Suits all KHT331 modelsINSTRUCTION BOOKLET
Important
Please retain your instruction
book for future use.
In the event that you need some assistance with your
Kambrook appliance, please contact our Customer Service
Department on 1300 139 798 (Australia) or 0800 273 845
(New Zealand). Alternatively, visit us on our website at
www.kambrook.com.au or www.kambrook.co.nz
Contents
Kambrook Recommends
Safety First
Your Kambrook Day Dreamer
Reversible Heated Throw
Using Your Kambrook
Heated Throw
Care, Cleaning and Storage p10
p4
p6
p8
Kambrook Recommends Safety First
IMPORTANT: Please retain your
instruction book for future use.
At Kambrook, we believe that safe performance is the first priority in any
consumer product, so that you, our valued customer can confidently
use and trust our products. We ask that any electrical appliance that
you use be operated in a sensible fashion with due care and attention
placed on the following important operating instructions.
Important Safeguards For Your Kambrook
Day Dreamer Reversible Heated Throw
• Carefully read all instructions before
operating the Kambrook heated throw and
save for future reference.
• Remove any packaging material and
promotional stickers before using the
Kambrook heated throw for the first time.
• Use the heated throw only with the
detachable controller CTL151 supplied. Refer
to the markings on the heating unit for the
model number of the controller.
• Connect only to 230V or 240V power outlet.
• Do not pull the heated throw by the
flexible cord or use the cord to carry the
heated throw.
• Do not attempt to expose the internal wires.
• Extended application at the HIGH heat
setting may result in skin irritation or burns.
• Do not use on areas of sensitive skin or areas
insensitive to heat.
• Do not use the heated throw with an
incapacitated person, an infant or a person
insensitive to heat.
• Children under the age of three are not to
use this heat throw due to their inability to
react to overheating.
• The heated throw is not to be used on or by
an invalid, a sleeping or unconscious person,
or a person with poor blood circulation
unless carefully attended.
• This heated throw is to be used as a
wrap only.
• This heated throw is not an electric blanket or
an under blanket.
4
• This heated throw is not intended for medical
use in hospitals.
• This heated throw is for household use only.
• Do not use this heated throw for anything
other than its intended use.
Do not use outdoors.
• Avoid s harp objects. Do not insert pins or any
sharp objects into the heated throw as they
may damage the electrical wiring.
• Do not use the heated throw in a folded,
rucked or rolled state.
• Do not use with wires tucked in.
• Do not sit on, crease or crush the
heated throw.
• Do not use the heated throw if it is wet or
moi st.
• Do not use under clothing, wraps or blankets.
• Do not use the heated throw as an electric
blanket. It is not designed for all-night use.
• This heated throw must not be used over a
water bed.
• If any abnormality or defect in operation of
this heated throw is observed, discontinue
its use immediately and contact Kambrook
Service Centre.
• Do not fall asleep when using the heated
throw. This product is not intended for use
while sleeping.
• Do not use the heated throw for animal
or pet care.
• Switch the heated throw control to the ‘OFF’
position, switch off at the power outlet and
remove the plug from the power outlet when
the heated throw is not in use and before
storing.
• Do not dry clean the heated throw. Dry
cleaning may have a detrimental effect on
the heated throw. Follow the instructions
in the Care, Cleaning and Storage section
when cleaning and storing the heated throw.
• Do not iron the heated throw.
• Do not bleach the heated throw.
• Regularly inspect the heated throw, power
supply cord, plug and controller for any
wear, damage or misuse. If signs of these
are detected, immediately cease use of the
heated throw and return the entire unit to
your nearest Kambrook Service Centre for
examination, replacement or repair.
• It is recommended that a qualified and
registered person inspect your heated throw
after each 3 years of use.
• When storing the heat throw, allow it to cool
down before folding.
• When storing, fold neatly but not tightly
(or roll) in the original packaging without
sharp bends in the heating element and
store where no other objects will be placed
upo n it.
• Do not place any items on top of the heated
throw when storing to avoid creasing.
