Kantronics TALON UDC SERIES User Manual

DWG ID: 181-0101-00A

Date: 2003-09-26

KANTRONICS

RADIO MODEM USER MANUAL

Kantronics Co., Inc.
1202 E. 23

rd

Street, Suite A
Lawrence, Kansas 66046
Phone: [phone]
Fax: [phone]
Web: http://www.kantronics.com

TALON UDC

SERIES

Page 2 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

1 REVISIONS

Revision Date Description

- 2003-09-26 Initial release.

A 2004-01-27 Added information on Input/Output CCA.

Page 3 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

2 TABLE OF CONTENTS

1 REVISIONS............................................................................................................ 2

2 TABLE OF CONTENTS........................................................................................ 3

3 GENERAL INFORMATION................................................................................. 6

3.1 Sales/Inquiries......................................................................................................... 6

3.2 Technical Support ................................................................................................... 6

3.3 Miscellaneous ......................................................................................................... 6

3.4 Disclaimer Notice ................................................................................................... 6

3.5 Kantronics Warranty Registration .......................................................................... 6

3.6 Important Information............................................................................................. 8

3.7 License Agreement ................................................................................................. 8

3.7.1 License .................................................................................................................... 8

3.7.2 Term........................................................................................................................ 8

3.7.3 Object Code ............................................................................................................ 8

3.7.4 Limited Warranty.................................................................................................... 8

3.7.5 General.................................................................................................................... 8

3.7.6 Other ....................................................................................................................... 9

3.8 Limited Warranty.................................................................................................... 9

3.8.1 WARRANTY ......................................................................................................... 9

3.8.2 REMEDY................................................................................................................ 9

3.8.3 EXCLUSIVE REMEDY ........................................................................................ 9

3.8.4 DISCLAIMER ...................................................................................................... 10

3.8.5 APPLICABLE PRODUCTS AND PERIODS ..................................................... 10

3.8.6 EXCLUSIONS...................................................................................................... 10

3.8.7 REMEDY PROCEDURE..................................................................................... 11

3.8.8 NON-ASSIGNMENT........................................................................................... 11

3.8.9 OTHER RIGHTS.................................................................................................. 11

3.9 Return/Repair Procedures ..................................................................................... 11

3.9.1 Check-List for Possible Problems......................................................................... 12

3.9.2 Return Procedures................................................................................................. 12

3.9.3 Service department contact information:.............................................................. 12

3.10 Repair Service Charges......................................................................................... 13

3.11 International Returns............................................................................................. 14

4 APPROVALS AND COMPLIANCE................................................................... 15

4.1 RF Exposure.......................................................................................................... 15

4.2 General Safety of Operation ................................................................................. 15

4.3 Information to the User......................................................................................... 16

4.4 FCC Notice ........................................................................................................... 16

4.5 Industry Canada Notice......................................................................................... 16

5 PRODUCT INFORMATION............................................................................... 17

5.1 Model Identification.............................................................................................. 17

5.2 FCC Regulations................................................................................................... 17

5.2.1 Licensing............................................................................................................... 17

5.2.2 Type Acceptance................................................................................................... 17

6 SPECIFICATION OF PRODUCT ....................................................................... 18

Page 4 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

6.1 TALON UDC UHF............................................................................................... 18

6.1.1 General.................................................................................................................. 18

6.1.2 Transmitter............................................................................................................ 18

6.1.3 Receiver ................................................................................................................ 18

6.2 TALON UDC VHF............................................................................................... 19

6.2.1 General.................................................................................................................. 19

6.2.2 Transmitter............................................................................................................ 19

6.2.3 Receiver ................................................................................................................ 20

7 CONNECTOR PINOUTS .................................................................................... 20

7.1 ANT Connector (A1J1)......................................................................................... 20

7.2 Dc Power Connector (A2J6)................................................................................. 20

7.3 Serial I/O Connector (A2J9) ................................................................................. 20

7.4 GPS Receiver Connector (A2W1J1) .................................................................... 21

7.5 Input/Output Connector (A3J1) ............................................................................ 21

7.6 Serial I/O Connector (A3J2) ................................................................................. 23

8 PACKET RADIO ................................................................................................. 23

8.1 Packet Radio Description...................................................................................... 23

8.2 Connected vs. Unproto.......................................................................................... 23

8.3 A Simple Connect................................................................................................. 24

8.4 Monitoring ............................................................................................................ 25

8.5 Selective Monitoring............................................................................................. 26

8.6 Digipeating............................................................................................................ 26

8.7 Advanced Digipeating .......................................................................................... 27

8.8 Multi-Connects ..................................................................................................... 28

8.9 Timing................................................................................................................... 29

8.10 FRACK (Frame Acknowledgment Time) ............................................................ 29

8.11 Retries in AX.25 Level 2, Version 1 vs. Version 2 .............................................. 30

8.12 Convers Mode vs. Transparent Mode ................................................................... 30

8.12.1 Exiting Transparent Mode .................................................................................... 30

8.13 Flow Control ......................................................................................................... 31

8.13.1 Software Flow Control.......................................................................................... 31

8.13.2 Hardware Flow Control ........................................................................................ 31

8.14 Remote Access...................................................................................................... 31

9 PROTOCOL DESCRIPTIONS ............................................................................ 32

9.1 Terminal Mode...................................................................................................... 32

9.2 Host Mode............................................................................................................. 32

9.2.1 Host Mode Description......................................................................................... 33

9.2.2 Exiting Host mode ................................................................................................ 33

9.3 KISS Mode............................................................................................................ 34

9.3.1 KISS Mode Description........................................................................................ 34

9.3.2 Exiting KISS mode ............................................................................................... 34

9.4 Transparent Unproto Packet (TUP) Mode............................................................ 35

9.4.1 TUP Mode Description......................................................................................... 35

9.4.2 TUP Mode Operation............................................................................................ 36

9.5 Poll Mode.............................................................................................................. 36

9.5.1 Poll Mode Protocol Description............................................................................ 37

Page 5 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

9.5.2 Poll Mode Operation............................................................................................. 37

9.6 Line Substitution (LINE SUB) Mode................................................................... 40

9.6.1 LINE SUB Mode Protocol Description ................................................................ 40

9.6.2 LSUB Mode Operation......................................................................................... 40

9.7 Mode Capabilities Matrix ..................................................................................... 41

10 CONFIGURATION.............................................................................................. 41

10.1 Automatic Vehicle Location (AVL) and Asset Tracking ..................................... 42

10.1.1 AVL Used Without a Terminal............................................................................. 42

10.1.2 AVL Used With a Terminal (For Text) ................................................................ 42

10.1.3 AVL Receive ........................................................................................................ 42

10.2 Base Station Operation ......................................................................................... 42

10.3 Data/Telemetry/SCADA/Text .............................................................................. 43

10.4 Digipeating............................................................................................................ 43

11 INSTALLATION ................................................................................................. 43

11.1 Dc Power............................................................................................................... 43

11.2 GPS Antenna......................................................................................................... 44

11.3 Serial I/O............................................................................................................... 44

11.4 Antenna ................................................................................................................. 44

11.5 Mounting of Unit .................................................................................................. 44

11.6 Input/Output .......................................................................................................... 44

11.7 Input/Output Serial I/O ......................................................................................... 45

12 THEORY OF OPERATION................................................................................. 45

12.1 Ritron’s VHF Radio XCVR, A1A1 ...................................................................... 45

12.1.1 Receiver ................................................................................................................ 45

12.1.2 Transmitter............................................................................................................ 47

12.1.3 Miscellaneous Functions....................................................................................... 48

12.2 Ritron’s UHF Radio XCVR, A1A1 ...................................................................... 48

12.2.1 Receiver ................................................................................................................ 48

12.2.2 Transmitter............................................................................................................ 50

12.2.3 Miscellaneous Functions....................................................................................... 51

12.3 Controller CCA, A2 .............................................................................................. 51

12.4 GPS Receiver, A2A1 ............................................................................................ 53

12.5 Input/Output CCA, A3.......................................................................................... 53

13 TALON COMMAND SET................................................................................... 54

14 SYSTEM FAULT INDICATION ...................................................................... 101

Page 6 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

3 GENERAL INFORMATION

3.1 Sales/Inquiries

Phone: [phone] (8 AM to 5 PM, Central Time, Monday through Friday)
Fax: [phone]
E-mail: [e-mail]
Web site: http://www.kantronics.com

3.2 Technical Support

Phone: [phone] (8 AM to 12 noon and 1 PM to 5 PM, Central Time, Monday

through Friday)
Fax: [phone]
E-mail: [e-mail]

3.3 Miscellaneous

The Kantronics TALON UDC (universal data controller) series of radio modems is
manufactured in the U.S.A.

All brands and product names are trademarks of their respective companies.

3.4 Disclaimer Notice

We have attempted to make this manual technically and typographically correct as of the
date of the current issue. Production changes to the TALON UDC series may add
changes to the manual at a later date.

Send comments or suggest corrections to Kantronics Co., Inc., 1202 E. 23rd Street, Suite
A, Lawrence, KS 66046, or e-mail [e-mail].

Information in this document is subject to change without notice.

Contents of this publication or the firmware within the TALON UDC series may not be
reproduced in any form without the written permission of the copyright owner.

Published in the United States of America.

3.5 Kantronics Warranty Registration

Please take the time to fill out a copy of the warranty registration form and mail it to
Kantronics, including a copy of your sales receipt, to register your purchase. Kantronics
must receive warranty registration within 10 days of purchase of the Kantronics TALON

Page 7 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

UDC series of radio modems to be valid. Both must be on file at Kantronics in order for
you to receive warranty service. Refer to the warranty policy in this manual for further
information.

Mail form and sales receipt to: Kantronics

1202 E 23rd Street, Suite A
Lawrence, KS 66046

Warranty Registration

Entity Name: ____________________________________________________________

Address: _______________________________________________________________

City: __________________________________________________________________

State: _______________________________ Zip/Postal Code: ____________________

Country: _______________________________________________________________

Contact Person’s Name: ___________________________________________________

Telephone Nr: ___________________________________________________________

E-mail: _________________________________________________________________

Product: TALON UDC series

TALON UDC UHF or TALON UDC VHF

Part Number: 001-0009-01 001-0009-11

001-0009-02 001-0009-12
001-0009-03 001-0009-13
001-0009-04 001-0009-14

Serial Nr: ________________________

Date of Purchase: ___________________

Dealer: _________________________________________________________________

Page 8 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

3.6 Important Information

READ THIS SECTION BEFORE INSTALLING THIS KANTRONICS PRODUCT

This product contains SOFTWARE in FLASH Memory, which is protected by both
United States copyright law and international treaty provisions.

If you install or use this product, you are bound by the terms of the SOFTWARE license
shown below. If you do not wish to be bound by such license, return the (unused)
complete product package to your supplier for refund. The supplier may deduct
restocking/re-packaging costs.

3.7 License Agreement

3.7.1 License

In consideration of payment of the License Fee, which is included in the price of the
product, the Licensor Kantronics Company, Inc. (Kantronics) grants (you) a non­exclusive right to use the SOFTWARE and associated documentation. No ownership
rights to the SOFTWARE or its Documentation are transferred from Kantronics to you.

3.7.2 Term

This License Agreement is effective until terminated. You may terminate this Agreement
by returning or destroying the unit and destroying the documentation. You may not rent
or lease the SOFTWARE, but you may transfer the SOFTWARE and accompanying
written materials on a permanent basis provided you retain no copies and the recipient
agrees to the terms of this Agreement. Kantronics may terminate this Agreement without
notice if you violate any terms or conditions of the agreement. In the event of termination
of the Agreement, provisions relating to Kantronics' disclaimers of warranties, limitation
of liability, remedies, or damages and Kantronics' proprietary rights shall survive.

3.7.3 Object Code

The SOFTWARE is delivered in object code only. You shall not reverse compile or
otherwise reverse engineer the SOFTWARE.

3.7.4 Limited Warranty

This product is covered by the standard Kantronics Company, Inc. Limited Warranty.

3.7.5 General

This License Agreement constitutes the complete Agreement between you and
Kantronics. The SOFTWARE and/or Documentation may not be exported or re-exported

Page 9 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

in violation of any export laws or regulations of the United States of America or any
other applicable jurisdiction. This Agreement shall be governed by and interpreted under
the laws of the State of Kansas, United States of America. Use, duplication, or disclosure
by the Government of the United States is subject to restrictions as set forth in
subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer SOFTWARE
clause of DFARS 252.227-7013. Kantronics may in its sole discretion, provide you with
upgrades of the SOFTWARE and/or Documentation if you have provided Kantronics
your completed Warranty registration with a copy of your receipt showing the amount
you paid.

3.7.6 Other

LICENSEE ACKNOWLEDGES HAVING READ AND UNDERSTOOD THIS
AGREEMENT AND AGREES TO BE BOUND BY ITS TERMS. LICENSEE
FURTHER AGREES THAT THIS AGREEMENT IS THE COMPLETE AND
EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN LICENSEE AND
LICENSOR AND SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT, ORAL
OR WRITTEN, AND ANY OTHER COMMUNICATIONS RELATING TO THE
SUBJECT MATTER OF THIS AGREEMENT.

3.8 Limited Warranty

KANTRONICS COMPANY, INC.
Effective 2003-09-01

To receive notice of future updates, or free copy of this manual, please go to
http://www.kantronics.com.

NOTE: Return of the Warranty Registration and proof of purchase is a pre-condition to
warranty coverage.

3.8.1 WARRANTY

Kantronics Co., Inc. ("Kantronics") warrants to the first consumer purchaser ("you"), for
the Applicable Warranty Period (as described below), that the Applicable Product (as
described below) will be free from defects in material and workmanship.

3.8.2 REMEDY

Kantronics agrees that, for any Applicable Product found by Kantronics to be in violation
of the warranty within the Applicable Warranty Period, it will, at its option, repair or
replace the defective Applicable Product at no charge to you, excluding in-bound
shipping charges.

3.8.3 EXCLUSIVE REMEDY

Page 10 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Repair or replacement of the Applicable Product, as provided herein, is the sole remedy
available to you against Kantronics, and in no event will Kantronics be responsible for
any other liability or damages or for incidental, special, or consequential damages,
regardless of whether purported liability is predicated upon negligence, strict tort,
contract, or other products liability theory and whether or not Kantronics is warned about
the possibility of such liability or damages. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY
TO YOU.

3.8.4 DISCLAIMER

This Limited Warranty is in lieu of all other warranties expressed or implied and no
representative or person is authorized to assume for Kantronics any other liability in
connection with the sale of its products. KANTRONICS SPECIFICALLY DISCLAIMS
THE IMPLIED WARRANTY OF MERCHANTABILITY AND IMPLIED
WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE FOR ANY
APPLICABLE PRODUCT. IF, HOWEVER, YOU ARE A CONSUMER WITHIN THE
MEANING OF 15 U.S.C. 2301(3), THE ABOVE DISCLAIMER OF IMPLIED
WARRANTIES IS EFFECTIVE ONLY FOR PERIODS OUTSIDE THE APPLICABLE
WARRANTY PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU.

3.8.5 APPLICABLE PRODUCTS AND PERIODS

Kantronics products are of two types: (1) hardware units and (2) firmware and software
for operation of these units, whether incorporated into the units themselves or separate
from the units as adjuncts or accessories to the units. Hardware units and the media
containing firmware, software, and documentation are sold to the consumer purchaser
and become property of the purchaser. Firmware and software are licensed for use by the
consumer purchaser in return for a fee included in the purchase price of the units and do
not become the property of the consumer. The product to which this warranty applies
(herein "Applicable Products") and the period during which the warranty shall apply
(herein, "Applicable Warranty Period") are as follows:

Applicable Products: TALON UDC series.
Applicable Warranty Period: Two (2) years from date of purchase.

3.8.6 EXCLUSIONS

This Limited Warranty does not apply to the cosmetic appearance of the Applicable
Product; to broken or cracked cabinets; to any accessory not supplied by Kantronics
which is used with the Applicable Product; to any product that has been subject to
misuse, abuse, or over-voltage; to any product that has been modified by non-Kantronics
personnel unless specifically authorized in writing by Kantronics; or to any product

Page 11 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

damaged or impaired by shipping (whether or not caused by poor packaging), neglect,
accident, wiring not installed by Kantronics, improper parameter settings which are
cleared by performing a hard reset, or use in violation of instructions furnished by
Kantronics or of generally accepted industry practice. Kantronics does not warrant that
the functions contained in any software will meet your requirements or achieve your
intended results; or that operation of any software will be uninterrupted or error-free or
without effect upon other software used with it. Responsibility for the selection of the
hardware and software program to achieve your intended results rests with you.

3.8.7 REMEDY PROCEDURE

Should you need to make a warranty claim, first contact the dealer from whom you
purchased the product. If the dealer is unable to assist you, contact Kantronics Co., Inc.:

• By mail at 1202 East 23rd Street, Suite A, Lawrence, Kansas 66046 USA

• By fax at 785-842-2031

• By phone at our Customer Support number 785-842-4476 (Hours: 8 AM to 12 noon

and 1 PM to 5 PM, Central Time)

• Or by e-mail at [e-mail].

Contact us prior to returning an Applicable Product to receive a Return Authorization
Number. (As a practical matter, problems can often be solved in such a manner without
the product having to be returned to Kantronics for repair or replacement.) Return of any
Applicable Product for the enforcement of rights under this Limited Warranty shall be at
your expense. Any product returned for warranty service, which Kantronics determines to
be without defect or not covered by this Limited Warranty, shall be subject to a minimum
labor charge and the product will be returned to you at your sole expense. Please note, no
warranty service will be provided until Kantronics has been furnished with your
Warranty Registration and copy of proof of purchase establishing purchase date.

3.8.8 NON-ASSIGNMENT

This Limited Warranty is not assignable by you. Any attempt to assign or transfer any of
the rights, duties, or obligations hereof is void.

3.8.9 OTHER RIGHTS

This Limited Warranty gives you specific legal rights and you may also have other rights,
which vary from jurisdiction to jurisdiction.

3.9 Return/Repair Procedures

Important: Our repair statistics show that a large percentage of units returned for
service, do not, in fact, require any service. Therefore, we advise you to please double­check the following list of common, user-solvable, sources of difficulty before contacting
Kantronics about returning your unit for service. An RMA (Return Merchandise

Authorization) number must be requested and received, and included with the unit

Page 12 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

returned for repair. If a unit is received without an RMA number, the shipment will be
denied.

3.9.1 Check-List for Possible Problems

If encountering difficulty in getting this equipment to "talk" to your computer, please
perform at least the following limited checks before calling or writing:

• Carefully check the wiring connections between the computer serial (RS232) port,

and the TALON UDC unit.

• If the cables were purchased from a third-party source, double-check to be sure that

they conform to the wiring instructions in this manual.

• Verify the serial baud setting in the terminal program.

• It may be useful to perform a "Hard Reset".

If service or repairs still appear necessary after checking the items listed above, it may be
wise to call, fax, email, or write Kantronics to determine if the problem can be solved
without returning the unit.

The Kantronics web page also includes a FAQ section, with a list of common problems
and solutions.

3.9.2 Return Procedures

When calling the service department, have the following information available:

• The unit name and serial number (the serial number is found on the bottom of the

unit)

• The firmware version number (the version number is displayed in response to the

VERSION command)

• The steps that have been taken to determine that the problem is with the TALON

UDC unit

3.9.3 Service department contact information:

Kantronics Co., Inc.
1202 E. 23rd Street, Suite A
Lawrence, KS 66046

Page 13 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The Service Department telephone hours are 8 AM to 12 noon and 1 PM to 5 PM
Central Time, Monday through Friday. Telephone access to the service department
is not available outside the stated hours.

Phone: [phone] (8 AM to 12 noon and 1 PM to 5 PM, central time)
Fax: [phone]
E-mail address: [e-mail]
Web site: http://www.kantronics.com

When writing, faxing, or sending email to Kantronics, include a clear description of the
problem, unit name, firmware version, computer type, communication software used and
if possible, a list of current parameter settings in the unit (as shown in response to a
DISPLAY command).

Be sure to include a return fax number, mailing address, and/or email address.

Returns direct to the factory for refund or exchange, are strictly regulated. The sales
department must approve any return for refund or exchange.

If the unit was recently purchased from one of our authorized dealers, contact that dealer
first.

3.10 Repair Service Charges

Consult the limited warranty policy in this manual for the service provisions offered by
Kantronics at no charge. This warranty is considered to be in force only when the
customer has submitted a completed warranty registration within ten days (10 d) of
purchase, and when the stipulations of the warranty have been met.

Violations of warranty clauses will automatically void the warranty, and cost of service
or repairs will be charged to the owner. Service outside the warranty period will be
charged at the cost of parts, labor, and return shipping, at the time of the repair or service.
Units sent in for service or repair, without prior Return Authorization, will be subject to
the minimum charge for labor plus cost of return shipping and handling.

Repair or DAMAGE to a unit, whether accidental or otherwise, is not covered by any
warranty provided by Kantronics, in which case, normal repair charges will apply.

