Karran USA - 1291 East Ramsey Rd, Vincennes, IN 47591 - T: 866.452.7726 F: 812.885.2440 - www.karran.com
We reserve the right to update product specications without notice. Please visit karran.com
for the most current specication sheets. All dimensions are accurate to 1/4”. REV 05-2022
Karran Undermount Series stainless steel kitchen sinks are manufactured from durable 18 gauge stainless steel that makes them
tough and resilient to even the toughest daily tasks. Each sink is
nished with an elegant soft satin brushed nish that resists and
disguises surface scratches. Designed to be undermounted in all
types of solid surface, granite and quartz countertops.
PROJECT INFORMATION
PROJECT: ___________________________________
CONTACT: __________________________________
DATE: _______________________________________
NOTES:______________________________________
_____________________________________________
_____________________________________________
APPROVAL:
Stainless steel 31-1/2” x 20-1/8”
Large/Small Bowl Undermount Sink
Model: U-6040L
Series: U Series
Material: 18 Gauge, Type 304 stainless steel
Installation Type: Undermount
Conguration / Style: Large/small bowl
Finish: Soft satin brushed nish
Overall dimensions: 31-1/2” x 20-1/8”
Left bowl dimensions: 13-5/8” x 16” x 6-3/4”
Right bowl dimensions: 14-3/4” x 18-1/2” x 8-3/4”
PRODUCT SPECIFICATION
INSTALLATION PROFILE
Drain size: 3-1/2”
Min. cabinet size: 36”
Template included: Yes
Clips included: Yes
Accessories included: None
OPTIONAL ACCESSORIES
• Stainless steel basket strainer [L-1]
• Stainless steel basket strainer [L-2]
• Stainless steel disposal flange [L-2DF]
• Stainless steel bottom grids [GR-3002 and GR-3003]
