Kanguru Mobile Clone 1HD SATA

User Manual

Model no.: KCLONE-1HD-MBC

Notices and Information

Please be aware of the following points before using your KanguruClone

Copyright© 2011, Kanguru Solutions. All rights reserved. Windows XP®, Windows Vista® and Windows 7® are registered trademarks of Microsoft Inc. Apple® and Macintosh® are registered trademarks of Apple Computer Inc. IBM and OS/2 are registered trademarks of the International Business Machines Corporation. All other brand or product names are trademarks of their respective companies or organizations.

Kanguru Solutions will not be held responsible for any illegal use of this product nor any losses incurred while using this product. The user himself is responsible for the copyright laws, and is fully responsible for any illegal actions taken.

Customer Service

To obtain service or technical support for your system, please contact Kanguru Solutions Technical Support Department at 508-376-4245, or visit www.Kanguru.com for web support.

Legal notice

In no event shall Kanguru Solutions’ liability exceed the price paid for the product from direct, indirect, special, incidental, or consequential software, or its documentation. Kanguru Solutions offers no refunds for its products. Kanguru Solutions makes no warranty or representation, expressed, implied, or statutory, with respect to its products or the contents or use of this documentation and all accompanying software, and specifically disclaims its quality, performance, merchantability, or fitness for any particular purpose. Kanguru Solutions reserves the right to revise or update its products, software, or documentation without obligation to notify any individual or entity.

Export Law Compliance

Regardless of any disclosure made to Kanguru Solutions pertaining to the ultimate destination of the specific Kanguru product, you warrant that you will not export, directly or indirectly, any Kanguru product without first obtaining the approval of Kanguru Solutions and the appropriate export license from the Department of Commerce or other agency of the United States Government. Kanguru Solutions has a wide range of products and each product family has different license requirements relative to exports.

FCC Compliance Statements

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the Distance between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Table of Contents

1. INTRODUCTION................................................................................................5

1.1 Package Contents......................................................................................5

1.2 Specifications.............................................................................................6

1.3 Parts and Functions ..................................................................................7

1.4 Hardware Setup ........................................................................................8

1.5 Function Diagram .....................................................................................9

2. THE USER INTERFACE ...................................................................................10

2.1 The Menus .................................................................................................11

2.1.1 The Main Menu ............................................................................11

2.1.2 The Setup Menu ...........................................................................11

2.1.3 The Advanced Setup Menu .........................................................11

3. DUPLICATION MODES ....................................................................................12

3.1 Brief Mode .................................................................................................12

3.2 Resize Mode ..............................................................................................12

3.3 Full Mode .................................................................................................12

4. DEFINING COPY AND/OR COMPARE .........................................................13

4.1 Set Copy Functionality .............................................................................13

4.2 Set Compare Functionality ......................................................................13

4.3 Set Copy & Compare Functionality .......................................................13

5. DUPLICATION ..................................................................................................14

5.1 Duplicating From a Master HDD ............................................................14

5.2 Duplicating From a Storage Center ........................................................15

5.2.1 Formatting a hard drive as a Storage Center ............................15

5.2.2 Loading a Master HDD image to the Storage Center ...............15

5.2.3 Duplicating an image file stored on a Storage Center ..............16

6. OTHER OPERATIONS .....................................................................................18

6.1 Erase ..........................................................................................................18

6.2 Wipe ...........................................................................................................19

6.3 Verify ..........................................................................................................20

6.4 Load ...........................................................................................................21

Table of Contents

7. SETUP MENU ......................................................................................................22

7.1 Set Copy .....................................................................................................22

7.2 Set Compare ..............................................................................................22

7.3 Button Sound ............................................................................................23

7.4 Select Image File .......................................................................................23

7.5 Delete Image File ......................................................................................23

7.6 Format Source ..........................................................................................24

8. ADVANCED SETUP MENU ..............................................................................25

8.1 Device Info .................................................................................................25

8.2 System Info ................................................................................................26

8.3 Set to Default .............................................................................................26

8.4 HPA Check ................................................................................................27

8.5 No Capacity Check ...................................................................................27

8.6 Max UDMA Mode ....................................................................................27

8.7 Skip Read Error ........................................................................................28

8.8 Load Full Image ........................................................................................28

8.9 Total Copy Count ......................................................................................28

8.10 Update Firmware ....................................................................................29

9. ERROR CODE LIST ..........................................................................................30

10. FAQ .....................................................................................................................30

11. TROUBLESHOOTING ....................................................................................31

12. WARRANTY INFORMATION ........................................................................32

13. TECHNICAL SUPPORT ..................................................................................33

Introduction / Package Contents

1. INTRODUCTION

Congratulations on your purchase of the Kanguru Mobile Clone Hard Drive Duplicator from Kanguru Solutions.

The Kanguru Mobile Clone is a high speed, stand-alone SATA/PATA hard drive duplicator that can clone just about any hard drive. With all the features of Kanguru’s full-size hard drive duplicators, transfer rates up to 6GB/min and a small form factor, the Kanguru Mobile Clone HD Duplicator is the perfect addition to any IT technician’s toolbox.