Contact the Service Department at:

• 785-842-4476 (hours: 8 AM to 12 noon and 1 PM to 5 PM Central Time)

• Or e-mail at [e-mail]

to obtain a Return Authorization number.
Repaired units will be returned via UPS (or FedEx) C.O.D., if other payment
arrangements have not already been arranged. C.O.D. charges can be avoided by
providing payment information (VISA, MasterCard, or Discover) either at the time of the
return authorization request, or included with the unit, when it is sent to be repaired.

Page 14 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

3.11 International Returns

This section applies to international returns only, not to domestic returns.

In case of unit problems, first contact the dealer from whom the product was purchased.
If a Kantronics product must be returned, please observe the steps outlined below. This
will prevent unnecessary difficulties and expense for both the shipper and Kantronics.

All returns must be shipped to the factory at 1202 East 23rd Street, Suite A, Lawrence,
KS 66046 U.S.A.

The shipper must pay all expenses of returning items to Kantronics. This includes any
duty/entry fees, whether the return is for warranty or non-warranty repair. Usually, the
best way to return items to us is by mail. However, if using a courier service such as
DHL, UPS Expedited, Federal Express, etc., be sure to use DOOR-TO-DOOR service.
When using one of these services, a commercial invoice may be required. Please check
with the carrier before shipping.

Include in the description of the items on the paperwork (whether postal or courier) the
words: "U.S. GOODS RETURNED FOR REPAIR/REPLACEMENT." An additional
description of "Data communications equipment", would be helpful. It would also be
helpful (but not required) to include the code number 9801.00.1035 which tells U.S.
Customs agents that the package contains "U.S. goods returned without
improvement/enhancement". However, if the words "U.S. goods returned for
repair/replacement" are on the paperwork, the number is not really necessary.

Provide a value for customs purposes. This is usually the value of the item(s) in their
current condition. A $0 value is not acceptable for U.S. Customs.

Inside the package, with the item(s), include:

• A fax number, daytime telephone number, mailing address, and/or e-mail address if

available, in case we need to contact you

• A correct and full shipping address for return

• Method of payment to be used for any charges (if VISA, MasterCard, or Discover,

include expiration date)

• A brief description of the problem

• A reference to any conversations with the technical/sales staff about the problem

• Return Authorization number

Page 15 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

For warranty repairs, we will pay the shipping charges to return the item(s) via air parcel
post. If you wish return by courier service, include your account number. To be eligible
for repair under warranty, we must have a record that you sent your Warranty
Registration card and proof of purchase to Kantronics, and the item(s) must still be within
the applicable warranty period at the time the return is authorized.

For non-warranty repairs, you must pay the return shipping charges, in addition to
applicable repair charges.

4 APPROVALS AND COMPLIANCE

4.1 RF Exposure

The FCC, with its action in General Docket 79-144 of 1985-03-13 adopted a safety
standard for human exposure to radio frequency electromagnetic energy emitted by FCC
regulated equipment.

In accordance with FCC RF exposure requirements, the antenna for this device
must be installed such that a minimum separation distance of 20 cm (7.874 in.) is
maintained between it and the general population. Special care should be taken to
ensure compliance with this requirement for antennas mounted on vehicles in which
the general public can be exposed to RF energy without their knowledge. In these
cases, the locations on the vehicle shall be carefully chosen such that, at no time
people can come within the range of 20 cm.

The above criteria are based on 6 W of power, a maximum transmitter duty factor of 10
%, and a maximum antenna gain of 13 dBi. The installer of the system, in any situation,
must adhere to FCC RF maximum permissible exposure (MPE) limits. See FCC OET
Bulletin 65 and 47 CFR Part 2.

4.2 General Safety of Operation

Please observe the following safety precautions.

• DO NOT operate radio equipment near electrical blasting caps.

• DO NOT operate radio equipment in an explosive atmosphere.

• DO NOT operate any radio transmitter unless all RF connectors are secure, and any

open connectors are properly terminated.

• DO NOT operate the transmitter of a fixed radio (base station, microwave, rural

telephone RF equipment) or marine radio when someone is within 0.6 m (two feet) of
the antenna.

Page 16 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

• ONLY authorized personnel shall perform repair of Kantronics TALON UDC

products.

4.3 Information to the User

This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.

4.4 FCC Notice

It is the responsibility of the user of this equipment to obtain the proper FCC license to
operate this product on the desired channel of operation.

This product complies with part 15 of the FCC rules and regulations. It may not be
modified without the expressed consent of Kantronics. Modification of this product could
void the user’s authorization to use the product.

The user is cautioned that any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
The user is also cautioned that any peripheral device installed with this equipment must
be connected with a high-quality shielded cable to insure compliance with FCC limits.

Note: The shield of the cable, whether foil, braid, braid over foil, or double braid, must

be properly terminated (connected) 360° to the connector. This is usually accomplished

by the use of a metal or metalized plastic back shell, but may be implemented by direct
contact, including soldering, with metal portion of connector. Experience has indicated
that cable assemblies (with connectors) advertised as “shielded” are not necessarily
terminated properly, if terminated at all. Check cable construction to be sure.

4.5 Industry Canada Notice

This Class A digital apparatus meets all requirements of the Canadian Interference
Causing Equipment Regulations. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may

cause undesired operation.

Page 17 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Cet appareillage numérique de la classe A répond à toutes les exigences de l'interférence
canadienne causant des règlements d'équipement. L'opération est sujette aux deux
conditions suivantes:
(1) ce dispositif peut ne pas causer l'interférence nocive, et
(2) ce dispositif doit accepter n'importe quelle interférence reçue, y compris l'interférence

qui peut causer l'opération peu désirée.

5 PRODUCT INFORMATION

The TALON UDC series of radio modems are wireless modems using four-level
frequency shift keying (4-LFSK) modulation to meet compliance with FCC and other
regulations for high-speed data.

5.1 Model Identification

Model FCC ID Option Kantronics P/N
TALON UDC UHF B2FTALON-U Without GPS 001-0009-01
TALON UDC UHF B2FTALON-U With GPS 001-0009-02
TALON UDC VHF B2FTALON-V Without GPS 001-0009-11
TALON UDC VHF B2FTALON-V With GPS 001-0009-12

Model Kantronics P/N Frequency Range Baud/Data Rate
TALON UDC UHF 001-0009-01 450 – 470 MHz 4800/9600 BPS
TALON UDC UHF 001-0009-02 450 – 470 MHz 4800/9600 BPS
TALON UDC VHF 001-0009-11 148 – 174 MHz 4800/9600 BPS
TALON UDC VHF 001-0009-12 148 – 174 MHz 4800/9600 BPS

Note: Radio transceivers with 6 W output are available on other frequency ranges of 136
to 162 MHz VHF and 400 to 420 MHz UHF in narrow band (12.5 kHz). Other options
are wide band (25 kHz) in the VHF frequency ranges of 136 to 162 MHz and 148 to 174
MHz and UHF in the frequency ranges of 400 to 420 MHz and 450 to 470 MHz.

5.2 FCC Regulations

5.2.1 Licensing

The FCC requires the radio owner to obtain a station license for the radio before using the
equipment to transmit, but does not require an operating license or permit. The station
licensee is responsible for proper operation and maintenance of his radio equipment, and
for ensuring transmitter power, frequency, and deviation are within limits specified by the
station license. This includes checking transmitter frequency and deviation periodically
using appropriate methods.

5.2.2 Type Acceptance

Page 18 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

When aligned in accordance with the procedures provided, for proper bandwidth, the
TALON UDC series is type-accepted for transmission of data and text.

6 SPECIFICATION OF PRODUCT

6.1 TALON UDC UHF

6.1.1 General

FCC Identifier B2FTALON-U
FCC Rule Part 90
Canada IC Identifier 4623A-TALONU
Frequency Range 450 – 470 MHz
Number of channels 1 RX and 1 TX
Transmit/Receive Spacing, maximum 20 MHz
Mode of Operation Simplex or Half Duplex
Frequency Control PLL Synthesizer
Frequency Step Size 5 or 6.25 kHz
Emissions Bandwidth (Carson’s rule) 9.4 kHz

Frequency Stability (-30 to +60 °C)

1.5 PPM
Supply Voltage 8.5 to 15 V dc (< 50 mV rms noise)
Supply Current @ 13.8 V dc RX, maximum: 100 mA

TX, maximum @ 6 W: 2.5 A
RF I/O Connector N(f)
Power Connector COMBICON 2-pin
Programming/Data Interface 9-terminal D-subminiature female
Operating Temperature

-30 to +60 °C

Humidity, maximum 95 % non-condensing
Dimensions w/o Protrusions 2.4” H X 6.5” W X 4.95” D
Weight/Mass 1.5 lbs. (0.68 kg)

6.1.2 Transmitter

Operating Bandwidth 20 MHz
RF Output Power, S/W adjustable < 1 W up to 6 W
Duty Cycle 50 % (TX maximum 30 s) @ 6 W
RF Z

load

50 
Attack time, maximum 15 ms
Spurious and Harmonics, maximum -20 dBm
Group Delay Variation (w/in Frequency
Response), maximum

5 µs

6.1.3 Receiver

Page 19 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Operating Bandwidth 20 MHz
Sensitivity, for 1 x 10-6 BER -115 dBm
RF Zin

50 
Adjacent Channel Selectivity, minimum 60 dB
Spurious and Image Rejection, minimum 70 dB
Intermodulation Rejection, minimum 70 dB
Conducted Spurious, maximum -57 dBm
Receive Attack Time (TX to RX),
maximum

15 ms

RSSI Squelch Attack Time, maximum 5 ms
Group Delay Variation (w/in Frequency
Response), maximum

20 µs

6.2 TALON UDC VHF

6.2.1 General

FCC Identifier B2FTALON-V
FCC Rule Part 90
Canada IC Identifier 4623A-TALONU
Frequency Range 148 – 174 MHz
Number of channels 2 (1 RX and 1 TX)
Transmit/Receive Spacing, maximum 26 MHz
Mode of Operation Simplex or Half Duplex
Frequency Control PLL Synthesizer
Frequency Step Size 2.5 kHz
Emissions Bandwidth (Carson’s rule) 9.4 kHz

Frequency Stability (-30 to +60 °C)

1.5 PPM
Supply Voltage 8.5 to 15 V dc
Supply Current RX, maximum: 100 mA

TX, maximum: 2.5 A
RF I/O Connector N(f)
Power Connector COMBICON 2-pin
Programming/Data Interface 9-terminal D-subminiature female
Operating Temperature

-30 to +60 °C

Humidity, maximum 95 % non-condensing
Dimensions w/o Protrusions 2.4” H X 6.5” W X 4.95” D
Mass (Weight) 1.5 lbs. (0.68 kg)

6.2.2 Transmitter

Operating Bandwidth 26 MHz
RF Output Power, S/W adjustable < 1 W up to 6 W
Duty Cycle 50 % (TX maximum 30 s) @ 6 W

Page 20 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

RF Z

load

50 
Attack time, maximum 15 ms
Spurious and Harmonics, maximum -20 dBm
Group Delay Variation (w/in Frequency
Response), maximum

5 µs

6.2.3 Receiver

Operating Bandwidth 26 MHz
Sensitivity, for 1 x 10-6 BER -115 dBm
RF Zin

50 
Adjacent Channel Selectivity, minimum 60 dB
Spurious and Image Rejection, minimum 70 dB
Intermodulation Rejection, minimum 70 dB
Conducted Spurious, maximum -57 dBm
Receive Attack Time (TX to RX),
maximum

15 ms

RSSI Squelch Attack Time, maximum 5 ms
Group Delay Variation (w/in Frequency
Response), maximum

20 µs

7 CONNECTOR PINOUTS

7.1 ANT Connector (A1J1)

N female. Mate with N male.

7.2 Dc Power Connector (A2J6)

Two-pin COMBICON. Mate with two-socket COMBICON, P1, provided.

Terminal Nr Physical Position Description

1 Left terminal + dc voltage
2 Right terminal GND (dc return)

7.3 Serial I/O Connector (A2J9)

D-sub 9 female. Mate with D-sub 9 male.

Page 21 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Terminal Nr Description

1DCD
2RXD
3TXD
4DTR
5 Digital GND
6DSR
7RTS
8CTS
9RI

7.4 GPS Receiver Connector (A2W1J1)

MPX female. Mate with MPX male, which is the connector on the end of the
transmission line, that is part of the supplied GPS magnet mount antenna.

7.5 Input/Output Connector (A3J1)

AI1 AI3 DGND AI5 AI7 DGND DI4 DI2 DGND DO4 DO2 GND AO1 AO3 GND

1 3 5 7 9 11 13 15 17 19 21 23 25 27 29
2 4 6 8 10 12 14 16 18 20 22 24 26 28 30

AI2 AI4 DGND AI6 AI8 DGND DI3 DI1 DGND DO3 DO1 GND AO2 AO4 GND

I/O (A3J1) CONNECTOR PINOUT

Page 22 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Nomenclature Description

AI1 Analog Input 1, 0 to 5 V dc*
AI2 Analog Input 2, 0 to 5 V dc*
AI3 Analog Input 3, 0 to 5 V dc*
AI4 Analog Input 4, 0 to 5 V dc*
AI5 Analog Input 5, 0 to 5 V dc*
AI6 Analog Input 6, 0 to 5 V dc*
AI7 Analog Input 7, 0 to 5 V dc*
AI8 Analog Input 8, 0 to 5 V dc*
AO1 Analog Output 1, 0 to 4.995 V dc @ minimum 10 k1 load
AO2 Analog Output 2, 0 to 4.995 V dc @ minimum 10 k1 load
AO3 Analog Output 3, 0 to 4.995 V dc @ minimum 10 k1 load
AO4 Analog Output 4, 0 to 4.995 V dc @ minimum 10 k1 load
DGND Digital ground of PCB (4P)
DI1 Discreet Input 1**
DI2 Discreet Input 2**
DI3 Discreet Input 3**
DI4 Discreet Input 4**
DO1 Discreet Output 1***
DO2 Discreet Output 2***
DO3 Discreet Output 3***
DO4 Discreet Output 4***
GND Chassis ground (PCB equivalent)

*Analog inputs may be jumpered internally (249 1 resistor) for two-wire or three-wire
0 to 20 mA range input.

**Discreet inputs are pulled up internally to logic high of 5 V dc. These inputs may be
activated, pulled low, with relay contact, open collector BJT, or open drain FET.

***Discreet outputs can handle up to +50 V dc and 115 mA dc (open
drain MOSFET).

*Note: Because of protection op-amps, which are rail-to-rail input and output
devices, the voltage to the YP internal 10 bit A/D converters is limited to 4.950 V.

Connect grounds as follows:

Nomenclature Terminal Nr Use Terminal Nr

AI1 1 DGND 5
AI2 2 DGND 6
AI3 3 DGND 5
AI4 4 DGND 6
AI5 7 DGND 11
AI6 8 DGND 12
AI7 9 DGND 11
AI8 10 DGND 12

Page 23 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

DI1 16 DGND 18
DI2 15 DGND 17
DI3 14 DGND 18

DI4 13 DGND 17
DO1 22 GND 24
DO2 21 GND 23
DO3 20 GND 24
DO4 19 GND 23
AO1 25 GND 29
AO2 26 GND 30
AO3 27 GND 29
AO4 28 GND 30

7.6 Serial I/O Connector (A3J2)

D-sub 9 female. Mate with D-sub 9 male.

Terminal Nr Description

1DCD
2RXD
3TXD
4DTR
5 Digital GND
6DSR
7RTS
8CTS
9RI

8 PACKET RADIO

8.1 Packet Radio Description

AX.25 was developed many years ago as a way of transferring data from one place to
another, through standard types of two-way radio equipment. It is a modification of the
X.25 networking protocol for wired networks.

8.2 Connected vs. Unproto

There are two ways to send data in the AX.25 packet protocol, connected or unproto
(unconnected).

In the CONNECTED mode, a “connection” or link is established between two packet
controllers, over a radio channel. Packets are sent from one controller to another, and
acknowledgments are expected in return that the packets were received correctly. If an

Page 24 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

acknowledgment is not received, the data will be re-sent (depending on the setting of the
AX25L2V2 command, it may send a poll first). The RETRY parameter will determine
how many times this is done before the connection is aborted due to bad conditions.

When acknowledgment is received, more data can then be sent. Therefore the
CONNECTED mode, barring impossible conditions, assures that data can pass from one
station to another correctly and in the proper order.

In the UNPROTO mode, data is transmitted with no acknowledgment expected or
required, and no retries are attempted. This mode is often used for transmitting beacons,
and for data broadcasts.

To manually type and send characters in UNPROTO mode, enter the Convers Mode by
entering the CONV (or K) command. Then, typed and entered characters will be
packetized and transmitted as data, and not be interpreted as commands.

When transmitting UNPROTO packets, the command called UNPROTO sets the
destination or “to” address of those packets. Its default setting is CQ.

To exit Convers mode and return to Command Mode, enter a <Ctrl+C>, by holding down
the Control key and pressing the "C" key.

8.3 A Simple Connect

To connect to another station, start from command prompt and enter a connect request.
For example:

CONNECT {callsign}<CR>

Where CONNECT is the command to establish a packet link with another station, and
{callsign} is the callsign of the other station. If the connect request fails, the following
messages will be displayed:

*** RETRY COUNT EXCEEDED
*** DISCONNECTED

When an acknowledgment is received for a connect request packet, the following
message will be displayed:

*** CONNECTED TO {callsign}

and the TALON will then change to the Convers Mode, or the communication mode
defined by the settings of the NOMODE and CONMODE commands.

Two commands determine when entered data will be packetized and transmitted. The
command SENDPAC defines the key or character that causes a packet to be transmitted.

Page 25 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Its default setting is the ENTER or RETURN key. Whenever that key is pressed, a new
packet will be transmitted.

A second command called PACLEN determines the maximum number of characters to
include in a transmitted packet. When the number of typed characters is equal to the
number defined by PACLEN, a packet will be made and transmitted even if the ENTER
key has not yet been pressed.

When the conversation with the other station has ended, the packet link to the station can
be “disconnected”. To disconnect, return to Command mode with <Ctrl+C> and type a
"D" for Disconnect. Press the return or enter key after any command to the TNC. A
Disconnect request packet will be sent to the other station, and when an
acknowledgement has been received back, the message:

*** DISCONNECTED

will be displayed and the TALON will return to Command mode.

Either station can issue the disconnect command no matter which station originated the
connect.

While connected to another station, the display of monitored packets will stop. To
continue the display of monitored packets, while connected to other stations, set the
command MCON to ON.

8.4 Monitoring

One of the main functions of a “Base” station TALON, would be to display position
packets heard from “remote” or mobile TALON units. Its command called MONITOR
should be set to ON, so that those packets heard from other stations can be displayed.

The display of monitored packets includes “header” and “data” parts. At the beginning of
the header, two callsigns are displayed separated by a ">". The first callsign is the station
that transmitted the packet, and the second callsign is the destination station that the
packet is intended for. Unproto packets may have any destination, but typically use CQ.

The setting of the command GBEACON specifies the format and amount of data that is
displayed from remote unit packets.

A remote unit will display its own transmitted packets, when the command MXMIT is set
to ON. It can also display its own location information at intervals set by the command
GREPORT (regardless of the setting of its GBEACON interval.) This “local” display in a
remote will be in the format specified by GTEXT.

Page 26 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

This “local” display is output from the serial port of the TALON, for use by an attached
computer. This computer may be running its own data recording program or displaying
this unit’s position on a map.

8.5 Selective Monitoring

With MONITOR ON, the BUDLIST command can be used to limit the display of
monitored packets from other stations, to only those packets specifically FROM (or TO,
or both) a specific station or any of up to 10 callsigns listed. This function would be used
in a remote unit, so that it would display only packets heard from a base station, and not
packets heard from other mobile stations.

8.6 Digipeating

Each TALON can be configured to digitally repeat or “digipeat” packets that are heard
from other TALONs. This can help extend the normal transmitting range of other
stations, to reach a destination station that they can not hear direct. This command is
called DIGIPEAT, and its default setting is ON.

A base unit TALON can be configured as a dedicated digipeater, and installed in a high
location to provide an extended coverage area for many other TALONs. Mobile
TALONs can also be configured digipeaters, but may not be as effective as a dedicated
unit placed in a high location.

When the command MRPT is set to ON, the display of monitored packets from
digipeater stations will include callsigns of the sending station and the intended recipient
of the packet, and the callsigns of any digipeaters used to relay those packets.

The command called MYALIAS defines an alternate callsign or alias name for the
digipeater.

A station that needs to send a packet to another station it can not hear direct would
address that packet “VIA” a digipeater stations callsign or alias. Up to 8 digipeaters can
be used to relay packets to reach a desired station.

To connect to another station VIA a digipeater, a command would be entered such as:

CONNECT REMOTE2 VIA DIGI3

or if several digipeaters are required,

CONNECT REMOTE2 VIA DIGI3,DIGI4,DIGI5

When Digipeating, a packet is transmitted by the originating station, is re-transmitted by
all relay stations specified, to reach the destination station. That station would then

Page 27 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

respond that it received the packet, by returning an acknowledgement packet by the same
path to the original station. This is often called end-to-end acknowledgment.

To send unconnected type packets like broadcast messages or BEACONs VIA a
digipeater, the UNPROTO command is used to set the path,

UNPROTO ALL VIA DIGI3

An advanced type of digipeater function for UI (unconnected-information) is also
available, configured by its own set of commands. It is described in another section,
called “Advanced Digipeating”.