• There are no customer ser viceable parts
inside. The heated throw is fit ted with a
specially designed controller and no attempt
should be made to repair it or to replace
the protective fuse. Have the heated throw
serviced only by a qualified ser vice agent at
your nearest Kambrook Service Centre.
Important Safeguards For All Electrical
Appliances
• Fully unwind the power cord before use.
• Connect only to a 230V or 240V power outlet.
• Do not let the power cord hang over the
edge of a bench or table, touch hot surfaces
or become knot ted.
• To protect against electric shock, do not
immerse the power cord, power plug or
appliance in water or any other liquid or
allow moisture to come in contact with
the part, unless it is recommended in the
cleaning instructions.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given super vision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• It is recommended to regularly inspect the
appliance. To avoid a hazard, do not use
the appliance if power cord, power plug or
appliance becomes damaged in any way.
Return the entire appliance to the nearest
authorised Kambrook Service Centre for
examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Kambrook Service Centre.
• This appliance is for household use only. Do
not use this appliance for anything other
than its intended use. Do not use in moving
vehicles or boats. Do not use outdoors.
Misuse may cause injury.
• The installation of a residual current device
(safety switch) is recommended to provide
additional safety protection when using
electrical appliances. It is advisable
that a safety switch with a rated res idual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
• Always turn the appliance to the OFF
position, switch off at the power outlet
and unplug at the power outlet when the
appliance is not in u se.
• Before cleaning, always turn the appliance
to the OFF position, switch of f at the power
outlet, unplug at the power outlet and
remove the power cord, if detachable, from
the appliance and allow all parts to cool.
• Do not place this appliance on or near
a heat source, such as hot plate, oven or
heaters.
• Position the appliance at a minimum
distance of 20cm away from walls, curtains
and other heat or steam sensitive materials
and provide adequate space above and on
all sides for air circulation.
5
Your Kambrook Day Dreamer Reversible
Heated Throw
Heated Throw:
1. Heated throw dimensions
approx. 1300 x 1600mm (WxL)
6
Controller:
2. Detachable controller
3. Power/ Heat Setting button:
Press button to turn the throw
on/off and adjust between three
heat settings
4. HIGH heat with Green colour LED
indicator
5. MEDIUM heat with Blue colour
LED indicator
6. LOW heat with Orange colour
LED indicator
7. Auto-Off with Red colour
indicator: After three hours the
heated throw will automatically
turn off
8. Controller connector:
Found attached to the
heated throw and fits to the
controller plug (see 9.)
9. Controller plug with locking clips:
Found at one end of the power
cord and plugged into the
controller connector on the
throw when in use
10. 1.8m power cord
Not Shown:
• Reversible Heated Throw
Material: Microplush on one
side / Sherpa on the other side
• Flexible heating wire
• Safety overheat protection
• Reusable poly bag:
Ideal for storing the heated
throw and controller when
not in use
7
Using Your Kambrook Heated Throw
Before First Use
Remove any promotional material
and packaging from the heated
throw.
The poly bag is reusable and can be
kept for safely storing the throw when
it is not in use.
The controller can be found
unattached and wrapped inside the
throw.
NOTE: The heated throw is
designed to be reversible. Heat
will generate equally from either
side of the throw.
To Connect The Controller
The heated throw has a detachable
controller which allows the throw to
be machine washable.
Ensure the heated throw Power/Heat
Setting button is in the ‘OFF’ position
and not pressed.
Ensure the heated throw is not
connected to a 230V or 240V power
supply.
To connect your controller, insert
the controller plug found at the end
of the power cord to the controller
connector on the throw.
Ensure that the plug is securely
fastened in the socket so that the
locking clips are fully inserted and
there is no gap between the plug
and socket
(See Fig. 1).
Fig. 1
To Detach The Controller
Press and hold down the locking clips
(See Fig. 2).
Fig. 2
Pull the controller plug out of the
controller connector to detach.
8
Turning On The Heated Throw
Ensure the heated throw Power/Heat
Setting button is in the ‘OFF’ position
and not pressed.
