crosstalk
Curve
Rim Sensitivity
Splash Sensitivity
Local on/off
GM on/off

Abbreviation

SEN

THR
CRO
CUR

R-S
S-S

LOC

GM

Value

1—16
0—16
1—16

1—6

1—16

1—9
ON/OFF
ON/OFF

Value

30—280

39

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 39 2012/9/4 13:32:09KMC_KIT_2_Manual_G09_120903.ai 39 2012/9/4 13:32:09

Function

Transmitted

10 ch
×
×
×
***********
0—127
***********
99H,V=1-127
×（99H,V=0）
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
Ч
ЧЧЧЧЧЧЧ
Ч
Ч
Ч
Ч

×
×
×
×

Recognized

1－16
×
×
×
***********
0－127
0－127

×
×

0-127

×
×
×
×
×
×
×

×

Remarks

Bank Select
Modulation
Portamento Time
Data Entry
Volume
Pan
Expression
Sustain Pedal
Portamento On/Off
Sostenuto Pedal
Soft Pedal
Reverb Program
Chorus Program
Reverb Level
Chorus Level
All Sound Off
Reset All Controllers
All Notes Off

Start And Stop Only

Basic
Channel

Mode

Note
Number
Velocity

After
Touch
Pitch Bend
Control
Change

Program
Change
System Exclusive
System
Common

System
Real Time
Aux

Messages

Default
Changed
Default
Messages
Altered

: True Voice
Note On
Note Off
Key’s
Ch’s

: True Number

: Song Position
: Song Select
: Tune
: Clock
: Commands
: Local On/off
: All Notes Off
: Active Sensing
: Reset

0
1
5
6

7
10
11
64
65
66
67
80
81
91
93

120
121
123

MIDI Implementation Chart

KIT_2_G09

C

M

Y

CM

MY

CY

CMY

K

KMC_KIT_2_Manual_G09_120903.ai 40 2012/9/4 13:32:10KMC_KIT_2_Manual_G09_120903.ai 40 2012/9/4 13:32:10