8.7 Advanced Digipeating

When establishing a large coverage area, one or more (sometimes, many) digipeater
stations may be required.

Using the same digipeater alias in more than one digipeater is allowed, and can simplify
system programming.

The TALON includes UI Digipeating commands that can be used to deal with
inefficiencies that can arise when a number of digipeaters using the same generic names
are located in the same area, and can transmit at the same time. These special digipeater
functions work only with UI (unconnected information) type packets.

The command UIDIGI may be used to set up to four additional aliases/call signs for
"special" Digipeating service. To-be-digipeated packets received containing one of these
aliases will be repeated (once) with the call sign (MYCALL) of the digipeater substituted
for the alias in the digipeated frame.

UIFLOOD is a bit more exotic. It provides for multi-hop Digipeating with just one
digipeater address per packet, thereby keeping the transmission time short. To digipeat
through three TALONs supporting the UIFLOOD command, a reporting station might set
a GPS position path as GPATH GPS via wide3-3.

A digipeater TALON supporting "wide" set by the UIFLOOD command and hearing the
reporting station's transmission would then repeat the UI location packet (assuming it had
not done so already, within a preset time), using an address of wide3-2. In turn each
similar digipeater down line would digi the reporting station's UI packet and reduce
(decrement) the SSID of the digipeater address again.

A TALON using UIFLOOD has the option of inserting MYCALL in the digipeater field
of a repeated packet, creating two digipeater addresses rather than one, in each
transmitted packet.

Page 28 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The current setting of UIDWAIT determines whether or not a delay is added to UI
digipeat packets (those formed by UIDIGI or UIFLOOD) before transmission, once the
channel is clear. If UIDWAIT is ON, the delay is determined by SLOTTIME and
PERSIST settings.

Note: Digipeater priority for call signs is as follows: MYCALL, MYNODE, MYALIAS,
UIDIGI, UIFLOOD (e.g. if the same call sign has been assigned to MYALIAS and
UIDIGI, a to-be-digipeated frame with that call sign will be digipeated according to the
rules that apply to MYALIAS.)

For more information on the Global Positioning System, we recommend the following
resources:

Collins, J., et al., GPS Theory and Practice, Second Edition, Springer-Verlag, 1993.

Etherington, Michael, "FM subcarrier network extends differential GPS nationwide",
Mobile Radio Technology, February 1994.

Kaplan, Elliot, "The global positioning system (GPS)", Communications Quarterly,
Summer 1994.

Langley, R., "The mathematics of GPS", GPS World Magazine, July/August 1991.

"NMEA 0183 ASCII Interface Standard", (NMEA 0183 version 2.0), NMEA, P.O. Box
50040, Mobile, AL 36605.

8.8 Multi-Connects

The TALON allows packet “connect” links (or streams) to as many as 26 other stations at
the same time.

The command MAXUSERS determines how many streams may be used at one time, and
the command USERS determines how many connect links from other stations will be
accepted. Each incoming connect is assigned to the next available stream. If the number
of streams allowed by USERS is full, a busy message will be returned to the next station
attempting to connect, instead of a connect acknowledgement.

By setting the USERS command to a lower number than MAXUSERS, the number of
streams between them will not be assigned to connect requests from other stations, and
are reserved for outgoing connect links.

The STATUS command (sent while in command mode) reports which streams are
currently active, the current “I/O” stream, and buffer status.

Page 29 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

To change streams, to make another connect or to direct data to another connected station
on a different stream, type the STREAMSW character, and the letter designation of the
desired stream. No return or enter key is necessary.

The setting of STREAMEV will then determine how often the stream designator is
displayed with received data. Setting it to ON will make the stream designators show on
every connected packet received. Setting STREAMCA also to ON will add the callsign
of the "from" station beside the stream designator.

8.9 Timing

Dwait vs. Persistence and Slottime

When the TALON acts as a digipeater, received packets that need to be relayed are
retransmitted as soon as the frequency is clear. Beacon and other unproto packets to be
transmitted are normally delayed by a small amount of time, by the
PERSISTENCE/SLOTTIME algorithm or DWAIT.

The default value for DWAIT is set to zero. If the DWAIT method is used, the TALON
sending non-digipeat packets will wait for DWAIT (times 10 milliseconds) time of clear
channel before beginning to key-up the radio to transmit.

The PERSIST/SLOTTIME algorithm helps avoid packet collisions by randomizing the
wait time before transmitting. By using this random timing, it is less likely that any two
TALONs will transmit at the same time, causing a packet collision. When a TALON has
a packet to transmit and detects that the channel is clear, it will wait SLOTTIME (times
10 ms), and generate a random number. If resulting number is smaller than the number
specified by the setting of PERSIST, the packet will be transmitted. If the number is
larger, it will wait another SLOTTIME and then generate another random number and
again decide whether to transmit or not.

When using PERSIST/SLOTTIME, DWAIT should be set to 0, since both will be used if
specified.

8.10 FRACK (Frame Acknowledgment Time)

If the TALON expects an acknowledgment of a packet it has sent, it will wait FRACK
seconds for the acknowledgment. If the acknowledgment is not received it will either
send a poll or retransmit the packet, depending on the setting of AX25L2V2. When digis
are used, extra time is allowed for each transmission using the following equation:

FRACK * ((2 * n) + 1) s

where n is the number of digipeaters and s is the SI symbol for seconds. The length of the
packet transmitted (determined by PACLEN and MAXFRAME) also needs to be taken
into account when deciding how to set FRACK. Longer packets (and more of them)

Page 30 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

require more time to be transmitted, more time to be repeated by the digipeater, and so on
down the line. The FRACK timer begins when the packet has been sent and is suspended
when data carrier from the radio is present, or when your station is transmitting.

8.11 Retries in AX.25 Level 2, Version 1 vs. Version 2

The way retries are accomplished depends on AX25L2V2 being OFF or ON. If a packet
is transmitted to a connected station, and an acknowledgement is not received back, the
entire packet is retransmitted (with the same frame number) up to the number of tries
specified by the RETRIES command, until an acknowledgement is received. If
acknowledgement is still not received, a disconnect sequence is started, up to the number
of RETRIES again. If there is still no response from the other station, the
unacknowledged packet is discarded. In level 1 type responses, single pairs of angle
brackets are used (such as <rr0>).

Under version 2 (AX25L2V2 ON), when an acknowledgement has not been returned, a
POLL only is sent (not the entire packet), up to the number of times specified by
RETRIES. In level 2 type responses, two pairs of angle brackets are use (such as
<<rr0>>).

8.12 Convers Mode vs. Transparent Mode

In the Convers Mode special control characters are still recognized. They are used to edit
typed data before transmitting it, to pass through special characters as data to another
station, or to cause a packet to be transmitted.

Transparent Mode was designed for sending files, whether ASCII data files or program
files. Special characters (other than TRFLOW and TXFLOW, when ON) have no
meaning to the TNC in transparent mode, they are just data characters to be put in a
packet and sent to the radio.

In Transparent Mode, the PACTIME command defines when packets are transmitted.
There is no MONITOR function while in TRANSPARENT mode. Only data from a
connected station can be received.

8.12.1 Exiting Transparent Mode

Since Transparent Mode allows the sending of all characters, only a special sequence of
characters or a modem break will exit Transparent Mode. The command called
CMDTIME sets a timing of character entry that will allow the use of the COMMAND
character in the special character sequence. Three COMMAND (<Ctrl+C>) characters
must be entered within CMDTIME of each other, with at least one CMDTIME before
and after the special sequence.

Some terminal programs can send a MODEM BREAK signal, which toggles the TXD
line for a specific period of time that is longer than a standard character bit time. This will

Page 31 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

also cause the TNC to exit TRANSPARENT mode, as long as its command BREAK has
not been set to OFF.

8.13 Flow Control

Both the computer and the TALON have fixed amounts of input (and output) buffer
space. Flow control prevents the loss of data in communication between the computer
and a TALON. If one of the devices has a nearly full input buffer, it can signal the other
device to stop sending data until it has been able to process the data it has already
received.

8.13.1 Software Flow Control

Software flow control uses special characters, as defined by the commands XOFF, XON,
STOP, and START, which are inserted into data on the TXD and RXD lines between the
computer and TNC. One of the devices will send a <Ctrl+S> to signal the other device to
stop sending data and a <Ctrl+Q> to signal that it can resume sending data. Software
flow control can be disabled, by setting the command XFLOW to OFF. The commands
TRFLOW and TXFLOW are used to enable software flow control in TRANSPARENT
mode.

8.13.2 Hardware Flow Control

Hardware flow control uses the RTS and CTS lines in the RS-232 cable. The TALON
will de-activate the CTS line to the computer, to signal it to stop sending data. The
computer will de-activate the RTS line to signal the TALON to stop sending data.

8.14 Remote Access

The commands of the TALON can be accessed or changed remotely from another
TALON, as long as its commands MYREMOTE and RTEXT have been set, and remote
access has been granted. MYREMOTE defines the callsign or name for the remote access
feature, and RTEXT is a password character string.

In a local TALON, command it to connect to the MYREMOTE callsign in the remote
TALON. That unit will respond to the connect request, and will present three lines of six
numbers per line. Pick one of the lines, and enter the characters at the positions indicated
in the line, as entered in RTEXT.

As a simple example, enter the command RTEXT aBcD. Since there are only 4
characters in the line, the numbers returned in the three lines of six numbers, in response
to a connect request to the MYREMOTE, will only be 1 to 4, such as:

1 1 3 2 4 2
2 1 4 4 3 1
4 3 1 2 4 1

Page 32 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Selecting the first line, the return entry would be:

aacBDB

Upper and lower case characters must be entered exactly the same as they were in
RTEXT, numbers and spaces also count as a character. Up to 128 characters can be
entered in the RTEXT string.

When remote command access has been granted, a prompt: (instead of cmd:) will be
returned, and commands to the remote TALON can then be sent. Any command that
causes a reset to occur, will cause the connection in the remote TALON to be lost, the
same as when cycling its power off and back on, leaving the local TALON still thinking
it is connected to that remote station. Enabling the CHECK command will cause the
TALON to check for a lost link, and will reset that stream when the connection is lost.

Proper care should be used when changing commands remotely, as some commands can
cause that remote TALON, to stop communicating completely.

If three password attempts are made and failed when linked to the MYREMOTE callsign
in a remote unit, that unit will disconnect and will not respond to connect requests to the
MYREMOTE callsign for 15 minutes.

There is a limitation on the amount of data that can be returned from the remote TALON
while using its remote access, so some commands will not fully display their response. In
response to the command DISPLAY, which is a large amount of return data, only about
the first 300 characters of the full display listing will be returned. But the setting of any
single command can be displayed in its entirety.

When finishing a remote access session, send the command to the remote TNC:

DISC MYREMOTE

The remote TALON will then send a disconnect packet back to the local TNC. The local
TALON can also be commanded to disconnect from the remote, by returning it to its
command prompt and entering the DISC command.

9 PROTOCOL DESCRIPTIONS

9.1 Terminal Mode

Terminal mode is the text-based command interface that allows operation and
configuration of communication with the TALON from a terminal program or “dumb”
terminal unit.

9.2 Host Mode

Page 33 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

9.2.1 Host Mode Description

The HOST interface mode provides a way of having more control of the TALON. A
specially written program, that communicates with the TALON in a “framed” data mode,
can make operation easier and with more functionality than when using a simple terminal
program or “dumb” terminal. This allows sending commands and receiving command
responses, communicating over the radio in two modes at once (connected and monitored
packets.)

Each data frame has a header, which indicates the frame type (command, data, etc), and
sent or received data. The TALON retains all of its commands and functions in Host
mode.

Host mode uses Hardware flow control only, and requires that the serial cable that
connects the TALON to the computer include the RTS and CTS lines (as well as TXD,
RXD, and signal ground).

9.2.2 Exiting Host mode

If a Host mode program has been used to operate the TALON, it may leave the TALON
in Host mode when it exits. If a standard terminal program is then used (set to the same
interface baud) to communicate with the TALON, instead of a “sign-on” message, some
characters and SØØ will be displayed. This is the Host mode current-status message.

The Host mode program should have an option to return the TNC to COMMAND or
TERMINAL mode, when that program exits. If the program is configured to do this,
other “standard” terminal programs can then be used.

If the terminal program allows entry of high-numbered ASCII characters, a sequence of
characters can be sent to exit Host mode so the terminal program can then be used. First,
make sure the terminal program is set to the proper interface baud rate. Then, send a
FEND (frame-end) character (ASCII code 192, or Hexadecimal 0xC0), then the letter q
(upper or lower case is ok), and finally another FEND character. A FEND character can
be entered manually, by pressing and holding the ALT key, entering 192 from the
number key pad on the right side of the keyboard (or in Hyperterm™ under Windows™,
holding the ALT key and entering 0192), and then releasing the ALT key.

A small plain-text file (called EXITHOST.TXT), containing these characters can be
found on the CD accompanying the TALON. Again, make sure that the terminal program
is set to the correct interface baud rate. Then send the text file containing the exit
sequence characters (as an ASCII or PLAIN TEXT file) to the TALON.

The TALON will exit Host Mode, will return to TERMINAL interface mode, and will
display its usual “sign-on” message.

Page 34 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

9.3 KISS Mode

9.3.1 KISS Mode Description

KISS mode is also a “framed” data mode, similar to HOST. However, when in KISS
mode the TALON becomes just a packet assembler/disassembler (PAD).

In the KISS Mode, the TALON simply passes all received data to the computer in a KISS
frame, and the computer program is responsible for all processing of that data, including
decisions concerning routing, Digipeating, and other control decisions. To transmit data,
again, the program is responsible for processing data to send in a packet and enclosing
that data in a KISS frame to be sent to the TALON. (References for KISS mode are at
end of this section)

A computer program can send any type of data (such as TCP/IP, or any other protocol)
enclosed in AX.25 packets, and sent to the TALON in KISS frames.

Very few of the TALON’s commands (and none of its other functions), are available
when it is in KISS mode. The operating functions that are available depend solely on the
computer program used.

The TALON converts the packets of synchronous data being received from the radio link
into packets of asynchronous data to be passed to the computer over the serial port, and
converts the packets of asynchronous data from the computer into the synchronous
format suitable for radio transmission. The TALON retains the responsibility of
determining proper timing for channel access.

To place the TALON in KISS Mode, at the command prompt (cmd:), type INTFACE
KISS and ENTER. Then, send a RESET command, or cycle power (off/on) to the
TALON.

The TALON will remain in KISS interface mode, until it receives the KISS exit code, or
it has been hard reset.

9.3.2 Exiting KISS mode

The TCP/IP program should include the command to EXIT KISS mode in the TALON.
See that programs documentation for the proper command.

To enter the EXIT KISS command manually (from a regular terminal program), send a
three character sequence which includes a FEND (frame-end) character (ASCII code 192
or Hexadecimal 0xC0), FF (ASCII code 255), then another FEND character. A FEND
character can be entered manually, by pressing and holding the ALT key, entering 192
from the number key pad on the right side of the keyboard, and then releasing the ALT
key. The ASCII code 255 can be entered by pressing and holding the ALT key, entering

Page 35 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

255 from the number key pad on the right side of the keyboard, and then releasing the
ALT key.

A small plain-text file (called EXITKISS.TXT), containing these characters can be found
on the CD accompanying the TALON. Again, make sure that the terminal program is set
to the correct interface baud rate. Then send the text file containing the exit sequence
characters (as an ASCII or PLAIN TEXT file) to the TALON.

The TALON will exit KISS Mode, will return to TERMINAL interface mode, and will
display its “sign-on” message.

Otherwise, perform a HARD RESET. This will reset all commands to their factory
default settings, and allow the TALON to be re-initialized as a new unit.

9.4 Transparent Unproto Packet (TUP) Mode

9.4.1 TUP Mode Description

The TUP mode protocol utilizes the Unproto mode of the AX.25 protocol, allowing
digipeaters (VIA path specified with UNPROTO command) to be used in order to
effectively extend the range of a radio data system beyond simplex distance. This
protocol uses the standard AX.25 CRC-16 error checking to provide a high degree of data
integrity. Data is sent and received in a totally transparent fashion, allowing all ASCII
characters to be utilized (hex 00 through hex FF). I.Radio transmission is based on the
PACTIME AFTER parameter setting of the modem, the setting of the carrier detect
method, and the settings of the slot and persist channel access algorithm. Any data that is
received by the modem via the radio is output to the serial port only if it contains no
detectable errors. The received data will be exactly the same as the data that was sent to
the input serial port of the transmitting mode, without any address headers or added
formatting of the data. The modem is capable of selectively filtering monitored data from
or to different modem addresses using the BUDLIST command.

If digipeaters must be used to extend the range of the system, the information frame sent
by any modems in the system will be output to the serial ports of the receiving modems
only once, regardless of how many times it was received correctly. Also, data sent by any
modem will not be decoded by itself when the data is digipeated. The TUP mode protocol
provides an automatic "Time to Live" timer that inhibits any modem from transmitting or
receiving additional data until sufficient time has expired to allow in-progress data to
travel through all the digipeaters specified in the UNPROTO field of the originating
modem. Since the time for a given packet to travel the entire UNPROTO path may vary
due to the presence of other signals or noise, TUPTIME is used to impose an additional
delay time, if needed, during which each modem will be inhibited from decoding or
transmitting new data. This setting can be determined experimentally. It is important to
note that TUPTIME applies only to the receiving modems and should be set to the same
value at all sites. It is the responsibility of the host system to insure that additional data is
not transmitted until sufficient time has elapsed to allow data to travel to the last

Page 36 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

digipeater and the response, if any, to travel back to the host. Note that the automatic
"Time to Live" timer and the TUPTIME timer are only in effect if packets are being
digipeated.

9.4.2 TUP Mode Operation

9.4.2.1 Commands Used

Basic TUP Operation involves just a few commands:

MYCALL - The MYCALL command determines the MODEM address. This must be
entered after the autobaud routine has detected an asterisk (*).

PACTIME - The PACTIME parameter determines how long the modem will wait after
receiving data to be transmitted from the DTE before beginning the radio key-up
sequence. Normally, this parameter should be set to AFTER 1 (100 ms) in order to
minimize "dead air" time on the system.

PACLEN - PACLEN sets the maximum size of the data packet(s). Most applications do
not require large amounts of data to be transferred so the default value (128) will
probably be satisfactory, allowing packets up to 128 bytes. If the amount of data to be
sent exceeds the PACLEN parameter setting, the transmission will be composed of
multiple packets containing the data.

PERSIST and SLOTTIME - These parameters determine how aggressively the modem
will attempt to access a multi-user channel based on carrier detect. See KPC-series
manual for a full explanation of these parameters.

9.4.2.2 Entering TUP Mode

Use the INTFACE command to begin TUP operation. Set the INTFACE command to
TUP:

cmd:INTFACE TUP <cr>

and turn the unit off and then back on.

9.4.2.3 Exiting TUP Mode

If you want to exit the TUP mode to "fine tune" parameter settings (or for any other
reason), the Command mode of the modem can be regained by using the transparent data
escape sequence, i.e., by sending a series of three control-Cs (unless a different control
character for COMMAND has been defined). (See TRANS command in Commands
section.

9.5 Poll Mode

Page 37 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

9.5.1 Poll Mode Protocol Description

The POLL mode is generally used in system applications that implement a polled­response protocol between a central site (Control Site) and one or more remote locations
(Remote Site). The POLL mode is similar to the TUP mode since it uses a data
transparent broadcast mode and a packet protocol with CRC-16 error checking to insure
the integrity of the received data. All ASCII characters (hex 00 through FF) can be
transmitted and received. The POLL mode differs from TUP mode by allowing an
application program to address specific locations without changing any modem
parameters. All data sent by the application program at the central sit must begin with the
address (POLLID) of the intended remote modem. When any remote modem receives
data from the radio, the data is checked for errors and the received POLLID is compared
with its own POLLID. If they match, the POLLID is stripped and the data that follows is
sent to the serial port. All data received by the central site from the remote location will
arrive with the POLLID of the remote site automatically attached to the beginning of the
data.

It is the responsibility of the application program to (1) address data to be sent to the
remote sites, (2) determine if the data was received, and (3) recognize responses that
contain the remote site's POLLID and data. Digipeating is not allowed

9.5.2 Poll Mode Operation

9.5.2.1 Commands Used

Each modem is set up differently depending upon whether it is to be a Control modem or
a Remote modem.

9.5.2.1.1 Control Site

Control Site Configuration - The POLLID command in the Control modem must be set
to 0000 and the INTFACE command must be set to POLL. (See "Entering POLL Mode"
below.)

Control Site Transmit Format - All data sent to the Control modem via the RS-232
serial port must begin with a POLLID (four-digit remote address between 0001-9999)
and be followed immediately by the poll data. The data sent by the application to the
Control modem must contain less than PACLEN bytes. If the poll data contains more
characters than allowed by the setting of the PACLEN command, the data will be
fragmented and multiple packets will be formed and transmitted by the modem. These
additional packets will contain only the balance of the data received by the modem. Since
these packets do not begin with a POLLID, they will be ignored by all Remote modems.