Plug the power cord into a 230V or
240V power outlet and switch the
power on.
Press the Power/Heat Setting button
once to turn the heated throw ‘ON’.
Adjusting The Heat
Temperature
The three heat settings allow you to
choose the right balance of heat
depending on your personal comfort.
Adjust the heat temperature by
pressing the Power/Heat Setting
button until the desired indicator light
illuminates:
LOW Heat Setting
Press the Power/Heat Setting button
once and the Orange coloured LED
indicator will illuminate.
MEDIUM Heat Setting
Press the Power/Heat Setting button
twice and the Blue coloured LED
indicator will illuminate.
HIGH Heat Setting
Press the Power/Heat Setting button
three times and the Green coloured
LED indicator will illuminate.
NOTE: The heated throw will take
40 minutes to reach the desired
setting temperature, however
you will start feeling warm after
15-20 minutes.
Auto-Off Protection
For added safety, the heated throw is
designed with auto-off protection.
After three hours the heated throw
will automatically turn off and the Red
coloured auto off LED indicator will
illuminate and "flash".
To stop the auto-off LED indicator from
"flashing" and to continue using the
heated throw, press the Power/Heat
setting button once to turn the throw
‘ON’ again.
Set the heat temperature according
to your heat preference. The throw is
now ready for another three hours of
use.
Turning Off The Heated Throw
Press the Power/Heat Setting button
until none of the heat setting indicator
lights are illuminated. The heated
throw is now in the ‘OFF’ position.
Switch off at the power supply and
unplug the power cord from the
power outlet.
NOTE: For added safety, after
three hours the heated throw
automatically switches off.
NOTE: Do not leave the heated
throw in contact with the
skin for excessive periods of
time. For continuous use, it is
recommended that the LOW
Heat Setting should be used.
9
Care, Cleaning and Storage
Do not dry clean. Do not iron. Use only
the following instructions.
Before cleaning, ensure that the
controller is unplugged from the
power supply and that the controller is
disconnected from the heated throw.
Spot Cleaning
Sponge the affected area using
a lukewarm neutral detergent or
mild soapy solution. Follow this with
sponging, using a clean water
solution. Remove any excess water by
compressing the wet area between
absorbent towels.
Hand Washing
Immerse the heated throw with
controllers removed in a soapy
solution of lukewarm water and mild,
neutral detergent.
Soak for five minutes then gently
squeeze the solution through the
throw.
Rinse thoroughly in clean, lukewarm
water, then gently squeeze any
excess water from the heated throw.
WARNING: The controller
must be removed from
the heated throw before
washing.
Machine Washing
The heated throw can be washed
in a domestic washing machine
(size permitting) or by a commercial
laundry.
To wash your throw in a domestic
washing machine, wash on the WOOL
or DELICATES setting using a neutral
wool detergent or mild soapy solution.
DO NOT wash on a HOT cycle, the
temperature must be kept below
30˚C.
Do NOT use high speed or extra spin
cycles.
Do NOT machine wash with the
controller connected to the throw.
Drying
Drape the heated throw across a
clothes line and drip dry.
DO NOT use pegs to secure the
heated throw in position.
DO NOT dry with a hair dryer or
heater.
DO NOT twist or wring dry.
DO NOT tumble dry the heated
throw as it may damage the internal
heating wires.
DO NOT use moth ball or sprays.
10
WARNING: Never
immerse the detachable
controller in water or any
other liquid.
WARNING: DO NOT
tumble dry.
Storage
Pack the heated throw in its original
poly bag packaging for best
protection.
When storing the heated throw, allow
it to cool down before folding.
DO NOT store the heated throw when
wet.
Detach the controller from the throw
before storing.
When storing, roll neatly but not tightly
in the poly bag without sharp bends in
the heating wires.
Place the detachable controller on
top of the rolled throw before zipping
the bag closed.
Store in a cool, clean and dry
location.
DO NOT place any items on top of the
heated throw when storing to avoid
creasing.
11
Loading...