Features

√ Up to 6GB/min transfer rates √ Natively supports 3.5” PATA and 2.5”/3.5” SATA hard drives √ HDD size and brand independent. √ Clones any operating system: including DOS, Win98, Win2K, Win NT, Win XP, Win Vista, Win

7, Linux, Mac and many more.

√ 3 Copy Operations:

○ Brief Copy - Copies only sectors with data (compatible with most major file systems) ○ Resize Copy - Copies HDDs with different capacities ○ Full Copy - Sector for sector duplication

√ Post duplication Compare √ Secure Disk Wipe √ Read Verify diagnostic √ Supports HPA (Host Protection Area) copy √ Load images to a Storage Center for convenient access to common duplication jobs √ One-year Standard Warranty

1.1 Package Contents

If any of the following items are missing, please call Kanguru Solutions’ Tech Support department at: (508) 376-4245, extension 2 and replacement parts will be shipped to you ASAP.

• 1 x Kanguru Mobile Clone HD Duplicator

• 1 x AC adapter

• 1 x Power cable

• 2 x IDE Data Cable

• 2 x IDE Power Cable

• 2 x SATA Data/Power Cable

• 1 x Quick Start Guide

Specifications

1.2 Specifications

Model KCLONE-1HD-MBC

Connection Interface

Transfer rate Up to 6GB/min

LCD Screen 20 x 2 Characters back-lit LCD

Input Device 2 Push Buttons

Dimensions 6.2” x 4” x 1.5”

Weight 2 lbs.

Power Supply 110/220V 60W

Operating Temperature 41ºF ~ 95ºF

Relative Humidity 20% ~ 80%

2.5”/3.5” SATA

3.5” PATA

Parts and Functions

1.3 Parts and Functions

IDE data connection

SATA data/power connection

IDE power connection

Power port

Target IDE / SATA

IDE Power

TARGET

RUN button

LCD Display

Hard Drive Duplicator

SET button

SET RUN

IDE Power

IDE power connection

SATA data/power connection

SOURCE

Source IDE / SATA

IDE data connection

Hardware Setup

1.4 Hardware Setup

1. Place the Kanguru Mobile Clone where there is proper ventilation. Avoid using the Kanguru Mobile Clone in environments with high temperatures or extreme humidity.

2. Make sure that sufficient power is supplied to the KanguruClone. Incorrect power will cause faulty operation.

3. You are now ready to begin using your Kanguru Mobile Clone. To begin, turn on the duplicator by connecting the power adapter from an electrical outlet to the unit’s power port.

Things to remember

• Make sure that sufficient power is supplied to the Kanguru Mobile Clone. Incorrect power may cause faulty operation.

• The KanguruClone supplies power to drives during a duplication session. There is no need to connect an external power source to the drives. The unit can supply up to 1.5A at 12V and up to 1A at 5V to each drive.

Note: the drives are not powered until you execute an operation.

• It is OK to connect and disconnect Master or Target drives while the Kanguru Mobile Clone is powered on. However, do NOT connect or disconnect drives while any operation is running or is in progress.

• The supplied cables are NOT standard cables like the ones found in a PC. Do not attempt to use these cables in a PC nor to use PC cables with the Kanguru Mobile Clone. Doing so may cause damage to the unit and/or drives.

• Connect all Master and Target hard drives before you execute an operation.

Function Diagram

1.5 Function Diagram

The User Interface

2. THE USER INTERFACE

Kanguru Solutions designed the Kanguru Mobile Clone’s menu system with the professional in mind. The menu system is fast, responsive, and easy to navigate. This means fewer key presses are needed to achieve a desired action.

Important! The menu system is controlled by 2 push buttons located below the LCD screen.

[BRIEF ] COPY

SET RUN

The ‘SET’ and ‘RUN’ buttons can be pressed in two ways:

• Tap – the button is pressed and released immediately. If the BTN. SOUND option is enabled (see section 7.3 Button Sound on page 23), a Tap will be accompanied by a short audible tone.

• Hold – the button is pressed and held for 2 seconds. If BTN. SOUND option is enabled (see section 7.3 Button Sound on page 23), a Hold will be accompanied by a short audible tone, followed by a higher pitched tone.

Note: When following the instructions listed in this manual, please pay close attention to whether you should tap a button or hold a button. The same button may function one way if tapped and another way if held.

The Menus

2.1 The Menus

There are three tiers to the Mobile Clone’s user interface: Main menu, Setup menu and Advanced Setup menu

2.1.1 The Main Menu

The Main menu contains the main duplication operations: BRIEF, RESIZE, FULL, ERASE, WIPE, VERIFY and LOAD. The duplicator will start in this menu by default.

[BRIEF ] COPY

• Tap the ‘SET’ button to navigate through the different operations within the Main menu.

• Tap the ‘RUN’ button to execute an operation.

2.1.2 The Setup Menu

The SETUP menu contains options for configuring the way your duplicator operates. From the Main menu, hold the ‘SET’ button to enter the SETUP menu.

SETUP >[ ] SET COPY

• Tap the ‘SET’ button to navigate through the different SETUP menu options

• Tap the ‘RUN’ button to select/configure an option.

• While in the SETUP menu, hold the ‘SET’ button to return to the Main menu.