Page 38 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Control Site Receive Format - All Remote transmissions received by the Control
modem shall consist of the Remote POLLID followed immediately by the Remote data.
Both POLLID and data will be sent to the control DTE via the RS-232 port.

9.5.2.1.2 Remote Site

Remote Site Configuration - The POLLID command in each of the Remote modems
must be set to a different number between 0001 and 9999. This assures that data is
received by just one remote device.

The INTFACE command in each modem must be set to POLL. (See "Entering POLL
Mode" below.)

Remote Site Transmit Format - Remote sites generally do not have much computing
capacity. Therefore, the transmitted format of the data is, of necessity, straightforward.
All data received via the serial port will be formed into packets and transmitted with the
address (POLLID) attached to the beginning of each data packet.

Remote Site Receive Format - All data received by the Remote via the radio is first
examined for errors using a CRC-16 error-checking algorithm. Data packets that contain
errors are discarded. If the data contains no errors, it is then checked for a match of the
received POLLID and its own POLLID. If there is not a match, the data is discarded. If
there is a match, the POLLID is stripped and the raw data is passed to the RS-232 serial
port for processing. The received data format will be exactly the same as the data sent to
the Control Modem by the application program.

The CONMODE parameter affects when data will be sent in Poll Mode.

If CONMODE is set to CONYERS (default), data will be transmitted when any of the
following conditions is met:

The SENDPAC character is received by the modem. The default SENDPAC character is
a carriage return and can be changed to suit an existing application. The SENDPAC
character can be either stripped or appended to the data by setting the CR command ON
to append, or OFF to strip.

PACLEN is exceeded. CAUTION: MASTER (Control Site) operation will be unusable if

PACLEN is exceeded since each packet of data sent MUST begin with a Slave (Remote
Site) POLLID (0001-9999). Remote transmission may exceed the setting of PACLEN

since each packet transmitted from the Remote will contain the proper POLLID. If
fragmentation of data occurs, the application program is responsible for reconstructing
the data. PACLEN determines the maximum size of data packets (default 128 characters).
Normally, the amount of data to be transmitted will be considerably less than this.

CPACTIME is on and PACTIME expires. If CPACTIME is ON, data will be periodically
transmitted based on PACTIME timeout.

Page 39 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

If CONMODE is set to TRANS, data will be transmitted when:

PACLEN is exceeded, or

PACTIME expires.

9.5.2.1.3 Suggested Settings

Usually, the CONMODE command is set to TRANS and the PACTIME command is set
to AFTER 1. The CONMODE TRANS command makes the modem data transparent to
the Remote device. The PACTIME AFTER 1 command allows the modem to transmit
the data received via the serial port with as little delay as possible. This speeds up the
response time of the system by reducing "dead-air" time.

It is also recommended to set the PACLEN command to zero. This allows the modem to
send a single packet of data to the radio of any size between 1 and the maximum of 256
characters. If the response data from the remote contains more characters than the
PACLEN command allows, the data will be transmitted in multiple packets with the
Remote POLLID automatically attached to the beginning of each data packet. In such a
case, it is the responsibility of the Control Application Program to reassemble the data.

CAUTION: Allowing the Control Site application to send more data than that permitted
by the PACLEN command is the most common cause of failure using the POLL mode.
BE ABSOLUTELY SURE THAT CONTROL SITE TRANSMISSIONS NEVER
EXCEED THE PACLEN LIMIT!

9.5.2.2 Entering POLL Mode

When you have entered the POLLID of the unit and made any desired changes from the
default settings in the parameters, use the INTFACE command to begin POLL operation.
Set the INTFACE command to POLL:

cmd:INTFACE POLL <cr>

and turn the unit off and then back on.

9.5.2.3 Exiting POLL Mode

If you want to exit POLL mode to "fine tune" parameter settings (or for any other
reasons), the command mode of the modem can be regained as follows:

If CONMODE = CONV

Enter: 0000QUIT<cr> (NOTE: MUST BE IN UPPER CASE)

Page 40 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

If CONMODE = TRANS

Use the transparent data escape sequence, i.e.; send a series of three control-Cs (unless a
different control character has been defined). (See TRANS command in the Reference
Manual).

9.6 Line Substitution (LINE SUB) Mode

9.6.1 LINE SUB Mode Protocol Description

The LSUB mode of operation provides a method of transmitting-and receiving raw
ASCII data via a radio. Data is sent and received in a totally transparent fashion, allowing
all ASCII characters to be utilized (hex 00 through hex FF). There is no addressing, error­detection or automatic retransmission of the data. When the receiving modem detects the
proper Start-of-Data sequence generated by the transmitting modem, it will output the
data that follows to its serial port. At the end of the received data there is an End-of-Data
sequence that permits the receiving modem to recognize the end of the data and quit
translating. Since the protocol constitutes a very small portion of the transmission, the
effective data throughput is very nearly that of the radio bit rate.

9.6.2 LSUB Mode Operation

9.6.2.1 Commands Used

PACTIME - The PACTIME parameter determines how long the modem will wait after
receiving data to be transmitted from the DTE before beginning the radio key-up
sequence. Normally, this parameter should be set to AFTER 1 (100 ms.) in order to
minimize "dead-air" time on the system.

PERSIST and SLOTTIME - These parameters determine how aggressively the modem
will attempt to access a multi-user channel based on carrier detect. See KPC-series
manual for a full explanation of these parameters.

9.6.2.2 Entering LSUB Mode

When you have made any desired changes from the default settings for the above
parameters, use the INTFACE command to begin LSUB operation. Set the INTFACE
command to LINESUB:

cmd:INTFACE LINESUB <cr>

and turn the unit off and then back on. Be aware that there is no data flow control.

9.6.2.3 Exiting LSUB Mode

Page 41 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

If you want to exit LSUB mode to "fine tune" parameter settings (or for any other
reason), the Command mode of the modem can be regained by using the transparent data
escape sequence, i.e., by sending a series of three control-Cs (unless a different control
character has been defined). (See TRANS command in the Reference Manual).

9.7 Mode Capabilities Matrix

Below is a summation of the different modes in table format.

Mode

Selective

Addressing

Connect

Links

Error

Detection

Error

Correction

Digipeating

Binary

Transfer

Terminal



1

Host



1
KISS *
POLL

 

TUP

  

LSUB



Note: All of these functions are with the modem IC FEC not being used.
*—Depends on capability of computer program.
1—When in TRANSPARENT mode.

10 CONFIGURATION

Following are examples of programming the TALON UDC for different types of
applications. Before programming the unit do the following preliminary setup:

• Connect the ANT port to a 50  RF dummy load of adequate power handling

capability, a service monitor or power meter, or an antenna

• Connect the Serial I/O port to a PC or terminal with an RS232 straight through cable,

not a null modem cable. The unit is considered DCE

• If there is a GPS antenna connector, connect a GPS antenna

• On the PC or terminal open a communications program, such as HyperTerminal™

found in Windows™. Set communications for the correct COM port number,
typically COM1, COM2, COM3, or COM4; baud for minimum of 1200 to maximum
of 19200; no parity; 8 data bits; and 1 stop bit. Baud should be set to rate intended to
be used in application

• Apply dc power to the unit

• Unit will come up in ABAUD (autobaud) mode. Push the asterisk key

• Unit will request call sign (MYCALL)

Enter your assigned callsign and SSID (number from 0 to 8191).

• The VDT will display the sign on message

Page 42 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Note: Issue the PERM command to store the changes you have entered. You should do
this after each entry so that information is not lost if the unit loses power or is somehow
reset.

Note: See TALON COMMAND SET section for explanation of commands.

10.1 Automatic Vehicle Location (AVL) and Asset Tracking

10.1.1 AVL Used Without a Terminal

Set gb (GBEACON) parameters.

EVERY hh:mm:ss for interval between beacons.
OR enter number of meters to travel before next beacon.

Set gt (GTEXT) for optional text mixed with $variables$.

10.1.2 AVL Used With a Terminal (For Text)

Set gb (GBEACON) parameters.

EVERY hh:mm:ss for interval between beacons.
OR enter number of meters to travel before next beacon.

Set gt (GTEXT) for optional text mixed with $variables$.

To send and receive text messages you must determine and set up the system for
connected or packet broadcast mode. See CONNECT, CONMODE, LLIST and
UNPROTO commands for starters.

10.1.3 AVL Receive

Set gt (GTEXT) according to your needs. See GTEXT command.

Set PC system in accordance with information and data needed.

10.2 Base Station Operation

Setup for transmit and receive as needed.

If your base station is used in a service requiring station ID, set cw (CWID) EVERY to
interval required. See FCC Part 90.425 Station identification for details. The unit will
send an FSK modulated tone of 600 Hz at approximately 40 % deviation of normal signal
deviation at approximately 20 WPM using the call sign you enter under MYCALL. If
there is something else you want to ID by enter it under cwidt (CWIDTEXT).

Page 43 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

10.3 Data/Telemetry/SCADA/Text

For sending and receiving information (data, text) over the Serial I/O (RS232) port see
the Modes section.

For SCADA probably just need transparent data, which several of the available modes
can do:

LSUB—point to point, no addressing, broadcast, no acknowledgment of data.
TUP—broadcast data, Packet headers, and can be digipeated.
Terminal Mode—can have connected transparent link.

10.4 Digipeating

If your system needs a repeater function see the Modes section and the DIGIPEAT
command.

11 INSTALLATION

Refer all installation to qualified personnel.

11.1 Dc Power

Make a power cable assembly using the supplied two-terminal connector, P1, some wire
of sufficient size and length, and mating connection to your dc power source. It is
recommended that a fuse with a rating of 3 A be used at the dc power source end of the
power cable assembly.

A two-terminal jack, A2J6, is located on the front panel for dc power input. The unit is
protected from reverse voltage application with a diode, A2D1, and from over current
with an automatic resetting solid state current limiting device, A2RT1. Equipment power
must be supplied by a well-regulated dc power supply capable of the required voltage and
current. For vehicle applications an external filter to reduce ignition noise transients and a
method to absorb load dump conditions is recommended. After-market dc noise filters
are available from automotive electronics supply companies.

The dc power connector, A2J6, is located on the front panel to the far, left side. Pinout is
as follows. Be sure you wire to the correct terminal on the mating connector. Plug P1 in
to A2J6 to make sure.

A2J6 pin out

Terminal Nr Physical Position Description

1 Left terminal + dc voltage
2 Right terminal GND (dc return)

Page 44 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The COMBICON type connector, P1, has straight slot small screwdriver tightening
clamp attachment for the wires. The unit has reverse polarity protection and the wires can
be easily swapped if needed.

The dc power requirement is 8.5 to 15 V dc at less than 3 A. Current demand is larger for
the higher RF power settings. It is suggested to use 18 AWG.

11.2 GPS Antenna

If your unit has a GPS receiver, the GPS antenna transmission line connector, E1P1, is
attached to the GPS connector, A2W1J1 that is on the front panel to the lower, far right
side.

11.3 Serial I/O

The Serial I/O connector, A2J9, near the center of the front panel, is for RS232
communications, normally with a PC. Be sure to use a shielded cable that is properly
terminated. See note in § 4.4 FCC Notice concerning shielded cables. The radio modem
is considered a DCE unit. Use a straight through RS232 cable and not a null modem
cable.

11.4 Antenna

The ANT connector, A1J1, located in the middle lower portion of the front panel, is an N
(female) type for attachment of your transmission line that connects to your antenna.

The antenna (radiating element) shall not be connected to the radio modem directly, as
the RF field could induce EMI in the unit. Space antenna away from unit at least 0.6 m (2
feet).

Refer to § 4.1 RF Exposure for FCC RF human exposure requirements.

11.5 Mounting of Unit

Method of mounting is left to the customer. For best heat dissipation the finned heat sink
on rear of unit should be vertical for natural airflow. Do not exceed the maximum
operating temperature.

An optional mounting kit is available. Please call Kantronics.

11.6 Input/Output

Page 45 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The Input/Output connector, A3J1, at the top left of the front panel, for units with an I/O
CCA, is for analog and discreet inputs and outputs. See § 7 for pinout and connection
details.

11.7 Input/Output Serial I/O

A 2nd serial I/O connector, A3J2, at the top right of the front panel, for units with an I/O
CCA, is for RS232 communications, normally with a PC. Be sure to use a shielded cable
that is properly terminated. See note in § 4.4 FCC Notice concerning shielded cables. The
radio modem is considered a DCE unit. Use a straight through RS232 cable and not a null
modem cable.

12 THEORY OF OPERATION

The TALON UDC units are radio modems utilizing four-level frequency shift keying (4­LFSK) modulation. The assemblies and subassemblies of the unit consist of:

A1–Radio transceiver (XCVR) assembly (A1A1 CCA with connector and cable).

A1A1–Radio XCVR circuit card assembly (CCA), UHF or VHF frequencies.

A2–Controller CCA.

A2A1–Global Positioning System (GPS) receiver (RCVR) CCA or other function.

A3–I/O CCA having sensor inputs and control outputs.

The basic unit consists of A1 and A2 assemblies with the A2A1 GPS RCVR added as an
option. Other configurations consist of the basic unit of A1 and A2, along with an A3 I/O
CCA, with the A2A1 GPS RCVR added as an option or having some other function.

12.1 Ritron’s VHF Radio XCVR, A1A1

12.1.1 Receiver

12.1.1.1 RF Amplifier and Band-pass Filters

The incoming RF signal from the input connector J101 passes backwards through the
transmitter low-pass filter and the electronic T/R switch to a three pole band-pass filter
formed around L102, L103, and L104. This filter is of Cohn type with 1.5 dB insertion
loss and a bandwidth of 30 MHz. This filter is followed by a low noise amplifier stage
formed around Q101. This amplifier has a gain of about 17 dB with a noise figure of 2
dB and serves to amplify the incoming RF signal above the noise of the following stages.
Following this stage is a three-pole Cohn filter formed around L107 through L109. The
characteristics of this filter are identical to that of the first. The two filter sections are

Page 46 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

narrow enough to filter out the spurious responses of the first frequency converter, while
wide enough to support a performance bandwidth of 26 MHz.

12.1.1.2 1st Frequency Converter, 1st IF Filters, and 1st IF Amplifier

IC101 is an active double-balanced frequency converter, which converts the incoming RF
signal to the first intermediate frequency (IF) of 43.65 MHz. This frequency converter
has a gain of 0 dB and a noise figure of 10 dB. Its differential output is matched to the
first IF filter, YF101, by L111, L112, C130, and C140. An IF amplifier based around
Q102 is used to provide gain. Its output drives another IF filter section, YF102, which is
identical to YF101. These two filters serve the double function of filtering out the
spurious responses of the second frequency converter and, with the second IF filter, of
removing signals at the adjacent and further removed channels.

12.1.1.3 2nd IF IC

The output of YF102 drives the mixer internal to IC102. IC102 is a FM IF IC which
contains a frequency converter, high gain limiting IF amplifier, FM discriminator
(detector) and other support circuitry. The frequency converter in IC102 converts the RF
signal at the first IF to the second IF of 450 kHz. The output of the frequency converter
exits the IC and is filtered by the second IF filter, YF103. The output of the filter reenters
the IC and drives the high gain, limiting amplifier. Because the discriminator inside
IC102 is sensitive to amplitude and frequency modulation components, a limiter must
precede it to remove any amplitude modulation. The output of the limiter amplifier
drives the discriminator. The resonator for the discriminator is YF104.

12.1.1.4 Receiver Audio and Carrier Detection

The recovered audio from IC102-9 is filtered and dc shifted by IC103A and associated
components.

Carrier detection is based upon the absolute RF signal level at IC102’s input. IC102 has
circuitry that develops a dc current, which is proportional to the input RF signal level.
Passing this current through a resistor (R123) creates a voltage, which varies from about

0.5 V at no signal input to about 3 V with –70 dBm at the antenna connector.

12.1.1.5 2nd Local Oscillator

To convert signals at the first IF frequency of 43.65 MHz to that of the second IF at a
frequency of 450 kHz, a local oscillator signal at a frequency of 43.2 MHz (43.65 MHz –

0.45 MHz) is used. Tripling the output of the radio’s 14.4-MHz master reference
oscillator, Y101, creates this signal. Transistor Q111 acts as a frequency tripler. Its
associated components are used to bias the transistor at a harmonic rich bias point and to
filter the output such that only the third harmonic remains for use as the 2nd local
oscillator.

Page 47 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

12.1.1.6 VCO and Synthesizer

The synthesizer is responsible for generating the carrier in transmit and the first local
oscillator in receive. A voltage-controlled oscillator (VCO) is an oscillator whose
frequency can be controlled by an external signal. The synthesizer, almost wholly
contained within IC109, divides the VCO frequency by digital dividers and compares the
result with an accurate reference. An error signal, proportional to the frequency error, is
created which is routed to the frequency control input of the VCO. This action locks the
VCO to a frequency, which is equal to the reference frequency multiplied by the divider
number. To set the VCO frequency, different divider numbers can be programmed into
the synthesizer. In most synthesizer designs, the divider must be an integer, which forces
the reference frequency to be equal to the synthesizer step size. The synthesizer IC used
in this radio, however, allows the use of non-integer values for the divider, which in turn
allows the reference frequency to be much higher than normal. This creates a synthesizer
whose output has lower noise, lower spurious levels, and higher switching speeds. The
reference frequency is derived by digitally dividing the frequency of the 14.4-MHz
master oscillator. When locked, the VCO attains the same relative frequency stability as
that of the master oscillator.

The VCO itself is a voltage-follower Hartley oscillator formed around Q107. One of the
elements in the resonant circuit is a varactor diode, CR105, whose capacitance when
reverse biased, varies as a function of the applied voltage. Since the oscillator frequency
is controlled by the resonant circuit, varying the voltage on the varactor diode effects a
change in frequency. To serve as a local oscillator for the first frequency converter, the
VCO operates at a frequency 43.65 MHz above that of the desired receive frequency. In
receive, the VCO’s oscillating frequency range is shifted upward by about 44 MHz by
switching C191, C192, and L122 into the resonant circuit. The VCO has a tuning range
of about 40 MHz when its tuning voltage is varied between 1 and 5 V. To frequency
modulate the VCO for transmit, another varactor diode, CR106, is lightly coupled into
the resonant circuit.

The output of the VCO is amplified to a level of about 0 dBm by Q106. Q110, R171, and
C196 act as a very low-noise power supply filter for the VCO.

12.1.2 Transmitter

12.1.2.1 PA Driver Stages

The output of the VCO buffer drives Q105 through R152. The signal level at this point is
about –10 dBm. Q105 amplifies this signal to about +5 dBm. Q104 further amplifies the
signal to +13 dBm, the level required by the PA module. The supply voltage to these two
stages is switched on in transmit by Q113.

12.1.2.2 PA Module, Low-pass Filter, and T/R Switch

Page 48 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

When driven by +13 dBm, the PA module is capable of producing 6 W or more of power
at the antenna connector. Pin 2 of the module is used for power control. The output
power level can be varied from less than 0.5 W to full power by changing the voltage at
this pin.

To reduce carrier frequency harmonics of the PA module output to acceptable levels, a
low-pass filter is inserted between the module and the antenna connector. This filter is of
elliptic design and formed around L115 and L116, and C169 through C173.

To isolate the PA module from the receiver, an electronic T/R switch is used. The switch
is formed around PIN diodes CR103 and CR104, which are turned on in transmit and are
off in receive. CR104 switches the PA module into and out of the circuit, while CR103
protects and isolates the receiver input when the radio is in transmit.

12.1.3 Miscellaneous Functions

Two on-board regulators are used to provide the 5 V dc used by most of the circuitry in
the radio. IC107 is a low noise, low dropout regulator which provides 5 V to all the
portions of the radio which do not get switched on or off as the radio changes from
transmit to receive. This regulator is enabled by the XCVR-EN (J102-5) input. When
this regulator is not enabled, the radio is essentially powered down. IC108 is an identical
regulator, which supplies voltage to those circuits that are to be powered-up only in
receive. The regulator is enabled through IC106E and F by the RX-EN (J012-4) input.

The transmitter PA module driver stages and the T/R switch are powered by +7.2 V
through Q113. The TX-EN (J102-3) input through delay and sequencing circuitry
formed around IC106, Q112, and Q114 enable Q113. The sequencing circuitry delays
PA turn-on until the driver stages and T/R switches are on, and delays driver stage and
T/R switch shutdown until the PA module has ramped down in power. This prevents
“keyclicks” from abrupt transmitter turn-on and turn-off.

12.2 Ritron’s UHF Radio XCVR, A1A1

12.2.1 Receiver

12.2.1.1 RF Amplifier and Band-pass Filters

The incoming RF signal from the input connector J101 passes backward through the
transmitter low-pass filter and the electronic T/R switch to a two-pole band-pass filter
formed around L101 and L102. This filter is of Cohn type with 1.5 dB insertion loss and
a bandwidth of 25 MHz. This filter is followed by a low noise amplifier stage formed
around Q101. This amplifier has a gain of about 17 dB with a noise figure of 2 dB, and
serves to amplify the incoming RF signal above the noise of the following stages.
Following this stage is a four-pole Cohn filter formed around L103 through L106. This
filter has an insertion loss of 4 dB and a bandwidth of 25 MHz. The two filter sections

Page 49 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

are narrow enough to filter out the spurious responses of the first frequency converter,
while wide enough to support a performance bandwidth of 20 MHz.

