Snugasabug
Fan Heaters
Due to continual improvement in design or otherwise, the product you purchase may differ slightly from the illustrations in this book. Issue 1/06
KFH35/36 Issue 1/06
Know your Kambrook Snugasabug Fan Heater
1
1. Thermostat control
2. 2 heat settings plus fan only
3. Thermo Guard pr
4. On/Off Neon indicator
5
4
3
6
otected
2
1
7
3
6
5. Carry handle
6. Safety tip-over cut-out switch
7. Oscillating function s
KAMBROOK SAFETY
Congratulations on your choice of
another quality Kambrook product.
Your Kambrook Snugasabug Fan Heater
has been designed and manufactured to
4
2
5
7
witch (KFH36)
high standards of engineering.With proper
use and care, you can expect to receive
many years of trouble free service. Please
read these instructions carefully.
GENERAL CARE AND SAFETY
GUIDE
Before using your fan heater, please read
the following instructions carefully and
retain for future reference.
Important safeguards
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electric shock and
injury to persons, including the following:
The heater is hot and consists of sparking
parts inside. Do not use in areas where
petrol, paints, aerosols or other flammable
substances are used or stored.
Do not touch hot surfaces.
Avoid touching heater body while it is
switched on as some parts of the heater
are very hot.When moving the heater,
switch off the unit and unplug at the
power outlet and hold the heater by
lifting it with the handle provided at the
back of the unit.
Keep combustible materials such as
drapes and other furnishings at least 1.7
metres from the front, sides and rear of
the heater. Do not use the heater to dry
your laundry.
WARNING: Do not cover the heater
in order to avoid overheating whilst it is
operating.
Do not use outdoors.
This heater is not intended for commercial
use, such as construction sites.
Do not locate the heater immediately
below a socket outlet when in use.
Do not locate the heater with a
programmer, timer or any other device
that switches the heater on automatically.
Fire risk exists if the heater is covered or
positioned incorrectly.This heater is not
intended for use in wet or moist
locations. Do not use this heater in the
immediate sur
shower, a laundry area or a swimming
pool. Do not immerse or allow liquids
to be spilt on the heater.
Switch off the unit and then unplug from
the power outlet.Allow the heater to
cool down before cleaning or storing.
Use this heater only as described in this
instruction manual.Any other use not
recommended by the manufacturer may
cause fire, electric shock or injury and
voids all warranties.
Do not allow materials that have been
in contact with oil, petroleum based
products or drying fluids to come in
contact with the heater.
Do not operate the heater with the cord
wound around any part of the heater, or
in contact with heated surfaces of the
heater.
roundings of a bath, a
21
Do not run the cord under carpeting or
cover the cord with rugs, runners or the
like.Arrange the cord away from traffic
areas and where it will not be tripped
over.
Do not insert or allow foreign objects to
pass through the inlet or outlet openings,
this may cause an electric shock. Or it
may cause fire or damage to the heater.
To prevent possible fire, allow ample space
around the heater (at least 1.7 metres at
the front and 0.5 metres at the rear, top
and sides) and do not block air inlets or
outlets in any manner. Check the openings
from time to time for accumulated dust.
This appliance is not intended for use by
young children or infirm persons unless
they have been adequately supervised by
a responsible person to ensure that they
can use the appliance safely.
Young children should be supervised to
ensure that they do not play with the
appliance.
Important – this heater is intended for
floor use only. Do not mount on ceiling
or walls.
Do not leave the heater unattended.
Always switch off the heater at the
controls and at the power outlet when
not in use.
Regularly inspect the supply cord, plug,
control settings, air inlets and outlets and
main housing for any damage. If found
damaged in any way, immediately cease
use of the heater and return to
Kambrook or an authorised service agent
for inspection or repair.
The installation of a residual current
device (safety switch) is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.
OPERATING
INSTRUCTIONS
1. Remove the heater from its carton and
associated protective wrapping and
unwind the cord to its full length.
2. Place the heater on a firm level surface,
in a stable upright position.
3.Visually inspect the air inlet and outlets
to ensure no foreign material is blocking
these areas.
4. Make sure the right Selector control
knob is turned to the ‘off’ position.
