USER MANUAL
KMLSP150W
I n d e x
Summarize ......................................................................... 3
Product introduction .......................................................... 3
Safety instruction ............................................................... 4
Installation instruction........................................................ 5
Main function ..................................................................... 6
Display operation instruction............................................... 7
Menu instruction ................................................................. 9
DMX controller function ......................................................16
XRL connection instruction .................................................20
Wiring diagram ..................................................................21
Problem analyze.................................................................22
Maintenance.......................................................................23
Technical’s specification…………….……………………….. .………24
Summarize
Thank you for purchasing our LED Moving lighting. Please read these instructions
carefully before begin
avoid any possible damages and
and operate the fixtures according to these instructions to
accidents causes by misusage.
Product introduction
This light uses Kandolite KMLSP150w LED light source
reaches 6200lm.
traditional moving head (with
It has
50000-100000hours life span. Compared with
Gas discharge light bubble
weight, energy-saving and long life span. The rotation angle is Pan 540°, tilt 270°.
It has the functions of auto reset and correction and 16bit fine adjustment. The
configuration includes: 2 gobo wheels, 2 color wheels, iris, zoom, focus, prism and
Atomization. International standard DMX 512 signal is requested. The
combination of DMX512 and DMX Ethernet network is optional
. The output luminous flux
), it is
featured by light
Packing list
• KMLSP150W 1PC
• Clamp hanger 2pcs
• Quick release lock 4set
• Safety cable 1pc
• Power cable
• user manual
Page 3 of 26
Safety instruction
• Please open the carton and check whether there is any damage at the arrival
of the fixture. If there is any damage caused by transportation, please do
not use the fixture and contact the distributor or manufacturer as soon as
possible.
• Make sure the power supply voltages are consistent with this lights，Ensure
the use of voltage is in the range of the request technical parameter.
• Before the installation, please check the light’s fasteners and mechanical
structure have been received in good condition and appear no damage.
• This light is designed for indoor use. The protection rate is IP20. The
fixture should be kept dry from water and other liquids. Do not use it in a
humid, overheated and dusty environment. The
lower than 50 degree.
• The fixtures maybe mounted in any position provided there is adequate
room for ventilation. Make sure there are no inflammable and explosive
items (ornaments) in 0.5 meters away. Do not project the light on
flammable materials. The distance between the fixture and lighting
object should be more than 5m.
• Do not open the fixture to repair by yourself.
•
Ensure safe grounding of Yellow / green cable and install electricity
according to relative standards. Don’t shake the fixture when it is working.
• Only qualified personnel can do electricity connection.
• Please do not connect the fixture with any other dimming devices.
working
temperature is
• Please do not use power cable with incomplete insulation and don’t
connect the power cable with other wires. When the fixture is not in use
or in cleaning, please make sure to turn off the power.
Page 4 of 26
If you have any questions or suggestions, please contact the distributor or manufacturer
promptly.
Installation instruction
Dimension diagram
Clamp
Release lock
Handle
Page 5 of 26
For Safey wire
Instruction for changing interchangeable gobos
Fixed gobos
Wheels gobo wheels
Color wheel 1 color wheel 2
Page 6 of 26
Main function
150W high brightness LED
2 gobo wheels, 2 color wheels, iris, zoom, focus, prism and Atomization
Accord with DMX512 protocol. Wireless DMX and DMX Ethernet network is
optional.
The color wheel can reach any position
2 DMX channel modes
Multi strobe effect, 5 dimmer modes
Sound control, auto run
Master-slave mode: no need to set slave manually; the slave will receive
data from master automatically
The fixture parameter can be downloaded mutually
When the fan is not working, the LED won’t light up
Page 7 of 26
Display Operation
MENU : access the menu or return to a previous menu option
ENTER : select the current menu option
UP : menu selection or parameter increments
DOWN : menu selection or parameters decrease
Page 8 of 26