12.2.1.2 1st Frequency Converter, 1st IF Filters, and 1st IF Amplifier

IC101 is an active double-balanced frequency converter, which converts the incoming RF
signal to the first IF of 43.65 MHz. This frequency converter has a gain of 0 dB and a
noise figure of 10 dB. Its differential output is matched to the first IF filter, YF101, by
L107, L108, C128, and C137. An IF amplifier based around Q102 is used to provide
gain. Its output drives another IF filter section, YF102, which is identical to YF101.
These two filters serve the double function of filtering out the spurious responses of the
second frequency converter and, with the second IF filter, of removing signals at the
adjacent and further removed channels.

12.2.1.3 2nd IF IC

The output of YF102 drives the frequency converter internal to IC102. IC102 is a FM IF
IC which contains a frequency converter, high gain limiting IF amplifier, FM
discriminator (detector) and other support circuitry. The frequency converter in IC102
converts the RF signal at the first IF to the second IF of 450 kHz. The output of the
frequency converter exits the IC and is filtered by the second IF filter, YF103. The
output of the filter reenters the IC and drives the high gain, limiting amplifier. Because
the discriminator inside IC102 is sensitive to amplitude and frequency modulation
components, a limiter must precede it to remove any amplitude modulation. In addition,
the noise-based carrier detection system available with this product requires that the RF
signal at the discriminator stay constant in amplitude as the RF input signal level varies.
The output of the limiter amplifier drives the discriminator. The resonator for the
discriminator is YF104.

12.2.1.4 Receiver Audio and Carrier Detection

The recovered audio from IC102-9 is filtered and dc shifted by IC103A and associated
components.

Carrier detection is based upon the absolute RF signal level at IC102’s input. IC102 has
circuitry that develops a dc current, which is proportional to the input RF signal level.
Passing this current through a resistor (R115) creates a voltage, which varies from about

0.5 V at no signal input to about 3 V with –70 dBm at the antenna connector.

12.2.1.5 2nd Local Oscillator

To convert signals at the first IF frequency of 43.65 MHz to that of the second IF at a
frequency of 450 kHz, a local oscillator signal at a frequency of 43.2 MHz (43.65 MHz –

0.45 MHz) is used. Tripling the output of the radio’s 14.4-MHz master reference
oscillator, Y101, creates this signal. Transistor Q112 acts as a frequency tripler. Its
associated components are used to bias the transistor at a harmonic rich bias point and to

Page 50 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

filter the output such that only the third harmonic remains for use as the 2nd local
oscillator.

12.2.1.6 VCO and Synthesizer

The synthesizer is responsible for generating the carrier in transmit and the first local
oscillator in receive. A voltage-controlled oscillator (VCO) is an oscillator whose
frequency can be controlled by an external signal. The synthesizer, almost wholly
contained within IC108, divides the VCO frequency by digital dividers and compares the
result with an accurate reference. An error signal, proportional to the frequency error is
created, which is routed to the frequency control input of the VCO. This action locks the
VCO to a frequency, which is equal to the reference frequency multiplied by the divider
number. To set the VCO frequency, different divider numbers can be programmed into
the synthesizer. In most synthesizer designs, the divider must be an integer, programmed
into the synthesizer. In most synthesizer designs, the divider must be an integer, which
forces the reference frequency to be equal to the synthesizer step size. The synthesizer IC
used in this radio, however, allows the use of non-integer values for the divider, which in
turn allows the reference frequency to be much higher than normal. This creates a
synthesizer whose output has lower noise, lower spurious levels, and higher switching
speeds. The reference frequency is derived by digitally dividing the frequency of the

14.4-MHz master oscillator. When locked, the VCO attains the same relative frequency
stability as that of the master oscillator.

The VCO itself is a voltage-follower Colpitts oscillator formed around Q108. One of the
elements in the resonant circuit is a varactor diode, CR106, whose capacitance, when
reverse-biased, varies as a function of the applied voltage. Since the oscillator frequency
is controlled by the resonant circuit, varying the voltage on the varactor diode effects a
change in frequency. To serve as a local oscillator for the first frequency converter, the
VCO operates at a frequency 43.65 MHz below that of the desired receive frequency. In
transmit, the VCO’s oscillating frequency range is shifted upward by about 44 MHz by
switching C190 and L115 into the resonant circuit. The VCO has a tuning range of about
30 MHz when its tuning voltage is varied between 1 and 5 V. To frequency modulate the
VCO for transmit, another varactor diode, CR105, is lightly coupled into the resonant
circuit.

Q107 and Q106 amplify the output of the VCO to a level of about 0 dBm. Q111, R172,
and C196 act as a very low-noise power supply filter for the VCO.

12.2.2 Transmitter

12.2.2.1 PA Driver Stages

The output of the last VCO buffer drives Q105 through R151. The signal level at this
point is about –10 dBm. Q105 amplifies this signal to about +5 dBm. Q104 further
amplifies the signal to +17 dBm, the level required by the PA module. The supply
voltage to these two stages is switched on in transmit by Q113.

Page 51 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

12.2.2.2 PA Module, Low-pass Filter, and T/R Switch

When driven by +17 dBm, the PA module is capable of producing 6 W or more of power
at the antenna connector. Pin 2 of the module is used for power control. The output
power level can be varied from less than 0.5 W to full power by changing the voltage at
this pin.

To reduce carrier frequency harmonics of the PA module output to acceptable levels, a
low-pass filter is inserted between the module and the antenna connector. This filter is of
elliptic design and formed around a buried stripline transmission line and C164, C165,
and C166.

To isolate the PA module from the receiver, an electronic T/R switch is used. The switch
is formed around PIN diodes CR101 and CR104, which are turned on in transmit and are
off in receive. CR104 switches the PA module into and out of the circuit, while CR101
protects and isolates the receiver input when the radio is in transmit.

12.2.3 Miscellaneous Functions

Two on-board regulators are used to provide the 5 V dc used by most of the circuitry in
the radio. IC106 is a low noise, low dropout regulator which provides 5 V to all the
portions of the radio which do not get switched on or off as the radio changes from
transmit to receive. This regulator is enabled by the XCVR-EN (J102-5) input. When
this regulator is not enabled, the radio is essentially powered down. IC107 is an identical
regulator, which supplies voltage to those circuits which are to be powered-up only in
receive. The regulator is enabled through IC105E and F by the RX-EN (J102-4) input.

The transmitter PA module driver stages and the T/R switch are powered by +7.2 V
through Q113. Q113 is enabled by the TX-EN (J102-3) input, through delay and
sequencing circuitry formed around IC105, Q115, and Q114. The sequencing circuitry
delays PA turn-on until the driver stages and T/R switches are on, and delays driver stage
and T/R switch shutdown until the PA module has ramped down in power. This prevents
“keyclicks” from abrupt transmitter turn-on and turn-off.

12.3 Controller CCA, A2

The Controller CCA uses a Motorola microprocessor (µP), U1, to process and control

information for the radio modem. The in circuit serial programming (ICSP) connector,

J5, is used only at the factory to install the boot loader program. The µP has flash

memory that can be updated through the Serial I/O port, J9.

The µP, U1, communicates with the Serial I/O port, J9, via RS232 transceiver, U5. The
Serial I/O port, J9, is used to communicate with the µP, U1, via a RS232 cable to a PC

running any communications program, such as HyperTerminal™ in Windows™.

Page 52 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

If J8 is jumped the system will come up in the Maintenance Program mode, when turned
on, where the frequency of operation is set and various transmit and receive levels are
adjusted and set. If J8 is not jumped, then the system will come up in its Operation
mode.

The µP, U1, communicates with a four-level frequency shift keying (4-LFSK) modem

IC, U3. The modem IC, U3, provides the four-level coded signal to FSK modulate the
radio transceiver transmitter and decode the demodulated FSK signal from the radio
transceiver receiver.

Because of dc offsets and to minimize bit error rate the TX and RX paths are dc coupled.

The four-level coded signal emanates from the modem IC at terminal 20, U3-20, at an
amplitude of 1 V pp and a dc offset of Vcc/2 ( 2.50 V dc). The signal is sent through a
RC low-pass filter, R3 and C13, to the input of buffer amplifier AR2D, an op-amp
voltage follower. The signal at the output of the buffer amplifier then goes to the top of
the DEVIATION setting software controlled potentiometer, U2C.

VBIAS from the modem IC is made available at terminal 21, U3-21, that is equal to
Vcc/2 ( 2.50 V dc) that the modem IC uses internally. This dc voltage is buffered by
AR1A and then goes to the bottom of DEVIATION setting software controlled
potentiometer U2C and to R8, one of two inputs to the inverting summing junction of
AR1C. The FREQuency OFFSET software controlled potentiometer, U2F, adds a dc
offset to the AR1C op-amp stage. The output of AR1C can be set for the proper signal
level to drive the transmitter to the proper deviation. The dc offset level of 2.50 V affects
the frequency of the transmitted and received signal because this voltage goes directly to
the master oscillator on the radio transceiver via terminal 7 of the radio interface
connector, P1-7.

Transmitter RF output power level is set with software controlled potentiometer U2G.
This dc level is buffered with AR1D.

For receiving, the RSSI signal from the radio transceiver is first looked at to see if there is
a signal of sufficient amplitude. The RSSI signal at P1-13 is sent to a times two non­inverting op-amp amplifier, AR2B, and then to AR2A that acts as a voltage comparator.
The RSSI ADJUST software controlled potentiometer U2E is adjusted twice.
Adjustment is done one time for a turn on level and a second time for a turn off level.
This adds hysteresis so that a good signal of specified level being received will not drop
out if, for some reason, the signal level drops a number of dB. Also the RSSI signal is
looked at before transmitting to determine if there is a signal on the air or not.

The DISC_OUT (discriminator output) signal at P1-14 is sent to RX GAIN software
controlled potentiometer U2D for adjustment of the amplitude. This demodulated four­level signal goes to op-amp AR2C where a dc offset voltage from the RX ADJ 2.5 V
software controlled potentiometer, U2B, is added. The discriminator output signal rides
on a dc offset voltage from the radio transceiver. Adjustment of the RX GAIN

Page 53 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

potentiometer also varies this dc-offset level. Thus there is an interaction of the dc levels
when adjusting the RX GAIN and RX ADJ 2.5 V. The received signal and dc offset at
the modem IC RXFB terminal, U3-23, is adjusted for a 1 V pp signal and a dc offset to
match the VBIAS dc level at U3-21.

Internal temperature is monitored by U4.

There are six LEDs for indications of operation.

DS1 TX Unit is transmitting
DS2 RX There is a carrier on frequency
DS3 A

1

User definable through programming

DS4 A

2

User definable through programming

DS5 A

3

User definable through programming

DS6 PWR Power to the unit is on

To keep digital noise out of the analog circuitry there are separate +5 V supplies for the
analog and digital sections. Voltage regulator VR1 supplies power to the radio
transceiver, the analog circuitry voltage regulator, VR2, and the digital circuitry voltage
regulator, VR3.

12.4 GPS Receiver, A2A1

The GPS receiver system consists of a GPS receiver circuit card assembly and an external
active antenna for reception of GPS signals from the GPS satellites.

The GPS RCVR CCA has a Trimble Lassen SQ GPS RCVR module that is the heart of
the system. IC voltage regulator, VR1, supplies 3.3 V dc to the Trimble GPS RCVR,
RE1, and the level translator, U1. RE1 in turn supplies dc voltage out the RF connector,
RE1J1, to the externally connected Trimble antenna. The GPS signals are brought into
the receiver over the transmission line into this same connector. The GPS information
signals are sent to the microprocessor, on the Controller CCA, through level translator,
U1. Battery backup is provided but is not necessarily needed. The battery backup reduces
the acquisition time if the unit has been off for a period of time.

The A2A1 CCA may have other functions designed in the future.

12.5 Input/Output CCA, A3

The I/O CCA, part number 001-0008-01, has eight analog inputs, four discreet inputs,
four analog outputs, and four discreet outputs as follows:

Page 54 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Nomenclature I/O Description

AI1
AI2
AI3
AI4
AI5
AI6
AI7
AI8

Analog
inputs

0 to 5 V dc, high Z of protection op-amp. Jumper
selectable 249 c, 1-% resistor is included for 2-wire or
3-wire, 0 to 20 mA dc input. Protection op-amp limits
voltage to YP 10-bit A/D converter to 4.950 V.

DI1
DI2
DI3
DI4

Discreet
(digital)
inputs

5 V CMOS logic inputs to YP. Inputs are pulled up to a
high. May be activated (pulled low) with an open
collector BJT, open drain FET, switch, or relay.

AO1
AO2
AO3
AO4

Analog
outputs

0 to 4.995 V dc into minimum 10 kc load.

DO1
DO2
DO3
DO4

Discreet
outputs

Open drain FET, will handle up to 50 V dc and sink up
to 115 mA.

The circuit card assembly also has a D-sub 9 female connector for a 2nd RS232 serial
port. This serial port can be used for diagnostics while the unit is running and the serial
port on the Controller CCA is in use.

Optionally the I/O CCA can be supplied without U1, the RS232 transceiver IC, so that a
GPS Receiver CCA, which uses the 2nd RS232 port, can be installed in the Talon UDC
radio modem unit.

For pinout of the connectors on the I/O CCA see section 7.

13 TALON COMMAND SET

All TALON commands are documented below, in alphabetical order. The underlined
characters in a command’s name show the short-cut version of that command. Required
or optional parameters are shown after the command name, as are allowable ranges of
values, where appropriate.

8BITCONV {ON | OFF}

Page 55 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default ON

This command is used to accommodate terminals that use only 7-bit ASCII characters,
and will not receive (or would be confused by) 8-bit characters. Also, it might be that
your computer is capable of handling 8-bit characters but your communications terminal
program will reject (or be confused or “hung”) by them. In these cases, you’ll need to set
8BITCONV OFF.

When ON, transmission of 8-bit data is allowed in the packet Convers Mode and
Transparent Mode. If you wish to obtain 8-bit data transmission but do not want all the
features of Transparent Mode, set this command to ON. If OFF, the 8th data bit is stripped
(set to 0) for transmission and all data received will have the 8th bit set to 0.

ABAUD [n][,[7|8][,[N|E|O][,1]]] RS232 baud (n = 0,1200,2400,4800,9600,19200)

default 0

The parameter n sets the baud rate used for input and output through the serial RS232
port to the computer. If 0 is used, the TALON will run an autobaud routine upon power­up. This routine looks for an asterisk (*) character from the attached computer to set the
ABAUD parameter.

7|8 selects either 7 or 8 bit data.

N|E|O selects the PARITY (NONE|EVEN|ODD)

1 sets the number of stop bits and is fixed at 1

If you wish to use a different baud rate, or to perform autobaud the next time the unit is
powered up, you must change the ABAUD parameter. If you change the baud rate in
your computer or terminal you should change the baud rate in the TALON first, then
issue the RESET command, then set the new baud rate on your computer. Otherwise a
hard reset will be required to erase the ABAUD setting and reinitialize the TALON to
perform the autobaud routine. (See Hard Reset section.) Note also that a hard reset will
erase ALL stored parameters and return them to factory defaults.

See also: reset, restore

ANALOG

immediate

Entering the ANALOG command returns a string of 8 values, based on the current
voltage readings from 8 A-to-D lines.

Page 56 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

At any given time, each of the 8 A-to-D lines will have a voltage value somewhere in the
range of 0 - 5 V dc. Instead of reporting voltages, the ANALOG command returns a
decimal number in the range of 0 - 255 (or a decimal number in the range specified by the
RANGE command) for each analog input. Each decimal value corresponds to a voltage
input.

The response is in the following form:

AN0/AN1/AN2/AN3/AN4/AN5/AN6/AN7

Data can be manually gathered from a remote site by connecting to MYREMOTE in that
remote unit, gaining access through the password query, and then issuing the ANALOG
command. The TELEMETRY command specifies a regular interval at which to transmit
samples of the ANALOG inputs.

See also: range, telemtry, myremote, rtext

AUTOLF {ON | OFF}

default ON

When ON, a line feed is sent to the terminal after each carriage return. This parameter
should be set ON when overprinting occurs and the terminal being used does not
automatically supply its own linefeed after a carriage return. This command affects only
the data sent to the terminal, not data sent to the radio.
See also: cr, lfadd

AX25L2V2 {ON | OFF}

default ON

When ON, Level 2 Version 2 protocol is implemented and the TALON will
automatically adapt to whichever version the connecting station is using. When OFF,
Level 2 Version 1 is implemented. Set this command to OFF if you need to digipeat
through other units, which do not digipeat version 2 packets. You may also find benefit
from setting this command OFF when using several digipeaters (not nodes) to send
packets, or when conditions are marginal between the two stations involved. (NOTE:
Changing this setting after connecting to another station will have no effect on the current
connection.)

The major difference in V1 and V2 protocol is the method used to handle retries. In the
connected mode, if a packet is sent and not acknowledged, Version 1 will re-send the

Page 57 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

entire packet until it receives an acknowledgment or will disconnect if the RETRY count
is reached. Version 2 will first send a poll, the response to this poll will determine if the
packet was received. It is possible that the ack was collided with and therefore the data
packet does not need to be resent. If the ACK shows that the data packet was not
received, it will be re-transmitted. Each time a poll is answered the TRIES count is reset
to 0. If the RETRY count is reached, version 2 will attempt to re-connect unless RELINK
is OFF. If the re-connect attempt is unsuccessful, then version 2 will issue a disconnect.

See also: relink, retry, tries

BEACON [EVERY | AFTER] n (n = 0 - 255)

default Every 0

The value entered for “n” is the number of minutes (i.e., one-minute intervals) to use with
the beacon command.

A value of 0 turns the beacon OFF. Setting a value greater than 0 activates the beacon
under the conditions specified. If the optional keyword Every is used, a beacon packet
will be sent every n minutes. If set to After, a beacon packet will be sent ONCE after the
specified interval with no channel activity.

The beacon frame consists of the text specified by BTEXT in a packet addressed to
“BEACON”. Beacon messages will be digipeated via any addresses specified in the
UNPROTO command.

See also: btext

BKONDEL {ON | OFF}

default ON

When ON, the sequence backspace-space-backspace is sent to the attached terminal when
a DELETE character is entered. When OFF, the backslash character “\” is sent to the
terminal when the DELETE character is entered.

See also: delete, redisplay

BREAK {ON | OFF}

default OFF

Page 58 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

If BREAK is ON, a modem break from the terminal causes a return to Command Mode
from Converse or Transparent Mode.

See also: COMMAND

BTEXT text (up to 128 characters)

default (blank)

BTEXT specifies the content of the data portion of the beacon packet. Any combination
of characters and spaces may be used with a maximum length of 128.

Entering a single “%” will clear BTEXT.

See also: beacon

BUDLIST [ON|OFF] [NONE | {+|-}call | call1,call2,...]

where call={callsign | {<|>}callsign | callsign{>|<>}callsign}

default OFF NONE

BUDLIST is used to determine which received packets will be monitored. When OFF or
NONE, BUDLIST will allow monitoring of all packets, even if it has callsigns in its list.

The maximum number of callsigns allowed in BUDLIST is 10. Up to 10 callsigns may be
entered at once, using the format shown after the command name, and the new list of
from 1 to 10 callsigns will replace the previous list. The BUDLIST command can be used
to add a single callsign (+callsign), so long as there is room for the new callsign on the
list (if there is not, the TALON responds with “EH?” and returns you to the command
prompt). Similarly, you can remove a single callsign (-callsign) from the list. And to
remove all items from the current list, enter BUDLIST NONE.

BUDLIST can be used in TUP mode to “filter” received packets in remote units, so that
they only “hear” a master or digipeater station.

A callsign entered without a SSID will match any SSID of that callsign. To match a
specific SSID only, enter the callsign with that SSID: for example, callsign-n, where n =
0-8191.

More selective monitoring is enabled when a callsign or two callsigns combined with a
“>” and/or a “<” character are entered. For example, entering “>callsign” will enable
monitoring of packets TO that callsign (assuming BUDLIST is ON). Entering
“<callsign” will enable monitoring of packets from the callsign. Entering
“callsign1>callsign2" will enable monitoring of packets from callsign1 to callsign2. And

Page 59 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

entering ”callsign1<>callsign2" will enable monitoring of all packets between callsign1
to callsign2 and vice-versa.

Note that entering callsign1>callsign2 or callsign1<>callsign2 counts as two of the 10
maximum allowed callsigns.

CANLINE n (n = $00 - $FF)

default $18 <Ctrl+X>

This command defines the cancel-line input editing command character. When in
Convers or Command Mode entering this character will cancel all characters input from
the keyboard back to the last un-PASSed carriage return (unless PACTIME has expired,
CPACTIME is turned on, and you are in Convers Mode).

See also: canpac, cpactime, pass

CANPAC n (n = $00 - $FF)

default $19 <Ctrl+Y>

This command defines the cancel-packet command character. When in the Convers Mode
entering this character will cancel all keyboard input back to the last unpassed
SENDPAC character (unless PACTIME has expired and CPACTIME is turned on).

This character also functions as a cancel-output character in Command Mode. Typing the
cancel-output character a second time re-enables normal output. For example, if you’ve
issued a DISPLAY command, a <Ctrl+Y> will cancel the display and a second one re­enables the cmd: prompt after the next “CR”.