2.1.3 The Advanced Setup Menu

The ADVANCED SETUP menu contains advanced options for configuring the way your duplicator operates. From the SETUP menu, tap the ‘SET’ button to navigate to the ADVANCED SETUP option and then tap the ‘RUN’ button to enter the ADVANCED SETUP menu.

ADVANCED SETUP >DEVICE INFO

• Tap the ‘SET’ button to navigate through the different menu options.

• Tap the ‘RUN’ button to select/configure an option.

• While in the ADVANCED SETUP menu, hold the ‘SET’ button to return to the SETUP menu.

Duplication Modes

3. DUPLICATION MODES

The Kanguru Mobile Clone can duplicate hard drives in one of three ways: BRIEF mode, RESIZE mode or FULL mode.

After duplication has been completed you can configure the duplicator to automatically compare the date on the Source drive with the data on the Target drives to ensure that the all data was copied successfully. For more information on configuring the Compare operation see chapter 4. Defining Copy and/or Compare on page 13.

3.1 Brief Mode

BRIEF mode copies only the sectors that contain data and skips any blank sectors (including information hidden in sub channels). This mode is the fastest copy mode; it supports the following file systems: FAT, FAT32, exFAT NTFS, EXT2, EXT3, EXT4, HFS, HFS+, JFS, XFS.

Note: If the Source is not formatted as a supported file system then the duplicator will automatically switch to FULL mode.

3.2 Resize Mode

RESIZE mode is used to duplicate from a smaller Source drive to larger capacity Target drives. The Resize mode first runs a BRIEF copy and then expands the resulting partition on the Target drives so that the resulting partition uses all unallocated space. Resize copy supports the following file systems: FAT, FAT 32, NTFS. If the Source is not formatted as a supported file system then the duplicator will automatically switch to FULL mode.

3.3 Full Mode

FULL mode copies drives sector by sector from the Source to the Target(s), and supports all major OS formats (DOS/Windows/Mac/Linux). This mode is the slowest copy mode, but the safest.

Defining Copy and/or Compare

4. DEFINING COPY AND/OR COMPARE

Before performing a duplication, take a moment to define the SET COPY and SET COMPARE options under the SETUP menu. These options will tell the duplicator how the FULL and BRIEF modes will operate.

4.1 Set Copy Functionality

When SET COPY is enabled BRIEF, RESIZE and FULL modes will execute a Copy process. The SET COPY option is enabled by default.

To change the SET COPY option:

1. From the Main menu, hold the ‘SET’ button to enter the SETUP menu.

2. Tap the ‘SET’ button to navigate to the SET COPY option. It is marked with an asterisk by default, signifying that copy functionality is currently enabled.

3. Tap the ‘RUN’ button to toggle whether copy functionality is enabled or disabled.

SETUP >[ ] SET COPY

4.2 Set Compare Functionality

When SET COMPARE is enabled BRIEF and FULL modes will execute a Compare process, comparing the data between the Source and Target drives and confirming that they are identical. The SET COMPARE option is disabled by default.

To change the SET COMPARE option:

1. From the Main menu, hold the ‘SET’ button to enter the SETUP menu.

2. Tap the ‘SET’ button to navigate to the SET COMPARE option. It should not be marked by default, signifying that compare functionality is currently disabled.

3. Tap the ‘RUN’ button to toggle whether the option is enabled or disabled.

SETUP >[ ] SET COMPARE

Note: The Compare process cannot be run with RESIZE mode.

4.3 Set Copy & Compare Functionality

Both the SET COPY and SET COMPARE options can be enabled at the same time. When both options are enabled BRIEF and FULL modes will execute a Copy & Compare process, copying the data from the Source to the Target drives and then comparing the data on all drives to ensure that they are identical.

Duplication / Duplicating From a Master HDD

5. DUPLICATION

The KanguruClone HDD Duplicator can operate in either one of two duplication methods:

• With a Master HDD as the source

• With a Storage Center as the source

Both methods are described in the following sections.

5.1 Duplicating From a Master HDD

Using a Master HDD as the Source is the simplest and most convenient way to perform the duplication process.

IMPORTANT! Connect your Master HDD on the side labeled “SOURCE”. Connect the Target hard drives on the side labeled “TARGET”. Connect all drives before you execute an operation.

To execute the duplication of a Master HDD:

1. From the Main menu, tap the ‘SET’ button to navigate to the desired copy mode. For more information on the different available copy modes see chapter 3. Duplication Modes on page

12.

The screen will display the following:

[BRIEF ] COPY

2. Once you have selected the copy mode, tap the ‘RUN’ button to execute it. The duplication process begins as the system initializes the connected disks.

[BRIEF ] COPY POWER ON...

3. Once all connected disks have been detected and initialized, the duplication process begins. During duplication the screen will display the following information:

[BRIEF ] COPY

30.44%

WARNING! Do not remove any drives while duplication is in progress. Wait for duplication to finish before removing a drive. If you wish to interrupt the current process, tap the ‘RUN’ or ‘SET’ button at any time.

4. Once the copy process is completed the screen will either provide you with a “Success” message or, if for any reason a drive was not duplicated successfully, an error message. Tap the ‘SET’ button to view the total duplication time.

