User’s Manual
Table of Contents
1. Introduction
1.1 About the KanguruMicro MP3 --------------------------------------------------2
1.2 Features -----------------------------------------------------------------------------3
2. How to use KanguruMicro MP3 player
2.1 Mechanical parts------------------------------------------------------------------4
2.2 How to install replacement battery--------------------------------------------4
2.3 Function-----------------------------------------------------------------------------5
3. How to Install / Modify / Repair / Remove driver
3.1 Windows 98 / 98SE Installation ----------------------------------------------- 10
3.2 Modify or Repair driver for Windows 98 / 98SE---------------------------- 12
3.3 Remove driver from Windows 98 / 98SE------------------------------------ 14
3.4 Windows 2000 / ME / XP Installation----------------------------------------- 16
4. Removing the KanguruMicro MP3 --------------------------------------------------16
5. Linux 2.4.0 + / Mac 8.6 + Installation -----------------------------------------------16
IMPORTANT NOTICES
----------------------------------------------------------------------17
1
Important Notice:
Some computers may have a small power leakage from the USB port. To
avoid any direct damage caused to KanguruMicro MP3, we suggest you
use the extension cable, USB hub, or docking station to connect the
KanguruMicro MP3 to your computer. Do not plug the KanguruMicro MP3
directly into the computer.
1. Introduction
1.1 About the KanguruMicro MP3
Palm Sized MP3 Player PLUS Portable Storage!
The KanguruMicro MP3 is a portable USB flash drive AND MP3 Player rolled
into one! Store and play all your favorite music as well as any other files you need
while on the go. It plugs directly into a USB port, working with Windows,
Macintosh and Linux, and is driverless with most Operating Systems.
2
1.2 Features
- Supports MP3 music format
- Earphone jack: 2.5 mm
-
Universal Headphone adapter
- Audio output: 5mW+5mW
- Output frequency range: 20HZ – 20KHZ
- Battery: Lithium-ION 500mA 3.7V
-
Battery Life: 7.5 hours of continuous use at full charge
- Support USB specification revision 1.1
- Transferring rate: up to 12MB per second at “Full Speed”.
- Power saving mode to reduce power consumption while unit is idle.
- Supported by Windows 2000, ME, XP, Mac OS 8.6 or above and Linux 2.4.0 or
above without device driver.
- Supported by Windows 98/98SE with device driver.
- Power LED: (i) Plug KanguruMicro MP3 into USB port to re-charge battery
through computer. Orange LED light means the battery is
charging.
(ii) Green LED light indicates the battery is fully charged.
- Play LED: (i) Red LED indicates you are in MP3 player mode.
(ii) Red LED flashes quickly when no MP3 files are found.
(iii) Red LED flashes slowly when you pause MP3 player.
(iv) Green LED indicates you are in USB removable disk mode.
(v) Green LED blinks when you are reading/writing.
- Write / delete protection switch.
- Hot Plug & Play - Enables you to install KanguruMicro MP3 at anytime.
- Durable solid-state storage – data retention for at least 10 years.
-
Erase Cycles: 1,000,000 times
- No external power is required - DC 4.5V ~ 5.5V from USB port.
- Low Power consumption：Write 39.1mA ~ 39.4mA / Read 35.0mA ~ 36.1mA.
- Read/Write Speed of USB interface: Read 800KB / Write 600KB
- Size: 91.2 x 30.4 x 26.3 mm
- Unit weight: 30g (not including battery)
-CE and FCC certificate of approval.
3
2. How to use KanguruMicro MP3 player
2.1 Mechanical parts
2.2 How to install a replacement battery
1. Remove battery cover by pressing two sides.
2. Connect battery’s cord to the power port.
3. Put back battery cover.
4. Connect to USB port to fully charge battery for first time use.
4
2.3 Function: MP3 player mode
1. The MP3 function is enabled when the earphones plugged in.
(Earphone port is 2.5mm)
5
2. Press the Control Switch button once: Play / Pause
Slide to right side and hold to increase the volume.
3.
Slide to left side and hold to lower the volume.
Volume raise Volume down
6
4. Quick pull to right side: next song
p
Quick pull to left side: previous song
revious song
next song
5. Power LED: (i) Plug KanguruMicro MP3 into USB port to re-charge battery
through computer. Orange LED light indicates battery is charging.
(ii) Green LED light indicates battery is fully charged.
Power LED
7
6. Play LED: (i) Red LED light indicates you are in MP3 player mode.
(ii) Red LED light flashes quickly when no MP3 files are found.
(iii) Red LED flashes slowly when you pause MP3 player.
(iv) Green LED indicates you are in USB removable disk mode.
(v) Green LED blinks when you are reading/writing.
Play LED
7. Read/Write protection
8
7. To charge battery: plug the unit into a USB port of notebook or desktop computer.
For best results, please charge at least 1 hour and 45 minutes.