See also: canline, cpactime, sendpac

CHECK n (n = 0 - 255)

default 0

This “timeout” command is used to prevent a “hang-up” in a connected mode when a link
failure occurs as a result of conditions beyond control of the connected stations. The
value entered for “n” is the number of 10 s intervals to wait during “no activity” before
making a periodic check (poll) to determine that a connected state still exists.

If n equals 0 this “timeout” function is disabled. While using Version 1 (AX25L2V2
OFF), a check timeout will initiate a disconnect.

Page 60 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

See also: ax25l2v2, relink, rnrtime

CHFREE EVERY [[hh:]mm:]ss START [[hh:]mm:]ss [FOR [[hh:]mm:]ss]

default EVERY 00:00:00

When slotted beaconing is used for GPS, CHFREE can specify when the channel will be
free for other transmissions.

See also: GBEACON

CMDTIME n (n = 0 - 15)

default 1

This command sets the time allowed for entry of required characters to exit the
Transparent Mode. In order to allow exit to Command Mode from Transparent Mode,
while permitting any character to be sent as data, a guard time of CMDTIME seconds is
set up.

Entering a value for “n” sets the value of CMDTIME to “n seconds”.

To exit Transparent mode, you need to wait at least CMDTIME since the last data
character was sent to the TALON. Then you need to enter the COMMAND character
(e.g., <Ctrl+C>)) three times, with a wait of LESS THAN the value of CMDTIME
between the first and second time you enter the COMMAND character and also a wait of
LESS THAN the value of CMDTIME between the second and third time you enter the
COMMAND character.

After a final delay of CMDTIME the TALON will exit Transparent Mode and enter
Command Mode. At this time you should see the cmd: prompt. If CMDTIME is set to
zero the only exit from Transparent Mode is a modem break signal; assuming BREAK is
set to ON.

For example (if CMDTIME is 1 second and COMMAND is <Ctrl+C>): wait at least one
second, type a <Ctrl+C>, within one second type a second <Ctrl+C>, within one second
type a third <Ctrl+C>, WAIT at least one second, and the cmd: prompt should appear. If
your computer/program has the capability you can also send a modem break to escape
Transparent Mode (assuming the command BREAK is set to ON.)

See also: command, trans, break

CMSG {ON | OFF | DISC}

Page 61 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default OFF

When OFF, the custom connect text stored in CTEXT will not be sent to the connecting
station upon receiving a connect request. When ON, the custom CTEXT string will be
sent. When CMSG is set to DISC, the custom CTEXT string will be sent to the
connecting station, and then your TALON will disconnect from that station.

See also: ctext

COMMAND n (n = $00 - $FF)

default $03 <Ctrl+C>

This command defines the Command Mode entry character. When COMMAND is set to
the default value, typing this character causes the TALON to return to Command Mode
from packet Convers Mode. See CMDTIME for returning to Command Mode from
Transparent Mode.

CONLIST [ON | OFF] [NONE | {+|-}callsign | callsign1,callsign2...]

default OFF

CONLIST is used to determine which stations (callsigns) may use your station for ANY
purpose, including digipeating. When ON, the TALON will recognize only those packets
received with a callsign that appears in the CONLIST’s list of callsigns; and you will not
be able to connect to any station that is not in the conlist. When OFF, the TALON will
process all packets.

The maximum number of callsigns allowed in CONLIST is 10. Up to 10 callsigns may be
entered at once, using the format shown after the command name, and the new list of
from 1 to 10 callsigns will replace whatever list was there before. The CONLIST
command can be used to add a single callsign (+callsign), so long as there is room for the
new callsign on the list (if there is not, the TALON responds with “EH?” and returns you
to the command prompt). Similarly, you can remove a single callsign (-callsign) from the
list. And to remove all items from the current list, enter CONLIST NONE.

A callsign entered without a SSID will match any SSID of that callsign. To match a
specific SSID only, enter the callsign with that SSID: for example, callsign-n, where n =
0-8191.

CONMODE {CONVERS | TRANS}

Page 62 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default CONVERS

This command controls the communication mode the TALON will be placed in
AUTOMATICALLY after a connect, if NOMODE is OFF. A connect may result either
from a connect request received or a connect request originated by a CONNECT
command. If the TALON is already in Convers or Transparent Mode when the
connection is completed, the mode will not be changed. If you have typed part of a
command line when the connection is completed, the mode change will not take place
until you complete the command or cancel the line input.

See also: canline, connect, convers, nomode, trans

CONNECT call [VIA call1,call2,...,call8]

Immediate

call = callsign of station to be connected to.

call1,...,call8 = optional stations to be digipeated through. A maximum of 8 digipeater
addresses (callsigns or aliases) can be specified. This is referred to as a path.

Each callsign may also have an optional Secondary Station Identifier (SSID) specified as

-n, where n = 1 - 15. The digipeat callsigns are specified in the order in which they are to
relay transmitted packets. The mode set by CONMODE will be entered upon successful
connect, if NOMODE is OFF. If no response to the Connect request occurs after RETRY
attempts, the command is aborted. A timeout message is printed on the display and the
TALON remains in the Command Mode. The station being connected to (call1) may
receive the connect request but be unable to accept connects, in which case a busy
message will be printed to the screen and the TALON will stay in Command Mode.
Connect requests may only be initiated in the Command Mode and the connect will be
established on the current stream.

If a connect is in progress, or already established, the path may be changed by simply re­issuing the CONNECT command with the desired path. This must be done on the same
stream as the original connect.

CAUTION, packets en route between your station and the reconnected station may be
lost.

If CONNECT is entered with no parameters, the status of the current stream is displayed.

See also: conmode, conok, dbldisc, maxusers, nomode, retry, ring, streamsw

CONOK {ON | OFF}

Page 63 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default ON

When ON, connect requests from other TALONs will be automatically acknowledged
and a <UA> packet will be sent. The standard connect message, with stream ID if
appropriate, will be output to the terminal and the mode specified by CONMODE will be
entered on the I/O stream if you are not connected to another station and NOMODE is
OFF.

When OFF, connect requests from other TALONs will not be acknowledged and a
<DM> packet will be sent to the requesting station. The message “connect request:
(callsign of whoever is trying to connect to you)” will be output to your terminal if
INTFACE is TERMINAL or NEWUSER.

When operating with multiple connects allowed, the connection will take place on the
next available stream. Connect requests in excess of the number allowed by the USERS
command will receive a <DM> response and the “connect request: (call)” message will
be output to your terminal if INTFACE is TERMINAL or NEWUSER.

See also: conmode, connect, intface, maxusers, monitor, nomode, users

CONPERM {ON | OFF}

default OFF

Setting CONPERM to ON forces the connection on the current stream to become
permanent and causes the TALON to attempt to reconnect when it is restarted.
CONPERMED connections are shown with /P in the status display, which is generated
by the STAT command.

See also: status

CONVERS

Immediate

CONVERS has no options. It is an immediate command and will cause entry into
Conversational Mode from Command Mode on the current I/O stream. Any link
connections are not affected.

Hint: K is the same as CONVERS, for quicker entry.
See also: k, command

Page 64 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

CPACTIME {ON | OFF}

default OFF

When OFF and in the Convers Mode, packets are sent when the SENDPAC character is
entered or when PACLEN is achieved. When ON and in the Convers Mode, packets are
sent at periodic intervals determined by PACTIME. Characters are sent periodically as in
Transparent Mode but the local editing and echoing features of Convers Mode are
enabled.

See also: convers, cr, paclen, pactime, sendpac, trans

CR {ON | OFF}

default ON

When ON the SENDPAC character (normally carriage return) is appended to all packets
sent in Convers Mode except when PACLEN is exceeded. Setting CR ON and
SENDPAC $0D results in a natural conversation mode. Each line is sent when a “CR” is
entered and arrives at its destination with the “CR” appended to the end of the line. To
avoid overprinting, AUTOLF may need to be ON at the receiving end.

See also: autolf, lfadd, sendpac

CRSUP {ON | OFF}

default OFF

When ON, the display of every other carriage return (when no data is between them) in
the received data is suppressed (removed) before sending the data to the terminal. When
CRSUP is OFF, all carriage return characters are left in the received data as it is sent to
the terminal.

See also: autolf, lfsup

CSTAMP {ON | OFF}

default OFF

When ON, the daytime stamp is printed with all “*** CONNECTED TO” and “***
DISCONNECTED” messages on the terminal.

See also: connect, daytime, disconnect, mstamp

Page 65 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

CTEXT text (0 - 128 characters)

default (blank)

Enter any combination of characters and spaces up to maximum length of 128. Entering a
single ‘%’ will clear CTEXT. This entry specifies the text of the first packet to be sent in
response to an accepted connect request provided that the parameter CMSG is not set to
OFF.

See also: cmsg, connect

CTRL { OFF | ON | LONG | SHORT | n} (n=1-20)

Immediate

default off/off/off/off/off/off/off/off

This command causes the TALON to activate the specified output line 0 - 7 as indicated.
If an output line is not specified, all outputs are affected. For instance, to set the 0 output
ON (active low), you would give the command “CTRL ON/”. You may optionally
specify a number of times to pulse an output ON, set the output ON, or set it OFF. Each
pulse on the output line lasts approximately 100 ms. Specifying LONG results in one
pulse of the output line, lasting approximately 1.5 s. The output lines are open drain
outputs and are pulled to ground when active (ON). For more information, see the section
on “Telemetry” in this manual.

Do not allow more than 200 mA of current in this circuit.

CWID [EVERY | AFTER] n (n = 0 - 255)

default EVERY 0

Each increment specifies 1-minute intervals. A value of 0 turns the CWID OFF. Setting a
value greater than 0 activates the ID under the conditions specified. If the optional
keyword “Every” is used, an ID will be sent every n minutes. If set to “After”, an ID will
be sent ONCE after the specified interval with no channel activity.

The string specified by the CWIDTEXT command will be sent in Morse code.

See also: mycall, cwidtext

Page 66 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

CWIDTEXT text (up to 15 characters)

default mycall

This command sets the text to be transmitted when the TALON performs an automatic
CWID. The text will be transmitted at the interval specified by the CWID command.

See also: cwid

DAYSTR text

default mm/dd/yyyy hh:mm:ss

The DAYSTR command is used to set the display FORMAT of your date/time display.
DO NOT enter an actual date or time, simply enter the form of the display you would
like, using the lower case letters m, d, h, y, and s as described below.

The format you enter is used for all time stamps, including the MHeard list.
The lower case characters m, d, y, h, and s have special meaning to this command and
will be replaced with data from the software clock. The lower case m will be replaced
with the minutes the first time it appears after a lower case h. If h, m, y, d, or s is
specified as a single character, the corresponding date/time element will be displayed as a
single digit if the value is less than 10. Entering two characters will force a two-digit
display for values under 10. If the month is entered as three ms (i.e. mmm), it will be
displayed as the first three characters of the month name (JUL). You may also enter any
other text you wish, allowing you to add such things as your time zone.

Remember that ALL lower case m, d, y, h, and s characters will be replaced by actual
values.

Some examples of setting the DAYSTR command and the resulting time/date display are:

DAYSTR setting Displayed Date/Time

mm/dd/yy hh:mm:ss 07/30/03 22:30:00
d.m.yy h:mm:ss 30.7.03 22:30:00
d.mm.yyyy h:mm 30.07.2003 22:30
mmm d yyyy h:mm CST JUL 30 2003 22:30 CST
TIME hh:mm DATE: mmm dd, yyyy TIME 22:30 DATE JUL 30, 2003

This command is used to define how date and time are to be displayed; it is not used to
enter an actual date and time (which you do by using DAYTIME). If you enter an actual
date and time with the DAYSTR command, the exact characters you entered will be
displayed in all timestamps and in response to the DAYTIME command, and your clock
will appear to stop.

See also: daytime

Page 67 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

DAYTIME yymmddhhmm[ss] (UTC time)

DAYTIME is used to manually enter a date and time (after which time and date are
formatted for display by the specifications given in DAYSTR).

When date and time are entered, using the input format specified in the command and
explained below, the values entered are used to set the software clock/calendar. The
software clock/calendar is then used for MHEARD logging, as well as for CSTAMP and
MSTAMP functions.

When entering the daytime digits, enter them in pure number sequence with no spaces,
dashes, or slashes. Notice that there are two digits each for entering a year, month, day,
hour, minute, and (optionally) second. Also, notice that you need to use the order given
here, which has nothing to do with the format (given in DATSTR) for displaying date and
time values. For example, to enter 2003, July 30, at 22:30:00 hours, the value of the
DAYTIME parameter would be 030730223000. In this case, seconds were entered, so the
string is 12 characters long (2 characters for each of six pieces of information entered).

If DAYTIME is entered with no parameter, the daytime is displayed using the format
defined by the DAYSTR command.

Note: If the TALON includes the GPS option, the DAYTIME will be set automatically
from the UTC time in the GPS data.

Hint: If the time appears to be stuck, check the current value of DAYSTR, to be sure that
the DAYSTR setting is being used to format the display of time and date, and not (in
error) to attempt to supply an actual date and time. If this is not the case, fix the problem
and see if time and date displays work correctly.

See also: cstamp, daytweak, daystr, mheard, and mstamp

DBLDISC {ON | OFF}

default OFF

When OFF, only one disconnect command (Disc) need be given to terminate an
unsuccessful connect attempt. If you are actually connected, the normal disconnect
sequence will occur.

When ON, a normal disconnect sequence will always occur (you will not be disconnected
until you receive an acknowledge of your disconnect or until the retry count is exceeded).
A second Disc command is required to force a local disconnect independent of the retry
counter.

Page 68 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

See also: disconnect

DELETE n (n = $00 - $FF)

default $08 <Ctrl+H>

This command defines the character to be used as the delete character. When this
character is typed, the last input character is deleted. The most common settings are $08
(backspace) or $7F (delete).

See also: bkondel

DIGIPEAT {ON | OFF | UIONLY}

default OFF

When ON, this unit will retransmit any packet it receives that has its MYCALL, or
MYALIAS, in the digipeat address field. Each station included in the digipeat list relays
the packet in the order specified in the address field. Digipeating takes place concurrently
with other TALON operations and does not interfere with normal connected operation of
the station. To disable digipeat operations (via MYCALL, or MYALIAS) set this
command to OFF.

If UIONLY is selected, the TALON will digipeat UI frames (unconnected information)
only.

See also: hid, myalias, mycall

DISCONNE

Immediate

When given without options, “disconnect” will initiate an immediate disconnect request
on the current I/O stream. A successful disconnect results in the display of “***
DISCONNECTED”. If the RETRY count is exceeded while waiting for the connected
station to acknowledge, the TALON moves to the disconnected state on that stream.
Entering a second Disconnect command before RETRY has expired will result in an
immediate disconnect on your end, but may leave the other station thinking it is still
connected to you. Disconnect messages are not displayed when the TALON is in
Transparent Mode. Other commands may be entered while a disconnect is in progress.

See also: dbldisc, newmode, retry, and status

Page 69 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

DISPLAY [{ A | C | G | I | L | M | T }]

Immediate

This command (when entered alone) causes the TALON to display a list of all the current
parameter settings in the TALON. A subset of this list will be displayed by specifying a
class identifier for a group of command parameters. When using the DISPLAY command
with a subclass, be sure to use a space between the DISPLAY command and the subclass.
Subclasses of related parameters are:

ASYNC asynchronous port parameters (TALON to computer)
CHAR special TALON characters
GPS parameters related to GPS operations
ID ID parameters
LINK parameters affecting packet link (TALON to TALON)
MONITOR monitor parameters
TIMING timing parameters

Individual parameter values can be displayed by entering DISPLAY and the command
name, followed by “CR”.

See also: Display Listings section

DWAIT n (n = 0 - 255)

default 0

DWAIT defines a delay to be used to avoid collisions with digipeated packets. The value
entered for “n” is the number of 10 ms intervals, after last hearing data on the channel,
for the TALON to wait before it begins its own key-up sequence.

This value should be established and set equally in all members of a local area network.
The best value will be determined by experimentation but will be a function of the key-up
time (TXDELAY). This feature is made available to help alleviate the drastic reduction
of throughput, which occurs on a channel when digipeated packets suffer collisions.
Digipeated packets are not retried by the digipeater but must be restarted by the
originating station. If all stations specify DWAIT, and the right value is chosen, the
digipeater will capture the frequency every time it has data to send since digipeated
packets are sent without this delay.

Observations have proven that a better algorithm for avoiding collisions between end­user stations, while still allowing digipeaters the high-priority access they require is
achieved using Persistence and Slottime to determine proper transmit intervals, and
setting DWAIT to 0.

Page 70 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

See also: persist, slottime

ECHO {ON | OFF}

default ON

When ON, characters received from the computer by the TALON are echoed back and
displayed. If you are receiving double print of characters entered at the keyboard, turn
this command OFF. This corresponds to the setting in your terminal program for duplex.
If your program is set for full duplex set ECHO ON. If your program is set for half­duplex (some call it echo) then set ECHO in the TALON to OFF. Regardless of the
setting of this command, the TALON will not echo an X-OFF or X-ON character to the
terminal when it receives a STOP or START character. Echo is disabled in Transparent
Mode.

See also: bkondel, flow

ESCAPE {ON | OFF}

default OFF

This command specifies the character, which will be sent to the terminal when an escape
character ($1B) is received in a packet. When OFF, $1B is sent. This is useful if your
terminal interprets ESC characters as screen positioning commands (ANSI). When ON,
the escape character is sent as a dollar sign ($).

FILTER {ON | OFF}

default OFF

When ON, this command will inhibit the printing of control characters (hex $00 - $1F)
which may be present in monitored packets. This will be useful if you are monitoring
channel traffic, which includes binary file transfers, or higher level protocols. Control
characters, which may be embedded in those packets, can have strange and unpredictable
effects on the monitoring TALON. All control characters except carriage return ($0D)
and line feed ($0A) will be filtered. This command DOES NOT affect receipt of control
characters in packets received from a “connected” station when MONITOR or MCON is
OFF.

See also: monitor

Page 71 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

FLOW {ON | OFF}

default ON

When FLOW is ON, any character entered from the terminal will halt output to the
terminal until the current packet or command is completed (by SENDPAC, PACLEN, or
PACTIME). Canceling the current input to the TALON or typing the REDISPLAY-line
character will also cause output to resume. FLOW will keep the display of received data
from interfering with data entry.

When FLOW is OFF, received data will be “interleaved” with keyboard entry. If using a
split screen terminal program, you should have FLOW OFF and ECHO OFF to allow
received data to be displayed while you type into the TALON’s type-ahead buffer.

See also: canline, canpac, cpactime, echo, paclen, redisplay, and sendpac

FRACK n (n = 1 – 15)

default 4

Each increment specifies an interval of 1 s. After transmitting a packet requiring
acknowledgment, the TALON waits FRACK seconds before incrementing the retry
counter and sending the packet again. If the retry count (specified by the RETRY
command) is exceeded, the current operation is aborted. If the packet address includes
digipeaters, the time between retries is adjusted to FRACK * ((2 * m) + 1) where m is the
number of digipeater stations specified. When the retried packet is sent, a random wait
time is also added to avoid lockups where two units repeatedly collide with each other.

The FRACK timer begins when PTT is released (the packet has been sent) and is
suspended when data carrier from the radio is present, or when your station is
transmitting.

See also: connect, resptime, retry

GBEACON {EVERY | AFTER} [[hh:]mm:]ss [{START [[hh:]mm:]ss[.s]} | {OR m}]
[CLEAR]

default EVERY 00:00:00

This command (used with GPS) sets the interval between beacons.

If EVERY is specified, the current position information will be transmitted at the interval
specified by the hh:mm:ss parameter. This is set in h:min:s. If the optional key word
START is given followed by a time (in 24 h format); the beacon will not be transmitted

Page 72 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

until the specified time. Thereafter, the beacon will be transmitted according to the
setting of the EVERY parameter. (NOTE: If the current time is past the start time, the
beacon will start at the next scheduled interval based on the start time.)

For example, setting GBEACON EVERY 00:15:00 START 00:05:10 would cause the
location beacon to be transmitted every 15 min, with the first transmission each day
occurring at 00:05:10.

If the OR parameter is specified, instead of START, the beacon will be sent when the
EVERY timer runs out or the vehicle has moved m meters since the last beacon,
whichever comes first

If AFTER is specified, the beacon will be transmitted once after no activity is detected on
the channel for hh:mm:ss time. Selecting AFTER does not allow the optional START or
OR parameter.

If the option CLEAR is specified, the buffer is cleared after transmission. This will
prevent copies of NMEA position data from being retransmitted at the next beacon
interval.

See also: chfree, gtext, and gpath

GPATH dest [via call1[,call2,...]]

default GPS

This command sets the destination callsign and the digipeaters used to transmit the
GBEACON position information. The destination callsign defaults to GPS. Up to 8
digipeater callsigns may be specified.

GREPORT n (n = 0 - 255)

default 0

This command sets the interval of local reports of GPS data from this unit’s own GPS
receiver, which will be displayed as defined in the GTEXT command.