Duplicating From a Storage Center

5.2 Duplicating From a Storage Center

The Kanguru Mobile Clone hard drive duplicator allows you to turn a standard hard drive into a Storage Center. You can load images of your Master HDDs directly to the Storage Center providing you with a convenient way to store common duplication jobs.

5.2.1 Formatting a hard drive as a Storage Center

First you need to format a hard drive as a Storage Center:

1. From the Main menu, hold the ‘SET’ button to enter the SETUP menu.

2. From the SETUP menu, tap the ‘SET’ button to navigate to the FORMAT SOURCE operation.

3. Connect the hard drive that you want to use as a Storage Center to the side of the duplicator labeled “SOURCE”.

4. Tap the ‘RUN’ button to execute the FORMAT SOURCE. Caution! Formatting will erase any data currently stored on the hard drive.

5. A confirmation screen appears. Tap the ‘RUN’ button to proceed with formatting the hard drive as a Storage Center or tap the ‘SET’ button to cancel.

Once the format has completed, tap any button to return to the SETUP menu. Your hard drive has now been formatted as a Storage Center. You can now load images of Master HDD’s to the Storage Center for convenient duplication.

Note: A hard drive formatted as a Storage Center will not be recognized when connected directly to a computer. The Storage Center uses a proprietary format not recognized by most operating systems.

5.2.2 Loading a Master HDD image to the Storage Center

Once you have formatted a hard drive as a Storage Center, you can load images of your Master HDDs to the Storage Center. To load a Master HDD image to the Storage Center:

1. Make sure your Storage Center is connected to the side labeled “SOURCE” and that the Master HDD is connected to the side labeled “TARGET”.

2. From the Main menu, tap the ‘SET’ button to navigate to LOAD. You will see the following screen:

[LOAD ] 000

(Continued on next page)

Duplicating From a Storage Center

3. Tap the ‘RUN’ button. The duplicator will initialize the disks and then ask you to input a name for the image file.

a) The file name consists of three digits. The digit furthest to the right will be blinking, indicating

that it is currently selected. Tap the ‘RUN’ button to increase the digit by one.

b) Tap the ‘SET’ button to select the next digit to the left. Tap the ‘RUN’ button to increase the

digit by one. Repeat this step as necessary.

Note: If your duplicator displays the error message, “TARGET NOT FORMATTED” then the hard drive connected to the “SOURCE” port has not been formatted as a Storage Center yet (see section 5.2.1 Formatting a hard drive as a Storage Center on page 15).

4. When you have completed naming the image file, hold the ‘RUN’ button and the duplicator will begin loading an image of your Master HDD to the Storage Center. Note: If the image file name you enter already contains an image file previously loaded on the Storage Center, the system will overwrite the previously saved file.

Please Input >[000] SEL IMG FILE

IMG file name

Size of Source data

[LOAD ]001 15.94G

33.44%

5. When the load process has completed you can remove the Master HDD from the side labeled “TARGET”.

Percentage completed

5.2.3 Duplicating an image file stored on a Storage Center

Now that you have loaded an image file on the Storage Center:

1. From the Main menu, hold the ‘SET’ button to enter the SETUP menu.

2. From the Setup menu, tap the ‘SET’ button to navigate to the SELECT IMAGE FILE option.

SETUP >[001] SEL IMG FILE

In the example above, file number 001 is currently selected.

(Continued on next page)

Duplicating From a Storage Center

3. Tap the ‘RUN’ button to select an image file. a) The file name consists of three digits. The digit furthest to the right will be blinking, indicating

that it is currently selected. Tap the ‘RUN’ button to increase the digit by one.

b) Tap the ‘SET’ button to select the next digit to the left. Tap the ‘RUN’ button to increase the

digit by one. Repeat this step as necessary.

4. Hold the ‘RUN’ button when you have completed selecting the image file name.

5. Hold the ‘SET’ button to return to the Main menu.

6. From the Main menu, tap the ‘SET’ button to navigate to the desired copy mode.

7. Connect your Target drive to the side of the duplicator labaled “TARGET”.

8. Tap the ‘RUN’ button to execute. Once all connected disks have been detected and initialized, the duplication process begins.

Note: If you receive the following error message: “NO DATA FOUND”, then the image file that you selected does not contain any data. Either select a different image file or load the data from a Master HDD to that image file.

9. Once the copy process is completed the screen will either provide you with a “Success” message or, if for any reason a drive was not duplicated successfully, an error message. Tap the ‘SET’ button to view the total duplication time.

Other Operations / Erase

6. OTHER OPERATIONS

Besides the Copy and Compare modes, the Kanguru Mobile Clone Duplicator has several additional operations that are incredibly useful, including: ERASE, WIPE, VERIFY and LOAD.

6.1 Erase

ERASE deletes all information on any hard drive connected to the side of the duplicator labaled “TARGET”. Data is erased by writing zeros into each sector on the hard drive.

CAUTION! The Erase operation will delete all data and file systems on any attached Target hard drives. Make sure that you back up any important data before executing the Erase operation. Only hard drives connected to “TARGET” will be erased. Any hard drives connected to the side of the duplicator labaled “SOURCE” will not be affected by the Erase operation.