9
3. How to Install / Modify / Repair / Remove driver
3.1 Windows 98/98SE Installation：
(1) Go to CD or floppy disk driver in “My Computer.”
(2) Execute “Setup.exe” by double click on the icon.
(3) Follow the instructions and click “Next”.
10
(4) System will install all the necessary files into your Windows operating system.
After setup installation completed, click “OK” to restart computer.
Once the installation has finished completely, you can see a “Removable Disk”
in “My Computer” when you plug in the KanguruMicro MP3.
11
3.2 Modify or repair driver for Win 98 / Win 98 SE
(1) If you have previously installed the drivers you will see the following screen
after executing the “Setup.exe” file again. If somehow the driver is damaged,
you can select “Repair” to fix the corrupted files.
Select “Modify” or “Repair” and then click “Next”.
(2) Select all files and click “Next”.
12
(3) Click “Finish” to complete modification.
13
3.3 Remove driver from Win 98 / Win 98 SE
(1) To remove the driver from your operating system. Execute the “Setup.exe” file
from CD driver disk again. Select “Remove” and click “Next”.
(2) System will then ask you to confirm deletion. Click “OK”.
(3) This screen may or may not appear. If your system asks you to confirm the files for
deletion just click “Yes”.
14
(4) Click “Finish” to complete the process of removing device driver from your
system.
15
3.4 Windows ME / Windows 2000 / XP Installation
For these three operating systems NO Driver is needed, because Windows has
built-in driver to support USB removable disk. Simply plug the KanguruMicro MP3
into the USB port and it will be recognized by the system.
Once installation has completed, you will see a “Removable Disk” drive in My
Computer.
4 Removing the KanguruMicro MP3
After using the KanguruMicro MP3, please choose one of the methods below
according to your Operating System to remove the unit from the USB port:
Windows 98/98SE：You can unplug the KanguruMicro MP3 from the USB port
directly once the LED stops blinking and its icon will disappear automatically.
Windows Me/2000/XP：Click the icon of the KanguruMicro MP3 in the task bar, and
a “Stop USB Mass Storage Device-Drive (H:)” menu appears (Fig.2.6.1). Click the
menu, and the below window appears telling you “the ‘USB Mass Storage Device’
device can be safely removed from the system”. Click “OK” to close the window
(Fig.2.6.2), then you can safely remove the KanguruMicro MP3.
Fig.2.6.1
Fig.2.6.2
16
5 Linux 2.4.0 + / Mac 8.6 + Installation
Again, No Driver is required for these two operating systems. Simply plug the
KanguruMicro MP3into the USB port and the system will automatically find the
KanguruMicro MP3. After using the KanguruMicro MP3, you can unplug the unit
from the USB port directly once the LED stops blinking, and then its icon will
disappear automatically.
For Linux user, please refer to Important Notices.
Important Notices
：
(i) In Windows 98/98SE, run the setup.exe first, without the unit plug in.
Installing the device while it’s plugged in may cause driver files to become
corrupted.
(ii) If you plug the KanguruMicro MP3 into the USB port and your system finds
the KanguruMicro MP3, but you are unable to access it. Please FORMAT
the KanguruMicro MP3.
(iii) Before unplugging the KanguruMicro MP3 from the USB port in Windows
ME/2000/XP
taskbar to stop the device. Otherwise, it may result in losing data that
you have saved on the KanguruMicro MP3. (Please refer to 2.6.)
(iv) Linux uses a so-called "USB Manager", which automatically loads kernel
modules (drivers) for USB devices. It loads only drivers for devices that
are present on the USB bus to reduce memory usage. Per default, the
USB Manager does not come with the USB Drive pre-configured.
However, you can easily configure the USB Manager to automatically
recognize the USB Drive yourself. Just add the following to the
configuration file,
usbmgr.conf (usually in /etc/usbmgr): vendor 0xd7d product 0x100
module scsi_mod, usb-storage
, make sure you go to the remove icon (green arrow) in the
This line identifies the USB Drive and tells the USB Manager to load the
SCSI as well as the USB storage module. The SCSI module is needed in
order to talk to both SCSI and USB storage devices, while the usb-storage
module is needed to talk to USB storage devices.
Do not forget to either reload the USB Manager's configuration or to restart the
USB Manager (for instance, do as root: /etc/init.d/usbmgr reload).
17
Warranty:
This product carries a 1-year limited warranty from the date of purchase.
- 1 Year for the Flash Memory
- 6 months for the lithium battery.
- 90 days labor
Tech Support
If you experience any problems installing your KanguruMicro MP3 or have any
technical questions regarding any of our products, please call our tech support
department. Our tech support is free and available Monday thru Friday, 9am to 5pm
EST.
Call 1-508-663-0105 or
Visit our website at www.KanguruSolutions.com