GTEXT optional text mixed with $variables$

default $GPRMC$

This command controls how received GPS beacon data is displayed. You can specify one
or more NMEA strings with optional text and/or other variables. To include a variable, it

Page 73 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

must be preceded and followed by a dollar sign ($) and must be in upper case. The
following variables are allowed: $GPRMC, $GPGLL, $GPGGA, $GPVTG, CHKSUM,
LAT, LONG, UTC, OFFSET, DATE, ESPD, NSPD, USPD, SOG, TRACK, ALT,
NUMSAT,TEMPC,TEMPF.

For example:

GTEXT Latitude: $LAT$, Longitude: $LONG$

$GPRMC, $GPGLL, $GPGSA, and $GPVTG, are all valid NMEA 0183 type sentences.
Data will be displayed in the specified sentence format. When included, CHKSUM adds
valid checksum to NMEA sentences. Note that when CHKSUM is specified, the NMEA
string header must include the leading $ character. For example, these specified strings
would be entered this way:

GTEXT $$GPRMC$$CHKSUM$

LAT displays the latitude.

LONG displays the longitude.

UTC displays the time in UTC format, as derived from the GPS satellites.

OFFSET displays the current time offset between the GPS satellites, and UTC (GMT)
time.

ESPD displays speed in easterly direction. (W will be included if movement is in a
westerly direction)

NSPD displays speed in northerly direction. (S will be included if movement is in a
southerly direction)

USPD displays rate of climb or descent.

SOG displays the speed over ground, in km/h.

TRACK displays the direction of travel, in degrees.

ALT displays altitude in m.

NUMSAT displays the number of satellites used to derive position information.

TEMPC displays the temperature in degrees Celsius.

TEMPF displays the temperature in degrees Fahrenheit.

Page 74 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

HEADERLN {ON | OFF}

default ON

When ON a carriage return is output to the terminal between the header and text of
monitored packets. This causes the packet header and time stamp (if on) to be displayed
on one line, with the packet text displayed below it on the next line. When receiving
packets addressed only to you (MONITOR and/or MCON OFF) this parameter does not
apply. When OFF, the data will be on the same line as the header.

See also: cstamp, mcon, monitor, and mstamp

HELP [command]

Immediate

Entering the word “HELP” alone, without any argument, will generate a display listing
all commands available in the TALON.

When the name of a command is entered also (e.g., HELP CONVERS), a brief
description of that command will be displayed. A wild card also can be used; entering
“Help C*” will display brief descriptions of all commands beginning with C.

HELP can also be called by entering “?”.

HID {ON | OFF}

default ON

When ON, an ID packet will be sent every 9.5 minutes, provided that packets are being
digipeated through your station. This command should be ON if digipeating is enabled. If
OFF, periodic identification packets will not be sent.

See also: digipeat, id, and myalias

ID

Immediate

When this command is entered an identification packet will be transmitted. This
command may be used to insure that your station identification is the last transmission
before taking the station off the air.

Page 75 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The ID packet is an unnumbered information <UI> packet whose data consists of your
station identification as set in MYCALL and a listing of other modes, if you have
activated them.

The MYCALL will be appended with “/R” if DIGIPEAT is ON, MYALIAS callsign
appended with “/D”. This packet will be addressed to “ID” and digipeated via any
addresses specified in the UNPROTO command.

See also: hid, unproto

INTFACE {TERMINAL|KISS|HOST|LSUB|POLL|TUP}

default TERMINAL

When set to KISS, the serial port communication is in KISS mode (a framed data mode,
similar to SLIP). This requires a special program or driver in the computer attached to the
serial port of the TALON that communicates in KISS mode. See the KISS mode section
for more information.

When set to HOST, the serial port communication is in the Kantronics HOST mode. This
requires a special program or driver in the computer attached to the serial port of the
TALON that communicates in HOST mode. See the HOST mode section for more
information.

When set to LSUB, the TALON is in a transparent data mode. Data from the serial port
will be transmitted, and received data (from another unit also in LSUB mode) will output
from the serial port. See LSUB mode in the Operating Modes chapter, for more
information.

When set to POLL, the TALON can be configured as a “master” (with its POLLID set to

0000), or as a “remote” (with its POLLID set to a 4 digit number other than 0000). See
POLL mode in the operating modes chapter, for more information.

When set to TUP, the TALON is in a transparent data mode. Data from the serial port
will be transmitted, and received data (from another unit also in TUP mode) will output
from the serial port. In this mode, other TALON units can be used as digipeaters, when
their callsigns have been entered in the UNPROTO command. See TUP mode in the
Operating Modes chapter, for more information.

For instructions on exiting KISS, HOST, LSUB, POLL, and TUP modes, see the
appropriate sections of this manual.

NOTE: After changing the setting of this command to KISS, HOST, LSUB, POLL, or
TUP, a soft reset is required for the new mode to take effect (see RESET for details).

Page 76 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

K

Immediate

This single letter command is synonymous with CONVERS. It is included as a single­keystroke convenience for entering Convers Mode.

See also: convers

LFADD {ON | OFF}

default OFF
When ON, a line-feed will be appended to every carriage return received from the
keyboard before being transmitted. When OFF, no line feeds will be added to the
transmitted signal.

LFSUP {ON | OFF}

default OFF

When ON, this command suppresses any line-feed characters received from the other
station, relying on your terminal program to properly advance to the next line. When
OFF, the line-feeds received from the other station are not suppressed but are sent to your
terminal as received.

See also: autolf, crsup

LLIST [ON | OFF] [NONE | {+|-}callsign | callsign1,callsign2...]

default OFF

LLIST is used to determine which stations (callsigns) may NOT use your station for
ANY purpose, including digipeating. When LLIST is ON, the TALON will NOT
recognize those packets received with any callsign that appears in the LLIST’s (lid) list of
callsigns. In addition, when LLIST is ON, you will not be able to connect to any station
that is on that list.

The maximum number of callsigns allowed in LLIST is 10. Up to 10 callsigns may be
entered at once, using the format shown after the command name, and the new list of
from 1 to 10 callsigns will replace whatever list was there before. The LLIST command
can be used to add a single callsign (+callsign), so long as there is room for the new

Page 77 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

callsign on the list (if there is not, the TALON responds with “EH?” and returns you to
the command prompt). Similarly, you can remove a single callsign (-callsign) from the
list. And to remove all items from the current list, enter LLIST NONE.

A callsign entered without a SSID will match any SSID of that callsign. To match a
specific SSID only, enter the callsign with that SSID: for example, callsign-n, where n =
0-8191.

LOCATION

Immediate

Displays the current location information.

MALL {ON | OFF}

default ON

When ON, monitored packets include connected and unconnected packets between other
stations. If OFF, only other station’s unconnected packets (UI frames) will not be
displayed.

This is a useful arrangement when stations are talking as a group in an unconnected
configuration.

See also: monitor

MAXFRAME n (n = 1 - 7)

default 4

MAXFRAME sets an upper limit on the number of unacknowledged information packets,
which can be outstanding at any one time. The TALON will send MAXFRAME number
of packets in a single transmission, if they are available.

See also: paclen

MAXUSERS n (n = 0-10)

default 1

Page 78 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

This command causes the TALON to allocate the memory required for the maximum
number of simultaneous connections you wish to allow. Each connection uses a different
stream. In order to direct what you want to say to a different stream you use the
STREAMSW character. All streams may be used for outgoing packets, but USERS sets
the number that may be used for incoming connections. Changing the value of
MAXUSERS will cause the TALON to perform a “soft reset”. Note that you may not
change the value of MAXUSERS while you are connected, since this would reset the
TALON and cause all existing connections to be lost.

Note: Although you must spell out the entire command word (MAXUSERS) to change
the current value of MAXUSERS, you can enter the short form, MAXU, if you just want
to see the current value of MAXUSERS.

See also: status, streamsw, users

MBEACON {ON | OFF}

default ON

This command determines whether packets addressed to Beacon or ID will be displayed
on the screen.

If you do not wish to display Beacon or ID packets, turn this command OFF.

See also: beacon, id, and monitor

MCOM {ON | OFF}

default OFF

Supervisory (control) packets are not monitored unless MCOM is set ON and MON is
ON. In addition if your station is connected, control packets are not monitored unless
MCON is also ON. Control packets, when displayed, are distinguished from information
packets by the “<>” and “<<>>” character sets appended to the packet header. With these
characters, a letter is included to denote the type of control packet received, e.g. <<c>> ­a connect request packet. The types of control packets are listed below.

<C> Connect request
<D> Disconnect request
<DM> Disconnected Mode

<UA> Unnumbered Acknowledge
In addition, the following bracketed information will be added to the Information packets
as appropriate:

Page 79 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

<UI> Unconnected Information frame

<Is> Information frame (connected);

s = send sequence number

See also: ax25l2v2, monitor, and mresp

For details on control packets, see the book AX.25 Amateur Packet-Radio Link-Layer
Protocol Version 2.0 October 1984, available from the ARRL.

MCON {ON | OFF}

default OFF

When OFF, and connected, the TALON will display only those packets addressed to you.
Any header information displayed will be determined by the settings of STREAMEV and
STREAMCA. When OFF, and not connected, all eligible packets (as determined by other
monitor commands) will be displayed. When ON, all eligible packets will be displayed,
whether connected or unconnected.

See also: monitor, streamca, and streamev

MHEARD [LONG | SHORT | CLEAR]

Immediate

This command causes display of a list of stations heard. An asterisk, *, indicates that the
station was heard through a digipeater. The date/time the station was last heard is also
displayed.

If the S option is used, i.e. MHEARD S, then only the callsigns of the stations heard will
be displayed.

If the L option is selected, all callsigns contained in the received packet including the
digipeater paths, are displayed. For example:

NORTH2 > ID 01/21/2003 14:31:30 VIA DIGI1,SOUTH

Here, your station heard NORTH2 transmitting an ID packet. NORTH was also using the
digipeating path DIGI1, SOUTH. If your station heard NORTH via one of these other
stations, an asterisk would show by the call or alias of the last digipeater heard. When
listed short, the asterisk would show beside NORTH2.

Page 80 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Whenever PASSALL is ON, packets will not be checked for errors and no additions will
be made to the MHEARD list.

If the C option is used, the list is cleared.

See also: daytime, passall

MHEADER {ON | OFF}

default ON

When ON, the headers are displayed for all monitored packets. When OFF, headers are
not displayed and only data is output from the serial port. Since only I and UI frames
have data, only these frames are displayed.

To avoid confusion when MHEADER is OFF, use BUDLIST to restrict the monitored
data.

See also: monitor, mcon, mbeacon, mall, suplist, budlist

MONITOR {ON | OFF}

default ON

When ON, unconnected packets will be monitored unless prohibited by SUPLIST,
BUDLIST, CONLIST, or LLIST. This will also allow monitoring of other packets if
permitted by the other monitor commands. The MONITOR command acts as a master
switch for the MALL, MCOM, MCON, MRESP, and MRPT commands. The addresses
in the packet are displayed along with the data portion of the packet. Callsigns (to and
from fields) are separated by a “>”; and the Secondary Station Identifier (SSID) is
displayed if it is other than 0. If any data is contained in the monitored packet, which
does not follow the AX.25 protocol, it is displayed in curly braces on the header line. All
monitor functions are disabled in the Transparent Mode.

When OFF, you will see just the data from those stations connected to you, no matter
how other monitor commands are set. Any header information displayed will be
determined by the settings of STREAMCA and STREAMEV.

See also: budlist, conlist, headerln, llist, mall, mbeacon, mcom, mcon, mresp, mrpt,
mstamp, pid, streamca, streamev, and suplist

MRESP {ON | OFF}

Page 81 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default OFF

When ON, monitored packets include the following AX.25 response packets, if
MONITOR and MCOM are ON. If connected, MCON must also be on. The bracketed
information will appear at the end of the header information. The “<” and “<<”
characters are used to bracket and denote packets received as version 1 or version 2,
respectively. For example, “<<RR1>>” denotes a version 2 packet. In addition upper case
characters are used to designate commands (polls) and lower case characters are used to
denote responses for RR, REJ, and RNR. For example, “<<rr1>>” is a response in
version 2.

<FRMR> Frame Reject

<REJr> Reject, r = received sequence number

<RNRr> Device busy, r = received sequence number

<RRr> Receive Ready, r = received sequence number

In addition, the following bracketed information will be added to the Information packets
as appropriate:

<Isr> Information frame (connected);

s = send sequence number,

r = received sequence number

See also: ax25l2v2, mcom, and monitor

For more information, see the book AX.25 Amateur Packet-Radio Link-Layer Protocol
Version 2.0 October 1984, which may be obtained from the ARRL.

MRPT {ON | OFF}

default ON

This command affects the way monitored packets are displayed. If ON, the entire
digipeat list is displayed for monitored packets, and the station that relayed the packet is
indicated with an asterisk. The MONITOR command must be ON for this command to
work, and if connected MCON must also be ON. If OFF, only the originating station and
the destination station callsigns are displayed for monitored packets.

See also: monitor

MSTAMP {ON | OFF}

default OFF

Page 82 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

This command enables time stamping of monitored packets. The date and time
information is then available for use for automatic logging of packet activity or other
computer applications. The date and time are set initially by the DAYTIME command,
and the date format is determined by the DAYSTR command. The MONITOR command
must be ON for this command to work, and if connected MCON must also be ON.

See also: cstamp, daytime, monitor

MXMIT {ON | OFF}

default ON

When ON, the TALON will display transmitted packets as monitored data on your
terminal. Repeated packets will be displayed as they are sent over the radio. The frames
to be displayed will be controlled by the MONITOR, MCOM, MCON, and MRESP
commands, and will obey the settings of TRACE, MSTAMP, HEADERLN, 8BITCONV
and FILTER commands.

See also: monitor

MYALIAS xxxxxxx-n (n = 0-8191)

default (blank)

Setting this command to a callsign or character string enables digipeating by using the
MYALIAS. Enter up to six characters (plus optional SSID) which are different than those
used for MYCALL, or MYREMOTE. For example: you may enter LAWRN as the
MYALIAS, which would be easier to remember for stations wishing to digipeat through
a station in Lawrence, enroute to a station more distant. You may disable the alias
digipeating with the command MYALIAS %.

See also: hid

MYCALL xxxxxxx-n (n = 0-8191)

This command tells the TALON what its callsign is.

The extension n is called a Secondary Station Identifier (SSID) and is defaulted as 0, but
may be any number from 0 to 8191. All packets originated by the TALON will contain
this callsign in the FROM address field. Any packets received by the TALON with this
callsign in the TO address field or digipeat fields will be responded to appropriately
(connect, disconnect, ack, digipeat, etc.).

Page 83 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

When the TALON is first turned on out of the box, or after a hard reset, it asks you for
your callsign – there is no default. The callsign you enter for MYCALL is automatically
used to compute other IDs too (CWIDTEXT). Changing MYCALL at the “cmd:” prompt
does not affect CWIDTEXT.

See also: cwidtext, digipeat, id, myalias, and myremote

MYDROP n (n = 0-15)

default 0

This command sets the KISS address of the radio port in the TALON. A KISS frame with
the upper nibble of the command byte set to this value will address this TALON.

See also: intface, KISS operation section

MYREMOTE xxxxxxx-n (n = 0-8191)

default (blank)

This command sets the callsign used for remote access of the TALON. Enter up to six
characters (plus optional SSID) which are different than the one used for MYCALL. In
addition, the RTEXT must be programmed with a text string. A station that connects will
be sent a series of numbers that must be decoded according to RTEXT.

See also: rtext; remote access section

NEWMODE {ON | OFF}

default ON

When ON, the TALON will return to Command Mode if the station on the current I/O
stream disconnects. The TALON will not return to Command Mode if the station
disconnecting is on a different stream. When OFF, a disconnect will not cause the
TALON to change modes.

See also: connect, disconnect, status

NOMODE {ON | OFF}

default OFF

Page 84 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

When OFF and a connection takes place, the TALON will change to whatever mode is
specified in CONMODE. When ON, the TALON stays in Command Mode after
connecting to another station; that is, it does not immediately change to Convers or
Transparent Mode.

See also: conmode, connect

PACLEN n (n = 0 - 255)

default 128

This command specifies the maximum length of the data portion of a packet. The
TALON will automatically send a packet when the number of input bytes reaches n. This
value is used in both Convers and Transparent Modes. A value of 0 means 256 bytes.

See also: maxframe

PACTIME [EVERY | AFTER] n (n = 0 - 255)

default After 10

This command is used to pace the formation (and transmission) rate of packets in
Transparent mode or in Convers mode if CPACTIME is ON. In addition, a PACTIME
timer is necessary in transparent mode, TUP and LSUB modes, since the SENDPAC
character is ignored and treated as data. The timer is not started until at least one byte is
entered for a packet; hence, a zero data length packet is never formed and sent.

When AFTER is specified, bytes are packaged (if any available) when input from the
terminal stops for n*100 ms or when PACLEN is reached. When EVERY is specified,
input bytes are packaged (if available) and queued for transmission every n*100 ms or
when PACLEN is reached.

See also: cpactime, trans

PASS n (n = $00 - $FF)

default $16 <Ctrl+V>

This command selects the ASCII character used to allow the passage of any characters in
Converse Mode.

Page 85 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

For example, if you wish to send a COMMAND character (<Ctrl+C>) as part of the
packet, you can do so by preceding it with the PASS character. The command character
will be sent rather than returning the TALON to Command Mode. In Transparent Mode
all characters are passed, there are no special functions except the one combination to get
out of transparent mode. However, see TRFLOW.

PASSALL {ON | OFF}

default OFF

When PASSALL is ON, the TALON will attempt to display received packet data, even if
it detects errors in the received data. If a packet contains beginning and ending flags, the
TALON will attempt to decode the address field as well as the data field and display the
packet as specified by other commands such as MONITOR. MHEARD logging is
disabled when PASSALL is ON.

When PASSALL is OFF, packets will be displayed only if the CRC (error checking) is
correct and as specified by other commands such as MONITOR.

PERSIST n (n = 0 - 255)

default 63

This command, used with SLOTTIME, implements an algorithm for channel access to
send packets. The algorithm used to determine whether or not to transmit using the
PERSIST/SLOTTIME method has been shown to be considerably more efficient than the
DWAIT method used by most standard AX.25 packet stations. The result of using the
persistence algorithm is increased throughput under most channel conditions.

The value of “n” is used to determine if a packet will be sent after SLOTTIME expires.
For example, let’s assume a PERSIST setting of 63 and a SLOTTIME setting of 10. This
slottime setting corresponds to 100 milliseconds. When the TALON detects that the
channel is clear and available (no carrier is detected), it starts a timer (SLOTTIME).
When the timer expires, (100 ms in our case), the TALON generates a random number
between 0 and 255. If the generated number is equal to or less than the PERSIST value,
the TALON keys up the transmitter and sends the data packet. With our setting of 63 the
odds of this occurring after the first slottime are 1 in 4. (Actually the probability is
PERSIST plus 1 divided by 256.) If the TALON generated random number is greater
than PERSIST, the TALON restarts the timer and waits for the timer to expire again
before generating a new random number. This is repeated until the TALON gains channel
access and sends its packet of information.

Making SLOTTIME smaller will cause the TALON to generate the random number more
frequently, whereas raising the PERSIST value will give a better chance (improve the

Page 86 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

odds) of transmitting the data. Through careful choice of these values, it is possible to
improve data throughput while at the same time permitting shared channel usage with
other packet stations. The persistence algorithm has been added on top of the DWAIT
algorithm.

See also: slottime

PERM

immediate

The PERM command causes all changed parameter settings to be stored in EEPROM.
Those changed parameters that require a reset to enable them, will not take effect until
the next reset (power off/on cycle, or RESET command) occurs.

PING callsign

immediate

Entering the PING command and a callsign, causes a single request packet to be
addressed and transmitted to the specified station. When that station hears this request, it
will immediately transmit its current gbeacon information, in place of its next scheduled
beacon.

POLLID n (n = 0000 to 9999)

default (blank)

This entry specifies this TALONs address when it is operating in POLL mode. If set to
0000, this unit operate as a “master”, in POLL mode. If set to a number other than 0000
(0001 to 9999), this unit will operate as a remote.

See also: POLL mode section

RANGE n-m (n=[-]0-254.00000, m=1-255.00000)

default 0-255/0-255/0-255/0-255/0-255/0-255/0-255/0-255

The 8 A/D inputs are normally read by the microprocessor, in response to the ANALOG
command, as a single byte value from 0 to 255, representing a voltage from 0 to +5 V on
the input pin. You can use the RANGE command to mathematically convert that single
byte value to any offset and scale you want. If you would like the input to be expressed as

Page 87 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

a voltage with 2 decimal precision, for example, set the range for that analog pin as 0-

5.00. If you connect a temperature sensor to an A/D pin, which outputs 0-5 V for
temperatures of –40 to 100, set the range for that input to –40 – 100.0. A pressure sensor
that gives 0-4 V for 1 PSI would use a range of 0-1.25.

See also: analog, telemetry

REDISPLA n (n = $00 - $FF)

default $12 <Ctrl+R>

This command is used to change the REDISPLAY input editing character. The parameter
n is the ASCII code for the character you want to type in order to REDISPLAY the
packet or command currently being entered.