To Erase a hard drive:

1. From the Main menu, tap the ‘SET’ button to navigate to ERASE.

[ERASE ]

2. Connect your hard drive to the side of duplicator labeled “TARGET”. Tap the ‘RUN’ button to begin the Erase process. The following screen will be displayed:

[ERASE ]

1.15%

Percentage completed

3. Once the Erase process has completed, the following screen will be displayed:

[ERASE ] 100% SUCCESS

Tap the ‘SET’ button to view the total erase time.

Wipe

6.2 Wipe

Although the data is removed through the Erase operation, the data may still be retrievable with the right tools. The WIPE feature allows you to perform a disk wipe operation, ensuring that the hard drive is completely erased and that the data is unrecoverable.

Unlike an Erase, which writes zeros to every sector on the hard drive, a Wipe is a four step process that ensures that data is unrecoverable. The four steps are as follows:

1. All sectors on the hard drive(s) are written to with 0’s.

2. All sectors on the hard drive(s) are written to with 1’s.

3. All sectors on the hard drive(s) are written to with a random pattern of 0’s and 1’s.

4. All sectors on the hard drive(s) are verified

CAUTION! The Wipe operation will permanently delete all data and file systems on a hard drive. Make sure that you back up any important data before executing the Wipe operation. Only hard drives connected to the side of duplicator labeled “TARGET” will be erased. Any hard drives connected to the side of the duplicator labaled “SOURCE” will not be affected by the Wipe operation.

To Wipe a hard drive:

1. From the Main menu, tap the ‘SET’ button to navigate to WIPE.

[WIPE ]

2. Connect your hard drive to the side of duplicator labeled “TARGET”. Tap the ‘RUN’ button to begin the Wipe process. The following screen will be displayed:

[WIPE ]WRT0

1.15%

Percentage completed

The following will be displayed next to “[WIPE ]” to indicate which step the Wipe feature is at:

○ WRT0 - Writing 0’s to all sectors ○ WRT1 - Writing 1’s to all sectors ○ WRTR - Writing a random pattern of 0’s and 1’s to all sectors ○ RVEY - Read Verifing all sectors

3. Once the Wipe process has completed, the following screen will be displayed:

[WIPE ] 100% SUCCESS

Tap the ‘SET’ button to view the total Wipe time.

Verify

6.3 Verify

VERIFY will check that all sectors are readable on the drive connected to the side of the duplicator labaled “TARGET”. If a hard drive fails duplication, you should run the Verify feature to ensure that the drive is healthy.

To verify your hard drives for duplication:

1. From the Main menu, tap the ‘SET’ button to navigate to VERIFY.

[VERIFY ]

2. Connect your hard drive to the side labled “TARGET”. Tap the ‘RUN’ button to begin the Verify process. The following screen will be displayed during verification:

[VERIFY ]

1.08%

Percentage Completed

3. Once the verification process has completed, the following screen will be displayed:

[VERIFY ]

100.00% SUCCESS

Tap the ‘SET’ button to view the total Verify time.

Load

6.4 Load

LOAD allows you to store an image of a hard drive to a Storage Center.

A Storage Center is a hard drive that has been formatted to store hard drive images. The Storage Center allows you to quickly and conveniently access common duplication projects. For information on formatting a hard drive as a Storage Center see section 7.6 Format Source on page 24.

To load an image of a hard drive to a Storage Center:

1. From the Main menu tap the ‘SET’ button to navigate to LOAD.

[LOAD ] 000

2. Connect your Storage Center hard drive to the side of duplicator labeled “SOURCE”.

3. Connect the Master hard drive to the side of duplicator labeled “TARGET”.

4. Tap the ‘RUN’ button to begin the load process.

Note: If the screen displays the message “SOURCE NOT FORMATTED” it means that the hard drive connected to the Source side has not been formatted as a Storage Center. Tap the ‘RUN’ button to format the hard drive connected to the Source side as a Storage Center or tap the ‘SET’ button to cancel.

5. The duplicator will ask you to input a file name for the image. Enter a file name:

Please Input >[000] SEL IMG FILE

a) The file name consists of three digits. The digit furthest to the right will be blinking, indicating

that it is currently selected. Tap the ‘RUN’ button to increase the value by one.

b) Tap the ‘SET’ button to select the next digit to the left. Tap the ‘RUN’ button to increase the

digit by one. Repeat this step as necessary.

6. When you have completed naming the image file, hold the ‘RUN’ button and the load process will begin.

Note: If the image file name you entered is already being used by another image file, the system will ask you to confirm overwriting the previously saved file. Tap the ‘RUN’ button to confirm or tap the ‘SET’ button to cancel.

IMG file number

Total data to be loaded

Percentage completed

[LOAD ]001 15.94G

33.44%

Setup Menu / Set Copy / Set Compare

7. SETUP MENU

To enter the SETUP menu, from the Main menu hold the ‘SET’ button. Once you have entered the SETUP menu:

• Tap the ‘SET’ button to navigate the different menu options.

• Tap the ‘RUN’ button to change an option’s setting.