5. Plug the cord into a 230-240V power
outlet.To avoid an electrical circuit
overload, be sure that no other appliances
are plugged into the same circuit with
your heater when you switch the unit on.
6. Control your heater with the right
selector knob, as follows:
The selector control knob has 4 settings:
‘Off’ shuts off both heater and fan
✾ Turns the fan on and provides cool air
only
• (Lo) Provides warm air with half heating
power
•• (Hi) Provides hot air with maximum
2400 watts of power
Note:There is a tip over switch located on the
base of the heater.When the heater tips over, it
will turn off automatically.
Thermostat Control
Turn the right selector control to the high
(••) temperature setting by turning the
knob clockwise.
Turn the left selector control to the
highest thermostat setting - 6.
Let the heater run until the desired room
temperature is achieved.Then turn the
knob clockwise until you hear a click
sound.The unit will stop.
At this setting, your heater will
automatically cycle on and off to maintain
the desired room temperature.
Do not operate heater whilst asleep.
Do not operate the heater with a
damaged cord or plug,
or if the heater has
been dropped or damaged in any manner.
Return the heater to your nearest service
centre for examination, electrical or
mechanical adjustment or repair.
Once the Thermostat is activated you can
simply turn the knob clockwise or anticlockwise in the thermostat function
section if you want to change the
.
temperatur
3
4
e
Oscillating function (applicable to the
KFH36 only)
Slide the oscillation switch located at the
bottom of the unit to I ‘on’ setting.The
heater will rotate providing warmth
throughout the room.
Thermoguard Overheating Safety
device
Your heater is fitted with a safety device
that switches off the heater in the event of
overheating. Should the heater stop
working, turn the heater off and inspect
for blockage of air inlet or outlet.Wait at
least 5 minutes for the protection system
to reset before attempting to restart the
heater.
If the heater fails to operate or the safety
device switches the heater off again, return
heater to your nearest service centre for
examination or repair.
Care and Maintenance
Always turn off and unplug the heater
before cleaning.
Use a clean dry cloth to clean the external
surfaces of the heater only.
If the heater has collected dust or dirt
inside the unit or around the element,
have the unit cleaned by a qualified service
agent. Do not operate the heater in this
condition.
Do not attempt to open the case of the
heater at any time; there are no customer
serviceable parts inside.
When not in use, pack the heater in its
original box for
Kambrook 12 Month
Replacement Warranty
KAMBROOK warrants the purchaser
against defects in workmanship and
material, for a period of 12 months from
the date of purchase (3 months
commercial use).
Guarantee and purchase receipt for this
product are to be retained as proof of
purchase and must be presented if making
a claim under the terms of the
KAMBROOK guarantee.
KAMBROOK reserves the right to
replace or repair the appliance within the
warranty period.
Warranty does not apply to any defect,
deterioration, loss, injury or damage
occasioned by, or as a result of the misuse
or abuse, negligent handling or if the
product has not been used in accordance
with the instructions.The guarantee
excludes breakages and consumable items
such as kneading blades.
This warranty is void if there is evidence
of the product being tampered with by
unauthorised persons.
If the product includes one or a number of
accessories only the defective accessory or
product will be replaced.
In the event of KAMBROOK choosing to
replace the appliance, the guarantee will
expire at the original date, ie. 12 months
from the original purchase date.
In Australia, this KAMBROOK Guarantee
is additional to the conditions and
guarantees which are mandatory as
implied by the Trade Practices Act 1974
and State and Territory legislation.
For service, spare parts or product
information in Australia, please call
KAMBROOK on the Customer Service
Line 1300 139 798.
For service, spare parts or product
information in New Zealand, please
call KAMBROOK New Zealand,
Private Bag 94411, Greenmount, Auckland
Phone 0800 273 845 Fax 0800 288 513.
For spare parts phone 0800 273 845.
If claiming under this guarantee the product
must be returned freight prepaid.
YOUR PURCHASE RECORD (Please complete)
Attach a copy of purchase
receipt here.
DATE OF PURCHASE______________________________________________________
MODEL NUMBER ________________________________________________________
SERIAL NUMBER (If a
pplicable)
PURCHASED FROM ______________________________________________________