You can type this character to cause the TALON to redisplay the packet you have begun.
When you type the REDISPLAY-packet character, the following things happen: First,
type-in flow control is released (if FLOW was enabled). This displays any incoming
packets that are pending. Then a \ (backslash) character is displayed, and the packet or
command you have begun is redisplayed on the next line. If you have deleted and retyped
any character, only the final form of the packet will be shown. You are now ready to
continue typing. Incoming packets will continue to be displayed until you type the next
character of your current message.

You can use the REDISPLAY-packet character to see a “clean” copy of your input if you
are using a printing terminal (or have BKONDEL OFF) and you have deleted characters.
The REDISPLAYed packet will show the corrected text.

You can also use this character if you are typing a message in Convers Mode and a
packet comes in. You can see the incoming message before you send your packet,
without canceling your input.

See also: bkondel, canline, canpac, and flow

RELINK {ON | OFF}

default OFF

When OFF, the TALON operating with AX25L2V2 ON does not attempt to
automatically reconnect. When ON, the TALON operating with AX25L2V2 ON will
attempt to automatically reconnect after RETRY is exceeded.

See also: ax25l2v2, retry, and tries

Page 88 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

RESET

immediate

This command is used to perform a soft reset. The MHEARD log is not cleared. Any
existing connections, which are not conpermed, will be lost, even though the other station
still indicates a connection to your station. The initial sign-on message will be displayed.

See also: intface, maxusers, myremote, and restore

RESTORE

immediate

When the RESTORE command is given, the TALON will revert to its factory default
settings (losing all previously PERMed settings), and start its AUTOBAUD routine. It
will then need to be initialized (by pressing the * to set its interface baud rate, and
entering a callsign.)

See also: reset

RETRY n (n = 0 - 15)

default 10

This command specifies the number of packet retries. Packets are re-transmitted n times
before an operation is aborted. The time between retries (when no acknowledgment is
received) is specified by the command FRACK.

See also: ax25l2v2, frack, relink, and tries

RING {ON | OFF}

default ON

When ON, three bell characters ($07) are sent to the terminal with each “***
CONNECTED TO” message (when another station initiates the connect).

RNRTIME n (n = 0 - 255)

default 0

Page 89 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

RNRTIME is set in 10-second increments. If a connection stays in a remote device busy
state (continues to receive RNR frames) for RNRTIME, the TALON will disconnect.
Setting RNRTIME to 0 disables this function.

See also: mresp

RTEXT text (text up to 128 characters)

default (blank)

This command sets the password string for use when accessing the MYREMOTE. When
you connect to the TALON MYREMOTE callsign, it will send three sets of numbers, one
of which must be properly decoded (matching position number with string character)
using this string, and those decoded characters entered back to the TALON to gain
remote command access.

For instance, if the RTEXT is set to “This is my RTEXT string” and you connect to the
MYREMOTE, the TALON would send three sets of random numbers. The numbers
would look like:

5 20 14 7 18 3

7 1 4 14 8 19

9 3 8 12 22 1

You must then pick ONE of these lines and decode the password string (i.e., assign letters
to each letter position). Let’s say you choose to decode line 3 (9 3 8 12 22 1). Rewriting
the RTEXT string to make this easier we have:

11111111112222

12345678901234567890123

This is my RTEXT string

Now, decoding the string, character 9 is “m” character 3 is “i”, character 8 is “ ” (i.e.,
space), character 12 is “R”, character 22 is “n”, and character 1 is “T”. You must send the
following in response to the string of numbers:

mi RnT

If correct, you’ll receive the MYREMOTE prompt (“prompt:”).

Note that case is significant and spaces are considered valid characters.

If you fail to properly decode the password, the remote TALON will send three new lines
of numbers. You will be given a maximum of three attempts to properly decode the

Page 90 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

password string. If you fail in three attempts, the TALON will disconnect, and will not
accept another connect request for 15 min.

SCRAMBLE { ON | OFF | FEC }

default OFF

When set to ON, transmit data is scrambled. When set to FEC, transmit data is scrambled
with FEC (forward error correction, or “redundant bits”).

SCREENL n (n = 0 - 255)

default 0

This value is used to format what is sent to your terminal. A “CR” sequence is sent to the
terminal at the end of a line when n characters have been printed. A value of zero inhibits
this action.

See also: autolf

SENDPAC n (n = $00 - $FF)

default $0D <Ctrl+M> (CR or ENTER)

This command specifies a character that will force a packet to be sent in Convers Mode.
In the Convers Mode, packets are sent when the SENDPAC character is entered or when
PACLEN is achieved.

See also: cpactime, cr

SLOTTIME n (n = 0 - 255)

default 10

n specifies the amount of time, in 10 millisecond increments, between successive tries of
the persistence algorithm.

See also: persist

START n (n = $00 - $FF)

Page 91 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

default $11 <Ctrl+Q>

This command specifies the character sent by the computer to the TALON to restart
output from the TALON. If set to $00 only hardware flow control will be used. For
software flow control, set this parameter to the character the computer will send to restart
data flow.

See also: stop, xflow, xoff, xon

STATUS [ LONG ]

immediate

Entry of the STATUS command will display the number of bytes available (i.e., free
bytes) in the RS232 input buffer, the current I/O stream, and connected status.

Entering STATUS LONG will cause the TALON to display the status of all streams
allowed by MAXUSERS, and MYREMOTE.

A pound sign ‘#’ (octothorp) indicates that there is unacknowledged data in the buffers
for that stream. The number immediately following the # is the number of bytes
outstanding. The number in parentheses is the number of packets not yet acknowledged.

The following is an example of a display (using STATUS LONG). A, B, C, through J
(i.e., MAXUSERS = 10) indicate the stream. “A” stream is connected to NORTH2 and
has 50 bytes in 2 packets that are unacknowledged. The current stream (IO) is the “B”
stream, which is connected to SOUTH.

cmd: STATUS LONG
FREE BYTES 1661
A stream - #50(2) CONNECTED to NORTH2
B stream – IO CONNECTED to SOUTH
C stream - DISCONNECTED

.....

.....

J stream - DISCONNECTED
REM DISCONNECTED

See also: conperm, maxusers, myremote, and streamsw

STOP n (n = $00 - $FF)

default $13 <Ctrl+S>

Page 92 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

This command specifies the character sent by the computer to the TALON to stop output
from the TALON. If set to $00 only hardware flow control will be used. For software
flow control set this parameter to the character the computer will send to stop data flow.

See also: start, xflow, xoff, xon

STREAMCA {ON | OFF}

default OFF

When receiving packets addressed only to you (MONITOR OFF and/or MCON OFF),
setting this command ON will enable the display of the callsign of the connected-to
station following the stream identifier of the connection (as controlled by STREAMEV).
This is especially useful when operating with multiple connections allowed.

See also: mcon, monitor, and streamev

STREAMEV {ON | OFF}

default OFF

When OFF, the stream indicator is displayed only when a change in streams occurs.
When ON, the stream indicator will be displayed with every incoming packet. This
command takes effect only when receiving those packets addressed to you and MCON is
OFF.

See also: mcon, monitor, streamca, and streamsw

STREAMSW n (n = $00 - $FF)

default $7C (|)

This command selects the character to be used to signify that a new “stream” or
connection channel is being addressed. To change streams you must type this
streamswitch character followed immediately by the stream designator. The stream
designator is an alphabetic character A through Z, or a through z, limited by the value of
MAXUSERS.

If STREAMSW is set to the dollar sign ($24) you will need to enter parameter values in
decimal. Alternatively, precede the $ with the PASS character in order to enter hex
numbers.

Page 93 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

The character selected can be PASSed in the Convers Mode by using a special PASS
character, and will always be passed as data in the Transparent Mode. If operating in the
Transparent Mode and you wish to change streams, you must first return to the Command
Mode.

See also: maxusers, pass, status

SUPLIST [ON|OFF] [NONE | {+|-}call | call1,call2,..]

where call={callsign | {<|>}callsign | callsign{>|<>}callsign}

default OFF NONE

SUPLIST is used to determine which received packets will not be displayed, i.e.
suppressed. When OFF or NONE, SUPLIST will not prevent the display of packets, even
if it has callsigns in its list.

The maximum number of callsigns allowed in SUPLIST is 10. Up to 10 callsigns may be
entered at once, using the format shown after the command name, and the new list of
from 1 to 10 callsigns will replace whatever list was there before. The SUPLIST
command can be used to add a single callsign (+callsign), so long as there is room for the
new callsign on the list (if there is not, the TALON responds with “EH?” and returns you
to the command prompt). Similarly, you can remove a single callsign (-callsign) from the
list. And to remove all items from the current list, enter SUPLIST NONE.

A callsign entered without a SSID will match any SSID of that callsign. To match a
specific SSID only, enter the callsign with that SSID: for example, callsign-n, where n =
0-8191.

Selective display is enabled when one or two callsigns are combined with a “>” and/or
“<” character. For example, entering “>callsign” will disable display of packets TO that
callsign (assuming SUPLIST is ON), entering “<callsign” will disable display of packets
from the callsign, entering “callsign1>callsign2" will block display of packets from
callsign1 to callsign2, and entering ”callsign1<>callsign2" will block display of packets
from callsign1 to callsign2 and vice versa.

Note that entering call>call or call<>call counts as two of the 10 maximum allowed
callsigns.

See also: monitor

TELEMTRY n ( n = 0 - 255)

default 0

Page 94 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

A telemetry beacon is sent every n*10 s. If n = 0, the beacon is disabled. The telemetry
beacon is a UI frame sent to BEACON. If there is a current UNPROTO digipeat path, it
will be used to transmit the telemetry beacon.

The data in the UI frame is in the form:
“T#nnn,an0,an1,an2,an3,an4,an5,an6,an7,bbbbbbbb”, where:

• “nnn” is a decimal count for the telemetry beacon and is incremented each time the

beacon is sent. When first used, or after the unit is reset, the beacon counter begins at
001 (T#001). After reaching 999 (T#999), the counter cycles around to 000 (T#000).

• “an0", ”an1", “an2", ”an3", etc., are the decimal readings on the corresponding

analog inputs.

• “bbbbbbbb” is the binary reading of the 8 inputs, where “b” = “1" means a Logic

High on the pin and ”b" = “0" means a Logic Low on the pin. The first ”b" in the
string of 8 binary digits is the most significant bit, and the last “b” is the least
significant bit.

See also: analog, range

TEMPERAT [C|F]

Immediate

Displays the current internal temperature of the TALON. Its default output is in degrees
Celsius. Enter TEMPERAT F to change the display to degrees Fahrenheit.

TRACE {ON | OFF}

default OFF

When ON, all received frames are displayed in their entirety, in hexadecimal, including
all header information. All packets which are eligible for monitoring also will be
displayed in normal text.

TRANS

immediate

This command causes immediate exit from Command Mode into Transparent Mode. The
current link state is not affected. There are no special editing characters, all characters are

Page 95 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

sent out as received. To get out of Transparent, send the TALON a modem break if
BREAK is ON, or see CMDTIME for a special keyboard sequence.

See also: break, cmdtime, and command

TRFLOW {ON | OFF}

default OFF

This command allows the TALON to respond to software flow control from the computer
while in the Transparent Mode. When TRFLOW is OFF, software flow control is not
used in the Transparent Mode. The TALON will expect hardware flow control from the
computer. The computer program needs to use hardware flow control, and the RS232
cable needs to be wired with CTS and RTS connected. When ON, software flow control
is enabled and the START and STOP characters are sent by the computer to the TALON
to control the flow of data. When START and STOP are set to $00, hardware flow
control must be used. If not zero, the TALON will respond to the computer’s START and
STOP characters, and remain transparent to other characters from the terminal or
computer for flow control.

When START and STOP are set for software flow control (normally <Ctrl+Q> and
<Ctrl+S>) all characters can be received in Transparent Mode (including the START and
STOP characters) by setting TRFLOW ON and TXFLOW OFF. You will not, however,
be able to send the START and STOP characters, since the TALON will interpret them as
flow control.

See also: trans, txflow, and xflow

TRIES [n] (n = 0 - 15)

The TRIES command will display and optionally set the number of attempts, which have
been made to re-send a packet (on the current stream) which failed to reach its
destination. For instance, if RETRY is set to 10, TRIES will show how many attempts
have already been made to pass the data. For example, if TRIES were to show 8, “TRIES
3” would reset the counter to make the TALON believe that it had only tried 3 times so
far, thus allowing 7 more attempts before the RETRY limit is exceeded.

See also: retry

TUPTIME n (n = 0 – 255 * 100 ms)

default 1 (100 ms)

Page 96 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

Sets the “time to live” for transmitted packets in TUP mode.

TXFLOW {ON | OFF}

default OFF

This command allows the TALON to send software flow control (XON and XOFF) to
stop and restart the flow of data from the computer while in the Transparent Mode. When
TXFLOW is OFF, hardware flow control must be used between the computer and
TALON. RTS and CTS must be connected between the TALON and computer for
hardware flow control. When TXFLOW is ON, software flow control between the
TALON and computer in Transparent Mode will depend on the setting of XFLOW.
XFLOW ON enables software flow control, XFLOW OFF disables it. When software
flow control is enabled, the TALON will send the XON and XOFF characters to the
computer to control data flow.

When set for software flow control, all characters can be sent in Transparent Mode
(including the XON and XOFF characters) by setting TXFLOW ON, XFLOW ON and
TRFLOW OFF. You will not, however, be able to receive the START and STOP
characters, since your terminal program should interpret them as flow control.

See also: trans, trflow, and xflow

UIDIGI [ON | OFF] [NONE | {+|-} call1[,call2[,call3[,call4]]]]

default OFF NONE

Up to 4 call signs can be specified for special digipeater duty. If any of the UIDIGI calls
appears in the to-be-digipeated field of a UI packet, and if MYCALL does not appear in
the source field or any of the has-been-digipeated fields, the UIDIGI call in the to-be­digipeated field will be replaced by MYCALL, with the H bit set, and the packet will be
digipeated.

See also: dwait, persist, uidwait, unproto

UIDWAIT [ON|OFF]

default OFF

When UIDWAIT is OFF, “special” digipeat packets (those formed by UIDIGI, or
UIFLOOD, only) have their usual channel access; there is no wait DWAIT or slottime
added before transmission once the channel is clear. However, if UIDWAIT is set ON,

Page 97 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

the packets waiting to be digipeated will be subject to the same wait times as not-to-be­digipeated packets awaiting transmission.

By subjecting “special” to-be-digipeated packets to a delay determined by slottime and
persist, it is more likely that to-be-digipeated packets of two or more stations in the same
vicinity would not collide. This may be good if one wants to guarantee that a digipeated
packet will “make it out” of its neighborhood but bad if one wishes to limit the number of
times a packet is redigipeated.

See also: dwait, persist, uidwait

UIFLOOD name[,n [,{ID|NOID}] (name = 5 char max)(n=0-255)

default disabled,30,NOID

When a UI frame is received with a call in the to-be-digipeated field of the form ‘name’
x-y where x is a number (1-7) appended to ‘name’ and y is a ssid (1-7), the ssid is
decrement and the UI frame is digipeated without setting the H bit. When the packet is
digipeated, a checksum is formed over the source, destination, and data fields of the
packet. This checksum is kept for n seconds (0-255). If an incoming UI packet is eligible
for digipeating as above, but its checksum matches one of those being saved, the packet
is discarded (not digipeated). The buffer holds a maximum of 64 checksums. If the
optional parameter ID is selected, the MYCALL callsign is inserted in an additional
digipeater address field with its H bit set.

See also: uidwait

UNPROTO {call [VIA call1,call2..call8] | NONE}

default CQ

call = destination address (this is really just a “dummy” address, as no connection takes
place, people often put their name or CQ here)
call1 ... call8 = optional stations to be digipeated through. A maximum of 8 digipeat
addresses (callsigns or aliases) can be specified. This is referred to as a path.
Each callsign may also have an optional Secondary Station Identifier (SSID) specified as

-n, where n = 1 - 15. The digipeat callsigns are specified in the order in which they are to
relay transmitted packets. This command is used to set the digipeat and destination
address fields for packets sent in the unconnected (unprotocol) mode. Unproto packets do
not receive an acknowledgment and are not retried. They are sent as Unnumbered I­frames <UI>. The digipeater list is also used for BEACON and ID packets. If UNPROTO
is “NONE”, no unconnected packets will be sent except for BEACON and ID. Setting
MONITOR ON can monitor unconnected packets sent from other units. If you are
connected, you must also set MCON ON.

Page 98 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

See also: beacon, id, monitor, mrpt, and xmitok

USERS n (n = 0 - MAXUSERS)

default 1

This command specifies the channels (streams) which may be available to incoming
connect requests. For example, if USERS = 5 then an incoming connect request will
connect to the lowest channel A - E, if any of these channels are in the unconnected state.
If none of the 5 channels are available (all of them are connected), a <DM> packet will
be sent back to the requesting station and the message “*** connect request: (call)” will
be output to your terminal, if permitted. If USERS is set to 0 no one will be able to
connect to you. If you try to set USERS higher than MAXUSERS, the extra is ignored
and the message “USERS LIMITED BY MAXUSERS” will be displayed.

See also: intface, maxusers, and streamsw

VERSION

Immediate

This command causes the TALON to display its model name and current installed BIOS
version number.

VOLTAGE

Immediate

Displays dc input voltage to unit in XX.XX format.

XFLOW {ON | OFF}

default ON

When ON software flow control will be implemented according to the settings of
START, STOP, XON, and XOFF. For normal software flow control set XFLOW ON,
START $11, STOP $13, XON $11, XOFF $13. The TALON expects the computer or
terminal to respond to the flow control characters XON and XOFF, and the TALON
responds to the START and STOP characters from the computer. When XFLOW OFF,
the TALON will only use and recognize hardware flow control lines (CTS and RTS) to

Page 99 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

start or stop data. The RS232 cable must be wired appropriately. If the software flow
control characters are set to $00, software flow control is not possible.

In the Transparent Mode flow control is also determined by the settings of TRFLOW and
TXFLOW.

See also: start, stop, trflow, txflow, xoff, xon, and xkchksum

XOFF n (n = $00 - $FF)

default $13 <Ctrl+S>

This command selects the character sent by the TALON to the computer to stop input
from the computer. If set to $00, hardware flow control must be used. For software flow
control set this parameter to the character the computer expects to see to stop sending
data to the TALON.

See also: xflow, xon

XON n (n = $00 - $FF)

default $11 <Ctrl+Q>

This command selects the character sent by the TALON to the computer to restart input
from that device. If set to $00, hardware flow control must be used. For software flow
control set this parameter to the character the computer expects to see to restart sending
data to the TALON.

See also: xflow, xoff

Additional commands for TALON with I/O board.

ALARM

Sets exception conditions which will cause an alarm packet to be sent out.

ALARM ANALOG r1/r2/r3/r4/r5/r6/r7/r8

Where r is "OFF" or specifies a valid range of values based on the RANGE

command

For example, if RANGE is specified as 0.00:5.00 for one of the analog inputs and
ALARM ANALOG is specified as 3.00:4.00, the Talon will send an alarm packet if that
input goes below 3.00 or above 4.00.

Page 100 of 101

DWG ID: 181-0101-00A

Date: 2003-09-26

ALARM INPUT i1/i2/i3/i4 Where i is { OFF | HIGH | LOW | CHANGE}

If i is HIGH, an alarm packet will be sent if the pin goes high.
If i is LOW, an alarm packet will be sent if the pin goes low.
If i is CHANGE, an alarm packet will be sent if the pin changes.

ALARM TEMP r Where r is "OFF" or specifies a valid temperature range

An alarm packet will be sent if the temperature goes outside of the range specified. The
range is based on the Celsius/Fahrenheit flag specified in the TEMPERATURE
command (-65:127 ºC or -85:206 ºF).

ALARM TIME n Where n=1 to 255 s

When an alarm exception occurs, an alarm packet is sent, unless the Talon is already in
an alarm condition. If a telemetry POLL is not received within n seconds, another alarm
packet is sent. This will continue until a telemetry POLL is received, at which time the
alarm condition is cleared. The alarm packet is sent to the address specified in the
UNPROTO command.

ALARM VOLTAGE r Where r is "OFF" or specifies a valid input voltage range

An alarm packet will be sent if the input voltage goes outside of the range specified
(0.00:16.57).

DACS n1/n2/n3/n4 Where n is in the range 0:1023

This command sets the output voltage of the 4 DACs on the I/O CCA.

IO d1/d2/d3/d4 Where d is { OFF | NO | ON | YES }

This command sets or clears the 4 digital outputs on the I/O CCA. The command also
displays the 4 digital inputs.

POLL call [VIA calls] n1,n2,n3,n4,d1,d2,d3,d4

call [VIA calls] is the address of the remote Talon.
n (0:1023) is the value which will be used to set the DACs on the remote Talon.
d (OFF|NO|ON|YES) is the setting for the digital outputs on the remote Talon.

When the remote Talon receives a poll packet, it will set its DACs and digital outputs
accordingly and return a response packet which contains all telemetry data. The response
packet is addressed to whoever sent the poll packet. The data in the response packet is
compressed, but it will be displayed in the form:

n1,n2,n3,n4,d1,d2,d3,d4,a1,a2,a3,a4,a5,a6,a7,a8,t,v,i1,i2,i3,i4.