• Hold the ‘SET’ button to return to the Main menu

7.1 Set Copy

The SET COPY option allows you to enable or disable the Copy operation. Tap the ‘RUN’ button to change this option’s setting.

• [ ٭ ] – Copy enabled (default). FULL, BRIEF or RESIZE modes will perform a Copy operation.

• [ ] – Copy disabled. FULL, BRIEF or RESIZE modes will not perform a Copy operation.

Note: To perform a Copy & Compare operation, set both the SET COPY and SET COMPARE options to enabled.

7.2 Set Compare

The SET COMPARE option allows you to enable or disable the Compare operation. Ta p the ‘RUN’ button to change this option’s setting. The Compare operation is not supported by RESIZE.

• [ ] – Compare disabled (default). FULL and BRIEF modes will not perform a Compare operation.

• [ ٭ ] – Compare enabled. FULL and BRIEF modes will perform a Compare operation.

Note: To perform a Copy & Compare operation, set both the SET COPY and SET COMPARE options

to enabled.

Button Sound / Select Image File / Delete Image File

7.3 Button Sound

The BTN. SOUND option allows you to enable or disable the audible tone that sounds when you tap or hold a button. Tap the ‘RUN’ button to change this option’s setting.

• [ ٭ ] – Button sounds are enabled (default). Tapping a button will be accompanied by a short

tone. Holding a button will be accompanied by a long tone followed immediately by a higher pitched tone.

• [ ] – Button sounds are disabled. No audible tones will sound when you tap or hold a button.

7.4 Select Image File

SEL IMG FILE is used for selecting an image file that has been saved to a Storage Center.

SETUP >[000] SEL IMG FILE

To select an image file:

1. From the SETUP menu, tap the ‘SET’ button to navigate to the SEL IMG FILE option.

2. Tap the ‘RUN’ button. The digit furthest to the right will be blinking, indicating that it is currently selected. Tap the ‘RUN’ button to increase the digit by one.

3. Tap the ‘SET’ button to select the next digit to the left. Tap the ‘RUN’ button to increase the digit by one. Repeat this step as necessary.

4. When you have completed selecting an image file, hold the ‘RUN’ button to confirm your selection.

7.5 Delete Image File

DEL IMG FILE is used for deleting an image file that has been saved to a Storage Center.

SETUP >[000] DEL IMG FILE

To delete an image file:

1. From the SETUP menu, tap the ‘SET’ button to navigate to the DEL IMG FILE option.

2. Tap the ‘RUN’ button. The duplicator will ask you to input the name of the image file you want to delete. a) The file name consists of three digits. The digit furthest to the right will be blinking, indicating

that it is currently selected. Tap the ‘RUN’ button to increase the digit by one.

b) Tap the ‘SET’ button to select the next digit to the left. Tap the ‘RUN’ button to increase the

digit by one. Repeat this step as necessary.

3. When you have completed entering the name of the image file, hold the ‘RUN’ button to delete the image file.

Note: If the screen displays the following message, “NO FILE_SYS IN SRC” then there is no data saved to the image file that you selected.

Format Source

7.6 Format Source

The FORMAT SOURCE operation allows you to format a hard drive as a Storage Center. Storage Centers can be used to store hard drive images for convenient access to your most commonly used Source files. For more information on using a Storage Center see section 5.2 Duplicating From a Storage Center on page 15.

To format a hard drive as a Storage Center:

1. Connect the hard drive you want to format as a Storage Center to the side of the duplicator labaled “SOURCE”.

2. In the Advanced Setup menu, navigate to FORMAT SOURCE and then tap the ‘RUN’ button to format the hard drive.

3. You will receive a message asking you to confirm formatting the drive. Ta p the ‘RUN’ button to proceed or tap the ‘SET’ button to cancel.

Caution! Formatting the hard drive will erase any data stored on the hard drive.

Once the format has completed you will receive a message confirming that the format was successful.

Advanced Setup Menu / Device Info

8. ADVANCED SETUP MENU

The ADVANCED SETUP menu provides you with extra options and operations for the advanced user. The ADVANCED SETUP menu can be accessed through the SETUP menu. From the SETUP menu, tap the ‘SET’ button to navigate to the ADVANCED SETUP option and then tap the ‘RUN’ button to enter the ADVANCED SETUP menu.

Once you have entered the ADVANCED SETUP menu:

• Tap the ‘SET’ button to navigate the different menu options.

• Tap the ‘RUN’ button to change an option’s setting.

• Hold the ‘SET’ button to return to the SETUP MENU

8.1 Device Info

DEVICE INFO allows you to view information about any hard drives currently connected to the duplicator.

To view device information:

1. From the ADVANCED SETUP menu, tap the ‘SET’ button to navigate to the DEVICE INFO function.

2. Tap the ‘RUN’ button to begin viewing the device information. Once the connected hard drives have been initialized you will see the following:

Number of sectors

UDMA mode supported /

Source [S] or Target [T] drive

UDMA mode followed

[ S]1250263728 (6/5) WDC WD6402AAEX-00Z3A

3. Tap the ‘SET’ button to view information about the next device.

4. After you have viewed all devices you will automatically return to the ADVANCED SETUP menu. You can also hold the ‘SET’ button to exit to the ADVANCED SETUP menu at any time.

