Kanto YU2 User Manual

English

User Manual

YU2 Powered Speakers

POWERED SPEAKERS

Supporting your digital lifestyle

™

Table of Contents

Important Safety Precautions . . . . . . . 2

Introduction / What’s in the Box? . . . . . 3

Front & Rear Panels . . . . . . . . . . . . 4

Connecting Audio Sources . . . . . . . . . 6

Connecting a Sub-Woofer . . . . . . . . . . 7

Specifi cations / Warranty . . . . . . . . . . 8

Setting Up Your Speakers . . . . . . . . . 5

Important Safety Precautions

ATTENTION

The exclamation point within an

equilateral triangle is intended to

alert the user of the presence of
important operating and maintenance
(servicing) instructions in the literature

accompanying the apparatus.

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with a dry cloth.

• Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifi ers)
that produce heat.

• Protect the power-supply cord from being walked on or
pinched, particularly at plugs, convenience receptacles and
the point where they exit from the apparatus.

• Only use attachments / accessories specifi ed by the
manufacturer.

• Use only with the cart, stand, tripod, bracket, or table
specifi ed by the manufacturer, or sold with the apparatus.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK, DO

NOT REMOVE BACK PANEL.

NO USER SERVICEABLE PARTS

INSIDE. REFER SERVICING

TO QUALIFIED SERVICE

PERSONNEL.

• Unplug this apparatus during lightning storms or when

• Refer all servicing to qualifi ed service personnel. Servicing

• Apparatus shall be connected to a MAINS socket outlet with

• An appliance input coupler is used as the disconnect device

• Batteries or battery packs shall not be exposed to excessive

DANGEROUS VOLTAGE

The lightning fl ash with arrowhead, within an

equilateral triangle, is intended to alert the user

of the presence of non-insulated “dangerous

voltage” within the product’s enclosure that

may be of suffi cient magnitude to constitute a

risk of electric shock to persons.

When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

unused for long periods of time.

is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, the
apparatus does not operate normally, or the apparatus has
been dropped.

a protective earthing connection.

- the disconnect device shall remain readily operable.

heat such as sunshine, fi re or the like.

FCC Warnings

• Changes or modifi cations not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.

• This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules.

FCC Notice:

• This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.

Industry Canada Notice:

• Complies with CAN ICES-3(B) / NMB-3(B)

2

Supporting your digital lifestyle

™

Introduction

Thank you for choosing YU2 Powered Speakers, designed by Kanto in Canada. YU2 outputs 25W
RMS per channel into 4 Ohm speakers, for remarkably bold and clean sound. Excellent sensitivity
and frequency response provide deep thumping lows and clear, scintillating highs, surprising for
speakers of this size. YU2 is a remarkably fl exible computer speaker system that can accept two
input sources and connect to a subwoofer for enhanced low frequency effect (LFE).

We recommend you read all instructions carefully before using the system, and keep them for
future reference. Kanto cannot be liable for damage or injury caused by incorrect setup or use of
this product.

This powered speaker system was carefully tested and inspected during production, and before
packaging and shipping. After unpacking, please check for any damage. It is rare that a unit is
damaged during shipping, but if this happens contact your retailer immediately. You can also
call Kanto directly at 1-888-848-2643 or email [e-mail].

What’s In the Box?

YU2 Active

Speaker

x8

Self-Adhesive

Rubber Feet

YU2 Passive

Speaker

AC/DC

Adapter

Speaker

Wire (10’)

USB cable

3.5mm AUX
cable

3

Front & Rear Panels

FRONT PANEL

1 3/4” Silk Dome Tweeter

2 3” Kevlar Mid/Woofer Driver

3 LED

REAR PANEL

4 ON/OFF Switch and Volume Control

5 Right Channel Output Terminals

(+ and −) for Passive Speaker
Connection

6 3.5mm Stereo Mini-Jack AUX

7 USB Audio Input Connector

8 Subwoofer Output

9 DC Input Connection

10 Bass Refl ex Port

1

2

3

Volume

í

4

OFF

5

+

4

10

6

7

8

9
