Kaspersky Lab Integration with Microsoft Operations Manager

KASPERSKY LAB

Integration with Microsoft
Operations Manager

ADMINISTRATOR GUIDE

INTEGRATION WITH MICROSOFT OPERATIONS

MANAGER

Administrator Guide

© Kaspersky Lab

http://www.kaspersky.com

Revision date: November 2006

Table of Contents

CHAPTER 1. INTRODUCTION ...................................................................................... 4

CHAPTER 2. INSTALLING AND UNINSTALLING THE MANAGEMENT PACK........ 5

1.1. Installing the management pack ........................................................................... 5

1.2. Uninstalling the management pack ...................................................................... 6

CHAPTER 3. VIEWING EVENTS IN OPERATOR CONSOLE .................................... 8

CHAPTER 4. E-MAIL NOTIFICATIONS......................................................................... 9

APPENDIX A. KASPERSKY LAB................................................................................. 10

A.1. Other Kaspersky Lab Products .......................................................................... 11

A.2. Contact Us........................................................................................................... 19

APPENDIX B. LICENSE AGREEMENT....................................................................... 20

Chapter 1. Introduction

Some Kaspersky Lab products have the capability of integrating with Microsoft
Operations Manager through a special management pack that enables you to:

• Automatically detect computers on the business's network that have a
manageable Kaspersky Lab application installed.

• Gather information on operation of the program managed on each
computer, output to the Microsoft Operations Manager console, or send
e-mail notifications with a description of events that occur in program
operation and recommendations for eliminating the errors.

Chapter 2. Installing and

uninstalling the management
pack

This section covers installation and uninstallation of management packs for
Kaspersky Lab products through Microsoft Operations Manager.

1.1. Installing the management pack

To integrate with Microsoft Operations Manager, take the following
steps:

1. Deploy Microsoft Operations Manager in the network (for more details,

see the documentation for that application).

2. Copy the management pack file with the extension *.akm to the

computer from which Microsoft Operations Manager will be used by the
administrator.

3. Open Microsoft Operations Manager Administrator Console. To do so

run the command Start \ Programs \ Microsoft Operations
Manager \ Administrator Console.

4. Install the new management pack. To do so, select Microsoft

Operations Manager/ Management Packs from the administrator's
console tree and use the command Import/Export Management Pack
on the context menu.

The Management Pack Import/Export Wizard will then start. Follow its
instructions. To import the management pack for Kaspersky Security
specify the path to the pack file with the extension *.akm.

5. To distribute the management pack to all computers where Microsoft

Operations Manager is deployed, we recommend running a
synchronization procedure. To do so, select Microsoft Operations

Manager/ Management Packs from the console tree and use the
Commit Configuration Change command on the context menu. The

synchronization procedure may take some time.

6 Integration with Microsoft Operations Manager

Once the management pack is integrated with Microsoft Operations Manager,
the pack requires no further configuration (except for e-mail notifications
configuration, for details see Chapter 4 on page 9).

1.2. Uninstalling the management
pack

To uninstall the management pack, take the following steps:

1. Open the Microsoft Operations Manager Operator Console using the

Start \ Programs \ Microsoft Operations Manager \ Operator
Console command.

In the Operator Console, select All: Public Views/ Kaspersky Lab,
and using the Delete command from the context menu, delete the folder
in it with the name of the Kaspersky Lab application managed, with all
nested objects.

If the Kaspersky Lab folder does not contain any other items, you can
delete it as well.

2. Open the Microsoft Operations Manager Administrator Console. To do

so run the Start \ Programs \ Microsoft Operations Manager \
Administrator Console command. Take the following steps:

• delete the group of rules for the Kaspersky Lab application
managed with all the nested subgroups of rules from the node

Microsoft Operations Manager/ Management Packs/ Rule
Groups/ Kaspersky Lab.

If the error "This rule group may not be deleted because one or
more rules in the group is associated with an alert" occurs, you

must wait, until all obsolete data is deleted from the Microsoft
Operations Manager database. You can speed this up by
changing the interval for cleaning the database on the

Database Grooming tab that opens when you select Global
Settings from the context menu under Microsoft Operations
Manager/ Administration/ Global Settings.

• delete all groups with the name of the Kaspersky Lab managed
program from the Microsoft Operations Manager /
Management Packs / Computer Groups node;

Installing and uninstalling the management pack 7

• delete all attributes with the name of the Kaspersky Lab
managed program from the Microsoft Operations Manager /
Management Packs / Computer Attributes node.

Note that some attributes can be used simultaneously by
management packs for several Kaspersky Lab programs. For
example, the Kaspersky Anti-Spam Service for Microsoft
Exchange Server and Kaspersky Anti-Virus Service for
Microsoft Exchange Server attributes are used by the
applications Kaspersky Security for Microsoft Exchange Server
and Kaspersky Anti-Virus for Microsoft Exchange Server.
Before deleting attributes, be sure that they are not being used
by other management packs.

• delete the KAV Administrators group from the node Microsoft
Operations Manager / Management Packs / Notifications /
Notifications Group, provided it is not used by any other

Kaspersky Lab management packs;

• delete the script Kaspersky Lab: Service Monitoring from the
node Microsoft Operations Manager / Management Packs
/ Scripts, provided it is not used by any other Kaspersky Lab
management packs.

3. To distribute the changes to computers where Microsoft Operations
Manager is deployed, run a synchronization procedure. To do so, select
Microsoft Operations Manager/ Management Packs from the
administrator's console tree and use the Commit Configuration
Change command from the context menu. The synchronization
procedure may take some time.

Chapter 3. Viewing events in

operator console

To work with the management pack via Microsoft Operations Manager,
take the following steps:

1. Open Microsoft Operations Manager. To do so use the command Start \
Programs \ Microsoft Operations Manager \ Operator Console.

2. In the console tree, select Kaspersky Lab and the folder with the name
of the Kaspersky Lab managed program contained in it. This folder
contains the following objects:

• Computers: information on network computers with the

Kaspersky Lab managed program installed.

• Warnings: information on important or security-critical events in

the operation of the Kaspersky Lab managed program.

• Events: information about all important events that occur in

program operation.

• Status: information on the status of computers in the group with

the name of the Kaspersky Lab managed program.

When you select an object from a folder in the right-hand part of the window, a
list of information will be displayed for that object.