Hard drive model number

System Info / Set to Default

8.2 System Info

SYSTEM INFO allows you to view information regarding your duplicator’s firmware version and build.

To view the system information:

1. From the ADVANCED SETUP menu, tap the ‘SET’ button to navigate to the SYSTEM INFO function.

2. Tap the ‘RUN’ button to begin viewing the system’s information:

KANGURU HDD COPIER VER: 2.26 BLD:1011

3. Tap the ‘SET’ button to exit back to the ADVANCED SETUP menu.

8.3 Set to Default

SET TO DEFAULT allows you to restore all settings back to their factory default values.

To reset your duplicator to its original default configuration:

1. From the ADVANCED SETUP menu, tap the ‘SET’ button to navigate to the SET TO DEFAULT function.

2. Tap the ‘RUN’ button. The screen will display a message asking you to confirm the reset. Tap the ‘RUN’ button to confirm, or tap the ‘SET’ button to cancel.

ARE YOU SURE? SET->NO RUN->YES

3. Once the reset has been completed, you will be displayed a confirmation message on the screen. Press any button to return to the ADVANCED SETUP menu.

HPA Check / No Capacity Check / Max UDMA Mode

8.4 HPA Check

The Host Protected Area (HPA), sometimes referred to as the Hidden Protected Area, is a partition on the hard drive that is not normally visible to an operating system. Tap the ‘RUN’ button to change this option’s setting.

• [ ] – HPA Check is disabled (default). The system will not check for HPA partitions.

• [ ٭ ] – HPA Check is enabled. When HPA CHECK is enabled the duplicator will support Host

Protection Areas. When you duplicate a Master HDD that contains HPA, the system will detect the HPA partition, unlock it, copy the area and then re-lock the area once duplication is complete.

8.5 No Capacity Check

The duplicator has a built in capacity check function which will check the capacity of the Master hard drive and the Target hard drive(s) during Full or Brief copy processes and determine whether the drives’ capacities are the same.

Tap the ‘RUN’ button to change this option’s setting.

• [ ] – No Capacity Check is disabled (default). When a Full or Brief copy process is executed the system will check the capacity between the Master and Target hard drive(s) to determine whether the capacity is the same. If the capacity is different the copy process will be cancelled.

• [ ٭ ] – No Capacity Check is enabled. When a Full or Brief copy process is executed the system will not check the capacity between the Master and Target hard drive and start the copy process as normal.

8.6 Max UDMA Mode

The MAX UDMA MODE option allows you to configure the maximum transfer speed allowed. Tap the ‘RUN’ button to change this option. The MAX UDMA MODE can be set as 0 – 5. The MAX UDMA MODE is set to 5 by default.

Skip Read Error / Load Full Image / Total Copy Count

8.7 Skip Read Error

The SKIP READ ERROR option allows you to enable or disable error skipping during FULL, BRIEF and RESIZE modes. Tap the ‘RUN’ button to change this option.

• [ ] – Disabled (default). When an error is detected while reading from the Source, the duplicator will cancel the current process.

• [ ٭ ] – Enabled. When an error is detected while reading from the Source, the duplicator will skip the bad sector on the Source and fill it with a zero on the Target.

8.8 Load Full Image

The LOAD FULL IMAGE option allows you to control how image files are saved to a Storage Center during a Load operation (see section 6.4 Load on page 21). Tap the ‘RUN’ button to change this option.

• [ ] – Disabled (default). The system will analyze the Source’s file system before building the image. If the Source’s file system is recognized as FAT/ NTFS/ EXT1/ 2/ 3/ 4, the image will be a Brief image based on the file system and data area. If the Source’s file system is unrecognized the image will be a Full sector by sector image.

• [ ٭ ] – Enabled. When executing a Load process, the system will not analyze the Source’s file system and will automatically build a Full sector by sector image.

8.9 Total Copy Count

TOTAL COPY COUNT keeps track of the total number of successful and unsuccessful duplications produced by the system. This is a running count that includes all copy modes. Tap the ‘RUN’ button to view the total copy count.

Update Firmware

8.10 Update Firmware

The UPDATE FIRMWARE function allows you to upgrade your Kanguru Hard Drive Duplicator to the latest firmware version.

Warning! Do not attempt to update your duplicator’s firmware unless specifically instructed to do so by a Kanguru Technician.

To update your firmware:

1. Contact Kanguru Technical Support at 508-376-4245 to receive a firmware update file.

2. Format a SATA hard drive as FAT32.

3. Copy the firmware file to the hard drive.

4. Connect the hard drive to the duplicator’s Source port.

5. From the ADVANCED SETUP menu, tap the ‘SET’ button to navigate to UPDATE FIRMWARE and then tap the ‘RUN’ button.

6. Once the system has confirmed the firmware file, a message will be displayed on the screen asking you to confirm the firmware update. Tap the ‘RUN’ button to proceed or tap the ‘SET’ button to cancel.

7. Wait for the firmware update process to complete.

8. Once the firmware update process has completed, reboot your system and the new firmware version and build number will be displayed on the startup screen.

Warning! Do not disconnect power or turn off the duplicator while updating the firmware. Doing so may cause the duplicator to become non-functional.

Error Code List / FAQ

9. ERROR CODE LIST

The Error Code List can give you some information to help you understand any problems that occur during duplication.

Error Code Problem

S Source read error R Target read error

W Target write error

D Timeout error C Compare error

F Skip read error

10. FAQ

Q: Do Target hard drives have to be the same capacity as the Master? Same Brand? A: If you select Full copy or Brief copy, the Target hard drive should be the same capacity as the

Master hard drive. The hard drive brand is not important but capacity must be identical.

Q: Can I clone a smaller capacity Master drive to larger capacity Target drives? A: Yes, use the RESIZE operation to clone a smaller capacity Master to larger capacity Targets.

Q: Can drives with different RPM speeds be cloned together? A: Yes, the machine will adjust to hard drives with different RPMs.

Q: How does the duplicator handle multiple partitions on the Master drive? A: The machine will auto-detect how many partitions in the source hard drive and then copy it, but

you are unable to select a specific partition to copy.

Q: How does the duplicator handle multiple partitions of varying formats on the Master drive? A: The machine will analyze the File System of the Master drive before it begins cloning.

Q: Can the duplicator clone operating systems such as UNIX and OS/2? A: Yes, use the Full copy operation to copy any operating system.

Q: Can the duplicator defragment a partition? A: No, this must be done directly by the operating system of your PC.

Q: Can the Duplicator copy Encrypted HDD’s? A: The KanguruClone is able to copy a limited number of encrypted HDD types through Full copy.

Troubleshooting

11. TROUBLESHOOTING

Problem Possible Cause Solution

The KanguruClone will not start or there is no display on the LCD screen.

The KanguruClone cannot make copies of a Master hard drive.

The power cable is damaged or not connected securely.

The voltage of the outlet the KanguruClone is plugged into does not match the KanguruClone.

The hard drive is not connected or was not detected by the Kanguru Clone.

The cables connecting the hard drive are not connected securely.

The hard drive jumpers are not set in the correct position.

The hard drive may be faulty.

Make sure that the power cable is not damaged and is not loose.

Make sure that the voltage of the outlet matches the voltage of the KanguruClone.

Make sure that all connected hard drives have been successfully detected by the KanguruClone.

Make sure that no hard drive connection cables are loose.

Make sure that all the hard drive jumpers are set to the Master or Cable Select position.

Make sure that the Master hard drive is not broken and does not have errors.

The KanguruClone is unstable or operates very slowly.

The hard drive’s format is not supported by Brief Copy or Resize Copy.

The hard drive contains a Host Protected Area.

The data cables from the KanguruClone to the hard drives are not connected securely.

A hard drive may have an error that is affecting the other hard drives, causing slow operation.

The cables do not meet the UDMA standards.

When executing a Brief Copy or Resize Copy, make sure that the format of the Master hard drive is supported.

Enable the HPA CHECK option under the Advanced Setup menu.

Make sure that none of the data or power cables are loose.

Try to identify the faulty hard drive and replace as needed.

Only use the cables provided by Kanguru Solutions with the KanguruClone.

Warranty Information

12. WARRANTY INFORMATION

This product carries a 1 year* limited warranty on the power supply, controller, and all internal components. The warranty does not cover any IDE, SATA, or Power cables. Kanguru Solutions is not responsible for any damages incurred in the shipping process. Any claims for loss or damage must be made to carrier directly. Claims for shipping errors should be reported to Kanguru Solutions within three (3) working days of receipt of merchandise. Please refer to the RMA Procedure section of this manual if your duplicator needs servicing.

*1-year warranty on labor. After 1-year, a $30.00 service charge will be applied to all duplicator RMAs. Shipping back to the customer is covered during the first year of purchase. After 1 year the customer is responsible for shipping both ways.

Kanguru Solutions does not offer money back returns on its duplicator product lines due to the unique nature of the product. All units will be fully supported under manufacturer’s and/or extended warranty plans.

Technical Support

13. TECHNICAL SUPPORT

If you experience any problems using your Kanguru product or have any technical questions regarding any of our products, please call our tech support department. Our tech support is free and available Monday thru Friday, 9am to 5pm EST.

Call 1-508-376-4245

Or visit our website at www.Kanguru.com

RMA Procedure

STEP ONE: Call for a RMA Number: 508-376-4245

Duplicators will not be accepted for repair without a valid RMA number. RMA numbers are valid for 30 days upon assignment. Any return without a valid RMA number will be returned to the customer at their expense.

STEP TWO: Ship and Insure your Duplicator

Kanguru Solutions strongly recommends you fully insure the duplicator for shipping. Kanguru Solutions is not responsible for if the package is lost or damaged in transit. We suggest using a shipping company that utilizes a “tracking” feature to verify “proof of delivery.” The customer is responsible for shipping charges when returning a product. Shipping back to the customer is covered by Kanguru Solutions during the first year of purchase. After 1 year of purchase the customer is responsible for shipping both ways.

Kanguru Solutions 1360 Main Street Millis, MA 02054

www.kanguru.com

Legal terms and conditions available at www.kanguru.com. Please review and agree before use. Thank you.

Kanguru Mobile Clone 1HD Duplicator User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
